HOW STATISTICAL INFORMATION FROM THE WEB

CAN HELP IDENTIFY NAMED ENTITIES

Mathieu Roche

LIRMM, CNRS, Univ. Montpellier 2, 161 rue Ada, 34392 Montpellier Cedex 5, France

Keywords:

Text-mining, Natural language processing, Terminology, Named entity.

Abstract:

This paper presents a Natural Language Processing (NLP) approach to ﬁlter Named Entities (NE) from a list

of collocation candidates. The NE are deﬁned as the names of ’People’, ’Places’, ’Organizations’, ’Software’,

’Illnesses’, and so forth. The proposed method is based on statistical measures associated with Web resources

to identify NE. Our method has three stages: (1) Building artiﬁcial prepositional collocations from Noun-

Noun candidates; (2) Measuring the ”relevance” of the resulting prepositional collocations using statistical

methods (Web Mining); (3) Selecting prepositional collocations. The evaluation of Noun-Noun collocations

from French and English corpora conﬁrmed the relevance of our system.

1 INTRODUCTION

In this paper, we focus on the study of French and En-

glish phrases called collocations that can be extracted

using NLP (Natural Language Processing) methods.

(Clas, 1994) uses two properties to deﬁne a colloca-

tion. First, it is deﬁned as a phrase with a meaning

that can be deduced from the words that comprise

the phrase. For instance, the French phrase lumi

ere

vive (bright light) is considered to be a collocation

because the overall meaning of the phrase can be de-

duced from the two words lumi

ere and vive. Based on

this deﬁnition, the phrase tirer son chapeau (to take

off one’s hat), is not a collocation because its mean-

ing cannot be deduced from each word. These forms

are called ”ﬁxed expressions”.

A second property was added by the author (Clas,

1994) to deﬁne a collocation. The meaning of the

words of the collocation has to be limited. For ex-

ample, acheter un chapeau (buy a hat) is not a col-

location since the meaning of acheter and chapeau is

not limited. Indeed, a multitude of objects can be pur-

chased. Such phrases are called ”free expressions”.

However it is still very difﬁcult to distinguish between

”ﬁxed expressions, ”free expressions”, and colloca-

tions automatically.

The above deﬁnitions of collocation can be en-

riched with two additional characteristics, i.e. se-

mantic and syntactic knowledge (Heid, 1998). The

ﬁrst point is based on a semantic shared by the

collocations. For example, lait tourn

e (sour milk)

and beurre rance (rancid butter) have a very sim-

ilar meaning as both describe a degradation phe-

nomenon. The semantic information contained in

collocations has been taken into account in many

studies (Melcuk et al., 1999; Heid, 1998). The

second linguistic characteristic is the syntactic in-

formation contained in the collocation (Clas, 1994;

Daille, 1996). Generally, collocations have one of

the following patterns: Noun-Verb, Noun-Adjective,

Noun-Noun, Noun-Preposition-Noun, Verb-Adverb,

Adverb-Adjective, etc.

Using automatic processing, it is difﬁcult to iden-

tify collocations based on all these linguistic deﬁni-

tions. So we decided to focus on the extraction of

”collocation candidates” displaying a speciﬁc syntac-

tic pattern. However, the originality of the approach

described in this paper is the automatic identiﬁcation

of Named Entities (NE) among these candidates.

NE are conventionally deﬁned as the names of

’People’, ’Places’, and ’Organizations’. Originally,

this deﬁnition was used in evaluation challenges such

as MUC (Message Understanding Conferences). To-

day these kinds of challenges (e.g. TREC in English,

DEFT in French) cover a wide range of tasks. As

indicated in (Daille et al., 2000), the basic classes

of NE deﬁned in MUC challenges needed to be en-

riched. For example, (Paik et al., 1994) deﬁned two

new classes: ’Document’ (e.g. software, hardware)

and ’Science’ (e.g. illness, medication). To identify

NE, many systems rely on the use of uppercase letters

(Farkas et al., 2007). However, this may not be appli-

685

Roche M..

HOW STATISTICAL INFORMATION FROM THE WEB CAN HELP IDENTIFY NAMED ENTITIES.

DOI: 10.5220/0003473906850689

In Proceedings of the 7th International Conference on Web Information Systems and Technologies (WTM-2011), pages 685-689

ISBN: 978-989-8425-51-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

cable to non-capitalized NE (for instance in non-

standard documents like emails, blogs, tweets, texts

or text fragments that are written using either up-

percase or lowercase). Consequently, in the present

study, we did not chose to exploit this lexical infor-

mation to identify NE. Neither do we use machine

learning approaches for the recognition of NE cited

in (Baluja et al., 2000; Farkas et al., 2007).

In addition to characterize the NE, the criteria

uniqueness referential (i.e. a proper name refers to

a single referential entity), and stability of the denom-

ination (i.e. few possible variations) are speciﬁed by

(Fort et al., 2009). Our approach is based on this

last criterion to identify NE among collocation can-

didates. The extraction of collocation candidates is

based on a text mining process (see ’stage 1’ – Fig-

ure 1). After the acquisition of a corpus, a cleaning

process has to be applied. This removes noise in the

texts (e.g. HTML tags) that can lead to mistakes in an

NLP application. With the normalized texts, a part-

of-speech (PoS) tagger can be used. This attributes

a grammatical label (e.g. adjective, noun, and so on)

to each word of the corpus (Brill, 1994). In this pa-

per, we describe a method to extract collocation can-

didates from tagged texts. The process is based on

the use of patterns to extract nominal terminology

such as Noun-Adjective (in French), Adjective-Noun,

Noun-Noun, Noun-Preposition-Noun (Bourigault and

Jacquemin, 1999; Daille, 1996; Roche and Kodratoff,

2006).

In the following section (section 2), we focus on a

statistical method for selecting NE from Noun-Noun

collocation candidates (see ’stage 2’ – Figure 1). The

results of experimental tests of our method conduced

on real data (French and English corpora) are pre-

sented in section 3. Finally, section 4 presents our

future work.

2 NAMED ENTITY FILTERING

2.1 General Principle

Noun-Noun terminology has often various forms.

For example, the French collocation ﬁchier clients

(customer ﬁle) can be found with the Noun-

Preposition-Noun form: ﬁchier de clients (ﬁle of

customers), ﬁchiers pour clients (ﬁle for customers),

and so forth. Note that the variations of NE are

rare. Based on this remark we will use NLP methods

in order to identify NE from a list of Noun-Noun

collocation candidates.

Stage 1:

Text-Mining

(Terminology

Extraction)

Stage 2:

Web-Mining

(Identification

of NE)

fichier clients

conseiller clientèle

front page

assurance qualité

logiciel ciel

...

front page

logiciel ciel

go sport

...

- Cleaning

- Tagging

- Terminology extraction

Web

- - - - - -

Corpus

Figure 1: Global process.

Our method has three stages detailled in the follow-

ing section:

1. Building artiﬁcial prepositional collocations from

Noun-Noun candidates.

2. Measuring the ”relevance” of the resulting prepo-

sitional collocations using statistical methods.

3. Selecting prepositional collocations with low

scores (i.e. irrelevant built collocation).

2.2 Description of the Process

Step 1 - Building. Based on Noun-Noun candi-

dates, we built prepositional candidates by adding the

most common preposition: ”de” (in French

) and ”of”

(in English). When this principle was applied to both

French examples ﬁchier clients (customer ﬁle) and

logiciel ciel (ciel software), we obtained the follow-

ing results:

• ﬁchier clients

→ ﬁchier de clients

N−Prep−N

• logiciel ciel

→ logiciel de ciel

N−Prep−N

Note that when the second word of the candidate begins

with a vowel, the preposition used is ” d’ ”.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

686

Note that the English variations of Noun-Noun

candidates consist in adding a preposition associ-

ated with a swapping operation between the nouns

(Jacquemin, 1997):

• knowledge discovery

→ discovery of knowl-

edge

N−Prep−N

Step 2 - Measuring. The goal of the second step

was to measure the dependence between each word

of the collocations we built. This process is based

on the use of the Dice measure (Smadja et al., 1996)

which has good behavior (Roche and Prince, 2008;

Roche and Kodratoff, 2009). The measure is deﬁned

by the following formula based on three elements as

in (Petrovic et al., 2006):

Dice(x, y, z) =

3 × nb(x, y, z)

nb(x) + nb(y) + nb(z)

(1)

The principle of this measure is to calculate the

number of occurrences of each word x (i.e. nb(x))

or collocation x y z (i.e. nb(x, y, z)). In general, the

number of occurrences represents the frequency of the

words and/or collocations. This frequency is gener-

ally calculated regarding a corpus (Daille, 1996). In

our case, the Dice measure is applied in a web-mining

context (Turney, 2001).

Thus, the frequency nb corresponds to the num-

ber of web pages containing words or collocations.

This number is returned by querying search en-

gines (Google, Yahoo, Exalead, etc.). For exam-

ple, nb( f ichier) is the number of pages returned with

the single keyword, and nb( f ichier, de, clients) is the

number of pages returned with the query ”ﬁchier de

clients” (by using quotes to search an exact phrase).

An example of values obtained with Dice measure is

given below:

Dice( f ichier, de, clients) =

3×999,000

37,200,000+6,350,000,000+208,000,000

= 0.000454

Dice(logiciel, de, ciel) =

3×89,800

35,000,000+6,350,000,000+35,400,000

= 0.0000419

This result shows that the lowest score in major

proportions (factor ten) is given by logiciel ciel. Thus,

our measure predicts that this Noun-Noun candidate

is a NE. This is very relevant because this one is a

management software adapted to one class of NE (i.e.

’Document’ class) (Daille et al., 2000; Paik et al.,

1994). Web gives an indication of popularity of the

words/collocations. Moreover with ”external” knowl-

edge (i.e. Web) we are less sensitive to the size of the

used data (i.e. corpus).

Note that this measure has two differencies

with the web-mining approach described in (Turney,

2001): (1) We use the Dice measure because it pro-

vides best results than Mutual Information (Roche

and Kodratoff, 2009); (2) The numerator of this mea-

sure is based on the exact search of phrases (by using

quotes) and not on the presence (i.e. AND operator)

or the proximity (i.e. NEAR operator) of the nouns.

Step 3 - Selecting. Constructed candidates with low

scores are elements with few possible variations. In

our approach, these candidates are considered to be

NE. We introduce a parameter S which represents a

selection threshold. For example, with a threshold

S = 10, ten candidates with the lowest scores will be

selected as possible NE. The results with different val-

ues of S are discussed in the following section.

3 EXPERIMENTS

3.1 Experimental Protocol

In our experiments, the ﬁrst used corpus (called CV)

is composed of 1, 144 Curriculum Vitae provided by

the VediorBis company (120, 000 words). The sec-

ond specialized French corpus (called HR) is com-

posed of a set of texts from the Human Resources

ﬁeld. The texts correspond to summaries of psycho-

logical tests of 378 persons (600, 000 words). First

we select collocation candidates which are present a

minimum number of times in the corpus. This prun-

ing task enables to exclude candidates which are often

unrepresentative of the ﬁeld. The Table 1 shows the

number of candidates obtained before and after prun-

ing at 3 such as (Thanopoulos et al., 2002; Roche and

Kodratoff, 2006).

According to the same ﬁeld and language, the re-

sults may differ. For example, with the CV corpus

after pruning, the number of Noun-Noun candidates

is much larger than the Human Resources corpus.

Yet the size of Human Resources corpus is ﬁve times

larger than the CV corpus. This is because CV are

written in a condensed way, using very speciﬁc nomi-

nal terminology. We select this kind of collocation in

the study presented below.

The goal of our experiments is to evaluate if the

collocation candidates selected with our web-mining

approach represent really relevant NE. In this context,

we relied on the most frequent Noun-Noun candidates

of the CV corpus. In our experiments, 70 candidates

have been evaluated manually (18 NE have been iden-

tiﬁed). Note that this protocol needs an automatic exe-

cution of 210 queries

with the search engine Exalead

We apply 70 queries for the numerators, and 140

HOW STATISTICAL INFORMATION FROM THE WEB CAN HELP IDENTIFY NAMED ENTITIES

687

Table 1: Number of collocation candidates obtained before and after pruning.

Before pruning After pruning

HR CV HR CV

Noun-Noun 98 1,781 11 162

Noun-Preposition-Noun 4,703 3,634 1,268 307

Adjective-Noun 1,260 1,291 478 103

Noun-Adjective 5,768 3,455 1,628 448

Table 2: Precision, Recall, and F-measure with different values of S – French corpus.

French corpus

S 10 40 70

Web-Mining Precision 0.60 0.35 0.26

ranking Recall 0.33 0.78 1

F-measure 0.43 0.48 0.41

Random ranking F-measure 0.18 0.35 0.41

Table 3: Precision, Recall, and F-measure with different values of S – English corpus.

English corpus

S 10 40 70 140 210 305

Web-Mining Precision 1 0.83 0.73 0.58 0.46 0.34

ranking Recall 0.10 0.31 0.49 0.77 0.92 1

F-measure 0.17 0.46 0.58 0.66 0.62 0.51

Random ranking F-measure 0.06 0.19 0.28 0.39 0.46 0.51

(http://www.exalead.com/), this search engine giving

good results, in particular for French data.

To evaluate the generalisation of our approach, we

also propose to work with an English corpus com-

posed of Noun-Noun collocation candidates. This list

has 105 NE (examples of topics: politicy, military,

religious, etc) and 200 terms (topic: data-mining).

We have ranked all the candidates applying our web-

mining approach by performing 915 queries.

The benchmarks used in these experiments are

very speciﬁc because they have only lowercase words.

This situation is distinct from classic benchmarks of

the state-of-the-art.

3.2 Results

In order to evaluate our text-mining system Precision

(formula (2)) and Recall (formula (3)) are calculated.

A precision at 100% means that all NE returned with

our system are relevant, and a recall at 100% means

that all relevant NE are returned. In addition, the F-

measure (formula (4)) combines the precision and re-

queries for both nouns of the denominators (the query for

the prepositions have been applied only once for all calcu-

lations).

call.

Precision =

Nb of returned relevant NE

Nb of returned NE

(2)

Recall =

Nb of returned relevant NE

Nb of relevant NE

(3)

F − measure =

2 × Precision × Recall

Precision + Recall

(4)

We measure the quality of our system with differ-

ent thresholds S (see Tables 2 and 3). The results show

that the best value of F-measure is obtained when

we take into account the ﬁrst half of candidates from

French and English corpora.

We can consider that our method has a good be-

haviour because our ranking function returns a lot of

NE at the top the list. For instance, with the English

corpus, the value of the precision is 83% when 40 can-

didates are selected with our web-mining approach (a

random ranking returns a precision at 34%).

Finally, note that the F-measure with our approach

is better in a large proportion than a random distribu-

tion for all values of S (see Tables 2 and 3).

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

688

4 CONCLUSIONS AND FUTURE

WORK

This paper presents a text mining method for extract-

ing collocation candidates and identifying Named En-

tities from a list of candidates. The ﬁltering method

uses only a statistical approach based on the Dice

measure and exploitation of the results of search en-

gines. The NE is ”stable”, which is why we built vari-

ations of the candidates and checked their popularity

using search engines. If the candidates we built turned

out to be irrelevant (i.e. low value of the statistical

measure), they were considered as NE.

In the next step of our work, we plan to enrich the

rules concerning variations, which is a precondition

to take into account the vast majority of possible lin-

guistic variations. Finally, we plan to combine this

approach, which is only based on statistical knowl-

edge, with lexical information, particularly the use of

uppercase letters when possible.

ACKNOWLEDGEMENTS

I thank Daphne Goodfellow who improved the read-

ability of this paper.

REFERENCES

Baluja, S., Mittal, V. O., and Sukthankar, R. (2000). Apply-

ing machine learning for high-performance named-

entity extraction. Comput. Intelligence, 16(4):586–

596.

Bourigault, D. and Jacquemin, C. (1999). Term extraction +

term clustering: An integrated platform for computer-

aided terminology. In Proceedings of the European

Chapter of the Association for Computational Lin-

guistics, pages 15–22.

Brill, E. (1994). Some advances in transformation-based

part of speech tagging. In Proceedings of AAAI (Con-

ference on Artiﬁcial Intelligence), volume 1, pages

722–727.

Clas, A. (1994). Collocations et langues de sp

ecialit

e. Meta,

39(4):576–580.

Daille, B. (1996). Study and implementation of combined

techniques for automatic extraction of terminology. In

The Balancing Act: Combining Symbolic and Statisti-

cal Approaches to Language, MIT Press, pages 49–66.

Daille, B., Fourour, N., and Morin, E. (2000).

Cat

egorisation des noms propres : une

etude en

corpus. Cahiers de Grammaire, 25:115–129.

Farkas, R., Szarvasand, G., and Ormandi, R. (2007). Im-

proving a state-of-the-art named entity recognition

system using the world wide web. In Proceedings

of Industrial Conference on Data Mining, pages 163–

172.

Fort, K., Ehrmann, M., and Nazarenko, A. (2009). Vers

une m

ethodologie d’annotation des entit

es nomm

ees

en corpus. In Proceedings of TALN (Traitement Au-

tomatique du Langage Naturel).

Heid, U. (1998). Towards a corpus-based dictionary of ger-

man noun-verb collocations. In Proceedings of the

Euralex International Congress, pages 301–312.

Jacquemin, C. (1997). Variation terminologique : Recon-

naissance et acquisition automatiques de termes et de

leurs variantes en corpus. In M

emoire d’Habilitation

a Diriger des Recherches en informatique fondamen-

tale, Universit

e de Nantes.

Melcuk, I., Arbatchewsky-Jumarie, N., Elnitsky, L., and

Lessard, A. (1984, 1988, 1992, 1999). Dictionnaire

explicatif et combinatoire du franc¸ais contemporain.

Presses de l’Universit

e de Montr

eal, 1,2,3,4.

Paik, W., Liddy, E., Yu, E., and McKenna, M. (1994). Cat-

egorizing and standardizing proper nouns for efﬁcient

information retrieval. In Corpus Processing for Lexi-

cal Acquisition, MIT Press, chap. 4.

Petrovic, S., Snajder, J., Dalbelo-Basic, B., and Kolar, M.

(2006). Comparison of collocation extraction mea-

sures for document indexing. In Proceedings of ITI

(Information technology interfaces conference), pages

451–456.

Roche, M. and Kodratoff, Y. (2006). Pruning Terminol-

ogy Extracted from a Specialized Corpus for CV On-

tology Acquisition. In Proceedings of onToContent

Workshop - OTM’06, Springer Verlag, LNCS, pages

1107–1116.

Roche, M. and Kodratoff, Y. (2009). Text and web min-

ing approaches in order to build specialized ontolo-

gies. Journal of Digital Information (JoDI), 10(4).

Roche, M. and Prince, V. (2008). Managing the

Acronym/Expansion Identiﬁcation Process for Text-

Mining Applications. International Journal of Soft-

ware and Informatics, 2(2):163–179.

Smadja, F., McKeown, K., and Hatzivassiloglou, V. (1996).

Translating collocations for bilingual lexicons : A sta-

tistical approach. Comp. Linguistics, 22(1):1–38.

Thanopoulos, A., Fakotakis, N., and Kokkianakis, G.

(2002). Comparative evaluation of collocation extrac-

tion metrics. In Proceedings of LREC (International

Conference on Language Resources and Evaluation),

pages 620–625.

Turney, P. (2001). Mining the Web for synonyms:

PMI–IR versus LSA on TOEFL. In Proceedings

of ECML/PKDD (European Conference on Machine

Learning and Principles and Practice of Knowledge

Discovery in Databases), pages 491–502.

HOW STATISTICAL INFORMATION FROM THE WEB CAN HELP IDENTIFY NAMED ENTITIES

689
