ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR

THE DEVELOPMENT OF COMPLEX, CRITICAL AND

FAST-CHANGING ENTERPRISE SOFTWARE

Marcos Vescovi

Finansolo Software, PO Box 847, Aptos, CA 95001, U.S.A.

Flavio Varejão

Departamento de Informática, Universidade Federal do Espirito Santo, Vitória, ES 29000, Brazil

Vagner Cordeiro

Finansolo Software, PO Box 847, Aptos, CA 95001, U.S.A.

Keywords: Agile methods, Scrum methodology, Software design, Software entropy, Change curve.

Abstract: A class of complex enterprise software including financial, taxation and supply chain management software

contains mission critical functionality and change requests are substantial and frequent. Agile

methodologies provide the adaptability but not the robustness necessary to deal with the criticality and to

avoid software entropy. Task analysis shows that a significant effort of analysis and design is required to

flatten the change curve. The Robust Agile Methodology, “R-Agile,” is proposed with the adaptability to

handle fast-changing requirements, and the design and test necessary to handle complexity and criticality.

1 INTRODUCTION

Boehm and Turner (2003) suggest that risk analysis

be used to choose between adaptive Agile and

predictive Plan-driven methodologies. The authors

suggest that each side of the continuum has its own

home ground. The Agile methodologies are well

suited for low criticality software with frequent

change of requirements, and the Plan-driven

methodologies are well suited for high criticality

software with stable requirements. Over the past

decade we have been developing enterprise software

for Fortune 500 and e-Commerce companies

presenting both challenges: high criticality and

frequent change of requirements. Additionally, and

more importantly, we had to deal with complexity

and the risk of software entropy. Software entropy is

a state reached over time as less well designed

software becomes harder and harder to change. At a

point, the cost of certain changes can become so

high that they are not worth undertaking.

In order to cope with these challenges, we have

successfully developed an adaptation of the Scrum

Agile Methodology. We have taken advantage of the

adaptability and have added design and test to

robustify the methodology. The change curve says

that as the project runs, it becomes exponentially

more expensive to make changes. In this paper we

focus on design and argue that a substantial effort is

necessary to flatten the change curve.

In section 2, we discuss the suitability of

traditional Plan-driven and Agile methodologies. In

section 3, we present the characteristics of critical

and fast-changing complex enterprise software. In

section 4, we discuss the key role of analysis and

design for flattening the exponential change curve.

In section 5, we present the Robust Agile

Methodology “R-Agile,” a more robust and agile

methodology. We close with the conclusions.

Vescovi M., Varejão F. and Cordeiro V..

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL AND FAST-CHANGING ENTERPRISE

SOFTWARE.

DOI: 10.5220/0003459800700079

In Proceedings of the 6th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2011), pages 70-79

ISBN: 978-989-8425-57-7

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2 SUITABILITY OF

METHODOLOGIES

In this section, we briefly discuss and summarize the

advantages and drawbacks of Plan-driven and Agile

methodologies. More extensive comparisons can be

found in the work of Boehm and Turner (2003) and

Fowler (2001), who focus on design and discuss

planned vs. evolutionary design.

2.1 Plan-Driven Methodologies

Traditional Plan-driven methodologies, such as the

waterfall method (Royce, 1970), are based on the

principle that time spent early in the software

production cycle can lead to greater economy at later

stages. McConnell (1996) shows that a bug found in

the early stages (such as requirements specification

or design) is cheaper in money, effort and time to fix

than the same bug found later on in the process.

With Plan-driven methodologies, a substantial

effort of analysis and design is performed up front.

This is an important advantage of the Plan-driven

methodologies, leading towards a flatter change

curve and potentially avoiding software entropy.

Another advantage relates to the extensive testing

phase which is necessary to ensure correct

functioning of mission-critical functionality. These

advantages are well-suited to handle complexity and

criticality of functionality.

The main drawback of the Plan-driven

methodologies is related to the long release cycles.

Most of the design is performed without learning

from later phases of development and operations.

With shorter cycles, a lot can be learned from

usability and incorporated into the design. Design is

usually longer than needed and many unnecessary

features are included in the project. The project costs

more and takes a much longer time to market, which

impacts business negatively. Customers most often

get involved later in the process when a full-

packaged release is available.

Besides the above inconveniences, the Plan-

driven methodologies are not well-suited and

adaptable for fast changing requirements software.

The design and overall project is rigid and

requirement changes are not welcome.

2.2 Agile Methodologies

Larman and Basili (2003) present a brief history of

iterative and incremental development, showing that

adaptive methods have been proposed since the

1970s. The "Manifesto for Agile Software

Development" was published by Kent et al. (2001).

The Agile methods promote development,

teamwork, collaboration, and process adaptability

throughout the life-cycle of the project. Such

methods became popular in the past decade, in

particular with fast paced web development.

Agile methods propose much shorter release

cycles, allowing quick feedback and adaptation. The

process involves customers more often, which

results in increased customer satisfaction.

Developers are empowered, feel more responsible

and become better contributors. Agile methods are

particularly well-suited for fast-changing

requirements software.

The main inconvenience with the Agile methods

is associated with decreased analysis and design,

which can result in software entropy and exponential

change curve. This is especially true in the case of

complex and large software. Another drawback is

that the reduced testing phase may not be sufficient

to ensure the quality necessary for mission-critical

functionality.

In summary, Plan-driven methods are better

suited for critical and complex software while Agile

methods are better suited for software requiring fast

changes. A methodology for dealing simultaneously

with complexity, criticality and adaptability is

sought. This paper proposes such a methodology.

3 COMPLEX, CRITICAL

AND FAST-CHANGING

SOFTWARE

Over the past decade we have developed enterprise

payment and financial software, supply chain

management and taxation software for several

Fortune 500 and e-Commerce companies world-

wide. The specific products and solutions developed

were functionally different but shared similar

characteristics. The most relevant characteristics are

presented below. For simplicity, we are not

discussing the additional complexity associated with

the enterprise requirements of performance,

scalability, robustness and security.

1. Large number of objects for modeling the

domain;

2. Complex relationships between the objects;

3. Complex calculations and processing methods;

4. Substantial and frequent change of

requirements;

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL

AND FAST-CHANGING ENTERPRISE SOFTWARE

5. Tight deadlines, limited resources and pressure

from customers;

6. Mission critical operations dependent on the

software.

The first two characteristics have implications on

the size and complexity of the objects and data

model. Without careful analysis and design, objects

and database schemas became large and overly

complex. Coding became more difficult and bugs

became more numerous and harder to find and fix.

Extensions and modifications became exponentially

expensive. Changes in data and object models were

usually deep and came at a higher cost. In our

experience, the tasks of abstraction and

generalization of concepts were necessary to

simplify the model and required substantial analysis

and design. Without this effort, complexity takes

over and the change curve becomes exponential.

The third characteristic relates to the complexity

of calculations and processes. Billing, revenue

sharing and taxation are common examples of

calculations in which the effort to define the

mathematics required as much effort as coding itself.

The consequences of careless analysis and design

were often buggy implementations requiring various

iterations to fix. The iterations were costly,

involving various releases and testing phases. In our

experience, non-modular design created the typical

scenario of gas plant complexity, which was hard to

understand, extend and fix. In order to accommodate

for customer requests, branching became the faster

and easier solution. But maintenance of the various

branches came at a prohibitive cost. The complexity

and its related costs were again exponential.

The fourth characteristic is also challenging. In

our experience, the change of requirements was

frequent and continuous for a single system and each

customer wanted something different. If there was

no change of requirements we could have

envisioned various steps of refactoring, thus

improving the design over time. But the continuous

change on top of the issues described with the first

three characteristics made development harder.

Carefully designing a system for extensive change

was the key to flatten the change curve. Besides

using well architected frameworks, in some cases we

used domain models, rule engines and workflow

engines to deal with the frequent change of

requirements. Up-front design was necessary to

develop such architectures.

The fifth and sixth characteristics simply added

stress to the development team. This paper describes

a methodology combining the best practices of the

Agile and the Plan-driven methodologies. We focus,

in particular, in adding analysis and design to the

Agile Methodology, which relates more directly to

characteristics 1 through 4 above. In order to deal

with the implications of characteristics 5 and 6,

other issues need to be examined. First, there has to

be resolution around the deadline-milestone

prevailing in the industry. Either the customers need

to agree to the more adaptable Agile methodologies

or some rigidity and predictability need to be added

to the methodologies. Another important issue

relates to the stricter testing necessary to ensure

correct functioning of critical functionality.

Although the proposed methodology contains the

necessary testing component, this paper focuses on

the need for further analysis and design and how it

has been balanced within the proposed

methodology.

4 THE ROLE OF ANALYSIS

AND DESIGN

We have experienced an exponential change curve

on various occasions, in particular when fast

development took priority and did not allow for

careful analysis and design. This happened despite

the fact that our engineering team was composed of

talented Silicon Valley developers. In such cases,

changing or enhancing the system became

prohibitively expensive and some of the systems had

to be redesigned and rebuilt.

According to Fowler (2001), Agile methods have

rejuvenated the notion of evolutionary design with

practices that allow evolution to become a viable

design strategy. It also provides new challenges and

skills as designers need to learn how to do a simple

design, how to use refactoring to keep a design

clean, and how to use patterns in an evolutionary

style. Simplicity is at the core of the Agile

methodologies. We argue that achieving Simplicity

in a more substantial way that can avoid software

entropy requires a significant effort of analysis and

design.

The definition of Simplicity proposed by Beck

(1999) is, in order (most important first):

1. Runs all the tests

2. Reveals all the intention

3. No duplication

4. Fewest number of classes or methods

If we further investigate the criteria above we see

that Simplicity (as defined by Beck), especially in

the case of complex enterprise software, can only be

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

achieved in a more substantial way with careful

analysis and design, contrasting with the "quick code

and test" premises of the Agile methodologies. Let’s

examine the criteria.

1. Runs all the tests

This is a Basic Requirement that a system must

verify its intended functionality. This is minimal and

required for most methodologies so we will not

analyze this any further.

2. Reveals all the intention

This is an Adequacy Requirement and should be

required for most methodologies as well. Fulfillment

of this requirement is often intuitive and is

ultimately defined by customer satisfaction. But for

a system to reveal all the intention, it must at least

have a complete model (i.e. it must cover the

functionality) that can lead to accurate enough and

precise enough results (i.e. the results must be

acceptable). In terms of coding, the underlying

model must be intuitive and clean so that

communication and collaboration can happen. In

terms of usability, careful interaction and graphical

design must also be realized. As we can see, this

criterion is not obvious to achieve and we find it

difficult to be realized without careful analysis and

design.

3. No duplication

This is an Optimization Requirement desirable in

other methodologies as well. No Duplication

requires the creation of modular code so that it can

be reused. The idea is to have more fundamental

building blocks that are used to build the system.

If we interpret this criterion as not duplicating

code in its most strict definition, i.e. not repeating

code that is exactly the same, then the criterion is

relatively easy to understand and follow. However, a

more powerful and interesting interpretation of the

criterion is the creation of more generic and abstract

code that can be used to replace similar (and more

numerous) pieces of code.

If we perform Cognitive Task Analysis

(Chandrasekaran, 1986), (Chandrasekaran, 1990),

(Pirolli & Card, 2005), we see that the design of

modular code that is generic and abstract to be

reused, involves the following mental tasks: (1)

decomposition of the problem into smaller

functional or structural parts, (2) pattern matching to

identify sets of similar parts, (3) creativity to create

generic and abstract modular code to cope with sets

of similar problem parts, (4) synthesis for combining

and integrating the modular code, (5) analysis for

critiquing the modular code and its integration, and

(6) modification capability for adjusting the modular

code and its integration whenever necessary.

No duplication, in its more extensive

interpretation, is underlying the construction of

frameworks and is at the core of software

architecture. Except for simpler software, it is

difficult to imagine the achievement of this criterion

without careful analysis and design.

4. Fewest number of classes or methods

The most basic interpretation of this criterion is that

classes and methods that are not necessary should

not be developed in advance. Classes and methods

that might be needed in the future should not be

implemented until they are definitely needed. This

criterion accords to the fundamental principles of the

Agile methodologies and is not too difficult to

interpret and follow.

However, a different interpretation of this

criterion has a fundamental impact when dealing

with complex software. In order to cope with the

complexity associated with the large number of

classes, their relationships and their complex

methods, it is important to design fewer but more

powerful classes and methods. It is necessary to

define classes and methods that are generic and

often abstract. Fewer generic and abstract classes

can replace multiple and more numerous specific

and concrete classes, simplifying the overall

representation. Fewer modular generic and abstract

methods can replace multiple and more numerous

specific and concrete methods as well, once again,

simplifying a complex problem. Design patterns, for

example, although more complex constructs

themselves, are powerful mechanisms that simplify

the overall design.

The examples above are just a few examples of

interpreting the criterion as creating fewer but more

powerful concepts. We claim that the design of these

fewer but more powerful concepts is crucial to deal

with complexity. But this task, once again, requires

significant effort. Cognitive Task Analysis

(Chandrasekaran, 1986), (Chandrasekaran, 1990),

(Pirolli & Card, 2005), indicates that such design

involves (1) pattern matching to identify sets of

similar classes or methods, (2) creativity to create

generic and abstract classes and methods, (3) search

on the space of possible design alternatives, (4)

definition of criteria for evaluating the design

alternatives, (5) synthesis and integration of classes

and methods and (6) critique and modification of

classes and methods. This is among the hardest tasks

in complex software development and requires

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL

AND FAST-CHANGING ENTERPRISE SOFTWARE

careful analysis and design.

As a result, in the case of complex software,

Simplicity requires a significant amount of analysis

and design. The more complex the system, the more

analysis and design it requires. In some cases, it is

arguable that the analysis and design effort required

is comparable to, if not greater than, the coding

effort.

5 FLATTENING THE

EXPONENTIAL CURVE

Fowler (2001) proposes that the practices of

continuous integration, testing, and refactoring

provide a new environment that makes the

evolutionary design of Agile methodologies become

plausible. But he adds that design is important to

flatten the curve. In Fowler´s words, "I'm sure that,

despite the outside impression, XP isn't just test,

code and refactor. There is room for designing

before coding. Some of this is before there is any

coding, most of it occurs in the iterations before

coding for a particular task. But there is a new

balance between up-front design and refactoring".

The criteria of Simplicity proposed by Beck

(1999) are clearly necessary to flatten the change

curve and avoid software entropy. In the previous

section, we examined the effort associated with

achieving Simplicity and showed that in the case of

complex software development, a significant amount

of analysis and design is necessary.

The short release cycles and the customer

involvement of the Agile methodologies provide

significant decrease in overall project effort and

increase in customer satisfaction. However, it is

important to add more analysis and design to the

methodology. But the difficulty is in finding the

right balance.

Figure 1 below shows the change curve for

options (1) Agile without additional design, (2)

Substantial upfront design, and (3) additional design

during iterations. Option 1 corresponds to the more

radical Agile methodologies with minimal design

effort. With option 2, substantial design is

performed up-front before coding. This is similar to

traditional Plan-driven methodologies in which the

software is more fully designed up-front. Option 3

corresponds to adding more design during each

iteration (release cycle) of the Agile methodologies.

Figure 1: Examples of change curves of Agile methods

based on the amount of design performed.

The curves showed in Figure 1 are qualitative

and were estimated based on our experience. Curve

(1) starts almost flat and then grows exponentially.

Curves (2) and (3) are linear approximations

assuming design was able to flatten the exponential

curve. In reality, these are flattened exponentials and

not lines. Option (1) has the advantage of short time

to market which is crucial in today’s web industry

but shows exponential behavior in the long run.

Option (2) is the most long term efficient option but

has longer time to market. Option (3) appears as a

good compromise between time to market and long

term efficiency.

The methodology that has worked best in our

experience is similar to option (3). Design has been

added to each cycle of the Scrum Agile

Methodology. Note that in our case we had

reference implementations with framework

architectures previously developed. For a

development effort starting from scratch it may be

necessary to develop a reference implementation.

The reference implementation defines architecture,

application server, framework, domain model and

whatever is necessary to cope with complexity. Such

reference implementation can be developed either in

advance, when time permits, or in parallel with

Option (1). In the latter case, an effort of integration

is necessary to move the code implemented faster

with the Option (1) model into the further

architected reference implementation. But we

strongly suggest developing the reference

implementation using the principles of Agile. If a

framework is to be developed then the necessary

functionality should be developed first. The

remaining functionality should only be developed if

necessary. Substantial refactoring of the framework

should also be considered, as suggested with Agile

methodologies.

6 THE ROBUST AGILE

METHODOLOGY

This section presents the Robust Agile Methodology,

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

“R-Agile.” For the past few years, we have

successfully used this methodology to develop

critical and fast-changing complex enterprise

software. Applications of our software include:

payment, revenue sharing and billing solutions for

the telecom and e-commerce industries; and order

management, taxation, logistics and financial

solutions for the supply chain industry.

The proposed methodology is a modified version

of the Scrum Agile Methodology (Beedle et al.,

1999). The fundamental change is that we have

included additional analysis and design to make the

methodology more robust

. We have also

complemented Scrum by adding a dedicated Testing

Team. In this section we will present more details of

the methodology, mostly highlighting the points

where our methodology differs from traditional

Scrum. Notice that the parameters of the

methodology, such as sprint duration and

chronology, ratio of team members and even more

structural elements of the methodology, can be

adjusted based on the specifics of the project. For

example, the criticality of the software, whether

mission or revenue critical, importance of time to

market, availability of resources and project budget

are factors that affect the parameters of the

methodology. The methodology described below is

the one that worked best in our overall experience.

6.1 Teams and Roles

We have added dedicated Design and Testing Teams

to the more traditional Product and Coding Teams of

the Scrum Methodology. We present below the

composition and the role of each team.

6.1.1 Product Team

The company can have various scrums running in

parallel. We had the experience of running about 2

to 3 simultaneous scrums. Running Agile methods

on very large projects can be challenging, requiring

special coordination and scaling strategies. These

experiences have been reported by Talby et al.

(2006) and Chow & Cao (2008). In this paper we

will concentrate on small to mid-size projects (< 20

developers) where the methodology works fine

without special treatment. We will describe the team

composition and roles for each Scrum.

Although the company can have multiple

product managers, we used one product manager per

Scrum. The product manager is called the “product

owner” and is responsible for making sure that the

product under development fulfills the business and

company requirements. The product manager

interfaces with the customers who can be external or

internal to the organization.

We had Scrums that required more than one

product manager. In such cases, the product

managers collaborated within the same Scrum but

one of the product managers was considered the

product owner for the Scrum. The product manager

also coordinates with the product managers of the

other Scrums so that the overall product integrates

well.

6.1.2 Design Team

The Design Team is dedicated to analysis and

design. The goal is to keep the code clean and as

simple as possible according to the definition of

Simplicity discussed in previous sections. The team

is responsible for the analysis and design required to

flatten the change curve, which is critical for

complex enterprise software development. In

addition to designing for Simplicity, the Design

Team is responsible for reviewing the code and

identifying parts that are candidates for Refactoring.

Although analysis and design are being added, it

is important to avoid overdesign. The design task

itself should follow the principles of Agile, by

designing at the necessary level. We suggest a

generalization of the suggestions proposed by

Fowler (2001). The Design Team should (1) invest

time in learning about analysis and design principles

and methods, (2) concentrate on when to apply such

principles and methods (not too early), (3)

concentrate on how to implement them in its

simplest form first, adding complexity later when

necessary, and (4) not hesitate in removing

overdesigned parts.

We have used one software designer for a team

of 4-6 developers. The exact number depends on

many factors including the maturity of the project,

the maturity of the team, the complexity of the

project and other factors. We can cite a few reasons

why we were able to design successfully using a

relatively small ratio of designer/developer: (1)

following the Agile principles and only designing

what was necessary, (2) the Coding Team was also

responsible for design, (3) often part of the Coding

Team is working on less complex or repetitive parts

of the code which do not require additional design

by the Design Team, and (4) later phases of the

project often require less design. Software architects

are a key part of the Design Team. In addition, the

team can include a few specialists, such as user

interface designers, a modeling analyst responsible

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL

AND FAST-CHANGING ENTERPRISE SOFTWARE

for data and process modeling, and a database

optimization analyst.

We have also experimented with rotating the

members of the Design Team. We usually strike a

balance considering the following factors: (1) level

of design and architecture experience, (2) project

phase, and (3) the need to have members of the

Coding Team also involved with design. The

rotation was interesting in many ways. It caused the

developers to feel more responsible and empowered.

It also allowed the primary designers and architects

to code, keeping them up-to-date with the

programming technologies. Learning by design is a

powerful learning tool (see research by Pappert &

Harel (1990)). In general, the rotation promoted

collaboration and avoided hierarchy and other

human relational issues.

6.1.3 Coding Team

The Coding Team has the responsibility to deliver

the product. The team is mostly responsible for

coding, but is also responsible for design, testing (in

particular unit testing), technical communication and

release.

Continuous integration is an important activity

for Agile methods. Scripts are developed to

automate code check-out, compilation, release

generation and to run test scripts. We were not

always able to implement continuous integration,

but the activity was very rewarding when

implemented. The continuous integration was

usually executed on a daily basis. When resources

are available, a dedicated Release Team should be

responsible for the continuous integration. In our

case it was implemented collaboratively by the

Coding and Test Teams.

One important member of the Coding Team is

the Scrum Master whose primary role is to make

sure that the developers are performing according to

the plan and do not get stuck. The Scrum Master

also ensures that the Scrum process is used as

intended. The Coding Team is usually composed of

4-8 developers, plus the Scrum Master. When time

permits, the Scrum Master can also code.

6.1.4 Testing Team

The Testing Team is a team dedicated to testing, the

same as traditional quality assurance teams. In the

case of mission critical systems, it has been

challenging to apply the “do only the minimal”

principle of the Agile Methodology to testing. We

were able to separate parts of the system that were

not critical, but the core required rigorous quality

assurance. We were also able to reduce the amount

of automated testing. Our Testing Team was

composed of 2 engineers for a team of 4-8

developers. Once again, this parameter will depend

on the specifics of the project at hand.

6.2 Activities and Schedule

One of the most important aspects of the Agile

methodologies is the much shorter release cycles

than traditional Plan-driven methodologies. In

Scrum, such release cycles are called Sprint. We

have had experience with both packaged releases

and incremental improvements. In the first case, we

had contractual obligations to release a particular set

of functionalities to external customers. The latter

case allowed for the release as improvements were

developed and fits more naturally with the Scrum

methodology. But even in the first case, we used the

Scrum methodology, thus generating shorter internal

releases and providing packaged releases at longer

cycles. What was important in this case was a close

relationship and agreement with the customer to

define the appropriate milestones for the packaged

releases, as the Scrum methodology avoids defining

long term plans in advance.

We have mostly worked with 2-week Sprints,

but have experimented also with 3-week Sprints.

The 2-week Sprint is more dynamic, allowing faster

time to market and market feedback. However, it

can feel tight, in particular before project

stabilization or when dealing with complex mission-

critical functions which are harder to implement and

require full testing. We experienced most difficulties

and pressure during the last two days of the 2-week

Sprint when we performed integration testing and

associated bug fixing and regression testing. When

we were able to do it, continuous integration

definitely helped to ease the process. It is also

important to check with the team in order to decide

on 2 or 3-week Sprints. The personality and style of

the team can affect the decision.

Table 1 shows the activities and schedule of the

R-Agile Robust Agile Methodology. It presents the

activities associated with each of the Product,

Design, Coding and Testing Teams and can be used

for either 2 or 3 week Sprints. The second week of a

3 week Sprint is simply a continuation of the

activities started in the first week.

A key aspect of the proposed R-Agile Scrum

Methodology is related to the temporal relationship

and sequencing of the activities. The main activities

of the Product and Design Teams, which are

Specification and Design respectively, happens one

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

Table 1: R-Agile Scrum Methodology with 2-3 Week Sprint Release Cycle.

Sprint First Week

Team Monday Tuesday Wednesday Thursday Friday

Product

Specification

Sprint n+1

Design

Design Review

Sprint n

Design

Sprint n+1

Coding

Design Review

Sprint n

Code

Sprint n

Testing

Code Test

Scripts

Sprint n

Test

Sprint n

Sprint Last Week

Team Monday Tuesday Wednesday Thursday Friday

Product

Review and

Sign-off

Sprint n

Planning

Sprint n+1

Design

Review

Sprint n

Planning

Sprint n+1

Coding

Integration

Sprint n

Review and

Push Production

Sprint n

Planning

Sprint n+1

Testing

Final Test

Sprint n

Review

Sprint n

Planning

Sprint n+1

Sprint before Coding. During a 2 (or 3) week period,

while the Coding Team is programming the features

of Sprint n, the Product and Design Team are

respectively specifying and designing for the

following Sprint n+1. This gives the Product and

Design Teams enough time to prepare their activities

before the beginning of Coding.

The Testing Team, on the other hand, performs

testing of the features of Sprint n during the same

Sprint n. The Testing Team starts developing the test

scripts early in the Sprint. Ideally, the test scripts get

developed before the corresponding code. This way,

the code can be tested as it gets implemented. Code

and test during the same Sprint can feel stressful, but

it allows the developers to fix bugs while the code is

still fresh in their minds. We have experimented

with testing executed one Sprint after the Coding

Sprint. It certainly provided more ease for the

Testing Team, but had the inconvenience of having

developers fixing bugs of the previous Sprint n-1

during Sprint n. In addition, we had to manage two

releases of the same features: the testing release at

the end of Sprint n and the production release at the

end of Sprint n+1.

In the remainder of this section we summarize

the main activities involved in the Scrum.

6.2.1 Specification

As described above, the Specification activity is

performed one Sprint ahead of its corresponding

Coding Sprint. Before starting the specification

activity, the product owner is responsible for

defining and prioritizing the desired product features

and adding them to the Product Backlog. Each

feature is described by a story and each story is

specified with enough details so that the Design and

Coding Team can understand it.

6.2.2 Design

Design is also performed in the previous Sprint n-1.

The Design Team chooses the stories which require

design from the Product Backlog according to their

priority. The Design Team can also spend time

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL

AND FAST-CHANGING ENTERPRISE SOFTWARE

reviewing the code and identifying areas for

redesign and refactoring.

6.2.3 Planning

The Planning activity sets the beginning of the

“official” Sprint. Planning is performed on a Friday.

One reason for this is so that Sprints can finish with

a Production Release on a Thursday. This allows for

any emergency repair of a release to be performed

on a Friday and not during the weekend.

An entire day is devoted to Planning and is split

into two meetings. During the first meeting the

engineers learn about the stories and choose which

ones to implement, taking into consideration the

priority set by the product owner. The chosen stories

are placed in the Sprint Backlog. During the second

meeting, the engineers break down the stories into

tasks that must be coded. The tasks are split among

the developers, making sure that they can be

completed during the Sprint.

6.2.4 Design Review

The Design Review activity is executed on a

Monday and can even be extended if necessary.

During this meeting, the Design Team discusses the

design (which was performed during Sprint n-1)

with the Coding Team. Only the developers

involved with the designed parts are mandated to

participate in the Design Review meeting. But in

some cases we involved other developers. This was

important so that more developers could learn about

the design. Developers often needed to understand

the design for a future Sprint and it saved everyone’s

time to have the design review done once. There was

also valuable feedback from the developers who, in

addition, felt more involved and empowered.

6.2.5 Coding

The Coding Team has about 7 full days (in the case

of a 2 week Sprint) to code, check in, unit test,

integrate code and fix bugs related to the tasks

committed during the Sprint Planning activity. Since

the release cycles are short, we decided that only

mission critical and revenue-affecting bugs and

feature requests could interrupt a Sprint. As

discussed, the Coding Team can also perform design

of their respective tasks, of course in coordination

with the Design Team and following the minimalist

principle of Agile.

6.2.6 Testing

The Testing Team participates on the Sprint

Planning activity. During the first meeting of the

Planning activity, the Testing Team learns about the

features to be implemented during the Sprint. This

allows the Testing Team to produce test scripts for

such features. During the second meeting of the

Planning activity, the Testing Team defines and

schedules the testing tasks to be executed during the

Sprint. These testing tasks are planned and executed

in the same way as the coding tasks of the Scrum.

The Testing Team can also participate on the

Monday Design review. This is important especially

if the Testing Team is to perform white-box testing,

which requires testing algorithm paths and their

efficiency.

The testing tasks are composed of tasks for

coding or for running test scripts. The Testing Team

starts coding the test scripts on Monday. Since test

scripts are usually coded faster than the actual code

to be tested, the code can be tested as soon as it gets

implemented. But we tended to spend a few days to

create a batch of test scripts before beginning code

testing around Thursday. This allowed the Testing

Team to focus on either coding or testing and

avoided too much back and forth between the two

activities. This can be planned based on what the

team feels comfortable with and also based on the

specific Sprint.

6.2.7 Review

On Thursday of the last Sprint week, an informal

Sprint Review is performed to make sure that the

implementation meets the requirements. The code is

pushed to production if signed-off by the product

owner. A Sprint Retrospective can also be organized

at times to evaluate the overall methodology and

propose improvements.

7 CONCLUSIONS

We performed Cognitive Task Analysis to show that

substantial analysis and design is necessary to create

powerful code and avoid software entropy and

exponential change curve. We have also discussed

the more extensive testing necessary for critical

functionality and the need for adaptability to handle

fast change requirements. We have presented R-

Agile which is a robust and agile methodology to

handle complexity, criticality and adaptability. We

have successfully employed R-Agile to develop

ENASE 2011 - 6th International Conference on Evaluation of Novel Software Approaches to Software Engineering

financial, taxation and supply chain management

enterprise software.

REFERENCES

Beck, K., 1999. Extreme Programming Explained:

Embrace Change, Addison-Wesley Professional;1999.

Beck, K.; et al., 2001. Manifesto for Agile Software

Development. Agile Alliance. In website: http://

agilemanifesto.org.

Beedle, M., Devos, M., Sharon, Y., Schwaber, K.,

Sutherland, J., 1999. Scrum: An Extension Pattern

Language for Hyperproductive Software

Development. In Pattern Languages of Program

Design 4, N. Harrison, B. Foote, and H. Rohnert, Eds.

Addison-Wesley.

Boehm, B., Turner, R., 2003. Using Risk to Balance Agile

and Plan-driven Methods; In IEEE Computer, Vol. 36

Issue: 6; pp. 57 - 66.

Chandrasekaran, B., 1986. Generic Tasks in Knowledge-

Based Reasoning: High-Level Building Blocks for

Expert System Design; In IEEE Expert 1(3): pp. 23–

30.

Chandrasekaran, B., 1990. Design Problem Solving: A

Task Analysis; In AI Magazine, Vol. 11, Number 4,

pp. 59-71.

Chow, T.; Cao, D., 2008. A Survey Study of Critical

Success Factors in Agile Software Projects, Journal of

Systems and Software, Volume 81, Issue 6, pp. 961-

971.

Fowler, M., 2001. Is Design Dead?, In Extreme

Programming Examined. Addison-Wesley Longman

Publishing Co., Inc., Boston, MA, USA, pp. 3–17.

Larman, C., Basili, V. R., 2003. Iterative and Incremental

Development: A Brief History; In IEEE Computer,

Cover Feature, June 2003, pp. 47-56.

McConnell, S., 1996. Rapid Development: Taming Wild

Software Schedules. Microsoft Press.

Papert, S., Harel, I., 1990. Software Design as a Learning

Environment; Interactive Learning Environments, v1

n1 pp. 1-32.

Pirolli, P., Card, S., 2005. The Sensemaking Process and

Leverage Points for Analyst Technology as Identified

Through Cognitive Task Analysis; In Proceedings of

International Conference on Intelligence Analysis.

Royce, W.,1970. Managing the Development of Large

Software Systems; In Proceedings of IEEE WESCON,

Number 26 (August), pp. 1–9.

Talby, D., Hazzan, A., Dubinsky, Y., Keren, A., 2006.

Agile Software Testing in a Large-Scale Project; In

IEEE Software, vol. 23, no. 4, pp. 30-37.

ROBUSTIFYING THE SCRUM AGILE METHODOLOGY FOR THE DEVELOPMENT OF COMPLEX, CRITICAL

AND FAST-CHANGING ENTERPRISE SOFTWARE
