Measuring and Improving IT Service Support Processes:

A Case Study

Kai Zhou and Beijun Shen

School of Software, Shanghai Jiaotong University, Shanghai, 200240, China

Abstract. With the rapid development of Information Technologies for many

organizations and the increasing importance of IT, the focus of IT management

has shifted from device-oriented management to service-oriented management.

This paper describes the approach and results of measurement and improvement

of IT service support processes in Bank of China and Nokia Co. The research

applied best practices of Organizational Process Performance Process Area

defined in CMMI to IT service support processes, and the following steps were

adopted: defining the process models, designing their metrics from goals, data

collection, processes evaluation, and the identification and elimination of

bottlenecks. Two research questions concerned with the research approach are

raised and explored in this paper.

1 Introduction

Over the past few years, Information Technology has become one of the most

important roles in an increasing number of companies [1] Accordingly, IT

performance directly affects the business performance. On the other hand, the

emergence of new technologies and the increasing complexities of systems make it

even harder for companies to achieve IT service management goals effectively and

efficiently. Therefore, one of the key points to achieve business goals successfully is

to ensure IT performance and quality.

To improve IT performance and quality, it is of utmost importance to enhance the

maturity of IT service support processes. Due to the increasing role of IT service

management in the enterprise, several standards and best practices – ITIL [2], [3]

ISO20000 [4] and CMMI [5] for service -- provide guidelines for IT service

management and are adopted in IT organizations all over the world. IT service

support processes include the incident management process, problem management

process, configuration management process, change management process and release

management process. The efficiency and quality of IT service support processes

directly influences the user’s perception of service and the business efficiency and

qualities. Thus, efforts are needed to identify and eliminate the bottlenecks to improve

the process performance.

Though the quantitative analysis of IT service support processes is seldom

discussed in ITIL, useful academic researches related to IT service support processes

have been reported in the literature [6], [7], [8]. In addition, other research attempts

have been made to measure and improve software processes [9], [10]. However, there

Zhou K. and Shen B..

Measuring and Improving IT Service Support Processes: A Case Study.

DOI: 10.5220/0003568100280035

In Proceeding of the 1st International Workshop on Evidential Assessment of Software Technologies (EAST-2011), pages 28-35

ISBN: 978-989-8425-58-4

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

is still a lack of a general method for IT service support processes measurement and

improvement. Furthermore, the lack of empirical studies in this field is evident and

must be addressed.

Organizational Process Performance (OPP) process area, which is defined in

CMMI, builds process performance baseline (PPB) to determine if the process quality

and performance objectives have been achieved. Based on PPB, process performance

model (PPM) is established to predict process quality and performance, but the

concrete steps to build PPM are not specified in CMMI.

Under this background, we conducted research on two organizations - Bank of

China and Nokia Co. This case study is continued from our previous work where we

proposed a BPDM-based IT service support process metamodel [11]. This research

utilizes the best practices of Organizational Process Performance (OPP) Process Area

defined in CMMI [12] to measure and improve performance and qualities of IT

service support processes.

In this work, we focus on the measurement and improvement of IT service support

processes in two case organizations. The remaining of the paper is structured as

follows: Section 2 describes the research methods of this study. Section 3 presents the

research results to answer research questions. In section 4, we summarize our results

and point out some limitations in this study.

2 Research Method

This case study is part of work of the research project SOMSMP (Software Operation

and Maintenance Service Management Process) from Shanghai Jiaotong University,

China, funded by the Key Laboratory of High Confidence Software Technologies of

the Ministry of Education of China. This project is a systemic research of software

operation and maintenance service management processes, and this paper makes a

preliminary study of IT service support process measurement and improvement.

Fig. 1. Framework of the OPP-based approach to measure and improve IT service support

processes.

Process objectives

establishment

Process analysis

and modeling

Modeltheprocesses EstablishMeasuresystem

Model analysis

Metric

determination

Data collection

Data anal

sis

prediction model

Evaluateandimprove

We choose two research questions related to the IT service support processes

measurement and improvement:

Q1: How is an IT service support process described and how are metrics defined?

Q2: How are the processes evaluated and bottlenecks identified effectively?

OPP [12] is one of the Key Process Areas in CMMI for Development (CMMI-DEV),

which is developed for the improvement of software development processes.

According to the research questions, we propose a method to measure and improve

the IT service support processes based on OPP. The framework of this method is

shown in Fig.1. Firstly, we establish the process objective for each process, since

different IT service support processes have different objectives. According to the

objectives established, we then analyze and model the current processes in the

organization, using an IT service support process BPDM-extension meta-model.

Based on the process model, we design and determine metrics to measure process

performance and qualities. Next, we collect data from the case organizations for each

IT service support process, and evaluate process performance and qualities according

to the metrics defined previously. Finally, a prediction model will be used to predict

the performance and qualities of the processes, but this step is not the focus of this

paper and will be explored in the future.

Two large scale case organizations, Bank of China and Nokia Co., are selected.

Both organizations adopt IT service management processes to manage their IT system,

but it is in our opinion that there is much potential for improvements to be made to the

maturity of their current IT service management processes.

The methods used to collect data include: Direct collection (DC, participation in

support teams and first-hand experience with the daily operation of processes),

Interview (IN, meetings and discussions with different roles), Questionnaire (QU,

questionnaires sent to stakeholders), Access to tools databases (AT, exporting records

from tools and consulting related documents) and Periodic summarization (PS,

collection of periodic summarizations which report some indicators related to

performance or qualities).

3 Research Results

This section presents our main research results of the case organizations involved in

this study. We identify the strengths of the IT service support processes of the case

organizations and present our exploration into the research questions in Section 2.

3.1 Strengths of the IT Service Support Processes

Though the IT service support processes in the case organizations are far from

mature, both organizations possess strengths in certain processes to facilitate the

exploration in this study. The first strength is that the roles and responsibilities of IT

service support processes are clearly documented in the two case organizations. The

second strength is that Service Level Agreement (SLA) in Nokia Co. is explicitly

defined in a document called Service Level Definitions, which provides another way

to judge the performance. The third strength is that tools have been adopted in the

organizations to support IT service management, recording detailed data that makes

the analysis easier. The fourth is that the process managers produce periodic

summarization of the performance of each process, which helps to understand and

analyze performance data. Finally, the commitment shown by high level managers is

a strong impetus to improve the process performance and qualities.

3.2 Exploration to the Research Questions

Q1: Process Modeling and Metric Determination. In many organizations, the

objectives of IT service support processes are established by high level managers,

which may neglect the operational realities of processes. To counter this, information

was collected from all stakeholders to establish process objectives which were more

suitable for the case organizations as a whole.

Two types of objectives were identified through interview and questionnaires to

the stakeholders in the case organizations: one being the common objective, and the

other being the process-specified objective. The objectives we summarized are

compatible with ITIL concepts.

Based on the process objectives, we analyzed the IT service support processes in

case organizations and ITIL standards, and then should describe the processes

properly. Because of limited space, we take incident management process modeling

as an example. Fig. 2 shows the process model of incident management in BoC using

BPDM-extension meta-model. In the BPDM-extension meta-model, we extend

BPDM to better reflect the characteristics of IT service support process from three

aspects: activity, resource, and interaction. To generalize the model and to support the

IT service support process model integration, exchange and reuse with other business

processes, we adopt this metamodel. The model in Fig. 2 consists of activities of

incident management process. The most important resource in incident management

process is IR (Incident Record). There are two levels of support groups in the case

organization: the first level being the service desk response for Service Request, and

the second level being the incident support team responsible for Onsite Incident

Solving. Columns indicate the roles in charge of the respective activities: the left

column lists the activities under the purview of a service desk worker, and the right

column includes the activities under the incident support team’s charge.

To define accurate metrics, we first analyzed the models to differentiate trivial

activities and key activities, the former describing activities which have a limited

impact while the latter indicating activities with a significant effect on the

performance and quality of the entire process respectively. We have highlighted the

trivial and key activities of Fig. 2.

Trivial activities included: create IR, record service request information, record

incident solution information, close; key activities included: classify and prioritize,

service request branch, assign, accept, reassign branch, solve correctly branch.

Fig. 2. Incident management process model.

Table 1. Metrics derived from key activities.

Metrics Meaning Derivation activity

M0 the ratio of correct preliminary classification of incidents classify and prioritize

M1 Mean solution time by priorities classify and prioritize

M2 the ratio of service request service request branch

M3 the ratio of solved incidents by one assignment assign &accept &reassign branch

M4 mean times of assignment/reassignment of incidents assign &accept &reassign branch

M5 the ratio of reopen closed incidents solve correctly branch

Our exploration focuses on key activities, since trivial activities are not important

to measure the process performance. According to the key activities and the incident

process objectives we summarized, we define metrics to elaborate the measure

system. Table 1 lists the metrics we defined according to corresponding key activities

to measure performance and qualities.

Q2: Evaluation and Improvement. We obtained process related data against the

metrics defined previously. Resources [11] records of IT service support processes

were collected from tool databases, including: Service Request Record, Incident

Record, Problem Record, Request for Change(RFC), Configuration Item(CI).

Furthermore, we also collected mail summaries and meeting reports which reported

on data relevant to performance or qualities.

Using the previous example, incident management process in BoC, we

demonstrate how to analyze data in our research. We retrieved 6962 Incident Records

service desk incident support team

[yes]

[no]

[no, reassign]

[no, slove again]

record service request information

service request?

create incident record

classify and prioritize

sol ve correctl y？

clo se

reassign?

record incident solutioninformation

assign

and 13670 Service Request Records spanning January 1, 2010 to October 31, 2010

from the incident management database, and obtained parts of the mail summaries

and some meeting reports since January 1, 2010. We discarded records which had

obvious errors. Table 2 shows values of the key activity metrics of the incident

management process in the case organization.

After getting values for the key activities metrics, we adopted two methods to

determine whether the performance of corresponding key activities is good or not:

Service Level Agreement (SLA) and Process Performance Baseline (PPB). We get

PPB in the both case organizations from the summarizations of the processes

performance for last two years. SLA, which is already documented, is a part of

a service contract. Since some metrics are not defined in SLA or PPB, we combine

the two methods to determine the qualities and performance of processes.

We compared the results in Table 2 to definitions in SLA and PPB, and we

concluded that the qualities and performance of incident management process in BoC

was desirable since all values of these metrics were in the range of SLA or PPB.

However, metric M4, which indicates times of assignment/reassignment of incidents,

in Nokia was not desirable because it did not meet the PPB standard value of 1.2. The

excessive value in this metric implies that the capability of service desk or incident

support team is not ideal.

Through the analysis of key activity metrics we could determine the bottlenecks of

IT service support processes, because the metrics is related to particular activities.

The abnormal values of metrics would make it easy to identify the presence of

bottlenecks. The manager of processes should then take the abnormality into account

and take actions to eliminate the bottlenecks thus improving the whole process

performance and qualities.

We explored one reason why BoC outperforms NC when it comes to IT service

support processes. After comparing the details of IT service processes and IT

departments in these two organizations, a possible reason identified was that the IT

service requirements in NC were more diverse and sophisticated than BoC.

Table 2. Values of key activity metrics of incident management process in case organizations.

Metrics Value in BoC Value in Nokia

M0 93.90% 88.50%

priority 1: 338.9 (min)

priority 2: 80.1 (min)

priority 3: 286.8 (min)

priority 4: 164.75 (min)

priority 5: 78.23 (min)

priority 1: 1313.9 (min)

priority 2: 932.3 (min)

priority 3: 464.3 (min)

priority 4: 203.5 (min)

M2 66.30% 55.00%

M3 93.50% 81.30%

M4 1.16 1.31

M5 0.52% 0.91%

4 Discussion and Conclusions

This paper describes the results of a case study focusing on improving IT service

support processes in two case organizations. In this study, we continued our previous

work – a BPDM-based IT service support process metamodel – and adopted an

OPP-based approach to measure and improve performance and qualities of IT service

support processes. The results and procedure of the measurement and improvement of

IT service support processes in case organizations and the exploration of the research

questions are presented.

Measuring and improving IT service support processes was a more difficult task

than previously expected, and some limitations are present in this case study. Some of

metrics appeared neither in PPB nor in SLA. We compared the value of the key

activity metrics to PPB or SLA, but we could not find the revelant data in both PPB

and SLA for some metrics. Another limitation is the lack of high qulity data.

We regard this study as the first step towards a more comprehensive quantitative

measurement and improvement approach. In the future, we will focus on the research

of performance prediction model to propose a elegant model.

Acknowledgements

This research is supported by the Opening Project of Shanghai Key Lab of Advanced

Manufacturing Environment (No. KF200902), and the Opening Project of Key

Laboratory of High Confidence Software Technologies (No. HCST201001).

References

1. Moura, A., Sauve, J., Bartolini, C.: Business-Driven IT Management - Upping the Ante of

IT: Exploring the Linkage between IT and Business to Improve Both IT and Business

Results. IEEE Communications Magazine, Vol. 46, Iss. 10 (2008).

2. Office of Government Commerce (OGC): IT Infrastructure Library. The Stationary Office,

UK (2000).

3. Office of Government Commerce (OGC): ITIL Core Books, The Stationary Office, UK

(2007).

4. International Organization for Standardization: “ISO/IEC 20000-1” & “ISO/IEC 20000-2”

(2005).

5. CMMI product team: CMMI® for Service, Version 1.3. Pittsburgh, PA, Carnegie Mellon

Software Engineering Institute (2010).

6. Marko Jantti, Kari Kinnunen: Improving the Software Problem Management Process: A

Case Study. European Software Process Improvement Conference, LNCS 4257 (2006)

40-49.

7. Liang Ping, Li Jianyang: A Change-Oriented Conceptual Framework Of Software

Configuration Management. International Conference on Service Systems and Service

Management (2007) 1-4.

8. Bartolini, C., Stefanelli, C., Tortonesi, M.: SYMIAN: Analysis and Performance

Improvement of the IT Incident Management Process. IEEE Transactions on Network and

Service Management, Vol. 7, Iss. 3 (2010) 132-144.

9. Qing Wang, Mingshu Li: Measuring and Improving Software Process in China.

International Symposium on Empirical Software Engineering (2005) 183-192.

10. Beijun Shen, Dehua Ju: On the Measurement of Agility in Software Process. International

Conference on Software Process, LNCS 4470 (2007) 25-36.

11. Beijun Shen, Xin Huang, Kai Zhou, Wenwei Tang: Engineering Adaptive IT Service

Support Processes Using Meta-modeling Technologies. International conference on

software process, LNCS 6195 (2010) 200-210.

12. CMMI product team: CMMI® for Development, Version 1.3. Pittsburgh, PA, Carnegie

Mellon Software Engineering Institute (2010).
