HURDLES IN MULTI-LANGUAGE REFACTORING OF HIBERNATE

APPLICATIONS

∗

Hagen Schink, Martin Kuhlemann, Gunter Saake

Otto-von-Guericke University, Magdeburg, Germany

Ralf L¨ammel

University of Koblenz-Landau, Koblenz, Germany

Keywords:

Refactoring, Multi-language Software Application, Object-relational Mapping, Hibernate, Database.

Abstract:

Different programming languages can be involved in the implementation of a single software application.

In these software applications, source code of one programming language interacts with code of a different

language. By refactoring an artifact of one programming language, the interaction of this artifact with an

artifact written in another programming language may break. We present a study on refactoring an software

application that contains artifacts of different languages.

1 INTRODUCTION

Today, different programming languages are used in

concert to implement software applications (Strein

et al., 2006; Linos et al., 2007; Chen and Johnson,

2008; Visser, 2008; Ford, 2008). The use of different

programming languages allows developers to accom-

plish speciﬁc tasks with less effort. However, artifacts

of different languages may interact. For instance, we

can use Java together with SQL (Andersen, 2006) and

artifacts of both languages must be kept consistent.

A refactoring is a transformation which alters the

structure but not the semantics of an artifact (Opdyke,

1992; Fowler, 1999). Refactorings exist for several

artifact types, e.g. source code of object-oriented pro-

gramming languages, UML diagrams, and database

schemas (Fowler, 1999; Li, 2006; Schrijvers et al.,

2004; Van Gorp et al., 2003; Suny´e et al., 2001; Am-

bler, 2003). However, a refactoring for an artifact of

one type does commonly not describe changes that

must be done in artifacts of other types.

We applied different refactorings on a soft-

ware application that contains artifacts of object-

oriented and functional programming languages, and

a database (Schink, 2010; Schink and Kuhlemann,

∗

An extended version of this paper has been published

as Master thesis and technical report before (Schink, 2010;

Schink and Kuhlemann, 2010).

2010). In the following we focus on object-oriented

and database refactorings for brevity. Based on our

observations, we implemented two refactorings and

performed experiments. We conclude that a general

approach to refactoring multi-language software ap-

plications is hard, if not impossible, to automate.

A coupled transformation describes the consis-

tent transformation of software applications after the

(possibly semantic-preserving) transformation of a

database schema or XML schema (Cunha and Visser,

2007; Cleve, 2009). Our study differs to work on cou-

pled transformations in that (1) we focus on refactor-

ings only, (2) our software application uses an object-

oriented mapper to communicate with a relational

database, (3) we discuss problems of refactoring a

software application on the one hand and a database

on the other hand.

2 BACKGROUND

In this section we deﬁne the term describing applica-

tions that are implemented by means of different pro-

gramming languages and describe the idea of refac-

toring these applications.

129

Schink H., Kuhlemann M., Saake G. and Lämmel R..

HURDLES IN MULTI-LANGUAGE REFACTORING OF HIBERNATE APPLICATIONS.

DOI: 10.5220/0003469501290134

In Proceedings of the 6th International Conference on Software and Database Technologies (ICSOFT-2011), pages 129-134

ISBN: 978-989-8425-77-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2.1 Multi-language Software

Application

A software application is a Multi-Language Soft-

ware Application (MLSA) if it is implemented using

different general-purpose and domain-speciﬁc lan-

guages (Linos et al., 2007). Different languages

are combined frequently, e.g. SQL is a standard-

ized query language for databases and was not in-

tended to be a general-purpose programming lan-

guage (Michels et al., 2003). But it is possible to em-

bed SQL statements in general-purpose programming

languages like C++ or Java (ISO/IEC, 2008; Ley-

derman, 2005; Andersen, 2006). Other examples of

language interaction exist (Chen and Johnson, 2008;

Harold and Means, 2002; Grogan, 2006). The com-

bination of different programming languages reduces

the effort to implement common tasks in software de-

velopment, e.g. data storage (Fjeldberg, 2008).

2.2 Multi-language Refactoring

A refactoring is a semantic-preserving modiﬁcation

of a software application (Fowler, 1999). A common

refactoring is Rename Field that is used, if the name

of a ﬁeld does not describe the purpose of that ﬁeld.

Besides source code, a software application may

contain documentation, design documents, speciﬁ-

cations, and unit tests et cetera (Mens and Tourw´e,

2004). An artifact type describes a set of artifacts that

share a common paradigm. For example we consider

artifacts of the object-oriented languages Java and

C++ to have a common artifact type. Refactorings for

artifacts of individual types exist, e.g. for artifacts of

object-oriented (Fowler, 1999), functional (Li, 2006),

and logical programming languages (Schrijvers et al.,

2004), and others (Van Gorp et al., 2003; Suny´e et al.,

2001; Ambler, 2003).

Refactorings for individual artifact types do not

describe at all or not in detail how they inﬂuence

artifacts of other artifact types, so developers are

forced to adapt interacting artifact types manually.

For instance, consider a class

Employee

and a table

Employee

. Let us assume that the class

Employee

re-

lates to the table

Employee

by name (common with

object-relational mappers). Based on the relation, an

object-relational mapper retrieves datasets from the

table

Employee

and provides these datasets as in-

stances of class

Employee

. If we apply a Rename

Class refactoring on class

Employee

, we have to mod-

ify the database schema to preserve the relation be-

tween class

Employee

and table

Employee

, though,

this modiﬁcation of the database schema is not part of

the standard refactoring deﬁnition. We call a refactor-

ing that describes a semantic-preserving modiﬁcation

on artifacts of at least two different artifact types a

multi-language refactoring (MLR).

3 ANALYSIS

HRManager is a software application we imple-

mented to manage employee data (Schink and Kuhle-

mann, 2010). HRManager is the basis upon which we

show effects of refactoring MLSAs. HRManager has

been implemented using the object-oriented program-

ming language Java and the functional programming

language Clojure. Application data is stored in a rela-

tional database. Datasets in the database are accessed

through the object-relational mapper Hibernate. As

we use HRManager as our running example through-

out the paper, we will present the different artifact

types and their relations in detail. In this paper we fo-

cus on the description of the Java/Hibernate artifacts

and the database.

All classes representing domain entities in

HRManager, e.g. employees or managers, are im-

plemented in Java. For each class that represents a

domain entity a table exists as counterpart in the rela-

tional database, whereas table columns represent the

states of the respective class. We map the class hi-

erarchy to multiple tables, i.e., a table for each class

(other options are possible). Class hierarchies are de-

scribed by foreign key references between the tables

that represent the classes of the respective hierarchy.

Java classes are mapped onto tables of the re-

lational database by an object-relational mapping

(ORM). We use Hibernate

to realize the ORM in

HRManager. To describe the ORM between Java

classes and the respective tables in the database

schema, we use Java annotations deﬁned by the Java

Persistence API (DeMichiel, 2009) that is imple-

mented by Hibernate. Listing 1 shows an excerpt of

the ORM of class

Employee

. We use the

@Entity

annotation (Line 1) to mark the class

Employee

persistent class of which instances are stored in the

database. With the

@Table

annotation we specify that

Hibernate shall store instances of

Employee

in table

employees

(Line 1). Without using the

@Table

an-

notation, Hibernate would map the class

Employee

an equally named table

Employee

Hibernate maps object states to the respective ta-

ble columns. We use Hibernate in property-access

mode, i.e., we use getter and setter methods to de-

ﬁne the properties to store in the database (Keith and

Schincariol, 2009).

http://www.hibernate.org

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

130

@Entity @Table(name="employees")

2 public class

Employee

implements

Serializable { ... }

Listing 1: Excerpt of the ORM of the class Employee.

3.1 Refactoring an MLSA

We applied a number of refactorings manually to our

sample MLSA and evaluated whether the refactorings

can be automated. Our aim was to preserve the se-

mantics of HRManager. First, we applied a refactor-

ing to one artifact. If the refactoring broke the interac-

tion with other artifacts, e.g. by introducing compiler

or runtime errors, we tried to re-establish the interac-

tion by refactoring the interacting artifacts of possibly

different artifact types. We call an MLR on HRMan-

ager successful, if the MLR describes a set of refactor-

ings for differentartifact types, that together preserves

the semantics of HRManager. By semantics we refer

to the speciﬁcation of HRManager.

We apply a special deﬁnition for semantics on the

database to take the existence of persistent data in the

database into account. A transformation of a database

schema and the related data instances is semantic-

preserving, if the transformation is reversible (Hain-

aut, 1996). For databases, we distinguish two terms

of semantic-preservation that describe if a database

refactoring can be undone: reversible and symmetri-

cally reversible (Hainaut, 1996). That is, a transfor-

mation T1 is reversible, if for T1 a transformation T2

exists, that undoes T1. A transformation of a database

is symmetrically reversible, if for T1 a transformation

T2 exists, so that T2 is the inverse transformation of

T1 and vice versa (Hainaut, 1996). Hence, we can

undo symmetrically reversibletransformationwithout

loosing any data already stored in the database.

In the following, we present the necessary modiﬁ-

cations to realize an object-oriented (Pull Up Method)

and a database (Introduce Default Value) refactoring

on the MLSA HRManager.

3.1.1 Pull Up Method Refactoring

In HRManager, only the class

Manager

provides the

methods

getBoss

and

setBoss

to manage the super-

visor of a manager. But also employees have a su-

pervisor, though, the class

Employee

(superclass of

Manager

) does not provide any method to manage su-

pervisors. Hence, we want to pull up the methods

There exist different semantic deﬁnitions for the differ-

ent languages discussed. As HRManager is a simple pro-

gram, we refer to the unmodiﬁed HRManager source code

as speciﬁcation of HRManager’s semantics. An exhaustive

discussion of semantics is not in the scope of this paper.

1 UPDATE

managers

2 SET

boss = (

SELECT

FROM

employees

aaaaaa a WHERE

surname = ’B’)

3 WHERE

(

SELECT

FROM

employees

aa aaaaWHERE

employees.surname

= ’S’

aaaaAND

employees.id =

managers.id);

Listing 2: Establishing a supervisor relationship between

subordinate S and boss B.

1 UPDATE

employees

2 SET

boss = (

SELECT

FROM

employees

aaaaaaaaaWHERE

surname = ’B’)

3 WHERE

employees.surname = ’S’;

Listing 3: Establishing a supervisor relationship between

subordinate S and boss B after refactoring.

getBoss

and

setBoss

from

Manager

Employee

The following modiﬁcations are necessary to per-

form the Pull Up Method refactoring (Fowler, 1999)

on HRManager: (1) pull-up method

getBoss

from

Manager

Employee

, (2) pull-up ﬁeld

boss

from

Manager

Employee

, (3) pull-up method

setBoss

from

Manager

Employee

, (4) move column

boss

and data stored in this column from table

managers

to table

employees

, and (5) update all references to

column

boss

of table

managers

to reference column

boss

in table

employees

. Step 2 is necessary, be-

cause after being pulled up

getBoss

Employee

can no longer access the private ﬁeld

boss

deﬁned in

Manager

. We use Hibernate in property-access mode,

so Hibernate maps getter/setter pairs deﬁned in a Java

class to columns deﬁned in the database schema; so

we need to apply step 3 to restore the getter/setter pair

getBoss

setBoss

Employee

The transformation of the database schema de-

scribed in the Steps 4 and 5 is reversible, because

we can move the column

boss

from

employee

back

managers

without losing any of the original infor-

mation in column

boss

. However, the transformation

is not symmetrically reversible, because with remov-

ing the column

boss

from table

employees

(required

when inverting the refactoring) tuples of employees

that are not managers lose their relation to an em-

ployee tuple representing their boss. That is, we can-

not guarantee the informational integrity of each tu-

ple in

employees

when undoing the Pull Up Method

refactoring. Hence, we may not be able to revert the

Pull Up Method refactoring by a reverse refactoring.

In the refactored database schema the column

boss

is part of table

employees

and removed from

table

managers

. Listings 2 and 3 show that the mod-

iﬁcation of SQL statements referencing the column

HURDLES IN MULTI-LANGUAGE REFACTORING OF HIBERNATE APPLICATIONS

131

boss

can be challenging.

In Listing 2, the

UPDATE

statement introduces a subordinate-boss-relation be-

tween the datasets of B (boss) and S (subordinate).

One way to adapt the

UPDATE

statement in Listing 2

to the new database schema is to swap the table refer-

enced in Line 1 (

managers

) and the table referenced

in the

FROM

clause in Line 3 (

employees

). Listing

3 shows an additional modiﬁcation. We can simplify

the

WHERE

clause in Listing 2, Line 3, by replacing

the

SELECT

statement with a comparison (Listing 3,

Line 3). We conclude, there exist at least 2 possible

modiﬁcations of the

UPDATE

statement of Listing 2

that differ in the amount of changes to apply. We fur-

ther conclude that the described transformations can

possibly only be realized by means of semantic anal-

ysis of the SQL statement at hand (e.g. Listing 2).

3.1.2 Introduce Default Value Refactoring

We use the Introduce Default Value refactoring (Am-

bler, 2003) to unify already existing default values (in

the database itself and in HRManager) by introducing

a single default value.

In HRManager, we want to set the default value

for the column

account

in table

managers

to acqui-

sition, because we deﬁne that a manager has to re-

port to the account acquisition, by default. We have

to modify HRManager in the following way to in-

troduce the default value acquisition: (1) deﬁne the

default value acquisition for the column

account

the table

managers

by using the keyword

DEFAULT

(2) initialize the ﬁeld

account

of the class

Manager

with the value acquisition. Step 2 is necessary to pre-

serve the semantics of the default value deﬁned in the

database for classes implemented in Java. Consider,

we would not have applied Step 2; when we create a

new instance of class

Manager

the ﬁeld

account

initialized with

null

. When we store this instance in

the database,

null

is written to the column

account

The default value of the column

account

would never

be applied to the instances of class

Manager

There can be methods assuming the ﬁeld

account

being initialized with

null

. Those methods would be-

have differently after refactoring, so the modiﬁcation

described in Step 2 can be semantics-changing.

If property access for Hibernate is set, the modi-

ﬁcations in Step 2 may require semantic analysis be-

cause from Hibernate’s point of view the representa-

tion of the state

account

is hidden in the implemen-

tation of its getter/setter methods (Keith and Schin-

cariol, 2009). The analysis of the implementation

of getter/setter methods may be achieved statically

The SQL statements are deﬁned with the syntax of

SQLite (http://www.sqlite.org).

1 public void

setAccount(String acc)

{

2 int

l = acc.length();

String accID=account.substring(l

-3, l);

accountName=acc.substring(0,l-3);

accountID=Integer.parse(

accIDString); }

Listing 4: Method deﬁnition setAccount.

for trivial implementations, but needs advanced treat-

ment for non-trivial getter/setter methods. In Listing

4, we deﬁned a non-trivial example for the method

setAccount

. In this method, we parse a parameter of

type

String

and store the parsed values in two dif-

ferent ﬁelds

accountName

(Line 4) and

accountID

(Line 5). Without semantic analysis of

setAccount

we would not know how to implement the new default

value in the ﬁelds

accountName

and

accountID

. But

static source code analysis may not reveal all needed

information (Laski et al., 1998), and, hence, does not

offer a general solution to the problem of ﬁnding the

ﬁelds accessed by getter/setter pairs.

4 EVALUATION

We implemented an MLR version of the Rename

Method and the Push Down Method refactoring for

applications written in Java, Hibernate, and SQL. The

Push Down Method refactoring removes a method

deﬁnition from a superclass and copies the method

deﬁnition to all subclasses (Fowler, 1999).

We evaluated the refactorings on applications

which use the Rich Internet Application Framework

JBoss Seam.

Depending on the application, we are

able to automate MLRs at least partially. The reason

for a partial application of a refactoring is the missing

support of certain artifact types by our prototype. We

identiﬁed all manual modiﬁcations required to com-

plete refactorings to be semantic-preserving.

The refactoring of the evaluated software appli-

cations is possible, because their implementation is

slightly different to the implementation of HRMan-

ager (Schink and Kuhlemann, 2010). The different

implementation allows the refactoring of an artifact of

one type without applying semantics-changing modi-

ﬁcations to artifacts of a different artifact type. Hence,

a refactoring applied on two MLSAs containing the

same artifact types may be successful on one MLSA

while the refactoring fails on the other MLSA due to

differences in the implementation of the MLSAs.

http://seamframework.org

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

132

5 RELATED WORK

The following approaches share the idea of ﬁnding

commonalities between artifact types. Generic Refac-

torings describe refactorings of concepts, program-

ming languages have in common, for instance meth-

ods (L¨ammel, 2002). Our study shows that artifact-

speciﬁc concepts exist which we cannot treat in a

generic way, because these concepts do not exist in

all languages. So the use cases for Generic Refactor-

ings in multi-language software applications may be

limited to languages which share at least some com-

mon concepts.

An approach to describe a refactoring in an

abstract way is to use meta models of source

code. The meta models FAMIX (Tichelaar, 2001),

MOOSE (Ducasse et al., 2000), and UML (Van Gorp

et al., 2003) are used for describing refactorings of

OOP languages independently from the OOP lan-

guage at hand. Therefore, FAMIX, MOOSE, as

well as UML cannot be used to abstract artifacts of

MLSAs in general. Another meta model based ap-

proach is used in the IDE X-Develop (Strein et al.,

2006). X-Develop realizes MLR on top of a Common

Meta-Model which uniﬁes the concepts of the sup-

ported languages in a single representation. The au-

thors evaluate the Rename Method refactoring imple-

mented in X-Develop on a project that utilizes differ-

ent languages. But these languages can be compiled

into a common base language, hence, the languages

share common properties and, therefore, belong to the

same artifact type in our understanding. Refactorings

of other artifact types are not considered by the au-

thors.

Some authors analyze and implement renaming

for different artifact types (Chen and Johnson, 2008;

Kempf et al., 2008). The authors show that the im-

plementation of MLR is possible for certain relations

(e.g. frameworks and the corresponding conﬁguration

ﬁles). We analyzed and implemented refactorings be-

yond renaming and showed that under certain condi-

tions MLR is not easy to automate.

Coupled Software Transformations or Co-

transformations are modiﬁcations of different

interacting artifact types (L¨ammel, 2004). Co-

transformations describe semantics-preserving as

well as semantics-changing modiﬁcations (L¨ammel,

2004). We argue that a general application of

semantics-changing modiﬁcations is irreconcilable

with the term refactoring. But co-transformations

exist for semantics-preserving database schema

transformations and the associated program transfor-

mations (Cleve, 2009). In (Cleve, 2009) the authors

argue that a semantic-preserving transformation of

a database schema leads to transformations that do

not modify the functionality of related applications.

We applied both, object-oriented and database refac-

torings. Although we applied semantic-preserving

transformations, i.e. refactorings, on Java source

code and a relational database, we found cases

where semantic-changing modiﬁcations are hardly

avoidable.

In (Cunha and Visser, 2007) another approach to

the consistent transformation of a data schema and re-

lated queries is presented. Refactorings are not dis-

cussed, and transformations of the application source

code are not considered.

Some of the problems shown in this paper may

be directly related to the object-relational impedance

mismatch (Carey and DeWitt, 1996). But not all prob-

lems, like alternative refactoring realizations and the

need for possibly semantics-changing modiﬁcations,

can be explained by the object-relational impedance

mismatch.

6 CONCLUSIONS

We applied an object-oriented and a database refac-

toring on a multi-language software application

(MLSA). The MLSA uses the object-relational map-

per Hibernate to communicate with a database. When

we applied the refactorings, we observed that (1) a

refactoring of artifacts of one artifact type can lead to

semantic-changing modiﬁcations in artifacts of other

artifact types, and that (2) there can be alternative

ways to realize a refactoring for artifacts of differ-

ent types. The alternative ways can differ substan-

tially in the amount of modiﬁcations or may not even

preserve program-semantics. The latter case leads to

conﬂicts with the refactoring term. We argue that a

general approach to automated multi-language refac-

torings (MLR) covering all possible MLSAs is not

feasible due to the different concepts of existing ar-

tifact types.

We automated the Rename Method and the Push

Down Method refactoring for software applications

using the object-relational mapper Hibernate. We

conclude that we are able to realize automated MLRs

if the conditions described in our study are met.

In an MLSA artifacts of different types are in-

volved. When we refactor an artifact of one type, ar-

tifacts of different types may be subject to semantic-

changes. Thus, we think that a modiﬁed deﬁnition

of semantics-preservation for MLSA is required. We

think that we will not be able to treat a range of

potentially useful semantics-preserving modiﬁcations

of single artifact types on MLSAs as MLRs, other-

HURDLES IN MULTI-LANGUAGE REFACTORING OF HIBERNATE APPLICATIONS

133

wise. Therefore, the issue of semantics- preservation

in MLSAs is subject of our ongoing work.

REFERENCES

Ambler, S. (2003). Agile Database Techniques: Effective

Strategies for the Agile Software Developer. John Wi-

ley & Sons, Inc., New York, NY, USA.

Andersen, L. (2006). JDBC

4.0 Speciﬁcation. Sun Mi-

crosystems, Inc., Santa Clara, USA, ﬁnal edition.

Carey, M. and DeWitt, D. (1996). Of objects and

databases:A decade of turmoil. In VLDB. Citeseer.

Chen, N. and Johnson, R. (2008). Toward Refactoring in

a Polyglot World: Extending Automated Refactoring

Support across Java and XML. Workshop on Refac-

toring Tools.

Cleve, A. (2009). Program Analysis and Transformation for

Data-Intensive System Evolution. PhD thesis, Univer-

sity of Namur.

Cunha, A. and Visser, J. (2007). Strongly Typed Rewrit-

ing For Coupled Software Transformation. Electronic

Notes in Theoretical Computer Science, 174(1).

DeMichiel, L. (2009). JSR 317: JavaTM Persistence API,

Version 2.0. Sun Microsystems, Inc., Santa Clara,

USA, ﬁnal edition.

Ducasse, S., Lanza, M., and Tichelaar, S. (2000). MOOSE:

An Extensible Language-Independent Environment

for Reengineering Object-Oriented Systems. CoSET.

Fjeldberg, H.-C. (2008). Polyglot Programming. Master

thesis, Norwegian University of Science and Technol-

ogy, Trondheim/Norway.

Ford, N. (2008). The Productive Programmer. O’Reilly.

Fowler, M. (1999). Refactoring: Improving the Design of

existing Code. Addison-Wesley Longman Publishing

Co., Inc., Boston, MA, USA.

Grogan, M. (2006). JSR-223 Scripting for the Java Plat-

form. Sun Microsystems, Inc., Santa Clara, USA, ﬁnal

edition.

Hainaut, J.-L. (1996). Speciﬁcation Preservation in Schema

Transformations – Application to Semantics and

Statistics. Data & Knowledge Engineering, 19.

Harold, E. R. and Means, W. S. (2002). XML in a nutshell.

O’Reilly & Associates, Inc., Sebastopol, CA, USA.

ISO/IEC (2008). International Standard ISO/IEC 9075-

1 Information technology Database languages SQL

Part 1: Framework (SQL/Framework). ISO/IEC, third

edition.

Keith, M. and Schincariol, M. (2009). Pro JPA 2: Master-

ing the Java Persistence API. Apress, Berkely, CA,

USA.

Kempf, M., Kleeb, R., Klenk, M., and Sommerlad, P.

(2008). Cross Language Refactoring for Eclipse plug-

ins. OOPSLA.

L¨ammel, R. (2002). Towards Generic Refactoring. ACM

SIGPLAN Workshop on Rule-based Programming.

L¨ammel, R. (2004). Coupled Software Transformations.

Workshop on Software Evolution Transformations.

Laski, J., Stanley, W., and Hurst, J. (1998). Dependency

analysis of Ada programs. ACM SIGAda Ada Letters,

XVIII(6).

Leyderman, R. (2005). Oracle rC ++ Call Interface. Or-

acle Corporation.

Li, H. (2006). Refactoring Haskell Programs. PhD thesis,

University of Kent, Canterbury, Kent, UK.

Linos, P. K., Lucas, W., Myers, S., and Maier, E. (2007). A

Metrics Tool for Multi-Language Software. SEA.

Mens, T. and Tourw´e, T. (2004). A survey of software refac-

toring. IEEE Transactions on software engineering,

30(2).

Michels, J.-E., Kulkarni, K., Farrar, M. C., Eisenberg, A.,

Mattos, N., and Darwen, H. (2003). The SQL Stan-

dard. it - Information Technology, 45(1).

Opdyke, W. (1992). Refactoring Object-Oriented Frame-

works. PhD thesis, University of Illinois at Urbana-

Champaign.

Schink, H. (2010). Sprach¨ubergreifende Refactor-

ing Feature Module. Master thesis, Otto-

von-Guericke-University, Magdeburg. Avail-

able online: http://wwwiti.cs.uni-magde

burg.de/iti db/publikationen/ps/auto/thesisSchink.pdf.

Schink, H. and Kuhlemann, M. (2010). Hurdles in refactor-

ing multi-language programs. Technical Report FIN-

007-2010, University of Magdeburg, Germany.

Schrijvers, T., Serebrenik, A., and Demoen, B. (2004).

Refactoring Prolog Code. Workshop on (Constraint)

Logic Programming.

Strein, D., Kratz, H., and Lowe, W. (2006). Cross-Language

Program Analysis and Refactoring. Workshop on

Source Code Analysis and Manipulation.

Suny´e, G., Pollet, D., Traon, Y. L., and J´ez´equel, J. (2001).

Refactoring UML Models. UML.

Tichelaar, S. (2001). Modeling Object-Oriented Software

for Reverse Engineering and Refactoring. PhD thesis,

University of Berne, Switzerland.

Van Gorp, P., Stenten, H., Mens, T., and Demeyer, S.

(2003). Towards Automating Source-Consistent UML

Refactorings. UML.

Visser, J. (2008). Coupled Transformation of Schemas,

Documents, Queries, and Constraints. Electronic

Notes in Theoretical Computer Science, 200(3).

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

134
