INCENTIVES AND PERFORMANCE IN LARGE-SCALE

LEAN SOFTWARE DEVELOPMENT

An Agent-based Simulation Approach

Benjamin S. Blau, Tobias Hildenbrand, Matthias Armbruster, Martin G. Fassunge

SAP AG, Dietmar-Hopp-Allee 16, Walldorf, Germany

Yongchun Xu, Rico Knapper

Research Center for Information Technology, Haid-und-Neu-Straße 10-14, Karlsruhe, Germany

Keywords:

Lean, Agile, Agent-based simulation, Performance, Incentive.

Abstract:

The application of lean principles and agile project management techniques in the domain of large-scale soft-

ware product development has gained tremendous momentum over the last decade. However, a simple transfer

of good practices from the automotive industry combined with experiences from agile development on a team

level is not possible due to fundamental differences stemming from the particular domain speciﬁcs – i.e. differ-

ent types of products and components (material versus immaterial goods), knowledge work versus production

systems as well as established business models. Especially team empowerment and the absence of a a hier-

archical control on all levels impacts goal orientation and business optimization. In such settings, the design

of adequate incentive schemes in order to align local optimization and opportunistic behavior with the overall

strategy of the company is a crucial activity of central importance.

Following an agent-based simulation approach with reinforcement learning, we (i) address the question of how

information regarding backlog item dependencies is shared within and in between development teams on the

product level subject to different incentive schemes. We (ii) compare different incentive schemes ranging from

individual to team-based compensation. Based on our results, we are (iii) able to provide recommendations

on how to design such incentives, what their effect is, and how to chose an adequate development structure

to foster overall software product development ﬂow by means of more economic decisions and thus resulting

in a shorter time to market. For calibrating our simulation, we rely on practical experience from a very large

software company piloting and implementing lean and agile for about three years.

1 INTRODUCTION

The application of lean and agile principles in large-

scale software product development turns out as non-

trivial transition and change management endeavor in

most companies (Cohn and Ford, 2003). This is partly

due to the fact that a simple transfer of known prac-

tices from lean manufacturing in other industries can-

not be achieved due to differences between produc-

tion versus product development processes and the

nature of knowledge work and immaterial goods—

such as software (Poppendieck, 2004; Reinertsen,

2009). Especially breaking down bigger products to

an organization requiring multiple teams and hierar-

chy levels, dealing with product dependencies, and re-

integrating features and functions while keeping the

overall market and economics of decisions in mind

is yet very challenging in the relatively young soft-

ware industry (Lefﬁngwell, 2007; Larman and Vodde,

2008). As a consequence, phenomena like queued ar-

tifacts, delayed product deliveries, and long-tail risks

occur (Reinertsen, 2009).

This research aims at gaining a better understand-

ing of the information sharing and motivation me-

chanics of a complex socio-technical system, such

as a large-scale software product development orga-

nization. Based on this increased understanding, we

want to derive implications for designing the develop-

ment organization, and issue incentives for the teams

in order to foster overall software product develop-

ment ﬂow by means of more informed and economic

decisions, resulting in a shorter time to market.

S. Blau B., Hildenbrand T., Armbruster M., G. Fassunge M., Xu Y. and Knapper R..

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based Simulation Approach.

DOI: 10.5220/0003418300260037

In Proceedings of the 6th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2011), pages 26-37

ISBN: 978-989-8425-57-7

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Based on our research goal and the complex, large-

scale industrial setting (see section 5), we follow an

agent-based simulation approach with reinforcement

learning. Using this method we (i) investigate the in-

formation ﬂow in lean large-scale software product

development systems in terms of dependency reso-

lution between requirements, user stories, and other

software artifacts (cp. (Hildenbrand, 2008; Som-

merville, 2010)). In this context, incentives for indi-

viduals to share such information are of central impor-

tance. Therefore, we (ii) furthermore tackle the ques-

tion of how different types of incentive schemes im-

pact information ﬂow and the overall performance of

empowered teams. Based on our simulation results,

we (iii) provide recommendations on how to design

such incentives and how to chose an adequate devel-

opment structure within an organization. For calibrat-

ing our simulation, we rely on three years of experi-

ence from one of today’s largest lean and agile adop-

tion at SAP AG (Schnitter and Mackert, 2010).

The remainder of this paper is structured as fol-

lows: Section 2 outlines related research in the con-

text of agile and lean software development. The

agent-based simulation methodology and the corre-

sponding ﬁeld of research is analyzed in Section 3.

The basic model underlaying the empirical evalua-

tion is described in Section 4. The simulation, its

parametrization and the research hypotheses are spec-

iﬁed in detail in Section 5. Evaluation results and their

practical implications are discussed in Section 6. Sec-

tion 7 summarizes our contribution and outlines fu-

ture work.

2 RELATED WORK

In order to model and understand a complex socio-

technical system, such as a multi-level software prod-

uct development organization, the underlying design

principles and processes need to be investigated. In

this work, we speciﬁcally address the application of

lean and agile principles in large software develop-

ment companies (e.g. (Schnitter and Mackert, 2010)).

While there is mostly narrative literature on agile

principles and Scrum in large-scale enterprise envi-

ronments “driven by practitioners and consultants”

(Conboy, 2009, p. 329)—examples include (Lefﬁn-

gwell, 2007; Schwaber, 2007; Larman and Vodde,

2008; Lefﬁngwell, 2009; Larman and Vodde, 2010),

there is only little empirical evidence and rigorous re-

search in this ﬁeld. For instance, there is only little

research on the effectiveness and efﬁciency gains ac-

tually achieved by introducing lean and agile princi-

ples, Scrum-based project management etc.—in this

small set less than 2% exhibit acceptable rigor, cred-

ibility, and relevance (Dyba and Dingsoyr, 2008, p.

851), while 75% of these studies only investigated ag-

ile projects speciﬁcally applying eXtreme Program-

ming (XP, (Beck, 1999; Dingsoyr et al., 2010)).

2.1 Agile Team Practices

The vast majority of research on agile methods and

practices focuses on XP (Beck, 1999; Beck, 2000)

as team practice and applies a single or multiple case

study methodology (Yin, 2007). Single practices cru-

cial to XP have been examined separately regarding

their impact on software quality, e.g. pair program-

ming is said to consume 30% more effort than solo

programming (Cao et al., 2010), resulting in 40-90%

fewer defects (Williams et al., 2000; Erdogmus and

Williams, 2003; Cao et al., 2010). However, with re-

spect to the broad range of agile methods and their

increasing prevalence in the software industry (West

and Grant, 2010), there is only very little scientiﬁc ev-

idence so far whether or not these models lead to more

effectiveness, efﬁciency, or productivity, respectively,

in real-world large-scale development environments

(Dyba and Dingsoyr, 2008).

Among the few evidence-based behavioral sci-

ence contributions (Hevner et al., 2004) on software

agility, Lee and Xia (Lee and Xia, 2010) investigated

the impact of two major agile characteristics (team

autonomy and team diversity) on three productivity

measures: (1) on-time and (2) on-budget completion

as well as (3) functionality provided to customers.

Among their ﬁndings, it turned out that there are con-

ﬂicting goals even within the boundaries of one team.

Besides these ﬁndings, the model exhibits that the

dependent productivity variables could only be ex-

plained to a degree that leaves substantial room for

future behavioral studies.

2.2 Large-scale Lean and Agile

Lean management or lean thinking – as underlying

philosophy and common set of values – as well as lean

and agile principles are either already implemented or

piloted in many practical scenarios of different scales

today, e.g. at Salesforce (Fry and Greene, 2007) or

SAP (Schnitter and Mackert, 2010). Figure 1 visu-

alizes how speciﬁc agile software development prac-

tices, such as XP (Beck, 1999), test-driven develop-

ment (TDD, (Beck, 2003)) and agile project man-

agement methods like Scrum (Schwaber and Beedle,

2001) build upon agile principles and lean thinking

values. While the basic principles and philosophy ap-

ply to many industries, some address a speciﬁc one

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach

more concretely, e.g. Scrum and XP for the software

industry.

Based on general principles of lean manage-

ment (Poppendieck and Poppendieck, 2006) and lean

thinking as well as basic agile principles (Agile Al-

liance, 2001) and consulting experience, a set of

guiding principles and practices for scaling Scrum

to larger-scale scenarios evolved, see e.g. (Pop-

pendieck and Poppendieck, 2003; Poppendieck and

Poppendieck, 2006; Larman and Vodde, 2008; Lar-

man and Vodde, 2010). In the same vein, similar

large-scale Scrum models have been described by

Schwaber (Schwaber, 2007) and Lefﬁngwell (Leff-

ingwell, 2007). These ideas on lean management

and lean software development have been further

elaborated and translated to some practical guide-

lines based on experience from multiple consulting

projects, see e.g. (Larman and Vodde, 2010). How-

ever, lean software development in large enterprise

environments requires scaling team-based approaches

such as Scrum (see section 2.1. Nevertheless, ﬁrst

implementation concepts and pilot approaches can

be found even for very large-scale software vendors

(Schnitter and Mackert, 2010). Hence, empirical re-

search and evidence for complex socio-technical sys-

tem in the software industry is even more scarce than

for team practices (cp. section 2.2 and (Dyba and

Dingsoyr, 2008)).

Lean and agile software development is based on

lean enterprise characteristics comprising focus on

value, synchronization, transparency, and perfection

as well as Just-in-Time (JIT) principles such as (one-

piece) ﬂow, takted development, customer pull, and

zero defects (Reinertsen, 2009).

Agile Lean

Team

empowerement

TAKT

Build to test

Prioritized

backlog

Customer

involvement

Team-based

100% quality

first time

Process view

CIP structure

Respect for

real life

experience

Inside out

Value/waste

Figure 1: Comparison and interrelation of lean and agile

principles.

Combining the lean enterprise perspective with an

agile perspective on development teams (Agile Al-

liance, 2001), leads to short iterative development cy-

cles, a uniquely prioritized backlog of requirements

and work items, direct customer involvement, as well

as tested and potentially shippable software incre-

ments.

As a common basis for further studies on ag-

ile practices, Conboy has developed a uniﬁed deﬁ-

nition and formative taxonomy of agility in informa-

tions systems development or software engineering,

respectively (Conboy, 2009, pp. 340). Such a com-

mon deﬁnition and/or taxonomy is required to link

existing and future contributions in this very interdis-

ciplinary ﬁeld of research, e.g. from information sys-

tems, computer science, organizational science, soci-

ology and psychology.

In context of lean and agile software development,

there are to-date only very few related simulation-

based contributions, e.g. using a system dynamics

approach (Cao et al., 2010). Moreover, (Petersen and

Wohlin, 2010) present potential performance indica-

tors and visualizations for ﬂow simulations (cp. also

(Reinertsen, 2009)).

3 METHODOLOGY

3.1 Simulation-based Approaches

Complementary to mere behavioral and design sci-

ence studies (Hevner et al., 2004), a simulation-based

approach allows to analyze and better understand

complex development scenarios with hundreds or

even thousands of individuals and even more artifacts

and process dependencies. Besides deduction and

induction, experimenting with simulations is consid-

ered a “third way of doing science” (Axelrod, 1997).

To analyze and optimize complex development sce-

narios, different analytical and simulation-based ap-

proaches can be considered: discrete event simu-

lations, agent-based simulation (Blau et al., 2010a;

Blau et al., 2010b), system dynamics etc. Simulating

software development processes to answer fundamen-

tal questions about agile and lean practices is, though

still scarce, rising in number (Cao et al., 2010, see).

The complexity arising from individual actions

and interactions that arise in the real world can be

explicitly modeled in agent-based simulations in sit-

uations discrete-event simulations or system dynam-

ics cannot (Siebers et al., 2010). Although being rel-

atively new, agent-based simulations gain more and

more momentum in various application areas where

the behavior of single individual actors constitute the

fundamental issues (Macal and North, 2007). An

agent-based system consists of autonomous agents

following simple behavioral rules while being a direct

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

abstraction from their real-world counterparts. Be-

ing autonomous and able to learn from their envi-

ronment, they behave proactively following their own

rule set (Siebers et al., 2010). Thus, the interaction

among the agents directly impacts the system proper-

ties (Bonabeau, 2002a).

(Siebers et al., 2010) and (North and Macal, 2007)

point out various issues where agent-based simula-

tions are well applicable. Among other reasons,

agent-based simulations can be used

• when agents are a natural representation of a sys-

tem’s participants,

• when the major factor is learning and adapting,

• when agents behave proactively, i.e. they make

strategic decisions based on past, current as well

as anticipated behavior of other agents, and

• when one important factor of a system is the rela-

tionship between the participants, i.e. agents form

and dissolve relationships with each other

Evaluating certain mechanism properties or be-

havior of participants in settings with a multitude of

variable factors, a theoretical analysis is not applica-

ble in most of the cases due to the high complexity of

the system. As a remedy, numerical simulations pro-

vide a useful tool to analyze particular properties of a

mechanism by means of randomly generated problem

sets, i.e. the variable factors are randomly generated

for multiple simulation runs. Numerical simulations

can provide insights into the general problem struc-

ture, performance aspects of the algorithm that solves

the winner determination problem, mechanism prop-

erties, and strategic behavior of participants.

Focusing on more complex settings with partici-

pants that face large strategy spaces precluding the-

oretical solutions, the methodology of agent-based

simulations has proven to be promising (Bonabeau,

2002b). In contrast to a traditional game theoretical

analysis, agent-based simulations provide means for

the evaluation of rare strategies which are more com-

plex and occur in special domains. Nevertheless, it is

crucial to design reasonable strategies as well as a rea-

sonable learning behavior and incorporate them into

software agents. Based on this notion, a lot of work

has been done in the area of agent-based simulations,

and a whole set of different strategies has been shown

to work well in many settings (Phelps, 2008).

This section has shown that following an agent-

based approach is an optimal choice to address the

research questions. The following section will intro-

duce, besides the system’s structure and further arti-

facts, the actual model taken for implementation.

4 ASSUMPTIONS & MODEL

This paper addresses large-scale business software

development organizations with several hundred or

thousands of developers. Moreover, we take a devel-

opment process based on lean management and agile

principles as a basis for our assumptions. In addition,

this section describes the basic model of our agent-

based simulation in a mathematical notation.

4.1 Work Items and Artifacts

Iteration Backlog. This backlogs contain all the

user stories (backlog items) one team has committed

to for one iteration, or sprint respectively, in Scrum.

The backlog items are permanently kept uniquely pri-

oritized by the team’s product owner (Schwaber and

Beedle, 2001).

Iteration Backlog Item. User stories are containers

for requirements and currently one of the most popu-

lar requirement modeling technique in agile methods.

”User stories are the primary currency that carries

the customer’s requirements through the value stream

into code and implementation.” (Lefﬁngwell, 2009).

They brieﬂy describe a feature from the perspective

of a certain user role, letting the team freedom in im-

plementational details. The effort of each user story

is estimated in ’story points’ instead of interpreted

as person day effort, which are oftentimes classiﬁed

into a Fibonacci-like sequence, i.e. 1,1,2,3,5,13, etc.

(Cohn, 2006).

Usable Software Increments each Iteration. At

the end of each iteration the team produces a new

software increment. This increment must be prop-

erly tested and fulﬁll other criteria in order to be

accepted by the responsible person with regard to

prior deﬁned “done” (non-functional and/or meta-

requirements) and functional “acceptance criteria”.

Agile methods aim at completing potentially ship-

pable product increments, i.e. usable software in each

iteration.

4.2 Team Process and Structure

Agile methods, such as Scrum, try to attain a trade-

off between pragmatism and discipline, i.e. avoiding

chaos on the hand and extensive bureaucracy on the

other (see ﬁgure 2).

Team Size and Skills. The team must be ”fully ca-

pable of deﬁning, developing, testing, and delivering

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach

Creative

Chaos

Efficiency

Professionalism

Chaos Bureaucracy

YesNo Pragmatism

Yes

No Process Discipline

Figure 2: Pragmatism vs. discipline.

working and tested software into the system’s base-

line” (Lefﬁngwell, 2009). Usually, such a “cross-

functional” team consists of one product owner, a

scrum master, 5-10 team members focussing on de-

velopment, quality and testing as well as other func-

tions and skills (Larman and Vodde, 2010). Teams are

typically organized around particular software com-

ponents (architectural view) or certain features (from

a customer’s perspective, see (Larman and Vodde,

2008)). In general, features and components exhibit

inherently dependent requirements, i.e. inter-team de-

pendencies. In practice, companies have a mixture

of both, feature and component teams, organized in a

matrix (see e.g. (Schnitter and Mackert, 2010)).

Inter-team Collaboration in Large Development

Organizations. In order to be able to release com-

plex and comprehensive software products, develop-

ment organizations of several hundred or even thou-

sands of developers in cross-functional teams need to

be coordinated, for which hierarchy levels need to be

introduced. In our research, we follow the large-scale

lean and agile model by Larman and Vodde (Larman

and Vodde, 2008; Larman and Vodde, 2010). This

is also the basis for the implementation with which

we calibrate our model (Schnitter and Mackert, 2010).

The mix of feature and component teams (see above)

is one of the reasons for occurring inter-team depen-

dencies, which need to be resolved for product deliv-

ery. For instance, a certain set of master data requires

multiple functional components of an enterprise re-

source planning application.

4.3 Model Parameters & Behavior

Agents & Teams. Let A

represent the set of agents

(e.g. developers and other cross-functional team

members) in team m (m and n are arbitrary teams in

the remainder of this article) with agents a

, . . . , a

such that A

= {a

, . . . , a

}. Let the agent a

be a

special agent (“team owner”) representing the Scrum

Master and the Product Owner of team m.

team’s capacity c

is determined by the number of

its agents n minus the team owner, i.e. a team A

, . . . , a

} has the capacity of c

= q − 1.

Team Backlog. Let furthermore B

denote the

backlog of team m with prioritized backlog items

, . . . , b

such that B

= {b

, . . . , b

} (b

and b

are

arbitrary backlog items in the remainder of this arti-

cle). The index l represents the priority or rank within

the backlog – i.e. the backlog item b

l−1

is the unam-

biguous antecessor of the backlog item b

Backlog Processing. It is assumed that until all

done criteria are satisﬁed, the processing of a backlog

item consumes a well-deﬁned

period of time t. The

processing function λ : B → T maps backlog items to

a processing time t ∈ T .

Backlog Dependencies. It is further assumed that

dependencies between backlog items may exist such

that the possibility to start processing a speciﬁc back-

log item depends on the successful processing and ﬁ-

nalizing of another item (all done criteria fulﬁlled).

The dependency function d : B × B → {0, 1} maps a

pair of backlog items (b

, b

) to elements 0, 1 with 0

representing independent backlog items and 1 denot-

ing that backlog item b

is dependent on item b

d(b

, b

) =

{

1 , if b

is independent of b

0 , if b

depends on b

(1)

For the sake of simplicity, it is assumed that

dependencies are not directed, i.e. if backlog items

are dependent, neither of them can be processed as

long as the dependency persists. More precisely,

this implies that if d(b

, b

) = 1 ⇒ d(b

, b

) =

1 ∧ d(b

, b

) = 0 ⇒ d(b

, b

) = 0 ∀ x ̸= y.

From a team’s perspective, it follows that there are

two designated types of dependencies, i.e. (i) intra-

team dependencies with d(b

, b

) = 1 ∧ m = n, i.e.

Our model is simpliﬁed based on the assumption that

both, Scrum Master or Product Owner, can take over team

tasks with approximately 50% of their capacity—therefore,

one full-time equivalent is accounted per team. The team

owner parameter is also applied for Area Product Owners

and Chief Product Owner depending on the level of hierar-

chy and aggregation.

As an extension of the model, the processing time

might be represented by a probability distribution.

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

0,8

1,2

1,4

1,6

1,8

Mean action fitness (across teams and agents)

Fitness of Actions Based on Individual Rewards

0,2

0,4

0,6

0 50 100 150 200 250 300 350 400 450

Mean action fitness (across teams and agents)

Sprint

Inter-team dependency resolution (INTERRES) Intra-team dependency resolution (INTRARES) No dependency resolution (NORES)

Figure 3: Mean ﬁtness across all agents and teams with individual rewards for actions inter-team dependency resolution

(INTERRES), intra-team dependency resolution (INTRARES), and no dependency resolution (NORES) (including training

phase).

within the team’s own backlog and (ii) inter-team de-

pendencies with d(b

, b

) = 1 ∧ m ̸= n, i.e. with

other teams’ backlog items.

Dependency Resolution. It is further assumed that

dependencies between backlog items need to be re-

solved during the development process. Such a res-

olution is done by investing additional time and ef-

fort for analysis, communication, coordination, and

in some cases, idle time. This means that the cost

for dependency resolution depends on three factors:

(i) The point in time during the development process

the resolution is conducted and (ii) the complexity of

the dependent backlog items which is implicitly rep-

resented by their processing time as well as (iii) the

type of dependency (intra- or inter-team dependency).

Practically this means: The earlier a dependency is

detected and the lower the item complexity is, the less

additional time is required to resolve it. The amount

of effort, i.e. the additional time to be spent for re-

solving the dependency, also depends on the type of

dependency (inter-team or intra-team). Thus, the res-

olution function r : B ×B × Θ → T (Equation 2) maps

pairs of backlog items and the point of time within the

development process to the period of time that is re-

quired for resolving their dependency (for a complete

mapping, the resolution functions returns t = 0 in case

backlog items are independent).

The resolution time at least equals the average

processing time of both items, i.e. their mean com-

plexity and is mainly determined by the constant

representing the type of dependency (intra- or inter-

dependency) and the point of time θ the resolution is

conducted.

5 SIMULATION

Thus, the evaluation is conducted by means of an

agent-based simulation based on a simple form of a

Q-Learning model (Watkins and Dayan, 1992). In

contrast to more sophisticated variants of Q-learning

models, the simulation model at hand considers mul-

tiple actions but only a single state. This reduction of

parameter complexity is done without loss of validity

and therefore simpliﬁes the calibration of the simu-

lation. Simplifying the simulation model reduces the

number of assumptions, allowing for a better general-

ization of results.

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach

0,6

0,8

1,2

1,4

1,6

Mean action fitness (across teams and agents)

Fitness of Actions Based on Individual Rewards

0,2

0,4

400 410 420 430 440 450 460 470 480 490 500

Mean action fitness (across teams and agents)

Sprint

Inter-team dependency resolution (INTERRES) Intra-team dependency resolution (INTRARES) No dependency resolution (NORES)

Figure 4: Mean ﬁtness across all agents and teams with individual rewards for actions inter-team dependency resolution

(INTERRES)(mean=0.040, std=0.008), intra-team dependency resolution (INTRARES)(mean=0.006, std=0.0004), and no

dependency resolution (NORES)(mean=1.479, std=0.012) (convergence phase).

r(b

, b

, θ) =











0 , if d(b

, b

) = 0

intra

p(b

)+p(b

)

, if d(b

, b

) = 1 ∧ m = n

inter

p(b

)+p(b

)

, if d(b

, b

) = 1 ∧ m ̸= n

(2)

5.1 Rounds

Reﬂecting the lean principles, simulation rounds Ω

are mapped onto development “takts” (or “sprints” in

Scrum (Schwaber and Beedle, 2001)). Each round

represents a development takt that is further dis-

cretized into a ﬁxed number of takt units ω

5.2 Actions

At the beginning of each TAKT, each agent chooses

an action k out of the action space K as speciﬁed in

Section 5.3. The following actions are available to

each agent:

Preceding Intra-team Dependency Resolution.

The agent focuses on resolving dependencies

between backlog items within its team at the

For the sake of simplicity, all time-related model values

are discretized accordingly.

beginning of the development takt (preceding). If

there is capacity left after this action, the agent

continues with processing backlog items.

Preceding Inter-team Dependency Resolution.

The agent targets the resolution of dependencies

between backlog items that are planned in dif-

ferent teams at the beginning of the development

takt (preceding). If there is capacity left after

this action, the agent continues with processing

backlog items.

Development without Early Dependency Resoluti-

on.

No resolution of dependencies at the beginning of

the development takt are addressed by the agent,

i.e. the agent directly starts with backlog item

processing. However, when processing a backlog

item that is constrained by a dependency, the

agent is forced to resolve this dependency at that

point in time which might be time consuming due

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

to the elapsed time (cp. Section 4.3).

Having chosen, the agents execute the particular

action which binds their capacity according to the de-

ﬁned time requirements. In case of dependency reso-

lution actions (k = 1, 2) the capacity is bound exactly

as long as the resolution function speciﬁes the number

of TAKT units required. If this period of time is less

than the total units within a TAKT, the agent’s capac-

ity is free for development activities. In case of the

development action (k = 3), the agent is processing

backlog items during the whole TAKT.

5.3 Feedback & Learning Behavior

At the end of each TAKT Ω, each agent a receives a

feedback π

Ω

a,k

as a response to the action k chosen at

the beginning of the TAKT.

To analyze the effect of different incentive

schemes on the exchange of information within and

between teams, we examine three feedback mecha-

nisms:

Individual incentives that reward value creation of

the individual developer, i.e. the number of suc-

cessfully processed backlog items by a single de-

veloper.

Team incentives that reward each individual based

on the value creation of the whole team the devel-

oper belongs to, i.e. the number of successfully

processed backlog items accumulated on team-

level.

At the end of each takt Ω, the feedback to a cho-

sen action k of an agent a is incorporated in the

agent’s private ﬁtness function f

Ω

a,k

. Balancing past

and present experiences, the learning parameter β ∈

[0, 1] determines to which degree past and present

feedback is incorporated into the ﬁtness update. Thus,

the ﬁtness update evolves as follows:

Ω

a,k

:= β f

Ω−1

a,k

+ (1 − β)π

Ω

a,k

(3)

Thus, each agent maintains a ﬁtness value for each

possible action that represents the historical “success”

of that particular action based on the cumulated feed-

back over time.

At the beginning of each TAKT Ω, each agent a

chooses an action k out of the action space K (cp. Sec-

tion 5.2) based on its particular probability p

Ω

a,k

that is

based on its ﬁtness value and therefore on its histori-

cal “success”:

Ω

a,k

Ω

a,k

∑

Ω

a,k

(4)

5.4 Parametrization & Hypothesis

The simulation model as described previously is pa-

rameterized as follows: According to lean develop-

ment best practices, the team size is set to 10 agents

per team. A learning rate β = 0.5 yields an optimal

trade-off between escaping local optima and achiev-

ing a quick convergence of strategies. The ﬁrst 400

rounds of 500 rounds in total are the simulation’s

training phase in order to achieve a converged state

and are therefore not considered for the statistical

evaluation. As the number of variable parameters

and their interdependencies are high, heavy statisti-

cal noise is likely to be generated. To counteract the

high volatility of the simulation model, a large num-

ber of 500 problem sets is evaluated and the mean re-

sults across all agents and teams are reported. The

large size of analyzed problem sets for each observa-

tion assures robustness of the t-test to violations of the

normality assumption (Sawilowsky and Blair, 1992).

By means of this agent-based simulation approach

we intent to verify the hypotheses outlined in Table 1.

Table 1: Incentive schemes and corresponding hypothe-

ses. NORES denotes the mean ﬁtness value of action k = 1

across all agents and teams. INTRARES denotes the mean

ﬁtness value of action k = 2 across all agents and teams.

INTERRES denotes the mean ﬁtness value of action k = 3

across all agents and teams.

Incentive Hypothesis

Scheme

Individual H1a: (NORES > INTRARES)

Incentives H1b: (NORES > INTERRES)

H1c: (INTERRES > INTRARES)

Team H2a: (NORES < INTERRES)

Incentives H2b: (INTERRES > INTRARES)

The set of hypotheses is derived from existing lit-

erature on the effect of incentives in lean development

(Poppendieck, 2004) and practical experiences from

lean projects in SAP. In settings with individual incen-

tives that reward agents solely on the number of back-

log items that are successfully processed on their own,

the agents are likely to follow an opportunistic strat-

egy, i.e. they focus on processing backlog items in-

stead of resolving dependencies (neither within their

team nor between teams) as stated in hypotheses H1a

and H1b. Resolving inter-team dependencies at a later

point in time is more time consuming than intra-team

dependencies which is likely to incentivize agents to

prefer the INTERRES strategy over the INTRARES

strategy at the beginning of each sprint. This argu-

mentation holds for either incentive scheme (cp. hy-

potheses H1c and H2b).

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach

On the other hand, team incentives that reward

agents based on the total number of successfully pro-

cessed backlog items of the whole team are likely

to implement incentives for agents to follow actions

which are beneﬁcial for the team itself. As the effort

to resolve backlog item dependencies at a later point

in time is exponentially higher than at the beginning

of the sprint, agents are likely to follow an early de-

pendency resolution (cp. hypotheses H2a).

The statistical signiﬁcance of the stated hypoth-

esis is tested using a one-tailed matched-pairs t-test

analyzing the alternative hypothesis, that is, the mean

difference of the actions’ ﬁtness values is greater than

zero. For the statistical analysis, the ﬁrst 400 simu-

lation rounds/sprints are skipped as they serve as the

initial learning phase of the agents until we observe a

convergence of strategies and achieve a stable state.

6 EVALUATION RESULTS &

IMPLICATIONS

This sections describes the main ﬁndings of the agent-

based simulation for the individual and team incentive

schemes. Having been analyzed by means of a sensi-

tivity analysis, the observations are robust against the

simulation parameters “number of agents per team“,

“number of teams“, and “learning rate“.

6.1 Individual Incentives

Simulation settings with the individual incentive

scheme yield the following results:

• The action no dependency resolution (NORES)

signiﬁcantly (p << 0.01) yields the highest over-

all mean ﬁtness across all agents and teams which

supports Hypothesis H1a and H1b.

• The action inter-team dependency resolution (IN-

TERRES) yields a signiﬁcantly (p << 0.01)

higher mean ﬁtness across all agents and teams

than the action intra-team dependency resolution

(INTRARES) which supports Hypothesis H1c.

In a setting with the individual incentive scheme,

Figure 3 depicts the mean ﬁtness across all agents and

teams for each action. The convergence phase that

is relevant for the statistical analysis is depicts sepa-

rately in Figure 4.

6.2 Team Incentives

In settings where agents are rewarded based on the to-

tal number of successfully processed backlog items of

the whole team, the following results can be observed:

• The action inter-team dependency resolution (IN-

TERRES) is strictly dominating the action no de-

pendency resolution (p << 0.01) which supports

hypothesis H2a.

• The action intra-team dependency resolution (IN-

TRARES) is signiﬁcantly (p << 0.01) outper-

formed by the action inter-team dependency res-

olution (INTERRES) which supports hypothesis

H2b.

Figure 5 illustrates the actions’ mean ﬁtness

across all agents and teams based on the team incen-

tive scheme in a setting with 5 teams consisting of

10 team members. The ﬁgure shows all simulation

rounds including the training phase whereas Figure 6

depicts rounds 400-500 that are relevant for the statis-

tical analysis.

6.3 Practical Implications

In our work, we analyzed the effect of organiza-

tional settings and incentive schemes in large-scale

lean software development on the information ﬂow

within and between teams as well as performance as-

pects.

Our analysis has shown that individual rewards

foster opportunistic behavior in teams, i.e. actions

that serve the team by resolving backlog item depen-

dencies and removing impediments are not conducted

by the agents. On the other hand, a team incentive

scheme that rewards agents based on the total number

of successfully processed backlog items of the whole

team promote behavior that is beneﬁcial for the whole

team. As the effort to resolve backlog item dependen-

cies at a later point in time is exponentially higher

than at the beginning of the sprint, agents follow an

early dependency resolution. More precisely, resolv-

ing inter-team dependencies at a later point in time is

more time consuming than intra-team dependencies

which incentivizes agents to prefer a dependency res-

olution across team boundaries. In general, our results

underline the importance of dependency resolution—

and therefore, traceability and requirements manage-

ment, in large software organizations (Hildenbrand,

2008).

One of the basic principles of the lean method-

ology states the empowerment of the teams instead

of enforcing a strictly governed process corset (Lee

and Xia, 2010). As a trade-off, this implies that man-

agerial monitoring and steering of the development

process becomes cumbersome. Therefore, traditional

methodologies and tools stemming from well-known

project management techniques are partly not appli-

cable in agile environments, which requires new ap-

proaches to manage a successful execution of lean

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

Mean action fitness (across teams and agents)

Fitness of Actions Based on Team Rewards

0 50 100 150 200 250 300 350 400 450

Mean action fitness (across teams and agents)

Sprint

Inter-team dependency resolution (INTERRES) Intra-team dependency resolution (INTRARES) No dependency resolution (NORES)

Figure 5: Mean ﬁtness across all agents and teams with team rewards for actions inter-team dependency resolution (INTER-

RES), intra-team dependency resolution (INTRARES), and no dependency resolution (NORES) (including training phase).

projects.

Moreover, our work has shown that a sensible and

efﬁcient design of incentive schemes in large-scale

lean software development is a promising tool to steer

individual behavior, diminish opportunism and local

optimization, foster efﬁcient communication across

team boundaries, and break silos that clash with the

company’s overall objectives. Hence, our results in-

dicate that team-based rewarding can prevent oppor-

tunistic behavior and silo thinking which is in line

with recent literature (Poppendieck, 2004).

7 SUMMARY OF FINDINGS &

CONCLUSIONS

The contribution of our work comprehends the fol-

lowing ﬁndings:

• Incentive schemes play a central role for steer-

ing large-scale lean software development and to

align individual and company objectives.

• In such complex environments, agent-based simu-

lations are a promising method to evaluate differ-

ent incentive designs and derive practical implica-

tions.

• Rewards based on individual performance advo-

cate selﬁsh behavior of team members, i.e. each

individual focuses on silo work instead of remov-

ing impediments and sharing information within

and between teams to resolve dependencies.

• Rewards directly tied to team-based value cre-

ation help to diminish opportunistic behavior and

implement incentives to foster backlog item de-

pendency resolution through intense communica-

tion across team boundaries.

Outlook. As future work, we will validate our sim-

ulation results more systematically with real-world

data from large-scale software enterprises implement-

ing lean and agile practices. More speciﬁcally, we

plan to analyze existing backlogs, log ﬁles, and other

documentation of work practices as well as conduct

qualitative interviews with a certain number of teams

from different product areas. In doing, so we intend to

(a) further elaborate the external validity of our simu-

lation results and (b) gain more insights regarding the

industrial context of our research questions.

Furthermore, we intend to investigate more so-

phisticated incentive schemes and their composition

into hybrid patterns. We also plan to extend our

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach

11,3

11,5

11,7

11,9

12,1

12,3

12,5

Mean action fitness (across teams and agents)

Fitness of Actions Based on Team Rewards

10,5

10,7

10,9

11,1

400 410 420 430 440 450 460 470 480 490 500

Mean action fitness (across teams and agents)

Sprint

Inter-team dependency resolution (INTERRES) Intra-team dependency resolution (INTRARES) No dependency resolution (NORES)

Figure 6: Mean ﬁtness across all agents and teams with team rewards for actions inter-team dependency resolution (INTER-

RES)(mean=12.0, std=0.087), intra-team dependency resolution (INTRARES)(mean=11.098, std=0.068), and no dependency

resolution (NORES)(mean=11.894, std=0.090) (convergence phase).

model regarding hierarchical organizational settings

and implications of distributed teams with communi-

cation barriers. Questions like how different incentive

schemes can be grouped and assessed regarding their

applicability and suitability in different organizational

settings need to be further investigated. From an eco-

nomic perspective, we plan to extend the underlying

model to capture partly irrational behavior and to vary

the feedback quality in terms of timeliness and signal

noise.

REFERENCES

Agile Alliance (2001). Agile Manifesto.

Axelrod, R. (1997). Advancing the art of simulation in the

social sciences. Complex., 3:16–22.

Beck, K. (1999). Embracing change with extreme program-

ming. IEEE Computer, 32:pp. 70–77.

Beck, K. (2000). Extreme Programming Explained: Em-

brace Change. Addison-Wesley.

Beck, K. (2003). Test-Driven Development: By Example.

Addison-Wesley.

Blau, B., Conte, T., van Dinther, C., and Weinhardt, C.

(2010a). A Multidimensional Procurement Auction

for Trading Composite Services. Electronic Com-

merce Research and Applications Elsevier Journal.

Special Issue on Emerging Economic, Strategic and

Technical Issues in Online Auctions and Electronic

Market Mechanisms, 9(5):460 – 472. Special Section

on Strategy, Economics and Electronic Commerce.

Blau, B., Conte, T., and Weinhardt, C. (2010b). Incen-

tives in Service Value Networks – On Truthfulness,

Sustainability, and Interoperability. In Proceedings of

the International Conference on Information Systems,

Saint Louis, Missouri, USA.

Bonabeau, E. (2002a). Agent-based modeling: Methods

and techniques for simulating human systems. In Pro-

ceedings of the National Academy of Science of the

USA.

Bonabeau, E. (2002b). Agent-Based Modeling: Meth-

ods And Techniques for Simulating Human Systems.

In National Academy of Sciences, volume 99, pages

7280–7287. National Acad Sciences.

Cao, L., Ramesh, B., and Abdel-Hamid, T. (2010). Mod-

eling dynamics in agile software development. ACM

Trans. Manage. Inf. Syst., 1:5:1–5:26.

Cohn, M. (2006). Agile estimating and planning. Prentice

Hall.

Cohn, M. and Ford, D. (2003). Introducing an agile process

to an organization [software development]. Computer,

36(6):74–78.

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

Conboy, K. (2009). Agility from ﬁrst principles: Recon-

structing the concept of agility in information sys-

tems development. Information Systems Research,

20(3):329–354.

Dingsoyr, T., Dyb

a, T., and M., B. (2010). Agile Software

Development: Current Research and Future Direc-

tions. Springer.

Dyba, T. and Dingsoyr, T. (2008). Empirical studies of agile

software development: A systematic review. Informa-

tion and Software Technology, 50(9-10):pp. 833–859.

Erdogmus, H. and Williams, L. (2003). The economics of

software development by pair programmers. Engin.

Econom, 48:283–319.

Fry, C. and Greene, S. (2007). Large scale agile transfor-

mation in an on-demand world. In Proceedings of the

AGILE Conference 2010, pages pp. 136 – 142.

Hevner, A., March, S., Park, J., and Ram, S. (2004). Design

science information systems research. MIS Quarterly,

28(1):75–105.

Hildenbrand, T. (2008). Improving Traceability in

Distributed Collaborative Software Development—A

Design-Science Approach. Phd thesis, University of

Mannheim, Germany, Frankfurt, Germany.

Larman, C. and Vodde, B. (2008). Scaling Lean and Agile

Development: Thinking and Organizational Tools for

Large-Scale Scrum. Addison-Wesley Longman.

Larman, C. and Vodde, B. (2010). Practices for Scal-

ing Lean and Agile Development: Large, Multisite,

and Offshore Product Development with Large-Scale

Scrum. Addison-Wesley Longman.

Lee, G. and Xia, W. (2010). Toward agile: An integrated

analysis of quantitative and qualitative ﬁeld data. MIS

Quarterly, 34(1):pp.87–114.

Lefﬁngwell, D. (2007). Scaling software agility: best prac-

tices for large enterprises. Addison-Wesley.

Lefﬁngwell, D. (2009). The big picture of enterprise agility

by dean. Whitepaper, pages 1–16.

Macal, C. M. and North, M. J. (2007). Agent-based model-

ing and simulation: desktop abms. In Proceedings of

the 39th conference on Winter simulation: 40 years!

The best is yet to come, WSC ’07, pages 95–106, Pis-

cataway, NJ, USA. IEEE Press.

North, M. J. and Macal, C. M. (2007). Managing Busi-

ness Complexity: Discovering Strategic Solutions

with Agent-Based Modeling and Simulation. Oxford

University Press, Inc., New York, NY, USA.

Petersen, K. and Wohlin, C. (2010). Measuring the ﬂow in

lean software development. Software - Practice and

Experience.

Phelps, S. (2008). Evolutionary Mechanism Design. PhD

thesis, University of Liverpool.

Poppendieck, M. (2004). Unjust deserts. BETTER SOFT-

WARE, pages 33–47.

Poppendieck, M. and Poppendieck, T. (2003). Lean soft-

ware development: an agile toolkit. Addison-Wesley

Professional.

Poppendieck, M. and Poppendieck, T. (2006). Imple-

menting Lean Software Development: From Con-

cept to Cash. The Addison-Wesley Signature Series.

Addison-Wesley Professional.

Reinertsen, D. G. (2009). The Principles of Product De-

velopment Flow: Second Generation Lean Product

Development. Celeritas Publishing. ISBN 978-

1935401001.

Sawilowsky, S. and Blair, R. (1992). A more realistic look

at the robustness and type II error properties of the t

test to departures from population normality. Psycho-

logical Bulletin, 111(2):352–360.

Schnitter, J. and Mackert, O. (2010). Introducing agile soft-

ware development at sap ag - change procedures and

observations in a global software company. In Pro-

ceedings of the 5th International Conference on Eval-

uation of Novel Approaches to Software Engineering

(ENASE).

Schwaber, K. (2007). The Enterprise and Scrum. Microsoft

Press.

Schwaber, K. and Beedle, M. (2001). Agile Software De-

velopment with Scrum. Prentice Hall.

Siebers, P.-O., Macal, C. M., Garnett, J., Buxton, D., and

Pidd, M. (2010). Discrete-event simulation is dead,

long live agent-based simulation! J. Simulation,

4(3):204–210.

Sommerville, I. (2010). Software Engineering. Addison-

Wesley Longman, 9th edition edition. ISBN-13: 978-

0137053469.

Watkins, C. and Dayan, P. (1992). Q-Learning. Machine

learning, 8(3):279–292.

West, D. and Grant, T. (2010). Agile development: Main-

stream adoption has changed agility. Technical report,

Forrester Research.

Williams, L., Kessler, R. R., Cunningham, W., and Jeffries,

R. (2000). Strengthening the case for pair program-

ming. IEEE Softw., 17:19–25.

Yin, R. K. (2007). Case study research: Design and meth-

ods. Sage Publications.

INCENTIVES AND PERFORMANCE IN LARGE-SCALE LEAN SOFTWARE DEVELOPMENT - An Agent-based

Simulation Approach
