INDEXING BANGLA NEWSPAPER ARTICLES USING

FUZZY AND CRISP CLUSTERING ALGORITHMS

A. K. M. Zahiduzzaman, Mohammad Nahyan Quasem, Faiyaz Ahmed and Rashedur M. Rahman

Department of Electrical Engineering and Computer Science, North South University, Bashundhara, Dhaka, Bangladesh

Keywords: Principal Component Analysis (PCA), Linear Discriminant Analysis (LDA), Factor Analysis (FA),

Intensification, c-Means clustering, Fuzzy c-Means clustering.

Abstract: The paper presents two document clustering techniques to group Bangla newspaper articles. The first one is

based on traditional c-means algorithm, and the later is based on its fuzzy counterpart, i.e., fuzzy c-means

algorithm. The key principle for both of those techniques is to measure the frequency of keywords in a

particular type of article to calculate the significance of those keywords. The articles are then clustered

based on the significance of the keywords. We believe the findings from this research will help to index

Bangla newspaper articles. Therefore, the information retrieval will be faster than before. However, one of

the challenge is to find the salient features from hundred of features found in documents. Besides, both

clustering algorithms work well on lower dimensions. To address this, we use three dimensionality

reduction techniques, known as Principle Component Analysis (PCA), Factor Analysis (FA) and Linear

Discriminant Analysis (LDA). We present and analyze the performance of traditional and fuzzy c-means

algorithms with different dimensionality reduction techniques.

1 INTRODUCTION

Clustering is a technique that allows grouping of

related data. The clustering is generally carried out

in two dimensional spaces where each sample point

is represented by an X and Y coordinate. The

samples are then grouped together according to

some inherent property that related points share.

Among many clustering algorithms, we deal with

traditional c–means (mostly known as k-means

algorithm) and the fuzzy c-means algorithm (Han

and Kamber, 2000). Both of those techniques use the

idea of grouping points against a pre selected

centroid within the points. The distance between the

points and the centroid is calculated and they are

assigned to relevant centroids according to some

proximity. A new centroid is calculated using the

mean of all points and the process repeats until no

new centroids are found. The primary difference

between traditional c–means and fuzzy c–means is

the fact that the former uses Euclidean distance to

measure proximity and determine corresponding

clusters, where the later uses a degree of

membership to a particular cluster.

Our research uses the idea of clustering to index

Bangla newspaper articles, according to their topic.

The frequency and significance of the keywords are

the features that are used to make the clusters. The

objective for this research is to make Bangla

information retrieval faster and more meaningful.

The paper introduces data acquisition in section

2. Methodology conducted in this research is

discussed in section 3. Section 4 presents and

analyzes the performance of fuzzy and traditional c-

means algorithms. Finally, section 5 concludes and

gives direction of future research.

2 DATA ACQUISITION

Data is collected manually in our research from a

Bangla newspaper, ProthomAlo ( Prothm Alo, 2011)

which is available online. Figure 1 shows the home

page of that newspaper. We look for different type

of articles in this research and we will deal with 9

different types of articles.

The articles are collected for various days. An

example of such an article is shown in Figure 2. We

collect 332 articles of 9 different types. The articles

type and their frequencies are depicted in Table 1.

361

K. M. Zahiduzzaman A., Nahyan Quasem M., Ahmed F. and M. Rahman R..

INDEXING BANGLA NEWSPAPER ARTICLES USING FUZZY AND CRISP CLUSTERING ALGORITHMS.

DOI: 10.5220/0003492603610364

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 361-364

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Prothom Alo home page.

Table1: Type and number of articles taken.

Number Classes of Article

Assigned Name Freq

1 Crime 24

2 Politics 35

3 Business 50

4 Development 26

5 Education 16

6 Sports 50

7 Entertainment 50

8 General 31

9 International 50

Total 332

Figure 2: A news on Share Market.

3 METHODOLOGY

We have designed a very structured pre-processing

stage where we tokenize each word and prepare the

document readable to the system. Then we intensify

the features and fed it to the clustering algorithms to

group documents. The clustering algorithms perform

better in lower dimensions, therefore from hundreds

of features we only keep salient features by

dimensionality reduction techniques, namely LDA

(Fisher, 1936, McLachlan, 2004), PCA(Pearson,

1901) and FA (MacCallum,1983).

3.1 Pre-processing: Unicode Arrays as

Words

The first part of the extraction is to get the article

text from the Prothom Alo web page and keep it in

Unicode (big endian) encoded text document. We

use Matlab (Maaten, 2007) as the platform where we

test our algorithm. It is not possible to manipulate

Unicode data in Matlab. Therefore, we gather a set

of delimiters for the strings including the white

space and then tokenize every word as array of

Unicode unsigned 16 bit numbers.

For example the word “tumi” in Bengali is

represented like this:

2468 2497 2478 2495

3.2 Keyword Extraction

We use mainly the frequency of the keyword as

feature value. Initially collection of words from all

articles is considered as features. Later we pass those

words in two phases, namely keyword

intensification and rejection phase.

3.2.1 Intensification

We have built a database where we store some

words which are the major keys to a particular

article, for example, Bangla word for murder will

mostly occur in the crime articles rather than a sports

article. If we get those words we will increase the

frequency count of the feature by multiplying with a

factor. This multiplying factor may be learnt by

machine learning algorithm. However, we find the

value by trial and error method and a good

approximation found is 10.

Imposing this intensification we have a weighted

frequency feature extraction. This technique will

make the articles biased towards main keys which

will help to get scattered in group with the class

itself.

3.2.2 Rejection

We also include in the database a list of bad words

that commonly occur to articles but are meaningless

and irrelevant to the article. If we have those words

in an article, we exclude those. There are two ways

we could deal extracting these keywords:

1. Select some known previous keywords

2. Learn from the article.

We preferred the later one to use in our system.

This way we could make our system flexible that

allows us to categorize almost any type of crime

article that could be cyber-crime or neighbourhood

crime. Both will be categorized as crime articles.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

362

3.3 Dimensionality Reduction

The dimension that is found after the key word

extraction is huge to handle so we had to reduce the

dimension. As there are almost 10,000 features in a

document, we got the vectors with 10,000

dimensions. We use PCA first to reduce this huge

dimension. Then we use the Factor Analysis (FA)

and LDA. The PCA first reduce the dimension to

250. Then two other techniques, one is supervised

(LDA) and other is unsupervised (FA) to make it

down to 4 and 5. We have tested with other

dimensions and find that the clustering algorithms

do not perform well in higher dimensions. It

performs best in 4th and 5

dimensions.

3.4 Clustering

We use both traditional and fuzzy c-means

clustering to group articles. We analyze the

performance through confusion matrix. The samples

in the fuzzy clustering algorithm if had a

membership to a particular cluster as maximum

membership for that sample m, then, we checked

whether the sample gives k*m membership to other

clusters. This will introduce the concept that we

explained earlier that which article goes to which

cluster can sometimes vary on the context. This way

we could create the opportunity to classify one

article as crime and say, politics if necessary. The

crisp c-means doesn’t have that special feature.

4 RESULT ANALYSIS AND

DISCUSSION

The performance of the two clustering methods were

not much apart in terms of the accuracy. Although

our expectation was that the fuzzy clustering would

perform better, the traditional c-means algorithm

also perfom well. The variaion of the results is due

to different feature reduction technique.The

accuracy of the clustering techniques is presented in

Table 2.

The blue shades in Figure 3 are the accuracy rates

for Factor Analysis feature reduction technique and

others are for LDA feature reduction technique. The

graph clearly visualizes the differences between the

Table 2: Accuracy Rates.

3 Feat 4 Feat 5 Feat

Fuzzy LDA 91.5663 87.9518 93.3735

Fuzzy FA 31.3253 31.3253 30.7229

Crisp LDA 88.5542 91.5663 92.7711

Crisp FA 43.9759 43.3735 33.7349

Figure 3: Accuracy plots.

two feature reductions techniques although, the

algorithm for the clustering does not much differ.

Both of the algorithms are iterative and they

recalculate the centroids for each cluster using some

data for the particular algorithm. The traditional c-

means algorithm calculates the Euclidian distance to

calculate the centroids in each iteration and the

fuzzy c-means calculates the centroids using the

membership values which again are calculated by

the Euclidian distance. So, getting the similar result

is more likely.

LDA is a supervised dimensionality reduction

technique. Therefore, the extracted features get

biased towards a particular class. This helps the

samples of the same class to converge to a particular

cluster. Since FA is unsupervised, i.e., it does not

use any class information, hence samples are

grouped more sparsely than LDA in dimension

space.

The features for the data are extracted in two

different techniques. First we use LDA to reduce to

5 features. Each row in the Table 3 represents a

single class of article that was collected into the

database. Each column represents the cluster into

which a particular sample has been included.

However, the cluster number does not necessarily

correspond to the class number. In this table, what is

important to note is, how samples of a particular

class exists in a particular cluster. For example, most

of the samples of class 4 have been clustered in

cluster 4 (cl4). On the other hand, most samples of

class 7 belong to cluster 1, the rest belong to cluster

8. The point that we want to stress is that the cluster

number is arbitrary and has nothing to do with a

particular class. In this case 92% of class 7 is

clustered in cluster 1; we consider this as the

accuracy of the clustering for class 7. Using the

above theory, the average accuracy of this system, is

93.3735%. Now let us take a look at the membership

values for all of one class into all clusters. Here the

following example shows the membership values for

article class 6 for the current system.

INDEXING BANGLA NEWSPAPER ARTICLES USING FUZZY AND CRISP CLUSTERING ALGORITHMS

363

Table 3: Confusion matrix for 5 feature LDA

Fuzzy c-means algorithm.

Cl1 Cl2 Cl3 Cl4 Cl5 Cl6 Cl7 Cl8 Cl9

C1 0 0 0 0 23 0 0 1 0

C2 0 0 29 0 4 0 0 2 0

C3 0 0 0 0 0 0 0 2 48

C4 0 0 0 24 0 0 0 2 0

C5 0 16 0 0 0 0 0 0 0

C6 0 0 0 0 0 50 0 0 0

C7 46 0 0 0 0 0 0 4 0

C8 1 0 0 0 0 0 0 29 1

C9 0 0 0 0 0 0 45 5 0

Figure 4: Membership of the Articles in class 6.

In the Figure 4 we plot the membership value of

the samples on Y axis and sample numbers on X

axis. The olive line is the maximum membership

value for documents in class 6 (cl6 cluster

membership) where other are other line represent

membership to others. The Cluster 6 is the most

dominant cluster for this class. So we say documents

in class 6 are clustered in 6

cluster. On the other

hand, if we observe the class 2 articles we will see a

very different result.

Figure 5: Membership of the articles in class 2 using LDA.

The class contains 35 articles where the cluster 3,

which is represented as a magenta line in the plot

above, has the most articles in it. But around the

, in between 15

and 20

and in between 25

and 30

samples, we observe some blue lines and

purple lines which exceed the value of membership

for that of the magenta line. This enumerates some

documents are wrongly clustered in other clusters,

i.e., cluster 5 (blue line) and cluster 8 (purple line).

Table 3 contains all these data in matrix form.

It is possible that documents overlap to multiple

clusters. A particular sample might have same or

very (90%) close membership to multiple clusters.

Figure 6 presents a situation where very low

performance is achieved by unsupervised FA feature

extraction technique. There are 4 features extracted

and the membership of the samples in class 2 is

shown here:

Figure 6: Membership of the articles in class2 using FA.

It is really hard to predict from the graph how

articles are clustered to a particular cluster, rather

distributed randomly to multiple clusters.

5 CONCLUSIONS AND FUTURE

WORK

Experimental results show that reducing number of

features using LDA prevail over FA in terms of

accuracy. However, choosing the number of features

has a significant impact on accuracy. Future work

will include supervised data collection that could

result in better clustering. By improving the

weighted frequency calculation we could get better

results. Lastly, neuro-fuzzy clustering could be

exploited to learn parameters by the system itself

and perform optimally.

REFERENCES

Fisher, R, 1936. The Use of Multiple Measurements in

Taxonomic Problems In: Annals of Eugenics, 7, p.

179—188.

Han J., Kamber, M., 2000. Data Mining Concept and

Techniques, Morgan Kaufmann Publishers.

Maaten, L. J. P. van der, 2007 An Introduction to

Dimensionality Reduction Using Matlab, Technical

Report MICC 07-07. Maastricht University,

Maastricht, The Netherlands.

MacCallum, R, 1983. A comparison of factor analysis

programs in SPSS, BMDP, and SAS. Psychometrika

48 (48).

McLachlan, 2004. Discriminant Analysis and Statistical

Pattern Recognition In: Wiley Interscience.

Pearson, K. 1901. On Lines and Planes of Closest Fit to

Systems of Points in Space. Philosophical Magazine 2

(6): 559–572.

Prothom Alo website, 2011. http://www.prothom-alo.com

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

364
