ON THE ECONOMICS OF HUGE REQUIREMENTS

OF THE MASS STORAGE

A Case Study of the AGATA Project

V´ıctor M´endez Mu˜noz

∗

, Mohammed Kaci, Andr´es Gadea and Jos´e Salt

IFIC - a mixted intitute CSIC and Universitat de Val`encia, Apt. Correus 22085, E-46071, Val`encia, Spain

Keywords:

Mass storage systems, Grid, Cloud, Costs analysis.

Abstract:

The AGATA is a shell detector for gamma-ray spectroscopy. At the present stage of the project the AGATA

collaboration is running an AGATA-demonstrator, which is a small part (only 12 Germanium crystals) of the

future full AGATA spectrometer (180 crystals). The AGATA-demonstrator is producing a huge amount of

raw-data with a high throughput. This paper focuses on the economics study regarding various options of

data storage for the AGATA spectrometer. We discuss the raw-data storage requirements on the demonstrator

and the forecasted storage size requirements for the full AGATA spectrometer. We also analyze the data

communication requirements. The case study focuses in costs analysis of three options: a dedicated storage,

a Grid storage and a Cloud storage service. In this manner, we explain how a huge size mass storage can

be affordable, and why the costs savings depends more in the particularity of the problems than in general

estimations. The results show a lower total costs for the Grid option.

1 INTRODUCTION

The AGATA collaboration (http://www-

win.gsi.de/agata/) is using a high purity Germanium

crystal based multi-detector array as a γ-ray spec-

trometer in multiple experimental conﬁgurations.

The AGATA spectrometer array produces a huge

amount of raw-data that would be reprocessed later

in order to reduce them by a factor of about 20. The

obtained reduced data are used by the physicists for

their analysis. The raw-data reprocessing is based on

the novel concepts of Pulse Shape Analysis (PSA)

and γ-ray tracking (Kaci et al., 2010). The raw-data

analysis have to be reprocessed off-line, since the

quality of the response of the AGATA detector array

depends on the performance of the PSA and data

tracking.

Nowadays, the AGATA collaboration is running

a demonstrator detector-array which is composed

of 4 triple highly-segmented Ge semiconductor

detectors (12 Ge crystals). The full AGATA γ-ray

spectrometer, with 180 Ge crystals, will run in the

next few years. With the demonstrator conﬁguration,

the raw-data production is in average of 10TB by

experiment. Thus, each triple detector throughput

is 5 TB in average. Depending on the experimental

∗

Currently at PIC: vmendez@pic.es

conﬁguration, with more detectors the ﬁlters of the

data taking are less effective, a complete ball can

increase to 5 TB in average for a triple detector.

More than 30 experiments a year are forecasted in

the AGATA collaboration. With this premises we

are talking about a mass storage requirement range

from 5PB/year up to 10PB/year for the AGATA

raw-data production. To particularize the case study,

the off-site storage for backup and recovery system is

not contemplated.

When the mass storage scales up to a huge size,

the storage system becomes critical regarding the

adoption of an overall computing solution. As the

storage system can be separated from the rest of the

computing solution, in this paper we focus on the

mass storage requirements, regardless of the other

computing requirements of the problem. Another im-

portant factor of this case study is, the collaborative

environment between the distributed research groups

of the AGATA experiments. This feature introduces

some constrains to the problem, related with the

raw-data accessibility while permissions are granted.

We make this case study in order to know how

a huge mass storage can be affordable, and why

the costs savings depends more in the particularity

of the problem than in the general estimations. For

this reasons, in this paper we focus in a detailed

507

Méndez Muñoz V., Kaci M., Gadea A. and Salt J..

ON THE ECONOMICS OF HUGE REQUIREMENTS OF THE MASS STORAGE - A Case Study of the AGATA Project.

DOI: 10.5220/0003380505070511

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 507-511

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

analysis of the costs. In Section 2 we analyse the

different cost factors. We identify the important cost

factors for a mass storage provider. Furthermore,

we qualify the costs analysis within the constrains

of the AGATA project. In Section 3, we focus in

the AGATA costs estimations of the storage service.

Particularly, we analyse a dedicated storage system,

a Data Grid solution within the European Grid

Initiative (http://www.egi.eu/projects/egi-inspire)

infrastructure, and a solution with the Amazon

Simple Storage (S3) (http://www.amazon.com/s3)

service. Section 4 discusses the results in the AGATA

context. The case study is summarized in Section 5.

2 RELEVANT MASS STORAGE

COSTS OF THE AGATA

STORAGE REQUIREMENTS

In this section we follow the general guidance in

(Alek Opitz and Szamlewska, 2008) to estimate the

costs of a Grid resource provider. Several parameters

have to be taken into account. Some of them are di-

rectly assumed by the AGATA project, other costs are

assumed as a best effort by the different partners of

the AGATA collaboration. Both of them have to be

taken into account in the costs analysis. Therefore,

we classify the typical parameters as follows

• Storage Total Costs of Ownership (TCO):

• Hardware costs.

• Business premises costs.

• Software costs.

• Personel costs.

• Costs of data communication with the computing

center.

The following subsections analyse the costs

breakdown differences between the three options: the

dedicated storage, the Grid storage and the Cloud In-

frastructure as a Service (IaaS).

2.1 Storage Total Costs of Ownership

The TCO is the aggregated costs of the hardware ac-

quisition, the replacement of defective components,

the business premises including electricity, the soft-

ware and the personnel costs. The dedicated storage

and the Grid storage require the acquisition of the

hardware, software installation and the maintenance

in the datacentre. The TCO in Cloud is included in

the storage service price.

Some papers about storage TCO have already been

published. Some of them are vendor reports focused

in consulting optimization of the TCO (IBM, 2003;

Marrill, 2008). Such models are based on general pa-

rameters for a wide range of storage systems. For

our particular case we have found in (Moore et al.,

2008), real costs analysis of the storage infrastruc-

ture at the San Diego Computing Center (SDSC). The

SDSC storage features are valid requirements for the

AGATA storage.

• The storage size of the SDSC costs analysis is

7PB, while in AGATA is about 10PB/year.

• The storage is a system of an archival in tapes and

disk-caching.

• The storage is standard range since the data are

”write-once-read-rarely”.

• The service is 24x7.

The SDSC storage reports a TCO breakdown in the

metric of $/TB/year. Table 1 shows these costs in

C/TB/year. The upper part of the table are transla-

tions from the SDSC costs analysis. The Grid speciﬁc

costs are explained below.

Table 1: Estimated normalized annual costs of storage.

TCO Breakdown SATA Disk Archival Tape

Costs TB/year 1 PB 9 PB

Disk/tape media 396 74

Other capital 174 122

Maintenance 170 81

Facilities 118 18

Personel 251 74

Dedicated TOTAL 1110 370

Other capital 116 81

Maintenance 0 0

Personel 168 49

Grid TOTAL 798 228

Hardware costs are the disk/tape media costs, and

also the other capital costs referring the replacement

components, the ﬁle system servers and the storage

area network. The maintenance costs are referred to

the support and the software licensing. Facilities costs

are the business premisses including electricity, es-

timated of the ”ﬂoor space” cost in the datacentre.

The personnel costs are 3 Full-time Person Equivalent

(FPE). The above are the translation in Euros from the

SDSC datacentre, to apply in the dedicated storage

option.

The Grid option has reductions in some of the

costs. In general terms, all the ﬁxed costs are reduced

CLOSER 2011 - International Conference on Cloud Computing and Services Science

508

because of the economy of scale, sharing resources

with other Virtual Organizations (VOs). In our par-

ticular case study, for simplicity, minor ﬁxed costs

differences, like building amortization, are not con-

sidered. There are also vendor discounts for capital

purchases and maintenance, which are difﬁcult to es-

timate, because it is not unusual that the negotiated

pricing is conﬁdential. Such discounts can be impor-

tant in the Grid option compared with the dedicated

datacentre, but they are not taken in consideration for

Grid costs estimation.

In other capital costs of the Grid, the ﬁle sys-

tem servers and the storage area network have costs

reduction because they are shared with other VOs.

We have estimate a reduction of 2/3, which is

easy to reach in the Grid context of EGI. Regard-

ing the maintenance and licensing costs, we take

the example of our institute complex Grid infras-

tructure. We have a site belonging to the federated

Tier-2 for the ATLAS experiment (http://atlas.ch/),

and a site belonging to the Grid-CSIC infrastructure

(http://www.grid.csic.es), with a total storage near of

1 PB. These infrastructures are integrated in the Na-

tional Grid Initiative NGI/EGI, and there is an oper-

ational collaboration with the rest of Grid site teams,

for coordination and self-support. The operation of

this complex Grid site includes not only the data-

centre, but also computing resources administration.

This complex infrastructure is supported by a team

of 3 FTE persons working without third party main-

tenance support. Additional support is obtained from

the collaboration with the NGI-EGI operation groups.

This is possible in the collaborative environment of

the Grid communities, with a know-how sharing con-

text. About licensing, the gLite middleware is pro-

vided by the European Middleware Initiative (EMI)

(http://www.eu-emi.eu/) with opensource license cut

off cost. The mass storage systems supported by gLite

middleware are dCache and CASTOR (Burke et al.,

2009). In our Grid complex infrastructure we also

use Lustre (SunMycrosytems, 2009), which neither

have licensing costs. Other third party mass stor-

age systems can have licensing costs. If we consider

these premises, we can take a similar scheme for the

AGATA storage Grid option and cut off the mainte-

nance and licensing costs. Finally in the costs break-

down analysis, Table 1 assigns to the Grid storage

of AGATA a 2 FPE, 1 FPE less than the dedicated

datacentre, because the economy of scale in the oper-

ational tasks which can be done for many VOs.

Since most of the Cloud providers offer a wide

range of storage service, the AGATA storage require-

ments are in the standard range of the Cloud storage.

2.2 Data Communication Costs

In what concerns AGATA, the data source is the Data

Acquisition system (DAQ). The DAQ includes a pre-

mium range storage system, which is able to deal with

the raw-data throughput of the AGATA detector. For

cost reasons, the DAQ storage size is reduced to the

space required for processing the data of the active

experiment. Therefore, the DAQ needs to transfer the

produced raw data in quasi-real time to the mass stor-

age system. In the following we analyse the transfer

requirements.

In the Introduction Section, we have shown

that the experimental data produced by the AGATA

demonstrator with 4 triple detectors is 10TB on aver-

age. For network requirements analysis we take into

account not the average but the peak throughput of

the experiments, which is about 20TB for the AGATA

demonstrator. The peak experiments produce 5TB for

a tripledetector throughput. If we considerer the men-

tioned ﬁltering factors, this throughput in the com-

plete AGATA ball can reach 10TB, which gives a to-

tal of 600TB for the peak experiments.

In our transfer tests we get 170MB/s of effec-

tive transfer rate. Therefore, for a peak experiment

600TB of raw data is transferred in 42 days. This

is clearly unscalable since there are about 30 exper-

iments planned for each year, and the AGATA DAQ

has storage space for only one experiment. For this

peak size experiments the AGATA project can book

some extra off-time before the next experiment. The

transfers can start during the data taking, so the peak

transfers can take two weeks. For our peak network

requirement, 600TB in 14 days, it is necessary an ef-

fective transfer rate of 520MB/s, equivalent to 4,160

Mbps, which requires a dedicated network of 5Gbps

rate.

This analysis illustrates a premium network re-

quirements, not only at physical layer but also in the

transfer software, to scale to the 60 triple detector data

transfer. Private leased lines are dedicated circuits,

with price depending basically on speed and distance.

A good option for our purpose can be two circuits of

OC-48 (Optical Circuit at 2,448 Mbps) to reach the

required 5Gbps of full time dedicated connection. A

estimation in (NortelNetworks, 2009) says that a 18

months leasing is 2,500 £per ﬁbre mile, including in-

stallation and the rest of the costs. This is equivalent

to 1,281

C/km for a year channel leasing. Vendors

discount are usual for multiple channels after the ﬁrst

one, but it is difﬁcult to estimate, for our purpose we

take the costs of two complete channels. For the dis-

tance estimations, we take the distance between the

AGATA demonstrator DAQ and the data storage, ab-

ON THE ECONOMICS OF HUGE REQUIREMENTS OF THE MASS STORAGE - A Case Study of the AGATA Project

509

out 100 Km.

In the dedicated storage option, the storage system

can be directly endorsed to the DAQ. In this case, for

the data transfer from the source to the storage sys-

tem, the cost is included in the hardware costs of the

datacentre local network. Traditionally, the physics

experiments have used this schema. In these cases,

the raw-data are stored in tapes at the DAQ, and each

research group took the tapes and transport them to

their institute, where they process the raw-data on

their own. Such schema is not possible in the AGATA

collaboration for two reasons. The ﬁrst one is: the

raw-data are owned by the entire collaboration for

security and scientiﬁc reasons, with the appropriate

access rights to the different experimental raw-data.

The second reason is: the AGATA raw-data size of

each experiment becomes the processing a not trivial

matter, so research groups have to join forces for an

affordable computing process. Thus, in AGATA we

are talking of raw-data transfer and processing on ap-

propriate computing performance. In this manner, we

have to consider the transfer costs between the stan-

dalone storage system and the computingcenter of the

raw-data processing.

The Grid option has to estimate the transfer costs

from the DAQ to the Grid storage. Grid Computing

technologies offers the possibility to send the process-

ing jobs to run at the sites where the data are located,

therefore, no additional remote transfers are needed.

Cloud companies incurs higher network charges

from their service providers for storage of terabytes

(Myerson, 2008). Since AGATA is a petabytes stor-

age, a way to obtain better network costs is to negoti-

ate with the cloud provider a third-party network leas-

ing. In this case study, we consider a such third-party

network leasing, without Cloud provider charges, for

the costs estimations. The Cloud option requires, at

least, 1 raw-data transfer from the DAQ. Additional

transfer of the raw-data can be needed if the process-

ing is performed out of the Cloud.

3 ESTIMATED COSTS OF THE

MASS STORAGE OPTIONS

In this section we analyse the storage models of the

different options, and we get the cost estimations in

year basis following the premises of Section 2. The

storage costs on delivery to the Computing Center is

the addition of the storage TCO and the data commu-

nication costs.

The storage TCO/year for the dedicated storage

and the Grid storage options is in the Equation 1, con-

sidering the costs of Table 1.

TCO = Disk

C/TB∗ 1PB+ Tape C/TB∗ 9PB (1)

Where Disk and Tape have different values for the

dedicated storage and the Grid storage.

For the Cloud storage option we have choosen a

standard storage service, good enough for AGATA

storage requirements shown in Subsection 2.1. A

Cloud storage option which fulﬁl those requisites is

the Amazon Simple Storage Service(S3). The price

list depends on the location of the Amazon S3 bucket,

(the European Union in our case study), and the stor-

age used, obtaining discounts for bigger sizes of stor-

age used. The S3 prices are in $/GB/month. The

storage size requirements in a year is about 10PB for

the full AGATA spectrometer, giving in average 833

TB per month. This affects to the price range, in

the ﬁrst year different prices have to be applied until

reach the lower unit price for the bigger S3 storages

over 5,000TB. Equation 2 shows the total year TCO

in function of the month i charge.

TCO = 833∗ t

∑

i=2

(833∗ i))∗ t

∑

i=5

(833∗ i))∗ t

(2)

Where t

> t

are the different S3 monthly price-

list for the accumulated storage size. Nowadays, in

November of 2010, these S3 price-list is for our case:

= 71.99,t

= 60, 62,t

= 41, 68 in

C/TB/month.

The next years storage costs would be accumulated

with the previous years costs. This is the same for the

three evaluated options. Considering these premises

the next years costs addition to the previous TCO is

in Equation 3.

TCO = (

∑

i=1

(833∗ i)) ∗ t

(3)

Regarding the data communication explained in

Subsection 2.2, the standard connection is a 2 chan-

nels OC-48 of a leased private line of 100km distance,

with a year costs of 256,200

C/year. The dedicated

storage option, endorsed to DAQ, requires a connec-

tion from dedicated storage to the Computing Center.

The Grid option requires a connection from DAQ to

the Grid storage. The Cloud option requires a connec-

tion from DAQ to Cloud and other from Cloud to the

Computing Center.

Table 2 summarizes the year costs of the three op-

tions in C, to be accumulated to the previous years

storage costs. Dedicated and Grid is from Equation 1,

Cloud year 1 is from Equation 2 and Cloud of the next

years (+1) is from Equation 3.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

510

Table 2: Total acumulative for C/10PB/year on delivery.

Storage Storage Transfer TOTAL

Option TCO Costs

Dedicated 4,546,560 256,200 4,802,760

Grid 2,918,400 256,200 3,174,600

Cloud

year 1 2,875,357 512,400 3,387,757

Cloud

year +1 2,708,116 512,400 3,220,516

4 DISCUSSION OF THE RESULTS

It is important to comment a particular issue of the

Cloud solutions, which is related with the costs . With

a traditional datacentre the costs are up-front, it is

a Capital Expenditure (CapEx), while Cloud Com-

puting is pay-as-you-go, it is an Operating Expenses

(OpEx). CapEx refers to an investment for a long pe-

riod of time. CapEx assets are depreciated in value

over time on the accounting. OpEx refers to expenses

incurred excluding cost of goods sold, taxes, depreci-

ation and interest. Cloud Computing moves CapEx to

OpEx, but there is no reason to think that there is a ﬁ-

nancial beneﬁt from here. Anyway, they are hardware

costs to be considerated, both in the storage acquisi-

tion and in the price of the IaaS.

It is also important, the difference between the

storage acquisition options and the Cloud storage op-

tion. The Cloud costs are the Amazon S3 prices,

therefore, it is true cost value, while in this sense, the

storage acquisition options have estimated costs. This

is an economical forecast advantage to the Cloud op-

tion.

In this context, Table 2 shows the Grid option with

the lowest total costs of storage and data communica-

tions. The lowest TCO/year without transfer costs, is

for the Cloud option.

Another consideration of Cloud storage is about

the possible integration with Cloud Computing for

raw-data processing. In this case, the storage upload

is raw-data and the storage download is reduced data

in a factor of 20. The communications requirements

would be a connection of two channels OC-48. With

this scheme, regardlessof Cloud Computing costs, the

Cloud storage on delivery is lower costs than the op-

tions in Table 2.

A ﬁnal consideration in the Grid option is about

the integration of a complete Grid solution for stor-

age, data management and computing processing. In

this case, communications from DAQ can be inte-

grated in the Grid infrastructure to cut off the costs,

because the economy of scale, sharing higher perfor-

mance networks with others VO.

5 CONCLUSIONS

This case study analyses three options for a huge re-

quirement mass storage system, in the context of the

AGATA collaboration. We have shown how such a

storage system can be affordable, focusing on the par-

ticularity of the problem. The estimated metrics have

been taken from the AGATA demonstrator detector

array (12 Ge crystals) throughput testing, and also

from the data transfer tests. Considering the results,

this case study supports the adoption of Grid mass

storage system for the AGATA collaboration.

ACKNOWLEDGEMENTS

We are greatly indebted to the founding agency Span-

ish National Research Council-CSIC for their support

from project Grid-CSIC.

REFERENCES

Alek Opitz, H. K. and Szamlewska, S. (2008). What does

grid computing costs? Journal of Grid Computing,

6(4):385397.

Burke, S., Campana, S., Lanciotti, E., Lorenzo,

P. M., Miccio, V., Nater, C., Santinelli, R.,

and Sciab‘a, A. (2009). glite 3.1 user guide.

http://glite.web.cern.ch/glite/documentation/.

IBM (2003). Ibm storage solutions: A total cost of owner-

ship study. Technical report, IBM.

Kaci, M., Rechina, F., Mendez, V., Salt, J., and Gadea, A.

(2010). Testing the agata pulse shape analysis and g-

ray tracking on the grid. In 4th Iberian Grid Infras-

tructure Conference Proceedings, page 482484. Uni-

versidad do Minho, Netbiblio.

Marrill, D. R. (2008). Storage economics: Four principles

for reducing total cost of ownership. Technical report,

Hitachi Data Systems.

Moore, R. L., DAoust, J., McDonald, R. H., and Minor, D.

(2008). Disk and tape storage cost models. Technical

report, San Diego Supercomputer Center, University

of California.

Myerson, J. M. (2008). Cloud computing versus grid com-

puting: Service types, similarities and differences, and

things to consider. Technical report, IBM - developer-

Works.

NortelNetworks (2009). Managed wavelength

services: The new wave bandwith op-

tions, commercial applications and values.

http://www.datasheetarchive.com/datasheet-pdf/010/

DSA00164117.html.

SunMycrosytems (2009). Sun lustre storage system featur-

ing the lustre ﬁle system. http://www.sun.com/

servers/hpc/storagecluster/datasheet.pdf.

ON THE ECONOMICS OF HUGE REQUIREMENTS OF THE MASS STORAGE - A Case Study of the AGATA Project

511
