EASY EDUCATIONAL LITERATURE COMPREHENSION

Applying TermPedia to Information Retrieval Knowledge Domain

Proscovia Olango, Gosse Bouma

The Center for Language and Cognition Groningen, The University of Groningen

Oude Kijk in ’t Jatstraat 26, Groningen, The Netherlands

Henny Klein

Department of Information Science, The University of Groningen, Groningen, The Netherlands

Keywords:

Document enrichment, Term extraction, Term deﬁnition, Term disambiguation, Hyperlink generation, Docu-

ment comprehension, e-Learning.

Abstract:

This paper provides a detailed description of how TermPedia which is a document enrichment tool, is applied

to educational literature in order to help students easily understand their reading material. The paper assumes

that technical terms are one of the major hindrances to document content comprehension. TermPedia has the

ability to extract, deﬁne, and link technical terms to Wikipedia. It is expected that relevant term deﬁnitions

and explanations will ease the comprehension of educational documents by students and thereby improve their

reading speed and shorten the time they needed for knowledge acquisition.

1 INTRODUCTION

Easy document comprehension can be deﬁned as the

ability to read and understand the concepts discussed

in a document without spending much time and brain

effort. In cognitive science, comprehension is often

characterised as the construction of a mental model

that represents the objects and semantic relations de-

scribed in a text (Thuring et al., 1995). This implies

that if a reader spends little effort in the construction

process, then the document is easily comprehensible.

The ﬁeld of document comprehension is widely

studied with reference to reading levels indicating

that persons who are not reading at a college level

or higher, have a low reading level and therefore do

not clearly understand the concepts of the documents

they read (Young et al., 1990). These studies indicate

that education plays an important role in vocabulary

level building which in turn eases understanding of

semantically related documents.

As an implementation of research ﬁndings based

on reading levels, vocabularies (or technical terms)

that occur in documents are substituted with sim-

pler words or word phrases that have similar seman-

tics (Graves and Graves, 2003). If the substitution is

done without considering word context, this venture

may not only distort document content meaning but

also limit the possibility for students to build their vo-

cabulary level. By technical term we refer to anything

that is a word, a group of words, an acronym, or an ab-

breviation which designates a special meaning in text

context. Although the meaning of technical terms is

often clear from context (Kate, 2007), it is also true

that technical terms are often used without proper def-

inition. However, human languages more especially

English constantly change by borrowing, coining, and

combining words to represent new ideas, [technol-

ogy,] and development (Engineer, 2005). Thereby vo-

cabulary level building becomes a lifetime obligation.

In 2009 the verb twitter was

borrowed as trade mark of a

social network that provides

microblogging services, enabling

its users to send and read messages

called tweets.

The example above presents three technical terms

that were borrowed or coined in the recent years to ex-

press ideas related to Short Message Services (SMS)

and Internet technology. For a person who is not fa-

miliar with these technologies the semantics of the

terms twitter, and tweet may be conspicuously re-

427

Olango P., Bouma G. and Klein H..

EASY EDUCATIONAL LITERATURE COMPREHENSION - Applying TermPedia to Information Retrieval Knowledge Domain.

DOI: 10.5220/0003346504270432

In Proceedings of the 3rd International Conference on Computer Supported Education (CSEDU-2011), pages 427-432

ISBN: 978-989-8425-49-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

vealed by considering them in context. On the con-

trary the meaning of the term microblogging may not

be that obvious from this sentence context.

Technical terms occur in almost all reading ma-

terial especially those intended for an audience at

higher institutions of learning like universities and

they may hinder content comprehension if they are in-

troduced without deﬁnitions and/or explanations. We

assume that easy access to context related deﬁnitions

and explanations of technical terms found in a docu-

ment will simplify document comprehension for read-

ers of all levels without depriving them the oppor-

tunity to build their vocabulary levels. Therefore,

TermPedia was designed with an objective to provide

easy access to contextually relevant deﬁnition of tech-

nical terms that are embedded in documents. In case

a technical term deﬁnition is obscure, TermPedia con-

tains an option for the reader to obtain additional ex-

planation on the deﬁned technical term by linking to

an article that discusses it explicitly.

1.1 TermPedia Technologies

TermPedia is a document enrichment tool that uses

Human Language Technologies (HLTs) to provide

contextually relevant information for technical terms

that are embedded in documents. TermPedia was de-

signed to deﬁne technical terms by extracting their

meaning from Wikipedia. Although Wikipedia offers

multilingual documents, we only utilize the English

content. Deﬁned technical terms are linked to con-

textually relevant Wikipedia articles so that in cases

where a term deﬁnition does not provide sufﬁcient in-

formation for content comprehension, a reader may

navigate to the Wikipedia article for additional expla-

nation. The HLTs used in TermPedia include semi-

automatic technical term extraction, automatic term

deﬁnition and automatic hyperlink generation.

Much as document enrichment [that is to say,

incorporation of contextually relevant information

into existing text] is the fundamental technology of

TermPedia, the tool uses document extraction tech-

niques for semi-automatic term extraction. In addi-

tion a simple string look-up algorithm is used for au-

tomatic term deﬁnition and a frequency based algo-

rithm is used to generate automatic hyperlinks. For

details on TermPedia technologies please see (Olango

et al., 2009) section III.

See http://en.wikipedia.org for the English Wikipedia.

2 RELATED WORKS

Work that has been done in relation to document

enrichment and eLearning, term and deﬁnition ex-

traction, and automatic hyper-link generation, is dis-

cussed in this section with a focus on their importance

to improving educational literature comprehension.

2.1 Document Enrichment and

eLearning

With an intention to simplify document comprehen-

sion by artiﬁcial extension of a reader’s knowledge-

base on a per-need basis (Csomai and Mihalcea,

2007), presented Wikify! A system that can im-

prove educational materials by automatically extract-

ing keywords, technical terms and other key concepts

and linking them to appropriate Wikipedia articles (a

concept they referred to as “text wikiﬁcation”). Af-

ter carrying out a test by selecting 14 quiz questions

from an on-line history course taught at the Univer-

sity of North Texas, the test results showed that bring-

ing information relevant to the topic of student’s study

within their easy reach through hyperlinking is a suc-

cessful strategy for increased effectiveness in peda-

gogical tasks. Technically, Wikify! is a document

enrichment tool that has shown basic success in im-

proving educational literature comprehension by use

of technical terms. Nowhere though does Wikify!

consider automatic term deﬁnition which TermPedia

proposes as a key for improving educational literature

comprehension. The time required to acquire knowl-

edge may be reduced since a student does not need to

link to an external source if the term deﬁnition pro-

vides adequate information for comprehension.

(Monachesi and Westerhout, 2008) worked on a

Language Technology for eLearning (LT4eL) project

where they adapted results from Natural Language

Processing (NLP) to eLearning context by using sta-

tistical measures in combination with linguistic pro-

cessing to detect keyword candidates. The key words

where then used as glossary candidates which allowed

for the creation of glossaries based on deﬁnition of

the relevant terms, to be linked to learning objects.

Whereas these authors focused on how to ﬁnd def-

initions of terms, we concentrate on integrating the

links to deﬁnitions, and on context-dependent disam-

biguation to provide relevant information for content

comprehension.

2.2 Term Extraction and Deﬁnition

Linguistic patterns, statistical methods, tf-idf (term

frequency-inverse document frequency) weight, term

CSEDU 2011 - 3rd International Conference on Computer Supported Education

428

co-occurrence, and concept identiﬁcation using

Wikipedia are methods that have been used in term

extraction (Fahmi et al., 2007; Medelyan et al.,

2008; Aguilar et al., 2010). The latter considers

Wikipedia page articles as terms and these are in turn

used to extract terms in other documents. (Medelyan

et al., 2008) reported that the Wikipedia technique

was signiﬁcantly more effective than the other tech-

niques, this report reinforced our motivation for using

Wikipedia titles and links for term detection. The re-

port also mentions that tasks such as word sense dis-

ambiguation and word similarity could be automati-

cally addressed by exploiting Wikipedia’s unique fea-

tures. A technique that TermPedia exploits.

2.3 Automatic Hyperlink Generation

Relative effectiveness of link generation based on

Wikipedia article names or titles was investigated

by (Fachry et al., 2008). After experimenting with

Vector Space Model (VSM) and sub-string match for

detecting missing links in Wikipedia, they showed

that exact sub-string matching indicates an improve-

ment in ﬁnding the missing links. This investigation

performs a ﬁltering which considers sub-strings that

only match Wikipedia article title but, we consider

all sub-strings as potential candidates. In addition to

link generation, we also provide relevant deﬁnitions

for the sub-strings used in the link creation with and

objective of reducing the time for information search

and improving document comprehension.

3 APPLICATION OF TERMPEDIA

This section discusses the application of TermPedia at

the University of Groningen in the Netherlands with

the prospects of surveying the tool’s usefulness. It is

worth mentioning that the user survey was in progress

at the time this paper was submitted to the conference

for review. In the mean time, the survey was com-

pleted and a brief discussion of the results is presented

in section 4. Students of information retrieval were

selected as users for this survey because TermPedia

is a practical application of information retrieval and

also because the textbook for this course is available

in soft copy

See, http://nlp.stanford.edu/IR-book/information-

retrieval-book.html

3.1 Creation of Information Retrival

(IR) Data for Annotation

We exported Wikipedia pages wrapped in XML in

the category of information retrieval and other re-

lated ﬁelds like computer science and computational

linguistics by using the “Export pages” feature of

Wikipedia. The exported pages were stored in a ﬁle

of 135 megabytes large and contained 18,685 arti-

cles. By extracting Wikipedia internal, and related

links from these articles, we were able to obtain ap-

proximately 166,974 terms which in turn referred to

159,507 Wikipedia articles. This shows that each of

the exported Wikipedia articles contained at least 9

links and each link could possibly refer to more than

one Wikipedia page. Since the links refer to more

than one Wikipedia page this shows that the links are

ambiguous and should be disambiguated in reference

to text context while using them for generating anno-

tations in the information retrieval textbook.

Table 1 below shows the possible ambiguity in

the term tables. We see that this term could refer

to a mathematical table or a database table. Which

meaning is relevant can only be determined in rela-

tion to text context and the TermPedia feature of au-

tomatic link generation helps to reduce this ambigu-

ity. In the table we also see an advantage of using

Wikipedia links to represent terms that the abbrevi-

ation IR is linked to the page with title Information

Retrieval. Notice that all possible deﬁnitions of each

technical term are extracted along with the Wikipedia

article to which that term refers. All this informa-

tion is stored in a database which makes TermPedia

a relatively fast tool for extraction and deﬁnition of

technical terms and automatic hyperlink generation.

3.2 Annotation of IR Book

As mentioned in section 1.1, a string look-up algo-

rithm is used to extract technical terms embedded in

the information retrieval text book. The string look-

up algorithm matches sub-strings from the database

that contains technical terms to sub-strings from the

information retrieval textbook. Each strict match in

the textbook is then annotated as a technical term and

provided with a deﬁnition. The annotation is then

transformed into an automatic html hyperlink by us-

ing the matched sub-string as an anchor text and pro-

viding a contextually relevant Wikipedia article as a

value for the href attribute. Manual correction was

done to make sure that each annotated technical term

(matched sub-string) referred to a contextually rele-

vant Wikipedia article.

EASY EDUCATIONAL LITERATURE COMPREHENSION

- Applying TermPedia to Information Retrieval Knowledge Domain

429

Table 1: Random selection of Terms and name of Wikipedia

articles to which they link.

Terms Title of Wikipedia

Articles

Deﬁnitions

IR IR Information retrieval (IR) is the sci-

ence of searching for documents, for

information within documents, and

for metadata about documents, as

well as that of searching relational

databases and the World Wide Web...

information

retrieval

-do-

tables Mathematical table Before calculators were cheap and

plentiful, people would use mathe-

matical tables -lists of numbers show-

ing the results of calculation with

varying arguments? to simplify and

drastically speed up computation...

mathematical table -do-

Table (database) In relational databases and ﬂat ﬁle

databases, a table is a set of data ele-

ments (values) that is organized using

a model of vertical columns (which

are identiﬁed by their name) and hor-

izontal rows...

database table -do-

3.3 Integration of Annotated IR Book

into Electronic Content

In order to present TermPedia to the information re-

trieval students we designed a web-based user inter-

face that integrated the annotated book into Nestor.

Nestor is the digital learning environment of the Uni-

versity of Groningen. A screen shot of the demonstra-

tion web-based user interface is given in ﬁgure 1.

The user interface

allows a student to read an an-

notated HTML version of the information retrieval

textbook with speciﬁc emphasis on chapters six to

nine. Each automatically created hyperlink has an

added [javascript] functionality, that allows deﬁni-

tions of the link (i.e. the ﬁrst paragraph of the

corresponding wikipedia page) to show in a pop-

up window, as soon as a students moves a mouse

over the link (mouse hovering action). Deﬁnitions

are retrieved in real-time from the current version of

Wikipedia with an excellent speed. In addition, all

existing generated hyperlinks on the page are turned

into links which point to the system, so that any new

page accessed by the student is also enriched.

On-line at http://www.let.rug.nl/ olango/TermPedia/

Figure 1: Screen Sorts of TermPedia User Interface.

4 TERMPEDIA USER SURVEY

After the students had used TermPedia for one month

they answered a quantitative questionnaire that inves-

tigated the usefulness of the tool. This part of the user

survey constituted a manual method of data collection

and analysis. An automatic method of data collection

and analysis was also done using Google Analytics, a

free web analytics tool offering detailed visitor statis-

tics (MAS11, 2011). Just before introducing TermPe-

dia to the students, they were given terminology exer-

cises in order to prepare them for the possible advan-

tages of the tool in identifying, deﬁning and explain-

ing difﬁcult terms.

4.1 Automatic Data Collection and

Analysis for TermPedia User Survey

The automatic collection and analysis of TermPedia

survey data was done using Google Analytics to pro-

vide proof that the students actually used TermPedia,

therefore their responses to the quantitative question-

naire could be trusted. The advantage of using Google

Analytics is that detailed visitor statistics are automat-

ically generated. From ﬁgure 2 we see that there were

a total of 68 visitors during the one month of TermPe-

dia usage by Information Retrieval students. The ﬁg-

CSEDU 2011 - 3rd International Conference on Computer Supported Education

430

Figure 2: Statistics for TermPedia Site Usage.

ure also reveals that 48 visitors out of the 68 (i.e.

70.6%) of the visits to TermPedia web-based user in-

terface was from nestor.rug.nl, the server on which

TermPedia was integrated into the students electronic

content. Thus we can conﬁdently say that the students

used TermPedia with a pick of 10 visit a day during

the month of November, 2010.

4.2 Manual Data Collection and

Analysis for TermPedia User Survey

As mentioned above, a quantitative questionnaire was

used in the manual collection of data during the

TermPedia user survey. The questionnaire was di-

vided into three sections that surveyed difﬁculty of

the information retrieval textbook, the possibility that

TermPedia is a useful tool for easy educational ma-

terial comprehension and design of TermPedia user

interface. The questionnaire demanded ranked re-

sponses from 0 to 4 as indicated in table 2.

Table 2: Ranks of answers to survey questionnaire.

Strongly agree Agree Somewhat agree Disagree Strongly disagree

4 3 2 1 0

Questions in the textbook difﬁculty section con-

centrated on whether the students found technical

terms that they could not easily understand without

the help of additional explanation and if these terms

hindered their understanding of the textbook content.

The section which surveyed the possibility that

TermPedia is a useful tool for easy educational liter-

ature comprehension included questions on whether

the tool was able to identify technical terms from the

textbook correctly and accurately provide their deﬁni-

tions and external link to a relevant Wikipedia article.

The section also included questions on whether the

students were able to easily understand the content of

the textbook after accessing the deﬁnition of technical

terms or rather if they needed additional explanation

of the terms in addition to their deﬁnition.

The last section of the questionnaire on TermPedia

user interface asked questions on whether it was easy

to ﬁnd information on the user interface, easily nav-

igate through the interface and also if the font sizes,

colours, and formats where legible.

Five (5) questions were selected from each sec-

tion for analysis of the survey results. We received 8

responses out of 13 students who attended the Infor-

mation Retrieval class. Cronbach’s alpha reliability

coefﬁcient was used to determine if the users’ ranks

were internally consistent. Alpha was calculated us-

ing the following formula:

α =

[1 + (k − 1)r]

(1)

Where: k = number of items considered

and r = mean of the inter-items correlations

Cronbach’s alpha reliability coefﬁcient normally

ranges between 0 and 1. The closer it is to 1 the

greater the internal consistency of the items in the

scale (Gliem and Gliem, 2003). Hypothesis for Cron-

bach’s alpha reliability coefﬁcient were set as follows:

• H

α 6= 0 i.e. Internal consistency of user ranks

in this scale.

• H

α = 0 i.e. No internal consistency of user

ranks in this scale.

Table 3: Cronbach’s alpha reliability coefﬁcient.

Survey Items Mean Scores α Interpretation

Section

Book difﬁculty 5 2.4 0.3 Poor /

unacceptable

TermPedia

usefulness

5 2.7 0.6 Questionable

TermPedia

user interface

5 2.5 0.7 Acceptable

Table 3 indicates alpha values for the three sec-

tions of the quantitative questionnaire along with their

mean ranks as answered by 8 students following the

Information Retrieval class. Although the mean rank

of the Information Retrieval book difﬁculty section is

slightly above average (i.e. 2.4 > 2.0), the students’

ranks for this section are inconsistent since α = 0.3.

It can therefore be said that the level to which each

student found the information retrieval book difﬁcult

was subjective to that particular student. An expla-

nation for the students’ inconsistency in interpreting

the book difﬁculty could be that they are at different

vocabulary levels of Information Science knowledge

domain. Since a total of 8 respondents is rather small,

EASY EDUCATIONAL LITERATURE COMPREHENSION

- Applying TermPedia to Information Retrieval Knowledge Domain

431

it can be said that α = 0.6 is acceptable for internal

consistency of students ranks for questions in the sec-

tion of TermPedia usefulness. The mean rank of 2.7

for this section shows that the students consistently

agree that the tool is useful for easy comprehension

of educational material. The web-based user interface

section gave the best results for α with α = 0.7 and

rank mean of 2.5 indicating that the students unani-

mously agreed that it was easy to access information

from and navigate through TermPedia user interface.

5 CONCLUSIONS

We have shown that TermPedia can be successfully

integrated into electronic content of educational liter-

ature. By use of TermPedia students can easily ac-

cess the deﬁnition of technical terms that occur in

educational literature and link to Wikipedia for fur-

ther explanation on the terms if the deﬁnitions do not

provide adequate information for content comprehen-

sion. Since TermPedia takes care of term ambigu-

ity, students are brought closer to accurate informa-

tion, this is expected to reduce the time required for

knowledge acquisition and understanding. The auto-

matic hyperlinking feature of Termpedia also reduces

the cost of maintaining unstructured information.

In future work, an experiment will be carried out

to verify if TermPedia actually reduces the time for

knowledge acquisition. In addition, frequency counts

of activated links in annotated text to Wikipedia ar-

ticles can reveal a patterns in the terms that students

often look-up. It is possible that the pattern in user

preferences shall expose technical terms that the stu-

dents ﬁnd difﬁcult to understand. This information

shall also highlight which technical terms could not

be understood by the students through their deﬁni-

tions.

REFERENCES

Aguilar, C., Acosta, O., and Sierra, G. (2010). Recognition

and extraction of deﬁnitional contexts in spanish for

sketching a lexical network. In YIWCALA ’10: Pro-

ceedings of the NAACL HLT 2010 Young Investiga-

tors Workshop on Computational Approaches to Lan-

guages of the Americas, pages 109–116, Morristown,

NJ, USA. Association for Computational Linguistics.

Csomai, A. and Mihalcea, R. (2007). Linking educational

materials to encyclopedic knowledge. In Proceed-

ing of the 2007 conference on Artiﬁcial Intelligence in

Education, pages 557–559, Amsterdam, The Nether-

lands, The Netherlands. IOS Press.

Engineer, S. (2005). 21st Century English Vocabulary. Per-

son Education.

Fachry, K. N., Kamps, J., Koolen, M., and Zhang, J. (2008).

Using and detecting links in Wikipedia. In Fuhr, N.,

Lalmas, M., Trotman, A., and Kamps, J., editors, Fo-

cused access to XML documents: 6th International

Workshop of the Initiative for the Evaluation of XML

Retrieval (INEX 2007), Lecture Notes in Computer

Science. Springer Verlag, Heidelberg.

Fahmi, I., Bouma, G., and der Plas, L. V. (2007). Learn-

ing to identify deﬁnitions using syntactic features. In

EACL 2006 Workshop on Learning Structured Infor-

mation in Natural Language Application, pages 64–

71.

Gliem, J. A. and Gliem, R. R. (2003). Calculating, inter-

preting, and reporting cronbachs alpha reliability co-

efﬁcient for likert-type scales. Presented at the Mid-

west Research-to-Practice Conference in Adult, Con-

tinuing, and Community Education, The Ohio State

University, Columbus, OH, October 8-10, 2003.

Graves, M. F. and Graves, B. B. (2003). Scaffolding

Reading Experiences: Designs for Students Success.

Christopher-Gordon Publishers, Inc., 2nd edition.

Kate, C. (2007). Deriving word meanings from context:.

Journal of Research in Reading, Vol.30:347–359.

MAS11 (2011). Seo and internet marketing services.

Internet Marketing and SEO Glossary. [online]

http://www.midatlanticseo.com/information/internet-

marketing-glossary/SEO-keywords-and-deﬁnitions-

a.php.

Medelyan, O., Legg, C., Milne, D. N., and Witten, I. H.

(2008). Mining meaning from wikipedia. CoRR, Vol.

abs/0809.4530.

Monachesi, P. and Westerhout, E. (2008). What can NLP

techniques do for eLearning? In INFOS2008 pro-

ceedings, pages 150–156. Faculty of Computer &

Information-Cairo University. Cariro, Egypt.

Olango, P., Kramer, G., and Bouma, G. (2009). Termpe-

dia for interactive document enrichment: using tech-

nical terms to provide relevant contextual informa-

tion. In IMCSIT ’09: International Multiconference

on Computer Science and Information Technology,

pages 265–272. IEEE.

Thuring, M., Hannemann, J., and Haake, J. M. (1995). Hy-

permedia and cognition:. In Design for Comprehen-

sion. Community of the ACM.

Young, D. R., Hooker, D. T., and Freeberg, F. E. (1990). In-

formation consent documents: Increasing comprehen-

sion by reducing reading level. The Hastings Center,

Vol. 12(No.3).

CSEDU 2011 - 3rd International Conference on Computer Supported Education

432
