A GENERAL-PURPOSE AND MULTI-LEVEL SCHEDULING

APPROACH IN ENERGY EFFICIENT COMPUTING

Mehdi Sheikhalishahi, Manoj Devare

Department of Electronics, Computer and System Sciences, University of Calabria, CS, Rende, Italy

Lucio Grandinetti, Demetrio Lagan

Department of Electronics, Computer and System Sciences, University of Calabria, CS, Rende, Italy

Keywords:

Green computing, Cloud computing, Scheduling, Energy, DVFS.

Abstract:

Green computing denotes energy efﬁciency in all components of computing systems i.e. hardware, software,

local area and etc. In this work, we explore software part of green computing in computing paradigms in

general. Energy efﬁcient computing has to achieve manifold objectives of energy consumption optimization

and utilization improvement for computing paradigms that are not pay-per-use such as cluster and grid, and

revenue maximization as another additional metric for cloud computing model. We propose a multi-level

and general-purpose scheduling approach for energy efﬁcient computing. Some parts of this approach such

as consolidation are well deﬁned for IaaS cloud paradigm, however it is not limited to IaaS cloud model.

We discuss policies, models, algorithms and cloud pricing strategies in general. In particular, wherever it is

applicable we explain our solutions in the context of Haizea. Through experiments, we show big improvement

in utilization and energy consumption in a static setting as workloads run with lower frequencies and energy

optimization correlates with utilization improvement.

1 INTRODUCTION

Primary use of energy in ICT is in data centers. Ef-

ﬁcient power supply design and evaporative cooling

rather than air conditioning are two common ways to

reduce the energy consumption; in addition, nowa-

days work on other areas such as resource manage-

ment and scheduling to optimize energy consumption

(Kim et al., 2007) (Dhiman et al., 2009) in computing

paradigms in order to be carbon neutral, more envi-

ronmentally friendly and reducing operational costs

is a hot research topic. In this paper, we present a

perspective on energy efﬁcient computing to achieve

manifold objectives of energy consumption optimiza-

tion, utilization improvement and revenue maximiza-

tion for cloud provider in cloud paradigm. This ap-

proach is a multi-level and general-purpose schedul-

ing approach which could be applied to all level of

resource management stack in any distributed com-

puting paradigm. There are many approaches, mech-

anisms and algorithms in the literature for energy efﬁ-

ciency, which most of them are special-purpose. The

proposed approach is architected in all layers of com-

puting paradigms and systems in order to be general

as much as possible. However, it can be extended or

specialized for different environments.

We focus our attention on exploring pricing strate-

gies, policies, models and exploiting the latest tech-

niques and technologies in modern processors to de-

sign scheduling algorithms to improve resource uti-

lization by using free spaces in scheduler’s availabil-

ity window and optimizing energy consumption.

Throughout this paper we refer to Haizea (Sotomayor,

2010), it is an open source lease (implemented as vir-

tual machines) management system which supports

pluggable scheduling policies, various scheduling al-

gorithms, etc. Being open, ﬂexible and modular for

further extensions and enhancements, and a general-

purpose VM-based scheduler, motivated us to select

Haizea as a tool for explaining where our solutions

could be applied. In brief, our paper makes the fol-

lowing contributions in the ﬁeld:

• We propose an abstract approach as a multi-

level and general-purpose approach in energy ef-

ﬁcient computing by exploring policies, models

and algorithms. We highlight that energy efﬁcient

Sheikhalishahi M., Devare M., Grandinetti L. and Lagan D..

A GENERAL-PURPOSE AND MULTI-LEVEL SCHEDULING APPROACH IN ENERGY EFFICIENT COMPUTING.

DOI: 10.5220/0003380000370042

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 37-42

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

scheduling is paradigm based; details of a pol-

icy, a model or an algorithm is different in dif-

ferent paradigms. We enumerate components of a

distributed system scheduler as frontend policies,

core scheduler, information service, and backend

policies.

• As part of core scheduler, we develop an energy

aware algorithm based on operations in DVFS.

Through experimentation we demonstrate how

using lower level frequencies as operating point

of processors, utilization and energy consumption

improves whereas total time increases. According

to the simulation results, energy consumption op-

timization correlates with utilization improvement

in a static setting.

Next parts of this paper are organized as follows. Af-

ter reviewing related works in Section 2, Section 3

goes over contemporary technologies for Energy Ef-

ﬁcient computing especially in processors (Section

3.1). Next, Section 4 proposes our multi-level and

general-purpose approach in Energy Efﬁcient com-

puting. Then, Section 5 discusses experimental re-

sults as early lessons on energy aware operations.

Finally, Section 5 presents our conclusions and dis-

cusses future work.

2 RELATED WORKS

In this decade, many approaches have been proposed

to address the problem of Energy Efﬁcient comput-

ing with special attention on energy consumption op-

timization and utilization improvement. The premise

in DVFS works is to shorten the idle period as much

as possible using time scaling, since it is always ben-

eﬁcial to do so from energy efﬁciency perspective.

In (Hong et al., 1999), there are some assumptions

to simplify DVFS-related operations, when the task

arrival times, workload and deadlines are known in

advance, these techniques target real time systems.

Techniques presented in (Azevedo et al., 2002) re-

quire either application or compiler support for per-

forming DVFS.

In (Varma et al., 2003) system level DVFS tech-

niques demonstrated. They monitor CPU utilization

at regular intervals and then perform dynamic scal-

ing based on their estimate of utilization for the next

interval.In contrast to the aforementioned works, the

approaches in (Knauerhase et al., 2008) characterize

the running tasks and accordingly make the voltage

scaling decisions only for those phases of the tasks

where it is beneﬁcial. Further, the policies take DVFS

decisions based on how beneﬁcial they are from CPU

energy savings perspective. Nonetheless, in (Dhiman

et al., 2008) it is shown that doing so does not neces-

sarily result in higher system level energy savings. In

(Dhiman et al., 2008) instead of using DVFS, simple

power management policies presented based on uti-

lizing the low power modes commonly available in

modern processors and memories.

In (Kim et al., 2007), authors proposed power-

aware scheduling algorithms for bag-of-tasks applica-

tions with deadline constraints on DVS-enabled clus-

ter systems. Eucalyptus (Nurmi et al., 2008), Nimbus

(Nimbus, 2010) as Virtual Infrastructure Managers do

not support scheduling policies to dynamically con-

solidate or redistribute VMs. Scheduling component

of OpenNebula (Sotomayor et al., 2009) (in Haizea

mode) and (Dhiman et al., 2009) are able to dynam-

ically schedule the VMs across a cluster based on

their CPU, memory and network utilization. Simi-

larly, scheduling algorithms in (Bobroff et al., 2007)

provide dynamic consolidation and redistribution of

VMs for managing performance and SLA i.e. service

level agreements violations. VMware’s Distributed

resource scheduler (VMWare, 2010) also performs

automated load balancing in response to CPU and

memory pressure. However, none of these scheduling

algorithms take into account the impact of resource

contention and policy decisions on energy consump-

tion.

Authors in (Laszewskiy et al., 2009) present an

efﬁcient scheduling algorithm to allocate virtual ma-

chines in a DVFS-enabled cluster by dynamically

scaling the supplied voltages. vGreen (Dhiman et al.,

2009) is also a system for energy efﬁcient computing

in virtualized environments by linking online work-

load characterization to dynamic VM scheduling de-

cisions to achieve better performance, energy efﬁ-

ciency and power balance in the system.

3 TECHNOLOGIES FOR

ENERGY EFFICIENT

COMPUTING

Modern hardware components such as processor,

memory, disk and network offer feature sets (Burd

and Brodersen, 1995) to support energy aware opera-

tions. Exploiting these feature sets in order to be more

energy efﬁcient is a very important and challenging

task, for example in modeling cost/performance, in

designing algorithms, in deﬁning policies, etc. In this

section, we review some of these feature sets.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

3.1 Technologies Embedded in

Processors

Nowadays processors offer two important features for

power-saving, cpuidle and cpufreq (Dynamic Voltage

and Frequency Scaling). In the cpuidle feature, there

are a number of CPU power states (C − states) in

which they could reduce power when CPU is idle

by closing some internal gates. The CPU C − states

are C0,C1, ...,Cn. C0 is the normal working state

where CPU will execute instruction and C1, ...,Cn are

sleeping state where CPU stops executing instruction

and power down some internal components to save

power. The cpufreq is another power-saving method

especially when CPUs are in load line, allowing quick

adjustment to frequency/voltage upon demand in

small interval. The key idea behind DVFS techniques

is to dynamically scale the supply voltage level of

the CPU so as to provide just-enough circuit speed to

process the system workload, thereby reducing the

energy consumption.

3.2 Electricity Consumption

Formulation

In this section, ﬁrst we formulate electricity consump-

tion and then we will discuss the effect of using two

different frequencies on energy consumption.

To formulate energy consumption model, we con-

sider that processors are homogeneous and DVFS-

enabled. They have n operating points for each core

in a multicore architecture as the following:

V F =

{

( f

, v

), ··· , ( f

, v

)

}

(1)

If a core runs at frequency f

it consumes v

volt-

age, respectively. According to (Kim et al., 2007)

the energy consumption for a computation which uses

v voltage to run at frequency f , is as the following

(quadratically dependent on the supply voltage level):

dynamic

≈ v

. f (2)

E ≈ E

dynamic

∑

dynamic

.∆t =

∑

. f .∆t (3)

Thus, if we have J number of jobs, the energy con-

sumption for scheduling them would be:

E ≈

∑

j=1

v( j)

. f ( j).t( j) (4)

In which v( j) and f ( j) are the amount of voltage

that is used and the core’s frequency while running

job j, respectively, from V and S sets deﬁned before.

Let’s have a job which requires t seconds execution

time to complete with a 1GHz processor. If this job

ran with two different operating points a(v

, s

) and

b(v

, s

), its energy consumption in these two scenar-

ios would be like the following:

≈ v

. f

= v

. f

= v

.t (5)

≈ v

. f

= v

. f

= v

.t (6)

so that:

> v

⇒ E

> E

(7)

If v

> v

this means that E

> E

, so energy con-

sumption in operating point a is greater than operating

point b while it will be ﬁnished earlier t

< t

4 A MULTI-LEVEL AND

GENERAL-PURPOSE

APPROACH IN ENERGY

EFFICIENT COMPUTING

We believe in order to approach conﬂicting goals of

Energy Efﬁcient computing, a multi-level approach

which applies to all the levels of workload’s path

in resource management stack should be devised.

Policies, cost/performance models and algorithms

within scheduling domain and pricing schemas in

cloud computing paradigm are the components which

should become or incorporate energy aware place-

ments, operations, techniques, models, etc.

4.1 Policies

Policies have profound impacts on Energy Efﬁcient

computing. Policies could be categorized into three

types: general-purpose policies (Dhiman et al., 2009),

architecture-speciﬁc (or infrastructure-speciﬁc) poli-

cies (Hong et al., 1999) application-speciﬁc (or

workload-speciﬁc) policies (Kim et al., 2007).

General-purpose policies are those that can be ap-

plied to most of the computing models. For instance,

CPU/cache-intensive workloads should run at high

frequencies, since by increasing frequency the per-

formance scales linearly for a CPU/cache-intensive

workload.Architecture-speciﬁc policies are deﬁned

based on the architecture or infrastructure in which

computation happens. Also application-speciﬁc poli-

cies are deﬁned around applications’ characteris-

tic.Workload consolidation (Hermenier et al., 2009)

policy is a sort of policy at the intersection of the

last two mentioned policies. Mixing various types of

workloads on top of a physical machine is called con-

solidation.Furthermore, consolidation-based policies

A GENERAL-PURPOSE AND MULTI-LEVEL SCHEDULING APPROACH IN ENERGY EFFICIENT COMPUTING

should be designed in such a way to be an effective

consolidation. In fact, effective consolidation is not

packing the maximum workload in the smallest num-

ber of servers, keeping each resource (cpu, disk, net-

work and memory) on every server at 100% utiliza-

tion, such an approach may increase the energy used

per service unit.

4.2 Algorithms

Algorithms constitute the next part of energy con-

sumption optimization. At this level, we are dealing

mainly with energy aware operations over resources

like processor, memory, disk and network. For in-

stance, for a processor we have lightweight operations

i.e. decrease/increase freq/volt, moving to an idle-

state or moving to a performance-state, and heavy-

weight operations such as suspend/resume/migrate

and start/stop on virtual machines or turn on/turn off

on physical machines.

Algorithms based on cost/performance models are

part of the scheduling to model cost vs. performance

of system states. A formal cost model quantiﬁes the

cost of a system state in terms of power and perfor-

mance. These models are exploited by the schedul-

ing algorithms to select the best state of a processor,

memory, disk and network. Sleep states’ power rate

and their latency i.e. the time needed to change to and

from the running state, are examples of parameters in

modeling cost vs. performance. In addition, mod-

els should specify how much energy will be saved in

state transitions and how long it takes for state transi-

tions. Models are also architecture and infrastructure

dependent e.g. internal of Multicore and NUMA sys-

tems have different features and characteristics to be

considered.

4.3 Pricing Strategy

At the highest level in the cloud interface, we have

pricing strategies such as Spot Pricing in Amazon

(Amazon, 2010) and recent pricing approaches in

Haizea or perhaps game theory mechanisms. These

mechanisms apply cloud policies that are revenue

maximization or improving utilization. More or less

these policies have the same goals, and also they

are energy efﬁcient, since they keep cloud resources

busy by offering various prices to attract more cloud

consumers. A dynamic pricing strategy like offering

cheaper prices for applications that will lead to less

energy consumption (or higher performance) based

on the current cloud status (workloads and resources)

compared to the others, is an Energy Efﬁcient pricing

schema.

4.4 Autonomic Scheduling

We enumerate components of a distributed system

scheduler as frontend policies, core scheduler, infor-

mation service, and backend policies. In summarizing

our approach, as a reference architecture, some com-

ponents of a distributed system scheduler are enumer-

ated as the following:

• Frontend policies: Admission control and pricing

are placed in this component. Job requests pass

via these policies before queueing.

• Core scheduler: Queue mechanism, various

scheduling algorithms and speciﬁc energy aware

algorithms such as those dealing with energy

aware operations (next Section) constitute core of

a scheduler.

• Information service: Scheduler’s slot table, avail-

ability window, etc. provide various information

to be exploited in different components.

• Backend policies: Host selection, mapping and

preemption constitute backend policies.

An autonomic scheduling approach could ex-

ploit this reference architecture to make various de-

cisions in different components, for example in queue

mechansim based on job’s characteristic, information

provided by information service, and other jobs in

the queue, a grouping or afﬁnity mechanism could

be implemented to reduce resource contention among

jobs; we are studying this research in another work.

Nonetheless, more details of this approach is out of

the scope of this paper.

5 EARLY LESSONS ON ENERGY

AWARE OPERATIONS

In this section, we review two main energy aware

operations from the scheduling point of view at the

processor level in a detailed manner compared to the

previous section.We have added DVFS feature in the

Haizea’ resource model to support a set of different

frequencies and voltages. We also extended duration

class of Haizea to keep track of running leases with

different frequencies and update the remaining time

of a lease accordingly. This section highlights the im-

portance of classifying compute intensive workloads

according to their demands and running them on the

most appropriate processor (i.e. operating on the fre-

quency required by the classiﬁed workloads).

CLOSER 2011 - International Conference on Cloud Computing and Services Science

5.1 Experimental Results

In the ﬁrst experiment, we run Haizea in simulation

mode to process 30 days of lease requests from the

SDSC Blue Horizon cluster job submission trace (Fei-

telson, 2010).We have done two separate experiments

with two different processors as the processing unit of

the nodes, with the following DVFS speciﬁcations:

Table 1: Operating Points for processor1.

Perf. state Frequency Voltage

P0 3600 1.4

P1 3400 1.35

P2 3200 1.3

P3 3000 1.25

P4 2800 1.2

Table 2: Operating Points for processor2.

Perf. state Frequency Voltage

P0 1600 1.484

P1 1400 1.420

P2 1200 1.276

P3 1000 1.164

P4 800 1.036

P5 600 0.956

In each run, we measured the whole experimen-

tation time, sum of all leases slowdown (all-leases-

slowdown) and energy consumption according to

equation (3) metrics as well as resource utilization.

Tables 3, 4 show these metrics for processor1 and

proessor2, respectively.

Table 3: SDSC Blue Metrics for processor1.

Freq Time(sec.) Slowdown(sec.) EC(Joule) Util

3600 2668402 9870 160560938160 0.68

3400 2690148 12552 149281951131 0.71

3200 2720196 14349 138431042048 0.75

3000 2748824 14473 127989300000 0.79

2800 2829515 20649 117954039168 0.82

This experiment reveals that as frequencies de-

crease, the running time increases slightly; resource

utilization increases and this is true also for slowdown

metric. On the other hand, there is a big decrease in

energy consumption. In conclusion, if we compare

the highest frequency run with the lowest frequency

run, we observe that while the running time increases,

but there is a big improvement for energy consump-

tion metric; in addition resource utilization increases

around 14% which for utilization is a very good gain.

Increasing utilization also is an energy efﬁcient ap-

proach, since resources would be busy and the waste

of energy would become less. Nonetheless, in case

of high load it would be better if we run applications

with the highest frequency, since during peak times

utilization is always high and by this technique com-

puting system could service more jobs. In fact, there

is a trade-off between load, utilization, cost, perfor-

mance, and sustainability. In all, in case of low load

which resource utilization is low, taking advantage of

running applications with low frequency is a promis-

ing technique to ﬁll out availability window of sched-

uler and increase utilization; on the other hand, in

high load times, we could run applications with the

highest performance of computing system. Trade-off

is a key in all these aspects. Furthermore, we have

the same observation for experimentation with pro-

cessor2.

Table 4: SDSC Blue Metrics for processor2.

Freq Time Slowdown EC Util

1600 2668402 9870 80180564496.3 0.68

1400 2739271 15832 73407588444.4 0.76

1200 2851453 22414 59276240343.1 0.85

1000 3269150 51268 49327094388.4 0.89

800 4017467 66126 39076964327.3 0.90

600 5336254 85235 33274070266.6 0.91

Table 5: SDSC DataStar Metrics for processor1.

Freq Time Slowdown EC Util

3600 2654637 9017 399685094928 0.58

3400 2658448 10538 371630049746 0.61

3200 2662737 12051 344615195392 0.65

3000 2667597 16264 318617648438 0.69

2800 2673151 20650 293637262464 0.74

In the second experiment, we studied the same

metrics on SDSC DataStar trace. Table 5 shows the

aforementioned metrics for processor1.

Interestingly, experimental results are promising with

big improvement in utilization and energy consump-

tion as workloads are running with low frequencies.

6 CONCLUSIONS AND FUTURE

WORKS

We have proposed a multi-level and general-purpose

approach for energy efﬁcient computing. In partic-

ular, we have added support for DVFS in Haizea’s

resource model to do some simulation experiments

regarding running workloads with different frequen-

cies in a static setting. Through experiments, we have

shown big improvement in utilization and energy

consumption as workloads are running with low fre-

quencies and the coincidence of Energy consumption

A GENERAL-PURPOSE AND MULTI-LEVEL SCHEDULING APPROACH IN ENERGY EFFICIENT COMPUTING

and utilization improvement.

We discussed different policies. Policies are

rules that we deﬁne based on the real facts and they

optimize related metrics based on our needs. Since

OpenNebula as a Virtual Infrastructure Manager

(Sotomayor et al., 2009) is integrated with Haizea

as an advanced scheduling backend, and they are

complementary to each other, we plan to implement

different policies in OpenNebula and Haizea.

We believe energy efﬁcient scheduling have to

be paradigms speciﬁc. Currently, we are exploring

consolidation based policies in HPC and cloud

paradigms in another work.

ACKNOWLEDGEMENTS

This work was supported by Ministry of University

and Research(MIUR) of Italy. We are grateful to

Borja Sotomayor for his support and help, develop-

ment of Haizea and his important contribution in the

ﬁeld. Also, we gratefully acknowledge Ignacio Mar-

tin Llorente and Wolfgang Gentzsch for their insight-

ful comments.

REFERENCES

Amazon (2010). Amazon ec2 spot instances.

http://aws.amazon.com/ec2/spot-instances/.

Azevedo, A., Issenin, I., Cornea, R., Gupta, R., Dutt, N.,

Veidenbaum, A., and Nicolau, A. (2002). Proﬁle-

based dynamic voltage scheduling using program

checkpoints. In DATE ’02, page 168.

Bobroff, N., Kochut, A., and Beaty, K. (2007). Dynamic

placement of virtual machines for managing sla viola-

tions. In International Symposium on Integrated Net-

work Management ’07.

Burd, T. D. and Brodersen, R. W. (1995). Energy efﬁcient

cmos microprocessor design. In Proceedings of the

28th Annual Hawaii International Conference on Sys-

tem Sciences.

Dhiman, G., Marchetti, G., and Rosing, T. (2009). vgreen:

A system for energy efﬁcient computing in virtualized

environments. In the 14th IEEE/ACM International

Symposium on Low Power Electronics and Design.

ISLPED ’09.

Dhiman, G., Pusukuri, K. K., and Rosing, T. S. (2008).

Analysis of dynamic voltage scaling for system level

energy management. In HotPower’08. the 2008 Work-

shop on Power Aware Computing and Systems.

Feitelson, D. (2010). Parallel workloads archive.

http://www.cs.huji.ac.il/labs/parallel/workload/.

Hermenier, F. et al. (2009). Entropy: a consolidation man-

ager for clusters. In VEE’09.

Hong, I., Kirovski, D., Qu, G., Potkonjak, M., and Srivas-

tava, M. B. (1999). Power optimization of variable-

voltage core-based systems. IEEE Trans. Computer-

Aided Design, 18(12):1702–1714.

Kim, K. H., Buyya, R., and Kim, J. (2007). Power aware

scheduling of bag-of-tasks applications with deadline

constraints on dvs-enabled clusters. In CCGRID,

pages 541–548.

Knauerhase, R., Brett, P., Hohlt, B., Li, T., and Hahn,

S. (2008). Using os observations to improve perfor-

mance in multicore systems. In IEEE Micro’08.

Laszewskiy, G. v., Wangz, L., Youngez, A. J., and Hez,

X. (2009). Power-aware scheduling of virtual ma-

chines in dvfs-enabled clusters. In Cluster 2009. Clus-

ter 2009.

Nimbus (2010). Nimbus toolkit project.

http://nimbusproject.org/.

Nurmi, D., Wolski, R., Grzegorczyk, C., Obertelli, G., So-

man, S., Youseff, L., and Zagorodnov, D. (2008). The

eucalyptus open-source cloud-computing system. In

Cloud Computing and Its Applications’08.

Sotomayor, B. (2010). Haizea.

http://haizea.cs.uchicago.edu/.

Sotomayor, B., Montero, R., Llorente, I., and Foster, I.

(2009). Virtual infrastructure management in pri-

vate and hybrid clouds. IEEE Internet Computing,

13(5):14–22.

Varma, A., Ganesh, B., Sen, M., Choudhury, S. R., Srini-

vasan, L., and Bruce, J. (2003). A control-theoretic

approach to dynamic voltage scheduling. In CASES,

pages 255–266.

VMWare (2010). Vmware dynamic resource scheduler.

http://www.vmware.com/ﬁles/pdf/drs datasheet.pdf.

CLOSER 2011 - International Conference on Cloud Computing and Services Science
