IMPLEMENTATION AND OPTIMIZATION

OF RDF QUERY USING HADOOP

YanWen Chen

, Fabrice Huet

and YiXiang Chen

Software Engineering Institute, East China Normal University, Shanghai, China

INRIA, Sophia-Antipolis, Le Chesnay, France

Keywords: Cloud Computing, MapReduce, RDF, Hadoop, Distributed Computing.

Abstract: With the prevalence of semantic web, a great deal of RDF data is created and has reached to tens of

petabytes, which attracts people to pay more attention to processing data with high performance. In recent

years, Hadoop, building on MapReduce framework, provides us a good way to process massive data in

parallel. In this paper, we focus on using Hadoop to query RDF data from large data repositories. First, we

proposed a prototype to process a SPARQL query. Then, we represented several ways to optimize our

solution. Result shows that a better performance has been achieved, almost 70% improvement due to the

optimization.

1 INTRODUCTION

Nowadays Resource Description Framework (RDF)

is used to describe semantic data. At the same time,

SPARQL query language has been developed for

handling these data. Frameworks such as Jena and

Sesame are provided to store and achieve semantic

data, but these frameworks do not scale well for

large RDF graphs. So distributed parallel processing,

as a solution, has been explored to resolve the

scalability problem for semantic web frameworks.

Georgia, Dimitrios, and Theodore focused on

designing SPARQL query mechanism for distributed

RDF repositories (Georgia et al., 2008). Min,

Martin, Baoshi and Robet paid more attention to

scalable Peer-to-Peer RDF repositories (Min et al.,

2004). Others did more work on querying RDF data

with distributed computing technology. Hadoop

which is mentioned in Tom’s book (Tom, 2009), as

a cloud computing tool, can process data in parallel,

achieving a great improvement in performance. Also

Hadoop provides a high fault tolerance because its

distributed file system HDFS adopts a file

replication mechanism. So now people start to focus

on using Hadoop to process semantic data.

Mohammad, Pankil and Latifur proposed an

architecture which includes file generator and query

processor (Mohammad et al., 2009). In the file

generator, RDF data file is split by predicates and

then each file is divided further by objects. In the

query processor, they proposed an algorithm to

answer a SPARQL query. The main idea of the

algorithm is to join several queries in one job. In the

University of Queensland, scale-out RDF molecule

store architecture (Andrew et al., 2008) has been

proposed by Andrew, Jane and Yuan-Fang, in which

instance data and ontology are converted to RDF in

pre-processing phase. RDF graph is broken down

into small sub-graphs which are then added into

HBase (a Hadoop database). A query engine

processes user’s queries and returns results.

Hyunsik, Jihoon, YongHyun, Min and Yon proposed

a scalable query processing system named SPIDER

(Hyunsik et al., 2009) which is also based on

Hadoop. The idea of SPIDER is to store RDF data

over multiple servers. Then sub queries are put to

these cluster nodes. At last these sub query results

are gathered and delivered to user.

In our work, we design a query engine which

involves pre-processor and job trigger. The first

module is responsible for dividing a SPARQL query

into several sub queries according to its ontology.

The second module contributes to creating jobs.

Besides, three optimization tools (job reducing

handler, query accelerator and file splitting handler)

are devised to improve its performance.

The difference between our work and others are

as follows: First, although we also propose a query

engine to handle SPARAL query, our work focuses

on handling ontology which is not considered by

512

Chen Y., Huet F. and Chen Y..

IMPLEMENTATION AND OPTIMIZATION OF RDF QUERY USING HADOOP.

DOI: 10.5220/0003387805120515

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 512-515

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Mohammad in his paper (Mohammad et al., 2009).

Second, we divide a complex query into sub queries

and handle them using Hadoop while Andrew and

his colleges focus on dividing RDF graph into small

sub-graphs (Andrew et al., 2008). The most

important point is we devise several optimizations

tools to improve performance.

The rest sections are organized as follows.

Section 2 describes our architecture. In section 3 we

introduce our implementation. Section 4 details three

optimizations. Section 5 presents some experiments

and then reports their results. At last, section 6

reports the conclusions and future extensions.

2 ARCHITECTURE

We propose an architecture which includes one

master node and several slave nodes (Figure 1).

Figure 1: Proposed Architecture.

In master node, query engine consists of three

modules: pre-processor module, job triggering

module and result combining module. Pre-processor

module is responsible for generating sub query

groups. Job triggering module takes charge of

triggering jobs (query and join). Result combining

module is used to combine results of each group.

After getting a job, master node assigns tasks to

slave nodes in which tasks are executed in parallel.

Figure 2 shows us a query workflow with four

stages: pre-processor stage, query stage, join stage,

and result combining stage. Input is a SPARQL

query. Output is a set of triples which meet the

requirement of the SPARQL query. The pre-

processor parses a SPARQL query into sub queries.

After getting the results of these sub queries, we join

them in the join stage. At last, the joining results

from each group are combined into one file which is

the final result of the SPARQL query.

Figure 2: Workflow of a SPARQL query.

3 IMPLEMENTATION

A RDF file includes three columns: Subject,

Predicate and Object. Before executing our query

workflow, we store sorted RDF files in file system.

Three sorted files which are sorted separately by

Subject, Predicate and Object are generated from

one original unsorted file. In our implementation, we

firstly parse a SPARQL query in pre-process stage

according to its Univ-Bench ontology. In the

ontology there is a ‘subClassOf’ relationship among

some classes. We create sub query jobs according to

the relationship. For example, if ‘Professor’ has two

subclasses ‘FullProfessor’ and ‘AssociatedProfessor’,

then for a query like <?x type Professor>, three sub

queries are generated--<?x type Professor>, <?x type

FullProfessor> and <?x type AssociatedProfessor>.

From each sub query, some parameters such as type,

input file name, primary keyword, and secondary

keyword can be gotten. At last, we use Hadoop to

execute query job and then use Pig (a sub product of

Hadoop) to execute join job.

4 OPTIMIZATION

4.1 File Splitting Handle

Before executing a map function, Hadoop splits

input file into many small files and then creates

Map-Reduce task for each split file. In our work we

use File Splitting Handle to filter these split files.

Since data has been sorted in each split file, the File

Splitting Handle can select out files which may

contain a certain keyword we need. So the

performance will be improved since fewer tasks are

IMPLEMENTATION AND OPTIMIZATION OF RDF QUERY USING HADOOP

513

created. In our implementation, the first line record

of each split file is compared with the certain word

to determinate whether the file should be selected or

not. If the first line record is larger than the certain

keyword, then we discard the file, otherwise we

choose it. The same strategy is used when reading a

selected split file to avoiding a whole file searching.

4.2 Query Accelerator

Without using our accelerator, in each group, sub

query jobs are executed sequentially. By using our

accelerator, these jobs can be executed in parallel

because we take advantage of multiple threads. Also

in our accelerator, a join job is triggered as soon as

at least two jobs are ready to be joined.

4.3 Job Reducing Handle

The job reducing handle is designed to reduce the

number of jobs. In our implementation, when

dividing SPARQL query into different groups, some

identical sub queries maybe generated. So we use

job reducing handle to detect these identical queries

so that Hadoop can create only one job for them.

Besides, in each group, if there is at least one query

result is empty or an intermediate join result is

empty, job reducing handle can find it and then stop

creating jobs in this group, since the final result of

the group must be empty.

5 EXPERIMENT AND RESULT

In our experiments, we investigate the performance

of queries and the impact of optimizations from

following aspects:

 Impact of job reducing handler optimization

 Impact of query accelerator optimization

 Impact of file splitting handler optimization

For these experiments we use a cluster with 14

nodes, each equipped with two dual core processors

with 4GB of main memory and 72GB hard disk. The

software we developed is written in Java 1.6 and

based on Hadoop version 0.20.2. We use the LUBM

benchmark (Yuanbo et al., 2005) designed by

Yuanbo, Zhengxiang and Jeff to test query

performance. In the benchmark, the number of RDF

triples increases with increasing number of

universities.

We use a simple query to test its query

answering time varying sizes of datasets. Result

shows it almost has a sublinear speed up.

5.1 Impact of Job Reducing Handler

We use the fourteen queries provided by the

benchmark which includes 1000 university to

investigate the relation between query answering

time and the number of jobs. Result shows that

query answering time has a linear speedup with the

increasing number of jobs. Table 1 reports the

impact of job reducing handler. Apparently the

performance improved after using the handler. In

order to know how much it is improved, we

calculate the percentage of job decreasing and its

performance improvement as shown in Table 2.

Table 1: Job numbers before and after job handling.

From the Table, we can see that, for query 2, 10,

even they have the same percentage of total jobs

decreasing, they still get a different improvement in

performance. The reason is that their percentages of

join jobs and query jobs are different. And according

to our test, the more decreasing of join jobs, the

better performance improvement we can get. So the

query 10 has a better performance. Besides, from the

table, we know that even there is no job decreasing

like query 1, 6, 11 and 14, they still can get some

performance improvement. It is because the impact

of query accelerator. Some detail discussion will be

given in the part 5.2.

Table 2: Percentage of performance improvement.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

514

5.2 Impact of Query Accelerator

In our query accelerator, multiple threads are used to

make sub query jobs executed in parallel. After

testing its impact, we found that performance has

been improved by almost 30% in average. In

addition, the numbers of jobs have directly influence

on the performance improvement. So the four query

mentioned in 5.1 have different improvement. Query

11 and query 6 which both have 4 sub query jobs

should have a same improvement of performance

and higher than query 1, 14. However the impact of

join jobs cannot be ignored, which will reduce the

performance. So the query 11 has a worse

performance improvement than query 6 because the

number of join jobs in query 11 is more than in

query 6.

5.3 Impact of File Splitting Handler

We investigate the performance without and with

file splitting handler using a dataset which includes

500 universities. In the experiments, we choose a

certain data which are located at different positions

of the dataset. Result shows that the closer to the end

position the data is located, the lower performance

we get, because more split files need to be read. The

average improvement rate reaches to 74.53%.

6 CONCLUSIONS

AND FUTURE EXTENSIONS

In this paper we address the problem of querying

RDF data from large repositories and then

investigate its performance. In order to improve the

performance, several optimizations such as file

splitting handler, query accelerator and job reducing

handler have been explored.

As a conclusion, the work has returned

encouraging results, almost 70% improvement

according to the results of our experiments. Also due

to these optimizations, the query time has a sublinear

speedup with the increasing number of datasets.

However, the performance of queries is not yet

competitive because too many jobs are created,

especially for the SPARQL query which has a wide

hierarchy information or inference.

So in our future work, we will put more focus on

the pre-processor module to reduce the number of

jobs as much as possible. One interesting way could

be to analyse each sub query before starting a job.

The sub queries which read the same input file

should to be combined as one job. However in this

way, we should take care of the output and find a

way to divide the output into different files.

REFERENCES

Andrew, N. and Jane, H. and Yuan-Fang, Li. (2008). A

Scale-Out RDF Molecule Store for Distributed

Processing of Biomedical Data. In Semantic Web for

Health Care and Life Sciences Workshop, Beijing,

China.

Georgia, D. S. and Dimitrios, A. K. and Theodore, S.P.

(2008). Semantics-Aware Querying of Web-

Distributed RDF(S) Repositories. In SIEDL2008,

Proceedings of 1st Workshop on Semantic

Interoperability in the European Digital Library, pp.

39-50, 2008.

Hyunsik, C. and Jihoon, S. and YongHyun, C. and Min, K.

S. and Yon, D C. (2009). SPIDER: A System for

Scalable, Parallel/Distributed Evaluation of large-

scale RDF Data. In CIKM’09, November 2-6, 2009,

Hong Kong, China, ACM 978-1-60558-512-3/09/11.

Min, C. and Martin, F. and Baoshi, Y. and Robet, M.

(2004). A Subscribable Peer-to-Peer RDF Repository

for Distributed Metadata Management. Journal of

Web Semantics: Science, Services and Agents on the

World Wide Web 2(2004) 109-130.

Mohammad, F. H. and Pankil, D. and Latifur, K. (2009).

Storage and Retrieval of Large RDF Graph Using

Hadoop and MapReduce. In CloudCom 2009, LNCS

5931, pp. 680-686. 2009.

Tom, W. (2009). Hadoop: The Definitive Guide. O’Reilly

Media, Yahoo!Press.

Yuanbo, G. and Zhengxiang, P. and Jeff, H. (2005).

LUBM: A Benchmark for OWL Knowledge Base

Systems. Journal of Web Semantics, 3(2), pp.158-182.

IMPLEMENTATION AND OPTIMIZATION OF RDF QUERY USING HADOOP

515
