DATA CONCERN AWARE QUERYING FOR THE

INTEGRATION OF DATA SERVICES

∗

Muhammad Intizar Ali, Reinhard Pichler

Database and Artiﬁcial Intelligence Group, Vienna University of Technology, Vienna, Austria

Hong-Linh Truong, Schahram Dustdar

Distributed Systems Group, Vienna University of Technology, Vienna, Austria

Keywords:

Data Services, Database as a Service, Data Services Integration, Data Concerns, XQuery.

Abstract:

There is an increasing trend for organizations to publish data over the web using data services. The published

data is often associated with data concerns like privacy, licensing, pricing, quality of data, etc. This raises

several new challenges. For instance, it must be ensured that data consumers utilize the data in the right

way and are bound to the rules and regulations deﬁned by the data owner and data service provider. Current

Data Integration systems using data services lack the ability to preserve data concerns while querying multiple

services in an integrated environment. In this paper, we design a new querying system which takes data

concerns into account. It supports automatic service selection based on data concerns and perfectly ﬁts into

dynamic data integration applications.

1 INTRODUCTION

More and more data providers are reaping the bene-

ﬁts of Web 2.0 technology and provide their data on

the web either through web services, APIs (REST/-

SOAP), or data services – also referred to as Data

as a Service (DaaS) (Dan et al., 2007; Hacig

et al., 2002). Data services combine the strength

of database systems and query languages on the one

hand with the beneﬁts of service-oriented architecture

on the other hand. Many big companies have started

to publish their data via query interfaces (rather than

simple forms in html) so that the data can be eas-

ily reused, composed and integrated with other data

sources. Amazon Public Data Sets on AWS

, Google

Squared

and UN data API’s are some prominent ex-

amples of publicly available data services.

Data services are increasingly used for data inte-

gration. Many tools and techniques are available to

dynamically compose, integrate and execute differ-

ent data services or sources

(Mykletun and Tsudik,

∗

This work was supported by the Vienna Science and

Technology Fund (WWTF), project ICT08-032.

http://aws.amazon.com/publicdatasets/

http://www.google.com/squared/

http://virtuoso.openlinksw.com

2006). These tools help to create situational applica-

tions by composing existing data services. The data

thus published and processed is often associated with

data concerns like privacy, licensing, pricing, quality

of data, etc. Hence, data integration tools not only

have to mitigate the heterogeneity in data formats and

query languages. In addition, also the various data

concerns should be preserved when data is published

and utilized. Moreover, data service selection and

data selection should be based on these data concerns.

Consider for example, a meta-search query (a query

that is posed against many data sources and selects

the best possible integrated results among them). A

user query will be executed on multiple data services

registered at the integrated application. After integrat-

ing the results of all the data services, usually top-k

results (where k is a constant value deﬁned by the ap-

plication) are returned. Now consider that different

users have different priorities for the data selection,

e.g., one user may be more interested in quality of

data while another user is more concerned about the

pricing. There is a clear need for an explicit system

that (semi)automatically selects the most appropriate

data service as well as data items for each user ac-

cording to various data concerns.

Some data concerns like data quality, privacy, and

quality of service (QoS) have long been studied in

111

Ali M., Pichler R., Truong H. and Dustdar S..

DATA CONCERN AWARE QUERYING FOR THE INTEGRATION OF DATA SERVICES.

DOI: 10.5220/0003548401110119

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 111-119

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

their respective domains of databases, data mining

and web services. However, data services are dif-

ferent. Recently, the importance of distinguishing

data services from web services has been recognized

(Truong and Dustdar, 2009). For instance, while li-

censing and quality of data are usually static for web

services, they are dynamic for data services. Indeed,

as the data gets “older”, the licensing and the data

quality (of which the up-to-dateness may be an im-

portant aspect) will most probably change. Moreover

data concerns can be dynamically updated. Hence

static information about usage permission or privacy

cannot deal with the requirements of the dynamic in-

tegration application created by composing data ser-

vices on the ﬂy. Hence, new techniques are required

to integrate data concerns into data services.

Among the various data concerns, privacy has re-

ceived most attention. It has been studied in many

different areas like data integration (Bhowmick et al.,

2006; Clifton et al., 2004), data mining (Zhang and

Zhao, 2007), and web services (Kobsa, 2001; Creese

et al., 2009). In (Mrissa et al., 2010) and similarly

in (McSherry, 2009), privacy has been studied in the

context of data services. However a systematic inte-

gration of data concern awareness into data services is

still missing to date. Moreover, previous approaches

of dealing with data concerns like privacy do not di-

rectly integrate the data concern awareness into the

query language, even though this would be very im-

portant for enabling the querying system to select the

best suited data source for various parts of a given

query. The goal of this work is to design a querying

system (i) which can take arbitrary data concerns into

account, (ii) which integrates the data concern aware-

ness into the query language, and (iii) which automat-

ically selects the appropriate data sources depending

on current context, user requirements and data con-

cerns.

Structure and Summary of Results. The main re-

sults of this paper are as follows.

• Roles and Concerns. In Section 2, we lay the

foundations of our study by identifying the actors in-

volved in data services and their speciﬁc concerns.

In contrast to common web services, there are nor-

mally three actors involved, namely consumer, ser-

vice provider, and also a data provider.

• Models. In Section 3, we present four possible

models of data concern aware querying. We discuss

the characteristics and virtues of each model and se-

lect the best suited one for our system.

• System. In Section 4, we come up with our data

concern aware querying system. We describe how

meta-data is organized and stored by this system and

how data concern awareness is integrated directly into

the XQuery language.

• Implementation and Evaluation. We report on an

implementation of our data concern aware querying

system and an evaluation on benchmark tests in Sec-

tion 5.

• Conclusion. Finally, in Section 6, we give a con-

clusion and point out directions for future work.

Related Work. In (Truong and Dustdar, 2009), the

authors give an overview of data concerns and dis-

cuss the different parties and their roles in data ser-

vice creation and utilization. As mentioned above,

there have been attempts to incorporate privacy con-

cerns into data services (Mrissa et al., 2010; Mc-

Sherry, 2009). Data source selection has been long

discussed in the database and information retrieval

community and different algorithms have been de-

veloped for optimal selection of the database (French

et al., 1999). Different frameworks and techniques

are available for the best service selection in a web

service environment (Maximilien and Singh, 2004).

In (Boulakia et al., 2004), the authors consider user

preferences for data source selection while (Liu et al.,

2004) used QoS attribute for the service selection. Se-

lection of data services based on data concerns has

not been considered so far. A query language exten-

sion method has been used to provide additional func-

tionality for the integrated applications. A framework

for data quality aware queries is presented by extend-

ing SQL query language (Yeganeh et al., 2009) while

privacy aware querying language has been designed

for preserving privacy in distributed query evaluation

(Farnan et al., 2010). To the best of our knowledge,

there is no querying system available for data concern

aware querying to integrate data services.

2 DATA SERVICES: ROLES AND

DATA CONCERNS

The concept of data services is based upon the

service-oriented architecture (SOA), which includes

standardized processes for accessing data “where

it resides” irrespective of the platform. Data ser-

vices take advantage of service-oriented architecture

to offer users a mediator for integrating information

from database systems and other structured or non-

structured data sources. Data services thus realize

a layer of software between the physical, distributed

data sources and the applications or services which

want to access the data. The data is exposed to the

customer via a virtual data model. It is the responsi-

bility of the data service to connect to the back-end

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

112

Consumer

Service Provider

Or Developer

Results

SemanticsDescription

Description Semantics

Parties “become known” to each other

Semantics

Description

Data Provider

Policy

Query

AgreementPolicy

Parties “agree” to provide data service

Data

User Query

Results

Agreeme

Figure 1: Conceptual architecture of the data services.

data sources via the available interfaces and to map

the physical data schema to the virtual data model.

The applications and services using the data service

leverage this virtual data model to access the required

information and the data service software handles the

collection and distribution of the data as needed from

the physical instances of the data. Figure 1 gives an

overview of the conceptual architecture of the data

services.

The traditional approach to the design of data ser-

vices is that the service provider and consumer agree

on how the service shall be used. The terms of this

agreement are usually static and are not altered over

time. Typically, data services in the form of inte-

gration server products have connectors or adaptors

built to connect applications together. A number of

them have added or will add new connectors for data

service applications such as integration adaptors for

salesforce

. However, the static nature of agreements

on data concerns is a severe drawback of the existing

technology – in particular in dynamic data integration

scenarios using mashups or cloud strategy. Moreover,

several important aspects of data integration applica-

tions are not addressed in these solutions, such as (1)

automatic updates, (2) changes of regulations, and (3)

changes of the location of the data.

2.1 Roles of the Data Service

As can be seen in Figure 1, there are three actors

involved in a data service architecture, namely Data

Provider (DP), Service Provider (SP), and Consumer.

Below we discuss each of them brieﬂy.

Data Provider. The Data Provider is responsible to

provide the actual data for the service. The DP is not

necessarily the owner of the data, since data can also

http://salesforce.com/

be outsourced. But it is the responsibility of the DP to

ensure the availability of the data for the usage by the

data service. All the concerns related to the data must

also be communicated to the service provider. Some

data concerns for the data provider like the privacy

and permission concerns can vary from data item level

to the whole data source level.

Service Provider. The Service Provider entity is

the person or organization that provides an appropri-

ate agent to implement a particular service. Service

Provider is owner of the data service. After making

the arrangement with the DP, the SP deﬁnes the func-

tionality of the service. It is responsibility of the SP to

make sure that all the concerns deﬁned by the various

data providers are preserved while the service is used.

Consumer. The consumer is a person or organization

that wishes to make use of the data service. It will

use a requester agent to exchange messages with the

provider agent. In most cases, the requester agent in-

teracts with the provider agent to exchange messages.

The requester entity and provider entity agree on the

service description (e.g. a WSDL document) and the

semantics that will govern the interaction between the

requester agent and the provider agent.

2.2 Data Concerns for Data Services

Data services have different requirements and con-

cerns compared with traditional web services. Data

provided through data services is usually associated

with many data concerns(Truong and Dustdar, 2009;

Truong and Dustdar, 2010). These concerns must be

precisely described, organized and stored in such a

way that the SP is capable of preserving these con-

cerns while querying any data source.

For the sake of simplicity we have chosen a few

of the most important concerns as shown in Table 1.

DATA CONCERN AWARE QUERYING FOR THE INTEGRATION OF DATA SERVICES

113

Table 1: Some data concerns associated with data services.

Category Scope Data Concern Description

Data Data Timeliness Deﬁnes the life time and freshness of the data

Quality Level Accuracy Data correctness and consistency

Completeness Missing information in terms of null values etc.

Availability Deﬁnes possible access limitations

Quality Service Performance Deﬁnes performance of the data service,

of Level e.g. execution time, response time

Service Reliability/availability What is the failure probability and what is the

recovery time in case of failure

Dependability/Trust Reputation, how trustful is the data service

Service Location Location of the service execution

License Data Usage Permission/Rights How a data service can be used

Level Data Location Deﬁnes where the data resides

Usage Fee Deﬁnes the fee associated with the usage of

the data or data service

Law Enforcement Deﬁnes laws which are used to deal with the

use of the service

Each concern can be categorized into a particular cat-

egory depending on the type of the concern. Every

category of the data concerns has its scope which will

be either service level or data level (for further details,

see Section 4.1).

2.3 Data Service Systems with Data

Concerns

Figure 2 describes the activities in a data service sys-

tem with data concerns. As an initial step, both DP

and SP mutually agree to provide the facility of the

data service. The data provider is required to provide

accessibility to its data for the service operations. The

DP should provide a mechanism to access its data and

additionally provide data concerns associated with the

data. The user can also contribute to the data concerns

meta-data by providing her preferences. Such infor-

mation can be easily managed using proﬁling tech-

niques. The service provider describes the service op-

erations to access the data sources. This access can be

realized via a query language, REST/SOAP or a pa-

rameterized query for structured data. The SP has to

make sure that all the concerns deﬁned by the DP are

preserved.

3 MODELS OF DATA CONCERN

AWARE QUERYING

Figure 3 depicts four possible models for querying

data services with concerns. As already discussed in

Section 2 there are three actors/roles involved. For the

sake of simplicity we assume that Data Provider and

Service Provider have already agreed on the storage

format of the data concerns: we assume that this in-

formation is stored in the form of an XML document

whose schema will be described in Section 4.1.

The main difference between the models pre-

sented in Figure 3 is due to the way how the data con-

cerns are associated with the queries that are posed

against the data sources: The models in Figure 3(a)

and (b) use the “Querying With Concerns” paradigm.

In this case, the system sends a pair hQ, Ci to the data

source, where Q is the query for the data service and

C is the collection of data concerns associated with

the query. Each data service must be capable of pre-

serving these concerns by using its own individual

querying system. The models in Figure 3(c) and (d)

are based on “Concern Aware Querying”. The ser-

vice provider has the concerns either stored locally or

fetched dynamically and is capable of writing queries

in such a way that they preserves all the data concerns

associated with the particular query and its relevant

data source.

Below we brieﬂy discuss each of the models

shown in Figure 3

Model (a): Querying with Data Concerns. Figure

3(a) shows the basic model of querying with data con-

cerns. DP and SP have mutually agreed and have ac-

cumulated their data concerns. These data concerns

are stored by the SP. A user query Q is subdivided into

multiple sub-queries for multiple data sources. The

SP must be capable of retrieving the data concerns

meta-data of a particular data source and attaching it

to the query. The data provider must be capable of

taking care of the supplied concerns while executing

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

114

Consumer

Service

Provider

Data Service

Data Source

Data Provider

Data Concerns

Data Service

Operations

owns

Data Concerns

describes

Concern

Aware Query

designs

constrains

describes

ensures

queries

uses

implements

provides

executes

describes

Figure 2: Activities in data concern aware data service systems.

the query and returning the results.

Model (b): Query with Data Concerns with Cen-

tralized Repository. This model deals with the

generic data concerns stored in a centralized repos-

itory. Such a model is best suited for an inter-

organization data integration system, where data con-

cerns are homogeneous for all of the data sources of

the organization. As shown in Figure 3(b) this model

is very similar to the existing data integration systems.

The SP sends user queries to multiple data sources

and assumes that the data sources are capable of pre-

serving the data concerns by accessing a centralized

repository of data concerns.

Model (c): Concern Aware Querying. The concern

aware querying model of Figure 3(c) is a data service

capable of re-writing user queries in such a way that

all the concerns associated with a particular data ser-

vice are incorporated into the query itself. All the data

sources and their concerns are already registered at

the SP and the required meta-data information is lo-

cally stored by the SP. The SP divides a user query

into multiple sub-queries in such a way that all the ap-

plicable data concerns (which are stored within meta-

data ﬁle locally stored at the SP) are incorporated into

these sub-queries.

Model (d): Concern Aware Querying Model with

Dynamic Discovery. Contrary to the legacy data in-

tegration systems for databases, data services usually

have no prior knowledge of the schema or the data

source. Mostly data sources are discovered dynami-

cally and the most suitable data source has to be se-

lected. Of course, storing meta-data information of

all data sources at internet scale is out of the question.

Figure 3(d) shows the model for concern aware query-

ing with dynamic discovery of data sources and their

associated data concerns. The SP stores data concerns

meta-data as in the concern aware querying model,

but at the same time it is capable of discovering data

services dynamically and creating meta-data of data

concerns by fetching them dynamically. These con-

cerns are then applied to queries for a particular data

source. This model also allows the consumer to pro-

vide her concerns and preferences within the query.

4 CONCERN AWARE QUERYING

For our system, we have chosen the concern aware

querying model as shown in Figure 3(d) since it is

the most ﬂexible and most powerful of the models

discussed in the previous section. Our system stores

the meta-data information of the concerns of all three

stake holders of the data service and is capable of

querying data concerns dynamically. All the three

actors of a data service have the possibility to con-

tribute their concerns to the meta-data. Each data

provider provides its data concerns associated with

its data along with its data. Similarly each consumer

has the option to add her preferences/concerns with

her query. The service provider can add its concerns

to form an aggregated data concerns meta-data which

DATA CONCERN AWARE QUERYING FOR THE INTEGRATION OF DATA SERVICES

115

ncn

(a) Querying with Data Concerns (c) Concern Aware Querying

Data

Concerns

Data

Service

Consumer

Data

Concerns

Data

Service

Consumer

ncn

Consumer

(d) Concern Aware Querying dynamic source/concern

discovery

Data

Service

Data

Concerns

(b) Query with Data Concerns

(centralized concerns repository)

Data

Service

Consumer

Data

Conc-

erns

Figure 3: Data concerns aware querying models.

will be utilized by the query language to write concern

aware queries. A data concern tree (dct) is generated

from the available meta-data and is associated with

each of the data sources.

We have extended the XQuery language to make

it concern aware, with the introduction of special key-

words for mentioning data concerns within the query.

The query parser looks into the data concern trees at-

tached to the available data sources and executes the

query by selecting the most suitable data sources and

data items for the particular user query. Below we

discuss the concern aware querying system in detail.

4.1 Data Concerns Collection

For storing the meta-data information of data con-

cerns of a particular data source, we have decided to

use XML because of its standardization and platform

independence. Figure 4 shows the schema deﬁnition

for the meta-data for the concern aware querying. A

data concern tree will be generated by using the meta-

data information available in the attached XML ﬁle.

The schema shown in Figure 4 describes the data con-

cerns as shown in Table 1. The data concern collec-

tion ﬁle can be expanded to any number of concerns

depending on the type and requirement of the SP or

DP. The data concern tree can be subdivided into two

categories based on the scope of the data concerns.

Service Level Concerns. Data concerns whose scope

is the entire data service are called service level con-

cerns. The data concerns tree of a data service con-

tains exactly one value for any of the service level

concerns. For instance, consider the performance

concern of QoS category of a service. Clearly, a data

service can have only one calculated value for its per-

formance data concern.

Data Level Concerns. Data concerns whose scope

is a single data item or a collection of data items are

called data level concerns. Data level concerns can

have multiple values in the data concern tree attached

to some data source. If a data source returns a node

or a list of nodes of an XML document as a result of

a user query (written in XQuery), then a data level

concern can be described for each of the nodes in this

result and for each element in the subtrees rooted at

these nodes.

The data concern tree is populated by the values

of data concerns depending on the type of each

data concern. There are two possible types of data

concerns based on their value, namely (i) boolean

data concerns, which can have either the value

true or false, e.g. usage permission for commercial

purposes can either be allowed or restricted by the

data provider, and (ii) value based data concerns,

which can have any value within a speciﬁc range e.g.

the performance concern of QoS of a data service or

the completeness concern of a data item can have a

speciﬁc value inside a pre-described range. Different

algorithms are available for the calculation of QoS

values of a data service or data quality measurements

for a data item, which is outside the scope of this

paper. We assume that after applying any of the

available algorithms and techniques a ﬁxed value

(positive integer) is provided for the value based data

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

116

D:\PhD Dbai\Restful\DataConcerns1.xsd 2/8/2011 9:57:23 PM

DataConcern

Data Concerns with Service

Level Scope

ServiceLevelConcerns

QoS

Trust

Fee

Availability

Performance

Licensing

LawEnforcement

UsagePermission

NoLinkage

NoIntegrity

NoDistribution

NonCommercial

Location

Data Concerns with Data

Level Scope

DataLevelConcerns

Multiple DataQuality

elements will show either

resource level or dataitem

level concerns

DataQual...



DataLocati...

Completeness

Timeliness

Accuracy

Consistancy

Level

DataItemLevel

ResourceLevel

Figure 4: Data Concerns Tree.

concerns within a range between 1 and 10, where 10

is the highest level.

Algorithm 1: Data Source Selection based on SLC.

input : Concern Aware Query Q,

DS = {ds

, ds

,...,ds

}

output: DS0 ⊆ DS

DS0 = {φ};

for each ds

∈ DS do

ﬂag = true;

for each Q.SLC

if Q.SLC

6= ds.SLC

then ﬂag = false

end

if ﬂag == true then

for each Q.SLC

if Q.SLC

≥ ds.SLC

then ﬂag = false

end

if ﬂag == true then DS0 ← ds

end

Return DS0;

4.2 Query Processing

If concern aware querying is used and a query con-

tains data concerns, then the SP iterates through the

data concern trees of all available data sources. Using

data concern information provided in the query and

the meta-data tree of data concerns, the data concern

aware querying system is able to select the most suit-

able data service for a particular query. Algorithm 1

shows the data source selection by assuring both types

(i.e., boolean and value based) of service level con-

cerns. A concern aware query and a set of available

data sources is provided as input. After evaluating

this algorithm, the most suitable data source or set of

data sources (in case multiple data source assure the

desired concerns) is returned for data querying. Sim-

ilarly, DLCs are also evaluated using the same tech-

nique mentioned in Algorithm 1 for data selection to

assure data level concerns.

4.3 Concern Aware XQuery

We have chosen XQuery because it is the de facto

standard language for XML data and because of its

capability to execute distributed queries over het-

erogenous data sources (Ali et al., 2009a). Now con-

sider a dynamic data sources integration system as

described in Figure 3(d), where a user query can be

executed on multiple data sources which perform the

same task and one data concern tree is attached to

each data source. Current query languages for semi-

structured data like XQuery or SPARQL need to pro-

vide the URI or location of the data source manu-

ally. In order to select the most appropriate data

source from the available data sources which perform

the same task, we have extended the XQuery syntax

by providing additional keywords to make it concern

DATA CONCERN AWARE QUERYING FOR THE INTEGRATION OF DATA SERVICES

117

Listing 1: Sample Concern Aware XQuery.

l e t $ a u c t i o n : =

doc ( ” a u c t i o n . xml ” ) SLC [ p e rf o r m anc e > 7 ,

C om me r ci a lU sag eP e rm i ss io n = t r u e ]

r e t u r n l e t [ $ca . t i m e l i n e s s ] : =

$ a u c t i o n / s i t e / c l o s e d a u c t i o n s / c l o s e d a u c t i o n r e t u r n

l e t

[ $ e i . c o m p l e t e n e s s > 4] : = $ a u c t i o n / s i t e / r e g i o n s / e u r op e / it e m

f o r $p i n $ a u c t i o n / s i t e / p e o ple / p e r s o n

l e t $a :=

f o r $ t i n $ca

where $p / @id = $ t / b u ye r / @person

r e t u r n

l e t $n : = f o r $ t 2 i n $ e i

where $ t / i t e m r e f / @item = $ t 2 / @id r e t u r n $ t 2

r e t u r n <ite m >{$n / name / t e x t () } < / item >

r e t u r n <p e r s o n name =”{ $p / name / t e x t ()}” > { $a }</ p er so n >

aware. All the service level concerns can be described

where a data source location or URI is mentioned.

Listing 1 shows a sample query over the

XMARK benchmark data of a web application for

auctions, which return a list of person names and

items bought by them within Europe. A comma sepa-

rated list of all the service level concerns is described

within square brackets using additional keywords de-

ﬁned for the service level concerns immediately af-

ter the URL/location of the data source mentioned in

XQuery. For the purpose of simple illustration we al-

low using data level concerns related to particular data

elements within an XQuery [QName.DLC] as part of

concern aware querying. Boolean data concerns can

have either a true or false value. Basic comparison

operators can be implied for the calculation of value

based data concerns.

5 IMPLEMENTATION AND

EVALUATION

Implementation. We have implemented a data con-

cern aware XQuery tool to support the idea of con-

cern aware querying. To store XML data sources,

we use the open source native XML database system

eXist-db

. Our concern aware querying tool uses java

on top of the XQuery processing facility provided by

eXist-db. When a a concern aware query is submitted

to the tool it implements the methods described above

and selects the most suitable data sources for a partic-

ular query. Once the most suitable data sources have

been selected, our tool excludes concern aware query-

ing clauses and sends standard XQuery to the selected

http://exist.sourceforge.net/

data sources. Our data concern aware XQuery tool is

built upon the DeXIN system (Ali et al., 2009a; Ali

et al., 2009b), which is a web based system to inte-

grate data over heterogeneous data sources. DeXIN

extends the XQuery language to support SPARQL

queries inside XQuery, thus facilitating the integra-

tion of data modeled in XML, RDF, and OWL. To

build our data concern aware XQuery system, we

have incorporated the data concern awareness into

DeXIN. Now DeXIN can integrate heterogenous dis-

tributed data source while preserving their individual

data concerns.

Evaluation. As a proof of concept we have evalu-

ated our system on XML benchmark data. We used

the XMARK

benchmark data set for experimental

analysis. XMARK is a popular XML benchmark and

models an internet auction application. We made 100

copies of the subset of the XMARK auction data and

deﬁned each as a data service. The resulting data

services were constructed with the same functional-

ity but with different concerns. Due to the unavail-

ability of data services which support data concerns,

we randomly generated data concern tree meta-data

for each data service and assigned different values to

both service and data level concerns. We used 20 dif-

ferent sample queries provided with the benchmark

and executed each of them with different data con-

cern values. There was no reported failure in the con-

cern aware query execution and all the provided data

concerns were assured, which proves the suitability

of our tool and the potential for its incorporation into

any data service integration application.

http://www.xml-benchmark.org/

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

118

6 CONCLUSIONS AND FUTURE

WORK

In this work, we have designed a querying system

which is capable of taking several kinds of data con-

cerns into account. We have provided a basic model

in which we concentrate on three concerns, namely

data quality, quality of service, and licensing. How-

ever, our approach is generic in the sense that one can

incorporate arbitrary data concerns. Indeed, one item

on our agenda for future work will be to integrate fur-

ther data concerns like pricing, data security, auditing

model, etc. Another important goal for future work is

the integration of our querying system into a powerful

mash-up tool. So far, our querying system is designed

to access data sources via XQuery. In the future, we

want our system to access also data sources which ex-

pose their data via web services.

REFERENCES

Ali, M. I., Pichler, R., Truong, H. L., and Dustdar, S.

(2009a). Dexin: An extensible framework for dis-

tributed xquery over heterogeneous data sources. In

Proc. ICEIS 2009, volume 24 of LNBIP, pages 172–

183. Springer.

Ali, M. I., Pichler, R., Truong, H. L., and Dustdar, S.

(2009b). On using distributed extended xquery for

web data sources as services. In Proc. ICWE 2009,

volume 5648 of LNCS, pages 497–500. Springer.

Bhowmick, S. S., Gruenwald, L., Iwaihara, M., and

Chatvichienchai, S. (2006). Private-iye: A framework

for privacy preserving data integration. In Proc. ICDE

Workshops 2006, page 91. IEEE Computer Society.

Boulakia, S. C., Lair, S., Stransky, N., Graziani, S., Rad-

vanyi, F., Barillot, E., and Froidevaux, C. (2004).

Selecting biomedical data sources according to user

preferences. In ISMB/ECCB 2004, pages 86–93.

Clifton, C., Kantarcioglu, M., Doan, A., Schadow, G.,

Vaidya, J., Elmagarmid, A. K., and Suciu, D. (2004).

Privacy-preserving data integration and sharing. In

Proc. DMKD 2004, pages 19–26. ACM.

Creese, S., Hopkins, P., Pearson, S., and Shen, Y. (2009).

Data protection-aware design for cloud services. In

Proc. CloudCom 2009, volume 5931 of LNCS, pages

119–130. Springer.

Dan, A., Johnson, R., and Arsanjani, A. (2007). Informa-

tion as a service: Modeling and realization. In Proc.

SDSOA 2007. IEEE Computer Society.

Farnan, N. L., Lee, A. J., and Yu, T. (2010). Investigating

privacy-aware distributed query evaluation. In Proc.

WPES 2010, pages 43–52. ACM.

French, J. C., Powell, A. L., Callan, J. P., Viles, C. L., Em-

mitt, T., Prey, K. J., and Mou, Y. (1999). Comparing

the performance of database selection algorithms. In

Proc. SIGIR 1999, pages 238–245. ACM.

Hacig

us, H., Mehrotra, S., and Iyer, B. R. (2002). Pro-

viding database as a service. In Proc. ICDE 2002.

IEEE Computer Society.

Kobsa, A. (2001). Tailoring privacy to users’ needs. In Proc.

User Modeling 2001, volume 2109 of LNCS, pages

303–313. Springer.

Liu, Y., Ngu, A. H., and Zeng, L. Z. (2004). Qos compu-

tation and policing in dynamic web service selection.

In Proc. WWW Alt. 2004, pages 66–73. ACM.

Maximilien, E. M. and Singh, M. P. (2004). A frame-

work and ontology for dynamic web services selec-

tion. IEEE Internet Computing, 8(5):84–93.

McSherry, F. (2009). Privacy integrated queries: an exten-

sible platform for privacy-preserving data analysis. In

Proc. SIGMOD 2009, pages 19–30. ACM.

Mrissa, M., Tbahriti, S.-E., and Truong, H.-L. (2010). Pri-

vacy model and annotation for daas. In Proc. ECOWS

2010, pages 3–10. IEEE Computer Society.

Mykletun, E. and Tsudik, G. (2006). Aggregation queries

in the database-as-a-service model. In Proc. DBSec

2006, volume 4127 of LNCS, pages 89–103. Springer.

Truong, H. L. and Dustdar, S. (2009). On analyzing and

specifying concerns for data as a service. In Proc.

APSCC 2009, pages 87–94. IEEE.

Truong, H. L. and Dustdar, S. (2010). On evaluating and

publishing data concerns for data as a service. In Proc.

APSCC 2010, pages 363–370. IEEE Computer Soci-

ety.

Yeganeh, N. K., Sadiq, S. W., Deng, K., and Zhou, X.

(2009). Data quality aware queries in collaborative

information systems. In Proc. APWEB/WAIM 2009,

volume 5446 of LNCS, pages 39–50. Springer.

Zhang, N. and Zhao, W. (2007). Privacy-preserving data

mining systems. IEEE Computer, 40(4):52–58.

DATA CONCERN AWARE QUERYING FOR THE INTEGRATION OF DATA SERVICES

119
