Information Security Governance Analysis Using

Probabilistic Relational Models

Waldo Rocha Flores and Mathias Ekstedt

Royal Institute of Technology, 100 44, Stockholm, Sweden

Abstract. This paper proposes the use of Probabilistic Relational Models

(PRM) for analyzing dependencies between Information Security Governance

(ISG) components and its impact on process capability of mitigating

information security vulnerabilities. Using the PRM enables inference between

different ISG components expressed in probabilities, and also inference on the

process capability. A concrete PRM which exemplifies how to assess the

capability of the access control process is further presented, and thus showing

how the PRM can be adapted to fit the analysis of a specific process in an

organizational environment.

1 Introduction

Information Security Governance (ISG) provides a holistic approach to information

security, and considers management commitment and leadership, organizational

structures, user awareness, policies, processes, and technologies, all working together

to ensure information security of enterprise’s assets is maintained at all times [1]. In

order to increase the understanding of dependencies between different ISG mechan-

isms, the ISG structure can be modeled with architecture metamodels. Architecture

metamodels support managers to effectively plan, design and communicate IT and

business related issues, i.e. they provide decision support for managers [2][3]. Model-

ing ISG as architecture metamodels does not only keep track of important ISG me-

chanisms and their internal relationship, it also provides information about any de-

pendencies in the structure. Therefore, the behavior and effect of changes to an ISG

structure can be predicted, and the structure can be established in an enterprise with-

out using trial and error. Conclusions can therefore been drawn on the consequences

in the enterprise given that one ISG mechanism (e.g. process) is not well implemented

or managed, that a certain organizational or human factor has not been considered, or

that an important role has not been assigned. There are several best-practice guide-

lines targeted to support the assessment of an organization’s current ISG. COBIT [4]

for instance, has been suggested as a framework for ISG. COBIT includes security-

related control objectives as check points to achieve security and a maturity model

that can be used to assess the current state of security.

The ISO 27000 is the root for a number of series of international standards for the

management of Information Security. For instance, ISO 27002 is a control-based

framework using the widely known “Plan-Do-Act-Check” approach to ensure infor-

mation security. Its related document, ISO 27004 includes several measures that can

Rocha Flores W. and Ekstedt M..

Information Security Governance Analysis Using Probabilistic Relational Models.

DOI: 10.5220/0003588001420150

In Proceedings of the 8th International Workshop on Security in Information Systems (WOSIS-2011), pages 142-150

ISBN: 978-989-8425-61-4

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

be used to evaluate the impact of implemented security controls and thus assess the

effectiveness of the information security management in an organization [5].

Current architecture frameworks for Business/IT analysis do not provide a model-

ing language that supports assessments in general and for information security is

particular [7]. There is also little research on the use of modeling languages to support

quantitative assessment for information security. One example is the work presented

in [8] where attack steps were defined as a part of a threat. The presented model was

used for analyzing the effect of technical countermeasures and made it possible to

predict quantified expected loss values from the suggested architecture model. How-

ever, technical countermeasures are not enough own its own. The purpose of the

present paper is to propose a model that can be used for analyzing ISG in an organiza-

tional environment. The presented approach includes organizational and human fac-

tors of information security in an ISG structure, and aid assessments of their impact

on security process capabilities, i.e., the effect of mitigating security vulnerabilities.

To support assessments the model is coupled with an assessment and analysis me-

chanism and extended to a Probabilistic Relational Model (PRM) - specifying a tem-

plate for a probability distribution over the architecture model. The classes in this

PRM are abstract and cannot be directly instantiated into an architecture model. They

can however be made concrete if they are specialized into subclasses according to a

set of constraints. If architecture models are instantiations of such concrete classes,

then the process capability to mitigate security vulnerabilities can be inferred from the

architecture model. By applying an instantiated model on real enterprise ISG envi-

ronments weaknesses and potential risks of security vulnerabilities in an organization

can be highlighted, thus supporting decision making and planning. The remainder of

the paper is structured as follows. In the next section PRM which severs as the as-

sessment mechanism is presented. Section three is the locus of this paper’s contribu-

tion and presents the PRM for ISG analysis, and an instantiation of the PRM to show

how the PRM can be used to support capability assessment of the access control

process. Section four concludes the paper.

2 Probabilistic Relational Models

A Probabilistic Relational Model (PRM) specifies a template for a probability distri-

bution over an architecture model [9]. An architecture metamodel M describes a set of

classes, 



,…, 



. Each class is associated with a set of descriptive attributes and a set

of reference slots (relationships). The set of descriptive attributes of a class X is de-

noted At(X). Attribute A of class X is denoted X.A and its domain of values is denoted

V(X.A). The set of reference slots of a class X is denoted R(X). We use X.υ to denote

the reference slot  of X. A reference slot  denotes a function from 



to 



, and its

inverse 



denotes a function from 



to 



. Thus, the fundamental modeling con-

structs are the same as in general conceptual modeling techniques. An architecture

instantiation I (or an architecture model) specifies the set of objects of each class, the

values for the attributes, and the references of the objects. It specifies a particular set

of process, activities, roles, etc. A PRM template describes the metamodel for the

architecture model, and the probabilistic dependencies between attributes of the archi-

tecture objects. A PRM П, together with an instantiated architecture model of specific

143

objects and relations, defines a probability distribution over the attributes of the

objects. This probability distribution is specified similar to a Bayesian network [10]

which consists of a qualitative dependency structure and associated quantitative

parameters. The probability distribution can be used to infer the values of unknown

attributes, given evidence of the values of a set of known attributes.

The qualitative dependency structure of a PRM is defined by associating attributes

X.A with a set of parents Pa(X.A). Each parent of X.A has the form X.τ.B where B ∈

A(X.τ) and τ is either empty, a single reference slot υ or a sequence of reference slots





,…,



such that for all i, Range[



]= Dom[



]. We call τ a slot chain. Note that

when X.τ.B reference attributes external to the class X, it might be referencing a set of

attributes rather than a single one since there multiple instantiated objects of one class

may exist. In these cases, we let X.A depend probabilistically on an aggregated

property over those attributes constructed using operations such as AND, OR, MEAN

etc. Considering the quantitative part of PRMs, given a set of parents for an attribute,

we can define a local probability model by associating a Conditional Probability Dis-

tribution (CPD) with the attribute, P(X.A|Pa(X.A)). In Fig. 3, fictive numbers are

included to illustrate the CPD table for the instantiated metamodel of the access

control process. Using the fictive numbers gives a value that specifies the probability

that the security process has high capability given that for instance the security culture

in the organization is developed and that the risk awareness is high. We can now

define a PRM Π for a metamodel M as follows. For each class X and each descriptive

attribute A ∈ At(X), we have a set of parents Pa(X.A), and a CPD that represents





(X.A|Pa(X.A)). Given a relational skeleton, 



(i.e. an instantiated metamodel

without attribute values), a PRM Π specifies a probability distribution over a set of

instantiations I consistent with 





ǀ



,Π



=Π



















(1)

where 



(X) are the objects of each class in the instantiated metamodel. Hence, the

attribute values can be inferred. A PRM thus constitutes a machinery for calculating

the probabilities of various architecture instantiations. This allows us to infer the

probability that a certain attribute assumes a specific value, given some (possibly

incomplete) evidence of the rest of the architecture instantiation.

3 A Probabilistic Relational Model for Information Security

Governance Analysis

Several definitions to the concept of ISG have been proposed by international associa-

tions, public institutions, and researchers [1][4][5][11][12][13][14]. [4] argues that

ISG is about management commitment and leadership, organizational structures, user

awareness and commitment, policies, processes, and technologies, all working togeth-

er to ensure information security of enterprise’s assets is maintained at all times [1].

[11] and [14] further emphasize assignment of responsibilities and segregation of

duties as important components of ISG. Internal dependencies between ISG compo-

nents such as organizational structure, and security process capabilities has been iden-

144

tified and validated by [15][16]. Adopting these definitions and findings, the proposed

PRM for ISG analysis (Cf. Fig. 1) focuses on how a structure of ISG in an organiza-

tional environment impacts the capability of a process in terms of mitigating vulnera-

bilities. Therefore, a high process capability leads to fewer flaws in an organiza-

tion’s security mechanisms, i.e. vulnerabilities that can be exploited by an attacker.

The qualitative part of the PRM consists of classes, reference slots, attributes and

their parents. A total of six classed were identified Organizational Unit, Process,

Activity, Artifact, Role, and Actor. The main class in the PRM is OrganizationalUnit

that represents an organization. An organization consists of processes and in our case;

processes to mitigate security vulnerabilities. The OrganizationalUnit has therefore

the reference slot ConsistOf whose range is the class Process. Each Process further

consists of a set of activities that defines a process and takes and creates artifacts such

as security policies, back-up storage, etc. This is represented by the two classes

Activity and Artifact with an IsapartOf reference slot for the Activity class and an

ExistsIn reference slot for the Artifact class. In a PRM, classes can further be specia-

lized through inheritance relationships. The classes are related to each other using

subclass relation. For instance, the AccessControlProcess is a subclass of Process

(AccessControlProcess << Process) and then Process class is a superclass of Ac-

cessControlProcess. In the PRM this inheritance relationships is represented by an

IsakindOf reference slot.

A role (e.g. a security manager) is assigned to a process. This relation is illustrated

by the class Role with an IsResponsibleFor/IsAccountableFor reference slot whose

range is the class Process. This Role class has further an IsakindOf reference slot

illustrating that there exist several specializations of a role. The SecurityManageRole

is for instance a subclass of the class Role (SecurityManagerRole << Role), and

Role is then a superclass of SecurityManagerRole. A role is further a resource in the

organization; this relation is represented by the class Role with an IsaResourceIn

reference slot whose range is the OrganizationalUnit. Finally, an actor fills the role,

and is illustrated in the PRM with the class Actor

and a FillsA reference slot with the

range Role.

Regarding the attributes in the PRM, The Process capability attributes is first and

foremost influenced if formal processes are effectively implemented. Further, the

capability of a process is influenced by an organization’s security culture, i.e. shared

attitudes, values, goals, and practices related to information security. The organization

further need to promote and communicate security awareness, establish security

awareness programs, provide education of employees about security policies, etc.

[11][13][14][15][18].

Internal efficiency in terms of the execution of activities, production of artifacts

and the capability of roles has earlier been identified to influence process capability in

[3][19]. We therefore, include an attribute considering if the process is efficiently

managed. The effective implementation of security processes in organizations is

strongly influenced by organizational factors such as top management support,

organizational size, how reliant the organization is on information technology, i.e. IT

reliance, and the environmental uncertainty [15][16][18]. Top management support

may take the form of guidance during planning, participation during design or

involvement during deployment. Besides the ability to secure adequate resources, top

management can also encourage positive user attitude towards the use of information

security. The size of the organization matters as smaller organizations suffer from a

145

lack of human and financial resources. With the lack of funds, smaller organizations

often implement their security processes throughout the organization in a less optimal

way. Depending on the type of industry the organization is active in, the requirements

for security differ. For instance, information security plays a more strategic and criti-

cal role in the financial industry were the environment is highly competitive and vola-

tile [18].

Competence is another critical factor for the effectiveness of implementing

information security [18]. However, [3] argues that competence influences an actor’s

decision making ability, and as competence is defined as experience and how often an

actor works with a subject by [15], these variables are included as attributes in the

Actor class and Role class, which in turn influence if the process is efficiently

managed in the process class.

In Table 1, the attributes for the abstract PRM are shown in this form, i.e. attributes

together with the slot chains defining their parents. In Fig. 1, the complete abstract

PRM is presented including classes, reference slots between classes, the attributes of

each class and the attribute relations. The attributes of the PRM are all defined with

scales. Excerpts of five attribute scales are presented in Fig. 2.

Table 1. Attributes for the abstract PRM shown together with the slot chains defining their

parents.

Attribute

Process.Capability

OrganizationalUnit.SecurityCulture

OrganizationalUnit.SecurityAwareness

Process.IsEffectivelyImplemented

Process.IsEfficientlyManaged

Process.IsEffectivelyImplemented

Process.HasTopManagementSupport

OrganizationalUnit.DegreeOfITReliance

OrganizationalUnit.EnvironmentalUncertainty

OrganizationalUnit.Size

Process.IsEfficientlyManaged

Artifact.Existence

Activity.IsExecuted

Role.HasRoleCapability

Role.IsAssigned

Actor.HasDecisionMakingAbilities

Actor.Competence

ActorIsAwareOfRisks

Actor.Competence

Actor.DegreeOfExperience

Actor.Frequency

Regarding the quantitative part of the PRM, for each attribute local probabilities are

presented using CPDs tables. Fictive numbers are used in Fig. 3 to demonstrate how

146

an instantiated PRM (combined with the proposed dependency model) allows infe-

rence of the process capability.

Fig. 1. The proposed PRM presenting classes, reference slots, attributes and their parents.

Fig. 2. Examples of attribute definitions, and model calculation scales for the two classes

Proce

ss and Organizational Unit.

3.1 Application to the Access Control Process

A simplified demonstration of how a modeler can use the PRM for ISG analysis

applied to the access control process is presented in Fig 3. The access control process

consists of 6 activities that are needed to be executed, 4 artifacts that should exist, and

2 roles that should be assigned in the process. In the evaluation of the fictive medium-

Process

Organizational Unit

Artifact

ExistsIn

SecurityCulture

Exists

Legend

Class

Attribute

ReferenceSlot

[Domain]

[Range]

[Attribute dependency]

[Child]

[Parent]

FillsA

1..*

IsaResourceIn

IsapartOf

ResponsibleFor/

IsAccountableFor

HasTopManagement

Support

1..*

Capability

0..*

Activity

IsapartOf

1..*

Role

Actor

IsAssigned

Competence

Frequency

DegreeOfExperience

IsExecuted

1..*

Size

Enviromental

Uncertainty

IsEffectivelyImple

mented

DegreeOfITreliance

HasDecisionMaking

Abilities

IsEfficientlyManaged

ConsistsOf

0..*

IsakindOf

1..*

SecurityAwareness

IsakindOf

0..*

IsAwareOfRisks

HasRoleCapability

Class Attribute Definition Model scale

The degree of Top management support for

information security.

Subjectively evaluated using perceptual responses

If more than 50% of the a c tivities relate d to a

process is executed

{True, False}

If more than 50% of the artifacts related to a

process exists

{True, False}

If the role is capable of managing the process or

is accountable for the process

{True, False}

The degree of security culture in the organization

Subjectively evaluated using perceptual responses

The de

ree of securit

awareness in the

Subjectively evaluated using perceptual responses

Is Efficiently

managed

Process Has Top

Management

Support

{True, False}

Security

Awareness

{Low, Medium, High}

Organisational

Unit

Security

Culture

{Not developed, Developed,

Highly developed}

147

Fig. 3. The instantiated PRM for access control with CPD tables and fictive numbers.

sized company AB Nordic Energy, the modeler found that 4 out of 6 activities were

executed, and 2 out of 4 artifacts existed in the process. Thus, 67% of the suggested

process activities were executed and 50 % of the artifacts existed. As both values are

more than 50%, these two values yield a True state for activities and a False for

artifacts. Further, at least one of the business manager (Mrs. Adams) and security

.. .. ..

T F T F .. .. .. T F T F

T 10.90.90.8..............

F 00.10.10.2..............

SmallSize Large

LDegreeOfITReliance H

IsEffectivelyImplemented

HasTopManagementSupport

EnvironmentalUncertainty T F

.. Not Developed

.. .. ..

.. ..

T F T F .. .. .. T F T F

H 10.90.90.7.. ...... .. ....

M 00.10.10.2.. ...... .. ....

L 0000.1.. ...... .. ....

Highly developedSecurityCulture

SecurityAwareness

Capability

IsEffectivelyImplemented

IsEfficientlyManaged

TF..TF

T 0.9 0.8 .. 0.2 0.1

F 0.1 0.2 .. 0.8 0.9

IsAwareOfRisks

HasDecision

MakingAbility

Competence H

High Low

Frequently .. Unfrequently

H0.9 .. 0

M0.1 .. 0.1

L0 .. 0.9

Competence

IsExperienced

Frequency

IsAssigned T F

T0.90.6

F0.10.4

HasRoleCapability

HasDecisionMakingAbilities

TF.. T F

T10.7..0.20

F00.3..0.81

HasRoleCapability

ActivityIsExecuted T F

ArtifactExistence

IsEfficiently

Managed

148

manager (Mr. Brown) is responsible for managing the process. The decision making

ability (based on their competence and awareness of risks) of the two actors was

assessed to False and True. Therefore, by combining the fictive probabilistic values

in the local CPD table, the attribute IsEfficientlyManaged yielded a True state.

As AB Nordic Energy is a medium-sized company active in an uncertain

environment and at the same time is Medium reliant on IT, but have top management

support for security endeavors, the attribute IsEffectivelyImplemented yielded a True

value based on the local CPD table for the attribute. Finally, by collecting data for the

last two organizational factors (security culture and security awareness) and combin-

ing these with the already collected data in the CPD table for the attribute process

capability, a state of High was yielded.

This simplified example of how the PRM can be put into practice has shown that

by collecting data from an enterprise ISG structure, using constraint such as those

presented in Fig 2., a value of process capability can be inferred. Further, different

components in the ISG PRM structure can be analyzed and their dependency can be

calculated.

4 Concluding Remarks and Future Work

A literature review was conducted to extract important variables for the governance of

information security, their relation to organizational and human factors and impact on

security process capability. The main contribution with this paper is that we have

argued and demonstrated the general feasibility of performing ISG analysis using

PRMs. We have also provided an instantiated PRM of the access control process and

thus shown how this analysis can be adapted to fit the analysis of a specific process in

an organizational environment. Of interest for future work, and parts of ongoing re-

search, is the enhancement of the PRM; focusing on more specialization of security

processes to provide a PRM that can be used to analysis and calculate the aggregated

capability value of several processes combined such as the risk management process,

patch management process, incidents management process etc. The greatest part of

future research is however to validate the qualitative structure and the attribute rela-

tions in the PRM so that the CPDs can be set with real empirical data. The data will

be collected from case studies combined with surveys with the aim to improve the

accuracy of the predictive function that the PRM can provide.

References

1. Von Solms, S H. Information Security Governance - Compliance Management vs. Opera-

tional Management. Computer & Security. September 2005, pp. 443-447.

2. Winter, R and Fischer, R. Essential layers, artifacts, and dependencies of enterprise archi-

tecture. Journal of Enterprise Architecture, volume 3. 2007, pp. 7-18.

3. Lagerström, Robert, et al., et al. A Method for Creating Enterprise Architecture Metamo-

dels - Applied to System Modifiabiltiy Analysis. International Journal of Computer

Science and Applications, Vol. 6, No. 5. 2009, pp. 89-120.

4. ISACA. Control Objectives for Information and related Technology: ISACA, 2007.

149

5. ISO/IEC. ISO/IEC 27002:2005 Information technology - Security techniques - Code of

practice for information security management. Switzerland : ISO/IEC, 2005.

6. ISO/IEC, JTC1/SC27. Common criteria for information technology security evaluation –

part 1: introduction and general model: ISO/IEC, 2006.

7. A Modeling Language for Interoperability Assessments. Ullberg, J, Johnson, P and

Buschle, M. Stockholm : Springer, 2011. IWEI, Lecture Notes in Business Information

Processing. pp. 61-74.

8. Sommestad, Teodor, Ekstedt, Mathias and Johnson, Pontus. A probabilistic relational

model for security risk analysis. Computers & Security 29. 2010, pp. 659-679.

9. Learning probabilistic relational models. Friedman, N, et al., et al. 1999. Proceeding of the

16th International Joint Conference on Artificial Interlligence. pp. 1300-1309.

10. Jensen, Finn V. An introduction to Bayesian networks. New York : Springer-Verlag, 1996.

11. ISACA. Information Security Governance: Guidance for Board of directors and Executive

management 2nd Edition: ISACA, 2006.

12. ISF. The standard of Good Practice for Information Security: Information Security Forum,

2007.

13. NIST. Special Publication 800-100 Information Security Handbook: A Guide for Manag-

ers: NIST, 2006.

14. US-CERT. Governing for Enterprise Security (GES) Implementation Guide: US-CERT,

2007.

15. Chang, Shuchih E and Ho, Chienta B. Organizational factors to the effectiveness of im-

plementing information security management. Industrial Management and Data Systems,

Vol. 3 No 3. 2006, pp. 345-361.

16. Kankanhalli, Atreyi, et al., et al. An integrative study of information systems security

effective-ness. Journal of International Journal of Information Management 23. 2003, pp.

139-154.

17. Knapp, Kenneth, et al., et al. Information Security Effectiveness: Conceptualization and

Validation of a Theory. International Journal of Information Security and Privacy, Volume

1 Issue 2. 2007, pp. 37-60.

18. Chang, Shuchih and Lin, Chin-Shien. Exploring organizational culture for information

security management. Industrial Management and Data Systems, Vol. 107 No 3. 2007, pp.

438-458.

19. Simonsson, M, Johnson, P and Ekstedt, M. The effect of IT Governance Maturity on IT

Governance Performance. Information Systems Management. December 2010, pp. 10-24.

150
