APPLICATION PORTABILITY FOR PUBLIC

AND PRIVATE CLOUDS

Manohar Jonnalagedda, Michael C. Jaeger, Uwe Hohenstein and Gerald Kaefer

Corporate Research and Technologies, Siemens AG, D-80200 Munich, Germany

Keywords:

Cloud computing, Portability, Application symmetry, Application architecture, Hybrid cloud.

Abstract:

With cloud computing, the general idea is to deploy applications and services in the cloud, at some cloud

provider’s facilities. But as with traditional software applications, business demands still exist including legal,

privacy, cost and technical issues. These demands can prohibit the deployment of the entire software in a cloud

provider space. Thus, some cases demand for a hybrid deployment where the application is split into one part

that resides on premises and into another part that is deployed to the cloud provider facilities.

Nevertheless, individual components could be suitable for a deployment in the cloud. Thus, an important

characteristic for cloud computing is portability of components: software should be ready for being deployed

on-premises, in a provider cloud or in a hybrid (mixed) setup. The goal is to provide ﬂexibility to this regard

for leveraging the advantages of cloud computing. This paper introduces design considerations for developing

a hybrid application, in terms of software architecture, communication and security between modules. We give

recent trends and recommendations on how to solve these issues so as to achieve portability of the components.

1 INTRODUCTION

The cloud is used as a metaphor for the Internet,

due to the depiction of the Internet in cloud forms.

The metaphor results from the location transparency

(cf. Reference Model for Open Distributed Process-

ing (ISO/IEC, 1996)) that is a characteristic of the

Internet today: the physical location of a service or

node in the Internet is hidden, software and user deal

with logical locations posed by IPv4 or IPv6 ad-

dresses. The cloud represents a set of services that

provide computing, networking, and software capa-

bilities without a clear physical location. Cloud com-

puting refers to the provision of these services in three

provisioning categories:

1. Software-as-a-Service (SaaS): giving a user ac-

cess to software which runs on the cloud. All

computation taking place on the cloud.

2. Platform-as-a-Service (PaaS): giving developers

access to platforms and frameworks that allow

them to leverage the computing power of the

cloud and to develop own applications that run ef-

ﬁciently on the cloud.

3. Infrastructure-as-a-Service (IaaS): giving access

to highly scalable and elastic computing, network

or storage resources. This allows the developer to

build applications that can scale (seamlessly) to

many thousands of users, without having to buy

the hardware for it.

While the ﬁrst category is end-user oriented, it

is IaaS and PaaS that have made cloud comput-

ing attractive to the software industry (Gartner Inc.,

2010). Generally, the global pressure to reduce cap-

ital expenditures (CAPEX) and operational expendi-

tures (OPEX) drives the industry to the adoption of

rationalisation and automation. Cloud computing has

gained a lot of popularity because of its promise to

lower costs, which can be seen as the main driver

here. Customers expect to pay less because of econ-

omy of scale: large providers invest highly in large

and modern data centres which allow operations of

servers at a very low cost. Customers expect to beneﬁt

from this cost reduction. Other important arguments

in favour of cloud computing have been discussed by

(Armbrust et al., 2009):

• Flexible Contracts. Contracts from existing of-

ferings allow users to resign after a short period

of time. Thus the customer does not have to plan

a long term commitment to a provider.

• Lower Administration. Because infrastructure

and platforms are basically part of the offering

of the provider, their administration is also per-

484

Jonnalagedda M., C. Jaeger M., Hohenstein U. and Kaefer G..

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS.

DOI: 10.5220/0003394104840493

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 484-493

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

formed by the provider.

• Cloud Grade SLA. At the time of this writing,

large providers offer usually 99.9% (or 99.95%)

availability of the services. Such availability is

not given per se with individual deployments and

one must carefully select and deploy a provision-

ing platform to actually offer 99.9%.

• Towards Strategic Technology. Cloud comput-

ing platforms target the market of classic appli-

cation servers. As such, the classic application

server technology has been developed further to

serve as platform for cloud computing.

• On Demand Self Service. The cloud offerings

have the advantage that they provide the customer

with a self-service point in the Internet that is open

24h a day. The customer can initiate the product

use at virtually any time of the day.

In summary, several drivers can exist for a busi-

ness to use cloud services and it basically depends on

the application case if either one or more drivers apply

for the own business to move activities to the cloud.

Companies are therefore looking to gain all the bene-

ﬁts by developing software for the cloud.

The portability of cloud applications has two main

drivers: ﬁrstly, an organization plans to take bene-

ﬁt from the cloud computing offerings, and secondly,

restrictions prevent to run the application entirely or

partially in the provider cloud space. From a business

point of view, an ideal goal is to decide at deployment

time, depending on business demands, if the software

shall run in the provider cloud, in a private cloud on

premises or in a hybrid (mixed) setup, so as to have an

optimal trade-off between privacy and economic use

of cloud resources. In this paper, application porta-

bility refers to the ease with which modules of an ap-

plication can be split and deployed on on-premises or

cloud platforms, ending up in a mixed setup. Figure 1

depicts this idea.

We introduce the engineering issues for applica-

tion portability, which refers to the ﬂexibility at de-

ployment regarding the location and the partitioning

of the application. Furthermore we explain trends in

the ﬁeld and possible technical solutions. The paper

continues with Section 2 which explains the business

drivers and motivates this kind of portability. Section

3 describes the issues with portability while Section

4 outlines possible solutions. In Section 5 we look at

related work, and Section 6 concludes this work.

2 MOTIVATION

Two basic cases for portability exist: one is a techni-

cal issue, as applications or parts of it can be moved

from a private cloud which runs on-premises to a

provider cloud to compensate for capacity shortage

of own resources. This portability is required during

runtime. Another kind of portability is a business is-

sue: the deployment of an application shall take ad-

vantage from CAPEX and OPEX reduction promised

by cloud computing offerings. Such a portability is

required during deployment time.

The focus of this paper lies in the portability

driven by business demands. There are naturally

reasons why cloud computing may not be preferred.

These may be privacy issues, legal or compliance, or

operational-related, which could result from responsi-

bilities and structures of a large organization. Moving

business-critical information onto the public cloud is

a matter of reticence to many big organizations as, if

on the cloud, this information can physically lie in any

continent, which may go against local laws and poli-

cies, or even make the information liable to laws in

another country (see the Patriot Act (The Library of

Congress / Thomas, 2001)).

Furthermore, there are legal obligations that com-

panies must fulﬁll for particular information.

This means that the company or organization must

actually store such information on-premises requested

by governmental law. In a different case, some com-

ponents can take beneﬁt from a deployment in a

provider cloud while other components are well lo-

cated on existing infrastructure, not causing addi-

tional cost at the provider.

Finally, some applications may not be suited for

the cloud at all, not for technical reasons, but the rea-

son that an organization does not intend to reveal that

such application runs in general (this category is nat-

urally not the focus of the paper).

For companies with legal obligation on the provi-

sion of data but which do want to beneﬁt from the

cloud, technical and engineering questions present

themselves. Examples for such companies or orga-

nizations are manifold. Consider an image manage-

ment application which allows for uploading images

taken with different devices to be uploaded onto a

cloud computing application that performs image cal-

culations. The images are stored somewhere in the

world, but do not contain any metadata about users or

persons depicted on these images. Imagine a vendor

providing such software to different clients:

1. The local police department with high-deﬁnition

cameras to take pictures of various crime scenes

and other surveillance pictures, it is interested in

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS

485

Figure 1: Development and Deployment Scheme.

keeping high-quality pictures in a private setup. It

goes without saying that the police would like the

portal to run on-premises.

2. A medical diagnostics application that has some

high-tech equipment which takes pictures re-

lated to different illnesses inside the human body.

These images are large in size, and plenty in num-

ber. The institute might therefore like to store

and process the images themselves on the cloud,

although metadata concerning each image, being

conﬁdential, would be kept on-premises.

3. A group of college friends would like their im-

ages of a trip to the Bahamas to be uploaded di-

rectly onto a public platform, so that their other

friends can also view the pictures. They do not

mind where the photos are stored.

So, in the individual cases, different demands for

storing the data apply. However, as a software de-

veloper and vendor of the image management appli-

cation, the application should not be developed three

times. The business goal is reuse of the application

software for all the three cases. An ideal solution for

this situation would be to let the business model de-

cide whether the application will run locally, on the

cloud or in a hybrid setup. Dividing the application in

such a manner brings forward some key engineering

issues, which are discussed in the next section. In this

case, the location is set at deployment time of the ap-

plication. This degree of ﬂexibility is not required at

run-time.

3 ISSUES OF APPLICATION

PORTABILITY

Portability in general, is a well know term. Some of

the ﬁrst notable publications deﬁne portability as A

program is portable to the extent that it can be eas-

ily moved to a new computing environment with much

less effort that it would be required to write it afresh

(Johnson and Ritchie, 1978). Mooney adds the no-

tion of narrowing the set of targets for the program

and states accordingly that a program exhibits porta-

bility referring to a set of environments, if the cost is

lower that a rewrite (Mooney, 1997). For portability

with cloud computing we can build upon this deﬁni-

tion and distinguish two major cases:

• Vertical Portability is the capability of an appli-

cation intended for on-premises infrastructure to

be portable to a provider cloud environment. The

restriction is that the application runs on the same

technology stack on both platforms (Java or .NET

and respective cloud offerings, for example).

• Horizontal Portability is the ability to port an

application from one technology stack to another,

staying at the same level of abstraction but chang-

ing the technology provider.

As described in the above example of image man-

agement, the emergence of cloud computing brings

the need to develop software that runs both on-

premises and on the cloud. The business case de-

mands for vertical portability, as it allows for the

decision to stay within one technology stack. This

presents the following scenarios: if a vendor is cater-

ing exclusively to the ﬁrst or third type of client (po-

lice department or the private initiative), the problem

CLOSER 2011 - International Conference on Cloud Computing and Services Science

486

is solved by making use of PaaS offerings (Windows

Azure (Chappell, 2009), Google App Engine (GAE)

(Google Inc, 2008), Heroku (Heroku Inc., 2010) are

some examples) which provide frameworks and APIs

for developing software. On the other hand, devel-

oping on-premises software is a tried and tested tech-

nique.

Engineering issues really arise when one wants to

develop in a hybrid setup: ideally, we would like to

develop the image sharing software only once, and de-

ploy different modules of the application to different

platforms, as dictated by the business requirements.

In the following, the particular issues are described.

3.1 Application Architecture

Design principles are an important consideration

when developing any software. The goal is to build

applications which are highly scalable, maintainable

and reliable. These requirements are naturally appli-

cable when it comes to developing software for the

cloud, but are not mandatory part for traditional ap-

plication development.

From the above example and other general cases,

an important issue is the division of an applica-

tion into separate, self-contained and loosely cou-

pled modules, which, ideally, should be deployable

to different platforms. The age-old recommendation

of component-based programming is, as we can see,

very much applicable in the given scenario. The

caveat, however, is that the platforms on which the

modules will be hosted can be very different in terms

of computer architecture, database management, and

access to ﬁner aspects of the underlying OS (cloud

applications typically run on virtual hardware). The

big challenge, in terms of software design and archi-

tecture is, therefore, that of creating modules that are

conscious of the environment in which they run (so

as to take advantage of the underlying structure), and

at the same time independent enough so that their de-

ployment to other platform is effortless.

3.2 The Data Model and Persistence

Cloud computing has brought everybody’s eyes a shift

in thinking about data that has been taking place in the

IT world for the past decade. Traditionally, industrial

applications have considered relational database man-

agement systems (RDBMS) as the de facto standard

for persisting data. These database systems use SQL

as the main query language, and are therefore also re-

ferred to as SQL databases. They are highly prevalent

in the industry: they have the advantage of offering

transactional services, a general schema for storing

structured data, and indexing mechanisms which op-

timize queries. They concentrate mainly on consis-

tency.

In recent years, however, many companies have

been challenged by the sheer quantity of information

stored and accessed over the Internet: the necessity to

make their services highly available has been the main

driving force. This has seen the development of many

No-SQL type of databases, light-weight databases

whose main selling point is distributed services and

high availability. CouchDB (Apache Software Foun-

dation, 2008), MongoDB (10gen Inc., 2009) and Cas-

sandra (Apache Software Foundation, 2010) are some

popular No-SQL databases.

Cloud computing, with its promise of elasticity

and availability, is a natural ﬁt for such No-SQL

databases. This explains why the ﬁrst storage solu-

tions have been BLOB (binary large objects) storages

emulating a ﬁle system to some extent, and table stor-

ages. The latter keep a table view without requesting

a ﬁxed pre-deﬁned table schema to be deﬁned in ad-

vance. Hence, heterogeneous structures can be stored

in one table. The main focus of table storages is to of-

fer the 80% of database functionality that typical Web

applications require. They sacriﬁce consistency for

the sake of availability and partition tolerance in the

sense of Brewer’s CAP theorem (Gilbert and Lynch,

2002).

Prominent cloud providers have started their offer-

ing with No-SQL DBs. They focussed on table and

blob storage products which are advantageous w.r.t.

availability and tolerance to partitions. However, in

the recent past, providers have also extended their of-

ferings with additional SQL-based RDBMS technol-

ogy. For instance, Microsoft has announced Azure

SQL in last year and Google has announced similar

support recently.

3.3 Communication in a Hybrid

Deployment

Another important aspect for portability is to en-

sure security with respect to communication between

modules; the security of the cloud platform itself does

not involve application symmetry, and generally, busi-

ness decisions (based on cloud platform security con-

cerns) decide which modules can be deployed on the

cloud anyway. Modules can communicate with each

other via different layers of the network stack. When

developing Web applications, the main grounds for

communication is to access and consume application-

level data. Communication hence takes place at the

application layer. This type of communication privi-

leges data consumption and serving stateless requests.

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS

487

Secondly, there is a need to communicate at a lower

level: we need to be able to access and manage re-

sources at a different level from the applications, and

also ensure that incoming and outgoing packets to

a certain module are secure (authenticated and en-

crypted).

4 TECHNIQUES AND

RECOMMENDATIONS

The previous section outlined several issues that arise

for engineering applications in a mixed cloud setup.

The general rationale is that the ﬁnished application

should be portable enough so that the entire appli-

cation, or parts of it, can be deployed on a provider

cloud with as little effort as possible. Thus, the pro-

posed business goal of Section 2 is to decide at de-

ployment time for a given setup at runtime.

4.1 Software Architecture

For Platform as a Service (PaaS) offerings there are

several paradigmatic characteristics for cloud use.

One of the standard paradigms is divide and conquer,

which has also been adopted in Google’s MapReduce

framework for efﬁciently processing large problem

sets (Dean and Ghemawat, 2008). Cloud comput-

ing offers horizontal scalability: adding more work-

ing units to increase capacity, the ideal goal being

to achieve almost inﬁnite scalability. The common

consensus seems to be that good cloud applications

should be designed with awareness of horizontal scal-

ability. If the problem can be partitioned, then solving

the problem can be inﬁnitely spread among a set of

working units.

Secondly, with the proliferation of development

platforms for the cloud, each of them privileges cer-

tain building blocks for writing software optimally for

the cloud. The Windows Azure platform, for exam-

ple, provides the concept of roles: self-contained en-

tities implementing an elementary unit of processing

capability. In general, it is a good practice to im-

plement elementary units as opposed to classic large

Note: as outlined in Section 2 as a technical motiva-

tion, the freedom to migrate services into or off the provider

during run-time might be also required but has different mo-

tivations. For example, an organisation could migrate ser-

vices to the provider cloud in the case that the on-premises

infrastructure does not have any further capacity to host

applications (known as cloud-bursting). However, this de-

gree of dynamic migration is not the scope of this work.

Therefore, the following trends and recommendations do

not cover dynamic migration but consider ﬂexibility of ap-

plication deployment.

blocks of functionality: the latter would lead to large

units in the software system, thereby not allowing for

partitioning of the problem and not taking advantage

of the horizontal scalability of the cloud. The partition

of the application in many elementary units is a nec-

essary condition for the split deployment of the appli-

cation. For application portability, this design shows

the advantage that the application has a high degree

of partitioning opportunities.

In conjunction with elementary application units,

the second larger design issue for cloud computing

applications is decoupling of application components.

For horizontal scalability, statelessness is preferred,

as state at a certain key point of the application can

block the command ﬂow, hence losing all the ad-

vantages of elasticity and availability. Furthermore,

strong coupling would prevent the application from

the ability to scale dynamically. In order to elas-

tically add working entities at runtime, the applica-

tion architecture must show decoupled units of stages

where problem parts can be processed in an indepen-

dent manner. For splitting the application into two

deployment locations, the decoupling allows for the

use of service buses or other communication mecha-

nisms in order to overcome the distance between the

two parts (described in section 4.3).

Additionally, an aspect of software development,

applying speciﬁcally to cloud computing, is the re-

duction of service calls and transactions. Cloud com-

puting being pay-as-you-go, money can be saved by

minimizing calls to services, database servers, other

storage offerings, number of CPU cycles, etc. Al-

though this effect is not strong when using only a few

servers, savings can be signiﬁcant when the applica-

tion scales to hundreds or thousands of servers. For

Internet programming, caching is a concept used to

increase performance by decreasing the number of di-

rect queries of the database: The idea is to cache the

result of common queries in memory, and, for exam-

ple, responding with this result in case such queries

are made. With respect to cloud computing, such

techniques also help save money, as they reduce stor-

age access calls. Memcache of the Google App En-

gine environment (Google Inc, 2003) helps in achiev-

ing caching for saving calls to the storage system or

for preventing redundant data transfer to external ap-

plication.

To summarize, horizontal scaling of elementary

working units in the staging of an application is an el-

ementary architectural consideration in order to lever-

age the cloud resources in an optimal way. This

paradigm also enables the slip deployment of the ap-

plication in a hybrid cloud setup.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

488

4.2 Data Models

Data representation is a key part of any application. In

this section, we look at a few techniques and trends as

to how different models can be used so as to achieve

application portability. In this section we look at

schemes for storing structured data.

As explained in section 3.2, Web application de-

velopers and cloud providers privilege distributed

key-value stores for persisting structured data. The

advantages of such storages are described in the given

section. However, there are, at the moment, no stan-

dardized database or storage products that run both

on the cloud, and can be installed on-premises. For

example, the table storage service as part of the Mi-

crosoft Azure offering is not compatible with Ama-

zon SimpleDB, Moreover, the industry still largely

prefers using the tried and tested technique of tra-

ditional RDBMSs (which explains why main cloud

providers are also starting to provide SQL solutions),

so there is a need to design data models so that they

can run on many different platforms.

With this in perspective, Object-Relational Map-

pers (ORMs) offer an abstraction for representing the

data of the database at the programming level. Such

mappers were initially developed in order to connect

relational databases to object-oriented programming

languages (Ambler, 2002). The development of Web

application stacks and tools has turned this abstrac-

tion into a good practice. These persistence abstrac-

tions present a uniform access interface to many dif-

ferent database types. When developing hybrid appli-

cations, structured data can be represented using these

mappers: in the next subsection we explain how JDO

and DataNucleus (DataNucleus, 2008) can be used to

develop modules that could run either on Google App

Engine or locally.

Google App Engine’s Java runtime uses a Jetty

servlet container and the Java Servlet Standard for

Web applications. Its datastore, based on BigTable,

supports standard Java interfaces such as JDO and

JPA, which are themselves implemented using the

DataNucleus Access Platform. DataNucleus supports

many RDBMS systems, along with Web-based stor-

age systems such as Amazon S3, Hadoop HBase and

Google App Engine.

To make use of the JDO mappings, a developer

needs to import the relevant packages and add anno-

tations (@Persistent) to classes and attributes that

he would like to be persisted. There are some addi-

tional conﬁguration properties he needs to deﬁne in

a datanucleus.properties ﬁle, which include the

database which will be used for the application.

For an application that is to deployed on Google

AppEngine, the conﬁguration ﬁle will contain Ap-

pEngine speciﬁc information. In order to make it

possible to deploy the same application on a MySQL

database, the idea is to create another conﬁguration

ﬁle, which this time contains properties related to this

database.

At the code level, the properties ﬁle

is passed on as an argument to the

JDOHelper.getPersistenceManagerFactory

method. The value can be changed depending on

which platform the

Abstractions on top of data storage schemes

present an interesting solution to achieving portabil-

ity of structured data. This follows the old adage:

“All problems in computer science can be solved by

another level of indirection”. More than being useful

for accessing multiple types of databases, they have

the already known advantage of helping in program-

ming applications. ORM implementations such as Hi-

bernate or EclipseLink are popular frameworks for fa-

cilitating the object/relational mapping with different

database servers. As a third beneﬁt, they can also be

useful for transferring data from one platform to the

other: one just needs to extract the data from one store

and store it into an other, without having to bother

about the database speciﬁcations at a high-level.

There are speciﬁc cases in which speciﬁc database

operations are required, and for which it is wiser to di-

rectly address the data store without using the mapper

framework. JDO allows bypassing the framework to

query the underlying database directly, and even to

execute stored procedures. These features are how-

ever very speciﬁc to the type of RDBMS used, and

therefore not subject to abstraction. It is hence impor-

tant to identify such requirements during the design

phase of the application; in case speciﬁc operations

are required, the application might not be suitable for

running on multiple databases. In order to run such

software in a hybrid setup, it is recommended to use

identical underlying database technology.

4.3 Communication and Security

4.3.1 Application layer

Communication at the application layer refers to the

availability of Web services and other API technol-

ogy which allow data to be absorbed from or inserted

into a service. Communication via Web services is

one of the simplest forms of communication, and use-

ful when developing highly available services, as it

makes the software easier to use for clients and cus-

tomers. As more and more data becomes available on

the Internet, there are ever more ways to combine dif-

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS

489

ferent pieces of information and present them in novel

ways: many popular Web applications therefore pro-

vide REST APIs for clients, customers or users to ac-

cess data, process and use it in new, imaginative ways.

The Programmable Web (Musser, 2010) provides a

list of applications offering such APIs.

This is relevant to application portability as we can

imagine different modules of an application providing

access to data through Web services. Moreover:

• Cloud services are accessible on the Internet, and

there is a need for appropriate security measures

at this level. Web services’ security standards and

identity federation are required building blocks

for design.

• Providing a data access API generally requires lit-

tle overhead on creating the application itself, and

provides an easy-to-use, generalized interface to

many potential clients without having to set up

speciﬁc protocols with each of them.

• Two sites communicating uniquely via calls to

Web services abstract the network layer beneath

them, and alleviate the need for developing com-

plex communication protocols. Any module of

the application becomes portable: wherever it re-

sides, it can be accessed as long as it provides an

interface to absorb data.

One of the main security issues in terms of commu-

nication via Web services is authorization; how one

gives an authorized user access to the API, and pre-

vent non-authorized users from accessing it. Design

of secure Web services is a difﬁcult topic and an ac-

tive subject of research and discussion (Fernandez,

2004; OAuth Core Workgroup, 2009; OASIS Con-

sortium, 2002; Fielding, 2000). Many Web applica-

tions allow third-party login: it is possible to get ac-

cess to an API/service by using one’s Google creden-

tials, for example. This is a security hazard, as appli-

cations could get access to unrelated login informa-

tion. A better idea is to hand out tokens to the third-

party website in question. This token, received from a

trusted source, is accepted by the website, and access

to data is thereby granted. This technique is named

OAuth (an open standard) (OAuth Core Workgroup,

2009). Microsoft AppFabric’s ACS (Brown, 2009) is

an implementation of this standard and allows devel-

opers to write secure APIs that accept ACS tokens.

4.3.2 Network Layer

While the use of Web services for data access may

be simple and elegant, there are certain types of ap-

plications (chat applications and collaboration tools,

for example) for which such interfaces have too much

overhead in communication. Transferring ofﬂine data

from one platform to another can also be a bottleneck

in terms of performance.

Large corporations having centers worldwide

study ways of connecting them in secure ways. Enter-

prise Service Bus is a prevalent concept among them.

Microsoft AppFabric’s Service Bus aims to take the

concept onto the cloud, enabling applications residing

on the cloud to work with those on other platforms.

The service bus concept is one way of looking at

the communication issue between different platforms.

Another way is to attempt to bring both the cloud

and on-premises platforms into a single virtual net-

work. Amazon’s VPC (Amazon.com Inc., 2009) is a

product which goes in this direction: the on-premises

network is connected to the Amazon Cloud resources

via a secure VPN connection over the internet. This

gives the illusion of a giant (seemingly inﬁnite) enter-

prise network, with all the advantages of cloud com-

puting (scalability, availability, computation). VPN

connections as links between cloud and on-premises

software have also been studied elsewhere. Wolinsky

et al. (Wolinsky et al., 2009) studied network archi-

tectures in which network clients can be seamlessly

added and removed from a virtual network. They

conclude in their study that virtual networks provide

excellent isolation, and good performance over Wide

Area Networks.

5 RELATED WORK

Relevant cloud providers continuously work to pro-

vide seamless integration of cloud computing with

on-premises technology. Amazon, Microsoft, and

Google have all released, or are in the process of re-

leasing, SQL related technologies to bridge the gap

(Amazon RDS, SQL Azure and Google App Engine

for Business, respectively).

On the other hand, people have come to realize

the advantages on No-SQL databases and storage sys-

tems, given their success with Web 2.0 applications

and social networks such as Facebook and Flickr.

Many of these storage solutions themselves offer inte-

gration with the cloud. CouchDB, for instance is used

by the Ubuntu One cloud provider as their distributed

document storage software. Ubuntu users can use

CouchDB to store data locally, and using CouchDB’s

replication capability, synchronize their documents

over different computers or over the secure storage

on the Ubuntu One cloud. The replication function-

ality comes into play for intensive cloud computing

applications when dealing with several server nodes:

efﬁcient replication between server nodes allows for

vertical scalability, meaning adding extra CouchDB

CLOSER 2011 - International Conference on Cloud Computing and Services Science

490

nodes for improving overall capability. ThruDB is

another relevant concept, especially for application

portability. ThruDB offers a key value store provided

by own implementation. In addition, it allows for set-

ting Amazon S3 as storage implementation replacing

the own functionality.

There are also many open-source solutions which

attempt to grant access to No-SQL databases as well

as cloud offerings. The DataNucleus Access Plat-

form, as mentioned in the above section, is a solution

that caters to various types of database servers or ser-

vices, including Google App Engine and Amazon S3.

Recent projects also include access to the MongoDB

datastore. AppScale allows users to deploy Google

App Engine applications on-premises, as well as on

Amazon EC2. It allows mappings to many differ-

ent datastores, such as Hypertable, HDFS, Cassandra,

MongoDB.

Another general direction of research has been

to bring the cloud paradigm to on-premises environ-

ments. Eucalyptus and Ubuntu Private Cloud are

open-source frontrunners in this ﬁeld. The advantage

of such technology is that it makes it easier for dis-

tributed algorithms and patterns to be portable. A

Hadoop-based Mapreduce application can be there-

fore run on-premises or on Amazon’s Elastic Mapre-

duce.

Section 3 has already mentioned two references

that discuss portability of the programming language

C, its compiler and the UNIX system (Johnson and

Ritchie, 1978), which was a fundamental effort, and

the issues of portability from a software development

perspective (Mooney, 1997). The general recommen-

dation that can be drawn from these writings are:

• Reduce the amount of platform-related code,

which is not focus of this work as the problem

posed by the business case actually allowed to

stay within one platform.

• Isolate dependencies which is generally a well es-

tablished practice of programming. For the con-

text of the problem of this work, this would trans-

late to dependencies to the actual environment

which has been discussed with the data model and

storage provider issues.

• Externalize interfaces, which means that access to

any given component inside or outside would be

made explicit by using a contract rationale. This

issue has also been covered by modern program-

ming languages offering separate constructs for

deﬁning interfaces.

These recommendations have also led to design pat-

terns: Most notable example is the Wrapper Fa-

cade (Schmidt et al., 2000) which proposes to isolate

system- or platform calls to a single point of entry.

Thus, porting the software to another system or plat-

form will require changes to only a single location

in the software. This applies also to the UNIX de-

sign featuring a hardware speciﬁc kernel, as described

by Johnson and Ritchie (Johnson and Ritchie, 1978).

Transferred to the vertical portability in the cloud

case, this work has focussed on the data provider as

speciﬁc platform calls.

Referring to cloud computing, the issue of porta-

bility is recent and not much covered in literature – as

current offerings are still in the phase of orientation

and sharpening of the focus. The main issue for ensur-

ing this kind of portability is the fear of vendor lock

in. Vambenepee states that many issues besides API

compatibility are currently not solved, such as migrat-

ing the data from one storage to another, compatibil-

ity to billing and metering, error handling and logging

or just administration(Vambenepee, 2009). However,

these issues are not the focus of this work, because:

• The concept of vertical portability allows for us-

ing the same technology stack when deploying the

application into the provider cloud.

• The business scenario decides on the deployment

at the deployment time. Thus, once an application

is deployed, it can keep its location. Thus, the

migration of data from existing systems is not an

issue in this scenario.

6 CONCLUSIONS

In this paper, we have discussed some of the trends

and recommendations when it comes to the portability

of application between the provider cloud and infras-

tructure on premises. It is important to note that we

focussed on portability (ﬂexibility in platform choice)

at deployment time, as opposed to dynamic portabil-

ity. We identiﬁed software architecture, data model,

communication and security as key issues when it

comes to developing such applications.

From the previously discussed points, we can

summarize recommendations for each category of is-

sues. In terms of software architecture, a developer

should concentrate on:

• Build APIs and Web services which allow access

to application data. This standardizes access to

data and moves the application into a SaaS world

(which is the overwhelming trend of software ap-

plications nowadays).

• Consider using patterns like MapReduce to dis-

tribute computation over multiple nodes and to di-

minish the overall time taken for batch-oriented

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS

491

tasks.

• Consider deploying high availability requiring

modules, such as Web applications, entirely on

the cloud. Use Web application PaaS offers such

as Google App Engine, Heroku or CloudBees for

such modules, as they scale (semi-)automatically.

With respect to data models, it is important to:

• Note that with simple No-SQL storage service of-

ferings, join operators in queries are sometimes

not supported. Thus, the data model should sup-

port a convenient handling of join-like queries in

program code.

• Consider using No-SQL databases on-premises

for achieving similar scalability on local infras-

tructure as well.

• Design the logic of the application to be agnos-

tic about a particular database software. Avoid

writing queries which are speciﬁc to a certain

database product or software in the source code.

Use ORMs or abstraction layers to achieve this

task.

Finally, for secure and authentication communica-

tion, it is important to:

• Restrict access to data by using open standards

and claims-based authentication. Use open stan-

dards such as OpenID and OAuth to achieve this.

• Consider using service bus technology for con-

necting cloud and on-premises infrastructure.

Cloud computing, after the initial hype, has reached

the ﬁrst steps with many big industrial players ac-

tively looking for cloud solutions. Portability of ap-

plications between provider and private clouds is a

very important issue for them, and we expect to see

many new solutions and ideas in this ﬁeld in the

coming months. The presented trends and recom-

mendations show that this desired ﬂexibility can be

achieved for some cases with patterns and program-

ming paradigms. Also, the available technology of-

fered by the major vendors in the cloud computing

business conﬁrms this possibility and provides API

and frameworks for a distributed application setup.

REFERENCES

10gen Inc. (2009). Mongodb - scalable, high-performance,

open source, document-oriented database. Available

from http://www.mongodb.org/.

Amazon.com Inc. (2009). Amazon virtual private cloud

(amazon vpc). http://aws.amazon.com/vpc/.

Ambler, S. W. (2002). O/r mapping in detail.

http://www.agiledata.org/essays/mappingObjects.html.

Apache Software Foundation (2008). Couchdb project.

http://couchdb.apache.org/.

Apache Software Foundation (2010). Cassandra project.

http://cassandra.apache.org/.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R. H., Konwinski, A., Lee, G., Patterson, D. A.,

Rabkin, A., and Zaharia, M. (2009). Above the

clouds: A berkeley view of cloud computing. Tech-

nical report, University of California at Berkeley.

Brown, K. (2009). A developer’s guide to access control in

windows azure platform appfabric. White paper, Mi-

crosoft and Pluralsight. Available online (35 pages).

Chappell, D. (2009). Introducing windows azure. White

paper, Microsoft and Chappell Associates. Available

online (25 pages).

DataNucleus (2008). Datanucleus project.

http://www.datanucleus.org.

Dean, J. and Ghemawat, S. (2008). MapReduce: simpliﬁed

data processing on large clusters. Communications of

the ACM, 51(1):107–113.

Fernandez, E. B. (2004). Two patterns for web services

security. In Proceedings of the Int. Symposium on Web

Services and Applications, Las Vegas.

Fielding, R. T. (2000). REST: Architectural Styles and

the Design of Network-based Software Architectures.

Doctoral dissertation, University of California, Irvine.

Gartner Inc. (2010). Gartner top

10 strategic technologies 2010.

http://www.gartner.com/it/page.jsp?id=1210613.

Gilbert, S. and Lynch, N. (2002). Brewer’s conjecture and

the feasibility of consistent available partition-tolerant

web services. In In ACM SIGACT News.

Google Inc (2003). Memcache. http://memcached.org/.

Google Inc (2008). Google app engine - run

your web apps on google’s infrastructure.

http://code.google.com/appengine/.

Heroku Inc. (2010). Heroku : Ruby cloud platform as a

service. http://heroku.com/.

ISO/IEC (1996). ITU.TS Recommendation X.902 —

ISO/IEC 10746-1: Open Distributed Processing Ref-

erence Model - Part 1: Overview.

Johnson, S. C. and Ritchie, D. M. (1978). Portability of c

programs and the unix system. Bell System Tech J,

57:2021–2048.

Mooney, J. D. (1997). Bringing portability to the software

process.

Musser, J. (2010). Programmable web: Keeping you up

to date with apis, mashups and the web as platform.

http://www.programmableweb.com/.

OASIS Consortium (2002). Saml — security assertion

markup language. http://saml.xml.org/.

OAuth Core Workgroup (2009). Oauth core 1.0.

http://oauth.net/core/1.0/.

Schmidt, D. C., Stal, M., Rohnert, H., and Buschmann, F.

(2000). Pattern-Oriented Software Architecture, Vol-

ume 2: Patterns for Concurrent and Networked Ob-

jects. Wiley, Chichester, UK.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

492

The Library of Congress / Thomas (2001). Uniting

and strengthening america by providing appropri-

ate tools required to intercept and obstruct terror-

ism (usa patriot act). http://thomas.loc.gov/cgi-

bin/bdquery/z?d107:h.r.03162:.

Vambenepee, W. (2009). The reality on cloud portability.

Available from http://www.sdtimes.com/link/33502.

Wolinsky, D. I., Liu, Y., Juste, P. S., Venkatasubramanian,

G., and Figueiredo, R. J. O. (2009). On the design

of scalable, self-conﬁguring virtual networks. In SC.

ACM.

APPLICATION PORTABILITY FOR PUBLIC AND PRIVATE CLOUDS

493
