BOTCLOUDS

The Future of Cloud-based Botnets?

Kassidy Clark, Martijn Warnier and Frances M. T. Brazier

Faculty of Technology, Policy and Management, Delft University of Technology, Delft, The Netherlands

Keywords:

Botnet, Click fraud, Cloud, Cloud services, DDoS, Extrusion detection, Intrusion detection, Security.

Abstract:

Many Cloud Service Providers (CSP) offer access to scalable, reliable computing resources following a pay-

as-you-go model. Research into security of the Cloud focusses mainly on protecting legitimate users of Cloud

services from attacks by external, malicious users. Little attention is given to prohibit malicious users from

using the Cloud to launch attacks, such as those currently done by botnets. These attacks include launching

a DDoS attack, sending spam and perpetrating click fraud. This paper discusses the threat of Cloud-based

botnets, or botclouds and the need for new techniques to detect them. Two experiments show how simple and

cheaply these attacks can be launched from botclouds.

1 INTRODUCTION

Cloud services refer to the provisioning of hardware

and software resources across the Internet (Armbrust

et al., 2010). Cloud Service Providers (CSP) typically

offer both reﬁned software services, such as databases

and raw compute resources, such as storage or pro-

cessing power. Customers often use these services

following a pay-as-you-go model. Using Cloud ser-

vices, companies can choose to, in effect, rent com-

puter resources, rather than to invest in them outright,

also providing elasticity of computing resources. For

instance, if a cloud service customer discovers that

he has over estimated his needs and has thus over-

provisioned cloud services, he can scale down the size

of his cloud. The reverse is also true, if a customer

ﬁnds that he has under-provisioned cloud services, he

can scale up the size of his cloud with little effort.

There are a growing number of CSPs includ-

ing Microsoft, Google and Amazon Web Services

(AWS). AWS is currently the largest

. AWS offers a

web interface for human access, as well a scriptable,

Java-based Application Programming Interface (API)

for automated access.

Research into the security of the Cloud focuses

primarily on protecting legitimate users of Cloud ser-

vices from attacks by external, malicious users (An-

thes, 2010; Maggi and Zanero, 2010; Chen et al.,

Techno-Pulse. http://www.techno-pulse.com/2009/12/

top-cloud-computing-service-providers.html. Accessed:

November 2010.

2010). Little attention has been given to the possi-

bility of malicious users using the Cloud to launch at-

tacks, such as those currently performed by botnets.

There is evidence that botnets are moving into the

Cloud

. Due to their ease of use, high reliability and

scalability, Cloud services provide malicious users a

new platform with which to launch attacks, literally

with the click of a button.

This paper discusses the possibility of attacks

originating from Cloud-based botnets, or botclouds.

The simplicity of these attacks is demonstrated in two

experiments. Section 2 gives an overview of botnets,

including attacks, structure and detection techniques.

The concept of botclouds is presented in Section 3.

Two botcloud attacks are demonstrated in Section 4.

Finally, the implications of botclouds and botcloud

detection are discussed in Section 5.

2 BOTNETS

A bot is a partially autonomous piece of software that

can be controlled remotely. The person controlling a

bot is referred to as a botmaster. A group of bots un-

der control of a botmaster is referred to as a botnet. A

botnet is created by ﬁrst infecting a computer without

the knowledge or consent of its owner by, for exam-

ple, sending a virus as an email attachment (Ianelli

SecurityFocus. http://www.securityfocus.com/brief/

1046. Accessed: November 2010.

597

Clark K., Warnier M. and M. T. Brazier F..

BOTCLOUDS - The Future of Cloud-based Botnets?.

DOI: 10.5220/0003381305970603

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 597-603

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

and Hackworth, 2005). Once a computer is infected

with bot software, it contacts the botmaster. At this

moment, the bot becomes part of the botnet. The bot-

master can then send orders to the bot to carry out

(malicious) tasks. Botnets can comprise thousands or

even millions of bots, such as the BredoLab botnet

estimated to have 30 million bots

2.1 Botnet Attacks

Common attacks launched by botnets include (1)

launching Distributed Denial of Service (DDoS) at-

tacks, (2) sending spam email and spreading malware,

(3) stealing private information and (4) performing

click fraud (Jing et al., 2009; Ianelli and Hackworth,

2005).

DDoS attacks are used to overload a target’s

servers so that legitimate trafﬁc can no longer access

them (Mirkovic and Reiher, 2004). This is achieved

by simultaneously ﬂooding a target domain with re-

quests until the response time to load a webpage is

longer than a legitimate user is willing to wait. Thus,

the system appears to have crashed. In some cases,

just the threat of a DDoS attack is often enough for

criminals to extort money from businesses.

Another common use of botnets is the sending

of spam and malware. It is estimated that more

than 97% of all email is unsolicited, bulk email (also

known as spam) and the majority is generated by bot-

nets (Anselmi et al., 2010). E-mail containing spam

messages or malicious attachments can be sent from

an infected machine using either a user’s personal ac-

count or their Internet Service Provider’s (ISP) e-mail

server. If each single machine sends only 10 such

messages per day, the massive size of most botnets

can thus send millions of spam messages each day.

Private information is stolen from bot infected

computers using keyloggers or making periodic

screenshots (Ianelli and Hackworth, 2005). Keylog-

gers capture passwords and usernames at the moment

that these are entered into a protected website, such as

a personal email site. In addition, a bot can identify

and copy sensitive ﬁnancial data, such as credit card

information.

Click fraud can be used to attack different targets

for different reasons. A typical use of click fraud is

to intentionally click on advertisements from pay-per-

click providers, such as Google or Adsense (Kshetri,

2010). There are two general motivations for this kind

of fraud: inﬂationary and competitive (Wilbur and

Zhu, 2009). Inﬂationary click fraud is when attackers

InfoSecurity. http://www.infosecurity-magazine.com/

view/13620/bredolab-downed-botnet-linked-with-

spamitcom/. Accessed: November 2010.

can earn money by clicking on advertisements they

themselves are hosting. The pay-per-click providers

then charge the targeted company for these clicks and

pass this money on to those who actually host the ad-

vertisements, in this case the attackers.

Competitiveclick fraud is when attackers click the

advertisements of a company with the goal of driving

up that company’s advertising costs. In this case, the

attackers click on any advertisement of that company,

regardless of where they are hosted and regardless of

who receives money for the click.

Another use of click fraud is to artiﬁcially inﬂu-

ence online polls. Online polls allow users to vote

on various topics. Examples include news sites that

poll how their readers feel about a certain news story

or software developers that poll their users for feature

requests. Often there is no monetary incentive to in-

ﬂuence the results, but rather only a psychic beneﬁt

such as enjoyment.

2.2 Botnet Classiﬁcation

Detecting and combating botnets remains a difﬁcult

task, but some progress has been made. Different bot-

net detection techniques correspond to different net-

work structures (Dagon et al., 2007) and communica-

tion protocols (Jing et al., 2009). Based on these two

attributes, two general classiﬁcations are recognized:

Internet Relay Chat (IRC) based botnets and (newer)

Peer to Peer (P2P) based botnets.

IRC is a text-based messaging protocol based on

the traditional client/server model. An infected com-

puter acts as an IRC client and contacts the IRC server

to join the network. The botmaster then uses the IRC

server to send instructions and data to the client for

execution. This structure is highly centralized around

the IRC server(s). If a server is taken ofﬂine, all bots

that depend on it will no longer be able to receive or

execute further instructions.

P2P based botnets use a more decentralized, dis-

tributed model without a centralized server. Each bot

has a list of known peers comprising only a small part

of the entire botnet. A botmaster sends data and in-

structions to one or more peers, that in turn pass these

on to all other peers they know. These messages then

traverse the entire network. As there is no central

server, there is also no central point of failure, thus

making this class of botnet more robust against attack.

Botnet creators havefound that truly decentralized

networks are relatively slow to organize and react to

new commands, so most P2P based botnets employ

a hybrid structure. Hybrid structures use a layer of

super-peers that maintain long lists of known peers.

When a new peer joins the network, it ﬁrst contacts a

CLOSER 2011 - International Conference on Cloud Computing and Services Science

598

super-peer and downloads this list. This download

process and the role of these super-peers makes the

hybrid structure more prone to detection by system

users and administrators (Schoof and Koning, 2007).

2.3 Botnet Detection Techniques

The main methods for traditional botnet detection are

honeypots and intrusion detection (Zeidanloo et al.,

2010). Honeypots are unprotected computers that are

intentionally (allowed to be) infected by botnets. Re-

searchers observe the bots to learn about the rest of the

network, including its behavior, structure and identi-

ties of its members. With this information, they can

take countermeasures against the rest of the network.

Intrusion detection is the process of monitoring a

host or network and analyzing the incoming network

trafﬁc. Trafﬁc can be analyzed for known botnet ac-

tivity or for general suspicious anomalies.

DNS tracking is a type of intrusion detection

that analyzes DNS queries between bots and their

server (Jing et al., 2009). As most bots must ﬁrst

contact a server (or super-peer) to join the network,

researchers look for these messages to learn which

computers are infected. For instance, if a particular

IRC server is known, researchers can analyze net-

work trafﬁc for DNS queries to this server. This re-

veals which computers are infected. This also works

in the opposite direction, if a computer is known to

be infected (e.g. using a honeypot), researchers can

watch for DNS queries to the server, thus learning

where the server is located. Once learned, the ad-

dress of the server can be added to public DNS black-

lists (DNSBL). Queries to blacklisted addresses are

blocked, thus preventing new from joining the botnet.

General trafﬁc analysis is another type of intru-

sion detection that can be applied to both IRC and

P2P based botnets. This technique analyzes messages

being sent to and from a machine and compares the

type, content, protocol or messaging pattern to a list

of known botnets. For instance, certain botnets are

known to either use certain ports, or send messages

of a certain size, or at a certain interval, or to a cer-

tain type of host (Chandrashekar, 2009; Noh et al.,

2009). To detect previously unknown botnets, re-

searchers can look for anomalies or unusual network

activity. For instance, if ‘typical’ network usage is

known, then suspicious anomalies that differ from this

safe baseline can be investigated.

3 BOTCLOUDS

Rather than use a network of infected machines, Bot-

masters can use Cloud services to build botnets. Bot-

masters purchase a large group of machines from a

CSP and install a bot on each machine to form a bot-

net. Cloud-based botnets, or botclouds, have several

advantages over traditional botnets. A traditional bot-

net requires substantial time to build, whereas a bot-

cloud can be online in minutes. In addition, while a

botnet is unreliable due to the constant threat of in-

fected computers being switched off by their owners,

a botcloud is always online and ready. Finally, a bot-

net cannot fully utilize the processor or bandwidth re-

sources due to the constant threat of detection or com-

puter use by the owner; however, a botcloud can be

fully utilized with no fear of interruption.

3.1 Botcloud Attacks

A DDoS attack can be launched by a botcloud and

can, at least temporarily, have the same effect as a

DDoS attack launched by a traditional botnet. This

attack can, in theory, be detected and neutralized by a

CSP. This, however, will only work if they are moni-

toring for this type of activity. For instance, if a CSP

is actively monitoring outgoing trafﬁc for surges of

HTTP requests that match a known pattern of DDoS

activity, the host sending these packets can be iden-

tiﬁed and, as a consequence, disconnected or shut

down. Therefore, a botcloud perpetrating this attack

can be successful in shutting down the target domain,

but perhaps only for a short period of time.

Sending spam from a botcloud can be (and has

been

) accomplished. A common defense against

spam is to blacklist the range of IP addresses from

which the spam is being sent. However, blacklisting

a large range of IP addresses of a CSP might block

access to many legitimate services, such as customers

that are hosting their email servers in the Cloud. This

very problem was encountered when the spam black-

list service Spamhaus.org detected spammers in the

Amazon Cloud and thus blocked a large block of IP

addresses used by Amazon Cloud customers

4. This

attack could also have been detected by a CSP, but

only if it is actively monitoring for it. Therefore, a

botcloud perpetrating this attack may be able to send

massive amounts of spam, but only for a short period

of time.

Click fraud can also be carried out by a botcloud.

This attack is more difﬁcult to detect than the ﬁrst

Washington Post. http://blog.washingtonpost.com/secur

ityﬁx/2008/07/amazon hey spammers get off my.html.

Accessed: November 2010.

BOTCLOUDS - The Future of Cloud-based Botnets?

599

two. Most detection techniques work from the side

of the pay-per-click provider to differentiate between

clicks generated by humans and those generated by

machines (Haddadi, 2010; Zhang and Guan, 2008). If

a fraudulent click is detected, it is removed from the

ofﬁcial tally, but no further action is taken. Unfortu-

nately, pay-per-click providers do not have a strong

incentive to stop click fraud. In fact, they have a

strong economic incentive to allow it to occur as they

have ﬁnancial beneﬁt from each click, regardless of

its validity (Kshetri, 2010). Therefore, a botcloud per-

petrating click fraud could remain in the Cloud for a

long period of time without detection. Without so-

phisticated trafﬁc analysis on the part of the CSP, this

attack might never be detected or permanently neu-

tralized.

3.2 Botcloud Detection

As discussed above, the main methods of botnet de-

tection are honeypots and intrusion detection. Porting

these methods to the Cloud is not a straightforward

process. Deploying honeypots in the Cloud requires

that a CSP monitors all activity on all or a subset of

the machines used by CSP customers. As customers

have paid for these machines, there may be (legal) ob-

jections to this privacy breach (Ruiter and Warnier,

2011). Furthermore, even if all system activity is

monitored, it is non-trivial to differentiate legitimate

from illegitimate activity.

Deploying intrusion detection software on each

machine of the Cloud individually is similarly com-

plex. Most intrusion detection algorithms are trained

using a safe baseline of ‘normal’ incoming network

activity. This baseline is compared to new patterns of

network activity to determine if abnormal, and thus

suspicious, activity is occurring. In the Cloud, this

would require working closely with each individual

customer to develop this safe baseline; an impractical

task.

In addition to monitoring network activity enter-

ing the Cloud, network activity exiting the cloud can

also be monitored for suspicious activity. This is re-

ferred to as outbound intrusion detection or Extrusion

Detection and has been applied to the domain of Inter-

net Service Providers detecting outgoing spam (Clay-

ton, 2004). Proactivelymonitoring for suspicious out-

bound activity, such as DDoS or spam, will alert a

CSP to the presence of malicious users and prompt

further action, such as termination of those users.

Click fraud remains the exception and requires close

collaboration between pay-per-click service providers

and CSPs. Without these minimal security measures,

CSPs leave it to the victims of botcloud attacks to re-

port the attack. This approach, while costing less time

and money for the CSP will possibly lead to a bad

reputation of that CSP.

4 EXPERIMENTATION

This section discusses two experiments to demon-

strate the possibility of creating a botcloud and

launching attacks. For both experiments, a leading

CSP was used to lauch the attacks and a web server,

owned by the authors of this paper, was used as the

target machine.

4.1 DDoS Attack

The ﬁrst experiment builds a botcloud to perform a

DDoS attack on a low-end, personal web server. The

server is a Dell PowerEdge 830 with a 2.6GHz pro-

cessor and 2GB RAM. The server runs Debian Linux

and the Apache Webserver with PHP and MySQL ca-

pability. The server hosts a test site consisting of a

small (< 5K), static HTML page and a dynamically

generated PHP page that queries a MySQL database

when executed.

A separate workstation is used to monitor the re-

sponsiveness of the server. This is done using a stan-

dard web browser and refreshing the test site period-

ically. Before the attack, the page refreshes in less

than one second. In addition, the server is contacted

every second using the ping command. Before the at-

tack, the server consistently responds in less than 100

milliseconds.

A fully automated script creates a botcloud of 20

bots. Each bot is commanded to send 1000 simulta-

neous requests to the web server for a period of 60

seconds. When the script is executed, it creates a bot-

cloud that sends 20,000 simultaneous page requests

per second for a duration of one minute.

The essence of this script is shown in Figure 1.

The script works as follows. First, a machine in-

stance is initiated using the run-instances CSP com-

mand. This command can specify the disk image,

number of machines and machine type (e.g. amount

of memory or disk). An asymmetric key (cloudkey) is

used to automate the login process. After the machine

has started, the unique identiﬁer (IDENT) is used to

lookup the IP address (IPADDRESS) by executing the

describe-instances CSP command. Once the IP ad-

dress is known, a new process is spawned that logs

into the newly created machine using the cloudkey.

This process then executes the httperf script to ﬂood

the target with HTTP requests. Finally, the machine

CLOSER 2011 - International Conference on Cloud Computing and Services Science

600

# begin loop of 20 bots

for i in { 1 . .2 0 }

# i n i t i a t e a bot in s tanc e

IDENT=‘run− in s t an ce s disk image1 −n 1 −g open −k cloudkey1 −t type1 | grep INSTANCE | cut −f 2 ‘

# get ip a ddress of runnin g bot

IPADDRESS= ‘ de s crib e −i n s t an ce s $IDENT | grep INSTANCE | cu t −f 4 ‘

# spawn new process to lauch 1000 re q ues t s per second for 60 seconds

ssh −o StrictHostK eyChecking =no − i ˜ / bin / cloudkey1 . pem root@$IPADDRESS \

’ h t t p e r f −−hog −−www. example . com −− ur i / index . html −−r a t e 1000 −−num−conn 60000 −−time out 1 ’ &

# term i n ate bot

ter m i nate −in st an c e s $IDENT

done

Figure 1: Summary of DDoS botcloud script.

is shutdown using the terminate-instances CSP com-

mand.

This attack overloaded the server. After only 10

seconds, the web browser could no longer refresh the

page. Server response to ping requests slowed down

until approximately only one of 10 requests were an-

swered while the others timed-out (after one second).

This particular script targeted a plain HTML page, but

could be modiﬁed to request a page that requires more

server processing, such as a PHP page that queries a

local database. This would require fewer requests to

overload the server.

4.2 Click Fraud

The second experiment builds a botcloud to perform

click fraud on an online poll hosted by a local server.

The server hardware and software is identical to the

description in the ﬁrst experiment. To simulate stan-

dard click fraud detection techniques, the server ex-

ecutes tests before accepting a vote as legitimate.

First, the web server checks for a unique IP address.

Therefore, no single machine can vote twice from the

same IP address. Secondly, to prevent the same ma-

chine from voting from multiple IP addresses (e.g. by

switching networks), the server saves a cookie on the

machine casting the vote. Before accepting a vote, the

server tests for the presence of this cookie. If present,

the vote is rejected.

The ﬁnal fraud detection technique records a

unique identiﬁer for each vote cast. This unique iden-

tiﬁer is created by adding a timestamp to each vote.

These timestamps are logged for later analysis.

An automated script creates a botcloud of 1000

bots. Each bot is commanded to cast a single, fraud-

ulent vote. When the script is executed, it creates a

botcloud that casts 1000 fraudulent votes, each with a

unique IP address. The essence of this script is shown

in Figure 2.

This script works as follows. First, a bot instance is

initiated using the run-instances CSP command. Af-

ter the machine starts, the unique identiﬁer (IDENT)

is used to lookup the IP address (IPADDRESS) of the

machine. Once the address is known, a new process is

spawned to login to the bot using the cloudkey. This

process then executes the wget command to execute

the fraudulent vote. Finally, the bot is terminated us-

ing the terminate-instances CSP command.

To avoid timestamp anomaly analysis done by the

web server, randomness is added to the script in two

places. First, between loops, the script rests for a ran-

dom length of time (e.g. 2 seconds, 5 minutes, etc.).

This prevents the web server from detecting inexpli-

cable surges of votes. Second, random padding is

added to the timestamp of each vote request. This

is done by choosing a random, three digit number and

appending this to the vote request.

The attack completed successfully. The web

server registered 1000 votes from unique machines

with unique IP addresses. Furthermore, visual analy-

sis of the voting log and its timestamps did not reveal

any obvious anomalies, such as clusters of votes.

5 DISCUSSION

While these experimentsmay not accurately represent

the effects of a large scale attack, they demonstrate

the possibility of constructing such an attack. They

illustrate the straightforward manner with which such

attacks can be launched. Both of these attacks were

constructed and executed in less than one day and for

approximately 100 euros and both were successful in

their respective goal. Furthermore, neither attack was

detected or shutdown by the CSP.

The price of renting a botnet is difﬁcult to esti-

mate, as these activities take place on the obscured

online black markets. However, some researchers at

BOTCLOUDS - The Future of Cloud-based Botnets?

601

# begin loop of 1000 b ots

for i in { 1..1000}

# r e s t for random l engt h of t ime ( to avoid d et e ct io n )

REST=$RANDOM

l e t ”REST %= $MAXREST”

sl e ep $REST

# i n i t i a t e a bot in s tanc e

IDENT=‘run− in s t an ce s disk image1 −n 1 −g open −k cloudkey1 −t type1 | grep INSTANCE | cut −f 2 ‘

# get ip a ddress of runnin g bot

IPADDRESS= ‘ de s crib e −i n s t an ce s $IDENT | grep INSTANCE | cu t −f 4 ‘

# random padding ( to avoi d d et e c t i o n )

PADDING=0

while [ ”$PADDING” −le 100 ]

PADDING=$RANDOM

l e t ”PADDING %= 1000”

done

DATE= ‘ da t e +%s ‘$PADDING

# spawn new process to c a st fr a u d u l e n t vo t e

ssh −o StrictHostK eyChecking =no − i ˜ / bin / cloudkey1 . pem root@$IPADDRESS \

’ wget h t t p : / /www. example . com / frontmodules / vote . c l a s s . php ? id =786359& =’$DATE &

# term i n ate bot

ter m i nate −in st an c e s $IDENT

done

Figure 2: Summary of click fraud botcloud script.

VeriSign estimate this price between $9 an hour and

$67 a day

. While this is cheaper than the equivalent

botcloud, botnets are also less reliable than Cloud ser-

vices, as discussed above. To make matters worse,

criminals willing to launch botnet attacks are most

likely also willing to commit identity theft. When

creating an account for Cloud services, a false name

and stolen credit card information is used

, thus mak-

ing the cost of the service a non-issue. With a dozen

stolen credit cards, a criminal could launch a series of

a dozen botclouds, possibly on different CSPs. When

one Cloud is ﬁnally detected and shut down, the next

is launched, and so on, resulting in an ongoing, mas-

sive attack.

The experiments presented above used a relatively

small number of machines to launch the attacks, how-

ever the very nature of Cloud services allows these

attacks to scale. The same scripts could be used to

launch an attack using thousands or tens of thousands

of machines across multiple CSPs.

As botnet detection techniques continue to im-

prove and the price of Cloud services continues to

drop, botmasters will move their activities to the

Cloud. However, most current botnet detection meth-

VeriSign. http://www.verisign.co.uk/press/page

20100

4.html. Accessed: December 2010

O’Reilly Community. http://broadcast.oreilly.com/

2009/03/blame-the-credit-card-franchis.html. Accessed:

November 2010

ods will not easily port to the Cloud. The CSP is in

the best position to detect botclouds and should be

responsible for maintaining intrusion detection mech-

anisms to detect not only incoming attacks (as they

do now) but also outgoing attacks. The CSP has com-

plete control of the Cloud and thus complete control

of any botclouds they detect. In general, the CSP is

in a better position to detect attacks better than other

actors. For instance, an extrusion detection system

designed to identify click fraud could be deployed

across all nodes under the control of a single CSP. To

achievethe same coverageoutside of the Cloud would

require multiple Internet Service Providers (ISP) to

implement and coordinate the same system.

As with the pay-per-click providers mentioned

earlier, CSPs do not currently have a strong incentive

to monitor all customers from the time they start using

Cloud services. As long as the customer pays, they

can use the service. Moreover, analyzing all outgoing

trafﬁc costs time and resources. As long as CPSs con-

tinue to take action to shut down malicious users only

after the fact (e.g. after the attack has been carried

out), Cloud based attacks will increase.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

602

6 CONCLUSIONS

This paper discusses the ability to launch attacks from

within the Cloud against external targets. Two ex-

periments demonstrate the simplicity and low cost of

launching such attacks. Porting traditional botnet de-

tection techniques to the Cloud is not straightforward,

thus new techniques are required. One possible tech-

nique is extrusion detection. This would require CSPs

to monitor outbound trafﬁc to detect and respond to

suspicious activity. Current policy is to wait until

the victims of attacks contact the responsible CSP at

which point action is taken to disable the attack. Until

CPSs implement a comprehensive botcloud detection

and removal policy, botmasters will continue to move

their malicious activities into the Cloud and botclouds

will continue to grow.

Possible areas of future work include research into

Cloud deployment of extrusion detection systems and

designing incentives for CSPs to proactively monitor

for botclouds.

ACKNOWLEDGEMENTS

This work is a result of support provided by the NLnet

Foundation (http://www.nlnet.nl).

REFERENCES

Anselmi, D., Boscovich, R., et al. (2010). Security intelli-

gence report. Technical Report Volume 9, Microsoft.

Anthes, G. (2010). Security in the cloud. Communications

of the ACM, 53(11):16–18.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A., Katz, R.,

Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., et al. (2010). A view of cloud computing.

Communications of the ACM, 53(4):50–58.

Chandrashekar, J. (2009). The Dark Cloud: Understanding

and Defending Against Botnets and Stealthy Malware.

Intel

 Technology Journal, 13(2).

Chen, Y., Paxson, V., and Katz, R. (2010). What’s New

About Cloud Computing Security. Technical Report

Report No. UCB/EECS-2010-5, University of Cali-

fornia, Berkeley.

Clayton, R. (2004). Stopping spam by extrusion detection.

In First Conference on Email and Anti-Spam.

Dagon, D., Gu, G., Lee, C., and Lee, W. (2007). A taxon-

omy of botnet structures. In acsac, pages 325–339.

IEEE Computer Society.

Haddadi, H. (2010). Fighting online click-fraud using bluff

ads. ACM SIGCOMM Computer Communication Re-

view, 40(2):21–25.

Ianelli, N. and Hackworth, A. (2005). Botnets as a vehicle

for online crime. CERT Coordination Center, pages

1–28.

Jing, L., Yang, X., Kaveh, G., Hongmei, D., and Jingyuan,

Z. (2009). Botnet: Classiﬁcation, attacks, detection,

tracing, and preventive measures. EURASIP journal

on wireless communications and networking.

Kshetri, N. (2010). The economics of click fraud. IEEE

Security and Privacy, pages 45–53.

Maggi, F. and Zanero, S. (2010). Rethinking security in a

cloudy world. Technical report, Dipartimento di Elet-

tronica e Informazione, Politecnico di Milano.

Mirkovic, J. and Reiher, P. (2004). A taxonomy of DDoS

attack and DDoS defense mechanisms. ACM SIG-

COMM Computer Communication Review, 34(2):39–

53.

Noh, S., Oh, J., Lee, J., Noh, B., and Jeong, H. (2009). De-

tecting P2P botnets using a multi-phased ﬂow model.

In Third IEEE International Conference on Digital

Society, pages 247–253.

Ruiter, J. and Warnier, M. (2011). Privacy regulations

for cloud computing, compliance and implementation

in theory and practice. In Gutwirth, S., Poullet, Y.,

de Hert, P., and Leenes, R., editors, Computers, Pri-

vacy and Data Protection: an Element of Choice,

chapter 17, pages 293–314. Springer.

Schoof, R. and Koning, R. (2007). Detecting peer-

to-peer botnets. University of Amsterdam,

http://www.science.uva.nl/ delaat/sne-2006-

2007/p17/report.pdf.

Wilbur, K. and Zhu, Y. (2009). Click fraud. Marketing

Science, 28(2):293–308.

Zeidanloo, H., Shooshtari, M., Amoli, P., Safari, M., and

Zamani, M. (2010). A taxonomy of Botnet detec-

tion techniques. In Computer Science and Information

Technology (ICCSIT), 2010 3rd IEEE International

Conference on, volume 2, pages 158–162. IEEE.

Zhang, L. and Guan, Y. (2008). Detecting click fraud in

pay-per-click streams of online advertising networks.

In The 28th International Conference on Distributed

Computing Systems, pages 77–84. IEEE.

BOTCLOUDS - The Future of Cloud-based Botnets?

603
