ENABLING UBIQUITOUS DATA MINING IN INTENSIVE CARE

Features Selection and Data Pre-processing

Manuel Santos and Filipe Portela

Departamento de Sistemas de Informação, Universidade do Minho, Guimarães, Portugal

Keywords: Ubiquitous Data Mining, Real-time Intelligent Decision Support Systems, Organ failure prediction, Clinical

Data Mining, Intensive Care Environment.

Abstract: Ubiquitous Data Mining and Intelligent Decision Support Systems are gaining interest by both computer

science researchers and intensive care doctors. Previous work contributed with Data Mining models to

predict organ failure and outcome of patients in order to support and guide the clinical decision based on the

notion of critical events and the data collected from monitors in real-time. This paper addresses the study of

the impact of the Modified Early Warning Score, a simple physiological score that may allow improvements

in the quality and safety of management provided to surgical ward patients, in the prediction sensibility. The

feature selection and data pre-processing are also detailed. Results show that for some variables associated

to this score the impact is minimal.

1 INTRODUCTION

The decision making process is a key factor in critical

environments such as intensive care, either in

prognosis or diagnosis of the patients’ condition, for

their lives may be at risk. According to some studies,

medical error may be the eighth cause of death in

industrialized countries (Kohn, Corrigan, &

Donaldson, 2000). The development of Intelligent

Decision Support Systems (IDSS) by means of Data

Mining (DM) prediction models for mortality and

organ failure may contribute to the reduction of

medical error.

Presently, there is an IDSS for organ failure

prediction by means of DM techniques. INTCare is

being tested in the Intensive Care Unit (ICU) of

Hospital Geral de Santo António (HGSA) (Santos et

al., 2009; Vilas-Boas, Santos, Portela, Silva, & Rua,

2010; Villas Boas et al., 2010).

The high volume of clinical information that

doctors have to deal with every day in ICU’s explains

the need to rely on Decision Support Systems (DSS).

ICU’s are a complex medical environment where

patients’ condition is critical and often their lives

depend on the care provided in those units.

Furthermore, there are so many data relating to a

patient, that one person can’t effectively process it

(Donchin & Seagull, 2002). Safer, less expensive, and

higher-quality health care can be achieved using

clinical DSS (Menachemi & Brooks, 2006).

Computer-based decision support tools are supposed

to help practitioners to avoid errors, ensure quality

and improve efficiency in healthcare. Health care

providers can manually enter patient characteristics

into the computer system, but ideally, information

retrieval, registration and display should be as

automated as possible.

Hence the interest by intensive care clinicians and

researchers in the development of prediction models

based on DM to support clinical decision. The

emergence of network-based computing

environments established a new dimension to this

area, regarding distributed sources of data and

computing. The growing use portable devices and

communication networks is making ubiquitous access

to large quantity of distributed data a reality and is

changing our relationship with a real-time and

distributed environment (Kargupta, 2001).

This paper presents the experiments regarding the

INTCare system, an IDSS for ICU in real-time, and

its pervasive and ubiquitous features. It focuses on the

features selection and data pre-processing for mining

intensive care data.

2 BACKGROUND AND RELATED

WORK

Pervasive computing has been pointed as a new

261

Santos M. and Portela F..

ENABLING UBIQUITOUS DATA MINING IN INTENSIVE CARE - Features Selection and Data Pre-processing.

DOI: 10.5220/0003507302610266

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 261-266

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

paradigm for the 21st century. Significant hardware

developments, as well as advances in location

sensors, wireless communications, and global

networking, have advanced towards technical and

economic viability (Saha & Mukherjee, 2003).

Ubiquitous computing, pervasive computing and

ambient intelligence are concepts evolving in a

growing number of applications in health care and are

increasingly influencing it (Orwat, Graefe, &

Faulwasser, 2008). However, the majority of these

systems are in their prototype stages and there is a

need for advanced research on their deployment,

mainly clinical studies, economic and social analyses

and user studies. Ubiquitous computing can transform

some key features of user interaction: their location,

the scope of the service, and its duration and

frequency (Fano & Gershman, 2002).

3 PERVASIVENESS IN

INTENSIVE CARE

3.1 Requirements of HealthCare

Environments and Computer

Applications

To our knowledge, there is no IDSS that uses DM

models and addresses the important aspects of critical

environments, mainly the need for acting in real-time

in a fast, reliable, secure and ubiquitous way.

To achieve that, it is essential to make clinical

information available by ubiquitous devices

(Varshney, 2007), making possible to avoid medical

errors that occur due to lack of the correct

information when and where it is required (Kohn, et

al., 2000). The lack of correct and complete

information may lead to decision errors in 50%

(Bergs, Rutten, Tadros, Krijnen, & Schipper, 2005).

Ubiquity in electronic medical records that contain

detailed data about patients leverage their analysis by

whom is authorized, anytime and anywhere

(Varshney, 2009), allowing physicians and nurses to

act in real-time and as fast as possible.

Pervasive healthcare addresses this challenge and,

according to Varshney (Varshney, 2007), it may be

defined as “healthcare to anyone, anytime, and

anywhere by removing locational, time and other

restraints”. A pervasive IDSS may bridge most of

this gaps and help to coordinate the various activities

underlying patients care and survival (Scicluna,

Murray, Xiao, & Mackenzie, 2008), relying on

prediction and decision models that may be accessed

anywhere. Based on the work done during the

research for the INTCare project, and after a thorough

analysis of the problem, some features were identified

as being essential to the development of an IDSS.

Within this context it was determined to be essential

for an IDSS that uses DM and acts in real-time the

following features:

a) Online Learning: The system should have the

ability to operate in online mode, i.e. the DM

models must be induced using online data, in

contrast to the existing approaches that

emphasize offline learning mode.

b) Real-Time: The system must be able to act in

real-time. The process of acquisition and storage

of data should occur immediately after the

events take place;

c) Adaptability: The system must have the ability

to automatically optimize the models with the

latest data;

d) Optimization: Consists in optimizing the values

obtained by the prevision models generated,

analyzing all the results and selecting the best.

e) Data Mining Models: The success of this IDSS

depends on the accuracy of DM models, i.e. the

degree of reliability of these models should be

high;

f) Decision Models: Achieving the best results is

highly dependent on the decision models

created. These models are based on various

factors such as the decision and differentiation

that are used in predicting models, so that they

can help doctors choose the best decision during

the process of decision making;

g) Intelligent Agents: This type of agents allows

the system to work through autonomous actions

that perform some essential tasks. These tasks

support some system modules: Data

Acquisition, Management of Knowledge,

Inference and interface;

h) Pervasive / Ubiquitous: The technology of

ubiquitous computing aims to improve the living

and working environments and to build

advanced devices, infrastructure and network

operating systems.

i) Safety: This type of system that operates in

critical environments must guarantee safety for

both patients and users. By using ubiquity, some

protocols need to be followed like access,

authentication, communication (Langheinrich,

2001; Nigel, 2002; Piramuthu, 2003)

4 UBIQUITOUS DATA MINING IN

INTENSIVE CARE

Advanced analysis of distributed data for extracting

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

262

useful knowledge is the next expected step in the

increasingly connected world of ubiquitous

computing (Neaga & Harding, 2005). In this context,

UDM is attracting a great amount of attention. Much

of the DM tasks which are being done currently focus

on databases or data warehouses whose data is

physically located in one place. However, the

scenario arises where information may be located in

different physical locations. Therefore, the goal is to

effectively mine distributed data streams which are

located in heterogeneous sites (Hsu, 2002). The

challenge and the novelty of this approach is to bring

ubiquity to DM, which is the process of selecting,

exploring and modeling large amounts of data in

order to discover unknown patterns or relationships

that provide a clear and useful result to the data

analyst (Giudici, 2003). The abundance of mobile

devices, such as PDA’s and cellular phones, coupled

with the progress made in wireless communication,

has made possible to perform mobile DM (Horovitz,

Gaber, & Krishnaswamy, 2005). Consequently,

considerable effort has focused on research and

development in this area.

The main functions performed by these systems

are: (1) data acquisition of biological sensors, (2) data

analysis, to detect some abnormal situations, and if

they are detected, then (3) generation alarm and

notifying doctors so they can make the right decision

(Goñi et al., 2009). Next, we will describe the

experimental settings we worked on regarding the

data description, data pre-processing, features

selection, DM techniques used and results. We

developed prediction models for dysfunction/failure

of five organic systems - cardiovascular, respiratory,

renal, coagulation and liver - as well as the outcome.

4.1 Data Description and Pre-processing

The data were gathered in the ICU of HGSA and

were collected in the first five days of stay of thirty

two patients.

They can be divided in five groups, described below.

1) SOFA Scores:

In intensive care, there are some scores to assess

severity of illness, like the Sequential Organ Failure

Assessment (SOFA), which is commonly used in ICU

on a daily basis to score the degree of

dysfunction/failure of six organic systems –

Cardiovascular, Respiratory, Renal, Liver,

Coagulation and Neurological (Vincent et al., 1996).

SOFA is scored in a scale from 0 (normality) to 4

(failure) for each organic system. In this experiment,

we transformed the SOFA scores in binary variables,

where 0 describes normality and 1 describes

dysfunction/failure and comprises the original SOFA.

SOFA

Cardio, Resp, Renal, Liver, Coagulat, neuro

= {0,1}

The variables required to calculate de SOFA

scores derive from heterogeneous sources, with

different frequencies, as shown in table 1.

Table 1: Data sources for sofa score calculation.

SOFA

Variables Source Frequency

Cardiovascular

Blood Pressure

BM Minute

Dopamine, dobutamine,

noradrenaline

EHR Day

Respiratory PaO

/FiO

NR Day

Renal Creatinine

EHR Day

Liver

Bilirubin EHR Day

Coagulation

Blood platets EHR Day

Neurological

Glasgow Coma Score NR Hour

In the data collecting phase, we have realized that the

Glasgow Come Score is rarely registered, so it was

not possible to generate models for the neurological

system due to the missing data regarding its

evaluation. As we can see in table 1, not only

variables are registered in different sources, but also

they have different frequencies. E.g. Blood Pressure

is registered every minute, whereas creatinine is only

measure and registered once a day. Taking this into

account, for the construction of the final dataset, we

transformed every SOFA score to an hourly register,

for we are making predictions in an hourly basis.

2) Critical Events:

Despite being commonly used, the SOFA score is

controversial, for it can’t predict the precisely

individual outcome (Vincent et al., 1998). As a

consequence, research has evolved towards the use of

intermediate outcomes such as Critical Events (CE)

(Silva, Cortez, Santos, Gomes, & Neves, 2008). CE

was defined by a panel of experts and relates to four

physiological variables – Blood Pressure (BP), Heart

Rate (HR), Urine Output (UR) and Oxygen

Saturation (O2). Whenever these parameters are out

of normal ranges for 10 minutes, it is considered a CE

for the corresponding parameter. They were

calculated hourly and, subsequently, it was derived a

new variable – Accumulated Critical Events (ACE) –

to reflect the patients’ clinical evolution/severity of

illness.

3) Case Mix = {

Age, Admission type, Admission from}

4) Ratios = {ACE

, ACE

SO2

, ACE

}

5) MEWS = {MS

, MS

Temp

, MS

AVPU

}

ENABLING UBIQUITOUS DATA MINING IN INTENSIVE CARE - Features Selection and Data Pre-processing

263

The Modified Early Warning Score (MEWS) is a

simple, physiological score that may allow

improvements in the quality and safety of

management provided to surgical ward patients

(Gardner-Thorpe, Love, Wrightson, Walsh, &

Keeling, 2006). This score uses data derived from four

physiological parameters - Systolic Blood Pressure,

Heart Rate, Respiratory Rate and Body Temperature -

and levels of consciousness - Alert, Voice, Pain,

Unresponsive (AVPU) - as shown in table 2. The

MEWS (MS) uses a scale from 0 (normal) to 3

(extreme risk) to classify the danger of each score.

With the data collected in the ICU, we were able to

calculate the score for only two variables for the

MEWS: Blood Pressure and Heart Rate.

Table 2: variables and data sources for the mews

calculation.

Score

Scale

Source Frequency

Blood Pressure

BM Minute

Heart Rate

BM Minute

Respiratory Rate

BM Minute

Body temperature

BM Minute

AVPU

NR Daily

To use it in final dataset, with hourly data, it was

calculated the number of occurrences for each score in

each hour, i.e., how many minutes the values were

out of normal range (danger) and its score.

In conclusion, the data required to calculate the

variables derive from heterogeneous sources -

Bedside Monitors (BM), Nursing Records (NR) and

Electronic Health Records (EHR) - as shown in Table

2. By exploring different and incremental scenarios

we intend to attest the importance of new variables,

other than the critical events. The inclusion of ratios

points to the severity of the patient’s clinical

evolution and the inclusion of SOFA scores relates to

the multi-organ failure perspective.

4.2 Features - Incremental Approach

For the prediction of each organic system and

outcome, it was explored five scenarios regarding the

inclusion of the variables mentioned before – M1,

M2, M3, M4 and M5. Previous research (Villas Boas,

et al., 2010) has shown that the inclusion of ratios and

the SOFA scores of other organic system for the

prediction of dysfunction/failure of some systems

presented better results when comparing to the

approach on the CE alone. Accordingly, we have

added a new variable – MS - as input and compared

the results to conclude if its inclusion leads to better

results. Also, we have tried to use exclusively the MS

to predict organ failure/dysfunction of the

cardiovascular system. We used the MS only for the

prediction of this system because the only available

data relates to. Data for the other organic systems, as

shown in table 3, was not registered.

M1 = {Case Mix, CE}

M2 = {Case Mix, CE, Ratios}

M3 = {Case Mix, CE, Ratios, SOFA}.

M4 = {Case Mix, CE, Ratios, SOFA, MEWS}

M5 = {Case Mix, MEWS}

4.2.1 Modelling

The DM techniques used for the experiments were

Artificial Neural Networks (ANN), Decision Trees

(DT), Regression and Ensembles. To avoid

overfitting due to their biased distribution, we

performed normalization by using the logarithmic

function. We used fully connected multilayer

perceptron’s with 5 hidden neurons and logistic

activation function. The training technique applied

was the backpropagation algorithm. To assure

statistical significance, 30 runs were applied to all

tests. For the DT, we used Classification and

Regression Tree (CART) algorithm. The splitting

method used for partitioning the data was the Gini

reduction. The default algorithm splits a node into 2

branches and, to avoid overfitting, the maximum

number of branches from a node was set to 10 and the

splits were evaluated as a reduction in impurity (Gini

index). We used logistic regression since the targets

have a binary measurement. The selection method

used was the Stepwise. The ensemble method used a

combined mode of the ANN, DT and Regression with

the Mean probability function.

4.3 Results

Previous research has concluded that, for intensive

care, is preferable to have models that favor

sensitivity (Vilas-Boas, et al., 2010). Hence, the

assessment of the models, presented in table 3, is

made in terms of sensitivity, derived from the

confusion matrices. For each system, we present the

DM technique that had the best results for each

scenario, in terms of sensitivity.

As we explained before, MEWS could only be

used to relate to the cardiovascular system, so there

are no results for the other systems regarding M4 and

M5. Table 4 sums the results and presents, for each

organic system, the best scenario and the technique

with the best results, in terms of sensitivity.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

264

Table 3: Results by scenario and technique for each target.

Target

in terms of sensivity (%)

Cardio Respirat Renal Liver Coag Out

92.4

ANN

89.2

ANN

97.7

94.3

ANN

94.2

ANN

98.3

ANN

91.3

ANN

96.2

ANN

95.4

ANN

97.5

ANN

93.4

ANN

98.1

ANN

98.3

ANN

95.6

ANN

97.6

ANN

73.2

- - - - -

90.0

- - - - -

Table 4: Best results for each target by scenario and

technique.

Target Scenario Sens Technique

Cardio M3

93.4 ANN

Respirat

M2 96.2 ANN

Renal M3

98.1 ANN

Liver

M3 98.3 ANN

Coag

M2 97.5 ANN

Out

M1 98.3 ANN

5 DISCUSSION

This experiment focused on features selection and

data pre-processing for the construction of the final

dataset for building the DM models for prediction of

organ dysfunction/failure. The experiments about the

features selection had the objective of analyzing the

impact on models’ sensitivity of adding more

variables. Accordingly, we conclude that adding the

score MEWS not only did not result in better models,

but actually worsened their sensitivity for all systems

and outcome. E.g. prediction of the cardiovascular

system has better results using CE, ratios and SOFA

scores (93.4%), however, when we added the MEWS

scores, sensitivity decayed to 73.2%. We can’t fairly

terminate that one shouldn’t use MEWS to predict

organ dysfunction/failure.

We also concluded that, regarding features

selection, the variables to be included are highly

dependent on the organic system; there isn’t a

scenario that is better for all systems, as shown in

table 3. E.g. for the prediction of the liver system, it

should be used CE, ratios and the SOFA of the other

systems (M3), whereas for the respiratory system, the

best results are achieved by not including the SOFA

(M2). The models have achieved great results in

terms of sensitivity and the best technique for all

systems and outcome was the ANN.

The INTCare system is still being tested,

however, in the future, the tasks regarding data

preprocessing will be automatically performed by the

application, with minimal human intervention and

awareness, with an Electronic Nursing Record

(ENR).

6 CONCLUSIONS AND FUTURE

WORK

In this paper we presented the work undergoing the

INTCare system, a real-time IDSS for intensive care.

We developed DM models for prediction of organ

dysfunction/failure and outcome and we presented the

scenarios and techniques we experimented.

As shown in table 3, the inclusion of the new

variable MEWS did not contribute to a better

performance of the models in terms of sensitivity.

However, one mustn’t discard this line of

investigation because in this experiment we only used

two out of six scores for MEWS. It would be

interesting to, in future research, rebuild the models

with all the six variables of MEWS and compare the

results. Also in future work, we will continue towards

ubiquity and pervasiveness of the system, with the

features presented in section 3 regarding DM and

decision models and intelligent agents and some

problems related to web traffic need to be studied and

predicted (Piramuthu, 2003).

ACKNOWLEDGEMENTS

The authors would like to thank FCT (Foundation of

Science and Technology, Portugal) for the financial

support through the contract PTDC/EIA/72819/2006.

REFERENCES

Bergs, E. A. G., Rutten, F. L. P. A., Tadros, T., Krijnen, P.,

& Schipper, I. B. (2005). Communication during

trauma resuscitation: do we know what is happening?

Injury, 36(8), 905-911.

Donchin, Y., & Seagull, F. J. (2002). The hostile

environment of the intensive care unit. Current opinion

in critical care, 8(4), 316.

Fano, A., & Gershman, A. (2002). The future of business

services in the age of ubiquitous computing.

Communications of the ACM, 45(12), 87.

Gardner-Thorpe, J., Love, N., Wrightson, J., Walsh, S., &

Keeling, N. (2006). The value of Modified Early

Warning Score (MEWS) in surgical in-patients: a

prospective observational study. Annals of The Royal

ENABLING UBIQUITOUS DATA MINING IN INTENSIVE CARE - Features Selection and Data Pre-processing

265

College of Surgeons of England, 88(6), 571.

Giudici, P. (2003). Applied data mining: Statistical methods

for business and industry: John Wiley & Sons, Inc.

Goñi, A., Burgos, A., Dranca, L., Rodríguez, J.,

Illarramendi, A., & Bermúdez, J. (2009). Architecture,

cost-model and customization of real-time monitoring

systems based on mobile biological sensor data-

streams. Computer Methods and Programs in

Biomedicine, 96(2), 141-157.

Horovitz, O., Gaber, M. M., & Krishnaswamy, S. (2005).

Making sense of ubiquitous data streams - A fuzzy

logic approach. In R. Khosla, R. J. Howlett & L. C. Jain

(Eds.), Knowledge-Based Intelligent Information and

Engineering Systems, Pt 2, Proceedings (Vol. 3682, pp.

922-928). Berlin: Springer-Verlag Berlin.

Hsu, J. (2002, 2002). Data mining trends and

developments: The key data mining technologies and

applications for the 21st century.

Kargupta, H. (2001, 2001). CAREER: Ubiquitous

Distributed Knowledge Discovery from Heterogeneous

Data.

Kohn, L. T., Corrigan, J., & Donaldson, M. S. (2000). To

Err Is Human: Building a Safer Health System:

National Academy Press.

Langheinrich, M. (2001). Privacy by Design - Principles of

Privacy-Aware Ubiquitous Systems. Paper presented at

the Proceedings of UbiComp 2001.

Menachemi, N., & Brooks, R. G. (2006). Reviewing the

benefits and costs of electronic health records and

associated patient safety technologies. Journal of

Medical Systems, 30(3), 159-168.

Neaga, E. I., & Harding, J. A. (2005). An enterprise

modeling and integration framework based on

knowledge discovery and data mining. International

Journal of Production Research, 43(6), 1089-1108.

Nigel, D. (2002). Beyond Prototypes: Challenges in

Deploying Ubiquitous Systems, 1, 26-35.

Orwat, C., Graefe, A., & Faulwasser, T. (2008). Towards

pervasive computing in health care–A literature review.

BMC Medical Informatics and Decision Making, 8(1),

26.

Piramuthu, S. (2003). On learning to predict web traffic.

Decision Support Systems, 35(2), 213-229.

Saha, D., & Mukherjee, A. (2003). Pervasive computing: a

paradigm for the 21st century. Computer, 25-31.

Santos, M. F., Portela, F., Vilas-Boas, M., Machado, J.,

Abelha, A., Neves, J., et al. (2009). Information

Modeling for Real-Time Decision Support in Intensive

Medicine. In S. Y. Chen & Q. Li (Eds.), Proceedings of

the 8th Wseas International Conference on Applied

Computer and Applied Computational Science -

Applied Computer and Applied Computational Science

(pp. 360-365). Athens: World Scientific and

Engineering Acad and Soc.

Scicluna, P., Murray, A., Xiao, Y., & Mackenzie, C. F.

(2008). Challenges to Real-Time Decision Support in

Health Care. Agency for Healthcare Research and

Quality

Silva, Á., Cortez, P., Santos, M. F., Gomes, L., & Neves, J.

(2008). Rating organ failure via adverse events using

data mining in the intensive care unit. Arificial

Intelligence in Medicine, 43(3), 179-193.

Varshney, U. (2007). Pervasive healthcare and wireless

health monitoring. Mobile Networks and Applications,

12(2), 113-127.

Varshney, U. (2009). Pervasive Healthcare Computing:

EMR/EHR, Wireless and Health Monitoring: Springer-

Verlag New York Inc.

Vilas-Boas, M., Santos, M. F., Portela, F., Silva, Á., & Rua,

F. (2010). Hourly prediction of organ failure and

outcome in intensive care based on data mining

techniques. Paper presented at the 12th International

Conference on Enterprise Information Systems.

Villas Boas, M., Gago, P., Portela, F., Rua, F., Silva, Á., &

Santos, M. F. (2010). Distributed and real time Data

Mining in the Intensive Care Unit. Paper presented at

the 19

European Conference on Artificial Intelligence

- ECAI 2010.

Vincent, J. L., de Mendonca, A., Cantraine, F., Moreno, R.,

Takala, J., Suter, P. M., et al. (1998). Use of the SOFA

score to assess the incidence of organ

dysfunction/failure in intensive care units: results of a

multicenter, prospective study. Critical care medicine,

26(11), 1793.

Vincent, J. L., Moreno, R., Takala, J., Willatts, S., De

Mendonca, A., Bruining, H., et al. (1996). The SOFA

(Sepsis-related Organ Failure Assessment) score to

describe organ dysfunction/failure. Intensive care

medicine, 22(7), 707-710.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

266
