DATA MINING ON DENGUE VIRUS DISEASE

Daranee Thitiprayoonwongse

, Prapat Suriyaphol

and Nuanwan Soonthornphisaj

Department of Computer Science, Faculty of Science Kasetsart University, Bangkok, Thailand

Bioinformatics and Data Management for Research Unit Office for Research and Development

Siriraj Hospital Mahidol University, Bangkok, Thailand

Keywords: Data mining, Decision tree, Dengue virus disease.

Abstract: Dengue infection is an epidemic disease typically found in tropical region. Symptoms of the disease show

rapid and violent for patients in a short time. The World Health Organization (WHO) classifies the dengue

infection as Dengue Fever (DF) and Dengue Hemorrhagic Fever (DHF). Symptoms of DHF are divided into

4 types. The problem might be happen when an expert misdiagnoses dengue infection. For Example, an

expert diagnosed a patient as non dengue or DF even if a patient was a DHF patient. That might be the

cause of dead if patient did not receive treatment. Therefore, we selected data mining approach to solve this

problem. We employed decision tree algorithm to learn from data set in order to create new knowledge.

The first experimental result shows useful knowledge to classify dengue infection levels into 4 groups (DF,

DHF I, DHF II, and DHF III). An average accuracy is 96.50 %. The second experimental result shows the

tree and a set of rules to classify dengue infection levels into 2 groups followed by our assumption. An

accuracy is 96.00 %. Furthermore, we compared our performance in term of false negative values to WHO

and some researchers and found that our research outperforms those criteria, as well.

1 INTRODUCTION

Dengue Fever is an acute viral infection

characterized by fever. It is caused by a bite from

mosquitoes carrying dengue virus. The World

Health Organization (WHO) classifies the dengue

infection as DF and DHF. Symptoms of DF are

rapidly fever, headache, myalgia, loss of appetite

food, vomiting, abdominal pain and

thrombocytopenia. The severity of DHF is divided

into 4 types. First, DHF I is a DF patient who has

fever and hemorrhagic appearance. Second, DHF II

is a DHF I patient who has spontaneous bleeding.

Next, DHF III is a DHF II patient who has sign of

physiological failure such as rapid/weak pulse,

narrow pulse pressure and cold/clammy skin. Lastly,

DHF IV is a DHF III patient who shock and can’t

detect blood pressure or pulse (Faisal, et al, 2010).

The objectives of our research are as following (1).

We would like to know a set of significant attributes

that classify the type of dengue infections (2)

Physician would like to know the criteria or patterns

found in each class. We selected decision tree

learning as an approach to find knowledge in order

to classify type of dengue infection. The total

number of patients is 258 patients from Siriraj

Hospital, Bangkok, Thailand. The data set consists

of 128 DF, 65 DHF I, 52 DHF II and 13 DHF III

(There is no patient who was diagnosed as DHF IV).

We focus on patients whose ages are lower than 15

years old because the infection in children is more

severe than adults. Forty-eight attributes are selected

as a feature set for decision tree learning. These

attributes are divided into 2 groups, which are

categorical attributes and numerical attributes. The

value of categorical attributes represented the

evidence of symptom. Whereas the numerical

attributes are obtained from hematological evidence

such as percentage of hematocrit increase (HCT),

white blood cell (WBC), etc. The original data set is

high dimension and has some missing values.

Therefore, we need to preprocess data to clean up

and clarify some error. We set up 2 experiments.

The objective of the first experiment is to find

knowledge for each type of dengue infection. The

second experiment explores the hypothesis to find

the pattern of severe and non severe dengue patients.

Thitiprayoonwongse D., Soonthornphisaj N. and Suriyaphol P..

DATA MINING ON DENGUE VIRUS DISEASE.

DOI: 10.5220/0003422000320041

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 32-41

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2 CRITERIA OF DENGUE VIRUS

DISEASE

Dengue is the most common virus transmitted by

mosquitoes which causes up to 100 million

infections and 25,000 deaths worldwide each year.

2.1 WHO Criteria

WHO announced a set of criteria for classifying

dengue patients according to DF and DHF (see

Table 1 for details).

However, WHO criteria are not sufficient to

classify the dengue patients. Since they are just a

common criteria for dengue virus disease. We

believe that there are some different clinical

evidence and laboratory results that fit to our

regional disease. There are some researchers work in

this area such as (Tanner, et al, 2008) and (Tarig, et

al., 2010). They tried to find new criteria in order to

classify dengue patients.

2.2 Tanner’s Criteria

(Tanner, et al, 2008) employed decision tree to

classify data into 4 levels which are Probable

dengue, Likely dengue, Likely non-dengue and

Probable non-dengue. Their data set contains 1,200

patients (1,012 patients from the EDEN study and

188 patients from Vietnam). They found 6

significant features which were platelet count (PLT),

white blood cell count (WBC), body temperature

(T), hematocrit (HCT), absolute number of

lymphocytes (Lymphocyte) and absolute number of

neutrophils (Neutrophil). They got 84.7%

correctness.

2.3 Tarig’s Criteria

Research work done by Tarig Faisal (Tarig, et al.,

2010). Showed that, they can predicted the risk of

dengue patients using Self Organizing Map (SOM)

and Multilayer Feed-forward Neural Networks

(MFNN). Nevertheless, their accuracy rate was only

70 %. Their next research was to do data clustering

on patients into 2 groups as low risk and high risk

patients. They classified 195 patients using three

criteria obtained from SOM. There are 3 risk criteria

which were platelet counts (PLT) (less or equal than

40,000 cell per mm

, HCT (greater than or equal to

25%) and aspartate aminotransferase (AST) (rose by

fivefold the normal upper limit for AST or alanine

aminotransferase) (ALT) (rose by fivefold, the

normal upper limit for ALT) A high risk patient was

a patient who had at least 2 criteria. A low risk

patient was a patient who had less than 2 criteria.

Their finding supported the criteria of WHO. Lastly,

in June 2010, they classified the risk of dengue

patients using MLP. The accuracy only 75 %.

(Ibrahim et al.,2005) predicted the day of

defervescence of fever (day0). Their data set

consists of 252 dengue patients (4 DF and 248

DHF). They applied Multi-Layer Perceptron (MLP)

and got 90 % correctness.

3 DATA PROCESSING

Data integration is a step that integrated the data

from several sources. In this study, Siriraj Hospital

integrated patient’s data from Srinagarindra Hospital

and Songklanagarind Hospital. Next step is data

cleaning. Sometimes the data sets contained noise

data that results from human error or machine error.

Table 1: WHO criteria (World Health Organization, 1999).

Symptoms Laboratory

Fever with two or more of the following

signs: headache, retro-orbital pain, myalgia,

arthralgia.

Leukopenia occasionally. Thrombocytopenia,

may be present, no evidence of plasma loss.

DHF I

Above signs plus positive tourniquet test Thrombocytopenia < 100,000, HCT rise >=20 %

DHF II

Above signs plus spontaneous bleeding Thrombocytopenia < 100,000, HCT rise >=20 %

DHF III

Above signs plus circulatory failure ( weak

pulse, hypotension, restlessness)

Thrombocytopenia < 100,000, HCT rise >=20 %

DHF IV

Profound shock with undetectable blood

pressure and pulse.

Thrombocytopenia < 100,000, HCT rise >=20 %

DATA MINING ON DENGUE VIRUS DISEASE

Table 2: Feature extraction obtained from the treatment period.

Attribute Meaning

Bleeding Evidence of Bleeding (Yes/No)

uri Evidence of upper respiratory infection (Yes/No)

hematocrit _max Maximum value of hematocrit concentration (%)

hematocrit _min Minimum value of hematocrit concentration (%)

AST_max Maximum value of AST (U/L)

AST_min Minimum value of AST (U/L)

AST_avg Average value of AST (U/L)

ALT_max Maximum value of ALT (U/L)

ALT _min Minimum value of ALT (U/L)

ALT _avg Average value of ALT (U/L)

temp_max Maximum temperature of patient (celsius)

temp_min Minimum temperature of patient (celsius)

sbp_minus_dbp_avg Average value of the difference between systolic blood pressure (sbp) and

diastolic blood pressure (dbp) (mm.Hg)

liver_size_average Average size of liver (cm)

hematocrit_max_dx Maximum value of hematocrit concentration (%)

hematocrit_min_dx Minimum value of hematocrit concentration (%)

hematocrit_avg_dx Average value of hematocrit concentration (%)

white_blood_cell_max Maximum number of white blood cells (x1000 cells/µl)

white_blood_cell _min Minimum number of white blood cells (x1000 cells/µl)

white_blood_cell _avg Average number of white blood cells (x1000 cells/µl)

platelet_max Maximum of platelet count (x1000 cells/µl)

platelet_min Minimum of platelet count (x1000 cells/µl)

platelet_avg Average of platelet count (x1000 cells/µl)

protein_avg Average value of protein in liver (g/dl)

albumin_avg Average value of albumin (g/dl)

globurin_avg Average value of globulin (g/dl)

ratio_albumin_avg Average value of ratio between albumin and globulin

quantity_max_found Maximize quantity obtained from tourniquet test.

pulse_pre_min_found The pulse pre min values of a patient.

rash_found Evidence of rash (Yes/No)

itching_found Evidence of itching (Yes/No)

bruising_found Evidence of bruising (Yes/No)

diarrhea_found Evidence of diarrhea (Yes/No)

uri_found Evidence of upper respiratory infection (Yes/No)

abdominal_found Evidence of abdominal (Yes/No)

dyspnea_found Evidence of dyspnea (Yes/No)

ascites_found Evidence of ascites (Yes/No)

jaundice_found Evidence of jaundice (Yes/No)

liver_tenderness Evidence of liver tenderness (Yes/No)

liver_found Evidence of Grown liver (Yes/No)

lymph_found Evidence of lymph node enlargement (Yes/No)

injected_found Evidence of injected conjunctive.

atypical_lymp_found Evidence of atypical lymphocyte.

Effusion_Result Evidence of effusion obtained from X-ray or Ultrasound test (Yes/No)

leakage Evidence of plasma leakage (Yes/No)

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

In case of missing value found in the data set, we

will replace them with mean value. Feature selection

is a step to exclude attributes that are not important

to improve the efficiency of experimental result.

Data transformation is a step that transformed some

attribute values in order to qualify the requirement

of the algorithm. Feature extraction is an important

step to pick up suitable attributes or create new

feature set to represent some data pattern.

In this paper, we created new feature set as

shown in Table 2 and transformed some numerical

attributes to categorical attributes. During the

treatment period, we observed the clinical

information and hematological information. These

attributes were extracted, as well.

4 DECISION TREE APPROACH

Decision tree learning is a supervised learning

method. The algorithm constructs a tree which

consists of a set of selected attributes. These

attributes are qualified by the gain ratio since they

can reduce the entropy of the classes. Consider the

entropy equation (see equation 1). For the multiclass

problem, entropy equation is defined as shown in

equation 2. Finally the gain value is calculated in

equation 3.

5 PERFORMANCE

EVALUATION

We use sensitivity, specificity and accuracy as

performance measures.Three equations are defined

as following. Sensitivity (see equation 4) measures

the proportion of the positive class which are

correctly identified (e.g. the percentage of dengue

patients who are correctly identified as having the

condition). Specificity (see equation 5) measures the

proportion of the negative class which are correctly

identified (e.g. the percentage of healthy people who

are correctly identified as not having the condition).

Moreover, we apply accuracy measurement (see

equation 6) in order to evaluate the proportion of the

true results.

(1)

Where S is the training data set, P is the number of positive class and N is the number of negative class.

(2)

Note that S is the training data set, p

is a ratio of class i compare with all data, and c is the number of class.

(3)

Note that S is the prior data set before classified by attribute A,

| is the number of examples those value of

attribute A are v,

| is the total number of records in the data set.

Sensitivity=

number of True Positives

number of True Positives + number of False Negatives

(4)

Specificity=

number of True Negatives

number of True Negatives+ number of False Positives

(5)

Accuracy=

number of True Positives + number of True Negatives

number of True Positives + True Negatives+ False Positives + False Negatives

(6)



SEntropy











loglog)(



ppSEntropy

log)(









)()(),(

)(

AValuesv

SEntropy

sEntropyASGain







DATA MINING ON DENGUE VIRUS DISEASE

6 EXPERIMENTAL RESULTS

6.1 Data Set

The total number of patients was 258 patients that

obtained from Siriraj Hospital, Bangkok, Thailand.

The data set consists of 128 DF, 65 DHF I, 52 DHF

II and 13 DHF III. These attributes value are clinical

attributes and hematological attributes. There are 48

attributes (26 numerical attributes, 21 categorical

attributes.

Attributes in Table 3 were recorded during the

first visit of each patient. Some attributes were

preprocessed such as Bleeding. The Bleeding value

was determined from any evidences found from

spontaneous petechiae, ecchymosis, gum, nose,

vomiting, stool and others.

During the treatment period, nurses and

physicians followed the symptoms as shown in

Table 4 and 5. Temporal attributes are summarized

in terms of maximum, minimum and average values.

6.2 The First Experiment

In the first experiment, we used decision tree

learning algorithm in order to find the knowledge in

dengue patient’s data set. The data set consists of 4

classes which were DF, DHF I, DHF II and DHF III.

We obtained the decision tree as shown in Figure 1.

We found 7 significant attributes needed to classify

patients. These attributes were leakage - leakage of

plasma in blood, shock – shock evidence found

during treatment period, Bleeding – bleeding

evidence found, lymp_found – lymph node

enlargement found, quantity_max_found –

bleeding spot found under skin, platelet_avg – the

average of platelet count and AST_max – the level

of aspartate aminotransferase.

Table 3: Attributes obtained in the early phrase of treatment.

Attribute Type Meaning

JE vaccine Categorical Received JE vaccine

URI Categorical Upper respiratory tract infection

Bleeding Categorical Bleeding

Table 4: Attributes obtained during the treatment period (numerical values).

Attribute Meaning

hematocrit _max Maximum value of hematocrit concentration

hematocrit _min Minimum value of hematocrit concentration

AST_max Maximum value of AST

AST_min Minimum value of AST

AST_avg Average value of AST

ALT_max Maximum value of ALT

ALT _min Minimum value of ALT

ALT _avg Average value of ALT

temperature_max Maximum of temperature

temperature _min Minimum of temperature

sbp _dbp_avg The difference between sbp and dbp

liver_size_avg Average size of grown liver

hematocrit_max_dx Maximum value of hematocrit concentration

hematocrit_min_dx Minimum value of hematocrit concentration

hematocrit_avg_dx Average value of hematocrit concentration

white_blood_cell_max Maximum of WBC (x1000)

white_blood_cell _min Minimum of WBC (x1000)

white_blood_cell _avg Average of WBC (x1000)

platelet_max Maximum of platelet count (x1000) by machine

platelet_min Minimum of platelet count (x1000) by machine

platelet_avg Average of platelet count (x1000) by machine

protein_avg Average value of protein in liver

albumin_avg Average value of albumin

globurin_avg Average value of globulin

ratio_albumin_avg Average value of ratio between albumin and globulin

quantity_max_found Maximize quantity value of tourniquet test

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

Table 5: Attributes obtained during the treatment period (categorical values).

Attributes Meaning

pulse_pre_min_found Minimum of different pressure value evidence

rash_found Rash on skin evidence

itching_found Itching related to rash evidence

bruising_found Bruising evidence

diarrhea_found Diarrhea evidence

uri_found Upper reparatory infection evidence

abdominal_found Abdominal pain

dyspnea_found Evidence of dyspnea

ascites_found Evidence of ascites

juandice_found Evidence of jaundice

liver_tenderness Evidence of liver tenderness

liver_found Evidence of grown liver

lymph_found Evidence of lymph node enlargement

injected_found Injected conjunctive evidence

atypical_lymp_found Atyp lymphocyte evidence

Effusion_Result Effusion evidence

leakage Evidence of plasma leakage

shock Evidence of shock

dx Class

Figure 1: Decision tree with 4 classes.

Table 6: Performance of the first experiment.

Class Sensitivity(%) Specificity(%) Accuracy(%)

Overall

Accuracy(%)

DF 100.00 99.13 99.59

96.50

DHF I 86.15 96.88 94.16

DHF II 86.54 96.10 94.16

DHF III 100.00 99.57 99.59

DATA MINING ON DENGUE VIRUS DISEASE

There was only one rule found for the DF patients. If

there was no leakage evidence found in the patient,

he/she would be diagnose as DF. There were three

rules found for the DHF I patients. If leakage

evidence was found and no shock and no bleeding

evidence were found, those patients would be

diagnose as DHF I. The second rule, if bleeding

evidence was found, no lymph node enlargement

and the tourniquet result were 14-17 bleeding spots

obtained from tourniquet test, the patients would be

diagnose as DHF I. The third rule, if the bleeding

spots were less than 14 and the average number of

platelet count was more than 88.8 cells/µl and the

maximum level of AST was more than 131 U/L,

then the patients would be diagnose as DHF I.

Consider DHF II class; there were four rules. The

patients would be diagnose as DHF II if there were

leakages evidence, no shock, bleeding evidence and

lymph node enlargement evidence. However, if

lymph node enlargement evidence was not found

and if the bleeding spots obtained from tourniquet

test were more than 17, they would be diagnose as

DHF II. The third rule of DHF II was that if the

maximum quantity of bleeding spots obtained from

tourniquet test was less than 14 and the average of

platelet count was less than 88.8 cells/µl. The fourth

rule was that if the average of platelet count was

more than 88.8 cells/µl and the maximum of AST

was less than 131 U/L, they would be diagnose as

DHF II. For DHF III class, there was only one rule

found. The patient would be diagnose as DHF III if

they found leakage evidence and shock evidence.

We found that the decision tree completely

classified patients in DF and DHF III with 100 % on

sensitivity value. For DF class, the specificity

performances of DHF II class were 86.54 %, 96.10

% and 94.16 % measured on sensitivity, specificity

and the average accuracy, respectively. The

specificity and the average accuracy of DHF III

were 99.57 % and 99.59 %, respectively. The last

column shows the overall accuracy of this model

which was 96.5 % (see Table 6 for details)value was

99.13 %. The accuracy of DF class was 99.59 %.

Consider DHF I class, we found that the sensitivity,

specificity, and average accuracy were 86.15 %,

96.88 % and 94.16 %, respectively.

Table 7: Confusion matrix of the first experiment.

a b c d classified

128 0 0 0

a = DF

0 45 6 1

b = DHF II

1 8 56 0

c = DHF I

0 0 0 13

d = DHF III

6.3 The Second Experiment

WHO has launched new criteria to classify patients

into 2 classes. Therefore, we set up the second

experiment in order to classify patients into 2

groups. We reassign DF and DHF I as Non Severe

(Group1) and reassign DHF II and DHF III as

Severe (Group2). Consider the decision tree shown

in Fig. 2, we found 8 significant attributes useful for

classifying data. Same attributes as the first

experiment were found in the tree which were

leakage evidence, shock evidence, bleeding evidence

and lymph node enlargement evidence. Different

attributes were abdominal pain, an average of white

blood cell, an upper respiratory infection and a

minimum of patient’s temperature. There were 5

rules for non-severe group and 5 rules for severe

group.

Figure 2: Decision tree with 2 classes.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

Table 8: Confusion matrix of the second experiment.

a b Classified as

185 8

a = Group1

5 60

b = Group2

Table 8 represented the number of correctly

classified patients performed by decision tree. We

found that 185 patients from 193 patients can be

correctly classified as a non-severe group. Sixty

patients from 65 patients were correctly classified as

a severe group.

For non-severe group, we found that the

sensitivity, specificity and the average accuracy

were 95.85 %, 92.31 % and 94.96 %, respectively.

For severe group, we found that the sensitivity,

specificity and average accuracy were 92.31 %,

95.85 % and 94.96 %, respectively. We obtained

96.00 % of the overall accuracy from ROC Area in

the second experimental result (see Table 9 for

details)

7 DISCUSSION

7.1 Experimental Result

(Tanner, et al, 2008), applied decision tree algorithm

to classify the patients into 4 levels of dengue

patients and non-dengue patients (Probable dengue,

Likely dengue, Likely non-dengue and Probable

non-dengue). The accuracy was only 84.70%. Thus

in this paper, we used decision tree algorithm in

order to learn and classify type of the patients (called

“grading”). We would like to classify the patients

into 4 classes. The first experimental result showed

new knowledge in Figure. 1. Our accuracy rate was

96.50 % in the first experiment. For the second

experiment, we would like to classify dengue

infection into 2 groups (severe and non-severe). Our

second experiment was similar to Tarig’s

experiment (Faisal, et al, 2010). They applied Self

Organization Map to characterize the low risk and

high risk dengue patients. They used three features

to cluster dengue patients which were HCT, PLT

and AST/ALT. (Faisal, et al. 2010) classified the

dengue patients using two algorithms of neural

networks. They used three features from the

research. Their best algorithm was MLPSCG. Their

accuracy was 75.00 % whereas our accuracy was

better than their result. Our experimental result

found different feature set compared to those of

Tarig Faisal. We found 8 significant features which

were leakage, bleeding evidence, shock, lymph node

enlargement, abdominal pain, upper respiratory

infection, white blood cell and body temperature.

Our accuracy of the second experiment was 96.00

7.2 Result Validation with other

Criteria

As stated before that WHO has launched a set of

criteria for physician to classify dengue infection

patients. The decision tree classified the patients into

4 classes which were shown in Table 10. The false

negative values were examined for comparison

between WHO criteria and the decision tree. The

false negative of decision tree were 10.77% and

17.31% for DHF I and DHF II. We applied the

WHO criteria to compared with the first

experimental result, the patients (258 patients) were

classified by WHO criteria (see Table 11).

Table 9: Performance of second experiment.

Class

Sensitivity

(%)

Specificity

(%)

Accuracy

(%)

Overall

Accuracy

(%)

Group1 95.85 92.31 94.96

96.00

Group2 92.31 95.85 94.96

Table 10: False Negative value obtained from the first experiment.

Class Label data

Number of patients

classified by Decision tree

False Negative (%)

DF 128 129 0

DHF I 65 53 10.77

DHF II 52 62 17.31

DHF III 13 14 0

DATA MINING ON DENGUE VIRUS DISEASE

Table 11: Result of WHO criteria.

Class Label data

Number of patients

classified by WHO criteria

False Negative (%)

DF 128 165 5.47

DHF I 65 39 44.62

DHF II 52 35 40.38

DHF III 13 0 100

DHF IV 0 17 -

Non Dengue 0 2 -

Table 12: Our second experimental result.

Class Label Data

Number of patients

classified by decision

tree

False Negative (%)

Group1 (Low risk) 193 190 4.15

Group2 (High risk) 65 68 7.69

Table 13: Confusion Matrix using Tarig’s criteria.

a b Classified as

173 20

a = Group1

50 15

b = Group2

Table 14: The result of Tarig's criteria.

Class Label data

Number of patients

Classified by Tarig’s

criteria

False Negative (%)

Group1 (Low risk) 193 223 10.36

Group2 (High risk) 65 35 76.92

Table 15: False Negative values.

Class

Number of patients

Decision Tree

classifier

WHO criteria Tarig’s criteria

DF 0 7 -

DHF I 7 29 -

DHF II 9 21 -

DHF III 0 13 -

Group1 8 - 20

Group2 5 - 50

Consider DF class, the false negative value

obtained from WHO was 5.47 % higher than the

decision tree. Moreover the false negative value of

DHF I, DHF II, DHF III were 33.85 %, 23.07 % and

100 % higher than the decision tree. It means that

the criteria from WHO were not sufficient to classify

type of dengue patients. However, our decision tree

provides better performance in classifying patients.

We hope that the knowledge obtained from the

decision tree algorithm may help physicians in

diagnosis process.

From Table 12, we found the value of false nega-

negative were 4.15 % and 7.69 %. After that, we

considered the data using Tarig’s criteria (see Table

13). We found that a false negative value of non-

severe group was 20 and a false negative value of

severe group was 50. We calculated them in term of

percentage in Table 14. We found that the false

negatives were increased when we used Tarig’s

criteria to classify the data.

Using Tarig’s criteria, their result also gave more

false negative value than that of our experimental

result. That means their criteria were not sufficient

in classifying the data because they had much of the

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

false negative value.

Table 15 shows the number of false negative

using WHO criteria which were greater than that of

decision tree classifier and the number of false

negative patients using Tarig’s criteria were greater

than that of decision tree classifier. Our experiment

gave better classifying result than WHO criteria and

Tarig’s criteria.

8 CONCLUSIONS

Our research work is in the framework of data

mining. We try to find new knowledge that

contributes to the more accurate classifying results.

We got an accuracy as 96.50% for classify levels

into 4 groups and 96.00 % for classify levels into 2

groups.

We create new feature set that make the learning

algorithm succeeded in classifying task. Finally, we

found some significant features such as lymph node

enlargement and upper respiratory infection that are

useful to differentiate the degree of dengue patients.

ACKNOWLEDGEMENTS

This research is supported by Faculty of Science and

Kasetsart University and Research Development

Institute, Bangkok Thailand.

REFERENCES

Ibrahim, F., Taib, M. N., Wan Abas, W. A. B., Chan, C.

and Sulaiman, S, 2005. A novel dengue fever (DF)

and dengue haemorrhagic fever (DHF) analysis using

artificial neural network (ANN), Comput. Methods

Programs Biomed. 79 pp. 273–281

Tanner, L., Schreiber, M., Low,J.G., Ong, A.,

Tolfvenstam, T., Lai, Y. L., Ng, L. C., Leo, Y. S. Thi

Puong, L., Vasudevan, S. G., Simmons, C. P.,

Hibberd, M. L., and Ooi, E. E, 2008. Decision Tree

Algorithms Predict the Diagnosis and Outcome of

Dengue Fever in the Early Phase of Illness. PLoS

Negl. Trop. Dis., 196.

Faisal, T., Ibrahim, F. and Taib, M. N., 2010. A

noninvasive intelligent approach for predicting the risk

in dengue patients. Expert Systems with Applications,

Volume 37, Issue 3, pp. 2175-2181.

Faisal, T., Taib, M. N. and Ibrahim, F., 2010.

Reexamination of risk criteria in dengue patients using

the self-organizing map. Med. Biol.Eng.Comput.48,

pp. 293-301.

Faisal, T., M. N. Taib, M. N., and F. Ibrahim, F., 2010.

Neural network diagnostic system for dengue patients

risk classification.

World Health Organization: Guideline for Treatment of

Dengue Fever/Dengue Haemorrhagic Fever, 1999.

DATA MINING ON DENGUE VIRUS DISEASE
