EVENT-BASED MAINTENANCE OF DIGITAL LIBRARY

COLLECTIONS

Wendy Osborn

Department of Mathematics and Computer Science, University of Lethbridge, Lethbridge, Alberta, Canada

Keywords:

Digital libraries, Greenstone, Event-based collection management.

Abstract:

We consider the problem of updating a digital library collection automatically when certain events occur. Ex-

isting digital library systems require the user to either re-build manually or to schedule re-building at speciﬁed

times. Ideally, a collection should be re-built whenever some collection-changing event occurs. We propose

the Event Monitor for Greenstone, a tool that continually tests for collection-altering events and re-builds the

collection when these events occur. The Event Monitor interacts with the existing scheduling mechanism on

the host system, thereby making it a simple yet powerful tool for event-based maintenance.

1 INTRODUCTION

Many applications generate multimedia documents

on a periodic basis. One example is a photo-radar pro-

gram whose purpose is to catch vehicles that break

certain trafﬁc laws, such as speeding. A signiﬁcant

number of pictures of vehicle license plates are gen-

erated every day. Another example is a medical in-

formation system such as CAIRN (Karanikolas and

Skourlas, 2000; Karanikolas, 2007), which would be

required to be updated continually to keep its content

current if it is going to be useful to physicians. In

either case, if these multimedia documents are orga-

nized into a digital library, the collection needs to up

dated regularly to include new documents.

When managing a digital library collection, the

owner usually adds new documents to the collection

manually. This is reasonable when documents are

added infrequency, or the user always has the time

and means to access to a computer that allows them to

access the digital library. However, when documents

are added constantly to a collection, an automated ap-

proach is more practical over a manual one. Ideally,

a collection should be updated immediately when any

changes to the collection are made.

Most existing digital library systems, such as

DSpace (Tansley et al., 2006) and Fedora (Lagoze

et al., 2006) require that documents be added man-

ually to a collection. Although both software systems

provide application programming interfaces (APIs)

that could be used to create an automatic updater, pro-

gramming knowledge is required for using an API.

Greenstone (New Zealand Digital Library Project,

2008; Witten et al., 2009) includes a mechanism for

scheduling a collection re-build to occur every hour,

day or week (Osborn and Fox, 2007). It works by

interacting with the Cron scheduler on the host sys-

tem. Limitations of this approach include the restric-

tions to re-build at speciﬁc intervals. An approach that

rebuilds immediately upon any change to the collec-

tion would better serve digital library users, especially

those requiring real-time updates to their collections.

We present a solution for event-based manage-

ment of a digital library in Greenstone. The ﬁrst part

involves the design and implementation of an event

monitoring module. The Event Monitor runs every

minute and tests a collection for any changes in doc-

uments, metadata or general conﬁguration. If any

changes are found, a collection building script is ex-

ecuted to re-build the collection. The second part

involves modifying the Scheduler (Osborn and Fox,

2007) to accept a frequency value of ”now” to in-

dicate event-based collection building, and to create

the appropriate Cron record. Therefore, the Sched-

uler will be responsible for setting up the event-based

construction of a collection.

2 BACKGROUND

In this section, we provide some necessary back-

ground on Greenstone, the Scheduler, and Cron.

123

Osborn W..

EVENT-BASED MAINTENANCE OF DIGITAL LIBRARY COLLECTIONS.

DOI: 10.5220/0003396301230128

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 123-128

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2.1 Greenstone

Greenstone (New Zealand Digital Library Project,

2008; Witten et al., 2009) is a software suite for cre-

ating custom digital library collections and making

them available locally or via the Internet. A digital

library collection contains documents of varying for-

mats, including images, PDF ﬁles, Word documents,

etc. A Greenstone collection can be customized in

many ways. For example, a user can specify the ap-

pearance of the interface to their collection, how the

collection will be accessed, and the types of docu-

ments that the collection can contain.

A greenstone collection can be maintained in two

ways. The ﬁrst is by using the import and build com-

mands that are executed from a command prompt.

The second is by using the Greenstone Librarian In-

terface (GLI) (Witten, 2004), which allows users who

are more comfortable with using a graphical user in-

terface to have full access to the same functionality.

2.2 Cron

Cron (Nemeth et al., 2007; Vixie, 1994; Schapira,

2004) is a program for users to schedule tasks that

will run automatically at a speciﬁed time. A task can

be one command, or a script containing several com-

mands that are executed in sequence. Initially, Cron

was implemented for Unix and Linux platforms, with

most systems running Vixie Cron (Vixie, 1994). Mac

OS X also runs Vixie Cron. In addition, versions of

Cron now exist for Windows platforms, such as Py-

cron (Schapira, 2004). We summarize the general

ideas behind all implementations of Cron that are ap-

plicable to our work.

Every minute, Cron reads task conﬁguration ﬁles,

called crontab ﬁles, that contain a record for every

task that is scheduled for execution at a speciﬁc time.

The format of a crontab record is (min hr dom moy

dow user task), where min, hr, dom, moy, and dow

are the minute, hour, day of month, month of year

and day of week, respectively, user is the username

that the command will run under, and task is the com-

mand or script that is executed at the speciﬁed time.

Two types of crontab include system crontab and

user crontab. A system crontab ﬁle is mainly for sys-

tem administration and maintenance tasks. Also, even

if all tasks have a speciﬁed low-level username, root

privileges are required for modifying a system crontab

ﬁle. A user crontab ﬁle can be set up by any user

on the system to execute tasks under their own user-

name. Assuming the user has permission to execute

the task, no root permissions are required. Therefore,

the Greenstone scheduler uses a user crontab ﬁle.

30 * * * * /collect/pics/gsdl.pl

59 23 * * * /usr/bin/cleanup.bash

00 6 * * 7 /home/someuser/alarm

00 0 1 1 * echo "Happy New Year!"

Figure 1: Sample Crontab File.

#!/usr/bin/perl

$ENV{’GSDLHOME’}="/home2/gsdl/gsdl";

$ENV{’GSDLOS’}="linux";

$ENV{’GSDLLANG’}="";

$ENV{’PATH’}="/bin:/usr/local/bin:

/usr/bin:/usr/local/gsdl/bin/script:

/usr/local/gsdl/bin/linux";

system("import.pl -removeold pics");

system("buildcol.pl -removeold pics");

system("\\rm -r /collect/pics/index/*");

system("mv /collect/pics/building/*

gsdl/collect/pics/index/");

system("chmod -R 755 /collect/pics/index/*");

00 0 * * * /gsdl/collect/pics/cron.pl

Figure 2: Sample Building Script and Crontab Record.

Figure 1 displays a sample user crontab ﬁle

with 4 tasks that are scheduled for speciﬁc times.

The ﬁrst task, /collect/pics/gsdl.pl, is scheduled to

be run at 30 minutes past every hour. The sec-

ond task, /usr/bin/cleanup.bash, is scheduled for

execution daily at 11:59pm. The third task,

home/someuser/alarm, is scheduled every Sunday at

6:00am. Finally, the fourth task, which echoes

”Happy New Year!”, is schedule for execution every

January 1st at 12:00am.

2.3 The Scheduler

The Scheduler (Osborn and Fox, 2007; Osborn et al.,

2008) is a command-line program that is part of the

Greenstone software suite. The Scheduler creates a

building script for a speciﬁc collection and also inter-

acts with Cron on the operating system. The original

version of the Scheduler takes as command-line argu-

ments the name of the collection, the import and build

commands (and all of their required arguments), and

the frequency of execution (hourly, daily or weekly).

The output from the Scheduler is a customized Perl

script that rebuilds the collection, and modiﬁcations

to the Cron scheduling service to execute the script at

the frequency speciﬁed.

For example, suppose we want to schedule a daily

build of the collection pics. A call to the Scheduler

would resemble the following:

schedule.pl

-import "import.pl -removeold pics"

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

124

-build "buildcol.pl -removeold pics"

-frequency daily

-colname pics

Figure 2 shows the resulting build script and crontab

record for the collection pics on Linux.

In addition, a call to the Scheduler can be made

through the GLI (Osborn et al., 2008). Figure 4(a)

depicts the Options Pane for the Scheduler. Here,

the collection owner can select the appropriate op-

tion. Then, they can click on Schedule Action for the

scheduling to take affect.

3 EVENT-BASED MAINTENANCE

We present a solution for the event-based construction

of a digital library collection in Greenstone. The over-

all process is presented ﬁrst, followed by all events

that require a digital library collection to be re-built.

Then, the Event Monitor is presented, followed by re-

quired changes to the Scheduler.

3.1 Overall Process

The following sequence of events is adopted for

the event-based building of a Greenstone collection.

First, an Event Monitor performs the task of detecting

the events that require that the collection be re-built. If

any of these events are detected, and the collection is

not already in the middle of a re-building process, the

collection is re-built using an automation script (i.e.

cron.pl) that is created speciﬁcally for the collection.

This sequence of events is set up by the Scheduler to

execute every minute.

3.2 Events

Many events require that a collection be rebuilt in or-

der to reﬂect changes. The events can be categories

into documents, metadata, and collection conﬁgura-

tion. Each is presented below.

3.2.1 Documents and Metadata

1. Adding a Document. When a new document is

added to the import folder of a collection, it is not

part of the collection until it is re-built.

2. Deleting a Document. Similarly, if a document is

deleted from the import folder, it is not removed

from the collection until it is re-built.

3. Updating a Document. Also, if the content of

an existing document needs to be updated, this

can only occur with the copy in the import folder.

Therefore, the collection needs to be re-built to

reﬂect changes in any document.

The same situations apply to user-speciﬁed meta-

data. If any metadata is added to a document, up-

dated for a document or removed from a document,

the collection must be rebuilt to reﬂect the changes.

In addition, any indices and browsers that depend on

those metadata values must be updated to reﬂect any

changes.

3.2.2 Updated Collection Conﬁguration

The conﬁguration of a Greenstone digital library can

be modiﬁed in the following ways:

1. Plugins. If documents of types currently un-

known to the collection are introduced, the corre-

sponding Plugins that are required for processing

them must be speciﬁed.

2. Indices and Classiﬁers. When working with both

indices and classiﬁers, the collection owner can

update the following. The ﬁrst is the type of index

or classiﬁer that will be created. The second is the

metadata that is organized for searching or brows-

ing (for example, dc.Title). The third are options

for the browsers.

3. Display Formatting. In addition, a collection

owner can specify how a list of documents that is

retrieved via searching or browsing is visualized

in a web browser.

The ﬁrst two options - updates to Plugins and In-

dices/Classiﬁers - requires a collection to be re-built.

3.3 Event Detection Module

In this section, we present our solution to event detec-

tion in Greenstone. The Event Monitor is written in

Perl and runs on Linux, Windows and Mac OS X. Perl

was chosen because a Perl script is executable across

different platforms and meets the cross-platform re-

quirement of Greenstone.

The Event Monitor requires as input the name of

collection to be monitored. It also requires that a

cron.pl script exists for the speciﬁed collection, and

that a Cron task is set up to execute the Event Moni-

tor every minute. The latter two requirements are han-

dled by the Scheduler, and will be presented later.

The events that are detected by the Event Monitor

are handled in this order: updates to the collection

conﬁguration, updated documents, added documents

and deleted documents.

EVENT-BASED MAINTENANCE OF DIGITAL LIBRARY COLLECTIONS

125

3.3.1 Updated Collection Conﬁguration

The conﬁguration of a Greenstone collection is stored

in a collection conﬁguration ﬁle (i.e. collect.cfg). The

modiﬁcation timestamp of the collection conﬁgura-

tion ﬁle is compared to the modiﬁcation timestamp

of the archives source ﬁle (i.e. archiveinfo-src.gdb).

If the collection conﬁguration ﬁle has a modiﬁcation

timestamp that is more recent, then the collection con-

ﬁguration has changed since the last time the collec-

tion was built, and therefore the collection needs to be

updated. This test is performed ﬁrst because it is the

fastest of all to perform. If the conﬁguration has been

updated, the collection can be re-built automatically

without having to test for the other events.

We compare modiﬁcation timestamp of the collec-

tion conﬁguration ﬁle against the archive source ﬁle

(i.e. archiveinf-src.gdb) modiﬁcation timestamp in-

stead of against the system clock (minus one minute)

for the following reasons: 1) For the ﬁrst iteration of

the Event Monitor, the collection may be out of date

by more than one minute and 2) If a collection takes

more than one minute to build, as the case is with

very large digital library collections, the resulting col-

lection will be out of date by more than one minute.

Therefore all time comparisons are performed versus

the archive source ﬁle.

3.3.2 Added and Updated Files

Each document in the import folder is evaluated to

see if it new or updated at the same time. Therefore,

only one pass needs to be made through the import di-

rectory. A list of documents that have been imported

into the collection is obtained from the archive source

ﬁle. In addition, the modiﬁcation timestamp for the

archives source ﬁle is obtained. This is an indicator

of when the collection was last built.

For each document, it is ﬁrst determined if it is

in the list of existing documents. Then, its modiﬁca-

tion timestamp is evaluated against that for the archive

source ﬁle. If the document is not in the list of exist-

ing documents, or if its timestamp is more recent that

that of the archives source ﬁle, then the document was

added or updated since the last build, and the collec-

tion must be re-built.

3.3.3 Deleted Files

When a ﬁle is deleted from the import folder, it is no

longer possible to use it for testing against any docu-

ments lists. However, it is possible to perform a quick

test to see if the number of documents is less than the

number that have been added to the collection. A dif-

ference in values indicates that some documents have

schedule.pl

-colname pics

-import "import.pl -removeold pics"

-build "buildcol.pl -removeold pics"

-frequency now

Figure 3: Scheduler Command for Event-based

Collection Building.

been deleted from the import directory. A count of

ﬁles in the import directory can be obtained during

the Add/Update stage. Therefore, only a count of the

number of documents in the list of existing documents

needs to be obtained to do this comparison.

3.3.4 Metadata Changes

Because any user-speciﬁed metadata is stored in a ﬁle

in the import directory, any additions, updates or dele-

tions of metadata are handled by comparing the mod-

iﬁcation timestamp of the metadata ﬁle against that of

the archives source ﬁle. Therefore, it is handled the

same way as a document update.

3.4 Scheduler Modiﬁcations

The Event Monitor requires that the collection it is

monitoring have an existing automation script and an

existing crontab record that schedules the execution of

the monitor every minute. The Scheduler creates that

appropriate automation script that is tailored to the

collection and the needs of its owner. In addition, the

Scheduler handles the generation of crontab records

for the scheduled build of collections. Therefore, all

that needs to be extended in the scheduler to work for

event-based collection building are: 1) the speciﬁca-

tion of a ’now’ value for the -frequency option, and 2)

for this option, the generation of a crontab record that

calls the Event Monitor module. Figure 3 depicts a

modiﬁed Scheduler command to initiate event-based

collection building. Also, Figure 4(a) depicts the GLI

with the frequency option value of “now”.

4 APPLICATION

We present a simple application of event-based col-

lection building from the GLI. In this scenario, we

have a traveler who wants to post pictures of her trip

in a Greenstone collection for her friends to view. In-

stead of waiting until the end of the trip, the traveler

wants to post her pictures from her hand-held device,

incrementally adding to the collection when neces-

sary. The traveler does not want to worry about ac-

cessing the GLI while traveling. Instead, she simply

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

126

(a) Scheduling Options Pane.

(b) Build - First Day. (c) Build - Second Day.

Figure 4: Collection Build Scheduling.

wants to upload the pictures to the import folder of

her collection, and have her collection rebuilt imme-

diately after she uploads her pictures. This can be

accomplished by setting up an event-based automatic

rebuild of the collection of travel photos from the

GLI.

Before departing, the traveler runs the GLI and

creates a new collection. Then, she selects the Cre-

ate tab to display the collection creation pane. From

here, clicking on Schedule Options will display the

available options for setting up a scheduled, auto-

matic collection build of the collection of travel pic-

tures. Figure 4(a) depicts the available scheduling op-

tions, which are displayed with default values. Here,

the traveler selects schedule, which indicates that she

wants to set up a scheduled, automatic build. Also,

she selects a frequency of now and an action of add

(or, to create a new event-based build).

Next, the traveler clicks on Schedule Action. This

will set up the building script for the collection of

travel pics, as well as the crontab record that will in-

dicate to Cron that the Event Monitor will continually

monitor her collection for new pictures, and automat-

ically update the collection whenever new pictures ar-

EVENT-BASED MAINTENANCE OF DIGITAL LIBRARY COLLECTIONS

127

rive. The collection is now ready to be re-built while

the traveler is away.

On the ﬁrst day of travel, she uploads three pic-

tures at different times, which are added to the collec-

tion immediately upon upload. The updated collec-

tion after the upload of the third picture is depicted in

Figure 4(b). The next day, the traveler uploads three

more pictures at different times. Figure 4(c) depicts

the updated collection with the new pictures.

5 CONCLUSIONS

We propose a solution for event-based collection

maintenance in Greenstone. The Event Monitor exe-

cutes every minute and checks for collection-altering

events so that the collection can be re-built. Also, this

solution takes advantage of the services of the Sched-

uler, so that the Event Monitor also uses the services

of Cron on the host system. Therefore, the Event

Monitor is a simple yet powerful edition to Green-

stone and will allow collection owners further ﬂexi-

bility in how they manage their collections.

Some future work includes the following. First,

although altering display formatting does not require

a re-build of a collection to take effect, the collec-

tion is re-built in this situation. It would be ideal

to not trigger a re-build in this case. Second, if a

collection owner wants to not test for events every

minute, an ideal approach would be to have an op-

tion specifying the number of minutes between event

checks. Although the Scheduler ensures that a collec-

tion build “in progress” will not be interrupted, some

users may feel more comfortable spreading out the

event checks anyway. Finally, although preliminary

tests were conducted to ensure that the Event Monitor

works, a more thorough evaluation of different event

scenarios is necessary. In particular, we need to de-

termine whether continuous monitoring will degrade

system performance overall.

REFERENCES

Karanikolas, N. N. (2007). Low cost, cross-language and

cross-platform information retrieval and documenta-

tion tools. Journal of Computing and Information

Technology, 15(1):71–84.

Karanikolas, N. N. and Skourlas, C. (2000). Computer as-

sisted information resources navigation. Medical In-

formatics and the Internet in Medicine, 25(2):133–

146.

Lagoze, C., Payette, S., Shin, E., and Wilper, C. (2006).

Fedora: an architecture for complex objects and their

relationships. International Journal on Digital Li-

braries, 6(2):124–138.

Nemeth, E., Snyder, G., and Hein, T. R. (2007). Linux Ad-

ministration Handbook. Prentice-Hall.

New Zealand Digital Library Project (2008). Greenstone

digital library software. Website. Last Visited June

2010. http://www.greenstone.org.

Osborn, W., Bainbridge, D., and Witten, I. H. (2008). A

user-oriented approach to scheduling collection build-

ing in greenstone. In Proceedings of the 11th Inter-

national Conference on Asia-Paciﬁc Digital Libraries

(ICADL 2008).

Osborn, W. and Fox, S. (2007). Automatic and scheduled

maintenance of digital library collections. In Pro-

ceedings of the 2nd IEEE International Conference on

Digital Information Management (ICDIM 2007).

Schapira, E. (2004). Python cron - great cron

for windows. Website. Last visited June 2010.

http://sourceforge.net/projects/pycron.

Tansley, R., Bass, M., and Smith, M. (2006). Dspace as an

open archival information system: Status and future

directions. In Proc. of the 10th European Conference

on Digital Libraries.

Vixie, P. (1994). Vixie cron for FreeBSD. website. Last

visited June 2010. http://www.freebsd.org/cgi/

cvsweb.cgi/src/usr.sbin/cron/.

Witten, I. H. (2004). Creating and customizing collections

with the Greenstone Librarian Interface. In Proc. of

the Int’l Symp. on Digital Libraries and Knowledge

Communities in Networked Information Society.

Witten, I. H., Bainbridge, D., and Nichols, D. (2009). How

to Build a Digital Library. Morgan Kaufmann.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

128
