REALISTIC 3D SCENE RECONSTRUCTION

FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES

TAKEN WITH A HANDHELD CAMERA

Minh Hoang Nguyen, Burkhard Wünsche, Patrice Delmas and Christof Lutteroth

Department of Computer Science, The University of Auckland, Auckland, New Zealand

Keywords: Structure-from-Motion, Image modelling, Fundamental matrix, RANSAC, SIFT, Image-based modelling,

Surface reconstruction.

Abstract We address the problem of reconstructing 3D scenes from a set of unconstrained images. These image

sequences can be acquired by a video camera or handheld digital camera without requiring calibration. Our

approach does not require any a priori information about the cameras being used. The camera's motion and

intrinsic parameters are all unknown. We use a novel combination of advanced computer vision algorithms

for feature detection, feature matching, and projection matrix estimation in order to reconstruct a 3D point

cloud representing the location of geometric features estimated from input images. In a second step a full

3D model is reconstructed using the projection matrix and a triangulation process. We demonstrate with

data sets of different structures obtained under different weather conditions that our algorithm is stable and

enables inexperienced users to easily create complex 3D content using a simple consumer level camera.

1 INTRODUCTION

The design of digital 3D scenes is an essential task

for many applications in diverse fields such as

architechture, engineering, education and arts.

Traditional modelling systems such as Maya, 3D

Max or Blender enable graphic designers to

construct complicated 3D models via 3D meshes.

However, the capability for inexperience users to

create 3D models has not kept pace. Even for trained

graphic designers with in-depth knowledge of

computer graphics, constructing a 3D model using

traditional modelling systems can still be a

challenging task (Yang et al., 2010). Hence, there is

a critical need for a better and more intuitive

approach for reconstructing 3D scenes and models.

The past few years have seen significant progress

toward this goal with the emergence of structure

from motion (SFM) methods in the research

community. There are two common approaches:

laser scanners and image-based modelling approach.

Laser scanners are very robust and highly accurate.

However, they are very costly and have restrictions

on the size and the surface properties of objects in

the scene (Hu et al., 2008). In contrast, an image-

based modelling approach reconstructs the geometry

of a complex 3D scene from a sequence of images.

The technique is usually less accurate, but offers a

very intuitive and low-cost method for

reconstructing 3D scenes and models.

We aim to create a low-cost system that allows

users to obtain 3D reconstruction of a scene using an

off-the-shelf handheld camera. The users accquire

images by freely moving the camera around the

scene. The system will then perform 3D

reconstruction using the following steps:

1. Image Accquisition and Feature Extraction

2. Feature Matching

3. Fundamental Matrix and Projection Matrix

Estimation

4. Bundle Adjustment and Refinement

5. Point Cloud Generation

6. Surface Reconstruction

The remainder of this paper is structured as follows.

Section 2 disucsses relevant literature in the field.

Section 3 presents our approach for reconstructing

3D scenes. Section 4 discusses our results. Section 5

concludes and summarises the paper and gives a

brief outlook on directions for future research.

2 RELATED WORK

2.1 Image-based Modelling

Various image-based modelling techniques have

Nguyen M., Wünsche B., Delmas P. and Lutteroth C..

REALISTIC 3D SCENE RECONSTRUCTION FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES TAKEN WITH A HANDHELD CAMERA.

DOI: 10.5220/0003376900670075

In Proceedings of the International Conference on Computer Graphics Theory and Applications (GRAPP-2011), pages 67-75

ISBN: 978-989-8425-45-4

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

been explored in recent years. In this section, we

discuss the most closely related work in image-based

3D reconstruction.

(Brown and Lowe, 2005) presented an image-

based modelling system which aims to recover

camera parameters, pose estimates and sparse 3D

scene geometry from a sequence of images.

(Snavely et al., 2006) presented the Photo

Tourism (Photosynth) system which is based on the

work of Brown and Lowe, with some significant

modifications to improve scalability and robustness.

(Schaffalitzky and Zisserman, 2002) proposed

another related technique for calibrating unordered

image sets, concentrating on efficiently matching

points of interest between images. Although these

approaches address the same SFM concepts as we

do, their aim is not to reconstruct and visualise 3D

scenes and models from images, but only to allow

easy navigation between images in three dimension.

(Debevec et al., 1996) introduced the Facade

system for modelling and rendering simple

architectural scenes by combining geometry-based

and image-based techniques. The system requires

only a few images and some known geometric

parameters. It was used to reconstruct compelling

fly-throughs of the Berkeley campus and it was

employed for the MIT City Scanning Project, which

captured thousands of calibrated images from an

instrumented rig to compute a 3D model of the MIT

campus. While the resulting 3D models are often

impressive, the system requires input images taken

from calibrated cameras.

(Hua et al., 2007) tried to reconstruct a 3D

surface model from a single uncalibrated image. The

3D information is acquired through geometric

attributes such as coplanarity, orthogonality and

parallelism. This method only needs one image, but

this approach often poses severe restrictions on the

image content.

(Criminisi et al., 1999) proposed an approach

that computes a 3D affine scene from a single

perspective view of a scene. Information about

geometry, such as the vanishing lines of reference

planes, and vanishing points for directions not

parallel to the plane, are determined. Without any

prior knowledge of the intrinsic and extrinsic

parameters of the cameras, the affine scene structure

is estimated. This method requires only one image,

but manual input is necessary.

2.2 Surface Reconstruction

Surface reconstruction from point clouds has been

studied extensively in computer graphics in the past

decade. A Delaunay-based algorithm proposed by

(Cazals and Giesen, 2006) typically generates

meshes which interpolate the input points. However,

the resulting models often contain rough geometry

when the input points are noisy. These methods

often provide good results under prescribed

sampling criteria (Amenta and Bern, 1998).

(Edelsbrunner et al., 1994) presented the well-

known α-shape approach. It performs a

parameterised construction that associates a

polyhedral shape with an unorganized set of points.

A drawback of α-shapes is that it becomes difficult

and sometimes impossible to choose α for non-

uniform sampling so as to balance hole-filling

against loss of detail (Amenta et al., 2001).

(Amenta et al., 2001) proposed the power crust

algorithm, which constructs a surface mesh by first

approximating the medial axis transform (MAT) of

the object. The surface mesh is then produced by

using an inverse transform from the MAT.

Approximate surface reconstruction works

mostly with implicit surface representations

followed by iso-surfacing. (Hoppe et al., 1992)

presented a clean abstraction of the reconstruction

problem. Their approach approximated the signed

distance function induced by the surface F and

constructed the output surface as a polygonal

approximation of the zero-set of this function.

Kazhdan et al. presented a method which is based on

an implicit function framework. Their solution

computes a 3D indicator function which is defined

as 1 at point inside model and 0 as point outside

model. The surface is then reconstructed by

extracting an appropriate isosurface (Kazhdan et al.,

2006).

3 METHODOLOGY

3.1 Feature Matching

The input for our reconstruction algorithm is a

sequence of images of the same object taken from

different views. The first step is to find feature

points in each image. The accuracy of matched

feature points affects the accuracy of the

fundamental matrix and the computation of 3D

points significantly. Many sophisticated algorithms

have been proposed such as the Harris feature

extractor (Derpanis. K, 2004) and the SUSAN

feature extractor (Muyun et al., 2004). We use the

SIFT (Scale Invariant Feature Transform) operator

to detect, extract and describe local feature

descriptors. Feature points extracted by SIFT are

GRAPP 2011 - International Conference on Computer Graphics Theory and Applications

distinctive and invariant to different transformations,

changes in illumination and have high information

content (Hua et al., 2007) , (Brown et al., 2005).

The SIFT operator works by first locating

potential keypoints of interest at maxima and

minima of the result of the Difference of Gaussian

(DoG) function in scale-space. The location and

scale of each keypoint is then determined and

keypoints are selected based on measures of stability.

Unstable extremum points with low contrast and

edge response features along an edge are discarded

in order to accurately localise the keypoints. Each

found keypoint is then assigned one or more

orientations based on local image gradients. Finally,

using local image gradients information, a

descriptor is produced for each keypoint (Lowe et al.,

1999).

Once features have been detected and extracted

from all the images, they are matched. Since

multiple images may view the same point in the

world, each feature is matched to the nearest

neighbours. During this process, image pairs whose

number of corresponding features is below a certain

threshold are removed. In our experiment, the

threshold value of 20 seems to produce the best

results.

The feature points matching between two images

could be achieved by comparing each keypoint of

the one image with keypoints of the other image.

The Euclidean distance

()

∑

−=−=

dim

),(

BABABAD

(1)

is used to measure the similarity between two

keypoints A and B. A small distance indicates that

the two keypoints are close and thus of high

similarity (Hu et al., 2008). However, a small

Euclidean distance does not necessarily mean that

the points represent the same feature. In order to

accurately match a keypoint in the candidate image,

we identify the closest and second closet keypoints

in the reference image using a nearest neighbour

search strategy. If the ratio of them is below a given

threshold, the keypoint and the closest matched

keypoint are accepted as correspondences, otherwise

that match is rejected (Hu et al., 2008).

3.2 Image Matching

The next stage of our algorithm attempts to find all

matching images. Matching images are those which

contain a common subset of 3D points. From the

feature matching stage, we have identified images

with a large number of corresponding features. As

Figure 1: Feature Extraction - The red arrow symbol

indicates the detected features. Detected features are

displayed as vectors indicating scale, orientation and

location.

Figure 2: Matched Features.

each image could potentially match every other

image, the problem may seem at first to be quadratic

in the number of images. However, it has been

shown by (Brown et al., 2005) that it is only

neccessary to match each image to k neighbouring

images in order to obtain a good solution for the

image geometry. In our system, we use k = 6.

3.3 Feature Space Outlier Rejection

We employ a feature space outlier rejection strategy

that uses imformation from all of the images in the

n-image matching context to remove incorrect

matches. It has been shown that comparing the

distance of a potential match to the distance of the

best incorrect match is an effective strategy for

outlier rejection (Brown et al., 2005).

The outlier rejection method works as follows:

Assuming that there are n images which contain the

same point in the world. Matches from these images

REALISTIC 3D SCENE RECONSTRUCTION FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES

TAKEN WITH A HANDHELD CAMERA

are placed in an ordered list of nearest-neighbour

matches. We assume that the first n - 1 elements in

the list are potentially correct, but the element n is

incorrect. The distance of the n

element is denoted

as outlier distance. We then verify the match by

comparing the match distance of the potential

correct match to the outlier distance. A match is only

accepted if the match distance is less than 80% of

the outlier distance, otherwise it is rejected. In

general, the feature space outlier rejection test is

very effective and reliable. For instance, a

substantial number of the false matches (up to 80%)

can be simply eliminated for a loss of less than 10%

of correct matches. This allows for a significant

reduction in the number of RANSAC iterations

required in subsequent steps (Brown et al., 2005).

3.4 Fundamental Matrix Estimation

At this stage, we have a set of putative matching

image pairs, each of which shares a set of individual

correspondences. Since our matching procedure is

only based on the similarity of keypoints, it

inevitably produces mismatches. Many of matches

will therefore be spurious. Fortunately, it is possible

to use a geometric consistency test to eliminate

many of these spurious matches. The epipolar

geometry of a given image pair can be expressed

using the fundamental matrix F.

For each remaining pair of matching images, we

use their corresponding features to estimate the

fundamental matrix. This geometric relationship of a

given image pair can be expressed as

0=Fvu

(2)

for any pair of matching features

vu ↔ in the two

images. The coefficients of the equation (2) can be

written in terms of the known coordinates u and v.

0''''''

333231232221131211

=++++++++ fyfxffyyfyxfyfxyfxxfx

()

01,,,',',',',',' =⇔ fyxyyyxyxyxxx

()

1,',' yxu =

and

()

1,, yxv =

where

[]

333231232221131211

,,,,,,,, ffffffffff =

From a set of n correspondent points, we can obtain

a set of linear equations of the form

''''''

⎥

⎦

⎤

⎢

⎣

⎡

= f

yxyyyxyxyxxx

nnnnnnnnnnnn

########

Thus a unique solution of F (up to scale) can be

determined if we are given 8 correspondences

(Hartley et al., 2003). Usually considerable more

than 8 correspondences are used because of

inaccuracies in the feature estimates. The resulting

overdetermined system can be solved resulting in a

solution optimal in a least squares sense, which is

then used to compute the fundamental matrix.

Many solutions have been proposed to estimate

the fundamental matrix. In our system, we use

RANSAC (Hartley et al., 2003) to robustly estimate

F. Inside each iteration of RANSAC, the 8-point

algorithm, followed by non-linear estimation step, is

used to compute a fundamental matrix (Hartley et al.,

2003). The computed epipolar geometry is then used

to refine the matching process.

3.5 Bundle Adjustment

Next, given a set of geometrically consistent

matches between images, we need to compute a 3D

camera pose and scene geometry. This step is critical

for the accuracy of the reconstruction, as

concentration of pairwise homographies would

accumulate errors and disregard constrains between

images. The recovered geometry parameters should

be consistent. That is, the reprojection error, which

is defined by the distance between the projections of

each keypoint and its observations, is minimised

(Brown et al., 2005).

This error minimization problem can be solved

using Bundle Adjustment. Bundle Adjustment is a

well-known method of refining a visual

reconstruction to produce joinly optimal 3D

structure and viewing parameter estimates. It

attemps to minimise the reprojection error between

observed and predicted image points, which is

expressed as the sum of squares of a number of non-

linear real-valued functions (Brown et al., 2005).

()()

[]

∑∑

−+−=

ijijijij

yyxx

(3)

where

),(

ijij

yxp =

denotes the coordinate of an

image point, and

)

(

ijij

yxp =

denotes the observed

image point.

The minimization can be formulated as a non-

linear least squares problem and solved with

algorithms such as Levenberg-Marquardt (LM

Such algorithms are particularly prone to bad local

minima, so it is important to provide a good initial

estimate of the parameters (Snavely et al., 2006).

The bundle adjustment algorithm starts by

selecting an initial image pair, which has a large

number of matches and a large baseline. This is to

GRAPP 2011 - International Conference on Computer Graphics Theory and Applications

ensure that the location of the 3D observed point is

well-conditioned. The bundle adjustment algorithm

will then estimate geometry parameters for the given

pair. Subsequent images are added to the bundle

adjuster one at a time, with the best matching

(maximum number of matched) image being added

at each step. Each image is initialised with the same

rotation and focal length as the image to which it

best matches. This has proved to work very well

even though images have different rotation and scale

(Snavely et al., 2006), (Brown et al., 2005).

Figure 3 shows the original model of the

Daliborka tower and its generated point clouds.

Figure 3: Model of the Daliborka tower (3D

Reconstruction Dataset. Centre for Machine Perception)

and its generated point clouds.

3.6 Surface Reconstruction

The final step is to reconstruct surfaces from the

obtained point clouds. Our objective is to find a

piecewise linear surface that closely approximates

the underlying 3D models from which the point

clouds was sampled (Kazhdan et al., 2006). Many

sophisticated surface reconstructions have been

proposed and extensively studied. In our system, we

employ the Power Crust algorithm (Amenta et al.,

2001) for remeshing the surfaces.

The Power Crust algorithm reconstructs surfaces

by first attempting to approximate the medial axis

transform of the object. The surface representation

of the point clouds is then produced by the inverse

transform. The algorithm is composed of 4 simple

steps: 1) A 3D Voronoi diagram is computed from

the sample points. 2) For each point s, select the

furthest vertex v

of its Voronoi cell, and the furthest

vertex v

such that the angle v

is greater than 90

degree. 3) Compute the Voronoi diagram of the

sample point and the Voronoi vertices selected from

the second stage. 4) Create Delaunay triangulation

from the Voronoi diagram in the previous stage. An

example of the resulting 3D model is illustrated in

figure 4. The complete algorithm is summarised in

figure 5.

Figure 4: The reconstruction of the model of the Daliborka

tower in Figure 3.

REALISTIC 3D SCENE RECONSTRUCTION FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES

TAKEN WITH A HANDHELD CAMERA

Algorithm for 3D Object Reconstruction

Input: n unordered and unconstrained images

1. Extract features from all input images using

SIFT operator

2. Find t nearest neightbors for each feature

3. For each image:

a. Select k candidate matching images

(those which have highest number of

features matched to this image)

b. Find geometrically consistent feature

matches using RANSAC to solve for

fundamental matrix between pairs of

images.

4. Compute 3D camera pose and scene geometry

using Bundle Adjustment.

5. Reconstruct surface for the obtained point

clouds.

6. (Future work) Apply hole-filling alogorithm for

the resulting model.

Output: 3D model of the object

Figure 5: Algorithm for 3D Object Reconstruction.

4 RESULTS

We have tested our system with a number of

different datasets, both indoor and outdoor scenes. In

all our test cases, the system produces good results

for rough, non-uniform and full-of-feature datasets.

Datasets with smooth and uniform surfaces often

result in inadequate number of 3D points generated,

since the feature detector (SIFT) has trouble

detecting and extracting features from these images.

The size of our test datasets varies from as few as 6

images to hundreds of images, which are all taken

with a simple handheld camera.

Dataset 1

The first data set consists of 37 images taken from

arbitrary view directions on ground level using a

normal consumer-level SONY DSC-W180 camera.

The reconstructed 3D model has 19568 faces and is

of good quality. The original object can be easily

identified. Some holes exist near concave regions

and near sharp corners. This is caused by large

variations in the point cloud density, which the

surface reconstruction algorithm was unable to deal

with.

Dataset 2

The second data set comprises 55 images taken at

ground level from two sides of the Saint Benedict

Church in Auckland, New Zealand. The other two

sides were not accessible. The images were taken

with the same camera as in the previous case and

under slightly rainy conditions. The reconstruction

results are satisfactory. The resulting model which is

Figure 6.1: The statue of Queen Victoria, Mt Albert Park,

Auckland - Original view.

Figure 6.2: Two views of the reconstructed model of the

statue of Queen Victoria. Number of images: 37

(2592x1944). Running time: approximately 4 hours

composed of 37854 faces has a high resemblance

with the original object and even the inaccessible

sides look plausible. A few details, such as some

windows, are missing causing holes in the model.

GRAPP 2011 - International Conference on Computer Graphics Theory and Applications

Figure 6.3a: Saint Benedict Church, Auckland.

Figure 6.3b: Reconstructed model of Saint Benedict

Church. The yellow circle indicates a reconstructed region

which was invisible in all input images. Number of

images: 55 (3648x2056). Running time: approximately

6h40 hours.

Dataset 3

The third data sets consisted of 63 images of Saint

George church. All images were taken from ground

level. Since the roof of that building is quite flat, this

resulted in missing information about the roof

structure and the reconstructed model contains large

gaps in that area. We intend to overcome this type of

problems with a sketch-based interface, which

allows the users to add missing geometric details.

The model contains of 28846 faces.

Figure 6.4a: Saint George (3D Reconstruction Dataset.

Centre for Machine Perception). Input images: 63

(2048x3072).

Figure 6.4b: Reconstructed model of Saint George

Church. Number of images: 63 (2048x3072). Running

time: approximately 9 hours.

Dataset 4

The fourth data set comprises 65 images taken from

many different views of the model of the Daliborka

tower shown in figure 3. The reconstruction result is

of very good quality and the final model has a high

resemblance with the original object. Small details

such as windows are also properly reconstructed.

The improved reconstruction is probably due to less

geometric features in the original model and a more

even illumination compared to outdoor scenes. The

resulting model is composed of 29768 polygons.

The computation time of this data set is over 9 hours.

Figure 7 summarizes the computation time and

parameters of the input data sets and resulting 3D

models for the presented examples. It can be seen

that the computation is quite slow, however, since it

can be performed in an offline process, this is

acceptable for our purpose.

REALISTIC 3D SCENE RECONSTRUCTION FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES

TAKEN WITH A HANDHELD CAMERA

Dataset

Statue of

Queen

Victoria

Saint

Benedict

Church

Saint

George

Church

Daliborka

Tower

Number of

Images

37 55 63 65


Resolution

2592x1944 3648x2056 2048x3072 4064x2704

Computation

time in hour

4.1 6.4 9.0 > 9 .0

Generated

Polygon

19568 37854 28846 29768

Figure 7: Comparison of the running time for

reconstructing 3D models from different input data sets

(photos). All examples were executed on a machine with

an Intel Quad-Core i7 and 6GB RAM.

5 CONCLUSIONS AND FUTURE

WORK

In this paper, we have discussed a novel approach

for reconstructing realistic 3D models from a

sequence of unconstrained and uncalibrated images.

Geometry parameters such as cameras’ pose are

estimated automatically using a bundle adjustment

method. 3D point clouds are then obtained by

triangulation using the estimated projection matrix.

We reconstruct surfaces for the point clouds to

recover the original model. In contrast to previous

approaches, we acquired the input images in just a

few minutes with a simple hand-held consumer level

camera. Our results demonstrate that our algorithm

enables inexperienced users to easily create complex

3D content using a simple consumer level camera.

This significantly simplifies the content creation

process when constructing virtual environments.

Problems, such as holes, still exist with the resulting

model. This is caused by large variation in the point

cloud’s density. Another disadvantage is that the

computation is quite expensive (the system takes

over 4 hours to process 37 images, and about 9 hours

for 63 images on a Intel Quad Core i7 with 6GB

RAM), but this is only an issue in applications

where the user needs the content immediately. A

common problem with this application is that not all

views of a model are obtainable. Especially the roof

is often not fully or not at all visible. Similarly in

some cases the backside of a building or object

might not be accessible. We propose to use sketch

input and symmetry information to "complete"

models in such circumstances. Additional future

work will concentrate on improved hole filling

algorithms and on speeding up the algorithm by

using an GPU implementation.

REFERENCES

Yang. R and Wünsche. B. (2010). Life-Sketch - A

Framework for Sketch-Based Modelling and

Animation of 3D Objects. AUIC '10 Proceedings of

the Eleventh Australasian Conference on User

Interface, Volume 106, pp. 1-9.

Hu. S, Qiao. J, Zhang. A and Huang. Q. (2008). 3D

Reconstruction from Image sequence taken with a

handheld camera. International Society for

Photogrammetry and Remote Sensing, Vol 37, pp. 1-4.

Zhang. J, Boutin. M, Aliaga. D. G. Robust Bundle

Adjustment for structure from motion. Image

Processing, 2006 IEEE International Conference, pp.

2185-2188.

Snavely. N, Seitz. M. S, Szeliski. R. (2006). Photo tourism:

Exploring photo collections in 3D. ACM Transactions

on Graphics - SIGGRAPH Proceedings, 25(3), 2006,

pp. 835-846.

Debevec. P, Taylor. C and Malik. J. Modeling and

Rendering Architecture From Photographs: A Hybrid

Geometry and Image-Based Approach. In SIGGRAPH,

1996, pp. 11-20.

Criminisi. A, Reid. I and Zisserman. A. Single View

Metrology. International Journal of Computer Vision

(2000), pp. 123-148 .

Hua. S and Liu.T. Realistic 3D Reconstruction from Two

Uncalibrated Views. International Journal of

Computer Science and Network Security, Volume 7

No.6 (2007), pp. 178-183.

Amenta. N, Choi. S, Kolluri. R. K. The Power Crust.

International Journal of Computational Geometry:

Theory and Applications (2000), Volume 19, pp. 127-

153.

Kazhdan. M, Bolitho. M, Hoppe. H. Poisson Surface

Reconstruction. ACM International Conference

Proceeding Series; Vol. 256 ( 2006), pp. 185-192.

Triggs. B, McLauchlan. P. F, Hartley. R. I, Fitzgibbon. A.

W. Bundle Adjustment - A Modern Synthesis. ICCV

'99: Proceedings of the International Workshop on

Vision Algorithms. Springer-Verlag. pp. 298–372.

Brown. M, Lowe. D. G. Unsupervised 3D Object

Recognition and Reconstruction in Unordered

Datasets. 3-D Proceedings of the Fifth International

Conference on Digital Imaging and Modelling, 2005.

pp. 110-119.

Kolmogorov, V and Zabih. R. Multi-camera Scene

Reconstruction via Graph Cuts. In European

Conference on Computer Vision (ECCV), May 2002.

pp. 82-96.

Derpanis. G. K. The Harris Corner Detector. 2004. URL:

http://www.cse.yorku.ca/~kosta/CompVis_

Notes/harris_detector.pdf

Muyun. W and Mingyi. H. Image Feature Detection and

Matching Based on SUSAN Method. First

International Conference on Innovative Computing,

Information and Control - Volume I (ICICIC'06), 2006.

pp. 322-325.

GRAPP 2011 - International Conference on Computer Graphics Theory and Applications

Lowe, D. G. Object recognition from local scale-invariant

features. Proceedings of the International Conference

on Computer Vision. 2. pp. 1150–1157. 1999.

Choudhury. R. Recognizing pictures at an exhibition using

SIFT. Biomedical Infomatics Department, Stanford

University, USA. EE 368 Project Report, 2007. URL:

http://www.stanford.edu/class/ee368/Project_07/report

s/ee368group11.pdf

Brown. M, Szeliski. R and Winder. S. Multi-Image

Matching using Multi-Scale Oriented Patches. In

Proceedings of the Interational Conference on

Computer Vision and Pattern Recognition, San Diego,

June 2005. Vol 1, pp. 510-517.

Hartley. R and Zissweman. A. MultipleView Geometry in

computer vision. Cambridge Press. 2003.

Kazhdan. M, M. Bolitho, H. Hoppe. Poisson Surface

reconstruction. Symposium on Geometry Processing

2006, pp. 61-70.

Hoppe. H, DeRose. T, Duchamp, T. McDonald, J. Stuetzle.

W. Surface reconstruction from unorganized points.

ACM SIGGRAPH 1992 Conference Proceedings, pp.

71-78.

Hoppe. H, DeRose. T, Duchamp, T. McDonald, J. Stuetzle.

W.. Mesh optimization. ACM SIGGRAPH 1993

Conference Proceedings, pp. 19-26.

Edelsbrunner. H and Mucke. E. P. Three-dimensional

alpha shapes. ACM Trans. Graphics 13 (1994), pp. 43-

72.

Edelsbrunner. H. Surface reconstruction by wrapping

finite point sets in space. Discrete and Computational

Geometry. The Goodman-Pollack Festschrift, ed. B.

Aronov, S. Basu, J. Pach and M. Sharir, Springer-

Verlag, 2003, pp. 379-404.

Cheng. H.L, Dey. T.K, Edelsbrunner. H and Sullivan. J.

Dynamic skin triangulation. Discrete Comput. Geom.

25 (2001), pp. 525-568.

REALISTIC 3D SCENE RECONSTRUCTION FROM UNSCONSTRAINED AND UNCALIBRATED IMAGES

TAKEN WITH A HANDHELD CAMERA
