ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

Carlos Javier Hernandez-Castro, Arturo Ribagorda

IT&C Sec. Group (SETI), Comp. Science Dept., Univ. Carlos III, Legan´es, Madrid, Spain

Julio Cesar Hernandez-Castro

School of Computing, Portsmouth University, Portsmouth, U.K.

Keywords:

CAPTCHA, HIP, Common sense, AI, Logic reasoning, Semantic extraction, Data mining, Natural language

modeling.

Abstract:

CAPTCHAs or HIPs are tests able to tell humans and computers apart, remotely and over an untrustworthy

channel. They rely on abilities that are though to be hard for algorithms, yet easy for humans. General logic

reasoning, based on common sense knowledge, is one of the areas that are still considered hard for AI. On

the other hand, logic reasoning targeting very speciﬁc areas has achieved success in AI. In this article, we list

current Semantic and Logic CAPTCHAs and examine how strong they are. We also discuss wether this model

is suited or not for automatic challenge generation and grading.

1 INTRODUCTION

In a recent congress on Computer Security, one well

known Computer Security expert asked me why just

not use common sense questions to create strong

CAPTCHAs. I tried to explain him all the associ-

ated theoretical problems, but I can tell that he was

not very convinced, thinking that his idea was strong

enough.

He is not the only one. Some CAPTCHA de-

signers think alike, and also many programmers

that design their own CAPTCHAs to protect their

sites. There are several on-line discussions about

CAPTCHA user-friendliness, and why not to use

logic-CAPTCHAs to improve it

. In this article,

we intend to present the current situation regarding

Logic and Semantic CAPTCHAs: which ones are be-

ing used, how are they performing, speciﬁcally how

strong they are against simple attacks.

1.1 Organization

The rest of the paper is divided into a very brief intro-

duction to the state of the art of CAPTCHAs; an intro-

duction to the state of the art of Logic and Semantic

Some examples at http://www.tylercruz.com/captcha-vs-

human-logic/, at http://www.rubyﬂow.com/items/209 or at http://

www.w3.org/2004/Talks/0319-csun-m3m/slide15-0.html.

CAPTCHAs, along with a deﬁnition of them; a brief

discussion on their security, as well as a more thor-

ough discussion on one of the most used ones; a gen-

eral discussion on Logic and Semantic CAPTCHAs;

and a conclusion, summarizing our results and what

we consider should (not) be future trends in Logic and

Semantic CAPTCHA design.

2 BRIEF HISTORY OF

CAPTCHAs

Any active Internet user has already faced

CAPTCHAs several times. If you have been

asked to pick up images with a certain property from

a set, to read a very distorted word, to hear and

write part of an speech, to drag and drop one image

from a set into a region, or to answer a common

sense question, you have already faced a CAPTCHA

challenge.

CAPTCHA history commences when engineers

from Yahoo! met a research team at CMU to explain

their problem with bots joining online chats and pro-

moting web addresses. The CMU team came with

an idea for a test for telling humans and computers

apart, and a set of rules that any such a test should

have. Their test (EZ-GIMPY) was put into produc-

tion at Yahoo! with initial success. However, the ﬁrst

157

Javier Hernández-Castro C., Ribagorda A. and Cesar Hernandez Castro J..

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs.

DOI: 10.5220/0003517001570167

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2011), pages 157-167

ISBN: 978-989-8425-71-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

instance of a CAPTCHA in a production system was

the one at the AltaVista search engine

. Although the

ﬁrst time that the idea was mentioned was even before

(Naor, 1996).

The original problem that created the need for

CAPTCHAs has aggravated in the recent years.

Nowadays it is not only about preventing spam, but

also about ticket scalping, search engine ranking ma-

nipulation (or SEO, Search Engine Optimization),

dictionary attacks for retrieving account passwords,

automatic registration (for phishing, social network

information gathering, spam through SMS services,

instant messaging, etc.), automatic voting in on-line

polls, creation of on-line traps (as bride proﬁles in

dating services), aggregation of information from dif-

ferent on-line sources, different scams (through sites

that include reputation rankings, or fake job advertise-

ments in on-line listings for mule recruiting), denial

of service (DoS) through consumption of limited re-

sources (stock booking), etc.

The initial success of CAPTCHAs did not last

very long. Within a few years most text-based

CAPTCHAs were broken. Concern over the strength

of this kind of CAPTCHA impelled research in the

ﬁeld. But many of the new proposals had several

drawbacks and resulted to be not as strong as intended

by their authors. Examples of CAPTCHAs that were

initially considered hard and resulted not to be so

have been ASIRRA

, IMAGINATION

, Captcha2

reCAPTCHA

, the Google text CAPTCHA, the orig-

inal Hotmail CAPTCHA

, Yahoo! CAPTCHAs (all

three reportedly broken several times), different au-

dio CAPTCHAs, etc. Several others resulted weak as

well: the QRBGS CAPTCHA (Hernandez-Castroand

Ribagorda, 2009a), PHP3BB CAPTCHAs

, Megau-

pload

and other ﬁle-exchange services CAPTCHAs,

etc.

Used to prevent bots that automatically send URLs to the

search engine for indexing (Broder, 2001).

Presented in (Elson et al., 2007), and broken in (Golle, 2009)

and (Hernandez-Castro et al., 2009).

Presented in (Datta et al., 2005) and broken in (Zhu et al.,

2010)

Available at http://www.captcha2.com as of the 8th of Febru-

ary of 2011, and broken at (Hernandez-Castro et al., 2010b)

Introduced in several articles, as (Ahn et al., 2008), and broken

professionally, and academically by (Wilkins, 2010), currently still

in use with variations.

Hotmail is using reCAPTCHA as of January 2011.

References to several ones can be found at http://

blog.phpbb.com/2008/08/28/captchas-in-phpbb/, being the most

common http://www.codeproject.com/KB/web-security/Phpbb-

Captcha.aspx.

With a Mozilla Firefox plug-in that bypasses it at

http://skipscreen.com/.

The current situation is that just a few ’strong’

text-based CAPTCHAs are still on-line, all of them

after several major changes in their design. At the

same time, many on-line services are using partic-

ular and much weaker CAPTCHAs, that are broken

as soon as there is enough interest. A new actor has

also entered the market: the CAPTCHA breaking ser-

vices based in the combination of low-wage workers

and automatic solutions. None of the currently in use

CAPTCHAs are able to counter these services, but

there are a few proposals against them.

2.1 Current Types of CAPTCHAs

There are literally hundreds, if not thousands, of dif-

ferent CAPTCHAs out in the Internet, if we sum all

the different types and their variants. Thus, in this

section we will try to present the most representa-

tive categories, citing some examples, so as to give

an overview of the current state of the art.

Of course, evolved text-based CAPTCHAs are

still in use (Table 1). They are typically based in older

designs that have been evolved to prevent different at-

tacks put into practice against them.

Table 1: Text-based CAPTCHA examples.

There are other ideas that can be considered also

variations of text-based CAPTCHAs: using artiﬁ-

cially generated ’handwritten-like’ text (Achint and

Venu, 2008) (Rusu and Govindaraju, 2004), making

the segmentation problem harder (Baird and Riopka,

2005). Breaking away from text-based CAPTCHAs,

Chew and Tygar (Chew and Tygar, 2004) used a set

of labeled images to generate CAPTCHAs challenges

(using Google Images). Others (von Ahn and Dab-

bish, 2004) proposed other image-labeling mecha-

nisms, and other authors have used on-line human-

labeled sets of images (Elson et al., 2007) (Figure 1).

Other image-based CAPTCHAs rely on closed

databases of labeled images (Warner, 2009)

(Hernandez-Castro et al., 2010a) (Datta et al.,

2005). All mentioned image-based CAPTCHAs

have been broken (Hernandez-Castro et al., 2009;

Golle, 2009; Zhu et al., 2010), or their image-base

is considered too small to be secure. There are

other proposals for image-based CAPTCHAs (Hoque

et al., 2006), but their hardness has not properly been

analyzed.

SECRYPT 2011 - International Conference on Security and Cryptography

158

Figure 1: The ASIRRA CAPTCHA.

A logic evolution from image based

CAPTCHAs has appeared recently, and

is based in video (or animation) based

CAPTCHAs (as in (Hernandez-Castro and Rib-

agorda, 2009b), or http://www.nucaptcha.com/,

http://www.kloover.com/video-captchas/, etc.). One

interesting proposal concerning moving images is

called Emerging Images CAPTCHA (EI) (Mitra

et al., 2009) (Figure 2). There is also another

quite special proposal, the Enhanced CAPTCHA

(Athanasopoulos and Antonatos, 2006), which aims

to prevent the relay problem

Figure 2: Example of a frame of an EI animation, with the

original shape depicted to the right. Example from (Mitra

et al., 2009).

Another comprehensive approach is based in try-

ing to model the behavior of human users of a web-

site, and use that model to tell them apart from

computers. This scheme cannot be always called a

CAPTCHA, as it might lack the Public characteristic.

There are some examples of this kind of tests

, al-

though not yet very common. There are other types

of CAPTCHA that typically mix more than just one

approach. One example of these is the QRBGS (Ste-

vanovic et al., 2008) CAPTCHA, that got wide media

attention (Knight, 2007) (Vaughan-Nichols, 2008).

And, of course, there are CAPTCHAs based on the

supposedly unique ability of humans to understand

common sense and solve logic questions.

3 LOGIC AND SEMANTIC

CAPTCHAs

A Logic CAPTCHA is one in which challenges are

http://www.zdnet.com/blog/security/inside-indias-captcha-

solving-economy/1835, retrieved on the 1 of August 2010

One provider is http://www.pramana.com/.

based on a question that requires common knowledge,

and sometimes some basic logic, to be answered.

These are some examples:

• Most people have ten ﬁngers and ...toes?

• What animal quacks? ...

• What comes next? ’Monday Tuesday Wednesday

...’

• Tomorrow is Saturday. If this is true, what day is

today? ...

• Choose the three that are artiﬁcial: moon, guitar,

balloon, test, glass, snow

A Semantic CAPTCHA is the one in which the

challenges urge you to complete it (or order it, etc.)

in a way that makes sense, and also can be intended to

involve some kind of reasoning. Of course, the def-

inition of to make sense is not unique, and some an-

swers that would be valid for some individuals might

not be valid for others, including the CAPTCHA de-

signer. Some examples of semantic CAPTCHA ques-

tions are:

• Complete with a verb: Stopwatches can

...numbers

• Choose the one that makes more sense: ’A hum-

mingbird is a ...of bird’ from: small, red, type,

subconscious, stone

3.1 Current Logic and Semantic

CAPTCHAs

Most current implementations of Logic and Semantic

CAPTCHAs are quite basic. Let us provide here some

examples:

1. The CAPTCHA used at https://

help.tenderapp.com/discussion/new, which

provides 8 pre-programmed questions.

2. The CAPTCHA used at Feedsee (http://

www.feedsee.com/submit.html), which pro-

vides test-type questions (Figure 3). These tests

require the user to select the one or several

answers that are related to a certain category

(numbers, shapes, birds, metal, mythical beings,

continents, etc.). There are 5 words in each list,

so 2

possible answers.

3. Logic CAPTCHA for Kentico CMS

(Figure

4). This CAPTCHA provides some logic ques-

tions, numerical questions, comparisons, pre-

programmed statements (in ﬁle statements.txt)

that can be true or false, etc.

At http://devnet.kentico.com/Blogs/Petr-Passinger/October-

2010/New-and-Free-at-the-Marketplace–Logic-Captcha.aspx.

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

159

Figure 3: Feedse.com CAPTCHA.

Figure 4: Kentico CMS CAPTCHA.

4. http://www.purple-dogﬁsh.co.uk/free-

stuff/accessible-captcha, also allows just

pre-programmed questions.

5. http://www.vision.to/simple-accessible-logical-

captcha.php, also with pre-deﬁned questions.

6. At xda-developers forum (a well-known site

for development for HTC and Android phones,

among others), they use not one CAPTCHA

but two, a combination of reCAPTCHA and

NoSpam!

, a vBulletin

CAPTCHA plug-in

that allows to add pre-programmed questions. In

the case of the xda-developers forums, we have

detected 22 questions pre-programmed. The us-

age of NoSpam! can be tracked in search en-

gines looking for the string NoSpam! Veriﬁcation

Question, and a search engine as Google reports

approximately 66.400 web-pages containing that

string

7. http://www.vision.to/simple-accessible-logical-

captcha.php, with pre-programmed questions of

the type ’Please enter the two ﬁrst letters of: The

lazy dog went to Chihuahua’.

8. HumanAuth is a image labeling CAPTCHA, but

because the classiﬁcation it requests is not direct

(i.e., it is not enough with naming what is in the

picture), but instead requires to decide if the pic-

ture content is something natural or artiﬁcial, it

can be considered a logic CAPTCHA too. In

fact, HumanAuth has a version for vision-disabled

people, in which every image is replaced for what

More information on NoSpam! at http://www.vbulletin.org/

forum/showthread.php?t=124828.

A CMS system. More information at http://

www.vbulletin.org/forum/portal.php.

Result from Google when queried with ”nospam! veriﬁcation

question”, the 29th of December of 2010.

the image represents, and the challenge has still

the same hardness.

9. BrainBuster

(Figure 5) is a CAPTCHA pro-

grammed in Rail, which includes a module for

storing questions and answers (thus, they have to

be previously input).

10. TextCaptcha

creates different questions based

on different question types, and an internal clas-

siﬁcation of certain words (white is a colour,

etc.). Its author claims that it is able to gener-

ate 180,243,205 different questions

. It has been

easily broken (Hernandez-Castro et al., 2011),

and also by an a program accessible on-line

, and

even more easily using out of the box tools

Figure 5: BrainBuster CAPTCHA.

Figure 6: xda-developers forum registration CAPTCHAs.

There is one a bit more elaborated. It relies on

a knowledge base, and rules to create questions (and

answers) based on it. It is egglue currently in broad

use today, which we will discuss in further detail.

4 Egglue CAPTCHA

The Egglue CAPTCHA requests us to complete a sen-

tence with a verb in a way that makes sense. For that,

The BrainBuster project page can be found at https://

github.com/rsanheim/brain buster.

At TextCaptcha.com.

Statements from http://textcaptcha.com/how it works, re-

trieved on the 17th of December of 2010

It can be found at http://textcaptchabreaker.appspot.com/

As in http://joelvanhorn.com/2010/11/10/using-

wolframalpha-to-hack-text-captcha/, but with a lower success

ratio.

SECRYPT 2011 - International Conference on Security and Cryptography

160

we will have to use our common sense, and general

knowledge. The Egglue author explains in the web-

page how it is designed (Figure 7).

Figure 7: Egglue description.

To better grasp the capabilities of Egglue, some

actual questions created by it in Figure 8.

Figure 8: Egglue challenge examples.

We have analyzed the source code of the PHP

module, written by Egglue’s author, that interacts

with the Egglue server. Other developers have cre-

ated a Drupal

module for Egglue. Drupal provides

a statistic of module usage, and the count of use for

this module is currently 1,154 Drupal web-pages

We can try to estimate also the usage of this mod-

ule by querying Google with a string that is charac-

teristic of this module: ”egglue powered”. This is a

bad decision of the Drupal plug-in designer, as it eas-

ily renders a list of web-pages using this CAPTCHA

and, worse, in order of relevance for a search engine.

Anyway, processing this query in different search en-

gines gives us an estimated count of 752 web-pages

Drupal is a very popular open-source CMS system. Drupal

web site is at http://drupal.org/.

All the ﬁgures in this section about Egglue usage have been

collected on December 2010.

Figure 9: Egglue Drupal module usage statistics.

in Google, 43 web-pages in AltaVista and 866 web-

pages in Yahoo!.

4.1 Egglue Protocol

Egglue PHP source code connects to the Egglue

server for challenge retrieval and answer evaluation.

We have analyzed its communications using the well-

known Wireshark tool. Egglue’s communications run

over HTTP, and are very straightforward. When a

new challenge is requested from the Egglue server,

its basic constituents are downloaded as an XML ﬁle.

Among these, it is an unique identiﬁer (ID), that will

be sent again to the veriﬁcation server with the pro-

posed answers. Figure 10 shows an example of an

Egglue capture in the moment that it answers with the

challenge-id and the challenge clues.

Figure 10: Egglue challenge id and clues from the Egglue

server.

One error in the implementation of Egglue is that

it does not check for ID reutilization. That means that,

once one correct solution is found, we can reuse the

solution and the ID to bypass the CAPTCHA again.

We can also try different solutions for the same ID till

we ﬁnd the correct one (Figure 11). Of course, this is

a major failure in its implementation.

The user’s answer is sent to http://

api.egglue.com/verify, posted as a form, with

the following parameters:

• remoteip: the IP of the client that is connecting to

the PHP front-end to answer the challenge.

• egglue challenge: the ID of the challenge.

• egglue response1: the verb for the ﬁrst challenge

sentence.

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

161

Figure 11: If we pressed the back button on the browser, the

same ID was requested to Egglue, and we could try again to

solve the same challenge.

• egglue response2: the verb answered to the sec-

ond challenge sentence.

The veriﬁcation server sends back the string true

if the answer is consider correct by the Egglue server.

4.2 Attack

Egglue poses us a question that has to be answered

with just a verb. The question has always the same

structure: noun can ... noun, with just one variant:

noun can be also a full subject, like ”pair of pliers”.

On a ﬁrst look, many questions arise:

• How random are those questions?

• How many different subjects, direct objects and

relations are in Egglue’s database?

• Are there questions with more than one correct

answer? (supposedly afﬁrmative by Egglue’s au-

thor) How many correct answers?

• How does Egglue deduct the relationship between

the subject and the direct object?

• How does Egglue’s scoring algorithm work?

The answers to these questions will help us know

how strong is Egglue against attacks. For exam-

ple, a low randomness in the subjects, or in the rela-

tions, will make a learning attack successful. Also, if

Egglue’s scoring algorithm is a simple or of both an-

swers, it will be much weaker. We will address these

questions after we analyze the results of our attacks,

in Section 4.4.

The ﬁrst, most straightforward strategy for de-

bunking Egglue, would be to use some knowledge-

base to answer its questions. Which knowledge base

can be handy for that? There are different ones we

can use:

• search engines: for example, for answering noun1

can ... noun2, we can query a search engine

with the string ”noun1 can” noun2, or just noun1

noun2, and explore the results for the regular ex-

pression noun1 can * noun2, parsing whatever

matches the * looking for verbs.

• English corpus on-line: there are a few of them,

some even with the ability of matching up to four

words substrings, which would be ideal for our

case

• create our own corpus, by parsing several on-

line text catalogs as, for example, the Gutenberg

Project.

One particular problem in English, that is not as

bad in other languages, is being able to tell verbs from

nouns, as many words can be both. As an example,

the word word can be a noun, and also a verb. We took

here a heuristic approach, consulting on-line dictio-

naries, and counting how many deﬁnition entries we

found for the word as a noun, and as a verb. Of course

this strategy is not fault-proof, but in general, it gave

us a good rate of verb identiﬁcation. We also tried

with different alternatives, including lists of verbs,

and querying simultaneously more than one on-line

dictionries

4.2.1 Type 1 Attack : Search Engines

Our ﬁrst approach for studying the strength of Egglue

was just to use a search engine to ﬁnd the correct an-

swers. We tested several search engines, and found

Google to be the best for this purpose, for two impor-

tant reasons:

• It returned more, and more signiﬁcant, results

than the other search engines, and

• it allowed us to search using wildcards.

We created a program in Python that downloaded

an Egglue challenge (consisting in two basic chal-

lenges), asked Google using queries related to each

challenge, studied the results, and sent an answer back

to Egglue.

We tested different ways of querying Google, be-

ing all of them combinations of the following basic

queries:

• ”noun1 can” * noun2

• ”noun1 can * noun2”

• ”noun1 * noun2”

• noun1 noun2

• noun1 can noun2

The more restrictive the query (as in: ”noun1 can

* noun2”) the more signiﬁcative the results, but also

the higher chance of not getting any result, so we

As the British National Corpus, at http://bncweb.info/. Un-

luckily, we did not gain access to in on time.

We particulary liked the results from http://

www.hyperdictionary.com/search.aspx?deﬁne=program, http://

dictionary.cambridge.org/dictionary/british/program 1 and http://

www.onelook.com/?w=program&ls=a.

SECRYPT 2011 - International Conference on Security and Cryptography

162

added to the (possible) result of these queries, the re-

sults of less restrictive ones (as: noun1 can noun2). If

we found that a query had many results, we requested

Google up to the ﬁrst three pages of results (returning

20 results per page).

Google did not like much to answer these queries.

Sometimes, it detected us as a bot and made us pass

a CAPTCHA (Figure 12), and other times, it even did

not give us this option.

Figure 12: Sometimes, Google required us to pass its

CAPTCHA to continue getting results for the same query.

There are other ways of querying Google apart

from using its regular web interface. One possible

way is using the Google Web Search API

(now dep-

recated) or the (newer) Custom Search API

. Both

solutions were suboptimal, as the ﬁrst one returned

different results, in different order, and in less quan-

tity, that the regular (web) search engine, and the sec-

ond one is quota limited. That is why we stick to using

Google’s regular web interface, using HTTP Proxies

and other tools and ideas to minimize the rejection

rate of our queries.

4.2.2 Type 2 Attack : Google + Common Verbs

Combined

Sometimes, we were not able to get enough results

from Google as to be able to select a verb, that would

link both parts of the sentence. Initially, in those

cases we sent the string ’???’ as an answer, expecting

Egglue’s to not validate it, and for us to have a mark

in the log for that incident.

Of course, a natural idea would be that, in those

cases, we can just send a random verb from the n most

common, instead of a nonsense string. We tried this

approach just as an easy way to marginally improve

the results from the previous attacks. But our results

were not exactly what we expected!.

4.2.3 Type 3 Attack : Common Verbs

A simpler strategy would be to answer using ran-

dom verbs. At ﬁrst we did not even consider this ba-

http://code.google.com/apis/websearch/.

http://code.google.com/apis/customsearch/v1/overview.html.

sic strategy, but observing some weird results from

Egglue’s validation mechanism, we decided to inves-

tigate into it.

Using all English verbs would be a poor strategy,

but using the ones more common in English could be

interesting. Given a list (taken from the Wikipedia

)

of the most common verbs in English, we can answer

selecting at random among the n most common.

4.3 Attack Results

The attacks previously described were used to learn

more from the Egglue CAPTCHA internals and

strength. They were put in place in several rounds

between June and October of 2010. We will discuss

their results in this section.

After several series of the type 1 attack, we found

that we did not get signiﬁcantly different results with

one type of query or the others. The only signiﬁcant

difference came when all our queries were too restric-

tive, so much as to not get a single verb as a valid

result. Even though we sent the string ’???’ as an an-

swer to Egglue in all these cases, not all of them were

consider wrong. For example, in one of our test runs

(composed of 500 challenges) we got the following

(which include our mark ’???’) as right:

• Allen wrenches can (???) shafts, Spanners can

(loosen) nuts

• Screwdrivers can (open) locks, Pocket knives can

(???) holes

• Carriers can (hold) cats, Paring knives can (???)

holes

• Vises can (hold) rods, Razors can (???) holes

• ...

This lead us to conclude that the validation mech-

anism was clearly not an and of both sentences be-

ing correctly resolved, but maybe an or, or some kind

of summation of correctness for both sentences that

should pass a certain threshold.

In general, the type 1 attack gave a success ratio

of 50.83% (calculated for our latest test run, with 214

correctly resolved challenges – according to Egglue –

out of 421 challenges). If we use the combined type

2 attack, the success ratio raised to 68.66% (103 cor-

rectly answered out of 150). Looking into the logs of

From the article Most common words in

English, retrieved the 2nd of June of 2010

(http://en.wikipedia.org/w/index.php?title=Most common words

in English&oldid=365914607). Note that this verb list is

associated by lemmas, that is, the entry be contains within

it the occurrences of is, was, be, are, etc. This informa-

tion is referenced from the Oxford English Corpus (http://

www.oxforddictionaries.com/page/oec?view=uk).

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

163

this result in more detail, we were astonished to see

that it seemed that when we used the most common

verbs in English, the success ratio seemed to increase.

That is why we thought of the type 3 attack, just

choosing randomly among the n most common verbs

in English. Our ﬁrst test included the ﬁrst 20 most

common English verbs according to the Wikipedia

They were ordered in descending order of frequency

of appearance, and we tested values of n between 1

(which means just always answering be) and 20 (us-

ing all the 20 most common verbs) – in increments of

1. Figure 13 represents how this strategy behaves for

each value of n (with the detail of each verb added to

the pool).

Figure 13: Success ratio if we answered using the n (1 ≤

n ≤ 20) most common English verbs.

As we see, we never get results below 50%!. In

fact, if we answer randomly using just the three most

common verbs in English (be, have and do), we cor-

rectly guess the answers 79% of the time!. Of course,

this is not possible in real life, so the validation mech-

anism of Egglue must be too lax to accept verbs when

it should not. In fact, if we check the log correspond-

ing to this situation (the three most common verbs),

we see answers such as:

Choosing randomly among the 3 most common English verbs to answer

Answering strategy : 3

1 : [’Plungers can (?:have) water’, ’Blades can (?:be) flaps’]

0 : [’Electric mixers can (?:have) butter’, ’Highlighters can

(?:have) words’]

1 : [’Paintbrushes can (?:have) colors’, ’Pair of pliers can

(?:have) tabs’]

1 : [’Vacuum pumps can (?:have) air’, ’Highlighters can

(?:be) words’]

1 : [’Scissors can (?:do) ends’, ’Needles can (?:have) veins’]

1 : [’Boats can (?:be) islands’, ’Transformers can

(?:do) impedances’]

1 : [’Scales can (?:do) sizes’, ’Trowels can (?:be) concrete’]

1 : [’Forks can (?:have) eggs’, ’Lenses can (?:do) images’]

1 : [’Ladles can (?:have) fat’, ’Awls can (?:do) holes’]

1 : [’Meters can (?:have) voltage’, ’Notebooks can

(?:be) information’]

1 : [’Chainsaws can (?:do) trees’, ’Calculators can

Retrieved the 2nd of June of 2010, at

http://en.wikipedia.org/w/index.php?title=Most common words in

English&oldid=365914607.

(?:have) answers’]

1 : [’Pitchforks can (?:have) soils’, ’Screwdrivers can

(?:do) plates’]

1 : [’Sextants can (?:be) altitudes’, ’Pliers can

(?:have) wires’]

1 : [’Switches can (?:be) voltages’, ’Wooden spoons can

(?:do) rice’]

0 : [’Spatulas can (?:do) layers’, ’Pencils can (?:be) holes’]

0 : [’Rakes can (?:be) areas’, ’Toners can (?:be) skin’]

(...)

It is very disputable that Forks can have eggs

and that Lenses can do images, but this answer was

marked as correct (1) by Egglue.

After analyzing the formerly discussed Figure 13,

we thought that maybe, a reordering of the set of

verbs, in which the ones that make the success ratio

raise were used ﬁrst, could even improve our success

of bypassing Egglue. With the aim of being more

precise at which verbs were more successful, we run

a test in which we always answered with the same

verb, for all these 20 most common verbs. We though

Egglue might somehow detect it, and give a nearly

0% success rate in this scenario, but we were wrong.

Figure 14 shows the results from this test. Amaz-

ingly, if you always answer make to Egglue, you solve

it 96.5% of the times. Two other verbs (get and take)

can be used it to solve it over 90% of the time. Not

only that, other six verbs (have, do, put, keep, run,

and go) can be used to solve it more than 80% of the

time. All verbs pass the CAPTCHA more than 30%

of the time, being think the one with the lowest score,

an still impressive 32.5%.

Figure 14: Success ratio of each of the most common En-

glish verbs.

Given that it is considered that a success rate of

0.6% is enough to consider a CAPTCHA broken (Zhu

et al., 2010) (others consider them broken with lower

rates, such as 0.01%) the current implementation of

the Egglue CAPTCHA can be considered completely

broken, using a simple strategy: always answering

make. Or, if you do not like being repetitive, you can

answer randomly among make, get and take, and still

score 95% of the time. A summary of our attack re-

sults can be seen in table 2.

SECRYPT 2011 - International Conference on Security and Cryptography

164

Table 2: Egglue attacks and their success ratios.

Attack Success ratio (%)

Search Engine 50.83

S.E. (restr.) & 20 most fr. verbs 68.66

20 most frequent verbs 73.5

3 most frequent verbs 79

make & get & take 95

make 96.5

4.4 Other Egglue Design Problems

Other Egglue versions, or derived CAPTCHAs might

get better at scoring the meaningfulness of a sentence.

If that is the case, we might need to resort to the origi-

nal idea of Data Mining (in our case, no more than an

advance search engine is needed) to bypass it. Even

that might be problematic if the CAPTCHA is really

well designed.

Unluckily with Egglue, this is not the case. When

we tested our ﬁrst basic automatic attacks against

Egglue, we were surprised of some of our ﬁndings.

We though that Egglue was able to do some kind

of data mining for creating a knowledge base, based

on which challenges were created. We expected this

knowledge base to be broad enough, and to cover dif-

ferent areas. Our ﬁndings were a bit different:

• Many of the objects used for creating the chal-

lenges were related to mechanics, electronics, and

engineering in general. That is, items like ”The

Moon”, or abstract ones like ”Attraction”, do not

appear at all, or rarely.

• Many of the subjects are repeated. And worse

than that,

• When subjects are repeated, they frequently are

related to the same subset of direct objects.

Not only the subject of the clues is not wide and

uniformly distributed: worse, the number of clues is

not enough. If we count the appearance of the dif-

ferent clues (in Egglue’s terminology, the beginning

and ending of each sentence) in a test round in which

we downloaded 6,000 compound challenges (14,000

sentences), we only found 710 different clues. As

an example, in another test run of 2,000 challenges

(that would be a maximum number of 8,000 different

clues) we found just 676 different clues (Figure 15).

The total number of categories is going to be well un-

der 1500.

Another problem is the frequency in which these

clues appeared. In table 3 you can see the ﬁrst 15

more frequent clues, and the least 15 frequent ones.

Just the 10 most frequent clues account for 11, 28% of

appearances. Learning how to answer to those with a

fair success rate will also bypass this CAPTCHA.

Figure 15: Number of new clues per every ten compound

challenges (20 sentences).

Table 3: Egglue ratios of clue appearance.

25% most frequent 25% least frequent

Clue # % Clue # %

holes 550 2, 29 clinometers 1 0, 004

screws 312 1, 3 spring balances 1 0, 004

ends 282 1, 17 candles 1 0, 004

paintbrushes 249 1, 03 jointers 1 0, 004

areas 243 1, 01 vessels 1 0, 004

pair of pliers 228 0, 95 grounds 1 0, 004

images 215 0, 89 bars 1 0, 004

water 214 0, 89 sheep 1 0, 004

air 214 0, 89 lists 1 0, 004

nuts 201 0, 83 forces 1 0, 004

signals 199 0, 82 dimensions 1 0, 004

spatulas 185 0, 77 pushpins 1 0, 004

prisms 174 0, 72 hand drills 1 0, 004

hammers 167 0, 69 pulp 1 0, 004

Such a big deviation from a standard distribution

makes Egglue weaker than necessary.

4.4.1 Egglue Scoring Algorithm

Apart from that, we discovered that the scoring al-

gorithm was not very precise. Sentences that clearly

make sense were scored as wrong, wether sentences

that were clearly wrong were scored as right. For

example, during our ﬁrst basic attacks, we used the

mark ??? for those times in which our (initial) algo-

rithm did not ﬁnd a verb suitable for answering. Even

though, some of these answers containing ??? were

scored as correct!. It also happened than sometimes

our algorithms incorrectly classiﬁed a word as a verb,

and used it for answering the challenge ...and some

of these challenges answers were reported as correct

(!). A few of the answers that were scored as correct,

when they clearly should have not, and correct ones

classiﬁed as wrong, are shown in table 4.

5 OTHER CONSIDERATIONS

The logic and semantic CAPTCHAs will always have

their advocates, as it is simple to think of improved

schemes that will ﬁlter typical bots. The problem is

that people designing those schemes will typically not

consider how easy it would be to circumvent them

for a bot, if they became popular enough, or if they

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

165

Table 4: Examples of Egglue wrongly scored answers.

Wrongly scored as correct.

Allen wrenches can (???) shafts

Spanners can (loosen) nuts

Knives can (bit) bits

Micrometers can (selected) diameter

Screwdrivers can (open) locks

Pocket knives can (???) holes

Lasers can (remove) tissues

Soldering irons can (buy) wires

Stopwatches can (unlimited) numbers

Magnetic compasses can (indicate) directions

Awls can (make) holes

Wrenches can (cleco) valves

Socket wrenches can (bolts) screws

Screwdrivers can (remove) plates

Forks can (contain) eggs

Hatchets can (get) wood

(...)

Wrongly scored as wrong.

Cranes can (reach) trees

Heating pads can (relieve) pain

Notebooks can (?:get

) information

Rakes can (seed) seeds

Smokers can (?:eat) bees

Tape measures can (measure) lengths

Can openers can (punch) holes

Atlases can (map) maps

Notebooks can (provide) information

Spanners can (tighten) nuts

(...)

are used to protect an interesting site. Let us give the

following example: on-line journals that allow com-

ments on news, as well as blogs that allow comments

on new posts, are typical sites for bots to wander and

publish their spam. One can argue that, as every en-

try in these systems should be done by an human (the

reporter, or the blog author), then it would be easy for

them to add one or two logic questions derived from

the text. For example, if in my blog about Charles

Darwin I create a new entry about his school years,

then I can easily add the following two questions for

anyone trying to post a comment:

• How many siblings did Charles Robert Darwin

have?

• With which brother did he attended Edinburgh

University?

Do you consider a general CAPTCHA scheme

like this a good idea? It is a very bad idea: both ques-

tions can be answered with one single word. Even

worse: it is a word that will be in the article!. Even

if we select more complex questions, as At Edinburgh

University, what could Charles not bear? (being cor-

rect answers the sight of blood or suffering), a sub-

string of just three consecutive words from the text

can be used to correctly answer.

Also, the ﬁeld of data mining is quickly improv-

ing. As an example, IBM has created an application,

based on data mining and parallel computing, that is

able to beat human players when playing the popu-

lar TV game Jeopardy

. It would be hard to base a

CAPTCHA on a private data mining algorithm (thus,

a CATCHA, without the P) that would prevail long

enough. If instead we use a corpus of private knowl-

edge, what is going to assure us that there is not a

public corpus which intersects with ours in a non null

set?

Other possibilities arise. We can think of a new

logic CAPTCHA which questions can be based on

telling the word, in a list, that does not correspond

to the rest. For example: Which word does not belong

to the list: blue green cat red?

. A quick access to

Google Sets

would be enough to answer it (Figure

16).

Figure 16: Start of Google Sets answer for blue green red.

6 CONCLUSIONS AND FURTHER

WORK

In this article we have presented the state of the art of

logic and semantic CAPTCHAs. We have seen that,

despite their current limitations and weaknesses, there

is a certain amount of hype and misunderstanding of

their capability in telling humans apart from comput-

ers.

We have analyzed in more detail one particular

CAPTCHA that is currently being used by hundreds

of web-sites, called Egglue. We have found that the

strength claims made by its author are unfortunately

not withstanding. We have seen that other popu-

lar logic CAPTCHAs (as the TextCaptcha, the Fed-

dsee.com CAPTCHA, BrainBuster, etc.), presented in

this article, share a similar fate.

More information on this subject can be found at http://

www-943.ibm.com/innovation/us/watson/research-

team/index.html.

Example taken from the word list CAPTCHA at http://

drupal.org/project/captcha pack.

Google Sets can be found at http://labs.google.com/sets.

SECRYPT 2011 - International Conference on Security and Cryptography

166

We conclude that there is not a strong enough

logic or semantic CAPTCHA to be put into produc-

tion. Also, designers willing to create new logic and

semantic CAPTCHAs should be aware of the com-

mon pitfalls done when estimating their strength.

We do not recommend to pursue research on this

line of CAPTCHA design. We consider at least un-

certain that a possible logic CAPTCHA is anything

else than a chimera. Instead, we recommend future

CAPTCHA designers to explore other ways of creat-

ing a CAPTCHA that have not to do with logic, se-

mantic, or data mining, because of the many possibil-

ities for CAPTCHAs based on those principles to be

ﬂawed.

REFERENCES

Achint, T. and Venu, G. (2008). Generation and perfor-

mance evaluation of synthetic handwritten captchas.

In Proceedings of the First International Conference

on Frontiers in Handwriting Recognition, ICFHR.

Ahn, L. V., Maurer, B., Mcmillen, C., Abraham, D., and

Blum, M. (2008). recaptcha – human-based character

recognition via web security measures.

Athanasopoulos, E. and Antonatos, S. (2006). Enhanced

captchas – using animation to tell humans and com-

puters apart. In Leitold, H. and Markatos, E., editors,

Communications and Multimedia Security, volume

4237 of Lecture Notes in Computer Science, pages

97–108. Springer Berlin – Heidelberg.

Baird, H. S. and Riopka, T. (2005). Scattertype: a read-

ing captcha resistant to segmentation attack. In

Proc., IS&T/SPIE Document Recognition and Re-

trieval Conf, pages 16–20.

Broder, A. (2001). US Patent no. 6,195,698.

Chew, M. and Tygar, J. D. (2004). Image recognition

captchas. In Image Recognition CAPTCHAs, pages

268–279. Springer.

Datta, R., Li, J., and Wang, J. Z. (2005). Imagination: a ro-

bust image-based captcha generation system. In MUL-

TIMEDIA ’05: Proceedings of the 13th annual ACM

international conference on Multimedia, pages 331–

334, New York, NY, USA. ACM.

Elson, J., Douceur, J. R., Howell, J., and Saul, J. (2007).

Asirra: a captcha that exploits interest-aligned manual

image categorization. In CCS ’07: Proceedings of the

14th ACM conference on Computer and communica-

tions security, pages 366–374, New York, NY, USA.

Golle, P. (2009). Machine learning attacks against the asirra

captcha. In Proceedings of the 5th Symposium on Us-

able Privacy and Security, SOUPS 2009, Mountain

View, California, USA, July 15-17, 2009, ACM Inter-

national Conference Proceeding Series. ACM.

Hernandez-Castro, C. J. and Ribagorda, A. (2009a). Pit-

falls in captcha design and implementation: the math

captcha, a case study. Computers & Security.

Hernandez-Castro, C. J. and Ribagorda, A. (2009b). Video-

captchas. In Proceedings of the 5th International Con-

ference on Security and Protection of Information,

Brno.

Hernandez-Castro, C. J., Ribagorda, A., and Hernandez-

Castro, J. C. (2011). Do current logic and semantic

captchas make sense?

Hernandez-Castro, C. J., Ribagorda, A., and Saez, Y.

(2009). Side-channel attack on labeling captchas.

http://arxiv.org/abs/0908.1185.

Hernandez-Castro, C. J., Ribagorda Garnacho, A., and

Saez, Y. (2010a). Side-channel attack on the huma-

nauth captcha. In Proceedings of the International

Conference on Security and Cryptography.

Hernandez-Castro, C. J., Stainton-Ellis, J. D., Ribagorda,

A., and Hernandez-Castro, J. C. (2010b). Shortcom-

ings in captcha design and implementation – captcha2,

a commercial proposal. In Proceedings of the Eighth

International Network Conference (INC2010).

Hoque, M. E., Russomanno, D. J., and Yeasin, M. (2006).

2d captchas from 3d models. In Proceedings of the

IEEE SoutheastCon.

Knight, W. (2007). Newscientist entry on the qrbgs captcha.

Retrieved on the 14th of August, 2010.

Mitra, N. J., Chu, H.-K., Lee, T.-Y., Wolf, L., Yeshurun, H.,

and Cohen-Or, D. (2009). Emerging images. ACM

Transactions on Graphics, 28(5).

Naor, M. (1996). Veriﬁcation of a human in the loop or

identiﬁcation via the turing test.

Rusu, A. and Govindaraju, V. (2004). Handwritten captcha

– using the difference in the abilities of humans and

machines in reading handwritten words. Frontiers in

Handwriting Recognition, International Workshop on,

0:226–231.

Stevanovic, R., Topic, G., Skala, K., Stipcevic, M., and

Rogina, B. (2008). Quantum random bit generator

service for monte carlo and other stochastic simula-

tions. In Heidelberg, S.-V. B., editor, Lecture Notes in

Computer Science, volume 4818, pages 508–515.

Vaughan-Nichols, S. J. (2008). Techworld.com article on

fallen captchas. Retrieved on the 14th of August,

2010.

von Ahn, L. and Dabbish, L. (2004). Labeling images with

a computer game. In Press, A., editor, CHI ’04: Pro-

ceedings of the 2004 conference on Human factors in

computing systems, pages 319–326. ACM Press.

Warner, O. (2009). Kittenauth. http://www.thepcspy.com/

kittenauth.

Wilkins, J. (2010). Strong captcha guidelines. http://

bitland.net/captcha.pdf.

Zhu, B. B., Yan, J., Li, Q., Yang, C., Liu, J., Xu, N., Yi,

M., and Cai, K. (2010). Attacks and design of image

recognition captchas. In Proceedings of the 17th ACM

conference on Computer and communications secu-

rity, CCS ’10, pages 187–200, New York, NY, USA.

ACM.

ON THE STRENGTH OF EGGLUE AND OTHER LOGIC CAPTCHAs

167
