A CLAIM TO INCORPORATE FUNCTIONAL DEPENDENCIES

IN DEVELOPMENT TOOLS

Benchmarking and Checking Functional Dependencies Algorithms

Manuel Enciso Garcia-Oliveros, Angel Mora Bonilla, Pablo Cordero and Rosario Baena

Research Group in Mathematics Applied to Computing, University of Malaga, Malaga, Spain

Keywords:

Database design, Functional dependencies.

Abstract:

In this work we summarize the state of the art in the use of database functional dependencies. We compare

the low impact that it has in the commercial environment with its successful acceptation in the academic

environment. Particularly we remark that there does not exists any commercial development tool which uses

the information provided by functional dependencies and this useful information is also deprecated by the

database management systems. As a result of this, large database designs have to be re-built a few years

after their establishment. In this work we identify the reasons which causes this situation and we propose a

guideline to wide spread the effective use of Functional Dependencies in commercial design and tools.

1 INTRODUCTION

Functional Dependencies (FD), were ﬁrst deﬁned by

E.F. Codd in the relational model (Codd, 1970) and

later used in Armstrong’s axiomatic system. It has

been well studied in the past and the design of a nor-

malization method may be consider one the most im-

portant result to take into account to produce high

quality database design.

Database designers do not explicitly use FDs as

it is shown in (Antony and Batra, 2002). In fact, its

use is sparse or inexistent in database design tools and

they do not play a central role in DBMS (Database

Management Systems) (they appears only in the form

of key constraints).

A tool which really uses this information is the

exception and it can be found in academical and re-

search institutions with an interesting approach from

the Knowledge Engineering perspective (Concepcion

and Villafuerte, 1990). Unfortunately, this work is

outdated and discontinued.

In this work, we summarize some result that we

consider as valuable elements that may open the door

to solve this problem, more concretely, we have:

• A strong theoretical background proposal: the

logic, a true executable logic for FDs.

• A careful and uniﬁed implementation of all clas-

sical FD-Closure algorithms.

• The group’s SL

-Closure algorithm, based on a

free and open framework of reusable components

for efﬁcient FD-algorithm and data structures in-

tegration (common framework).

• A method to generate random test sets for FDs

algorithm benchmarking with several parameters

and strategies and suitable to be extended.

• An multi-languageweb site to illustrate the execu-

tion of these algorithms and theirs performances.

Our intention with the proposal of these elements

in a uniﬁed tool is to motivate the research in the de-

sign of efﬁcient methods to manage FDs and to pro-

mote their use and the integration into database tools.

2 THEORETICAL BACKGROUND

Throughout the literature there have been a lot of al-

gorithms for the management of FDs. In (Mora et al.,

2006) the authors carried out a empirical study of the

efﬁciency of closure algorithms for FDs. One conclu-

sion of this preliminary study was the need for a care-

ful implementation of the algorithms to allow further

comparisons with new methods.

Another important consequence of FDs algo-

rithms comparisons, is the need for test suites that

allow a uniform and heterogeneous comparison. We

claim for a set of test which recreate different models

to stress the algorithms in different directions. Nowa-

days, there isn’t public repositories that provide clas-

313

Enciso Garcia-Oliveros M., Mora Bonilla A., Cordero P. and Baena R..

A CLAIM TO INCORPORATE FUNCTIONAL DEPENDENCIES IN DEVELOPMENT TOOLS - Benchmarking and Checking Functional Dependencies

Algorithms.

DOI: 10.5220/0003608803130316

In Proceedings of the 6th International Conference on Software and Database Technologies (ICSOFT-2011), pages 313-316

ISBN: 978-989-8425-76-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

sic benchmarks of FDs to verify both the efﬁciency

and behavior of the algorithms.

Another important concern is the design of infer-

ence systems for the management of FDs that may

serve as a basis for the development of automated

management of FDs. Armstrong’s axiomatic system

is the core for many logics of FDs. All these logics

have a common characteristic: they use the transitiv-

ity rule which limits their direct application and the

further development of methods with efﬁcient deduc-

tion capabilities. As a conclusion, these logics are not

used in the deﬁnition of FDs management algorithms.

There exists another logic approach that substi-

tutes the transitivity rule by a new rule and allows

the creation of automatic algorithms for the manage-

ment of FDs. The authors (

Angel Mora et al., 2004)

presented the Simpliﬁcation Logic for FDs (SL

which is equivalent to Armstrong’s axiomatic system.

The main core of SL

is a new rule of simpliﬁca-

tion, that allow the elimination of redundant attributes

efﬁciently, turning it into an executable logic which

opens the door to the creation of efﬁcient algorithms.

The authors have also developed a set of algo-

rithms to solve the most important FDs problems: the

closure of a set of atoms, the redundancy removal to

get FDs basis and the calculation of minimal keys.

3 A DISCUSSION AROUND

IMPLEMENTATION ISSUES

All the algorithms for FDs deal with a simple data

structure: FDs are represented using two associated

sets of attributes. Their ﬂow are mainly based on

primitives set operators: union, intersection, differ-

ence, etc.

As (Wirth, 1978) points out, programs arenotonly

algorithms, they depend strongly in data structures.

We have made two version of the implementation of

set of attributes. The two implementations are based

on the representation of the set of attributes as a set of

bits. So we have two versions of each DF algorithm:

Fixed. The size of the set of atoms of is ﬁxed and

each bit represents an attribute. The cost of set

operators depends on the maximum number of at-

tributes of all the FDs in the set.

Sparse. The size of the set is variable, having the

same cardinality than the number of attributes on

each side of the FD. The cost of set operators de-

pend on the size of the FD involved in the concrete

execution.

Sparse implementations are recommended when

the number of attributes which form FD, is very low

compared to the cardinality of the set of atoms. This

situation may be found on those models with a sig-

niﬁcant number of “small” FDs. In models where all

the attributes appears in only a few number of FDs is

better tackled using the ﬁxed approach. A degener-

ated version of this situation is the start models, used

in data warehousing, with a central table containing

the data analysis, surrounded by other smaller tables

called dimension tables.

The standard algorithm (Maier, 1983) is ﬁrst pre-

sented in the literature that calculates the closure in a

nonlinear time: O(kUkkΓk

)

, where Γ is the set of

FDs and U the set of all attributes in Γ.

In this work we have consider ﬁve different clo-

sure algorithms which appears in the literature: (Beeri

and Bernstein, 1979), (Diederich and Milton, 1988),

(Paredaens et al., 1989) , (Maier, 1983) and (Mora

et al., 2006). Each algorithm, as we have mention

above, has been development in two different ver-

sions: ﬁxed and sparse. To compare the efﬁciency

of these algorithms, we have also developed a method

to generate random sets of FDs with different char-

acteristics, provided by a set of different parameters

detalied above.

3.1 Benchmarking of Functional

Dependencies

As we have mentioned, the lack of benchmarks for

FDs limits the uniﬁed comparison of proofs for the ef-

ﬁciency and behavior of the FDs algorithms. Unless it

is possible to generate random FDs sets, a more depu-

rated method to produce set of FDs which represent

different models is demanded. He have developed

strategies to increase the control in the generation of

FDs sets. In our approach the user can parametrize

the random generation which determines the selection

of an strategy. This strategies are characterized by a

combination of the cardinality of the set of attributes

and the size

of the right and left hand sides in the

FDs:

Size. This is the ﬁrst strategy used in (Mora et al.,

2006). In this strategy, we provide a maximum

level to the size of FDs and the left size is limited

of this threshold and

on the right.

Vanilla. The user provides two values which repre-

sent the maximum percentage of attributes on the

left and on the right. The percentages determines

two separate lengths in both sides of the FDs and

kXk

denotes the cardinality of

The size is deﬁned in the literature as the sum of the

lengths of the left-hand side and the right-hand side.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

314

Figure 1: FDs algorithm in action.

its size is always proportional to the cardinal of

the set of attributes.

Groups. It allows us a more precise generation of the

FDs sets and it obtains more realistic sets, closer

to real database schemas. The attributesare classi-

ﬁed in three groups: very frequents, medium fre-

quents, lower frequents. For each group we pro-

vide the probabilities for left and right hand sides.

The methods to built both sides of the FD are dif-

ferent: the attributes more frequents has a big-

ger probability of being in the left-hand side that

the others two groups. In the right-hand side the

attributes with medium and lower frequency are

more frequently used.

3.2 A Tool to Motivate the Use of

Functional Dependencies

The proposal of this paper is to re-activate the

use of FDs in real software engineering tools.

To illustrate the successful management of

FDs, a web application has been developed

(http://sicuma02.lcc.uma.es:8080/WebTin2007).

This web application provides a simple and straight-

forward interface for the interactive execution of

closure algorithms over tree kind of input data:

1. The user supplies a concrete set of FDs. We pro-

vide a simple language to be used as a speciﬁca-

tion of FD sets which allows to test a single prob-

lem with one algorithm or with all the algorithms.

2. Examples from the literature: the user may select

a FDs set and an attributes set speciﬁed in the in-

put language.

3. Random generation of big FDs sets: an advanced

FDs set generator can be used to automatically

generate a big and complex set of FDs.

4 CONCLUSIONS

This work claims for the practical use of Functional

Dependencies and try to promote the integration of

the FDs algorithms into the software engineering

tools. In this work we have concluded:

• The theoretical efﬁciency of the algorithms in the

literature does not match with the empirical re-

sults obtained after a rigorous implementation of

them.

• The theoretical studies do not pay attention to data

structures.

• It is not possible to establish a uniform compari-

son among algorithms without the source code.

• In others areas the use of benchmarks for the com-

parison of hard problems is a crucial issue.

These evidences reinforce the proposal oft his

work: the need to have a common framework for

algorithms tests, including the deﬁnition of bench-

marks, as a preliminary step to promote the use of

FDs in software Engineering tools for the design and

development of database schemas.

REFERENCES

Antony, S. R. and Batra, D. (2002). CODASYS: a consult-

ing tool for novice database designers. ACM SIGMIS

Database, 33:54–68.

Beeri, C. and Bernstein, P. A. (1979). Computational prob-

lems related to the design of normal form relational

schemas. ACM TDS, 4(1):30–59.

Codd, E. F. (1970). A relational model of data for large

shared data banks. Commun. ACM, 13(6):377–387.

Concepcion, A. I. and Villafuerte, R. M. (1990). Expert db:

an assistant database design system. In Proceedings

A CLAIM TO INCORPORATE FUNCTIONAL DEPENDENCIES IN DEVELOPMENT TOOLS - Benchmarking and

Checking Functional Dependencies Algorithms

315

of the 3rd Int. Conf, volume 1 of IEA/AIE ’90, pages

333–340. ACM.

Diederich, J. and Milton, J. (1988). New methods and fast

algorithms for database normalization. ACM TODS,

13:339–365.

Maier, D. (1983). The theory of relational database. Com-

puter Science Press.

Mora, A., Aguilera, G., Enciso, M., Cordero, P., and

de Guzm´an, I. P. (2006). A new closure algorithm

based in logic: Slfd-closure versus classical closures.

Inteligencia Artiﬁcial, Revista Iberoamericana de In-

teligencia Artiﬁcial, 10(31):31–40.

Angel Mora, Enciso, M., Cordero, P., and de Guzm´an, I. P.

(2004). An efﬁcient preprocessing transformation for

functional dependencies sets based on the substitution

paradigm. In Current Topics in Artiﬁcial Intelligence,

volume 3040 of LNCS, pages 136–146. Springer.

Paredaens, J., Bra, P. D., Gyssens, M., and Gucht, D. V.

(1989). The structure of the relational database

model. Springer.

Wirth, N. (1978). Algorithms + Data Structures = Pro-

grams. Prentice Hall PTR.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

316
