COMPARATION OF OWL ONTOLOGIES REASONERS

Testing Cases with Pellet and Jena

José R. Hilera, Luis Fernández-Sanz and Adela Díez

Department of Computer Science, University of Alcalá, Alcalá de Henares, Spain

Keywords: Ontology, OWL reasoner, Jena, Pellet.

Abstract: This article describes the results of an evaluation process of four OWL reasoners: Pellet and other three

included in Jena framework (OWL Default, OWL Mini, and OWL Micro). A simple ontology about

programming languages has been used for the validation process carried out by reasoners and a Java

program has been developed for testing different cases: reasoning over the original ontology model and

testing different possible inference situations.

1 INTRODUCTION

One of the reasons for building applications based

on ontologies comes from the fact that a reasoner

can be used to infer additional assertions about the

knowledge being modeled. One of the most popular

frameworks for programming in Java applications

using ontologies is Jena, which includes support for

various types of reasoners through its API for

inference (jena.sourceforge.net). A common feature

of Jena reasoners is that they create a new model

containing RDF triples resulting from the process of

reasoning, but maintaining the set of original triples

of the base model (Reynolds, 2010). When ontology

is processed using Jena, it is possible to use a

reasoner for inference. This article describes a work

about the evaluation of four reasoners when new

facts from the same OWL ontology are inferred.

2 EVALUATION

OWL Reasoners to be Evaluated. The Jena

inference system was designed to allow different

types of reasoners extract new knowledge.

Normally, access to inference is achieved using the

ModelFactory Java interface: this associates a

dataset with a reasoner to create a new ontology

model. This new model is composed of the

assertions which were present in the original data,

but also adding those ones derived from such data by

applying rules or other inference mechanisms

implemented by the reasoner. The Jena OWL

reasoners could be described as instance-based

reasoners, i.e., they use rules to propagate the “if and

only if” implications of the OWL constructs on data

instances. This approach contrasts with more

sophisticated Description Logic reasoners which

work with class expressions: they can be less

efficient when handling instance data but more

efficient with complex class expressions as well as

able to provide complete reasoning. In this work an

ontology represented in OWL is evaluated, using

four reasoners: Pellet (2011) and other three

reasoners which are included in Jena (OWL Default,

OWL Mini, and OWL Micro). We define test cases

and then compare the execution times and the results

created by the different reasoners.

Ontology for Test Cases. We have used a simple

ontology about programming languages to compare

performance of the four reasoners. The formal

knowledge modeled reflects some of the various

categories used to classify programming languages

depending on: the level of abstraction, the purpose,

the historical development, and the programming

paradigm. Figure 1 shows the classes included in the

ontology. The main class is ProgrammingLanguage.

Listing 1 presents the code about an instantiation of

the class ProgrammingLanguage, in this case, the

“Java” language. It can be noted that the property

belongsParadigm has the value "object oriented", so

it satisfies the restriction equivalentClass defined in

the class ObjectOrientedLanguage.

Software used for Evaluation. The evaluation was

done by modifying the ontology in order to test

419

R. Hilera J., Fernández-Sanz L. and Díez A..

COMPARATION OF OWL ONTOLOGIES REASONERS - Testing Cases with Pellet and Jena.

DOI: 10.5220/0003471404190422

In Proceedings of the 6th International Conference on Software and Database Technologies (ICSOFT-2011), pages 419-422

ISBN: 978-989-8425-77-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

different possible inference situations using the four

reasoners. Listing 2 shows part of the Java code

developed for validation, using the Jena API. An

object using the InfModel interface must be created

to test each reasoner previously. InfModel is an

extension to the normal Model interface in Jena. It

supports access to any underlying inference

capability. After creating the object, the function

validate () is executed returning a validation report

about the results of the reasoning. The time devoted

to validation is measured.

Figure 1: Classes in the ontology of programming

languages.

<owl:Class

rdf:ID="ObjectOrientedLanguage">

<owl:disjointWith>

<owl:Class rdf:ID="FunctionalLanguage"/>

</owl:disjointWith>

<owl:disjointWith>

<owl:Class rdf:ID="LogicLanguage"/>

</owl:disjointWith>

<owl:disjointWith>

<owl:Class rdf:ID="ProceduralLanguage"/>

</owl:disjointWith>

<owl:equivalentClass>

<owl:Restriction>

<owl:hasValue>object oriented

</owl:hasValue>

<owl:onProperty>

<owl:FunctionalProperty

rdf:ID="belongsParadigm"/>

</owl:onProperty>

</owl:Restriction>

</owl:equivalentClass>

<rdfs:subClassOf>

<owl:Class

rdf:ID="ProgrammingLanguage"/>

</rdfs:subClassOf>

</owl:Class>

Listing 1: Ontology (class “ObjectOrientedLanguage”).

<belongsGeneration>third

</belongsGeneration>

<belongsParadigm>object oriented

</belongsParadigm>

<hasExtension>.class</hasExtension>

<hasReservedWord>public</hasReservedWord>

</isCreatedBy>

<isCreatedIn

rdf:datatype="&xsd;gYear">1995

</isCreatedIn>

</supportsOperatingSystem>

</supportsOperatingSystem>

</supportsOperatingSystem>

</supportsOperatingSystem>

</ProgrammingLanguage>

Listing 2: Ontology source code (individual “Java”).

//Validation with OWL Default reasoner

long startTime= System.currentTimeMillis();

InfModel im = ModelFactory.createInfModel

(

ReasonerRegistry.getOWLReasoner(),

modelOWL.getRawModel());

ValidityReport vr = im.validate();

if (vr.isValid())

System.out.println("Correct model");

else

for(Iterator<Report>I = vr.getReports();

i.hasNext();)

System.out.println("____+++___"+i.next());

long endTime = System.currentTimeMillis();

System.out.println(endTime–startTime);

Listing 3: Java code for evaluation of time for reasoning.

Test Case 1: Validation of the Original Model. In

this first case we used the original ontology, only

considering cardinality constraints and values

applied to the parent class and to child classes

generated by the value of the functional properties

that define a particular classification. As seen in

Table 1, the results for all the reasoners are the

same, resulting in a correct validation of the model,

but with significant differences in the execution

time. The time taken by the default reasoner is four

times the one by OWL Mini, because this avoids

infinite expansions when bNodes are included,

where restrictions as minCardinality or

someValuesFrom enter in the process, so it leads to a

significant performance improvement. Validation

with OWL Micro is similar in time values to the

ones by Pellet, with an execution time 56 times

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

420

lower than the default reasoned: this is possible

because it restricts its functionality to RDFS

hierarchies, and intersectionOf, unionOf and

HasValue axioms.

Table 1: Results of the test cases for validation of

restrictions (execution time in “ms” and error messages).

Test

case

OWL

Default

OWL

Mini

OWL

Micro

Pellet

21036

7635 855 1022

2 49902 6440 505

727

(KB is

inconsistent)

38071

Too

many

values,

Conflict

12342

Too

many

values,

Conflict

1073

Conflict

977

KB is

inconsistent

4 71494 13912 1029 1080

5.1

187200

Too

many

values

18056

Too

many

values

1392

Too

many

values

1144

KB is

inconsistent

5.2

48068

10786 1002 1136

5.3

(val.2)

52742

14490

1142

1096

(KB is

inconsistent)

5.3

(val.1)

----

Code

exception

27276

Too

many

values

1235

1152

KB is

inconsistent)

Test Case 2: Validating Value restrictions on

Data. This test case requires changing the original

model by altering the values of the properties that

settle ratings for any of the defined individuals. For

example, the value of the property belongsParadigm

has been changed in the case of the individual

"Java", from "object oriented" to "imperative". As a

value not covered by the range of data that has been

assigned to the property domain, the validation of

the resulting model would be incorrect. Table 1

shows the results. While all reasoners incorporated

in Jena get a successful validation, Pellet recognizes

the inconsistency in the model and launched a bug

report. The cause might be found in the

documentation on Jena inference: "The critical

constructs which go beyond OWL lite and are not

supported in the Jena OWL reasoner are oneOf and

complementOf" (Reynolds, 2010). Due to the

transformation of DataRange as combined lists with

oneOf in the modified ontology, the reasoners skip

checking this type of construction and continue

validating the rest of the model, returning a positive

result.

Test Case 3: Validating Cardinality Restrictions

on Functional Properties. A functional property is

one that can take only a single value for each

instance. We have added in the ontology a property

belongsGeneration in the case of individual

"Prolog" and it is set to "fourth". Since this kind of

special properties are not sensitive to context (in a

global level), an error should emerge in the

validation when a second literal is added. In this

case, all reasoners notify errors, but with different

error reports (table 1). The differences between

OWL Mini and Default are minimal. Most notable

differences appear in the case of OWL Micro

reasoner, which suppress the validation of the

functional property value, but recognizes that there

is a case of incompatibility between disjoint classes.

The validation would have been positive if it had

been declared as a value of this property, an out of

range value, because this checking is not

implemented in this reasoner, so it would have not

provoked inconsistency between classes (there

would be no disjunction between classes). The error

launched by Pellet just affects the value of the

functional properties, rather than class operations.

Test Case 4: Validating minCardinality

Restrictions. In this test case, we have defined a

lower value for the same type properties to the same

instance, so that they remain below the declared

value for that restriction. It has been eliminated the

property isCreatedBy of the individual "SQL" so

reference to the creators of this language has been

missed. With this scenario, a priori, the resulting

model validation should fail. However, as shown in

table 1, the validation with all the four reasoners is

correct, showing an unexpected result. This happens

because, as in other ontology languages, the

semantics of OWL adopt the Open World

Assumption (OWA) approach. OWA model holds

that an agent or observer cannot have a complete

view of the world, and therefore it cannot make

assertions about facts which are unknown. This

involves, directly, an incomplete inference process

with open world reasoners, against those based on

closed world assumption, in which the lack of

information is automatically translated into an

assertion of falsehood. In essence, we can say that it

is wrong to expect that the absence of information in

the OWL model validation will generate an error,

taking into account the principles governing OWA,

and adopted by RDF and OWL. For a simulation of

the closed world assumption, it is possible to use the

Jena framework "Eyeball" and the new integrity

checker that offers the Pellet reasoner for OWL.

Test Case 5: Validating maxCardinality

Restrictions. This case requires reversing the

changes to the previous point, i.e., we defined a

larger number of the same type of properties on the

same instance, so that they are higher than the

COMPARATION OF OWL ONTOLOGIES REASONERS - Testing Cases with Pellet and Jena

421

declared maximun value for that restriction. There

are no problems in the case of working with

DataType properties, but in the case of Object type

properties, we can test the differences when

individuals are different or not. We have validated

the following possibilities:

1) Exceeding the Maximum Cardinality of a

DataType Property. We changed the restriction

associated to the property hasExtension,

defining as maxCardinality the value "2". With

this assumption, should fail in the case of the

individual "Java" of the class

lenguajeProgramacion, which has three

properties of this type. In this case, the reasoners

generate incorrect validation reports (table 1).

The Default OWL and OWL reasoners behave

in the same way. There are two types of warning

in reports: one about the classes and subclasses

to which the individual "Java" belongs and

another one referred to nodes with names

related to the ID assigned to each constraint that

define each subclass. In the case of OWL Micro

reasoner the message only shows the first

occurrence where there is conflict and stops

validation. Pellet also shows a validation

message that is enough to verify that it has

exceeded the value of a particular property, but

it does not show what the individual or class is

affected.

2) Exceeding the Maximum Cardinality of an

Object Property without defining the

Individuals involved as Different. We changed

one of the restrictions,

supportsOperatingSystem, defining a maximum

cardinality "2", in order to see how it acts on

individuals (as "Prolog", "SQL", "Java") which

have assigned more than 2 operating systems.

We can realize in this case the validation is

successful with all the reasoners (table 1),

because we have to explicitly state that

individuals are different for the cardinality

constraints operate as desired although each of

the three individuals has various instances of

supportsOperatingSystem property. Here it is a

consequence of the paradigm OWA because it

cannot cause any definitive deductions whether

knowing if the individuals are identical or not.

3) Exceeding the Maximum Cardinality of an

Object Property identifying the Individuals

involved as Different. We took the same case

as above excepting that define the operating

systems as different from each other (for this

example, four individuals: "Windows", "Linux",

"MacOSX" and "Solaris"). To do this, the

individual "SQL" of ProgrammingLanguage

was modified by adding the four instances for

the property supportsOperatingSystem. In this

case, validation should be wrong for all

reasoners. But Pellet reasoner was the only one

that detected that cardinality is exceeded for any

individual. This is because the sublanguage on

which are built the OWL Jena reasoners, OWL

Lite, only supports 0 or 1 as cardinality

constraints (Reynolds, 2010). So we can

consider this limitation and change the value of

the maximum cardinality from 2 to 1. The

validation with this change produces the results

shown in table 1. In this case, the OWL default

reasoner gets hooked in an infinite loop trying to

insert blank nodes for all generated classes that

take the cardinality constraint, throwing an

exception message. OWL Mini reasoner is very

helpful to avoid this because it prevents these

expansions and performs validation controlling

this inconsistency in the model. Finally, Pellet

also locates directly this inconsistency.

3 CONCLUSIONS

From results of test cases we can conclude that the

reasoners embedded in Jena to provide inference and

validation are incomplete and with important

limitations. In the case of OWL reasoners, the

validation capacity is quite limited, assuming as

valid cardinality restrictions broken in the ontology.

In these situations, the external reasoner Pellet

provides a more complete reasoning based on OWL

DL version with shorter response times. Moreover,

certain aspects of the programming interface are

obsolete, as Jena has been built based on OWL 1.

ACKNOWLEDGEMENTS

This research has been partially funded in Spain by

CAM and UAH (grant CCG10-UAH/TIC-5915).

REFERENCES

Pellet, 2011. Pellet: OWL 2 Reasoner for Java, Clark &

Parsia. http://clarkparsia.com/pellet.

Reynolds, D., 2010. Jena 2 Inference support, souceforge.

http://jena.sourceforge.net/inference/index.html.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

422
