ADAPTIVE ASSESSMENT BASED ON DECISION TREES

AND DECISION RULES

Irena Nančovska Šerbec, Alenka Žerovnik and Jože Rugelj

Faculty of Education, University of Ljubljana, Ljubljana, Slovenia

Keywords: Adaptive assessment, Formative assessment, Machine learning, Decision tree, Decision rules.

Abstract: In the e-learning environment we use adaptive assessment based on machine learning models called

decision trees and decision rules. Adaptation of testing procedure relies on performance, current knowledge

of test participants, on the goals of educators and on the properties of knowledge shown by participants. The

paper presents sequential process of adaptive assessment where human educator or intelligent tutoring

system uses different adaptive rules, based on machine learning models, to make formative assessments.

1 INTRODUCTION

Educational assessment is the process of evaluation

and documenting, usually in measurable terms,

knowledge, skills, attitudes, and beliefs. In the e-

learning environment we need assessment that is,

besides being valid and reliable, quick and

automated. The last two properties could be

achieved by means of adaptive assessment. E-

assessment involves the use of a computer to support

assessment which happens in the case of web-based

assessment tools.

Computerized adaptive testing (CAT) systems

are computer supported tests that adapt to the

student's knowledge level and use a shorter number

of queries tailored to his individual characteristics

(Wainer, 2000). The existing computerized adaptive

testing (CAT) systems base their adaptation mainly

on the learner’s performance using statistical

models, which can be considered as restrictive from

a pedagogical viewpoint. As it will be discussed

later, some novel adaptation approaches for testing,

which seem more pedagogically promising, have

already been suggested (

Nirmalakhandan, 2007;

Lazarinis, Green, & Pearson, 2009, 2010; Sitthisak,

Gilbert, & Davis, 2008).

Many research communities work on

adaptability of learning objects in the e-learning

environment. Their work is based on different

learning theories and practices, cognitive

psychological research and teaching strategies.

Adaptability is the main property of intelligent

tutoring systems (ITS) that provide direct

customized instruction or feedback to students. They

can be classified as an intersection of education,

psychology (cognitive science, developmental

psychology) and computer science (artificial

intelligence, multimedia, Internet) (Woolf, 2009).

The paper presents prospective software tool for

adaptive testing based on machine learning models,

such as decision tree (Nančovska Šerbec et al, 2006,

2008) and decision rules. The tool could be used in

the blended learning scenario for formative and self-

assessment, after the topic is taught by the educator

(see Figure 2). Adaptation of the assessment to

individual student relies on the following factors:

• current knowledge of the student,

• goals of the educator/student,

• properties of the knowledge absorbed by the

participants

From the e-learning point of view, data mining

or artificial intelligence applications in e-learning

could be divided into the following categories

(Castro at al, 2007):

1. Applications dealing with the assessment of

students’ learning performance.

2. Applications that provide course adaptation

and learning recommendations based on the

students’ learning behaviour.

3. Approaches dealing with the evaluation of

learning material and educational Web-based

courses.

473

Nan

covska Šerbec I., Žerovnik A. and Rugelj J..

ADAPTIVE ASSESSMENT BASED ON DECISION TREES AND DECISION RULES.

DOI: 10.5220/0003521104730479

In Proceedings of the 3rd International Conference on Computer Supported Education (ATTeL-2011), pages 473-479

ISBN: 978-989-8425-50-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

4. Applications that involve feedback to both

teachers and students of e-learning courses,

based on the students’ learning behaviour.

5. Developments for the detection of atypical

students’ learning behaviour.

Our system could be classified into categories 1

and 4. Machine learning methodologies decision

trees and decision rules are data mining methods,

which means that our research could be ?related? to

the field of educational data mining (EDM) (Baker

& Yacef, 2009; Romero & Ventura, 2010).

In the next section we will present the

architecture of the proposed tool for adaptive

assessment.

2 ADAPTIVE ASSESSMENT

TOOLS

A Computer Adaptive Test (CAT) can be defined as

a test, administered by a computer where the

presentation of each item (exercise, question, task)

and the decision to finish the test are dynamically

adapted according to the answers of the examinees.

CAT tools are used mainly as skill meters presenting

the overall learner’s score on a subject and a

pass/fail indication. More specifically, test items

dynamically adjust to student’s performance level,

and as a result, tests are shorter and test scores tend

to be more accurate (Lazarinis, Green, & Pearson,

2009).

In this paper a framework for creating adaptive

tests is presented (see Figure 1),. The framework

incorporate rules (based on machine learning

models) which allow personalized assessments. The

Web tool implementing the framework supports the

sequence of adaptive exercises (Gouli et al,, 2002).

In the following subsections we describe the

main parts of adaptive testing tool, for modelling the

adaptive engine. We continue with machine learning

models which are used to generate if-then rules for

adaptation.

2.1 Components of the Adaptive

Testing Tools

Typically, adaptive e-learning tools consist of four

parts that work closely together (see Figure 1,

Lazarinis, Green, & Pearson, 2009). The domain

model maintains the topics, concepts and other

fragments that are used in creation? of lessons. User

(student) models contain information about the

learners that varies from demographics (name,

address, etc) to their current knowledge and to

learning style and preferences.

The adaptation model is a part in the adaptive

multimedia tool. Model consists of collection of

rules that define how the adaptation must be

performed. The rules are used for updating the user

model through the generated relationships between

the concept and the existing learner knowledge. The

final part, the adaptive engine, performs the actual

adaptation. The adaptation model describes the

conditions and the actions on which the presentation

of the information is based and the adaptive engine

implements these rules. In the presented adaptive

system the domain model consists of the topics and

the testing items that are adaptively presented to the

learners. The user model component of the exemplar

adaptive learning tool corresponds to the learner

profile module of our adaptive testing tool. The

adaptation model consists of a set of customizable

if-then-else rules concerning performance,

knowledge and the goals of the test participants

(Lazarinis, Green, & Pearson, 2009).

In the paper, we are concerned only with the

design of the adaptation model and not with other

components of adaptive testing tool. The adaptation

engine selects the current exercise by following the

rules defined in the adaptation model.

2.2 Decision Tree

A decision tree is a decision support tool that uses a

tree-like graph or model of decisions and their

possible consequences.

Decision trees are generated or induced by using

datasets that consist of validated statically generated

tests with wide set of exercises. Through the process

of building of decision trees we capture the

knowledge structure of the statically tested students.

Process of assessment is routed by decision tree

structure and it is ended by student’s classification

by reaching the tree leaf.

The procedure of generating decision tree from

training set is called induction of the tree. We start

with blank tree and whole set of training objects.

Then on every step with the help of heuristic

evaluation function we choose an attribute

(exercise), which wasn't used jet (Witten & Frank,

2005). If there is not enough training objects or if the

data contains missing values, then it usually leads to

overfitting. The result of that are large trees with a

lot of unimportant branches. That's why it is

important where to stop growing of the tree by using

the procedures for pruning unimportant branches. In

most of the algorithms today we can find a

CSEDU 2011 - 3rd International Conference on Computer Supported Education

474

mechanism called n-fold cross validation, which is

one of the mechanisms for preventing the overfitting

of the model to the training set). The final model is

built on a whole training set.

The algorithm for tree induction, which selects

the attributes (problems) in the nodes, utilizes the

high dependency among attributes (problems).

2.3 Decision Rules

Decision rules are tree-like structures that specify

class membership based on a hierarchical sequence

of (contingent) decisions. For generation decision

rules we used RIpple-DOwn Rule learner . It

generates a default rule first and then the exceptions

for the default rule with the least (weighted) error

rate. Then it generates the "best" exceptions for each

exception and iterates until pure. Thus it performs a

tree-like expansion of exceptions. The exceptions

are a set of rules that predict classes other than the

default (Weka, 2010).

3 EXPERIMENTAL SETTINGS

We suppose blended learning scenario. In the

following subsection we will explain the activities

taken in order to design the adaptation model.

3.1 Diagram of Activities

Diagram of activities taken to model the system, is

given in the figure 3. By these activities we gather

information about students, their knowledge,

learning styles, preferences, etc. In the paper we are

concerned with activities labelled in grey boxes.

Student (learner profile) and domain modelling will

be part of further research.

The first step of designing of the adaptation

model is presentation of thematic unit by the

educator After the presentation of the thematic unit

by a professor (in our case elementary mathematics

“Expressions”, “Introduction into programming with

programming language Pascal” or “Common

knowledge about European Union” (Nančovska

Šerbec at al. 2006, 2008), we carry out static (not-

adaptive) web-testing of students with wider set of

questions, e.g. 20-30 questions or exercises. Each

exercise is randomly selected from the set of items

of the selected topic. We use items scored correct

(associated with number of points) or incorrect.

Questions of type: “choose correct answer” or “fulfil

the answer” are solved for each domain.

For example, the domain of EU consists of web-

inquire results. Static tests were sent to students and

teaching staff on a program study of computer

science at the Faculty of Education. Solved tests

were anonymously stored in MySQL database. We

have collected 120 instances. The test contained 20

questions, each of them marked with 5 points. The

values of the attributes were numerical (except the

attribute class which was descriptive) and they

presented achieved points of an individual student

for each individual question. The maximum number

of points for the test was 100. Attribute Success was

the rating of student into three classes as regards the

points achieved on the test.

For machine learning modelling we use the open

source software tool Weka: tree-induction algorithm

J4.8 and RIpple-DOwn Rule learner RIDOR

(Witten, Frank, 2005)

After the generation of decision trees/rules we

implement the adaptive model based on the tree

structure. Table 1 presents the classification

accuracy of the tree and the rules. We can see that

the classification accuracy of decision tree is better.

The system asks questions sequentially, one after

another. In the background, algorithm follows the

structure of decision tree. The question in the root of

a tree is given to all students. (see Figure 4) After

they answer particular question, the algorithm

chooses the next one regarding to the correctness of

the current answer. The testing is finished after the

leaf of decision tree/decision rule is reached. It

means that student’s knowledge is successfully

rated.

A set of decision rules built on the EU domain is

given In the Figure 2. Although their classification

accuracy is worse compared to decision trees, they

represent interesting pedagogical paradigm for

assessment because we suppose that all participants

belong to predefined class, e.g. excellent. For

example, the last subgroup of rules in the Figure 2

can be interpreted in following manner: the test

participant knowledge about EU is excellent, but he

doesn’t know the number of languages used in EU.

In that case his knowledge is sufficient. If the

participant doesn’t know the correct answer to the

following questions: the number of languages used

in EU, which country doesn’t belong to EU, the

meaning of EU logo and the country name where the

Danube rises, we can classify his knowledge as not

sufficient. The adaptive system based on decision

rules uses four questions to make decision whether

the participant knowledge is not sufficient. To

diagnose the excellent knowledge on the EU topic,

the system uses three questions: the year of

ADAPTIVE ASSESSMENT BASED ON DECISION TREES AND DECISION RULES

475

Figure 1: Main components of the adaptive testing tool (Lazarinis, Green, & Pearson, 2009; 2010).

Table 1: Classification accuracy (in %) of decision tree on each domain (10-fold cross validation/whole training set).

Domain

Decision tree accuracy

(cross val./whole set)

Decision rules accuracy

(cross val./whole set)

Expressions (math.) 76/100 73/83

Programming 95/98 82/90

EU knowledge 88/96 85/95

Figure 2: Decision rules for EU domain.

class = excellent (120.0/117.0)

Except (foundation <= 2.5) => class = sufficient (60.0/0.0) [31.0/0.0]

Except (contry_not_EU <= 2.5) and (not_EU_inst <= 2.5) and

(ECTS <= 2.5) => class = not_sufficient (3.0/0.0) [1.0/0.0]

Except (mean_of_EU_logo <= 2.5) => class = suff. (12.0/0.0)[5.0/0.0]

Except (contry_not_EU <= 2.5) and (not_EU_inst <= 2.5) =>

class = not_suff. (3.0/0.0) [2.0/1.0]

Except (no_laguages_EU <= 2.5) => class = suff. (3.0/0.0)

[2.0/0.0]

Except (contry_not_EU <= 2.5) and (meaning_of_EU_logo <= 2.5)

and (Danube_rise_country <= 2.5) => class = not_suff. (2.0/0.0)

[2.0/1.0]

CSEDU 2011 - 3rd International Conference on Computer Supported Education

476

day of Europe

not EU

institution

Not suff. (4)

not member

Suff. (67/2)

establishment

ECTS

Suff. (25/2)

Number

languages

Suff. (9)

Suff. (3)

Excel. (9/1)

Figure 3: Diagram of activities.

Figure 4: Decision tree on the domain of EU.

Mark Meaning

Correct answer

Incorrect answer

Leaf’s

mark

Joint num. of

class.

instances/incorr.

class. instances

Excel.

9/1

Suff.

103/4

Not suff.

Solving of the

wider web tests

(Stude

)

web , TV…

(information

sources)

Collaboration:

material distribution

among peer s

(Student)

Learning –

individual or

in the group

(

Student

)

Student

Educator

Presentation of the

thematic unit (

(educator)

Learning style

identification

(student)

Modelling the

domain of solved

tests

(Educator/ITS)

Personalized learning

materials

Learner centric and outcome

based orientation

Models as feedback

information

Personalized tests

ADAPTIVE ASSESSMENT BASED ON DECISION TREES AND DECISION RULES

477

foundation, the meaning of the EU logo and the

number of EU languages.

If we need a quick, adaptive testing without

realization of wider, static test, we can use models

related to population of student with similar learning

properties. Because testing with wider static test is

expensive, it could be carried out on a representative

pattern of students.

4 PEDAGOGICAL VALUE OF

MODELS

Assessment is a part of the developmental process of

learning and is related to the accomplishment of

learning outcomes. Recently, the main goal of

assessment has shifted away from content-based

evaluation to intended learning outcome-based

evaluation. As a result, by means of assessment the

focus has shifted towards the identification of

learned capability instead of learned content. This

change is associated with changes in the method of

assessment.

Self-assessment is a crucial component of

learning. Questions should be appropriate to the

learner’s level of knowledge based on the concept of

a hierarchy of knowledge and their cognitive ability

in order to use questioning more effectively as a

pedagogical strategy (Sitthisak, Gilbert, & Davis,

2008).

Our models for adaptive assessment could be

used as a part of formative assessment tool. With

quick, adaptive self-assessment individual student

can follow his progress and gain the feedback

information about the success of his learning.

Other possible purpose of such a tree could be

directing students in the learning process with the

purpose to improve his/her learning outcome.

Students classified in the left leaves in the tree

structure could be directed to adopt topics which

distinguish them from the right or better classified

colleagues.

Another benefit for a teacher is an overview on

the accomplished learning outcomes in the group.,

he can easily find out the main topics which need to

be explained again From the decision tree, because a

great deal of students did not accomplish the

learning goals on that area. A teacher needs to

recognize if a misunderstanding is due to lack of

student’s knowledge or due to difficulty of the

exercise.

A tree or a group of decision rules also gives us

the information about difficulty level of specific

exercises or assignments for specific group. It is

interesting to compare those results from the tree

and the learning outcomes levels from the

predefined curricula. With respect of levels of

learning outcomes, teacher can recognize the main

areas where students need more explanation or

additional exercise.

We can see that models are beneficial from

different points of view. They are allowing teachers

to see their students as individuals and also give

teachers the information about a whole group of

learners or individual classrooms. There is also a

benefit from the student’s point of view. Why should

the student take a long and exhausting test when he

can achieve the same feedback with just a few

questions and exercises? The main benefit for the

student is that a tree or the applied decision rules are

not allowing to ask a question or to offer an exercise

with the same learning goals that he has already

proven to be accomplished before.

A test will begin with an exercise that is on the

root of the tree. This is the exercise with the learning

goal that has been proven to be the most decisive.

The next exercise will depend on whether the

answer was true or false. This will be repeated until

it reaches the leaf of the tree or it comes to a

decision. Decision can be whether a grade or a

descriptive rating. In this way we can test a group of

students and allow each student to have a

personalized test to achieve the feedback as quickly

and as accurate as possible.

5 CONCLUSIONS

We modelled the students’ knowledge captured in

the tests on knowledge about the selected thematic

units. Decision trees and decision rules are

interesting models not only because they are

predictors of learning outcomes but because of the

transparency of their structure. As knowledge

structures, they are interesting for teachers as

feedback information about the learning outcomes of

their students.

For students, they are interesting as a paradigm

for adaptive formative assessment or self-assessment

where the adaptation of the assessments relies on

factors such as the knowledge, educational

background, goals, preferences and performance of

the learners.

One limitation of the tree-based approach is that

the question/exercise/problem related to the topic in

the root of the tree is asked all students. Another

limitation is that the tree should be built off-line,

CSEDU 2011 - 3rd International Conference on Computer Supported Education

478

before the adaptive assessment, and its structure

doesn’t adapt to the knowledge shown through the

current adaptive assessments. Other limitation is that

the students should answer all the questions in the

nodes on the path from the root to the leaf, without

possibility to omit some of them. Weakness of these

models is that their classification accuracy is in

average around 90%. Wrong classification can be

especially problematic in the cases of successful

students with low self-confidence. Besides this, we

can not predict how the rating will influence on the

motivation of students.

The adaptive assessment tool is in its initial

testing phase and a lot of improvements are needed.

REFERENCES

Albert, D. and Mori, T. (2001) Contributions of cognitive

psychology to the future of e-learning. Bulletin of the

Graduate School of Education, Hiroshima University,

Part I (Learning and Curriculum Development), 50, p.

25-34.

Baker R. & Yacef K. (2010). The State of Educational

Data Mining in 2009: A Review and Future Visions.

Journal of Educational Data Mining, Volume 1, Issue

1 1: 3– 17.

Castro F., Vellido A., Nebot A. and Mugica F. (2007)

Applying Data Mining Techniques to e-Learning

Problems, In Studies in Computational Intelligence

(SCI) 62, 2007, p. 183–221.

Colace, F., & De Santo, M. (2010). Ontology for E-

Learning: A Bayesian Approach. IEEE Transactions

on Education, 53(2), 223-233

Giannoukos, I., Lykourentzou, I., & Mpardis, G. (2010).

An Adaptive Mechanism for Author-Reviewer

Matching in Online Peer Assessment, 109-126.

Gouli, E., Papanikolaou, K., & Grigoriadou, M. (2002).

Personalizing Assessment in Adaptive Educational

Hypermedia Systems. Assessment, (ii), 153-163.

Lazarinis, F., Green, S., & Pearson, E. (2009). Focusing

on content reusability and interoperability in a

personalized hypermedia assessment tool. Multimedia

Tools and Applications, 47(2), 257-278. doi: 10.1007/s

11042-009-0322-8.

Lazarinis, F., Green, S., & Pearson, E. (2010). Creating

personalized assessments based on learner knowledge

and objectives in a hypermedia Web testing

application. Computers & Education, 55(4), 1732-

1743. Elsevier Ltd. doi: 10.1016/j.compedu.2010.07.

019.

Nančovska Šerbec I., Žerovnik A. and Rugelj J. Machine

Learning Algorithms Used for Validation of the

Student Knowledge, MIPRO 2006, May 22-26, 2006,

Opatija, Croatia. Vol. 4, Computers in education, p.

95-100.

Nančovska Šerbec I., Žerovnik A. and Rugelj J.(2008)

Adaptive assessment based on machine learning

technology. V: AUER, Michael E. (ur.). International

Conference Interactive Computer Aided Learning ICL,

September 24- 26 2008, Villach, Austria_. The future

of learning - globalizing in education. Kassel:

University Press, cop.

Nirmalakhandan N. (2007) Computerized adaptive

tutorials to improve and assess problem-solving skills,

Computers & Education 49, 2007, p.1321–1329.

Romero C. and Ventura S.. Educational Data Mining: A

Review of the State-of-the-Art. IEEE Tansactions on

Systems, Man and Cybernetics, part C: Applications

and Reviews, 40(6), 601-618, 2010.

Sitthisak, O., Gilbert, L., & Davis, H. (2008). An

evaluation of pedagogically informed parameterised

questions for self-assessment. Learning, Media and

Technology, 33(3), 235-248. doi: 10.1080/174398

80802324210.

Triantafillou, E., Georgiadou, E., & Economides, A.

(2008). The design and evaluation of a computerized

adaptive test on mobile devices. Computers &

Education, 50(4), 1319-1330. doi: 10.1016/j.compedu.

2006.12.005.

Weka 3 - Data Mining with Open Source Machine

Learning Software, The University of Waikato: <http:

//www.cs.waikato.ac.nz/ml/weka/>,downloaded in

2010.

Witten I. H. and Frank E. (2005) Data Mining: Practical

machine learning tools and techniques, 2nd Edition,

Morgan Kaufmann, San Francisco.

Woolf, B. P. (2009). Building Intelligent Interactive

Tutors for revolutionizing e-learning. Pragmatics.

ADAPTIVE ASSESSMENT BASED ON DECISION TREES AND DECISION RULES

479
