Find the Best Greedy Algorithm with Base Choice

Experiments for Covering Array Generation

Jing Jiang and Changhai Nie

The State Key Laboratory for Novel Software Technique, Nanjing University, Nanjing, China

Abstract. A number of greedy algorithms have been conducted for covering ar-

ray construction, and most of them can be integrated into a framework, and more

approaches can be derived from the framework. However, such a framework is

affected by many factors, which makes its deployment and optimization very

challenging. In order to identify the best conﬁguration, we design Base Choice

experiments based on six decisions of the framework to study systematically, pro-

viding theoretical and practical guideline for the design and optimization of the

greedy algorithms.

1 Introduction

Many modern systems are built by components; unexpected interactions among com-

ponents may cause some potential system failure. Combinatorial testing has been pro-

posed as a means to detect failures triggered by the interactions among components in

Software Under Test (SUT)[2].

For instance, an Internet-based software system in which end-users may use a vari-

ety of web browsers, operating systems, connection types and memory conﬁgurations,

as shown in Table 1. To exhaustively test all possible combinations needs 3

= 81 test

cases. In this system each component is a factor, and each setting of the component is a

level for the factor. As the combinatorial explosion of larger systems prohibits exhaus-

tive testing, it is a challenge to detect failures caused by interactions among the different

factors.

Combinatorial testing has been proposed as a means to offer signiﬁcant savings. We

reduce to 9 test cases by employing pair-wise interaction testing (shown in Table 2).

All individual pairs are tested instead of testing every combination. Given larger system

with ten factors each having four levels, we only need 25 test cases by employing pair-

wise interaction testing, instead of 4

= 1, 048, 576 test cases by exhaustive testing

Table 1. The online system.

Web Browser Operating System Connection Type Memory

Netscape Windows LAN 256MB

IE Macintosh PPP 512MB

Mozilla Linux ISDN 1GB

Jiang J. and Nie C..

Find the Best Greedy Algorithm with Base Choice Experiments for Covering Array Generation.

DOI: 10.5220/0003559200530060

In Proceeding of the 1st International Workshop on Evidential Assessment of Software Technologies (EAST-2011), pages 53-60

ISBN: 978-989-8425-58-4

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Table 2. The online system.

Test No. Web Browser Operating System Connection Type Memory

1 Netscape Windows LAN 256MB

2 IE Macintosh LAN 512MB

3 Netscape Macintosh PPP 1GB

4 Mozilla Linux LAN 1GB

5 Netscape Linux ISDN 512MB

6 IE Linux PPP 256MB

7 Mozilla Windows PPP 512MB

8 IE Windows ISDN 1GB

9 Mozilla Macintosh ISDN 256MB

[10]. This sampling approach is scientiﬁc and effective. Kuhn et al. examined fault

reports for several systems. They showed that more than 70% of defects can be caught

with 2-way interactions [3].Overall consideration of the cost of testing, the execution

time to generate covering arrays and the array size, pair-wise testing is considered as a

practical method.

In order to generate combinatorial test suites, a combinatorial object called covering

array is often used. Covering array MCA(N; t, k, (v

, v

, · · · , v

) is an N × k array on

v symbols, where v =

i=1

, t is the strength of the coverage of interactions, and k

is the number of factors. Each column i (1 ≤ i ≤ k) contains only elements from a set

with |V

| = v

. The rows of each N × t sub-array cover all t-tuples of levels from the

columns at least once [2]. Table 2 is a 2-way covering array in which all combinations

between every two factors are covered by the nine test cases.

Covering array generation is a key issue in combinatorial testing. Early combina-

torial methods can provide fast generation. However, they depend on the existence of

speciﬁc algebraic of combinatorial objects. For example TConﬁg [4] is a recursive con-

struction method based on orthogonal arrays, and can generate covering array effec-

tively, but it depends on the existence of the corresponding orthogonal array. In terms

of heuristic search, Simulated Annealing [5] and Tabu Search [6] can produce many

small covering arrays, but it is very time-consuming. In addition to heuristic search

methods, there are many greedy methods such as AETG [7,8], TCG [9], DDA [10],

IPO [11] and so on. We have also proposed some greedy algorithms to generated test

suites [13,14].

In this paper, we focus on a series of existing greedy methods including AETG [7],

TCG [9] and DDA [10]. Bryce [1] has integrated these methods into a uniﬁed frame-

work, these methods can not only be included by this framework, but also more new

approaches can be derived from it. However, such a framework is affected by multiple

factors, which makes its deployment and optimization very challenging. Bryce et al.

used ANOVA to analysis the effect of each decision in array size[1], but they did not

give any concrete usable conﬁguration to create effective greedy algorithm from the

framework. We design and conduct Base Choice[12] experiments under the framework

with six decisions. Through the experiments we can ﬁnd the best conﬁguration to build

the most effective greedy algorithm from the framework. It provides practical guideline

for the design and optimization of the greedy algorithms.

The remainder of this paper is organized as follows: Section 2 brieﬂy introduces the

greedy algorithm framework, Section 3 describes the Base Choice experiment design,

Section 4 and 5 analyze the experimental data, and Section 6 presents a summary and

the future work.

2 Framework of the Greedy Algorithms

Bryce [1] proposed a four layer framework with six decisions from AETG,TCG and

DDA. Fig. 1 provides the detail of the greedy framework. Six decisions need to be

made (see Table 3), shown in shadows in the skeleton of Fig. 1. For convenience, we

write six decisions as f

, f

, · · · , f

.We will explain them one by one next.

1. Select a factor 

୧

according to the factor ordering selection criterion.

2. In the case of more factors selected, then choose the factor 

୧

by factor tie-breaking.

3. Assign a level 

୧

for the factor 

୧

according to the level selection criterion.

4. In the case of more levels selected, then choose the level 

୧

by level tie-breaking.

5. Repeat the process until all factors have been fixed, then create a test case.

6. Repeat the above steps Candidates times, candidate rows are generated.

7. Choose a candidate that covers the most new pairs into the covering array.

8. Repeat the above steps until all pairs have been covered, the covering array is complete.

9. Re

eat the above ste

s Re

etitions times

then choose a smallest coverin

arra

Fig.1. The framework of greedy algorithm.

– Decision One – Repetitions (f

): Due to the randomness of certain decisions,

smaller covering arrays may be generated by repetitions [1]. In this paper, we only

consider four kinds of repetitions: 1, 5, 10 and 20 repetitions.

– Decision Two – Candidates (f

): The algorithm may generate a number of rows

as candidates, and choose the one adding the most new pairs into the covering array

[1]. Here we set the numbers of candidates as 1, 5, 10 and 20.

– Decision Three – factor Ordering (f

): The factor ordering is the essence of the

framework. Researchers have reﬁned ﬁve strategies [1]: (1) uncovered pairs, by

the number of new pairs involving the factor and the ﬁxed factors; (2) density, by

expected number of pairs covered involving both ﬁxed and free factors; (3) level, by

the number of associated levels; (4) random; (5) hybrid, the ﬁrst factor is selected

by uncovered pairs, and remaining factors are ordered randomly.

– Decision Four – Level Selection(f

): Its goal is to cover the largest number of

new pairs. Bryce has raised three criterions [1]: (1) random; (2) uncovered pairs,

by the number of new pairs involving the level of the current factor and the ﬁxed

factors; (3) density, by the expected number of new pairs associated with ﬁxed and

free factors.

– Decision Five – Factor Tie-breaking (f

): When employing the strategy of factor

ordering, the algorithm may suffer from ties. To break ties, one of the following

methods may be used [1]: take ﬁrst, random, uncovered pairs.

Table 3. The speciﬁc strategies of six decisions.

No. f

0 1 1 random random random random

1 5 5 uncovered uncovered uncovered uncovered

pairs pairs pairs pairs

2 10 10 density density take ﬁrst take ﬁrst

3 20 20 level least used

4 hybrid

– Decision Six – Level Tie-breaking(f

): The level tie-breaking is also needed, the

following methods are used [1]: random, take ﬁrst, uncovered pairs and least used.

3 Experimental design

In this paper, we compare the performance of the greedy algorithms on the size of

the generated covering array, and aim to answer the following questions: (1) does the

conﬁguration of the framework affect the size of the generated covering array? (2) If

the conﬁguration of the framework has an impact on the performance of the generated

covering array size, can we ﬁnd an optimal conﬁguration to generate smaller covering

arrays for some systems? (3) If the optimal conﬁguration exists in some speciﬁc sys-

tems, is it able to construct smaller covering arrays for the other systems? (4) Is the

optimal conﬁguration of the framework competitive with AETG, TCG and DDA?

To address these questions, we employ a sampling method –Base Choice to study

all kinds of methods based on the framework. We produce a conﬁguration set with

Base Choice method, this method starts by identifying a base conﬁguration, subsequent

conﬁgurations are constructed by varying the choices of one decision at a time and

keeping the choices of the other decisions ﬁxed on the base conﬁguration [12]. The

process is not ﬁnished until the conﬁguration set covers all choices for the six decisions.

For example, we select base conﬁguration randomly as B1 = (2, 2, 1, 1, 2, 0), Table 4 is

a conﬁguration set generated by Base Choice strategy. (We use natural numbers (No.)

to denote each choice of the decisions in Table 3, B1 = (2, 2, 1, 1, 2, 0) represents the

conﬁguration (10, 10, uncovered pairs, uncovered pairs, take ﬁrst, random).)

4 Experimental Analysis

Using the Base Choice conﬁguration set (Table 4), we conﬁgure the framework and get

18 greedy algorithms, then generate covering arrays with them for ﬁve systems listed in

the ﬁrst row of Table 5, and record the size of the generated covering array respectively

in Table 5. For example, for the system 3

(which means a system with 9 factors, 4

factor having 3 levels, 5 factors having 4 levels), we can get 24 test cases with conﬁgu-

ration B1. The letter ”f” denotes that the greedy method is failed to generate a covering

array.The results in Table 5 demonstrate that the conﬁgurations of the framework have

a signiﬁcant impact on the performance of the generated covering array size. The ex-

perimental results are analyzed in the following.

Table 4. Base Choice conﬁguration set.

No. f

B1 2 2 1 1 2 0 B10 2 2 3 1 2 0

B2 0 2 1 1 2 0 B11 2 2 4 1 2 0

B3 1 2 1 1 2 0 B12 2 2 1 0 2 0

B4 3 2 1 1 2 0 B13 2 2 1 2 2 0

B5 2 0 1 1 2 0 B14 2 2 1 1 0 0

B6 2 1 1 1 2 0 B15 2 2 1 1 1 0

B7 2 3 1 1 2 0 B16 2 2 1 1 2 1

B8 2 2 0 1 2 0 B17 2 2 1 1 2 2

B9 2 2 2 1 2 0 B18 2 2 1 1 2 3

Table 5. Results for Base Choice experiments.

B1 20 24 94 42 97 B10 20 23 97 43 102

B2 21 26 94 42 97 B11 20 25 93 41 101

B3 20 24 93 42 97 B12 29 33 132 55 173

B4 19 23 92 41 97 B13 20 24 95 43 97

B5 21 25 102 44 106 B14 20 23 92 42 97

B6 20 24 93 43 99 B15 20 23 93 43 97

B7 20 24 93 42 95 B16 20 25 100 44 103

B8 21 25 94 41 101 B17 f f f f f

B9 20 22 93 41 96 B18 21 f f 44 f

– Repetitions (f

): The conﬁgurations B1, B2, B3 and B4 only vary the number of

repetitions in B1. The numbers of repetitions are studied using settings of 10, 1, 5

and 20. From Table 5, we can ﬁnd that by increasing the number of repetitions, the

array size can reduce slightly, it improves the size performance at the cost of time.

For example, with conﬁguration B2, the greedy algorithm can generate a covering

array of 26 test cases in .437s for 3

, with B4, the size is 23 in 8.25s. As the

tradeoff between the time and the generated covering array size, f

= 20 is the best

choice.

– Candidates (f

): The conﬁgurations B1, B5, B6 and B7 just change the number

of candidates. Its settings are 10, 1, 5 and 20 respectively. The results in Table 5

indicate that more candidates can reduce the array size. But when the candidates

are increased to some extent, the performance tends toward stability. Moreover the

increase of candidates wastes time. Also as the trade-off between the size and time

cost, f

= 20 is the best choice.

– Factor Ordering (f

): The difference of the conﬁgurations B1, B8, B9, B10 and

B11 is only the choice of factor ordering. Their choices are uncovered pairs, ran-

dom, density, level and hybrid respectively. Density in B9 appears to be the best

choice, and uncovered pairs factor ordering is competitive. Only random factor

ordering produces the worst results. The performance of other two choices is the

average. So f

= density is the best choice.

– Level Selection(f

): There are three level selection methods under the conﬁgura-

tions B1, B12 and B13: uncovered pairs, random and density. From Table 3, B12

with random level selection always generate the largest covering array. Both den-

sity in B13 and uncovered pairs in B1 have good performance. However uncovered

pairs level selection is a little better than density, so we let f

=uncovered pairs be

the best choice.

– Factor Tie-breaking (f

): The choices of the factor tie-breaking in the conﬁgu-

rations B1, B14 and B15 are take ﬁrst, random and uncovered pairs respectively.

From Table 5, the three choices have similar performance, so we let f

=take ﬁrst,

random or uncovered pairs.

– Level Tie-breaking(f

): The choices of the level tie-breaking in conﬁgurations B1,

B16, B17 and B18 are random, uncovered pairs, take ﬁrst and least used. Take ﬁrst

yields very poor performance, frequently suffering from a dead loop. In addition

the methods that use least used would fail occasionally. We can ﬁne the optimal

choice for level tie-breaking is f

=random.

Based on the above analysis, 20 repetitions, 20 candidates, density factor order-

ing, uncovered pairs based on level selection, free choices for factor tie-breaking and

random level tie-breaking can be the optimal choice for each decision, totally we can

obtain three best conﬁgurations Best1 = (3, 3, 2, 1, 0, 0),Best2 = (3, 3, 2, 1, 1, 0) and

Best3 = (3, 3, 2, 1, 2, 0).

Table 6. Comparison with published results.

Best1 Best2 Best3 DDA AETG TCG

18 18 18 18 15 20

19 20 19 21 19 20

33 33 34 34 34 33

26 26 26 27 30 30

34 34 34 35 41 35

42 42 42 43 45 45

43 44 44 43 42 46

5 Verifying Experiments

To verify the optimal conﬁgurations Best1, Best2 and Best3 of the above experiments,

we make some verifying experiments, and examine the following two aspects: 1) are the

optimal conﬁgurations able to generate smaller covering arrays for the other systems;

2) are they competitive with the existing methods AETG, TCG and DDA?

For evaluation, we generate covering arrays with them for the seven systems in the

ﬁrst column of Table 6, and the experiments conﬁrm that the optimal conﬁgurations

also do well in generating covering array for the systems . In addition, we compare the

published results for AETG, TCG and DDA in the literature [7, 9, 10]. From Table 6,

we can see that the conﬁguration Best1 is a little better than other two conﬁgurations,

so we select Best1 as our optimal conﬁguration. We can ﬁnd that the optimal conﬁgu-

ration Best1 is competitive in generating covering arrays. For example, for the system

, the size of the generated covering array by Best1 is 26, the size by AETG is

30, the size by TCG is 30, and the size by DDA is 27.

6 Conclusions

We studied a greedy framework with six decisions built by Bryce [1]. Thousands of

greedy methods can be derived from this framework. In order to ﬁnd the best algo-

rithm, we employ Base Choice method [12] to systematically sample an amount of

greedy algorithms derived from the framework. According to the experimental results,

we can draw the following conclusions: (1) the conﬁgurations of the framework have a

signiﬁcant impact on the performance of the covering array size; (2) We can obtain an

optimal conﬁguration in some speciﬁc systems, and (3) the optimal conﬁguration can

work for the other systems as well; (4) Comparing the optimal conﬁguration with the

existing methods AETG, TCG and DDA, we ﬁnd that the optimal conﬁguration has its

advantages, it can generate smaller covering array than the existing methods.

Our conclusion is a complementaryand veriﬁcation to Bryce’s results. We ﬁnd more

repetitions and candidates may decrease the covering array size, but it requires more

time cost. Moreover, while these two factors are increased to some extent, the size no

longer decreases. We also ﬁnd the randomfactor ordering yields very poor performance.

In the future work, we plan to conduct more profound and comprehensive studies

on the greedy framework, which may include: (1) consider more choices of the frame-

work; (2) employ other more scientiﬁc sampling methods to optimize the framework;

(3) consider the cases of seeds and constraints in covering array generation.

Acknowledgements

This work was supported by the National Natural Science Foundationof Jiangsu province

(BK2010372),the National Natural Science Foundation of China (60773104,60721002),

863 high technical plan of China (2009AA01Z143).

References

1. R. C. Bryce, C. J. Colbourn, M. B. Cohen: A Framework of Greedy Methods for Construct-

ing Interaction Test Suite. In: Proceedings of 27th international conference on software en-

gineering (ICSE2005). St. Louis, Missouri, USA, May 15-21, 2005:146–155.

2. Changhai Nie, Hareton Leung: A suvery of combinatorial testing. ACM Computing Survey,

2011, 43(2).

3. D. Kuhn and M. Reilly. An investigation of the applicability of design of experiments to

software testing. Proc. 27th Annual NASA Goddard/IEEE Software Engineering Workshop,

October 2002.

4. A. W. Williams,R. L. Prober. A Practical Strategy for Testing Pair-wiseCoverage of Network

Interfaces. In Proceedings of 7th International Symposium on Software Reliability Engineer-

ing (ISSRE1996), White Plaints, NY, USA, October 30-November 2, 1997: 246–254.

5. M. B. Cohen, P. B. Gibbons, W. B. Mugridge, C. J. Colbourn. Constructing Test Suites

for Interaction Testing. In Proceedings of the 25th International Conference on Software

Engineering (ICSE2003), Portland, Oregon, USA, May 3–10, 2003: 38–48.

6. K. J. Nurmela. Upper Bounds for Covering Arrays by Tabu Search. Discrete Applied Math-

ematics, 2004, 138(1–2): 143–152.

7. D. M. Cohen, S. R. Dalal, M. L. Fredman, G. C. Patton: The AETG system: an approach

to testing based on combinatorial design. IEEE Transactions on Software Engineering,

23(7):437–44, October 1997.

8. D. M. Cohen, S. R. Dalal, M. L. Fredman, J. Parelius, and G. C. Patton. The combinatorial

design approach to automatic test generation. IEEE Software, 13(5):82–88, October 1996.

9. Y. Tung, W. Aldiwan: Automating test case generation for the new generation mission soft-

ware system. IEEE Aerospace Conf. , pages 431–37,2000.

10. R. C. Bryce, C. J. Colbourn: The density algorithm for pairwise interaction testing. Journal

of Software Testing, Veriﬁcation, and Reliability, 2007.

11. K. C. Tai, Y. Lei. A Test Generation Strategy for Pairwise Testing. IEEE Transaction on

Software Engineering, 2002, 28(1): 109–111.

12. M. Grindal, B. Lindastrom, A. J. Offutt, S. F. Andler: An Evaluation of COmbination Strate-

gies for Test Case Selection. Empirical Software Engineering, 2006,11:583–611.

13. C. H. Nie, B. W. Xu, Z. Y. Wang, L. Shi. Generating Optimal Test Set for Neighbor Factors

Combinatorial Testing. QSIC 2006: 259–265.

14. C. H. Nie, B. W. Xu, L. Shi, Z. Y. Wang. A new Heuristic for Test Suite GEneration for

Pair-wise Testing. SEKE 2006:517–521.
