OPTIMIZING CRYPTOGRAPHIC THRESHOLD SCHEMES

FOR THE USE IN WIRELESS SENSOR NETWORKS

Position Paper

Manuel Koschuch, Matthias Hudler, Michael Kr¨uger

Competence Centre for IT-Security, FH Campus Wien, University of Applied Science, Favoritenstrasse 226, Vienna, Austria

Peter Lory

Institut f¨ur Wirtschaftsinformatik, Universit¨at Regensburg, Universit¨atsstrasse 31, Regensburg, Germany

J¨urgen Wenzl

TMMO GmbH, Vilsgasse 25, Kallm¨unz, Germany

Keywords:

Sensor networks, Threshold cryptography, Efﬁcient implementation, Multiparty multiplication protocol of

Gennaro, Rabin and Rabin.

Abstract:

A huge number of small, computationally restricted sensor nodes can be connected wirelessly to form a sensor

network. Such networks can be used to monitor large areas and communicate a multitude of measurements

(like temperature, humidity, radiation, and so on) to a remote base station. Since this communication happens

over the air interface, the transmitted messages are susceptible to forgery, manipulation and eavesdropping.

Conventional cryptographic countermeasures against these kind of attacks cannot be readily applied in the

context of sensor networks, due to the limited resources of the individual nodes. Since single nodes can be

very easily captured and examined, symmetric schemes with the secret key present in every (or at least a

subset of) node(s) pose quite a risk in this setting. In this work, we examine the applicability of threshold

cryptographic techniques, especially the Gennaro-Rabin-Rabin multiparty multiplication protocol, for sensor

networks by employing several optimizations to the different steps of this algorithm, building on previous

results we obtained. We are able to improve the running time up to a factor of 6 compared to an unoptimized

version for a bitlength of 1,024 Bit and 33 players.

1 INTRODUCTION

Wireless Sensor Networks (WSNs), where a (poten-

tially huge) number of small, resource-constrained

sensor nodes is deployed in a large area to measure

a wide variety of parameters and communicate them

wirelessly in a hop-to-hop manner to a base station

for evaluation are still an emerging ﬁeld of technol-

ogy. They can be used to efﬁciently monitor things

like water quality, temperature distribution or radioac-

tive particles in areas where approaches using wired

devices are too costly or even impossible.

The current challenge when dealing with wireless

sensor networks is the difﬁculty to achieve conﬁden-

tial, authenticated communication over the air inter-

face. Common techniques against eavesdropping,

message forgery and manipulation that can easily be

deployed on stationary PCs usually do not work in

WSNs, due to the huge constraints in terms of avail-

able memory, computing power and energy of the in-

dividual nodes. The usual way to secure WSNs today

is to use symmetric cryptographic techniques, which

in general can be calculated much more efﬁciently

than their asymmetric counterparts. The problem with

this approach is the storage and distribution of the

keys: two sensor nodes can only communicate when

they share a common symmetric key. But due to the

special structure of WSNs, the loss or malicious re-

moval of single nodes goes largely undetected, so that

an attacker can easily try to extract the secret key from

a captured node. To avoid the whole network becom-

ing compromised by such an attack, usually only a

Koschuch M., Hudler M., Krüger M., Lory P. and Wenzl J..

OPTIMIZING CRYPTOGRAPHIC THRESHOLD SCHEMES FOR THE USE IN WIRELESS SENSOR NETWORKS - Position Paper.

DOI: 10.5220/0003607400750078

In Proceedings of the International Conference on Data Communication Networking and Optical Communication System (DCNET-2011), pages 75-78

ISBN: 978-989-8425-69-0

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

certain number of nodes share the same key, which

raises the new problem of key distribution. A general

overview of different key management techniques us-

able in WSNs is given in (Merwe et al., 2007).

Given these special challenges, the use of thresh-

old cryptography becomes attractive: instead of stor-

ing the secret key on a single node, a number t + 1

of uncompromised nodes must cooperate to generate

a valid secret. Capturing a single node is now use-

less for an attacker, he has to gain access to at least

t+1 nodes to extract the individual shares of the secret

and combine them. There is a multitude of threshold

cryptography schemes proposed in the literature, their

main problem usually being the computational com-

plexity.

In this work we extend our previous work on the

subject by further trying to optimize the Gennaro, Ra-

bin and Rabin (GRR)(Gennaro et al., 1998) protocol,

thereby improving the applicability of this protocol in

the context of sensor nodes.

The remainder of this position paper is structured

as follows: Section 2 gives a general introduction to

the protocol of Gennaro, Rabin and Rabin and details

of our optimizations. Section 3 then presents our cur-

rent experimental results, while ﬁnally Section 4 gives

an outlook on our next steps planned.

2 THE PROTOCOL OF

GENNARO, RABIN AND RABIN

Classical theoretical results (Ben-Or et al., 1988;

Chaum et al., 1988; Goldreich et al., 1987; Yao, 1986)

show that any multiparty computation can be per-

formed securely if the number of corrupted partici-

pants does not exceed certain bounds. For a survey

of these results the reader is referred to the article of

Cramer and Damg˚ard (Cramer and Damg˚ard, 2005).

Unfortunately, without further optimizations these

results are not easily applicable in real world appli-

cations. One of the most prominent examples for

the efforts to accelerate these approaches is the pa-

per of Gennaro, Rabin and Rabin (Gennaro et al.,

1998). Among other results, it presents a more efﬁ-

cient variant of the Ben-Or, Goldwasser and Wigder-

son (Ben-Or et al., 1988) multiplication protocol. It

gives a protocol for the fast multiparty multiplication

of two polynomially shared values over Z

with a

public prime number q.

Polynomial sharing refers to the threshold scheme

originally proposed by Shamir (Shamir, 1979), which

assumes that n players share a secret α in a way that

each player P

(1 ≤ i ≤ n) owns the function value

(i) of a polynomial f

with degree at most t and

α = f

(0). Then any subset of t + 1 participants can

retrieve the secret α (for example by Lagrange’s inter-

polation formula). At the beginning of the multiplica-

tion protocol each player P

holds as input the function

values f

(i) and f

(i) of two polynomials f

and f

with maximum degree t and α = f

(0),β = f

(0). At

the end of the protocol each player owns the function

value H(i) of a polynomial H with maximum degree

t as his share of the product αβ = H(0). Multiplica-

tion protocols of this type are important cryptographic

primitives. In particular, they play a decisive role

in comparing shared numbers (Damg˚ard et al., 2006)

and in the shared generation of an RSA modulus by a

number of participants such that none of them knows

the factorization (Algesheimer et al., 2002; Catalano,

2005).

The multiplication protocol of Gennaro, Rabin

and Rabin (Gennaro et al., 1998) consists of two

steps and requires one round of communication and

O(n

klogn + nk

) bit-operations per player, where k

is the bit size of the prime q and n is the number of

players.

In step 1. player P

(1 ≤ i ≤ 2t + 1) computes

(i) f

(i) and shares this value by choosing a ran-

dom polynomial h

(x) of maximum degree t, such that

(0) = f

(i) f

(i). He then givesplayer P

(1≤ j ≤ n)

the value h

( j).

In (Lory, 2007) a modiﬁcation of this step is given,

which reduces its complexity from O(n

klogn) to

O(n

k) (and thus the complexity of the entire protocol

to O(n

k+nk

)) by utilization of Newton’s scheme of

divided differences.

However, in many practical situations (e.g. the

above mentioned shared generation of an RSA mod-

ulus) k (typically k = 1024) will exceed n and the

O(nk

)-term will still dominate. For these cases, in

(Lory, 2009) a protocol is given, which modiﬁes step

2 to require only O(n

k) bit-operations per player. All

of the above mentioned optimizations were also im-

plemented and subsumed in (Koschuch et al., 2010).

In this work, we perform an additional investiga-

tion of step 2: in this step, each player P

(1 ≤ j ≤ n)

determines his share H( j) of αβ by locally computing

the linear combination

H( j) =

2t+1

∑

i=1

( j), (1)

where the values h

( j) have been communicated to

him by players P

(1 ≤ i ≤ 2t + 1) during step 1. Here,

the λ

are the coefﬁcients of Lagrange’s interpolation

formula of degree 2t, which interpolate the support

abscissas i = 1,2,...,2t + 1 to 0. In general, for a

polynomial of degree d − 1 these known non-zero-

DCNET 2011 - International Conference on Data Communication Networking

constants are given by

(d)

∏

1≤k≤d

k6=i

k− i

modq. (2)

Expanding this equation becomes:

(d+1)

1·2·...·(i−1)·(i+1)·...·d·(d+1)

(−(i−1))·(−(i− 2))·...·(−1)·1·2·...·(d−i)·(d+1−i)

= (−1)

i−1

(d−i+2)·(d−i+3)·...·d·(d+1)

2·3·...·i

Consequently

|λ

(d+1)

| =

(d−i+2)·(d−i+3)·...·d·(d+1)

2·3·...·i

|λ

(d)

| =

(d−i+1)·(d−i+2)·...·(d−1)·d

2·3·...·i

|λ

(d)

i−1

| =

(d−i+2)·(d−i+3)·...·(d−1)·d

2·3·...·(i−1)

and

|λ

(d)

i−1

| + |λ

(d)

| =

i·(d−i+2)·(d−i+3)·...·(d−1)·d

2·3·...·i

(d−i+1)·(d−i+2)·...·(d−1)·d

2·3·...·i

(d−i+2)·(d−i+3)·...·(d−1)·d

2·3·...·i

∗

(i+d−i+1)

(d−i+2)·(d−i+3)·...·(d−1)·d·(d+1)

2·3·...·i

= |λ

(d+1)

From this it follows that for equidistant support ab-

scissas i = 1,2,...,d (as they are used in the GRR pro-

tocol) the unreduced coefﬁcients λ

(d)

of Lagrange’s

interpolation formula of degree d − 1 obey the recur-

sion

|λ

(d+1)

| = |λ

(d)

i−1

| + |λ

(d)

| (3)

This and trivial initial values demonstrate that the λ

(d)

are always integers.

This fact has the consequence that the reduced co-

efﬁcients as given by Equation (2) can be calculated

very easily, because no computation of a modular in-

verse is necessary. In order to keep the absolute val-

ues of the coefﬁcients low, the reduction should not

be done into Z

= {x ∈ Z|0 ≤ x < q} . Rather, the co-

efﬁcients should be from Z

:= {x ∈ Z| − q/2 < x ≤

q/2} (Algesheimer et al., 2002). For small values of

d = 2t + 1 this guarantees small absolute values for

the coefﬁcients and saves computing time.

3 PRELIMINARY RESULTS

Tables 1 and 2 give the comparison between step 2

of the unmodiﬁed GRR protocol with the modiﬁca-

tions made in (Lory, 2009) and in this work, respec-

tively. The ﬁrst version is the straightforward imple-

mentation of the unoptimized GRR protocol, with co-

efﬁcients λ

in the interval Z

; the second version is

designed for small values of n as presented in (Lory,

2009); the third version ﬁnally exploits the observa-

tions of this work and uses coefﬁcients λ

from Z

All the computations use the GNU multiple preci-

sion arithmetic library

in version 5.0.1 and are on

an AMD Athlon64 X2 5200+ with one physical core

deactivated, ﬁxed to 1.0GHz. The results obtained

on this setup can obviously not be compared to those

achievable on actual sensor hardware, but if the cy-

cle count on this test setup is already far too large,

the proposed solution obviously does not work as ex-

pected.

Table 1: Comparison of the running time in milliseconds

of step 2 of the unmodiﬁed GRR protocol and our opti-

mizations of this protocol, as published in (Koschuch et al.,

2010). k denotes the bitlength, n the number of players.

k = 1024 GRR (Koschuch et al., 2010)

n = 5 0.047 0.018

n = 9 0.154 0.081

n = 33 2.218 2.866

n = 129 40.495 154.847

Table 2: Comparison of the running time in milliseconds of

step 2 of the unmodiﬁed GRR protocol and the additional

optimizations of this protocol from this work. k denotes the

bitlength, n the number of players.

k = 1024 GRR Reduction to Z

n = 5 0.047 0.009

n = 9 0.154 0.027

n = 33 2.218 0.371

n = 129 40.495 12.588

Tables 1 and 2 show the comparison of step 2 of

the unmodiﬁed protocol with the optimizations de-

tailed in (Lory, 2009) and the ones performed in this

work, respectively. Our new approach with reduction

to Z

improves the running times signiﬁcantly, up to

a factor of 6 when compared to an unmodiﬁed GRR

implementation. In addition, it can be assumed that

this reduction also results in signiﬁcantly less mem-

ory requirements during protocol execution, although

this still remains to be proven by complementary mea-

surements.

4 OUTLOOK

Our preliminary results look promising and clearly in-

dicate an additional performance improvement when

using the optimizations proposed in this work. The

http://gmplib.org

OPTIMIZING CRYPTOGRAPHIC THRESHOLD SCHEMES FOR THE USE IN WIRELESS SENSOR NETWORKS

- Position Paper

next steps will be to replace the GMP library with

our own code, optimized for constrained devices and

much smaller than the GNU library and ﬁnally port-

ing the protocol to a sensor node to get the timings on

real hardware.

In addition, we also plan to perform a more de-

tailed analysis of the algorithm, including several dif-

ferent bitlengths and numbers of players.

ACKNOWLEDGEMENTS

Manuel Koschuch, Matthias Hudler, and Michael

Kr¨uger are supported by the MA27 - EU-Strategie

und Wirtschaftsentwicklung - in the course of

the funding programme “Stiftungsprofessuren und

Kompetenzteams f¨ur die Wiener Fachhochschul-

Ausbildungen”. Peter Lory is supported by the Eu-

ropean Regional Development Fund - Europ¨aischer

Fonds f¨ur regionale Entwicklung (EFRE).

REFERENCES

Algesheimer, J., Camenisch, J., and Shoup, V. (2002). Ef-

ﬁcient computation modulo a shared secret with ap-

plication to the generation of shared safe-prime prod-

ucts. In Yung, M., editor, Advances in Cryptology

– CRYPTO 2002, number 2442 in Lecture Notes in

Computer Science, pages 417–432. Springer Berlin.

Ben-Or, M., Goldwasser, S., and Wigderson, A. (1988).

Completeness theorems for non-cryptographic fault-

tolerant distributed computation. In Proceedings of

the 20th Annual Symposium on Theory of Computing

(STOC’88), pages 1–10. ACM Press.

Catalano, D. (2005). Contemporary Cryptology, Advanced

Courses in Mathematics - CRM Barcelona, chapter

Efﬁcient distributed computation modulo a shared se-

cret, pages 1–39. Birkh¨auser, Basel.

Chaum, D., Cr´epeau, C., and Damg˚ard, I. (1988). Mul-

tiparty unconditionally secure protocols. In Proceed-

ings of the 20th Annual Symposium on Theory of Com-

puting (STOC’88), pages 11–19. ACM Press.

Cramer, R. and Damg˚ard, I. (2005). Contemporary Cryp-

tology, Advanced Courses in Mathematics - CRM

Barcelona, chapter Multiparty computation, an intro-

duction, pages 41–87. Birkh¨auser, Basel.

Damg˚ard, I., Fitzi, M., Kiltz, E., Nielsen, J., and Toft,

T. (2006). Unconditionally secure constant-rounds

multi-party computation for equality, comparison, bits

and exponentation. In Proceedings of the 3rd The-

ory of Cryptography Conference (TCC’2006), num-

ber 3876 in Lecture Notes in Computer Science, pages

285–304. Springer Berlin.

Gennaro, R., Rabin, M. O., and Rabin, T. (1998). Simpli-

ﬁed VSS and fast-track multiparty computations with

applications to threshold cryptography. In Proceed-

ings of the 17th ACMSymposium on Principles of Dis-

tributed Computing (PODC’98).

Goldreich, O., Micali, S., and Wigderson, A. (1987). How

to play any mental game. In Proceedings of the

19th Annual Symposium on Theory of Computing

(STOC’87), pages 218–229. ACM Press.

Koschuch, M., Hudler, M., Kr¨uger, M., Lory, P., and Wenzl,

J. (2010). Applicability of multiparty computation

schemes for wireless sensor networks - position pa-

per. In Sevillano, J. L., Obaidat, M. S., and Nicopoli-

tidis, P., editors, DCNET 2010 - International Confer-

ence on Data Communication Networking - Proceed-

ings of DCNET and OPTICS 2010, pages 125–128.

SciTePress - Science and Technology Publications.

Lory, P. (2007). Reducing the complexity in the distributed

multiplication protocol of two polynomially shared

values. In Proceedings of the 21st International Con-

ference on Advanced Information Networking and Ap-

plications (AINA’2007), volume 1, pages 404–408.

IEEE Computer Society.

Lory, P. (2009). Secure distributed multiplication of two

polynomially shared values: Enhancing the efﬁciency

of the protocol. In Proceedings of the Third Inter-

national Conference on Emerging Security Informa-

tion, Systems and Technologies (SECURWARE 2009),

pages 486–491. IEEE Computer Society.

Merwe, J. V. D., Dawoud, D., and McDonald, S. (2007).

A survey on peer-to-peer key management for mobile

ad hoc networks. ACM Computing Surveys (CSUR),

39(1):1–45.

Shamir, A. (1979). How to share a secret. Communications

of the ACM, 22(11):612–613.

Yao, A. C. (1986). How to generate and exchange secrets.

In Proceedings of the 27th IEEE Symposium on Foun-

dations of Computer Science (FOCS’86), pages 162–

167. IEEE Computer Society.

DCNET 2011 - International Conference on Data Communication Networking
