ELASTICITY THANKS TO KERRIGHED SSI AND XTREEMFS

Elastic Computing and Storage Infrastructure using Kerrighed SSI and XtreemFS

Alexandre Lissy

, St´ephane Lauri`ere

Laboratoire d’Informatique, Universit´e de Tours, 64 avenue Jean Portalis, Tours, France

Mandriva, 8 rue de la Michodi`ere, Paris, France

Julien Hadba

Laboratoire d’Informatique, Universit´e de Tours, 64 avenue Jean Portalis, Tours, France

Keywords:

Kerrighed, Cloud, Infrastructure, Elastic, XtreemFS, Storage.

Abstract:

One of the major feature of Cloud Computing is its elasticity, thus allowing one to have a moving infrastructure

at a lower cost. Achieving this elasticity is the job of the cloud provider, whether it is IaaS, PaaS or SaaS. On

the other hand, Single System Image has a hotplug capability. It allows to “transparently” dispatch, from a

user perspective, the workload on the whole cluster. In this paper, we study whether and how we could build

a Cloud infrastructure, leveraging tools from the SSI ﬁeld. Our goal is to provide, thanks to Kerrighed for

the computing power aggregation and uniﬁed system view, some IaaS and to exploit XtreemFS capabilities to

provide performant and resilient storage for the associated Cloud infrastructure.

1 INTRODUCTION

When talking about Cloud, John Mc-

Carthy’s (Garﬁnkel, 1999) quotation at the MIT’s

100

year celebration is often used: “computation

may someday be organized as a public utility”. This

idea, which dates back to 1961, came back after the

Dot-Com bubble, pushed by Amazon: like many,

the company had datacenters full of servers, running

mostly at 10% of their full capacity and occasion-

ally running at their full capacity in the periods of

potential peaks as the ones occurring at Christmas

for example. Amazon decided to stop wasting this

power, and created Amazon Web Services (AWS), in

July 2002. This date might be refered to as the Year

Zero of Cloud Computing. Since then, all big IT

companies have been involved in Cloud.

From a user perspective, the main advantage of

AWS is the ease of use that it provides. It became pos-

sible to easily access huge computing power at low

cost. With Amazon Elastic Cloud Computing (Ama-

zon EC2), the idea went further and Xen virtual ma-

chines now are available via the service. Elastic Com-

puting is now becoming a major feature that is tightly

linked to Cloud, especially for its Infrastructure part.

Another interesting ﬁeld is the Single System Im-

age: SSIs are distributed systems running on top of a

network of computers, that appear as one big unique

computer to the user. Several projects aimed at pro-

viding such a system. Among them, we can cite

MOSIX (Barak and Shiloh, 1977), openMosix (Bar,

2008), OpenSSI (Walker, 2001) and Kerrighed (Ker-

labs, 2006). The ﬁrst one is not a free software, but is

still actively developed. The openMosix project died

in 2008, but the LinuxPMI (Longtin, 2008) project

is trying to continue the work initiated. OpenSSI is

not dead but still based on a rather old kernel (2.6.14

for the most recent kernel used, 2.6.12 in the latest

released version). Kerrighed is the only project still

active and working with a kernel 2.6.30.

XtreemFS is a part of the European Founded

project “XtreemOS”. Its goal is to provide a dis-

tributed and replicated ﬁlesystem for the Internet. It

has now reached some useable state as demonstrated

in (Lissy, 2009a).

Our goal is to leverage these tools and gather them

together.

The rest of this paper is structured as follows: in

section 2 we present some related works on SSI and

Cloud, we also introduce the involved tools as well as

our goal regarding what has already been done by oth-

ers. Then, in section 3 we present our goal and mo-

431

Lissy A., Laurière S. and Hadba J..

ELASTICITY THANKS TO KERRIGHED SSI AND XTREEMFS - Elastic Computing and Storage Infrastructure using Kerrighed SSI and XtreemFS.

DOI: 10.5220/0003391504310438

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 431-438

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

tivations. In section 4 we present our solution from

a technical and implementation point of view, and in

section 5 we propose a critical analysis of the pro-

posed solution as well as a test plan and criterions to

validate or not the viability of this implementation.

Then we conclude in section 6 whether our solution

is viable or not.

2 RELATED WORKS

In this section, we present a couple of papers related

to our topic: Single System Image, Cloud, and/or

XtreemFS. It can be noticed that there are only few

papers dealing with the use of SSI to provide Cloud.

2.1 A View of Cloud Computing

Deﬁnition. Based on view of cloud computing

(Armbrust et al., 2010), we deﬁne a cloud as a sys-

tem which respect three properties

• impression of inﬁnite capacity: cloud cannot be

limited by the system capacity. User must have

impression that the capacity of the cloud is un-

bound by hardware (storage, computing, ...).

• short term usage: usage of cloud computing is

free constraint. User must use cloud just for his

needed.

• no upfront cost: utilization of cloud avoid the ini-

tial cost of his own equipment. This must not be

visible for the user.

Important Cloud Features. We note important

features which appear as essential in cloud comput-

ing.

• Elasticity. To respect the three properties above,

a cloud must have the capacity to scale quickly.

Plus in practice, we note peaks of utilization. For

instance, reactivity is an important user require-

ment. We can explain the failure of services by

a too long response time. Generally capacity

of cloud computing is design on maximum need

reached on peaks. The rest of the time (most of

the time), the cloud is under used.

• Scalability. If demand evolution of resources is

unknown, need of resource can be assumed by an-

other one. That is a typical use case of cloud and

that’s why capacity of cloud have to be scalable

(unbound).

• Development Framework. Utilization of cloud

implies a new model for application design. The

model is dependent on the cloud. A general

rule can be picked up: the more developers have

freedom, the more they have to consider speciﬁc

mechanisms of the cloud. Inversely, more mech-

anisms of cloud is automatic, more the model of

development is restrictive. To ensure the porta-

bility of application under more than one cloud,

framework have to tend toward standard. A

smooth solution is to reuse existing standard of

programming.

• Virtualization Solution. Quality of service and

bug detection is difﬁcult to manage by direct uti-

lization of cloud. Bugs are hardly repeatable be-

cause it is difﬁcult to recreate environment. Clas-

sic solution is to partition the user space. That’s

why we used virtualization.

2.2 Kerrighed

Kerrighed (Kerlabs, 2006) is a project that was initi-

ated in 1999, at INRIA. It was developed until 2006

at IRISA, in Rennes, with people from INRIA, EDF

and the University Rennes 1. In 2006, it was judged

that it was time to move from a research prototype to

an industrial solution, and thus Kerlabs was founded

by members of the research team, to continue the de-

velopment. Kerrighed allows a set of interconnected

(LAN) computers to function as a so-called “Virtual-

SMP”, aiming at making a Single System Image: sin-

gle process space, single IO space, single root, etc.

Single File system root is provided through a com-

mon NFS server for all nodes. One major feature of

Kerrighed is the ability to handle processes on several

nodes. There are two ways to deal with it: migration

or distant fork. The goal of those two is to balance the

load on the whole cluster. Migration might still suffer

from some hiccups, even if these are improving incre-

mentally each time. The idea is to freeze the process,

transfer it to another node, and continue the execu-

tion. Distant fork is much simpler: when

fork()

ing,

Kerrighed intercepts the system call, and manages to

execute it on another node.

These features are controlled, since the Kerrighed 2.4

version, by a userspace-conﬁgurable kernel scheduler

framework, called SchedConﬁg. The “legacy” sched-

uler provided with Kerrighed behaves like MOSIX’

one. As part of (Lissy, 2009b), another scheduler was

implemented, based on the work by (P´erotin, 2008),

called “RBT”. This scheduler is able to control migra-

tion and/or distant fork, i.e. to decide on which node

the execution of a process should be done, either by

migrating the process, or when

fork()

occurs.

As part of the 3.0 release, major work was done

to support Hotplug node. Currently, the addition

of nodes while running the cluster is fully function-

CLOSER 2011 - International Conference on Cloud Computing and Services Science

432

nal. The removal of nodes, however, remains com-

plicated. The developers have patches that works rel-

atively well to allow the administrator to get a node

out of the cluster. However these patches are not quite

ready yet. A crashing node is still a big issue, but it

should be addressed eventually (patches allowing safe

removal of a node from the cluster are already avail-

able and working). This hotplug feature is very inter-

esting, since it allows very easy elasticity: basically,

you take a node, you rack it, plug the network, power

up and your cluster has more power.

2.3 XtreemFS

XtreemFS (XtreemFS Team, 2006) is a distributed

and replicated Internet ﬁlesystem, that was devel-

oped as part of the XtreemOS (XtreemOS Consor-

tium, 2006) project. The objective of the project is

to provide a solution to have a distributed, parallel

and replicated ﬁlesystem for sharing data inside the

XtreemOS project, butnot just limited to it. It consists

of several components: a directory service (DIR), a

metadata and replication service (MRC) and a stor-

age service (OSD). The directory service allows all

the other services to register themselves and be able

to know which is available. MRC is responsible for

the metadata of the stored data and replication. The

OSD service is the one that runs on each node and ef-

fectively stores data. The administrator will be able to

create several volumes on the MRC, which will deter-

mine the features of the volume: access control policy

(POSIX by default), a stripping policy (only RAID0

for the moment) a stripe size (128kB by default) and

a stripe width (1 by default). This stripping feature al-

lows chunks of data to be stored onto different OSD.

When the client will mount the ﬁlesystem, it will en-

able him to perform parallel reads from all the OSD

that have the data, thus improving throughoutput.

Replication works but might still need some work in

order to be better and easier to deal with. The ﬁlesys-

tem providesan extension mechanism, so speciﬁc fea-

tures might be added easily. This stripping enables

elasticity too, even though data will not, currently, be

replicated automatically onto the new nodes, at least

the volume size will increase when adding new OSD

to the system. Thanks to the DIR service, this is kind

of automagic.

2.4 Apache Hadoop

Apache Hadoop, which some consider to be a PaaS

component of Cloud, is a framework designed to treat

very large datasets. It is a free implementation of

Google’s MapReduce, implemented thanks to their

publications. It is distributed and fault-tolerant, but

requires using its speciﬁc API to be used. It is not

POSIX-compliant, but there are projects aiming at

providing a FUSE interface to Hadoop (Foundation,

2009).

2.5 Ceph Project

This project, started as a PhD thesis, aims at pro-

viding a distributed and scalable free ﬁle system for

Linux. Scaling is achieved simply, in the same way as

XtreemFS is, by adding new Object Storage Device

(OSD). The ﬁlesystem replicates data accross several

OSDs inside the cluster, allowing both resilient be-

havior when losing some nodes, and parallel reading

while retrieving data. One feature that is very interest-

ing is the ability to rebalance the load when extend-

ing the cluster with new OSDs. Both an advantage

and an issue is the fact that Ceph is now mainstream

Linux kernel. It means that it works well enough to

be included in the ofﬁcial vanilla sources since 2.6.34,

which is very good. It also means that if we want to

have it in Kerrighed, we will have some work to do

to backport it to 2.6.30 used by the SSI. As the kernel

evolves very rapidly, this might be an issue. More-

over, dealing with FUSE might be much more valu-

able: there are other interesting ﬁlesystems based on

this tool that might beneﬁt from our work.

2.6 XtreemOS and Cloud Computing

In (Morin et al., 2009), the authors analyse the “im-

pact” of the recent Cloud Computing idea and how it

interacts with XtreemOS. Two approaches are used:

leveraging clouds for XtreemOS usage, and using

XtreemOS technologies to manage cloud computing

infrastructures.

In the ﬁrst case, the idea is to install XtreemOS

in several Clouds to be able to federate themselves.

XtreemFS is an interesting piece of software for this

case, due to its POSIX interface for easy integration

with legacy application, contrary to “classical” Cloud

storage. Also, the use of an SSI (LinuxSSI precisely

in XtreemOS) allows to provide much larger virtual

machines than Amazon EC2 does. The processor

transparency provided by SSI is an advantage here.

In the second case, XtreemOS is used as an infras-

tructure for cloud providers. The major concept of

Virtual Organization, at the heart of XtreemOS, can

be leveraged here to deﬁne and apply policies and ac-

cess control for the resources used. XtreemOS will be

running Virtual Machines, and these will be managed

as an application. Any operating system might run

inside the VM. Migration and hotplug allow for ser-

ELASTICITY THANKS TO KERRIGHED SSI AND XTREEMFS - Elastic Computing and Storage Infrastructure using

Kerrighed SSI and XtreemFS

433

ver consolidation depending on the workload.

2.7 SSI on the Cloud

In (Modzelewski et al., 2009), the authors describe

how they intend to ease the use of cloud and mas-

sively parallel computers (1000+ cores, called “many-

cores”), by designing a cloud-aware operating sys-

tem: fos. The main idea is to have a Single System

Image running on top of an Infrastructure as a Ser-

vice cloud. To design their OS, they introduce four

challenges that fos must address: scalability, elastic-

ity of demand, faults and programming large systems.

Scalability. Algorithms inside the OS, such as lock-

ing for example, must scale beyond one hundred or

more cores. They reuse their work analyzing the lim-

itations towards this goal in current OS design.

Elasticity of Demand. It is deﬁned as this: work-

load and resources to treat demand will change dy-

namically.

Faults. Obviously, large systems are more prone to

failures, and there are several references about these

issues, such as (Shang et al., 2007; Huysmans et al.,

2006; Hacker et al., 2009). So the Operating System

must be designed with fault tolerance in mind.

Programming Large Systems. Currently, tools to

efﬁciently use large systems easily are not available:

no uniform programming model for communication

(threads for local resources, sockets for remote re-

sources), cloud complexity embedded inside the ap-

plication whereas for multiprocessor systems it is em-

bedded inside the OS.

The authors propose a solution, “a factored OS”.

The main design principles are:

• Space multiplexing instead of time multiplexing.

• Factorization into speciﬁc services.

• Faults detection and handling.

Even though it does not correspond exactly to our

research, those challenges are interesting in the way

that they demonstrate the complexity of large sys-

tems.

2.8 SuperComputers and Cloud

Computing

In “Providing a Cloud Network infrastructure on a

Supercomputer” (Appavoo et al., 2010), the authors

present a similar idea: they state that, due to cost and

scale condiserations, cloud hardware will evolve to

something similar to supercomputer hardware. More

precisely, they are interested in showing that it is

possible to use supercomputers as cloud infrastruc-

ture. Scientiﬁc computing, and thus supercomput-

ers aim at delivering the highest performances achiev-

able. Nowadays, however, they tend to use standard

general-purpose software environments rather than

highly-specialized and dedicaded ones, to allow easy

portability. Some might then consider using Cloud

for High Performance Computing (HPC). For them,

a central feature of Cloud is “elastic resource provi-

sioning of standardized resources”, to easily scale ac-

cording to users needs. Elasticity can also be used in

high-performancesystems, and the authors introduces

two hypotheses that they intend to verify by adding

dynamic network virtualization to a supercomputing

system:

1. Elasticity can be achieved along with the pre-

dictability associated with high performancecom-

puting;

2. General-purpose elastic computing can be sup-

ported with direct access to specialized networks.

This elasticity is not part of the supercomputer ar-

chitecture. The authors’ idea is thus to adapt HPC,

by emulating Ethernet over their BlueGene/P’s spe-

ciﬁc networking, RDMA, to allow the use of classical

Cloud tools. They demonstrate its performances, with

a patched version of memcached and benchmark.

They conclude that by providing commodity soft-

ware layer, they can run a cloud computing applica-

tion on top of their BlueGene/P and beneﬁt from its

computational power. One of their future works will

be to backﬁll the supercomputer with cloud in idle pe-

riods.

2.9 Using XtreemOS for NBX Grid

In the technical report (Mason et al., 2010), the

authors study the use of XtreemOS components in-

side NBX (NuGO Black Box, a project that aims at

providing a “lab-scale” bioinformatics servers. As

part of an upgrade of the solution, the authors study

the possibility to leverage XtreemOS for their needs:

mainly, Kerrighed and XtreemFS. They justify the

Kerrighed choice by the status of all others FLOSS

SSI: openMosix is dead since march 2008, OpenSSI

is rather old (latest release was in 2010, 18th Feb.,

and with kernel 2.6.12). Only Kerrighed is still de-

veloped actively. Even though they had a couple

of hiccups using this piece of software, they ﬁnally

validated its use. Then, they studied the ﬁlesystem

Free and Libre Open Source Software.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

434

Figure 1: The Cloud Computing Stack (Clubic.com, 2010).

part: replacing the use of “sshfs”

to share data, with

XtreemFS, which is considerably more robust than

“sshfs”. However, they managed to achieve good re-

sults in local network (stating that XtreemFS uses too

many ports for the ﬁrewall conﬁguration which made

them unable to test at WAN level). Finally, as a con-

clusion, they validate the use of both XtreemFS and

Kerrighed inside their NBX platform.

3 AN ELASTIC AND

TRANSPARENT

INFRASTRUCTURE

In the previous sections, we have shown how elastic-

ity is one of the biggest advantagesprovided by Cloud

Computing. Before introducing the idea, it is impor-

tant to remind our readers of the layers (ﬁgure 1) in-

volved in Cloud, in a bottom-up approach:

1. Infrastructure as a Service (IaaS): Amazon EC2

2. Platform as a Service (PaaS): Google App Engine

3. Software as a Service (SaaS): ERP5 SaaS

As we have also seen previously, both Kerrighed

and XtreemFS are elastic-aware, meaning that they

can be extended at will and without any downtime.

So the idea is pretty simple in fact: following the same

kind of logic as in (Morin et al., 2009) and in (Ap-

pavoo et al., 2010), we would like to beneﬁt from

these capabilities to easily provide the basis for an

IaaS, effectively leveraging Kerrighed and XtreemFS.

Even though both might not be production ready for

this kind of usage, it is worth checking the feasibility

of this kind of construction. One usage of this solution

can be imagined as part of the CompatibleOne (Team,

2010) project to provide IaaS, either as a ﬁnal basis

for the solution, or more likely as a way to have an

elastic infrastructure as a prototype.

A FUSE software to mount SSH folders.

The process that sustains the production of a

Linux distribution relies on infrastructure services

that are both CPU and storage intensive: a build ser-

vice, a code analysis service, and a system integra-

tion testing service. For example, in Mandriva’s case,

it consists of approximately 10,000 source packages

and 20,000 binary ones, which evolve at a rapid pace:

during activity peaks, the amount of new packages

produced every day can amount to more than 1,000,

as a consequence of the availability of new compo-

nent versions, bug ﬁxes or security updates, and of

the complex dependency graph among packages. The

volumes at stake and the need to meet highly demand-

ing industry requirements in terms of speed, test cov-

erage and traceability call for an innovative scalable

infrastructure. The elasticity and the robustness of-

fered by Kerrighed and XtreemFS are appealing for

the creation of such a Linux engineering platform.

The use of both as an infrastructure for the Mandriva

distribution build and analysis system will be experi-

mented and measured in 2011-2012. The key success

criteria will hinge on the following aspects: efﬁcient

elasticity, performance, robustness, and simplicity of

the set up, administration and replication processes.

4 PROPOSED SOLUTION

Now that a description of the context as well as the

main idea have been set, we will focus on deliver-

ing a description of the technical aspects of the so-

lution. But ﬁrst, we will summarize the qualities of

Kerrighed and XtreemFS for this topic.

4.1 Components of the Solution

Kerrighed. Kerrighed is a Single System Image for

a cluster of computers. A kerrighed cluster can be

viewed as a big computer which is an agregation of

all nodes. Following the same idea than for the “fOS”

project, the idea is to beneﬁt from the kernel-side sin-

gle view inherent to the SSI aspect of the project.

XtreemFS. Other distributed ﬁlesystems exist, such

as Ceph, but XtreemFS is more interesting mainly be-

cause it is less intrusive than Ceph. The former is a

userspace ﬁlesystem, implemented with FUSE, while

the latter is in-kernel, which would require patching

Kerrighed to add it. XtreemFS also provides elastic-

ity even though it does not support rebalancing the

load when adding new storage devices.

Association of Kerrighed and XtreemFS. So now

the idea is to associate both Kerrighed and XtreemFS

ELASTICITY THANKS TO KERRIGHED SSI AND XTREEMFS - Elastic Computing and Storage Infrastructure using

Kerrighed SSI and XtreemFS

435

in one node, so that we can plug new computers and

extend both storage and computing power.

4.2 Implemented Solution

To set up the solution, we reused our Kerrighed de-

velopment cluster. The basic setup involves a NFS

server, serving the root ﬁlesystem (later referred as

“NFSROOT”), and client nodes booting the kerrighed

kernel over PXE. Inside the NFSROOT, we simply

install XtreemFS server package, to provide OSDs

for each node. We installed XtreemFS directory and

metadata services on the NFS server. In the end, the

setup can be summarized as in ﬁgure 2.

Figure 2: Implemented solution.

Now, in order to mount the ﬁlesystem, we can en-

visage two ways:

• Mount it on the NFS server, then share via NFS.

• Mount it on each Kerrighed node.

It is important to notice that when the client, that is

the kerrighedbooted nodes, will mount the ﬁlesystem,

they will request to directory and metadata server.

DIR will be in charge of providing the information

about the presence of MRC and OSD. When manip-

ulating data, the XtreemFS client will have direct ac-

cess to the OSD. So the ﬁrst solution will be bottle-

necked by the NFS server.

For our test bed, we deployed two OSDs per Ker-

righed node. This requires a couple of operations, as

the default installation only allows for one OSD to be

launched, but nothing serious (duplicating the conﬁg-

uration ﬁle for each node and each instance, setting

the appropriate UUID). These had to be done in order

to be able to use the two storage devices we added to

each node. For the test, they are simply Kingston 4GB

USB key, providing a total of 42GB (some reports as

4.01GB, others at 3.8GB). We could have setup some

Software RAID0 to allow the two keys to be exposed

“as one”. But in production this would have meant

risking loosing the data of the two disks if loosing

one. Two (or more) OSDs provide a better solution.

One interesting feature of Kerrighed is, as we pre-

viously stated, distant fork. Thus, we want to exploit

distant fork “over” XtreemFS, that is having a dis-

tributed storage volume which is used by applications

running inside the cluster. At ﬁrst, it was impossible

due to some implementation issues. After notiﬁca-

tion to the Kerrighed’s developer, they came with an

idea that we implemented and, as of now, validated.

Some work is still needed to polish the code, but the

main goal is achieved. Further investigations exposed

another issue, related to XtreemFS, on which we are

working.

While uncompressing the sources, we also ran

into some bug lying in XtreemFS and related to man-

agement of symbolic links, which we helped to get

ﬁxed.

4.3 Towards PaaS Solution

The goal of the proposed solution is to include ker-

righed and XtreemFS as foundation for IaaS as part

of a Cloud stack (ﬁgure 3). The IaaS layer can be en-

sured by the management of virtual machines. This

management is controled by an intelligent migration

policy (section 2.2) in kerrighed and by a control of

data in XtreemFS (section 2.3).

5 ANALYSIS OF THE PROPOSED

SOLUTION

In this part, we will ﬁrst characterize the properties

that we want to achieve, then we will show how the

proposed solution allows to comply with them.

5.1 Properties to Achieve

Elasticity. We deﬁne elasticity as the capacity of the

system which we want to build to serve for Infrastruc-

ture as a Service to be resized, while running, without

any downtime. This capacity is needed, for several

reasons. First of all, it will allow for easy scaling:

need more computational power? Add more servers.

Secondly, if we can shrink the system, we can take

nodes down when the load is too low. It also allows

to remove parts of the system for maintenance for ex-

ample.

Robustness. We deﬁne robustess as the capacity for

the system to remain accessible and (even not) fully

functionnal when critical events occur. Since it will

havemany components, it is very likely that some will

fail. We don’t want the whole system to be down in

that case. What would be better would be that nothing

got lost: data or process. Even if it bad to be at the

cost of computational power.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

436

Transparency. We deﬁne transparency as the ca-

pacity of the system to manage both these proper-

ties in a transparent way for the applications using it.

That is, unlike other cloud applications, as stated in

(Modzelewski et al., 2009), we do not want to man-

age elasticity and robustness in applications.

5.2 Validation of Properties

5.2.1 Elasticity

Kerrighed. As deﬁned previously, elasticity in Ker-

righed is the ability to add and/or remove nodes while

keeping a running computer accross the nodes. This

is precisely the behavior of Kerrighed. Since the lat-

est release, 3.0.0, Kerrighed supports hotplug: we can

add new nodes to an already living cluster. Since

November, 22nd, Kerrighed has support for hot re-

moval of nodes. It works, even though there are still

issues to be solved.

XtreemFS. Elasticity in XtreemFS is natural and

linked with the directory service. Each OSD regis-

ters to DIR and then can be used for every volume

that is present in the system. Removing an OSD, for

example by shutting its node down, will reduce the

available size of the volume, and if the ﬁle chunks

it was hosting have not been replicated, correspond-

ing ﬁles will remain unavailable until the OSD comes

back online.

5.2.2 Robustness

Table 1 summarizes the issues that might arise for

both Kerrighed and XtreemFS.

Kerrighed. The question of robustness for Ker-

righed can be seen as a two-way question: is it able to

handle the loss of one or more several nodes? Can we

remove nodes by hand and keep the cluster usable?

As of today, only the second part has been addressed

in an interesting way. Even if node removal is very

recent, publicly available in git tree since November

22nd, it works relativelywell. However, we havebeen

able to trigger bugs in some cases. When removing a

node, the system tries to migrate all the processes that

are running on this node onto other nodes. If a process

is not migrateable, then it will be killed. Otherwise,

it will remain running. As far as the ﬁrst question is

concerned, the current answer is simply “no”. It is

not a limitation, it is a bug not yet addressed. Loosing

one node will still crash the whole cluster. Work is

being done on failure prediction to avoid this kind of

damages.

XtreemFS. Regarding XtreemFS, we can ask our-

selves the same questions than for Kerrighed: how

does it behave when loosing one node? Can we re-

move one node safely? While in Kerrighed there is

a tool managing node hotplugging, krgadm, there is

no such thing for XtreemFS, thus both questions are

the same. XtreemFS can afford loosing one or sev-

eral OSDs, as long as there are other providing repli-

cas of the chunks involved. If not, it will issue an

error to the requesting application. Once the miss-

ing OSDs are back, the data is available again. Also,

there is currently a single point of failure for the direc-

tory and metadata services. However, this should be

addressed in the 1.3 release of XtreemFS (currently

1.2.3). One must also be aware that replication is not

yet automatic: the ﬁle must be set as “read-only” for

replication to be able to start.

Table 1: List of potential problems.

safety stop crash

XtreemFS full disk space

& recovery

full disk space

& recovery

Kerrighed loss of avail-

able power

system crash

5.2.3 Transparency

Kerrighed. As a SSI, it is totally transparent to the

applications that are run inside the cluster. Techni-

cally, Kerrighed is implemented as a Linux Container,

a lightweight virtualization technique. Once the clus-

ter environment is started, the user can connect to it

(through a sshd started inside the container) and see a

SMP machine that aggregates all the power and mem-

ory of all the nodes participating. Transparency is

complete. If one wants to beneﬁt from process migra-

tion or distant fork, however, running processes must

be “conﬁgured” (setting capability) to allow those ac-

tions. This can be easily circumvented.

XtreemFS. As a FUSE and POSIX-compatible

ﬁlesystem, XtreemFS is rather transparent. One just

need to mount it and then it is possible to use it as any

storage device that exists.

5.3 Efﬁciency

Once we have checked that the requirements are glob-

ally met, it seems important to us to check that the

performances are not bad. Kerrighed and XtreemFS

are not dedicated to Cloud IaaS, so highest perfor-

mance levels are not expected. However, we want to

be able to get an honest average performance. One

ELASTICITY THANKS TO KERRIGHED SSI AND XTREEMFS - Elastic Computing and Storage Infrastructure using

Kerrighed SSI and XtreemFS

437

possible way to exploit the IaaS that we have created

with Kerrighed and XtreemFS would be to run vir-

tual machines inside, and to store virtual hard disks

on XtreemFS. Doing so, we could be able to bench-

mark against Amazon EC2.

For the record, we have “checked” this by doing

a massive parallel build of the Linux Kernel (

make

-j24

6 CONCLUSIONS

We ﬁnally set up the IaaS Layer of cloud stack. The

described setup is functional. Thanks to kerrighed,

we obtain an elastic and transparent computing solu-

tion. Thanks to XtreemFS, the proposed solution has

an efﬁcient elastic and transparent data storage solu-

tion. However we are aware of the current limitations

of both, and efforts are made to improve the robust-

ness. Thus we are hoping to reach an ideal elastic

solution of cloud.

Our solution has been tested by the execution of a

massive parallel computing application. The pro-

posed solution has the advantage of the elasticity

which is very interesting in many use cases like the

one presented previously. Now that this achievement

has been made, we can go further and expect to ﬁnally

be able to run some benchmarks.

REFERENCES

Appavoo, J., Uhlig, V., Stoess, J., Waterland, A., Rosen-

burg, B., Wisniewski, R., Silva, D. D., Hensbergen,

E. V., and Steinberg, U. (2010). Providing a Cloud

Network Infrastructure on a Supercomputer. In 1st

Workshop on Scientiﬁc Cloud Computing, Chicago,

IL, USA, June 2010, Chicago, Illinois.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., and Zaharia, M. (2010). A view of cloud

computing. Communications of the ACM, 53(4):50–

58.

Bar, M. (2002–2008). The openMosix Project.

http://openmosix.sourceforge.net/.

Barak, A. and Shiloh, A. (1977). MOSIX – Cluster and

Multi-Cluster Management. http://www.mosix.org.

Clubic.com (2010). Cloud stack. http://img.clubic.com/

photo/02883120.jpg.

Foundation, A. (2009). Hadoop hdfs. http://wiki.apache.org

/hadoop/MountableHDFS.

Garﬁnkel, S. L. (1999). Architects of the Information Soci-

ety: Thirty-Five Years of the Laboratory for Computer

Science at MIT. The MIT Press.

Hacker, T. J., Romero, F., and Carothers, C. D. (2009). An

analysis of clustered failures on large supercomputing

systems. J. Parallel Distrib. Comput., 69(7):652–665.

Huysmans, J., Baesens, B., Vanthienen, J., and Gestel, T. V.

(2006). Failure prediction with self organizing maps.

Expert Syst. Appl., 30(3):479–487.

Kerlabs (2006). Kerrighed – Linux Clusters Made Easy.

http://www.kerrighed.org.

Lissy, A. (2009a). Espace de stockage avec XtreemFS.

Master’s thesis, D´epartement Informatique de l’

Ecole

Polytechnique de l’Universit´e de Tours.

Lissy, A. (2009b). Politiques hybrides d’ordonnancement

dans un cluster Kerrighed. Master’s thesis,

D´epartement Informatique de l’

Ecole Polytechnique

de l’Universit´e de Tours.

Longtin, J. (2008). The LinuxPMI Project. http://linuxpmi.

org/trac/.

Mason, A., Clivio, L., and Travis, A. (2010). Application of

XtreemOS for development of NBX Grid. Technical

report.

Modzelewski, K., Miller, J., Belay, A., Beckmann, N.,

Gruenwald, Charles, I., Wentzlaff, D., Youseff, L.,

and Agarwal, A. (2009). A Uniﬁed Operating

System for Clouds and Manycore: fos. Techni-

cal report, MIT Dspace [http://dspace.mit.edu/dspace-

oai/request] (United States).

Morin, C., Gallard, J., J´egou, Y., and Riteau, P. (2009).

Clouds: a New Playground for the XtreemOS Grid

Operating System. Research Report RR-6824, IN-

RIA.

P´erotin, M. (2008). Calcul Haute Performance sur Mat´eriel

G´en´erique. PhD thesis, Laboratoire d’Informatique de

l’

Ecole Polytechnique de l’Universit´e de Tours.

Shang, Y., Jin, Y., and Wu, B. (2007). Fault-tolerant mech-

anism of the distributed cluster computers. Tsinghua

Science and Technology, 12(Supplement 1):186 – 191.

Team, C. (2010). The compatibleone project.

http://compatibleone.org.

Walker, B. (2001). OpenSSI Clusters for Linux.

http://www.openssi.org.

XtreemFS Team (2006). XtreemFS – a cloud ﬁlesystem.

http://www.xtreemfs.org.

XtreemOS Consortium (2006). XtreemOS. http://www.

xtreemos.eu.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

438
