where P
D
is the dissipated power.
All these parameters have a physical limit,
therefore, once the best heatsink is chosen, the way
to improve the resistance is the inclusion of air flow
by means of a mechanical cooling system. The use
of a fan is very common in this type of equipment,
but the low MTTF of this type of components is its
major drawback.
In order to fulfil EMC requirements, radiated
and conducted interferences have to be eliminated
by means of the inclusion of extra components. The
conducted interferences are eliminated using bypass
capacitors. ESD protections are needed in all the
external connectors of the system. As said
previously, the insertion of all these components
worsens the system MTTF and HR.
It is crucial to know that the variations due to
RAMS aspects affect the characteristics of the
system regarding FTE performance (RAMS-FTE).
Safety-aimed changes must not vary the system
main functionality, but the characteristics of the
system blocks may be varied if the new architecture
needs them. As explained previously, the two
possibilities analyzed in this work to improve system
safety are the BIST and redundancy. Both
techniques affect system consumed power and
transmitted or received RF signal power.
The need of including components in the
transceiver chain results in a reduction of the
transmitted power. Therefore, equipment
characteristics need to be changed to obtain the same
output power as in the absence of these techniques.
Either BIST or redundancy implies the insertion
of new components in the system and hence, new
signals. These generate two types of EMC issues,
interferences to the environment and interferences
within the components of the system; both of which
must be avoided.
5 ANALYSIS RESULTS
Once the causes and consequences among FTE and
RAMS characteristics have been analyzed, RAMS-
FTE and FTE-RAMS (section 4) analyses results are
gathered. Table 1 exhibits FTE-RAMS trends, where
the columns show the requirements and the rows
define the design parameters. The parameters trend
is defined by means of – and +. The ↑ in the cells
shows the improvement of the requirement while the
↓ the worsening.
In the case of BIST technology, the decrease of
MDT (quantifiable parameter) makes the THR
better, but, at the same time, the use of new
components (non quantifiable) worsen some
requirements. The advantage of BIST is the HR
improvement, at the cost of worsening system
MTTF.
System MTTF is inversely proportional to the
sum of the components failure rate. Therefore, the
lower the BIST and EMC solution components
failure rate is, the lower its effect in MTTF.
Although, as shown in the next section, these
components usually have a very low failure rate.
Table 1: Effect on RAMS requirements.
RAMS req.
THR MTTF
Functional Chosen architecture
↓ ↓
Temp.
Thermal resistance -
↑ ↑
Max junction temp +
↑ ↑
Cooling mechanism +
↓ ↓
EMC
Filter +
↓ ↓
Capacitances +
↓ ↓
ESD protections +
↓ ↓
As shown in (1), HR strongly depends on the
MDT and r
H
. The shorter this period (MDT) the
better the system HR, however the failure rate of the
components included in the system is directly added
to the failure rate of the system. So, a trade-off must
be considered between the failure rate of the
included components and the MDT.
6 SIL 2 RF TRANSMITTER
The methodology, based on studying functional,
thermal, EMC and RAMS from the beginning is
applied to a design of a SIL 2 RF transmitter.
The system to be designed is an analogue
transmitter for a signalling system located in a high
speed train. RAMS requirements are defined by the
railway safety requirements (UNISIG 2009). The
minimum MTTF limit is defined as 5·10
5
hours.
Whereas the safety requirement of the transmitter is
given by the THR related to the safety related
hazard. This THR for the transmitter is 2.2·10
-8
dangerous failures per hour.
6.1 FTE-RAMS Analysis Results
The basic architecture for this type of transmitter is
based on a signal generator and different amplifier
stages. By means of the failure rate of every
component at 25ºC and 60% confidence level, the
reliability data calculation can be obtained. It shows
that the proposed architecture (first line of
Table 2)
