SMARTPHONE SECURITY EVALUATION

The Malware Attack Case

Alexios Mylonas, Stelios Dritsas, Bill Tsoumas and Dimitris Gritzalis

Information Security and Critical Infrastrucutre Protection Research Laboratory

Department of Informatics, Athens University of Economics & Business (AUEB)

76 Patission Ave., GR-10434, Athens, Greece

Keywords: Smartphone, Security, Malware, Attack, Evaluation criteria.

Abstract: The adoption of smartphones, devices transforming from simple communication devices to ‘smart’ and

multipurpose devices, is constantly increasing. Amongst the main reasons are their small size, their en-

hanced functionality and their ability to host many useful and attractive applications. However, this vast use

of mobile platforms makes them an attractive target for conducting privacy and security attacks. This scena-

rio increases the risk introduced by these attacks for personal mobile devices, given that the use of smart-

phones as business tools may extend the perimeter of an organization’s IT infrastructure. Furthermore,

smartphone platforms provide application developers with rich capabilities, which can be used to compro-

mise the security and privacy of the device holder and her environment (private and/or organizational). This

paper examines the feasibility of malware development in smartphone platforms by average programmers

that have access to the official tools and programming libraries provided by smartphone platforms. Towards

this direction in this paper we initially propose specific evaluation criteria assessing the security level of the

well-known smartphone platforms (i.e. Android, BlackBerry, Apple iOS, Symbian, Windows Mobile), in

terms of the development of malware. In the sequel, we provide a comparative analysis, based on a proof of

concept study, in which the implementation and distribution of a location tracking malware is attempted.

Our study has proven that, under circumstances, all smartphone platforms could be used by average develo-

pers as privacy attack vectors, harvesting data from the device without the users knowledge and consent.

1 INTRODUCTION

Smartphones are some of the devices that enhance

Weiser’s vision of ubiquitous computing (Weiser,

1991). Their small size, mobility, connectivity capa-

bilities, and multi-purpose use are some of the rea-

sons for their vast pervasiveness (Gartner, 2010).

Malicious software, or malware (Andleman,

1990; Cohen, 1989; Kephart & White, 1991) has

also appeared in smartphone platforms (Hypponen,

2006), but initially their occurrences and severity

were limited. Nonetheless, recent reports show that

the risk of malicious application execution on smart-

phones is severe and contingent (McAfee, 2010;

CISCO, 2011). Moreover, the use of smartphones

extends the infrastructure perimeter of an organiza-

tion, thus amplifying the impact and the risk of po-

tential execution of malicious applications (Sindhu

et al., 2010).

Apart from the increasing smartphone sales

(Gartner, 2010), the annual downloads for applicati-

ons developed for smartphones and distributed from

official application repositories are also bound to

increase by 117% in 2011 (Gartner, 2011). In additi-

on, popular web applications (Gmail, YouTube, etc.)

and social networks (Facebook, Twitter, etc.), are

being accessed on mobile devices through native ap-

plications, instead of their usual web browser inter-

face. In this context, smartphones contain a vast

amount of the user’s data, thus posing a serious pri-

vacy threat vector (PAMPAS, 2011; ENISA, 2011;

GSMA, 2011). These data are augmented with

smartphone sensor data (i.e. GPS) and data created

by daily use (personal or business) making the

device a great source of data related with the

smartphone owner. This data source is invaluable to

attackers trying to harvest them to increase their

revenues (e.g., with blackmail, phishing,

surveillance attacks). Hence, attackers try to infect

smartphones with malware applications, harvesting

Mylonas A., Dritsas S., Tsoumas B. and Gritzalis D..

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case.

DOI: 10.5220/0003446800250036

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2011), pages 25-36

ISBN: 978-989-8425-71-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

smartphone data without the user’s knowledge and

consent. It should be noted that the everyday use of

smartphones by non-technical and non-security

savvy people increases the likelihood of using

smartphones as a security and privacy attack vector.

The security model of smartphone platforms has,

under these circumstances, two contradicting goals.

On the one hand, it must provide mechanisms to

protect the users from attacks and on the other hand,

it must attract third party developers, since the popu-

larity of a platform depends on the attractiveness of

its applications. The former goal is approached by

each smartphone platform under a non unified and

standardised approach that its effectiveness is con-

troversial (Sophos, 2011). For the latter smartphone

platforms provide developers with development

friendly environments that include extensive docu-

mentation, programming libraries, and emulators.

However, this development friendliness may also be

used to write applications that can compromise the

security and privacy of smartphone users more

easily.

This paper examines the feasibility of malware

development on smartphones by average program-

mers that have access to the official tools and

programming libraries provided by smartphone plat-

forms. This is mainly achieved through a proof of

concept study that aims on evaluating the ease of

malware development against users of smartphone

devices. Thus, issues like state of the art attacks that

might be performed by sophisticated attackers

(Seriot, 2010; Lineberry et al., 2010) and the relation

between malware attacks on smartphones and desk-

top computing devices are out of the scope of this

paper.

This paper contributes towards this direction by

(a) proposing a set of evaluation criteria, assessing

the development of malware, and (b) providing a

comparative case study analysis where the imple-

mentation and distribution of proof of concept loca-

tion tracking malware is implemented in the current

smartphone platforms.

The paper is organized as follows. Section 2 pro-

vides background information about current smart-

phone operating systems. In section 3 the comparati-

ve criteria are introduced, while in section 4 our pri-

vacy attack implementation scenarios are presented.

Finally, the paper concludes in section 5.

2 SMARTPHONE PLATFORMS

In this section we discuss the security models and

development environments of the surveyed smart-

phone platforms: (a). Android OS, (b). BlackBerry

OS, (c). Symbian OS, (d). Apple iOS, and (e). Win-

dows Mobile 6 OS. Our analysis focuses on applica-

tion installation and execution. Security mechanisms

that are used for the physical protection of the device

(data encryption, anti-theft solutions, etc.) are out of

the scope of this paper.

2.1 Android OS

The Android OS is a Linux based open source ope-

rating system developed and maintained by Google.

Android was designed to be executed on portable

devices, such as smartphones and tablets. It provides

a free and publicly available Software Development

Kit (SDK) that consists of tools, documentation and

emulators necessary for the development of new ap-

plications in Java. According to Gartner (Gartner,

2010), the Android platform increased its worldwide

smartphone sales from 3.5% in the Q3 of 2009 to

25.5% in the Q3 of 2010.

A core element of the Android security model

(Google, 2011c) is the manifest file. The manifest fi-

le is bundled into the Android installation package

file (.apk file), along with the applications bytecode

and other related resources. The file follows the

XML structure and provides all the necessary infor-

mation to the Android platform for the execution of

the application. Security-wise the manifest file is

crucial for the system, since a developer defines in it

the permissions of each application. These permis-

sions control: (a) the way the application interacts

with the system via access to system API, and (b)

the way the system and the other applications intera-

ct with the given application’s components. By de-

fault, every application runs in a sandboxed environ-

ment without any permission to perform an action

that can impact the operating system itself, the other

applications and the user.

Every application requests authorization for its

permissions at installation time, which is based on

the user’s approval. No further checks are made du-

ring the applications’ execution. Hence, if the user

decides to grant permission to the application, then

the protected system resources are available to the

application, otherwise the access to the resources is

blocked

The installation package file of every Android

application has to be digitally signed by its develo-

per. Android’s security model then maps the signa-

ture of the developer with a unique ID of the appli-

cation package and enforces signature level permis-

sion authorization (Google, 2011c). However, in the

Android security model it is not obligatory that the

developer’s certificate is signed by a trusted

SECRYPT 2011 - International Conference on Security and Cryptography

certificate authority. Thus, the applications are

usually digitally signed with self-signed certificates,

providing only poor source origin and integrity

protection. This preserves the anonymity of a

potential attacker, since the certificate is not verified

by a Trusted Third Party (TTP).

A developer distributes her application either in

the official Android application repository maintain-

ed by Google, the Android Market , or outside the

repository. Google does not enforce any restriction

in the installation of applications originating outside

its repository. On the other hand, Google developed

technologies to remove applications (Google, 2011a)

from the devices and the Android Market in case

they pose a threat to the Android platform. The ap-

plications in the Android Market are provided to end

users without being tested for malicious behaviour.

Hence, a developer must only provide her Google

account and pay a small fee for the distribution of

any application in the Android application reposito-

ry. It is evident that this procedure is not able to stop

malware from being distributed via the Android

Market and being installed οn devices.

According to (Google, 2011b), version 2.2 is the

dominant Android version, currently deployed in the

majority of the Android devices (51.8%). Older ver-

sions of the OS are still being in use: 35,2% of the

devices run version 2.1, while version 1.6 runs on

7.9% of the devices. The adoption of the latest ver-

sion of the OS (version 2.3) is still low, since it is

deployed only in the 0.4% of the Android devices.

2.2 BlackBerry OS

The BlackBerry OS is an operating system maintain-

ned by Research In Motion Inc. (RIM). The current

version of the OS is version 6. The OS is executed

on BlackBerry smartphones and tablet devices crea-

ted by RIM. According to Gartner (2010), RIM’s de-

vice worldwide market share dropped to 14.8% in

the Q3 of 2010 from 20.7% in the Q3 of 2009.

Documentation about the OS details is not provi-

ded by RIM. However, the company provides,

through the BlackBerry SDK, the related documen-

tation, tools, API and emulators, which are neces-

sary for application development.

The platform security model (RIM, 2011b) en-

forces restrictions to third party applications trying

to access protected APIs of the OS, by demanding

the signing of the application with a cryptographic

key provided by RIM (RIM, 2011a). A developer

needs to pay a small amount in order to acquire a va-

lid RIM signing key pair. However, this process on-

ly provides poor source origin and code integrity and

does not offer any assurance about the validity and/

or the security level of the third party application.

The official application repository for BlackBer-

ry smartphones is the App World (RIM, 2011b). Un-

official repositories of applications, such as Crack-

berry (Smartphone Experts, 2011), also exist.

Application distribution in the official repository

requires registration for a vendor account. Develo-

pers incur a registration cost of $200 for the afore-

mentioned account creation, allowing them to sub-

mit 10 applications. For additional submissions an

administration fee is required. It should be noted that

before the application publication in the repository,

its code is not examined by BlackBerry for malici-

ous behaviour and, in addition, BlackBerry does not

operate a remote application removal mechanism.

Finally, the platform provides the following opti-

ons for the installation of applications in the device

(a). via the BlackBerry App World, (b). Over the Air

(OTA), (c). via the device’s browser, and (d). via

RIM desktop synchronization software.

2.3 Symbian OS

Symbian OS is an operating system maintained by

Nokia. Symbian’s current version is Symbian^3. The

platform had a major worldwide market share dec-

rease in Q3 of 2010 falling to 36.6% from 44.6% in

the Q3 of 2009 (Gartner, 2010).

Symbian is executed in smartphones and provi-

des multiple free and publicly available SDKs. The

SDK includes the tools, documentation and emula-

tors that are necessary for the development of new

applications, written in C++.

The cornerstone in Symbian’s security model is

the use of capabilities (Nokia, 2011a) for defining

restrictions to sensitive platform APIs. These capabi-

lities are grouped in the following categories: (a).

basic, (b). extended, (c). manufacturer. The first ca-

tegory includes basic functionality (e.g. access to the

network, access to location data, etc.), where the u-

ser is prompted for its authorization during installa-

tion. The second capability category controls the use

of sensitive API that is only granted through the Sy-

mbian Signed process (Nokia, 2011c). The last capa-

bility category controls application access to the mo-

st sensitive API in the platform (i.e. All-Files, DRM,

TCB). These capabilities are only granted by a Devi-

ce Manufacturer (e.g. Nokia, Sony Ericsson, etc). As

indicated by Nokia (2011a) the basic capability cate-

gory contains sufficient functionality for application

development. In this context, our proof of concept

study uses capabilities.

For each application installation, signing the ap-

plication’s package file (.sis file) is required by the

Symbian security model. Signing ensures that the

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case

application is not using API apart from the one cor-

responding to the applications signing level (Nokia,

2011a). If the application uses only basic capabili-

ties the developer can self sign it (Nokia, 2011b).

Self-signing has the advantages to be performed in

the developer’s computer, and it is not necessary to

map the application installation package file with a

device IMEI. This results in no restriction during

multiple device installations, but the smartphone u-

ser will be prompted with security warnings at insta-

llation time, since the signing key is not trusted. To

eliminate the warnings and access sensitive capabili-

ties the developer submits her application to Sym-

bian Signed along with the list of device IMEIs. Ho-

wever, guidelines for bypassing Symbian’s secu-rety

model are available (Symbian Freak, 2011), allow-

ing the execution of unsigned applications, but the

modified version of the OS is out of scope of this

paper.

The applications are not required to reside in an

application repository in order to be installed to

Symbian devices. Nonetheless, Nokia maintains an

official application repository, the OVI store.

2.4 iOS

iOS is a proprietary operating system maintained by

Apple. iOS is only executed in Apple smartphones

and tablets (i.e. iPhones, iPADs) and its current ver-

sion is 4.2.1. According to Gartner (2010), Apple’s

worldwide smartphone market share dropped slight-

ly to 16.7% in the Q3 of 2010 from 17.1% in the Q3

of 2009.

Apple provides, after registration to the compa-

ny’s Dev Center (Apple, 2011a), documentation, to-

ols and the necessary API for application develop-

ment in Objective C. It should be noted that the tool-

set provided by Apple is only compatible with Mac

OS X operating system.

The official repository of iOS applications is the

App Store. The distribution of applications in the re-

pository costs $99 per year (Apple, 2011b). None-

theless, the iOS protection code can be altered and

bypassed (jailbroken) and the user is able to install

applications that are not officially signed by Apple

from an unofficial repository, such as Cydia Store,

Installus, etc. Installation of applications in modified

versions of the OS is out of the scope of this paper.

The security model of the iOS only permits the

installation of applications that have been signed by

Apple (Apple, 2011a). Before being signed, an ap-

plication is tested for its functionality consistency

and for malicious behaviour. However, the testing

process and criteria applied by Apple are not public-

ly available.

Applications are installed on the device with: (a).

the use of an application installed on the device that

connects to Apple’s App Store, or (b). the use of

cross-platform synchronization desktop software

provided by Apple (iTunes). Once the application is

installed to the device the user neither controls nor is

prompted when an application accesses some OS’

sensitive resources. An in depth analysis of all the

data that are available to an application in version 3

of iOS is provided in (Seriot, 2010).

2.5 Windows Mobile

Windows Mobile is a smartphone OS developed and

maintained by Microsoft. The OS’s worldwide

smartphone market share decreased from 7.9% in

the Q3 of 2009 to 2.8% in the Q3 of 2010 (Gartner,

2010). The latest version of the OS is Windows Pho-

ne 7. However, until the writing of this paper Micro-

soft has not made available basic API functionality,

such as sockets for internet connectivity (Microsoft,

2010 d). Therefore, in this section we present the se-

curity model of Windows Mobile 6, since its deve-

lopment API is available.

The security model of Windows Mobile (Micro-

soft, 2010c) depends on the enabled policy of the de-

vice. This policy is responsible for controlling which

applications are allowed to be executed on the devi-

ce, what functionality of the OS is accessible to the

application, how desktop applications interact with

the smartphone, and how the user or application ac-

cess specific device settings. The enabled policy on

a Windows Mobile smartphone is either one-tier ac-

cess or two-tier access (Microsoft, 2010c).

A device with one-tier access policy enabled, on-

ly controls if one application runs on the device or

not, without inspecting if the application is using

sensitive API. This decision depends on whether the

application’s installation package file (.cab file) is

correctly signed with a certificate that exists in the

device’s certificate store. If the application is signed

with a known certificate, then the application runs in

privileged mode, with the ability to call any API, ac-

cess and modify anything in the device’s file system

and registry. Otherwise, if the application is unsign-

ed or signed with a certificate that is not known, fur-

ther policy checks take place for the decision of ap-

plication execution. In this case, security policies

settings define whether the user is prompted to give

her consent for the application to run. It must be cla-

rified that if the user permits the execution, then the

application will run in privileged mode. This means

that an unknown and unsigned application maintains

full access to the device.

SECRYPT 2011 - International Conference on Security and Cryptography

On the other hand, a device with two-tier access

policy enabled, apart from controlling application e-

xecution, it also checks runtime permissions by con-

trolling the APIs that the application uses. Access to

protected API is determined by the application’s di-

gital signature. More specifically, if the application

is signed with a known certificate (i.e. a certificate

present in the device’s certificate store), then the ap-

plication is executed without further checks, granted

the permissions defined by the certificate class. In

the case that the certificate belongs to the Privileged

Execution Trust Authorities certificate store, the ap-

plication is executed with privileged permissions.

Otherwise, the application is executed in normal mo-

de. When the application is unsigned or signed with

an unknown certificate, then further checks are re-

quired to determine if the application is allowed to

run in normal mode. It is worth noting that the func-

tionality provided by normal privileges is enough for

most third-party developed applications.

According to (Microsoft, 2010c; Microsoft, 2010

a) the default security configuration of Windows

Mobile, provides weak security protection as: (a). it

allows the execution of unsigned applications or sin-

ged ones with an unknown certificate, (b). in case

(a). the user is prompted to authorize the execution

of the application. Hence, in both access tiers of the

default security configurations, unsigned and un-

known code is executed with the user’s approval

either in normal mode (two-tier access) or privileged

mode (one-tier access). Furthermore, although one-

tier access does not provide strong security, it is the

default access tier in some devices (Microsoft,

2010c). Nonetheless, it should be noted that the se-

curity model permits Mobile Operators to make

post-production changes to security settings configu-

rations of the device.

The security model of Windows Mobile includes

security mechanisms enabling a Mobile Operator to

revoke (i.e. remove) applications running on smart-

phones (Microsoft, 2010c). The revocation may con-

cern either (a). a class of applications signed with

the same certificate, where the corresponding certifi-

cate is being revoked, or (b). a specific application

binary, where the hash of the binary is being trans-

ferred to the device with transfer mechanisms des-

cribed in (Microsoft, 2010c).

For application implementation in Windows Mo-

bile 6, Microsoft freely provides the required deve-

lopment toolkit (i.e. SDK, emulator, documentation,

etc.). The supported implementation languages (e.g.

C#, Visual C++) are compatible with the Compact

.NET Framework.

For the acquisition of certificates that are known

to the devices, the developer opts from the paid ser-

vices provided by Microsoft (Microsoft, 2011b).

3 COMPARATIVE EVALUATION

OF SMARTPHONE

PLATFORMS

This section provides a comparative evaluation of

the smartphone platforms in terms of malware deve-

lopment and distribution. Our analysis examines the

feasibility of attacks implemented by average appli-

cation developers. More specifically, the presented

evaluation is based on: (a). the definition of qualita-

tive evaluation criteria, and (b). a proof of concept

malware implementation study, in which the deve-

lopment of a location tracking application is examin-

ed. At this point it should be stressed that any sop-

histicated attack conducted by experienced attackers,

as well as, publicly available malicious code used by

script kiddies are not examined in this paper. Fur-

thermore, a comparison with malware development

in desktop computing is not examined in this paper

either.

3.1 Evaluation Criteria

The comparative evaluation of smartphones is per-

formed by defining and using a set of evaluation cri-

teria, which are elaborated in this section. The pro-

posed criteria concern the development platform and

the developer. From the proposed evaluation criteria

the former are objective, relying solely on characte-

ristics of the smartphone platform. The latter are

subjective, giving details about the attack develop-

ment effort and as a result depend on the developer’s

skills and background. The latter, however, are gi-

ven as an indication on the effort needed to conduct

such attacks via smartphone applications.

Our overall approach focuses primarily to the ob-

jective criteria (development platform), while at the

same time takes into account the subjective criteria

(regarding the developer side). It must be noted that

this list of criteria is not exhaustive. Table 1 summa-

rizes the proposed evaluation criteria.

3.1.1 Development Platform Criteria

In this section we describe and analyse the

introduced development platform evaluation criteria

in relation with their possible data type.

Development Tools Availability {Yes, Partial,

No}: This criterion refers to the availability of deve-

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case

lopment tools needed for application development.

The public and free nature of these tools makes the

development of malware easier and cost effective.

The reason for this is that the presence of a free e-

mulator reduces the development cost of the attac-

ker, since a purchase of a device is not necessary. In

addition, the SDK contains all the tools (e.g. debug-

gers, compilers, etc.), which are necessary for the

implementation of the malicious application.

Development Friendliness {Yes, No}: This

Boolean criterion assesses the “developer” friendli-

ness of the programming language supported by the

smartphone platform. The adoption of a well known

and widely used programming language (e.g. Java)

is preferred during any application deployment.

Installation Vectors {Multiple, Restricted}:

This criterion assesses the available installation

options for an application on the smartphone device.

These installation options include the use of

removable media, through the WEB, email, etc.

Application Portability {Yes, No}: This criteri-

on refers to the ability of the malicious application to

be executed in different versions of the target smart-

phone OS. The more compatible an application with

different versions of the OS is, the greater the attack

target population becomes.

Application Testing {Yes, No}: This criterion

refers to the possible application testing procedures,

which could be used from official vendors (e.g. Ap-

ple) in order to determine applications’ potential ma-

licious activity. The tests take place before the appli-

cation is available in the official vendor application

repository.

Application Removal {Yes, No}: This Boolean

criterion refers to the existence of a remote applica-

tion removal mechanism. The automated removal of

an application from the repository and the smart-

phone devices is triggered when enough evidence is

discovered that the application acts in a maliciously

way.

Unofficial Repositories {Yes, No}: This Boo-

lean criterion refers to the existence of application

sources outside the official application repository. In

the case that the official repository adopts applica-

tion testing procedures, one option for a potential

attacker is to place the application in alternative

sources. This is a common action when the security

model of the smartphone permits the installation of

applications from sources other than the official

repository.

Distribution Cost {Yes, No}: This criterion

assesses whether the cost of application distribution

into the official application repository deters a

potential attacker.

API Restrictions {Yes, No}: This criterion re-

fers to the restrictions imposed by smartphones’ OS,

in terms of how they control the use of protected

APIs.

Application Signing {Yes, No}: This criterion is

used for assessing the restrictions imposed by smart-

phones’ OS, concerning the signing of the applicati-

ons, before they are installed on a device.

3.1.2 Developer Criteria

This set of criteria includes the Developer’s Back-

ground and the Development Time. In specific:

Developer’s Background {Education Level},

refers to the developer’s knowledge in information

security as well as to her programming skills. We as-

sume that the amount of knowledge a developer

possesses in information security and her program-

ming skills, determine the sophistication of the at-

tacks she is able to implement.

Development Time {Number}, which is used

for determining the effort needed to conduct a

malware attack.

Apparently, the abovementioned criteria are gi-

ven as an indication for the time and skills needed

for the development of an attack by an average-skil-

led programmer. The evaluation criteria are summa-

rized in Table 1.

Table 1: Proposed Evaluation Criteria.

Evaluation Criteria Type

Development Tools

Availability

String {Yes, Partial, No}

Development Friendliness Boolean

Installation Vectors

String {Multiple,

Restricted}

Application Portability

Boolean

Application Testing

Boolean

Application Removal

Boolean

Unofficial Repositories

Boolean

Distribution Cost

Boolean

API Restrictions

Boolean

Application Signing

Boolean

Developer’s Background Education Level

Development Time Number

4 IMPLEMENTATION OF A

MALWARE ATTACK

In this section the implementation of a malware

attack is presented, as a proof of concept study. The

SECRYPT 2011 - International Conference on Security and Cryptography

criteria defined in the previous section are applied to

evaluate the robustness and the security properties of

the smartphones platforms under examination.

Our study examines the implementation feasibili-

ty of a simple attack scenario (see Figure 1).

Figure 1: Case study attack scenario.

The attack scenario refers to a location tracking

malicious application. The application collects the

smartphone’s user GPS coordinates (i.e. her exact

position) and sends them to the attacker. It is assu-

med that the malicious functionality is included in a

free GPS navigation application. The application

apart from getting the user’s location and presenting

it using Google Maps, it also sends the location data

to the attacker server. The described malware, in

most cases, is executed without creating any suspi-

cion to a naive smartphone user. The reason for this

is that the application’s requests (i.e. access to devi-

ce location and Internet access to connect to the In-

ternet) are consistent with the application’s expected

functionality.

We have implemented our development case

study in our lab using two computers running a Win-

dows XP and a Mac OS Leopard operating system.

In the Windows machine we installed the emulators

and the SDKs of all the smartphone platforms, apart

from Apple’s iOS that was only compatible with

Mac OS X.

For the malware implementation we selected two

computer science students (one undergraduate and

one post-graduate student, respectively) with basic

information security background and moderate

programming skills. Before the case study imple-

mentation the students had successfully completed

information security related courses that are consis-

tent with the Common Body of Knowledge describ-

ed in (Theoharidou et al., 2008). The undergraduate

student had completed a course on Information

Security Management and the postgraduate had

completed the courses Information Security Mana-

gement, Information System Auditing, Network Se-

curity, and Cryptography. Both students were more

familiar with the Java programming language, since

this was the language used in implementations du-

ring undergraduate and postgraduate projects. The

post-graduate student would only be involved in the

proof of concept attack implementation in a smart-

phone platform only if the undergraduate was unable

to implement it.

In the following paragraphs we analyse the re-

sults regarding the development and use of this mali-

cious application to the smartphone platforms des-

cribed in Section 2 to check their security model

robustness to our attack scenario. The platforms that

we have examined are: Android OS, BlackBerry OS,

Symbian OS, Apple’s iOS and Windows Mobile 6

OS. The results of the case study are presented in the

sequel.

4.1 Android OS Case Study

Our attack implementation was successfully develo-

ped on the Android platform in one day. The official

development toolkit (i.e. SDK and emulator) was

used for the implementation purposes. The reasons

why our attack implementation was efficient are: a).

the adoption by the platform of a widely used prog-

ramming language (i.e. Java), and b). the effective

documentation of its API. In addition, the same

source code successfully compiled and executed in

versions 2.1 and 2.2 of the Android platform; hence

the application is considered portable within the An-

droid platform at the time of the writing.

Regarding application distribution there are ma-

ny options for the attacker. The reason for this is that

the Android platform does not impose any restriction

neither on the source of application (i.e. originating

from an unofficial repository) nor on the installation

vector (e.g. removable media, WWW, etc.). A small

registration fee is required for the placement of

applications in the official repository, but it is consi-

dered inadequate to impede an attacker. Furthermo-

re, even if the official repository is selected for the

distribution, application testing for malicious beha-

viour is not taking place. Hence, it is likely that mal-

ware such as one described in this case study is cur-

rently present and downloaded by naive users from

the repository.

As we have already mentioned the security

model of the Android platform imposes some appli-

cation restrictions concerning the application signing

and API control. We argue that these restrictions

provide only partial security protection. For the for-

mer, API control restrictions are authorized by the

naive user only during the application installation.

No further checks about application permissions

take place after the installation. Hence, it is likely

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case

that the malicious application would be granted the

requested permissions (i.e. access to location data

and the Internet), especially in our case, where the

permissions fully match the expected application’s

functionality. For the latter, the imposed signature

can be self-signed by the developer and as a result

the application’s source origin is not verified. This

situation, combined with the fact that an attacker

may find valid credit cards numbers in the under-

ground market, could be used to commence elite

spoofing attacks. These attack scenarios are out of

the scope of this paper. Finally, Google’s remote re-

moval mechanism is the only efficient post installati-

on protection mechanism against our case study

scenario.

From the above analysis we infer that the likeli-

hood of conducting such an attack on the Android

platform is very high. In this context, Table 2 sum-

marizes the results of our case study based on the

criteria we have defined in section 4.1.

Table 2: Android OS Analysis and Results.

Evaluation Criteria Android OS

Development Tools Availability

Development Friendliness

Installation Vectors multiple

Application Portability

Application Testing

Application Removal

Unofficial Repositories

Distribution Cost

API Restrictions

Application Signing

Developer’s Background B.Sc.

Development Time 0.5day

4.2 BlackBerry OS Case study

Regarding our attack analysis on BlackBerry plat-

form, the results were again successful. The attack

was conducted by the B.Sc. student. RIM’s official

development toolkit (i.e. SDK and emulator) was us-

ed for attack implementation. The attack implemen-

tation was not demanding and its duration was one

day. The reasons for the effectiveness of the attack

implementation are the adoption by the platform of a

widely used programming language (i.e. Java), and

the effective documentation of its API. Furthermore,

the same source code successfully compiled and

executed in versions 5/6 of the BlackBerry platform,

therefore the application is considered portable.

Τhe security model of the BlackBerry does not

impose any restrictions regarding the origin of the

application. Nevertheless, the application package

file (.cod) must be signed to access restricted and

sensitive platform APIs. For the signing process the

developer incurs a small key acquisition fee. As

there is no strong authentication in the key acquisi-

tion process, the signing of the application provides

only integrity protection and poor source origin.

The cost for the cryptographic keys is considered

inadequate to deter an attacker. On the other hand,

the cost for the publication is expected to impede an

attacker from publishing the application in the

RIM’s official repository, especially if she is in pos-

session of limited economic resources; the attacker

still has the option to submit an application to an

unofficial repository.

The security model of the RIM’s platform does

not employ any application testing before accepting

the submission of an application. Furthermore, there

is no application removal system automatically

removing applications with malicious behaviour.

Hence, if the malware application is submitted in the

official repository, then it is very likely to be down-

loaded and installed in BlackBerry devices.

Conclusively, the development of the malware

attack examined in this scenario is feasible and it de-

mands little development effort. The only impedi-

ment is the cost of submitting the application to the

official repository. Table 3, depicts the results of the

case study regarding Blackberry OS.

Table 3: BlackBerry OS Analysis and Results.

Evaluation Criteria BlackBerry OS

Development Tools Availability

Development Friendliness

Installation Vectors multiple

Application Portability

Application Testing

Application Removal

Unofficial Repositories

Distribution Cost

API Restrictions

Application Signing

Developer’s Background B.Sc.

Development Time 1 day

4.3 Symbian OS Case study

Symbian OS provides basic functionality sufficient

for application development providing the developer

the option to self sign her application. Nevertheless,

some compatibility issues exist, since the location

capability -which controls access to API determin-

ing the location of the device - does not reside in the

basic capability category in some Symbian OS

versions (Nokia, 2011a).

SECRYPT 2011 - International Conference on Security and Cryptography

For the deployment of the malware attack scena-

rio only the basic capability category was used. Self-

signed applications create a security warning at in-

stallation time that the user has to accept. Even so,

the user would likely accept the installation of the

application bypassing and ignoring the security war-

nings. Apart for signing the application, the security

model of the platform does not restrict the applica-

tion’s distribution and as a result the attacker has

many distribution options (e.g. through an attacker-

controlled application repository). Hence, the attac-

ker has the option to avoid distribution cost and the

Symbian Signed application testing. In addition,

Symbian will only be able to revoke the self-signed

certificate used in this case study, if Symbian beco-

mes aware of the malware binary existence.

The attack implementation was not successfully

completed in the Symbian platform. Even though the

implementation was performed with the officially

recommended development toolkits, the case study

developers were unable to compile their code. In ad-

dition, even the sample applications provided by

Symbian could not be compiled. The installation of

the development toolkit was fully automated and the

developers did not participate in its configuration.

Hence, the possibility of toolkit misconfiguration is

eliminated.

Table 4: Symbian OS Analysis and Results.

Evaluation Criteria Symbian OS

Development Tools Availability

Development Friendliness

Installation Vectors Multiple

Application Portability

Application Testing

Application Removal

Unofficial Repositories

Distribution Cost

API Restrictions

Application Signing

Developer’s Background M.Sc.

Development Time N/A

Furthermore, the developers faced other develop-

ment obstacles during our case study, namely inade-

quate structure in the platform’s API documentation

(e.g. encountered “file not found” links), and the fact

that they were not familiar with the platform’s prog-

ramming language. However, the obstacles reported

in this subsection are of a minor importance to an

experienced attacker; a case which is out of scope in

this paper. Hence, the above obstacles are likely to

deter unmotivated attackers from developing malwa-

re attacks. The results of the case study on Symbian

platform are presented in Table 4.

4.4 iOS Case study

The implementation of our simple location tracking

attack was successfully completed on Apple’s iOS.

The implementation lasted seven 7 days and was tes-

ted on emulators running iOS 3 (version 3.1.2) and

iOS 4 (version 4.1). The implementation duration

was expected a priori to last more than in the other

platforms due to no prior experience with Objective

C. However, the toolset provided by Apple (i.e.

SDK, documentation and emulator) minimized this

lack of experience. In Table 5 the relevant criteria

was assigned the value partial, since the provided

toolkit is available only to Mac OS X users.

The installation of applications to devices run-

ning the iOS system is only possible via Apple’s

App Store. Hence, unofficial application repositories

are not available for devices running the official ver-

sion of iOS. As a result, a malware author must sub-

mit the application to the official repository. The

submission of an application to the App Store requi-

res a non free registration to Apple’s development

program. Prior to the inclusion of an application in

the official repository it must be examined and sign-

ed by Apple. Nonetheless, the process of application

testing (e.g. static binary code analysis, dynamic

binary code analysis) is not available. The applica-

tion testing criteria are also not available, apart from

the rejection of not official Apple’s API usage. This

security mechanism may be circumvented by a sop-

histicated attacker using encrypted payloads and lo-

gic bombs on the binaries.

Table 5: iOS Analysis and Results.

Evaluation Criteria Apple’s iOS

Development Tools Availability partial

Development Friendliness

Installation Vectors restricted

Application Portability

Application Testing

Application Removal

Unofficial Repositories

Distribution Cost

API Restrictions

Application Signing

Developer’s Background M.Sc.

Development Time 7days

The user has no control on the application’s ac-

tions after the installation of an application in the

device. In addition, the user is not informed when

the application uploads data to a remote server. In

our case study, the user would only be prompted to

permit access to location data. But, as the applicati-

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case

on is providing location based services the user is

expected to confirm access to location data.

Afterwards, the data would be transferred to the

attacker’s remote server, without the user noticing it.

Apple has developed security mechanisms allow-

ing the remote deletion of malicious applications

from its devices and their removal from the applica-

tion repository. This is a significant post installation

security mechanism in case Apple or the user beca-

me suspicious of the malware software. The results

of the case study in iOS platform are depicted in

Table 5.

4.5 Windows Mobile 6 Case Study

The implementation of our location tracking applica-

tion on a Windows Mobile device was successfully

completed by the student in 2 days. The program-

ming language was C#. The reasons of the effective-

ness of the attack implementation are the adoption

by the platform of programming language, namely

C# that resembles the programming rationale of Java

and the effective documentation of its API.

The proof of concept malware software was im-

plemented for the versions of Windows Mobile 6.1

and 6.5 using the SDK provided by Microsoft. The

installation package of the application was not sign-

ed. During the implementation the default configura-

tion of the security model was preserved, in essence

that: (a). unsigned applications would be allowed to

run, (b). the user would be prompted to authorize the

application execution, and (c). if the application had

been authorized by the user it would have full access

to the smartphone’s OS system services.

The security model of Windows Mobile does not

impose restrictions on the installation vector of ap-

plications. Moreover, applications are able to be ins-

talled on the devices even if they are downloaded

from a source outside Microsoft’s official repository.

Hence, the attacker does not have application distri-

bution costs. Furthermore, the application is not

being tested for malicious behaviour, since it is not

distributed by Microsoft distribution services. None-

theless, the application removal mechanism, applied

by Microsoft, may be used for the automated

removal of the implemented malware application.

To sum up, the feasibility of our malware attack

in Windows Mobile depends on the device configu-

rations regarding the security model, the user autho-

rization at installation time and the automated appli-

cation removal security mechanism. Table 6

summarizes the results, w.r.t. Windows Mobile plat-

forms.

Table 6: Windows Mobile OS Analysis and Results.

Evaluation Criteria Windows Mobile

Development Tools Availability

Development Friendliness

Installation Vectors multiple

Application Portability

Application Testing

Application Removal

Unofficial Repositories

Distribution Cost

API Restrictions

Application Signing

Developer’s Background B.Sc.

Development Time 2days

4.6 Case Study Overview

The security model of a smartphone operating sys-

tem has two contradicting goals. On the one hand, it

must provide users with security assurance concer-

ning the execution of third-party applications on

their devices. On the other hand, it must provide the

developers with a secure system where on the one

hand, consumers are willing to install new applicati-

ons and on the other, it is easy and efficient to im-

plement new applications.

The proof of concept exercise demonstrated that,

under certain circumstances, the security model of

all available smartphone platforms would not coun-

ter a location tracking attack. Moreover, it showed

that it is possible to easily implement the attack on

all smartphone platforms, except from Symbian and

iOS.

The reasons of the implementation failure on

Symbian were not security related. They were rela-

ted with the developer’s programming skills and

Symbian’s unstructured API documentation.

The implementation in all other platforms was

efficiently and effectively completed by average

programmers and tested on the officially provided

emulators. Nonetheless, by using the API document-

tation most of the attacks were implemented by the

undergraduate student. This is a serious indication of

how malicious software can evolve in smartphones.

Application testing for malicious behaviour

cannot be avoided only on Apple’s iOS. Furthermo-

re, iOS was the only platform having strict instal-

lation requirements.

Among the examined platforms only Windows

Mobile allowed, under some security model configu-

rations, the execution of unsigned applications. Yet,

the digital signature process gives different security

assurance to the smartphone holder on the examined

platforms. The user was found, on the one hand, not

having any control on the API running in the device,

SECRYPT 2011 - International Conference on Security and Cryptography

Table 7: Malware scenario implementation overview.

Evaluation Criteria Android BlackBerry Symbian iOS

Windows

Mobile

SDK & simulator availability

9 9 9

partial

Development Friendliness

9 9 8 8 9

Installation Vectors multiple multiple multiple restricted multiple

Application Portability

9 9 8 9 9

Application Testing

8 8 8 9 8

Application Removal

9 8 9 9 9

Unofficial Repositories

9 9 9 8 9

Distribution Cost

8 9 8 9 8

API Restrictions

9 9

9 8 8

Application Signing

9 9

9 9 8

Developer’s Background B.Sc. B.Sc. M.Sc. M.Sc. B.Sc.

Development Time 0.5day 1 day N/A 7days 2days

on some platforms. On the other hand, the user is

fully responsible for authorizing application executi-

on on other platforms. The latter is identified as a

major weakness in the security model of some

smartphones platforms, since the user’s security

knowledge and awareness is often insufficient.

Only in two smartphone platforms an attacker

could not avoid distribution costs and only four of

them contained remote application removal mecha-

nisms. Table 7 summarizes our findings.

According to the case study findings, a non pro-

ficient attacker would not choose to use the iOS as a

privacy and security attack vector, since it is the

platform having the most defensive mechanism in

place (i.e. application testing, controlled application

installation vectors and remote application removal)

and being difficult in application development. An

attacker is expected to use one of rest platforms,

where, in this case study, Android and Windows

Mobile were found to provide the least protection

against our attack scenario.

5 CONCLUSIONS

Smartphone devices are multi-purpose portable devi-

ces enclosing a vast amount of third party applica-

tions that augment the device’s functionality. The

existing smartphone security models facilitate mec-

hanisms and processes controlling the installation

and execution of third party applications. Even so,

the sufficiency of the adopted security mechanisms

seems to be controversial. Their ability to protect the

devices from being a privacy attack vector from de-

velopers, such as undergraduate and postgraduate

computer science students, is proven to be unclear.

Our paper (a). proposes evaluation criteria

assessing the development of smartphone malware,

and (b). provides a comparative case study analysis

where the implementation and distribution of proof

of concept location tracking malware is attempted in

the current smartphone platforms.

Our proof of concept study has proven that under

circumstances all smartphone platforms would not

stop average developers from using them as privacy

attack vectors, harvesting data from the device

without the user’s knowledge and consent. It also

showed the easiness of malware application deve-

lopment by average programmers that have access to

the official tools and programming libraries

provided by smartphone platforms.

A silver bullet solution against similar attack

scenarios is not available. Some of the solutions that

can be used to avoid a potential malware outbreak in

smartphones are: (a) user awareness, i.e. informing

user about security and privacy risks in smartphone

platforms, and (b) providing secure application

distribution in smartphone platforms.

In this context our further work will focus on

providing a secure application distribution scheme

for smartphone applications. Moreover, we plan to

extend the evaluation criteria and attribute weights

to them. We also plan to repeat the case study with

more developers to acquire more generalizable

results.

ACKNOWLEDGEMENTS

This work has been partially funded by the European

Union (European Social Fund) and Greek national

funds through the Operational Program Education

SMARTPHONE SECURITY EVALUATION - The Malware Attack Case

and Lifelong Learning of the National Strategic

Reference Framework - Research Funding Program:

HE-RACLEITUS II - Investing in Knowledge

Society.

REFERENCES

Adleman, L. (1990). An Abstract Theory of Computer

Viruses. In S. Goldwasser, Advances in Cryptology —

CRYPTO’ 88 (pp. 354-374). Berlin: Springer/

Heidelberg.

Apple. (2011a). iOS Dev Center. Retrieved February 18,

2011, from http://developer.apple.com/devcenter/ios/

Apple. (2011b). iOS Developer Program. Retrieved

February 18, 2011, from http://developer.apple.com/

programs/ios/

CISCO. (2011). Cisco 2010 Annual Security Report.

Retrieved February 18, 2011, from http://

www.cisco.com/en/US/prod/vpndevc/annual_security

_report.html

Cohen, F. (1989). Computational aspects of computer vi-

ruses. Computers & Security, 8(4), 325-344.

Gartner. (2010). Gartner Press Releases. Retrieved

February 18, 2011, from http://www.gartner.com/it/

page.jsp?id=1466313

Gartner. (2011). Gartner Press Releases. Retrieved

February 18, 2011, from http://www.gartner.com/it/

page.jsp?id=1529214

Google. (2011a). Exercising Our Remote Application

Removal Feature. Retrieved February 18, 2011, from

http://android-developers.blogspot.com/ 2010/06/

exercising-our-remote-application.html

Google. (2011b). Platform Versions. Retrieved February

18, 2011, from http://developer.android.com/

resources/ dashboard/platform-versions.html

Google. (2011c). Security and Permissions. Retrieved

February 18, 2011, from http://developer.android.com/

guide/topics/security/ security.html

GSMA. (2011). Mobile Privacy. Retrieved February 18,

2011, from http://www.gsmworld.com/our-work/

public-policy/ mobile_privacy.htm

Hogben, G., Dekker, M. (2011). Smartphone security:

Information security risks, opportunities and recom-

mendations for users. Retrieved from:

http://www.enisa. europa.eu/act/it/oar/ smartphones-

information-security-risks-opportunities-and-

recommendations-for-users/at_download/fullReport

Hypponen, M. (2006). Malware goes mobile. Scientific

American, 295(5), 70-77.

Kephart, J., White, S. (1991) Directed graph epidemiologi-

cal models of computer viruses. 1991 IEEE Symposi-

um on Research in Security and Privacy, 343-359.

Lineberry, A., Richardson, D., Wyatt, T. (2010). These

aren’t the permissions you ‘re looking for. Retrieved

from https://www.defcon.org/images/defcon-18/dc-18-

presentations/Lineberry/DEFCON-18-Lineberry-Not-

The-Permissions-You-Are-Looking-For.pdf

McAfee. (2010). 2011 Threats predictions. Retrieved from

http://www.mcafee.com/us/resources/reports/rp-threat-

predictions-2011.pdf

Microsoft. (2010a). Security Policy Settings. Retrieved

February 18, 2011, from http://msdn.microsoft.com

/en-us/library/bb416355.aspx

Microsoft. (2010b). Windows Mobile Code Signing.

Retrieved February 18, 2011, from

http://msdn.microsoft.com/en-us/windowsmobile/

dd569132.aspx

Microsoft. (2010c). Windows Mobile Device Security

Model. Retrieved February 18, 2011, from http://

msdn.microsoft.com/en-us/library/ bb416353.aspx

Microsoft. (2010d). Windows Phone 7 Series Developer

General FAQ. Retrieved February 18, 2011, from

http://social.msdn.microsoft.com/Forums/en/windows

phone7series/thread/2892a6f0-ab26-48d6-b63c-

e38f62eda3b3

Nokia. (2011a). Capabilities. Retrieved February 18,

2011, from http://wiki.forum.nokia.com/index.php/

Capabilities

Nokia. (2011b). Developer certificate. Retrieved February

18, 2011, from http://wiki.forum.nokia.com/index.php/

Developer_certificate

Nokia. (2011c). Symbian Signed. Retrieved February 18,

2011, from https://www.symbiansigned.com/app/page

PAMPAS. (2011). Pioneering Advanced Mobile Privacy

and Security. Retrieved February 18, 2011, from

http://www.pampas.eu.org/

RIM. (2011d). Java Code Signing Keys. Retrieved

February 18, 2011, from http://us.blackberry.com/

developers/javaappdev/codekeys.jsp

RIM. (2011e). Security Overview. Retrieved February 18,

2011, from http://docs.blackberry.com/en/developers/

deliverables/21091/Security

_overview_1304155_11.jsp

Seriot, N. (2010). iPhone Privacy. Retrieved from http://

seriot.ch/resources/talks_papers/iPhonePrivacy.pdf

Sindhu, U., Balaouras, S., Hayes, N., Coit, L. (2010). The

Security of B2B: Enabling An Unbounded Enterprise.

Retrieved February 18, 2011, from

http://www.forrester.com/rb/Research/security_of_b2b_en

abling_unbounded_enterprise/q/id/56670/t/2

Smartphone Experts (2011). CrackBerry.com – The #1

Site for BlackBerry Users & Abusers. Retrieved

February 18, 2011, from http://crackberry.com/

Sophos (2011). Pirated Mac App Store apps pose major

risk. Retrieved February 18, 2011, from

http://nakedsecurity.sophos.com/2011/01/07/app-store -

developers-leave-purchased-apps-vulnerable-to-piracy/

Symbian Freak. (2011). S60 3

ed. FP1 Hacked!

Retrieved February 18, 2011, from http://www.

symbian- freak.com/news/008/03/s60_3

_ed_has_

been_hacked.htm

Theoharidou, M., Xidara, D., Gritzalis, D. (2008). A Com-

mon Body of Knowledge for Information Security and

Critical Information and Communication Infrastructu-

re Protection. International Journal of Critical Infra-

structure Protection, 1(1), 81-96.

Weiser, M. (1991). The computer for the 21st century.

Scientific American, 265 (3), 94-104.

SECRYPT 2011 - International Conference on Security and Cryptography
