A CRITICAL COMPARISON OF EXISTING SOFTWARE

CONTRACT TOOLS

Janina Voigt, Warwick Irwin and Neville Churcher

Department of Computer Science and Software Engineering, University of Canterbury, Christchurch, New Zealand

Keywords:

Software contracts, Design by contract, Formal software speciﬁcation.

Abstract:

The idea of using contracts to specify interfaces and interactions between software components was proposed

several decades ago. Since then, a number of tools providing support for software contracts have been devel-

oped. In this paper, we explore eleven such technologies to investigate their approach to various aspects of

software contracts. We present the similarities as well as the areas of signiﬁcant disagreement and highlight

the shortcomings of existing technologies. We conclude that the large variety of approaches to even some

basic concepts of software contracts indicate a lack of maturity in the ﬁeld and the need for more research.

1 INTRODUCTION

When writing software, we aim to create programs

which not only work correctly, but are also reliable,

easy to use, understand and maintain. These and other

factors combine to determine the level of quality in

software.

Developing high quality software is a difﬁcult,

complex and time-consuming task. The sheer size and

complexity of software contribute to these difﬁculties;

it is not unusual for a single program to contain mil-

lions of lines of code, far too much for one person to

understand. To manage this size and complexity, we

break large systems into smaller components which

can be developed independently. A developer work-

ing on one component does not need to know the in-

ternal details of other components of the system; he or

she only needs to understand the other components’

interfaces in order to use their services.

Software contracts (a subﬁeld of formal speciﬁca-

tions) are used to explicitly deﬁne the interfaces of

software components, specifying the responsibilities

of both the client using a service and the supplier of

the service. This formalises the interactions between

components of the software and ensures that two com-

ponents interact correctly (Meyer, 1997).

When software contracts are not used, clients of

a service usually have access to information about

the service’s interface, including method signatures,

as well as, optionally, documentation about how to

use the service. Software contracts elaborate on this

by formally specifying protocols of interaction which

otherwise may have remained implicit. Consequently,

we regard contracts as a natural extension of explicit

type systems; they specify interfaces fully rather than

just specifying signatures.

We believe that software contracts can mitigate

some of the problems surrounding large scale soft-

ware development. They not only improve the cor-

rectness of software by explicitly specifying interac-

tion protocols, but also serve as documentation and

clarify correct use of inheritance (Meyer, 1997).

Further, formal speciﬁcations such as software

contracts “represent a signiﬁcant opportunity for test-

ing because they precisely describe what functions the

software is supposed to provide in a form that can eas-

ily be manipulated” (Offutt et al., 1999, page 119).

In particular, software contracts describe valid inputs

and outputs to methods; this information can be used

by automatic testing tools to ﬁnd valid test inputs and

decide if particular test outputs are correct.

Despite the fact that the main ideas of software

contracts were proposed several decades ago, they are

still not commonly used in mainstream software de-

velopment. Meyer remarks that

In relations between people and companies, a

contract is a written document that serves to

clarify the terms of a relationship. It is really

surprising that in software, where precision is

so important and ambiguity so risky, this idea

has taken so long to impose itself. (Meyer,

1997, page 342)

However, more recently several different tech-

Voigt J., Irwin W. and Churcher N..

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS.

DOI: 10.5220/0003421200380047

In Proceedings of the 6th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2011), pages 38-47

ISBN: 978-989-8425-57-7

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

nologies supporting software contracts have been de-

veloped, including tools for mainstream program-

ming platforms such as Java and .NET. Along with

these technologies, a number of supporting tools are

emerging. Testing tools such as AutoTest for Eiffel

(Meyer et al., 2007) and Pex for .NET (Barnett et al.,

2009; Tillmann and Halleux, 2008) automatically ex-

tract unit tests from contracts without the need for in-

put from developers. Static analysers such as Boogie

for the .NET contract language Spec# (Barnett et al.,

2006) and ESC/Java for the Java contract language

JML (Flanagan et al., 2002) attempt to prove the cor-

rectness of software at compile-time.

As more technologies supporting software con-

tracts emerge and their usage becomes more common,

it is important for us to take stock of current develop-

ments and uncover any issues and areas of disagree-

ment which need to be addressed in the future. This

is what we attempt to do in this paper, as part of a

wider project in which we seek both to strengthen the

theoretical underpinnings of contracts and to develop

tools to support the adoption of contracts in modern

software engineering environments.

The rest of this paper is structured as follows: Sec-

tion 2 explains the background of software contracts.

Section 3 presents a comparison of several contract

technologies, highlighting the similarities and differ-

ences. A discussion of the issues and criticisms of

existing approaches follows in Section 4 before we

present our conclusions in Section 5.

2 BACKGROUND

The roots of software contracts run very deep in the

ﬁeld of computer science; although it has been little

recognised in the literature, the origins of the idea can

be traced as far back as Turing, who ﬁrst presented

the idea of assertions to check program correctness in

1949 (Turing, 1949).

In 1969, Hoare introduced Hoare triples. He used

the notation P{Q}R to mean that “If the assertion P is

true before initiation of a program Q, then the asser-

tion R will be true on its completion” (Hoare, 1969,

p. 577); P is commonly called the precondition, while

R is the postcondition. Three years later, Hoare also

presented the concept of the class invariant, a logical

predicate I where “each operation (except initialisa-

tion) may assume I is true when it is ﬁrst entered; and

each operation must in return ensure that it is true on

completion” (Hoare, 1972, p. 275).

In the late 1980s, Meyer applied Hoare’s work

in his development of Design by Contract

T M

and

the programming language EIFFEL which included

the concepts of preconditions, postconditions and

class invariants (Meyer, 1989). Preconditions spec-

ify what the client must ensure before calling the ser-

vice provider; this could for example include ensur-

ing that the parameters are not null. Postconditions

deﬁne what the service provider promises in return,

given that the client has fulﬁlled the preconditions.

As an example, we deﬁne the contract for a sim-

ple Stack class with the three standard methods

push(Object obj), peek() and pop():

class Stack {

private Object[] stack;

private static final int MAX_SIZE = 100;

private int size;

Invariant: size >= 0 && size <= MAX_SIZE;

public Stack() {

stack = new Object[MAX_SIZE];

size = 0;

}

Precondition: !isFull()

Postcondition: peek() == obj

&& size == old size + 1

public void push(Object obj){

stack[size++] = obj;

}

Precondition: !isEmpty()

Postcondition: size == old size

public Object peek(){

return stack[size-1];

}

Precondition: !isEmpty()

Postcondition: size == old size - 1

public Object pop() {

return stack[--size];

}

public boolean isFull(){

return size >= MAX_SIZE;

}

public boolean isEmpty(){

return size <= 0;

}

Our Stack class uses a simple Object array to

store its values. It keeps track of the current Stack

size and also knows the maximum number of items it

can store.

We have deﬁned preconditions and postconditions

for push, pop and peek. The preconditions for pop

and peek ensure that the methods are not called when

the Stack is empty; the precondition for push makes

sure the method is not called if the Stack is already

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS

full. These preconditions call the query methods

isEmpty and isFull in their deﬁnitions instead of

referring directly to the private size ﬁeld. Since pre-

conditions are the client’s responsibility, they must

be deﬁned in such a way that the client can check

them before calling a method; that is, their deﬁnition

should only include members which are accessible to

the client (Meyer, 1989; F

ahndrich et al., 2010). The

isEmpty and isFull methods therefore need to be

public.

The postconditions of the three methods check

that the size of the Stack has changed in the correct

way by comparing it to the old size of the Stack;

that is, the size before the method’s execution. Us-

ing old values is a common occurrence in contracts

and therefore contract speciﬁcation languages usually

provide syntax for doing so. Calling the push method

increases the size of the Stack by one; calling pop de-

creases it by one; calling peek should have no effect

on the size. Unlike the preconditions, the postcondi-

tions access the size ﬁeld directly and do not make

use of query methods. This does not cause any prob-

lems here because postconditions are the responsibil-

ity of the service supplier; that is, the Stack itself.

They do not need to be checked by outside clients and

can therefore refer to the private details of the Stack.

The invariant of the Stack ensures that its size

never drops below zero or exceeds the array’s capac-

ity. This invariant must be satisﬁed in all observ-

able states of every instance of a class (Meyer, 1989).

Speciﬁcally, the class invariant must be true after the

constructor has ﬁnished constructing a class instance

and before and after each call to an exported method

of the class; that is, a method accessible from outside

the class. This implies that while methods of the class

are executing, they may violate the class invariant, as

long as it is again satisﬁed when the method returns

(Meyer, 1997).

Software contracts also apply in the presence of

inheritance, through the concept of subcontracting

(Meyer, 1997); that is, the original contractor engages

a subcontractor for part of or all of the work. For this

to work, the subcontractor “must be willing to do the

job originally requested, or better than requested, but

not less” (Meyer, 1997, page 576).

Inheritance allows substitution of a subtype in

place of an expected type. This means, for example,

that a method expecting an object of type A may be

given an object of type B as long a B inherits from

A. Whenever a client makes use of a supplier, it does

not need to know whether the supplier is an imme-

diate instance of the speciﬁed type or an instance of

some subtype. Therefore, for contracting to continue

to work, the subclass must adhere to the contract spec-

iﬁed by the superclass (Meyer, 1989). This means that

• Preconditions must be the same or weaker than in

the superclass. The subclass cannot expect more

of the client, although it may expect less;

• Postconditions must be the same or stronger than

in the superclass. The client expects certain re-

sults which must be delivered by the subclass. In

addition, the subclass may choose to deliver more

than promised by the superclass; and

• Class invariants are inherited from the superclass.

The subclass may introduce additional class in-

variants (Meyer, 1997).

In the next section, we present several different

contract technologies and contrast their approaches

to the implementation and interpretation of software

contracts.

3 CONTRACT TECHNOLOGIES

We investigated a number of technologies and pro-

gramming languages which allow the addition of soft-

ware contracts to programs, with a particular focus on

the following eleven:

• Java contract tools, including

– JAVA MODELING LANGUAGE (JML) (Leav-

ens et al., 2006; Leavens et al., 2005; Leavens

and Cheon, 2006);

– ICONTRACT (Kramer, 1998);

– CONTRACT JAVA (Findler and Felleisen,

2000);

– HANDSHAKE (Duncan and Hoelzle, 1998);

– JASS (Bartetzko et al., 2001);

– JCONTRACTOR (Karaorman and Abercrombie,

2005; Karaorman et al., 1999); and

– JMSASSERT (Man Machine Systems, 2009).

• .NET contract languages, including

– SPEC# (Barnett et al., 2004b; Leino and Mon-

ahan, 2008); and

– CODE CONTRACTS (F

ahndrich et al., 2010;

Microsoft Corporation, 2010).

• EIFFEL (Meyer, 1989; Meyer, 1992; Meyer,

1997); and

• OBJECT CONSTRAINT LANGUAGE (OCL) (Ob-

ject Management Group, 2010; Warmer and

Kleppe, 2003)

The large number of existing software contract

tools made it impractical to consider all of them and

we therefore focused our investigation on the main

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

technologies which add contract support to the pop-

ular programming platforms Java and .NET. In addi-

tion, we looked at Eiffel, the original software con-

tract language. OCL was included because of its close

links to Java technologies such as JML.

All the tools we investigated aim to support soft-

ware contracts, most of them at the implementation

level. OCL is the only technology to work exclusively

at the software design level; it allows contracts in-

cluding preconditions and postconditions to be added

to UML diagrams, while all other tools we looked at

allow developers to augment source code using con-

tracts.

We have identiﬁed signiﬁcant differences and

shortcomings in what they deliver. Table 1 gives an

overview of the similarities and differences of the

tools. In the following section, we describe the main

characteristics of the technologies, and in the sub-

sequent section we summarise the most important

themes and highlight areas of inconsistency.

3.1 Core Contract Support

All of the technologies we looked at provide core con-

tract support, allowing the speciﬁcation of precondi-

tions, postconditions and class invariants, with the ex-

ception of CONTRACT JAVA which omits class invari-

ants.

In addition to the basic contract speciﬁca-

tions, some technologies offer additional constructs.

SPEC#, JML and JASS allow the speciﬁcation of

frame conditions. Frame conditions specify which

parts of the memory a method is allowed to mod-

ify. This ensures that a method does not unexpectedly

change the value of variables it should not be allowed

to modify (Barnett et al., 2004b; Leino and Monahan,

2008). A variable is deemed to have been modiﬁed if

it is accessible at the start and the end of a method and

its value has been changed. This means that newly

created objects and local variables are not included

in the restrictions of frame conditions (Leavens et al.,

2006).

SPEC#, CODE CONTRACTS and JML further

allow the deﬁnition of exceptional postconditions,

which specify conditions that need to be satisﬁed if

the method terminates with an exception.

Of the technologies we considered, JML provided

the most extensive contract support. Among other

constructs, it also supports history constraints which

describe how the value of a ﬁeld is allowed to change

between two publicly visible states. This can for ex-

ample be used to express that the value of a ﬁeld

may only increase (Leavens et al., 2006). JML fur-

ther introduces the concept of model ﬁelds which can

be used when the inner data representation of a class

needs to be changed but the developer does not want

to update all of the contracts to the new data format.

The model ﬁeld of the old data format can be used

from within the contracts and a correspondence is de-

ﬁned between the new data format and the model ﬁeld

(Leavens and Cheon, 2006).

3.2 Special Operators and Quantiﬁers

The different technologies also offer varying amounts

of special operators and quantiﬁers for use in con-

tracts. All allow postconditions to refer to the return

value of the method; this functionality is usually pro-

vided by the result or return operator. In addition,

all except CONTRACT JAVA and HANDSHAKE also

allow postconditions to refer to the value of a variable

before method execution, often through the old op-

erator. This is important to check that the value of a

ﬁeld is changed correctly by a method, as we did in

our Stack example above.

Most technologies also offer some quantiﬁers

such as for all and exists; no such quantiﬁers are

available in EIFFEL, but Meyer argues that they can

be easily emulated using conventional programming

language constructs (Meyer, 1989). Several tools,

including JML, SPEC#, JCONTRACTOR and OCL,

have a sophisticated range of additional operators in-

cluding quantiﬁers, counting functions and predicate

logic operators.

3.3 The Contract Language

Contract speciﬁcations for Java and .NET repre-

sent additions to an existing programming lan-

guage. Some tools, including CODE CONTRACTS

and JCONTRACTOR, specify contracts in the exist-

ing language. EIFFEL and SPEC# are both languages

which natively support contracts and thus the lan-

guage used to specify contracts is part of the wider

programming language. The advantage of this ap-

proach is that there is no need for a separate com-

piler and contracts can be processed by standard tools

along with the remainder of the program. In CODE

CONTRACTS, contracts are speciﬁed by calling the

static methods of the Contract class; for example,

preconditions are deﬁned by calling the Requires

method of the Contract class. In JCONTRACTOR,

method contracts are speciﬁed in contract methods,

using standard Java. Postcondition methods take the

additional parameter RESULT, which can be used to

refer to the return value of the method. Postcondi-

tions also have access to a special object called OLD,

which contains the state of the current object as it was

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS

Table 1: Overview of Contract Tools.

JML

iContract

Contract Java

Handshake

Jass

jContractor

JMSAssert

Spec #

Code Contracts

Eiffel

OCL

Contract Pre / Postconditions X X X X X X X X X X X

Support Class Invariant X X X X X X X X X X

Frame Conditions X X X

Exceptional Postconditions X X X

Operators Result X X X X X X X X X X X

Old X X X X X X X X X

Contract Original Language X X X X X

Language Modiﬁed Language X X X X X

Scripting Language X

Contract Comment X X X

Placement Annotation X

With Program X X X X X X X X

Separately X X X X

Method Purity Enforced X X X

Precondition Visible Members Only X X X

Invariant After Method X X X

Check Before and After X N/A X X X X N/A

Expose Block X

Invariant All Methods X

Check Non-private Methods X N/A X X N/A X N/A

Public Methods Only X X X

Contract Enforced X X X X X X X X X N/A

Inheritance Precondition Weakening X X X X X X X X N/A

Contract Preprocessor X X X

Compilation Custom Compiler X X N/A

Standard Compiler X X X

Runtime Linking X X

before the method executed (Karaorman et al., 1999).

The remaining tools we considered take a slightly

different approach: they take the original program-

ming language as a basis but augment it using addi-

tional keywords and operators. This approach is taken

by ICONTRACT, JML and others; it requires special

tools to translate the contracts into the original pro-

gramming language.

JMSASSERT takes this approach a step further by

using a full scripting language, JMScript, for con-

tract speciﬁcation. While JMScript is similar to Java,

the underlying programming language, it differs suf-

ﬁciently that developers need to learn the scripting

language before being able to write contracts, signiﬁ-

cantly steepening the learning curve.

3.4 Integration of Contracts into Source

Code

There are several ways in which contracts can be in-

corporated into source code. Some contract technolo-

gies, including JML, JASS and JMSASSERT, require

contracts to be added in the form of comments, while

in ICONTRACT they are deﬁned as annotations. The

advantage of these two approaches is that they work

when the contract language is not the same as the stan-

dard programming language; the contracts are sim-

ply ignored by the standard compiler, meaning that

no special compiler is needed when working with

contracts. Instead, the contracts are inserted into the

source code by a preprocessor and the program is then

compiled using the standard compiler.

In EIFFEL, SPEC#, CODE CONTRACTS and

JCONTRACTOR, contracts are deﬁned as an integral

part of the program and are compiled and checked by

the standard compiler. This approach works for these

technologies because the contracts are expressed in

the same language as the rest of the program.

The placement of contracts in the programs also

varies between different technologies. In most

cases, for example in JML, ICONTRACT and SPEC#,

method contracts including preconditions and post-

conditions are speciﬁed as part of the method header.

In CODE CONTRACTS, preconditions and postcondi-

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

tions are placed inside the method body along with the

method implementation. These two approaches have

the advantage of clearly showing which contracts ap-

ply to which methods.

Other technologies enforce a separation between

contracts and the code to which they apply. In HAND-

SHAKE, speciﬁcations are placed in separate contract

ﬁles (Karaorman et al., 1999); in CONTRACT JAVA

they are placed in separate interfaces (Findler and

Felleisen, 2000). This approach has the advantage

of clearly separating contracts from standard code, al-

lowing them to be considered independently of imple-

mentation. It further allows the addition of contracts

even when source code is not available, for example

when working with third party software.

JCONTRACTOR allows both of these approaches:

contract methods to deﬁne preconditions and post-

conditions may be placed in the same class as the

methods to which they apply; alternatively, they

can be deﬁned in a separate contract class named

ClassName CONTRACT, which must extend the class

to which it is adding contracts in order to inherit rele-

vant behaviour and to make the objects with contracts

substitutable for objects without contracts (Karaor-

man et al., 1999).

3.5 Side Effects in Contracts

Preconditions, postconditions and invariants should

not call methods which cause side effects since this

can create bugs which are difﬁcult to trace. Some

technologies, including SPEC# and JML, enforce

this and allow only methods which have been de-

clared free of side effects (pure methods) to be called

from within contracts. Pure methods may only call

other pure methods and may not modify any part of

the memory. For example, the two query methods

we used to deﬁne our Stack contract, isEmpty and

isFull, have no side effects and can therefore safely

be called from within a contract.

Most of the technologies do not explicitly enforce

method purity; they only recommended that no meth-

ods with side effects are called from within contracts.

CODE CONTRACTS is expected to enforce purity in

the future (Microsoft Corporation, 2010). OCL is a

modeling language and all its code is implicitly free

of side effects and thus any methods called from the

contract are guaranteed to have no side effects.

3.6 Precondition Visibility

Contract theory requires clients to ensure that pre-

conditions hold; therefore, it is important to ensure

that preconditions do not refer to any data or meth-

ods which are not visible to clients. Some contract

technologies enforce this restriction, while others do

not.

CODE CONTRACTS ensures that anything used to

deﬁne the precondition is visible to clients. JASS and

JML require anything referred to by the precondition

to be at least as visible as the method itself. Thus,

the preconditions of public methods must be deﬁned

using only publicly visible data and methods; pre-

conditions for protected methods may refer to both

public and protected items.

3.7 Checking of Class Invariants

Class invariants are constraints that need to be main-

tained in all visible states of the objects of a class; that

is they must be true at the start and the end of each

method that can be called by a client. For this rea-

son, Meyer asserts that each invariant essentially rep-

resents an additional precondition and postcondition

for each exported method in a class (Meyer, 1989).

EIFFEL, JML and JMSASSERT therefore check class

invariants at the start and end of each method execu-

tion.

However, seeing the invariant as an addition to

each method’s precondition raises a new problem:

The object invariant of class T is a condition

on the internal representation of T objects, the

details of which should be of no concern to

a client of T, the party responsible for estab-

lishing the precondition. Making clients re-

sponsible for establishing the consistency of

the internal representation is a breach of good

information hiding practices. (Barnett et al.,

2004a, page 30)

For this reason, other technologies, including

CODE CONTRACTS, ICONTRACT and JASS, check

the class invariant only at the end of method execu-

tions; that is, only in the postconditions, not the pre-

conditions.

SPEC# takes a more complex approach to invari-

ant checking. It allows changes to memory only

inside special expose blocks because such changes

could invalidate class invariants. At the start of each

expose block, the object’s invariant is set to false.

Changes to data are now allowed and at the end of the

expose block the invariant is re-checked. This pro-

tects invariants even in the presence of concurrency

and reentrancy: an expose block can only be entered

when the object’s invariant is true; that is, it can only

be entered by one thread of execution at a time (Bar-

nett et al., 2004b). While this approach has the ad-

vantage of working in the presence of concurrency, it

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS

greatly increases the complexity of writing programs

with contracts.

Apart from the disagreement over when the invari-

ant needs to be checked, there is also some debate

about which methods this check applies to. Strictly

speaking, the class invariant must be maintained in

all externally visible states but may be broken while

internal methods are executed. For example, a recur-

sive method needs to maintain the invariant only for

its outermost invocation. Private methods should be

allowed to break the invariant; only methods called by

the client should need to maintain it.

Of the technologies we considered, only JASS

checks the invariant after each method execution,

effectively forcing all methods, including private

methods, to maintain the invariant. EIFFEL, ICON-

TRACT, HANDSHAKE and JMSASSERT require all

non-private methods to maintain the invariant, while

CODE CONTRACTS, JML and JCONTRACTOR only

require public methods to do so.

Some of the Java technologies allow only

private methods to break the class invariant, while

others allow private, package and protected

methods to do so. The latter approach is problematic,

since calls to package and protected methods may

come from a different class, and therefore should be

forced to maintain the invariant. On the other hand,

this allows methods from the subclass to call methods

in the superclass while the invariant is broken, which

may provide valuable ﬂexibility.

3.8 Inheritance of Contracts

Inheritance is an important mechanism in object ori-

ented (OO) programming and consequently contract

tools need to support it. In many technologies, includ-

ing EIFFEL, ICONTRACT, JML and JCONTRACTOR,

correct contract inheritance is enforced by disjunct-

ing inherited preconditions and conjuncting inherited

postconditions; this leads to a weakening of precon-

ditions and a strengthening of postconditions and in-

variants. CODE CONTRACTS and CONTRACT JAVA

take a more restrictive approach: while postcondi-

tions and invariants may be added by subclasses, pre-

conditions must be speciﬁed completely in the super-

class; subclasses are not allowed to specify any addi-

tional preconditions. This ensures that preconditions

are not strengthened, but also makes developers un-

able to weaken them.

While almost all technologies we investigated al-

ways enforce correct use of contract inheritance, JASS

takes a more ﬂexible approach. It can check for cor-

rect inheritance using reﬁnement checks, but this is

optional and can be turned off by the developer. In

OCL, the semantics of contract inheritance are not

fully speciﬁed because it is a general purpose mod-

elling language rather than a concrete implementa-

tion.

3.9 Conversion of Contracts into

Runtime Checks

Once contracts have been written, they can be turned

into runtime checks that report whenever a contract

is violated. This conversion may be done in several

ways.

Programs written in EIFFEL, CODE CONTRACTS

and SPEC# can simply be compiled using a stan-

dard language compiler, since contracts are expressed

in the same language as the rest of the code. The

EIFFEL and SPEC# compilers insert runtime checks

for contracts during compilation; CODE CONTRACTS

uses library classes to implement contract checking.

JML and CONTRACT JAVA provide a customised

Java compiler which not only compiles the program

but also generates the runtime checks. ICONTRACT,

JASS and JMSASSERT all use a preprocessor which

inserts Java statements into the code before it is com-

piled by the standard Java compiler. This has the

advantage that the standard Java compiler can be

used after preprocessing is completed. HANDSHAKE

and JCONTRACTOR use a dynamic library and class

loader to inject runtime checks when the program is

executed, rather than at compile time.

4 DISCUSSION

In our investigation of existing software contract tech-

nologies we have found some areas of signiﬁcant dis-

agreement. The approaches of the technologies vary

widely and from Table 1 it becomes clear that no two

tools take exactly the same approach.

Interestingly, we have uncovered some relatively

basic issues which are handled inconsistently, for ex-

ample concerning the checking of class invariants.

We believe that it is important that the inconsisten-

cies are resolved - or at least justiﬁed - in order to

increase developers’ conﬁdence in contract tools and

the practice of using software contracts in general.

We found good support for core contract concepts,

including preconditions, postconditions and invari-

ants, in nearly all tools. We believe that any contract

tool which does not support these basic constructs is

inadequate for practical use. CONTRACT JAVA, for

example, does not support the speciﬁcation of class

invariants, representing a serious gap in this tool.

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

In addition to preconditions, postconditions and

class invariants, we ﬁnd the concept behind frame

conditions useful. It is often difﬁcult to know what

data is changed when calling a method, particularly if

this method calls other methods. In some cases, un-

expected data changes can be difﬁcult to trace to their

origins. Deﬁning frame conditions forces developers

to think carefully about which parts of the memory a

method should be able to access and modify. They in-

form the programmer of inappropriate memory mod-

iﬁcations, reducing the incidence of unexpected data

changes.

Some contract technologies provide a wide range

of special operators and quantiﬁers; most tools pro-

vide at least two: the result or return operator to

access the return value of a method and the old opera-

tor to refer to the value of variables before the method

execution. However, two tools, CONTRACT JAVA and

HANDSHAKE, do not provide an old operator. This

is a serious omission and severely restricts what con-

tracts can be expressed, such as the size checks in our

Stack example.

Most tools we considered here declared contracts

using the same programming language as for the rest

of the program, although many introduced small ad-

ditions in the form of operators and quantiﬁers. Only

one tool, JMSASSERT, used a signiﬁcantly different

language to deﬁne contracts. We suggest that this is

an unnecessary burden on developers and is likely to

inhibit uptake of the technology.

With the exception of CODE CONTRACTS, all of

the technologies we investigated use contract deﬁ-

nition syntax that groups contract information with

method declaration information. CODE CONTRACTS

places contracts inside the actual methods. We feel

that this approach is not ideal, since it mixes con-

tracts with implementation code and makes it difﬁ-

cult to distinguish between them. We suggest that

contracts should ideally be declared separately from

the implementation as part of a type deﬁnition. This

is consistent with existing literature, which suggests

that public interfaces, or types, should be separated

(Bruce, 2002; Canning et al., 1989); that is, the type

deﬁnition should contain signatures of visible meth-

ods, but no internal details. By extension, such a type

deﬁnition should include contracts for publicly visible

methods since, similarly to method signatures, con-

tracts provide vital information to clients wanting to

use a service.

Some tools do not allow contracts to call meth-

ods with side effects since this can create bugs which

are difﬁcult to trace; other technologies do not im-

pose this restriction. We agree with Barnett et al.,

who claim that the latter approach gives developers

too much freedom and is unsound (2004). As we ar-

gued above, it can be difﬁcult to see which parts of the

memory a method modiﬁes; similarly, it can be difﬁ-

cult to determine whether or not a method is pure, par-

ticularly when this method calls other methods, which

in turn could have side effects. This makes both frame

conditions and explicit declarations of pure methods

very useful.

Clients are responsible for ensuring that precondi-

tions are met before calling a method. We are there-

fore surprised that not more tools ensure that meth-

ods and data referred to in preconditions are visible

to clients. If this is not the case, clients may not be

able to check preconditions and may therefore fail to

fulﬁll their responsibilities under the contract. Con-

tracts are based on the idea of shared responsibility

between clients and service providers and having po-

tentially invisible preconditions violates the founda-

tion of software contracts.

In the tools we studied, we found a particularly

variable approach to invariant checking. Some tools

check invariants after each method, others before and

after; some tools require the invariant to hold at the

start and end of all methods while others only ap-

ply this restriction to public methods. In our view,

the wide range of approaches stems from the incom-

plete body of theory about this aspect of contracts. We

have found no research that explains when invariants

should be checked and what implications the different

approaches have. Given the wide range of different

approaches, we feel that this is an area where further

investigation is warranted.

Most of the technologies allow private methods to

break the invariant temporarily. This makes sense be-

cause the internal operations of an object may not al-

ways maintain the invariant at all times; however, it

needs to be restored before returning control to the

client to ensure that the object is left in a consistent

state. We therefore argue that ideally the invariant

should to be checked before and after every method

call originating from outside the object. This would

allow the object to break its own invariant temporar-

ily (possibly while calling code in the superclass) but

would also ensure that the object remains in a consis-

tent state when it returns control.

In the context of invariant checking, SPEC#’s ap-

proach is far more complex than that of any other

technology we investigated. It requires the object to

be explicitly exposed whenever its state is modiﬁed

to ensure that its invariant cannot be violated by op-

erations from the outside or through the presence of

reentrancy and concurrency. Although this approach

is sound, we argue that it is too complex; it requires

the use of complicated constructs even when writing

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS

simple programs. We believe that this complexity is

likely to alienate new users and slow the uptake of

SPEC# and software contracts in general.

Support for inheritance of contracts is essential for

their use in OO programming. We found that all the

tools with the exception of JASS ensure that contracts

are inherited correctly. JASS also allows correct con-

tract inheritance to be enforced but makes this op-

tional. We are encouraged by this high level of sup-

port for correct inheritance. Using inheritance cor-

rectly is notoriously difﬁcult and our intuition some-

times leads us to use it incorrectly. This is particularly

evident in the well-known square-rectangle problem

(Martin, 1996). Our own experience shows that con-

tracts are very valuable when creating inheritance hi-

erarchies because they force us to ensure that an in-

stance of the subclass is substitutable for an instance

of the superclass; problems with contract inheritance

usually signal incorrect use of inheritance.

Most of the tools we looked at enforce the cor-

rect use of contracts by allowing weaker precondi-

tions through disjuncting inherited preconditions and

allowing stronger postconditions through conjuncting

inherited postconditions. CODE CONTRACTS uses

this approach to ensure postconditions are strength-

ened; however, the tool does not allow the weakening

of preconditions because “We just haven’t seen any

compelling examples where weakening the precon-

dition is useful” (Microsoft Corporation, 2010, page

15). CODE CONTRACTS forces developers to declare

all preconditions on the root method of an inheritance

chain. In our work with CODE CONTRACTS, we have

found this approach very frustrating because it does

not allow for ﬂexible precondition deﬁnition. In par-

ticular, problems arise when a class inherits the same

method from multiple interfaces. In this situation, the

preconditions of this method in all ancestors must be

compatible; this is an example where we feel that al-

lowing precondition weakening is essential.

5 CONCLUSIONS

In our investigation of existing software contract tools

we have uncovered a range of differences, clearly

demonstrating a level of confusion and conﬂict sur-

rounding even some basic concepts of software con-

tracts. This indicates to us that more work is needed

in this area to resolve these issues and create a con-

sensus or at least a clear taxonomy of the different

semantics of software contracts. We have identiﬁed

a number of shortcomings of existing tools and areas

that require more research, including:

• The checking of class invariants;

• The separation of contracts and implementation;

and

• The inheritance of contracts, particularly the

weakening of preconditions.

We believe that using software contracts has the

potential to greatly increase the quality of software

and speed up software development. Not only do they

ensure that different components of a system know

how to interact with each other correctly, but they also

serve as documentation of developers’ intentions and

can be used as a basis of automated testing tools. Fur-

thermore, we believe that they are a highly valuable

tool for creating correct inheritance hierarchies.

We are currently developing our own contract

tool; having carefully studied other contract tools, we

are now aware of the major issues and questions in

the area. We plan to create a contract tool that empha-

sises:

• Rigorous separation of interface (i.e. contracts)

from implementation. This will ensure clients can

depend only on public information.

• Enhanced explicit support for inheritance and

substitutability and enforcement of correct con-

tract inheritance.

• Prevention of invalid contracts, such as precondi-

tions that cannot be tested by clients, or use of

methods with side-effects in contracts.

• Support for more ﬂexible and expressive deﬁni-

tion of contracts.

REFERENCES

Barnett, M., Chang, B.-Y. E., DeLine, R., Jacobs, B., and

Leino, K. R. M. (2006). Boogie: A modular reusable

veriﬁer for object-oriented programs. In FMCO 2005,

volume 4111 of Lecture notes in computer science.

Springer Verlag.

Barnett, M., Deline, R., F

ahndrich, M., Leino, K. R. M., and

Schulte, W. (2004a). Veriﬁcation of object-oriented

programs with invariants. Journal of Object Technol-

ogy, 3(6):27–56.

Barnett, M., F

ahndrich, M., Halleux, P. d., Logozzo, F.,

and Tillmann, N. (2009). Exploiting the synergy be-

tween automated-test-generation and programming-

by-contract. In Proceedings of ICSE 2009, 31th Inter-

national Conference on Software Engineering, Com-

panion, pages 401–402.

Barnett, M., Leino, K. R. M., and Schulte, W. (2004b). The

Spec # programming system: an overview. In CAS-

SIS 2004, volume 3362 of Lecture notes in computer

science. Springer Verlag.

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

Barnett, M., Naumann, D., Schulte, W., and Sun, Q.

(2004c). 99.44% pure: useful abstractions in speci-

ﬁcations. In ECOOP workshop on Formal Techniques

for Java-like Programs (FTfJP) 2004.

Bartetzko, D., Fischer, C., M

oller, M., and Wehrheim, H.

(2001). Jass - Java with assertions. Electronic Notes

in Theoretical Computer Science, 55(2).

Bruce, K. B. (2002). Foundations of object-oriented lan-

guages: types and semantics. MIT Press, Cambridge,

MA, USA.

Canning, P. S., Cook, W. R., Hill, W. L., and Olthoff, W. G.

(1989). Interfaces for strongly-typed object-oriented

programming. In OOPSLA ’89: Conference proceed-

ings on Object-oriented programming systems, lan-

guages and applications, pages 457–467, New York,

NY, USA. ACM.

Duncan, A. and Hoelzle, U. (1998). Adding contracts to

Java with Handshake. Technical Report TRCS98-32,

University of California at Santa Barbara, Santa Bar-

bara, CA, USA.

ahndrich, M., Barnett, M., and Logozzo, F. (2010). Em-

bedded contract languages. In SAC ’10: Proceedings

of the 2010 ACM Symposium on Applied Computing,

pages 2103–2110, New York, NY, USA. ACM.

Findler, R. and Felleisen, M. (2000). Behavioral interface

contracts for Java. Technical Report TR00-366, Rice

University.

Flanagan, C., Leino, K. R. M., Lillibridge, M., Nelson, G.,

Saxe, J. B., and Stata, R. (2002). Extended static

checking for Java. In PLDI ’02: Proceedings of the

ACM SIGPLAN 2002 Conference on Programming

language design and implementation, pages 234–245,

New York, NY, USA. ACM.

Hoare, C. A. R. (1969). An axiomatic basis for com-

puter programming. Communications of the ACM,

12(10):576–580.

Hoare, C. A. R. (1972). Proof of correctness of data repre-

sentations. Acta Informatica, 1(4):271 – 281.

Karaorman, M. and Abercrombie, P. (2005). jContractor:

Introducing design-by-contract to Java using reﬂective

bytecode instrumentation. Formal Methods in System

Design, 27(3):275–312.

Karaorman, M., H

olzle, U., and Bruno, J. L. (1999). jCon-

tractor: A reﬂective Java library to support design by

contract. In Reﬂection ’99: Proceedings of the Sec-

ond International Conference on Meta-Level Archi-

tectures and Reﬂection, pages 175–196, London, UK.

Springer-Verlag.

Kramer, R. (1998). iContract - the Java(tm) design by con-

tract(tm) tool. In TOOLS ’98: Proceedings of the

Technology of Object-Oriented Languages and Sys-

tems, page 295, Washington, DC, USA. IEEE Com-

puter Society.

Leavens, G., Baker, A., and Ruby, C. (2006). Preliminary

design of JML: a behavioral interface speciﬁcation

language for Java. SIGSOFT Software Engineering

Notes, 31(3):1–38.

Leavens, G. and Cheon, Y. (2006). Design by contract with

JML.

Leavens, G., Cheon, Y., Clifton, C., Ruby, C., and Cok, D.

(2005). How the design of JML accommodates both

runtime assertion checking and formal veriﬁcation.

Science of Computer Programming, 55(1-3):185–208.

Leino, K. R. M. and Monahan, R. (2008). Pro-

gram veriﬁcation using the Spec # program-

ming system. http://research.microsoft.com/en-

us/projects/specsharp/etaps-specsharp-tutorial.ppt.

Man Machine Systems (2009). Design

by contract for Java using JMSAssert.

http://www.mmsindia.com/DBCForJava.html.

Martin, R. (1996). The Liskov Substitution Principle. C++

Report, 8(3):16 – 17, 20 – 23.

Meyer, B. (1989). Writing correct software. Dr. Dobb’s

Journal, 14(12):48–60.

Meyer, B. (1992). Applying “design by contract”. Com-

puter, 25(10):40–51.

Meyer, B. (1997). Object-oriented software construction.

Prentice Hall, 2nd edition edition.

Meyer, B., Ciupa, I., Leitner, A., and Liu, L. L. (2007). Au-

tomatic testing of object-oriented software. In SOF-

SEM ’07: Proceedings of the 33rd conference on Cur-

rent Trends in Theory and Practice of Computer Sci-

ence, pages 114–129, Berlin, Heidelberg. Springer-

Verlag.

Microsoft Corporation (2010). Code contracts

user manual. http://research.microsoft.com/en-

us/projects/contracts/userdoc.pdf.

Object Management Group (2010). Ob-

ject constraint language version 2.2.

http://www.omg.org/spec/OCL/2.2.

Offutt, A. J., Xiong, Y., and Liu, S. (1999). Criteria for

generating speciﬁcation-based tests. In ICECCS ’99:

Proceedings of the 5th International Conference on

Engineering of Complex Computer Systems, page 119,

Washington, DC, USA. IEEE Computer Society.

Tillmann, N. and Halleux, J. d. (2008). Pex - white box test

generation for .NET. In Proceedings of TAP 2008:

the 2nd International Conference on Tests and Proofs,

Lecture Notes in Computer Science, pages 134 – 153.

Springer Verlag.

Turing, A. (1949). Checking a large routine. In Report of

a Conference on High Speed Automatic Calculating

Machines, pages 67 – 69.

Warmer, J. and Kleppe, A. (2003). The Object Con-

straint Language: Getting Your Models Ready for

MDA. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA.

A CRITICAL COMPARISON OF EXISTING SOFTWARE CONTRACT TOOLS
