LABEL ORIENTED CLUSTERING FOR SOCIAL NETWORK

DISCUSSION GROUPS

Ahmed Rafea, Ahmed El Kholy Sherif and G. Aly

Computer Science and Engineering Department, School of Science and Engineering, American University in Cairo

New Cairo, Egypt

Keywords: Clustering, Bisecting K-mean algorithm, Social network, Discussion groups.

Abstract: This paper proposes applying Bisecting K-means algorithm, to cluster the social network discussion groups

and providing a meaningful label to the cluster containing these groups. The clustering of the discussion

groups is based on the heterogeneous meta-features that define each group; e.g. title, description, type, sub-

type, network. The main ideas is to represent each group as a tuple of multiple feature vectors and construct

a proper similarity measure to each feature space then perform the clustering using the proposed bisecting

K-means clustering algorithm. The main key phrases are extracted from the titles and descriptions of the

discussion groups of a given cluster and combined with the main meta-features to build a phrase label of the

cluster. The analysis of the experiments results showed that combining more than one feature produced

better clustering in terms of quality and interrelationship between the discussion groups of a given cluster.

Some features like the Network improved the compactness and tightness of the cluster objects within the

clusters while other features like the type and subtype improves the separation of the clusters.

1 INTRODUCTION

In both professional and personal life, human beings

naturally form groups based on affinities and

expertise. We gravitate toward others with whom we

share common interests. Most of us belong to real

world networks that are formed organically. Not

surprisingly, these networks rapidly migrated to the

online world. Online social networking sites like

MySpace, Facebook, and Bebo have been around in

various forms for nearly a decade, and have begun to

achieve worldwide notice in the past few years.

Social networks connect people with friends and

others who work, study and live around them.

People use social networks to keep up with friends,

upload an unlimited number of photos, share links

and videos, and learn more about the people they

meet. These online networks contain great power.

They change the online space from one of static web

pages and stale marketing messages to a live, vibrant

network of connected individuals who share their

abilities; expertise and interests. Online social

networks take many forms, and are created for many

reasons. Despite their differences, online social

networks do, however, commonly exhibit some

concepts like discussion groups (Chastain, 2008).

The motivation behind this work is to provide an

approach for clustering discussion groups that will

contribute in the enhancement of efficient searching

and browsing of these groups. Solving the problem

of finding a related discussion board won’t be

complete unless the users knows how and why these

groups are related and this could be achieved by

adding a label to each cluster that describes the

similarity aspects between the member groups of

each cluster.

The main goal of this paper is to apply an

algorithm for clustering discussion groups using

their heterogeneous meta-features, and investigate

the quality of clustering process when some or all of

these meta-features are used to facilitate discussion

groups browsing.

The proposed approach is based on applying one

of the well known clustering algorithms on typical

discussion groups, and experiment with different

features to measure their impacts on the clustering

quality. This could be summarized in the following

steps:

 Collect (crawl) a set of discussion groups in

one of well-known social network like

Facebook

 Extract the social meta-features used in the

205

Rafea A., El Kholy Sherif A. and Aly G..

LABEL ORIENTED CLUSTERING FOR SOCIAL NETWORK DISCUSSION GROUPS.

DOI: 10.5220/0003488402050210

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 205-210

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

discussion groups

 Build a representation model for each feature,

 Utilize these feature vectors to build a

similarity measure to cluster these groups

 Conduct experiments to investigate the impact

of different features

The second section reviews previous works

related to multiple features clustering. The third

section describes our approach for clustering

discussion groups. The forth section explains the

evaluation methodology to measure the impact of

different features on the clustering quality. The fifth

section describes the experiments conducted, their

results, and discussion. The sixth section illustrates

how labels are generated for clusters

2 MULTIPLE FEATURE

CLUSTERING

Using multiple features in clustering has been

always a major concern as it is common in real life

to have more than one feature for the objects that are

intended to be clustered. Moreover, in many cases

these features that characterize the clustered objects

are heterogeneous in nature which complicates the

process of building the similarity measures.

A good example of multiple feature clustering is

XML documents. Many research works attempted to

solve the XML clustering problem by proposing

several techniques and algorithms. Basically, the

clustering of XML documents as a problem has two

dimensions; content and structure. The content

dimension needs distances that estimate similarity in

terms of the textual content inside elements, while

the structure dimension needs distances that estimate

similarity in terms of the structural relationships of

the elements. Taken these two dimensions into

consideration, the authors in (Tagarelli, Greco,

2006) tackled the problem of clustering XML data

according to structure and content features enriched

with lexical ontology knowledge. In (Costa et al.,

2004), the authors proposed a methodology for

clustering XML documents based on their structural

similarities which is based on the notion of XML

cluster representatives. They exploited the tree

nature of XML documents and provided techniques

for tree matching, merging and pruning. Another

work in (Dalamagas, 2006) the application of

clustering methods was explored for grouping

structurally similar XML documents by modelling

the XML documents as rooted ordered labelled

trees. The authors applied clustering algorithms

using the tree-edit distance between these trees in

terms of the hierarchical relationship of their nodes.

Another interesting work in (Doucette, Ahonen,

2002) deals with clustering homogeneous collections

of text-centric XML documents. They used the

classic k-means clustering algorithm and combining

structural similarities and content similarity in order

to improve the clustering quality. One of the most

recent approaches is the work presented in (Nayak,

Xu, 2006). The authors proposed a compact level

structure representation of each XML document

based on node summaries per level of the XML

document. Based on this representation, Antonellis

et al. (2008) define an appropriate distance metric

for heterogeneous XML documents and they apply a

hierarchical clustering algorithm in the set of level

structure representations of the documents

Media Clustering is also a main application that

employs multiple features in the clustering

techniques. Abrantes (2000) extended a class of

constrained clustering algorithms for shape

estimation by using multiple features. These features

consist of edge points and associated image

properties, e.g., gradient, texture and colour.

Eterfreund (1998) exploited the image gradient and

optical flow using an algorithm called velocity

snake. Moreover, Gradient and texture information

were integrated in directional feature extraction

(Blake, Isard, 1998). In (Zhong, Jain, 1998), the

author used image gradient, colour, and motion cues

to update a deformable template model. In addition

to images, videos also built up from multiple

features that could be used in clustering; Lee et al.

(2000) proposed an efficient method to detect abrupt

shot changes in a video sequence.

3 REPRESENTING AND

CLUSTERING DISCUSSION

GROUPS

A data set is built by crawling discussion groups

from Facebook which is the most popular social

network nowadays. Examining the meta-features of

these discussion groups, we found that this data set

has numerical, text and categorical features.

Standard k-means is designed to work with

numerical data, and does not work well with

categorical and text data which are of heterogeneous

feature spaces by nature so it was necessary to build

a data model and similarity measures that overcome

this problem by treating each feature space as a

separate problem and applying different weights to

each element of meta-features.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

206

3.1 Discussion Groups Representation

and Similarity Measures

Every object (instance) in the data set consists of 5

features; 2 text (title &description) and 3 categorical

(network, type and subtype). Each object is

represented as a tuple of 5 component feature

vectors. The data object is written as x = (F1, F2, F3,

F4, F5) where the i

component feature vector F

, 1

<= i <= 5, is a column vector and lies in a

certain feature space.

3.1.1 Textual Features

The Title & Description group features (F1, and F2)

are represented using the information retrieval

vector space model. (Salton, McGill, 1983). The

basic idea is to construct a word dictionary of all the

words that appear in any of the objects in the dataset,

and to prune or eliminate stop words, then, the size

of the word dictionary is further reduced using

stemming (Frakes, Baeza-Yates, 1992). Suppose f1

unique words remain in the dictionary after such

elimination. A unique identifier is assigned from 1

to f1 to each of these words. Now, for each group x

in the dataset, the first 2 vectors F1 & F2 will be an

f1-dimensional vector. The j

column entry, 1 <=

j <= f1, of F1 & F2 is the number of occurrences

of the j

word in the title or description respectively

in group x. Finally, each of the two components F1

and F2 is normalized to have a unit Euclidean norm

(Singhal et al., 1996), that is, their directions are

retained and their lengths are discarded (Modha,

Spangler, 2003)

The similarity measure used for these textual

features is the Euclidean distance. The less the

distance the more similar the groups are.

3.1.2 Network Feature

The Network feature (F3) is an attribute or feature in

the user profile as well as in the discussion group. A

group could have one or more networks and the

subscriber of a group could also belong to more than

one network. This feature is represented as a set of

values representing the networks given as an

attribute of the group.

A similarity relationship matrix of the networks

is built based on the members of the groups; for

example, network N1 and network N2 could be

considered highly related if many members belong

to both networks. The relation is based on

association analysis which is useful for discovering

interesting relationships hidden in large datasets

(Tan et al., 2006). We built the Network dataset

from the networks of the users to which they belong;

for example, if a user belongs to Egypt, AUC-Egypt

and IBM, then a transaction Egypt, AUC-Egypt,

IBM is added to the dataset. After building the

dataset we generate a 2 item set (the set of paired

items (2-Networks) in the dataset. We evaluate the

relationship based on objective measure that is

computed using the frequency counts tabulated in a

contingency table that is used to compute the

correlation between a pair of networks using

Pearson’s correlation coefficient. The value of

correlation ranges from -1 (perfect negative

correlation) to +1 (perfect positive correlation). If

the variables are statistically independent then the

value is 0. The whole process is repeated for every

couple of networks and a similarity relationship

matrix for m networks, was built. The similarity

measure between two groups is calculated using this

similarity matrix by taking the average of the

similarity measures between the networks in one

group and the networks in the other group.

3.1.3 Type and Subtype Features

The Type & Subtype features (F4 and F5) are of

categorical nature. A group could have one or more

type and one or more subtype features values. These

features are represented as a set of values

representing the types and subtypes.

A similarity relationship matrix of types is built

using the members of the groups, for example type

T1 and type T2 could be considered highly related if

many members subscribe to groups have both types.

If a user subscribed in a group that has Business,

Geography and Music as types then a transaction of

Business, Geography, and Music is added in the type

dataset. The similarity relationship is based on

association analysis in the same way as we did for

network feature. The same approach was also used

for the subtype feature values to build a similarity

matrix for the subtypes. The similarity measure

between two groups using the type feature is

calculated using the type similarity matrix by taking

the average of the similarity measures between the

types’ values in one group and the types’ values in

the other group. The similarity measure using the

subtype feature is calculated in the same way using

the subtype feature similarity matrix.

3.2 Clustering Discussion Groups using

a Combined Similarity Measure

The minimization problem of the classical Euclidean

k-means is known to be NP-complete (Kleineberg et

al., 1998). So we used an adaptation of the classical

LABEL ORIENTED CLUSTERING FOR SOCIAL NETWORK DISCUSSION GROUPS

207

K-means algorithm which is the bisecting K-means

algorithm. The bisecting K-means algorithm is based

on a simple idea; to obtain k cluster split the set of

all objects into two clusters, select one of these

clusters to split and so on until k clusters have been

produced or a threshold is reached. Bisecting K-

means has less trouble with initialization because it

performs several trial bisections and takes the one

with the lowest sum of the squared errors (SSE) and

because there are only two centroids at each step

(Tan et al., 2006).

Finding weights for combining the features

similarity measures is an optimization problem.

Genetic algorithm (GA) is well known method to

solve such optimization problem. At the heart of the

genetic algorithm is the Chromosome. The

Chromosome represents a potential solution and is

divided into multiple genes. There is also what is

called the fitness function. In our case the weights of

the features similarity measures are represented as

genes with values that range from 1..5. The fitness

function was decided to be the Silhouette function

(Tan et al., 2006) which is a well known function

that measures the quality of clustering a dataset. The

bigger the value of this function the better is the

solution.

4 EVALUATION

METHODOLOGY

Due to the lack of the evaluation dataset, we used a

crawler to crawl 1000 Facebook discussion groups

as to test our clustering approach. Facebook was

chosen because of its popularity and diversity in

discussion groups. Moreover, Facebook provides

APIs to access the required information. A crawler is

built that crawls the discussion groups to collect the

group identification numbers and then used the APIs

to collect all the other information required like the

title and description and all other Meta features.

The Silhouette Coefficient was used as it

integrates the cohesion and separation quality

measures of clustering. The steps explaining how to

compute the Silhouette coefficient for an individual

object in a cluster, is given in (Tan et al., 2006). The

basic idea is to measure the average distance of an

object (discussion group in our work) in a cluster to

all objects in the same cluster (a

) and to get the

minimum distance of the same object to other

objects in other clusters (b

). Then compute the

Silhouette coefficient using the following formula:

Silhouette coefficient = (b

- ai) / max (a

, b

)

The average Silhouette coefficient of a cluster

can be computed by simply taking the average of the

silhouette coefficients of objects belonging to the

cluster. An overall measure of the goodness of a

clustering can be obtained by computing the average

silhouette coefficient of all points. The Silhouette

coefficient values range from -1 to +1. The greater

the value of the coefficient the better the clustering

is.

In order to apply the Silhouette, the distance

between groups is used instead of similarity. For

textual feature we have already proposed the

Euclidean distance while the inverse of the similarity

measure will be used for network feature and the

inverse of the similarity measure is used for type and

subtype features.

5 EXPERIMENTS

Several experiments have been conducted to show

the impact of using multi-features on the quality of

the clustering. In order to do that, three experiments

were conducted. The first experiment was conducted

using features having the same type, the second

experiment was conducted using different

combinations of features, while the third experiment

was conducted using all features with equal and

different weights for each feature.

5.1 Single Type Features Clustering

In this experiment, the groups were clustered based

on a single type of features and the evaluation was

based on the whole set of features in order to have a

solid common ground to be able to make a fair

comparison and show how other features that are

not counted for in the clustering affects the quality

of the clustering. The implemented clustering

approach was applied on the dataset to generate 10,

20 and 40 clusters then measuring the Silhouette

coefficient values for each run. The results in Table

1 show that using the Type and Subtype features for

clustering provide the best clustering, while the

network feature came as the second best independent

of the number of clusters.

5.2 Multiple Feature Clustering

In this experiment, the focus is on showing the effect

of combining more than one feature on the quality of

clustering. Different combinations of the features

were used in the clustering and as the previous

experiment; the evaluation was based on the whole

set of features in order to have a solid common

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

208

ground in comparing the output. Applying the

implemented clustering to generate 10, 20 and 40

clusters then measuring the Silhouette coefficient

values for each run, the results are shown in Table 2.

Table 1: Single Feature Clustering.

Clusters Number Clustering Features Silhouette

10 Clusters Title & Description 0.45

Type & Subtype 0.58

Network 0.56

20 Clusters Title & Description 0.46

Type & Subtype 0.59

Network 0.56

40 Clusters Title & Description 0.47

Type & Subtype 0.59

Network 0.57

Table 2: Multiple Feature Clustering.

Clusters Features Silhouette.

Title & Description

and Network

0.60

Title & Description

and Type & Subtype

0.57

Network and Type &

Subtype

0.66

Title & Description

and Network

0.62

Title & Description

and Type & Subtype

0.59

Network and Type &

Subtype

0.67

Title & Description

and Network

0.63

Title & Description

and Type & Subtype

0.61

Network and Type &

Subtype

0.68

When comparing these results with the first

experiment results, it became clear that the effect of

combining more than one feature produces better

results. The best results were produced when

combining the Network with Type and Subtype

features while the second best was when the textual

features were combined with the Network feature. It

should also be noticed that adding the textual

features to Type and Subtype features did not have

any impact on clustering enhancement.

5.3 Multiple weighted Features

Clustering

In this Experiment, we compared the effect of

changing the weights of the features used in the

clustering. A development set of 100 groups was

taken out of the evaluation dataset, to estimate the

weights. The GA was run using the bisecting K-

means and the Silhouette function to choose the best

solutions among the solutions population generated

by the GA. Keeping the GA running for more than

36 hours with 22 evolution cycles over the

development dataset, the best weights produced

were 1, 5, 2, 4, 1 to be assigned to the group’s title,

description, network, type and subtype respectively.

The clustering was done one time using the

recommended weights and another time with equal

weights. The results are shown in Table 3.

Table 3: Multiple versus Equal Weights Assignment.

Clusters Features Silhouette

10 Different Weights (1,5,2,4,1) 0.69

Equal Weights 0.68

20 Different Weights (1,5,2,4,1) 0.73

Equal Weights 0.70

40 Different Weights (1,5,2,4,1) 0.77

Equal Weights 0.70

The results showed that the more features used

the better clustering quality is. It is also worth noting

that the weighted features clustering produced better

results than equal weights features clustering.

5.4 Analysis and Discussion

The overall analysis of the three experiment results

has revealed that:

 The best result obtained when using Type and

Subtype features only was 0.59

 The best result obtained when using the

Network, Type, and Subtype features, was 0.68

 The best result obtained when using equal

weights for all features, was 0.70

 The best result obtained when using weights

for all features, was 0.77

 The number of clusters has noticeable impact

only when clustering was conducted using

weights for features. Silhouette coefficients

ranged from 0.69 to 0.77 when the number of

clusters was 10 and 40 respectively.

 Adding the Title and Group description

features to Network, Type, and Subtype

features, without giving weights, slightly

improved the clustering quality.

 Using weights for all features improved the

clustering quality with 10% over using equal

weights

LABEL ORIENTED CLUSTERING FOR SOCIAL NETWORK DISCUSSION GROUPS

209

6 CONCLUSIONS

In this research the Bisecting K-means clustering

technique was applied to cluster the social network

discussion groups using the groups’ meta-features.

The main contributions in this paper are: assigning a

suitable similarity measure for each meta-feature,

and enhancing the clustering quality by assigning a

weight for each feature using genetic algorithms.

Making use of the data of the members of a

group; namely the networks to which they belong

and the types and subtypes of the groups they joined

was the new idea in developing the similarity

measure. The similarity measures of network, type

and subtype features were based on building

statistical correlation for analyzing relationships

between a pair of feature values of group members.

One of the important results is that giving

weights to the features has increased the clustering

quality. When more weight is given to the group

description and type features better Silhouette

coefficient was obtained. The results of the

experiments illustrates the effect of social features,

induced from members data, as the best results were

obtained when the network, type, and subtype

features are combined in the experiment in which we

tried different combinations.

As a future work, more social features; for

example, the users posts, should be investigated and

used in building the clusters and see the effect of

these social features on the clustering quality. More

experiments are needed on larger dataset to prove

the preliminary findings explained in this work.

ACKNOWLEDGEMENTS

The authors of this paper are especially grateful for

Cairo Microsoft Innovation Center CMIC, for the

support to this research.

REFERENCES

Abrantes, A., 2000. A Constrained Clustering Algorithm

for Shape Analysis with Multiple Features. ICPR, 15th

International Conference on Pattern Recognition

(ICPR'00) - Volume 1, page 1916.

Antonellis, P., Makris, C., Tsirakis, N., 2008. XEdge:

Clustering Homogeneous and Heterogeneous XML

Documents using Edge Summaries. In Proceedings of

the 2008 ACM symposium on Applied computing,

Fortaleza, pages 1081-1088.

Blake, A., Isard, M. 1998. Active Con tours, Springer,

Chastain, L., 2008. Social networking for Businesses and

Association. Cerado Inc. Half Moon Bay.

Costa, G., Manco, G., Ortale, R, Tagarelli, A., 2004. A

Tree-Based Approach to Clustering XML Documents

by Structure. In Proceedings of the 8th European

Conference on Principles and Practice Knowledge

Discovery in Databases (PKDD ’04).Pisa, pages 137-

148.

Dalamagas, T., Cheng, T., Winkel, K., Sellis, T.K., 2006.

A methodology for clustering XML documents by

structure. In Information Systems Journal, 31(3),

pages 187-228.

Doucet, A., Ahonen-Myka, H., 2002. Naïve Clustering of

a large XML Document Collection. In Proceedings of

the 2002 Initiative for the Evaluation of XML

Retrieval Workshop (INEX ’02), pages 81-87.

Eterfreund, N., 1998. Robust Tracking with Spatio-

Velocity Snakes: Kalman Filtering Approach. ICCV,

pages 433-439.

Frakes, W. B., Baeza-Yates, R., 1992. Information

Retrieval: Data Structures and Algorithms, Prentice

Hall, Englewood Cliffs.

Kleinberg, J., Papadimitriou, C., Raghavan, P., 1998. A

Microeconomic View of Data Mining. Data Mining

and Knowledge Discovery, 2(4), pages 311-324.

Lee, H., Lee, C., Kim, S., 2000. Abrupt Shot Change

Detection using an Unsupervised Clustering of

Multiple Features. In Proceedings of IEEE

International Conference on Acoustics, Speech, and

Signal Processing, Volume 6, pages 2015 - 2018

Modha, D., Spangler, S., 2003. Feature Weighting in K-

means clustering. Machine Learning, 52(3), pages

217-237.

Nayak, R., Xu, S., 2006. XCLS: A Fast and Effective

Clustering Algorithm for Heterogeneous XML

Documents. In Proceedings of the Pacific-Asia

Conference on Knowledge Discovery and Data

Mining (PAKDD ’06). Singapore, pages 292-302.

Salton, G., McGill, M. J., 1983. Introduction to Modern

Retrieval, McGraw-Hill Book Company.

Singhal, A., Buckley, C., Mitra, M., Salton, G., 1996.

Pivoted Document Length Normalization. In Proc.

ACM SIGIR, pages 21-29.

Tagarelli, A., Greco, S., 2006. Toward Semantic XML

Clustering. In Proceedings of the 2006 Siam

Conference on Data Mining (SDM ’06). Maryland,

pages188-199.

Tan, P., Steinbach, M., Kumar, V., 2006. Introduction to

Data Mining, Pearson Addison Wesley.

Witten, I., Paynter, G., Frank, E., Gutwin, C., Neville-

Manning, C., 1999. KEA: Practical Automatic

Keyphrase Extraction. In Proceedings of the Fourth

ACM Conference on Digital Libraries, Berkeley,

pages 254-255.

Zhong, Y., Jain, A., Dubuisson-Jolly, M., 1998. Object

Tracking Using Deformable Templates, ICCV, pages

440-446.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

210
