GUARANTEEING STRONG (X)HTML COMPLIANCE

FOR DYNAMIC WEB APPLICATIONS

Paul G. Talaga and Steve J. Chapin

Syracuse University, Syracuse, NY, U.S.A.

Keywords:

W3C compliance, Web development, Haskell.

Abstract:

We report on the embedding of a domain speciﬁc language, (X)HTML, into Haskell and demonstrate how this

superﬁcial context-free language can be represented and rendered to guarantee World Wide Web Consortium

(W3C) compliance. Compliance of web content is important for the health of the Internet, accessibility,

visibility, and reliable search. While tools exist to verify web content is compliant according to the W3C, few

systems guarantee that all dynamically produced content is compliant. We present CH-(X)HTML, a library

for generating compliant (X)HTML content for all dynamic content by using Haskell to encode the non-trivial

syntax of (X)HTML set forth by the W3C. Any compliant document can be represented with this library, while

a compilation or run-time error will occur if non-compliant markup is attempted. To demonstrate our library

we present examples and performance measurements.

1 INTRODUCTION

Conformity of web content to the World Wide Web

Consortium’s (W3C) standards is a goal every web

developer should aspire to meet. Conformity leads

to increased visibility as more browsers can ren-

der the markup consistently, increased accessibil-

ity for disabled users using non-typical browsing

styles(Chisholm, 1999), more reliable Internet search

by presenting search engines with consistent page

structures(Davies, 2005), and in some cases com-

pliance with legal requirements (Brewer and Henry,

2006; Moss, 2010; Wittersheim, 2006; dda, 2010).

Unfortunately the majority of web content is non-

compliant, with one study ﬁnding 95% of pages on-

line are not valid(Chen et al., 2005). Not surprisingly,

the majority of web frameworks do not guarantee gen-

erated content is compliant. Popular internet browsers

perpetuate the problem by creatively parsing and ren-

dering invalid code in an attempt to retain users.

While tools exist to check validity of static con-

tent, few systems exist that claim strong validity of all

produced content. With dynamic web applications, it

is harder to guarantee validity due to the dynamic na-

ture of their outputs. Assuring compliance for spe-

ciﬁc inputs is possible, but proving compliance for all

inputs is analogous to proof by example. Web frame-

works using Model-View-Controller design practices

provide some assurances based on compliant templa-

tes, but it remains easy for an unknowing developer

or user input to break this compliance. Such deﬁcien-

cies in frameworks can have security consequences

as well(Hansen, 2009). Rather than make it easy

for developers to produce invalid content, frameworks

should make it impossible to be non-compliant.

1.1 Contributions

We present CH-(X)HTML, a Haskell library for build-

ing (X)HTML content with strong W3C compliance

for all outputs. By using Haskell’s recursive types,

multiple parameter and functional dependencyof type

classes, web content is built by separating structure

from content in a typed tree data structure way, much

like the underlying (X)HTML. The resulting structure

can be stored, manipulated, or serialized to a standard

W3C compliant textual representation.

We identify ﬁve traits common to all W3C

(X)HTML speciﬁcations which must be met for

a document to be compliant and show how CH-

(X)HTML enforcesfour of these at compile-time, with

the ﬁfth optionally at run-time.

The remainder of the paper is structured as fol-

lows. We analyze and categorize commonalities be-

tween different W3C (X)HTML speciﬁcations in Sec-

tion 2, identifying requirements a W3C compliant

producing system must possess. Section 3 provides

an overview of CH-(X)HTML and discusses how it is

G. Talaga P. and J. Chapin S..

GUARANTEEING STRONG (X)HTML COMPLIANCE FOR DYNAMIC WEB APPLICATIONS.

DOI: 10.5220/0003348800710079

In Proceedings of the 7th International Conference on Web Information Systems and Technologies (WEBIST-2011), pages 71-79

ISBN: 978-989-8425-51-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

able to enforce the W3C speciﬁcations while being

easy to use. Sample code is provided showing the use

of the library, followed by a performance evaluation

in Section 4. Related work and our conclusion are in

Sections 5 and 6 respectively.

2 W3C COMPLIANCE

The W3C has set forth numerous variants of speciﬁ-

cations of HTML and XHTML, with more on the way

in the form of HTML5. Examples include HTML 3.2,

HTML 4.01 Strict, and XHTML 1.00 Transitional.

While conformance to a speciﬁc document type def-

inition (DTD) is our goal, identifying commonalities

will assure easy conversion to any HTML DTD. For

example, the difference between HTML 4.01 Strict

and HTML 4.01 Transitional is merely the allowance

of certain tags. Likewise, HTML 4.01 Frameset and

XHTML 1.00 Frameset differ in their document type:

SGML and XML respectively(Group, 2002).

We have identiﬁed ﬁve classes of common re-

quirements between different (X)HTML DTDs based

on Thiemann’s work(Thiemann, 2001). A system ca-

pable of supporting all requirement classes should be

able to include support for all requirements in any of

the W3C speciﬁcations. These classes include the fol-

lowing:

Well-formed. An (X)HTML document is well-

formed if all tags have appropriate starting and ending

characters, as well as an ending tag when needed. All

attributes have the form

attribute="value"

inside

a tag. All characters should be in the correct con-

text. For example, all markup characters should only

be used for markup including

<,>,&,"

Tag-conforming. An (X)HTML document is tag-

conforming if all tags are deﬁned and valid within that

DTD. No browser speciﬁc tags should be used.

Attribute-conforming. An (X)HTML document is

attribute-conforming if all attributes names are al-

lowed for that speciﬁc tag. For example, the

tag

can not contain an

href

attribute. Similarly, the value

type of every attribute matches its DTD description.

Required attributes are also provided.

Inclusion & Exclusion. An (X)HTML document

obeys inclusion & exclusion if the nesting of all tags

follow the speciﬁc DTD. For example, in HTML 4.01

tag can be a descendant of another

tag. Simi-

larly, the

tag requires a

tag to be its child. While

SGML, of which HTML is a member, allows deep

nesting rules, XML does not(Group, 2002). XML

can specify what children are allowed, but not grand-

children or beyond. Thus, the XHTML 1.0 speciﬁca-

tion recommends the inclusion & exclusion of tags,

but can not require it. We feel that since XHTML

is fully based on HTML this requirement is impor-

tant and should be enforced. In support, the W3C on-

line validator marks inclusion & exclusion problems

in XHTML as errors. The draft HTML5 speciﬁcation

broadens nesting rules by restricting groups of tags

to be children(htm, 2010). For example, an

tag in

HTML5 must not contain any interactive content, of

which 15 tags are members.

Tag Ordering. An (X)HTML document obeys tag

ordering if sibling tags are ordered as described in

their DTD. As an example, the

head

tag must precede

the

body

tag as children of the

html

tag.

3 CH-(X)HTML

Our system is built as an embedded domain-speciﬁc

language, implemented in Haskell, capable of em-

bodying the requirements set forth by the W3C. The

use of a strongly typed language guarantees strong

compliance of the application at compile time, while

allowing easy representation of the embedded lan-

guage. Any strongly typed language could be used

for such a system, but Haskell’s multiple parameter

and functional dependency type classes cleans up the

syntax for the developer.

CH-(X)HTML is available for download

or on

Hackage

. XHtml 1.0 Strict(Group, 2002), Transi-

tional, and Frameset are currently supported at this

time.

3.1 Implementation Overview

CH-(X)HTML’s design is outlined through a series of

reﬁnements guaranteeing each of the ﬁve W3C spec-

iﬁcation classes described above. Code examples are

meant to convey design methods, not produce fully

correct HTML.

Well-formed & Tag Conformance. At its core,

CH-(X)HTML uses ordinary Haskell types to imple-

ment a recursively deﬁned tree data structure repre-

senting the (X)HTML document. Each node in the

tree represents a tag, with inner tags stored as a list

http://fuzzpault.com/chxhtml

http://hackage.haskell.org/package/CHXHtml

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

of children. Depending on the tag, the node may

have none, or a variable number of children. Tag at-

tributes are stored with each node. Character data is

inserted using a

pcdata

constructor. An example of

this scheme is given:

data Ent = Html Attributes [Ent] |

Body Attributes [Ent] |

P Attributes [Ent] |

A Attributes [Ent] |

Br Attributes |

Cdata String | ...

data Attributes = [String]

render :: Ent -> String

Only deﬁned tags for a speciﬁc DTD exist as con-

structors, thus forcing tag-conformance. When the

data structure has been constructed and is ready to

be serialized, a recursive function

render

traverses

the structure, returning a string containing tags and

properly formatted attributes and values. All charac-

ter data (CDATA) is HTML escaped before rendering

preventing embedding of HTML markup. Separating

content from structure, along with HTML escaping,

forces all produced content to be well-formed and tag-

conforming.

Attribute Conformance. To limit allowed at-

tributes and their types, each tag is given a custom at-

tribute type allowing only valid attributes to be used.

If an attribute is set more than once the

render

func-

tion will use only the last, guaranteeing a unique value

for each attribute. Required attributes can either be

automatically inserted at run-time to guarantee com-

pliance, or rendered as-is with a warning if attributes

are lacking. This run-time compliance issue is dis-

cussed in Section 3.2.

The example below implements attribute confor-

mance described above.

data Ent = Html [Att_html] [Ent] |

Body [Att_body] [Ent] |

P [Att_p] [Ent] |

A [Att_a] [Ent] |

Br [Att_b] |

Cdata String | ...

data Att_html = Lang_html String |

Dir_html String | ...

data Att_body = Lang_body String |

Dir_body String |

Onload_body String | ...

...

render :: Ent -> String

Inclusion & Exclusion Conformance. Thus far

any tag can be a child of any other. For inclusion &

exclusion conformance we use new data types repre-

senting the context of those tags. Each DTD describes

allowed children for each tag, required tags, as well

as limits on all descendants. For example, Table 1 de-

scribes the inclusion & exclusion rules for some tags

in HTML 4.01 Strict. A + in the required children

column signiﬁes at least one child must exist.

By using unique types for each tag only allowed

children tags can be inserted. To enforce descendant

rules, a new set of types are used which lack the for-

bidden tag. Thus, rather than one constructor speci-

fying a tag, a set of constructors may, each valid in

a different context. For example the following code

correctly prohibits nesting of the

tag by effectively

duplicating the

Ent3

type but lacking the

data Ent = Html Att_html [Ent2]

data Ent2 = Body Att_body [Ent3]

data Ent3 = A3 Att_p [Ent_no_a] |

P3 Att_p [Ent3] |

Br3 Att_b |

Cdata3 String | ...

data Ent_no_a = P_no_a Att_p [Ent_no_a] |

Br_no_a Att_b |

Cdata_no_a String | ...

- Attributes same as above

render :: Ent -> String

In practice, preventing a deep descendant results in

duplication of nearly all types. Had

Ent3

allowed

some other child other than itself, then it too must be

duplicated with a

_no_a

version, and so on. A com-

binatorial explosion could prove this approach unfea-

sible, but our analysis has shown otherwise. For ex-

ample, by enumerating all possible valid nesting situ-

ations in HTML 4.0 Strict, a total of 45 groups of tags

were needed to properly limit allowed children while

preventing invalid descendant situations.

Assuring the required children tags exist is

checked at run-time which is discussed in Section 3.2.

Tag Order Conformance. To validate or warn

against tag-order conformance errors, a run-time

checker

childErrors

can be used. Section 3.2 dis-

cusses the issues and trade offs involved with such a

run-time system.

3.2 Complete Compile-time Compliance

vs. Usability

A trade-off exists between complete compile-time

compliance and usability with regard to tag ordering,

GUARANTEEING STRONG (X)HTML COMPLIANCE FOR DYNAMIC WEB APPLICATIONS

Table 1: Inclusion & Exclusion Examples in HTML 4.01.

Tag Required Children Allowed Children Disallowed Descendants

html head,body head,body

body + p,div,...

p a,br,cdata,...

a br,cdata,... a

tr + th,td

form + p,div,... form

... ... ... ...

required children tags, and required attributes. A li-

brary’s interface should be obvious, allowing exist-

ing HTML knowledge to be used easily in a new con-

text. For usability we’ve decided to have four forms

of tag constructors: two with children, and two with-

out, detailed in Section 3.4. Children tags are spec-

iﬁed as a regular Haskell list for those tags allowing

children. Similarly, tag attributes are described in list

form as well. This allows the developer to easily write

markup and apply any list manipulation function to

tags or attributes. Unfortunately there is no way to re-

strict the list elements or their order at compile-time.

A run-time checker

childErrors

can scan the com-

pleted document for tag ordering, required children,

or required attribute errors if needed.

The alternative would be to specify children or

attributes as a tuple. Tuples allow different type el-

ements, but all must be provided. List manipula-

tion would not be possible, nor would all tags have

a standard interface. Some tags may take a 3-tuple,

while others may take a list, or some other combina-

tion thereof. Burdening the developer with such com-

plexities and limitations was deemed too harsh given

the complete compile-time guarantee beneﬁt. The

HaXml project contains a DtdToHaskell utility which

enforces ordering in this manner using tuples(Wallace

and Runciman, 1999).

To strengthen the compile-time guarantees with

regard to W3C compliance, the

fix_page

function

can attempt to manipulate the document to reach full

W3C compliance. It will return a repaired document,

a synopsis of changes made, and if it was able to reach

full W3C compliance. Currently required attribute

and tag errors are repaired, with tag ordering errors

still in development.

3.3 Cleanup

Writing (X)HTML content using complex construc-

tors described in Section 3.1 becomes unwieldy

quickly. By using multi-parameter type classes and

functional dependencies we can hide this complexity

while still retaining the compile-time guarantees. We

construct a type class per tag such that a function cor-

rectly returns a constructor of the correct type based

on context. The following example shows the type

class for specifying the

tag.

class C_P a b | a -> b where

p :: [Att_p] -> [b] -> a

instance C_P Ent3 Ent3 where

p at r = P_1 at r

instance C_P Ent_no_a Ent_no_a where

p at r = P_2 at r

The class instance used is determined by the con-

text the function is called in, which determines what

type children it may have provided by the functional

dependency of classes. Thus, as long as the root of

the recursive structure has a concrete type all chil-

dren will be uniquely deﬁned. Nesting errors man-

ifest themselves as compile-time class instance type

errors.

Attribute speciﬁcation is handled in a similar way.

Thus, during development, only the tag or attribute

names must be speciﬁed, all complex constructor se-

lection is done by the functional type classes.

3.4 Library Usage

Building an (X)HTML document is done by con-

structing the recursive data structure and serializ-

ing it using the

render

render_bs

functions.

Content can be served to the web with any num-

ber of Haskell web servers such as HAppS(hap,

2010), Happstack(Elder and Shaw, 2010), Mo-

HWS(Marlow and Bringert, 2010), turbinado(Kemp,

2010), SNAP(Collins et al., 2010), or via ex-

ecutable with CGI(cgi, 2010)(Bringert, 2010) or

FastCGI(Saccoccio et al., 2010)(Bringert and Lem-

mih, 2010) Haskell bindings. CH-(X)HTML can be

used anywhere a

String

type containing (X)HTML

is needed in Haskell. For speed and efﬁciency the

render_bs

function returns a lazy ByteString repre-

sentation suitable for CGI bindings.

All HTML tags are represented in lower case with

an underscore

before or after the tag text. Before

assigns no attributes, while after allows a list of at-

tributes. Tags which allow children then take a list of

children.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

Table 2: W3C Conformance Performance.

Library Well-formed Tag-conf. Attribute-conf. Inclusion/Exclusion Tag-order-conf.

CH-(X)HTML G# G# #

CH-(X)HTML w/runtime

Text.Html G# # #

Text.XHtml G# # #

BlazeHtml G# # #

Hamlet G# # #

Text.HTML.Light G# # #

PHP # # # # #

Attributes are represented in lower case as well, but

sufﬁxed with

_att

. This assures no namespace con-

ﬂicts. Assigning an attribute which does not belong

results in a compile-time class instance error.

Validating child ordering is done using the

childErrors

function which takes any node as an ar-

gument. A list of errors will be returned, if any, along

with the ordering speciﬁcation in the DTD which

failed.

Figure 1 exhibits the obligatory Hello World page

where

result

holds the resulting serialized HTML as

a string.

For a more through description of the CH-

(X)HTML’s usage see the

demo.hs

included with the

library source.

4 LIBRARY PERFORMANCE

To gauge our library’s performance against similar

dynamic HTML creation systems, we compared it

to six other libraries: Text.Html, Text.XHtml, Blaze-

Html(Meier and der Jeugt, 2010), Hamlet(Snoyman,

2010), Text.HTML.Light, PHP. The ﬁrst ﬁve are com-

binator libraries in Haskell used for building HTML

content while PHP is a popular web scripting lan-

guage. CH-(X)HTML was tested twice, once with

run-time list checking, and once without.

Table 2 shows each’s W3C compliance guarantees

for all produced content with regard to the ﬁve W3C

areas of compliance. Half-ﬁlled circles indicate par-

tial compliance. For example, CH-(X)HTMLwithout

run-time list checking is not fully attribute conform-

ing due to possible omission of required attributes.

Other libraries fare even worse by allowing any at-

tribute to be used with any tag.

It is clear CH-(X)HTML without run-time list

checking offers stronger compliance than any library

tested, with full compliance attainable with run-time

checking and repairing enabled.

To test rendering performance, an XHTML 1.0

Strict ’bigtable’ document was created containing a

table with 1000 rows, each with the integers from 1 to

10 in each row´s column.

Head

and

title

tags were

added for W3C compliance with no other content on

the page. The table is generated dynamically leading

to very short page generating code. The ﬁnal page

consisted of 11,005 tags and about 121kB total size.

To rule out web server performance each library is

timed until the content is prepared in memory ready

to be sent. The

criterion

library in Haskell is used

to benchmark in this way while the cpu time was mea-

sured for PHP. Testing was done on a Fedora Core 11

server with an AMD 2.3Ghz Athlon 64 X2 processor

with 2GB of RAM.

Speed results are shown in Fig 2. Hamlet was the

fastest, with BlazeHtml and PHP slightly slower at

10ms. CH-(X)HTML without run-time tag ordering

validation beats out Text.Html and Text.XHtml show-

ing CH-(X)HTML is able to compete with generic

HTML productions systems while enforcing four of

the ﬁve compliance classes. Adding tag order valida-

tion adds signiﬁcant time, requiring 115(ms) to render

bigtable in our current implementation. This is due to

an external regular expression library being called for

each tag; for this case 11,005 times. Further bench-

marking with different size tables showed a perfectly

linear relation between tag count and page rendering

time for CH-(X)HTML with tag ordering validation.

To gauge real-world performance for CH-

(X)HTML with tag order validation, a sample of

31,000 random HTML pages were downloaded from

the web and analyzed. The average tag count per

page was 801, with the 50th percentile having 330

tags. Average page size for the sample was 60kB,

with the 50th percentile being 23kB. While bigtable

may stress a dynamic web content generator, it does

not represent a typical web page with respect to tag

count or size. A new average page benchmark was

constructed by using 30 rows from the bigtable bench-

mark and adding plain text in a

tag resulting in

335 tags and about 60kB total size. Figure 3 shows

the vastly different results. PHP now leads, closely

followed by CH-(X)HTML without tag order check-

ing. Even with tag order checking CH-(X)HTML does

quite well beating out three other libraries.

GUARANTEEING STRONG (X)HTML COMPLIANCE FOR DYNAMIC WEB APPLICATIONS

page name = _html [_head [_title [pcdata "Hello " ++ name]],

_body [_h1 [pcdata "Hello " ++ name ++ "!"],

_hr,

_p [pcdata "Hello " ++ name ++ "!"],

]

result :: String

result = render (page "World")

Figure 1: Hello World implementation in CH-(X)HTML.

While speed is not our goal, CH-(X)HTML pre-

forms on par with similar dynamic HTML production

systems for most pages while providing more guaran-

tees on compliant output. For pages containing atyp-

ically large amounts of tags, additional speed can be

gained by not running run-time list checking.

5 RELATED WORK

There exist two areas related to our work: XML cre-

ation and manipulation, and general HTML produc-

tion. XHTML has now joined these two areas.

Numerous projects have embedded XML into

other languages and allowed for its manipulation.

Web content creation is not their main goal, but rather

generic XML with custom schema.

The mainstream language Java has JAXB(jax,

2010), which can create a set of Java classes based

on an XML schema, as well as the inverse. Data can

marshaled in either direction easily allowing dynamic

schema to be accessed in Java. If used for XHTML

production, inclusion/exclusion errors could still be

present as well as possible invalid characters. XML-

Beans is a similar tool(xml, 2010).

The automatic generation of Haskell types from

DTD’s or schema are covered in the HaXml project:

a set of Haskell utilities for parsing, ﬁltering, trans-

forming, and generating XML(Wallace and Runci-

man, 1999). Their DtdToHaskell utility produces a

Haskell source ﬁle containing datatypes conforming

to the provided XML DTD. DtdToHaskell’s generic

XML to Haskell type production system works with

XHTML DTDs and even guarantees tag-ordering, but

at the price of usability. Every element (tag) attribute

must be speciﬁed even if not used due to their record

syntax implementation. Elements (tags) requiring an

ordered or speciﬁc number of children aren’t speciﬁed

using list syntax like most tags, but n-tuples, requir-

ing one to reference either the DTD or datatypes to

resolve compilation errors. Our specialized solution

of XHTML uses lists for all children, simplifying the

syntax. Child ordering can be validated at run-time

if needed. XML’s lack of tag inclusion/exclusion re-

striction prevents HaXml from enforcing it as well.

CH-(X)HTML is generated with a similar tool to Dt-

dToHaskell from a raw DTD, but is able to interpret

hybrid DTDs containing nesting restrictions.

HSXML is an XML serialization library for func-

tional languages(Kiselyov, 2010). It is part of a larger

effort to parse XML into S-expressions in functional

languages such as Scheme and Haskell, with HSXML

preforming the reverse. S-expressions are a natu-

ral way of representing nested data with its roots in

Lisp, thereby guaranteeing a well-formed and tag-

conforming document. The library’s current imple-

mentation can handle Inline vs Block context restric-

tions, but no other inclusion/exclusion or child order-

ing restrictions are enforced.

Constructing web content by means of a DOM-

like data structure isn’t new, but libraries guaranteeing

near or full HTML validity are scarce. Many HTML

libraries use HTML like syntax, unlike the above

XML tools, allowing easy construction of pages for

the developer, but with little guarantees to the valid-

ity of the output. Peter Thiemann’s work on W3C

compliance is the closest in the Haskell WASH/CGI

suite(Thiemann, 2002b; Thiemann, 2005; Thiemann,

2001), which includes a HTML & XML content pro-

duction system using types to enforce some validity.

The use of element-transforming style in the library

allows Haskell code to look similar to HTML while

still being valid Haskell source. The author docu-

ments different classiﬁcations of validity, which our

analysis in Section 2 is based on, followed by a dis-

cussion of enforcement of those classiﬁcations in his

system. The Inclusion & Exclusion issue is raised

and discussed brieﬂy in his 2002 work, concluding the

type class system is unable to handle inclusion & ex-

clusion in their implementation due to the inability to

handle disjunctions of types. As a result, their library

does not support inclusion or exclusion with the ex-

cuse of extreme code size, difﬁculty in usability, and

a lack of strict guidelines for inclusion & exclusion in

the XHTML speciﬁcation.

Further work by Thiemann explores an alternate

way of dealing with the inclusion & exclusion issue

in Haskell by way of proposed extensions providing

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

100

120

Hamlet

BlazeHtml

PHP

Text.HTML.Light

CHXHtml

Text.Html

Text.XHtml

CHXHtml w/check

Latency (ms)

Rendering Benchmark for Bigtable

Figure 2: Rendering times for XHTML libraries for bigtable.

PHP

CHXHtml

BlazeHtml

Text.Html

CHXHtml w/check

Hamlet

Text.XHtml

Text.HTML.Light

Latency (ms)

Rendering Benchmark for Average Page

Figure 3: Rendering times for XHTML libraries for an average page.

functional logic overloading, anonymous type func-

tions, and rank-2 polymorphism. With these they are

able to accurately encode and enforce the inclusion &

exclusion properties speciﬁed in the DTD(Thiemann,

2002a). A strong symmetry exists between our work

and the suggested extensions. The ability to em-

bed regular expressions on types is analogous to our

generous use of recursive types and run-time child

validation. While extending the type system further

may lead to more enhancements, CH-(X)HTML can

be used currently without any additional extensions.

The LAML(Nørmark, 2005) package for Scheme pro-

vides a set of functions representing HTML tags and

attributes capable of generating HTML programati-

cally. Their goal is bringing abstraction and web au-

thoring to Scheme rather than standards compliance.

Their functions are easy to use and provide well-

formed, tag-conforoming, and some attribute con-

forming content while not preventing inclusion & ex-

clusion, or tag ordering errors.

GUARANTEEING STRONG (X)HTML COMPLIANCE FOR DYNAMIC WEB APPLICATIONS

A common Haskell HTML library is

Text.Html(tex, 2010) and relative Text.XHtml

used above, which uses element-transforming style

to build pages. Produced content is well-formed

and tag-conforming due to their structured building

method and HTML escaping of text content. Any

attribute can be added to any tag, thus not being

attribute-conforming. All tags are of the same type

and can be added in any order leading to tag ordering

and inclusion/exclusion violations. Blaze-html(Meier

and der Jeugt, 2010) and Hamlet(Snoyman, 2010) are

similar Haskell libraries, but unfortunately they also

suffer from the same lack of compliance guarantees.

XMLC for Java allows an application developer to

manipulate a DOM structure obtained from parsing a

HTML or XML template ﬁle(xml, 2008). Manipula-

tion of the DOM is therefore similar to DOM manip-

ulations in JavaScript. When all transformations are

complete the DOM is serialized and sent to the user.

XMLC does not restrict operations which would re-

sult in invalid content being sent to the user.

Separating structure from content in a web set-

ting is advantageous for security as well. Robert-

son & Vigna(Robertson and Vigna, 2009) explore us-

ing a strongly typed system for HTML generation as

well as producing SQL queries in the web applica-

tion. Their goal is to increase security by preventing

injection attacks targeting the ad-hoc mixing of con-

tent and structure in SQL by representing structure

in a typed way and ﬁltering inserted content. Thus,

the client or SQL server’s parser will not be fooled

by the attempted injection attack. Our work similarly

mitigates injection attacks but does not address web

application vulnerabilities relating to a database.

6 CONCLUSIONS

We have shown how (X)HTML W3C compliance can

be achieved by Haskell while performing on par with

more mature dynamic (X)HTML production systems.

We generalize the W3C (X)HTML speciﬁcations into

ﬁve classes of requirements a web production sys-

tem must be able to enforce to produce compliant

output. The inclusion & exclusion nesting require-

ment of nearly all (X)HTML DTD’s has proven difﬁ-

cult to enforce and thus ignored by web production

libraries. Our (X)HTML library, CH-(X)HTML, is

able to partially enforce four of the ﬁve classes of

requirements at compile-time, including inclusion &

exclusion, with full compliance attainable at run-time.

Use of the library is straightforward due to multi-

parameter type classes and functional dependencies

allowing a coding style similar to straight (X)HTML,

while guaranteeing strong compliance for all pro-

duced content.

REFERENCES

Brewer, J. and Henry, S. L. (2006). Policies relating to web

accessibility. http://www.w3.org/WAI/Policy/.

Bringert, B. (2010). cgi: A library for writing cgi programs.

http://hackage.haskell.org/package/cgi.

Bringert, B. and Lemmih (2010). fastcgi: A

haskell library for writing fastcgi programs.

http://hackage.haskell.org/package/fastcgi.

CGI (2010). The common gateway interface.

http://hoohoo.ncsa.illinois.edu/cgi/.

Chen, S., Hong, D., and Shen, V. Y. (2005). An experimen-

tal study on validation problems with existing html

webpages. In International Conference on Internet

Computing, pages 373–379.

Collins, G., Beardsley, D., yu Guo, S., and Sanders,

J. (2010). Snap: A haskell web framework.

http://snapframework.com/.

Davies, D. (2005). W3c compliance and seo.

http://www.evolt.org/w3c-compliance-and-seo.

Directgov (2010). The disability discrimination act (dda).

http://www.direct.gov.uk/en/DisabledPeople/Rights

AndObligations/DisabilityRights/DG

4001068.

Elder, M. and Shaw, J. (2010). Happstack.

http://happstack.com/index.html.

Group, W. H. W. (2002). Xhtml 1.0: The ex-

tensible hypertext markup language (sec-

ond edition). http://www.w3.org/TR/xhtml1/,

http://www.w3.org/TR/xhtml1/.

Hansen, R. (2009). Xss (cross site scripting) prevention

cheat sheet. http://ha.ckers.org/xss.html.

Happs (2010). Happs. http://happs.org/.

Html5 (2010). Html5. http://dev.w3.org/html5/spec/

Overview.html.

Jaxb (2010). jaxb. https://jaxb.dev.java.net/.

Kemp, A. (2010). Turbinado. http://wiki.github.com/

alsonkemp/turbinado.

Kiselyov, O. (2010). Hsxml: Typed sxml.

http://okmij.org/ftp/Scheme/xml.html#typed-SXML.

Marlow, S. and Bringert, B. (2010). Mohws: Modu-

lar haskell web server. http://hackage.haskell.org/cgi-

bin/hackage-scripts/package/mohws.

Meier, S. and der Jeugt, J. V. (2010). Blazehtml.

http://jaspervdj.be/blaze/.

Moss, T. (2010). Disability discrimination act (dda) & web

accessibility. http://www.webcredible.co.uk/user-

friendly-resources/web-accessibility/uk-website-

legal-requirements.shtml

Nørmark, K. (2005). Web programming in scheme with

laml. J. Funct. Program., 15(1):53–65.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

Robertson, W. and Vigna, G. (2009). Static Enforcement

of Web Application Integrity Through Strong Typing.

In Proceedings of the USENIX Security Symposium,

Montreal, Canada.

Saccoccio, R. et al. (2010). Fastcgi. http://www.fastcgi.com

/drupal/.

Snoyman, M. (2010). Yesod web framework.

http://docs.yesodweb.com/.

Text.html (2010). Text.html. http://hackage.haskell.org/

package/html

Thiemann, P. (2001). A typed representation for html and

xml documents in haskell. Journal of Functional Pro-

gramming, 12:2002.

Thiemann, P. (2002a). Programmable type systems for do-

main speciﬁc languages.

Thiemann, P. (2002b). Wash/cgi: Server-side web script-

ing with sessions and typed, compositional forms. In

Practical Aspects of Declarative Languages: 4th In-

ternational Symposium, PADL 2002, volume 2257 of

LNCS, pages 192–208. Springer-Verlag.

Thiemann, P. (2005). An embedded domain-speciﬁc lan-

guage for type-safe server-side web-scripting. ACM

Transactions on Internet Technology, 5:1533–5399.

Chisholm, W., G. V. I. J. (1999). Web content accessibility

guidelines 1.0. http://www.w3.org/TR/WCAG10/.

Wallace, M. and Runciman, C. (1999). Haskell and xml:

Generic combinators or type-based translation? pages

148–159. ACM Press.

Wittersheim, A. (2006). Why comply?

the movement to w3c compliance.

http://ezinearticles.com/?Why-Comply?-The-

Movement-to-W3C-Compliance&id=162596.

Xmlbeans (2010). Xmlbeans. http://xmlbeans.apache.org/.

Xmlc (2008). Xmlc. http://xmlc.enhydra.org.

GUARANTEEING STRONG (X)HTML COMPLIANCE FOR DYNAMIC WEB APPLICATIONS
