NO SECURITY BY OBSCURITY – WHY TWO FACTOR

AUTHENTICATION SHOULD BE BASED ON AN OPEN DESIGN

Jinying Yu

and Philipp Brune

Hochschule Neu-Ulm - University of Applied Sciences, Wileystraße 1, D-89231 Neu-Ulm, Germany

Keywords: IT-Security, Identity Management, Two Factor Authentication, Smart Cards.

Abstract: The recently reported security issue possibly compromising the security tokens sold by a major vendor of

two factor authentication (2FA) solutions (Schneier, 2011) demonstrates the importance of the basic

principle of using an open design for security solutions (Saltzer and Schroeder, 1974). In particular, the

safety of such devices should not be based on the use of a secret algorithm or seed value to generate a

sequence of one-time passwords (OTP) inside the security token. Instead, we argue in favour of using an

open design using pre-generated sequences of OTP that are stored encrypted on the security token. Here, the

safety of the solution only relies on the confidentiality of the decryption key and not the design of the

solution itself. We illustrate our argumentation by describing a respective authentication scheme and a

prototype based on an open design, the latter being used as the basis for the security analysis.

1 INTRODUCTION

There exist several established commercially

available solutions for implementing 2FA in an

enterprise context. There, the 2FA is achieved by a

user's secret knowledge (e.g. a password) in

combination with the user's possession of a certain

device, the so-called security token (e.g. a smart card

or USB device). By means of entering the password,

the user obtains a OTP (usually a multi-digit

number) from the security token. The user now

authenticates with the OTP at the desired service.

The advantage of the OTP is that it is only valid for

a short period of time, thus providing additional

security.

Since Lamport (Lamport, 1981) published a

remote user authentication scheme in 1981, many

smart card-based 2FA authentication schemes have

been proposed in the literature (Yang and Shieh,

1999, Yang et al., 2006 and references therein).

Most related publications discuss possible

mathematical algorithms to compute the OTP within

the security token and the related security problems

(Sood et al., 2010, and references therein).

Based on these results, most available 2FA

solutions also use an algorithm implemented in

parallel inside the security token as well as the

authentication server to generate a secret OTP

number sequence. Thus, an OTP presented by the

user may be verified inside the authentication server

by comparing it to the value generated by the

implementation inside the server. However, this

design embodies two weaknesses:

 Due to inevitable small derivations in the

accuracy of the timer clocks inside the security

token and the server, the number sequence

generation for the OTP runs out of sync after

some time. Thus, an additional mechanism for

re-synchronization is needed.

 The safety of this approach lies in the

unpredictability of the generated number

sequence used for the OTP. Thus, the

algorithm used for the number generation or at

least its seed values need to be kept secret.

Especially the second point prohibits the use of a

fully open design for such solutions. The recently

reported theft of algorithm and seed value details

from a major vendor of 2FA solutions, performed

probably by an advanced persistence threat (APT)

attack against the companies' servers (Schneier,

2011) in the authors' opinion once again clearly

emphasizes the necessity of using an open design for

IT security solutions.

For a long time, open design is considered as one

of the basic principles of IT security (Saltzer and

Schroeder, 1974). Thus, the authors emphasize that

it should be applied also to the design of 2FA

solutions. Particularly, the safety of the solution

418

Yu J. and Brune P..

NO SECURITY BY OBSCURITY – WHY TWO FACTOR AUTHENTICATION SHOULD BE BASED ON AN OPEN DESIGN.

DOI: 10.5220/0003610004180421

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2011), pages 418-421

ISBN: 978-989-8425-71-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

should not rely on the obscurity of the OTP

sequence generation algorithm or seed value.

One approach for an authentication scheme

allowing for an open design would be to abandon the

use of a security token in the scheme (Ku, 2004).

However, this would be no true 2FA scheme

anymore.

Using an open design, a suitable 2FA solution

should instead at least fulfil the following

requirements:

 No OTP generation inside the security token,

thus removing the need for synchroni-sation

with the authentication server as well as for

keeping the generation algorithm secret.

 No need for a secret seed value or generation

algorithm, the full design should be open

without a loss of security.

 No need for a special purpose hardware device

(e.g. a smart card) used as the security token.

 Thus, neglecting legal issues, a 2FA solution

should be at least potentially releasable as open

source software (OSS) without a loss of

security.

Any solution following these requirements keeps

to the basic principle of an open design. In

particular, its security would not be based on

obscurity.

The rest of the paper is organized as follows:

First, an authentication scheme for 2FA using an

open design and based on the requirements stated

above and a prototype implementation for it are

presented. Second, based on the prototype

implementation, a security analysis in comparison

with the standard smart card-based approach is

presented. We conclude with a summary of our

findings.

2 AUTHENTICATION SCHEME

Figure 1 shows an overview of a two factor

authentication scheme fulfilling the above

requirements and used as the reference model in

what follows. It contains four main components,

namely:

 The service server (e.g. a web or virtual private

network (VPN) server) the user wants to

access,

 The clients representing the users and their

respective client software to connect to the

service server,

 The authentication server used to validate the

user's credentials and OTP,

 The storage medium used as the security token

that contains the encrypted OTP sequence.

Figure 1: Authentication scheme overview.

Within this scheme, the 2FA is achieved as

follows:

In the registration phase, a user-specific list of

OTP sequence numbers is generated by the

authentication server and stored encrypted on the

security token and the authentication server. In

addition, a client software is installed on the security

token that allows to decrypt the OTP list and obtain

the next valid OTP by entering a valid PIN or

password.

In the authentication-and-login phase, a user

first authenticates at the (web-based) authentication

server with a valid user-id and password (e.g. via

HTTPS protocol). The authentication server then

presents the user a sequence number indicating

which OTP in the list shall be used.

Next, the user enters the OTP sequence number

and the password (this password is designed to

decrypt the OTP list and is not necessarily the same

as the one used to log in at the authentication server)

in the client software running on the security token.

The software decrypts and displays the

corresponding OTP. The user now could

authenticate at the service server with user-id and

OTP within validity time period of the OTP.

In the verification phase, the service server

checks the validity of the provided user-id and OTP

with the authentication server. Thus, user logs in at

the service server with a different OTP each time

and each OTP is only valid for a short period of

time, e.g. 30 seconds. As the security token any

mobile device capable of storing the encrypted OTP

list and running the decryption client software may

be used.

In order to perform the security analysis, the

authors also implemented the described

NO SECURITY BY OBSCURITY - WHY TWO FACTOR AUTHENTICATION SHOULD BE BASED ON AN OPEN

DESIGN

419

authentication scheme as a prototype for evaluation

and further studies. This implementation uses

ubiquitous cell phones as security tokens storing the

encrypted OTP list, similar to many commercially

available solutions.

The web-based authentication server and the

client software components were developed in the

the Java programming language, using the Java EE

and Java ME frameworks for the server-side and

cell-phone components, respectively. The service

server calls the authentication server by means of a

web service. The OTP list is generated by the

authentication server and encrypted using a strong

encryption algorithm, e.g. Twofish (Schneier et al.,

1998).

Since almost every business person today uses a

Java-enabled cell phone, this approach to 2FA a

does not require additional equipment for users, thus

creating no additional costs. Therefore, also some

commercially available 2FA solutions now offer a

cell phone-based software replacement of the smart

card.

3 SECURITY ANALYSIS

In the security analysis of the prototype

implementation for the described authentication

scheme, different typical attacks are considered (Lin,

2001).

Since the algorithm for generating the OTP lists

is not needed to be defined within the authentication

scheme and its implementation needs to reside only

on the authentication server and not the security

tokens, any known algorithm for generating a

sequence of random numbers may be used. It is also

possible to easily switch the generation scheme

regularly or to use different versions at the same

time. Therefore, assuming that always a state-of-the-

art algorithm is used, an intruder may not predict or

forge the OTP list.

E.g., the HMAC-based OTP algorithm (HOTP)

may be used (M'Raihi et al., 2005), which generates

OTP values by using keyed hashed message

authentication code (HMAC). With the HOTP

algorithm, the only thing that has to kept secret is the

so-called secret key (not necessarily identical with

the user's OTP list decryption key). Any iterative

cryptographic hash function could be used within the

HOTP algorithm. Since the proposed scheme allows

to use arbitrary secret keys and hash functions for

the OTP list generation, the difficulty of forgery and

prediction attacks is additionally increased. Thus,

the authentication scheme is resistant against these

attacks as well as an eavesdropping of the sequence

number send to the user during the authentication-

and-login phase.

If an intruder eavesdrops a valid authentication

message during the login process to the service

server, the attempt to perform a replay attack will

fail in the verification phase since every OTP is

invalidated by the authentication server after used

once. This is similar for all approaches using an

OTP.

However, a major security threat for the scheme

is the possible disclosure of the encrypted OTP list

from a user's security token. In case the security

token (i.e. a cell phone) is stolen or lost, and the user

realizes the loss, the stored list may easily be

invalidated on the authentication server and replaced

by a new one. However, if the user does not realize

the loss of the device or only the OTP list is copied

from the device, the list may be disclosed by an

offline password guessing attack. Although the

stored OTP list is encrypted using a strong

encrypting algorithm (e.g. Twofish), there is still the

danger that an intruder might decrypt it within its

period of validity. Depending on the length and the

strength of the used password, the encryption might

be broken by a password guessing attack. Thus, it is

important to use sufficiently strong passwords for

the OTP list encryption.

In the future, an interesting solution for this

might be the use of self-destructing digital data to

prevent copying of the list. E.g., the research project

Vanish (Geambasu et al., 2009), conducted by

University of Washington, intends to develop such a

digital data.

Additionally, the OTP lists should be exchanged

frequently. However, this increases the

administrative overhead of distributing the OTP lists

to the security tokens. Thus, a suitable automation

solution for this should be considered.

In summary, any solution implementing the

described 2FA scheme, following the stated open

design principles and fulfilling the above

requirements, in the authors' opinion is not less

secure than the frequently used OTP number

generation inside the security token.

4 CONCLUSIONS

In conclusion, we presented our opinion on how

2FA should be implemented using an open design

approach. We claimed that the recently reported

security issue once again demonstrated the

SECRYPT 2011 - International Conference on Security and Cryptography

420

importance of the basic principle of using an open

design.

We described a respective two factor

authentication scheme and developed a prototype

implementation used for the security analysis.

The presented security analysis discusses the

resistance of the scheme against the most common

attacks. However, further research is needed to

prove the resistance of the approach to various other

kinds of attacks. In addition, the possibilities of

using self destructing data to secure the OTP list

need to be further investigated.

REFERENCES

Geambasu, R., Kohno, T., Levy, A., Levy, H. M. (2009).

Vanish: Increasing Data Privacy with Self-Destructing

Data. In Proceedings of the USENIX Security

Symposium. Montreal, Canada.

Ku, W. C. (2004). A Hash-Based Strong-Password

Authentication Scheme without Using Smart Cards.

SIGOPS Operating Systems Review, 38(1), 29-34.

Lamport, L. (1981). Password authentication with insecure

communication. Communications of the ACM, 24(11),

770-772.

Lin, C. L., Sun, H. M., Hwang, T. (2001). Attacks and

Solutions on Strong-Password Authentication. IEICE

Transactions on Communications, E84-B(9), 2622-

2627.

M'Raihi, D. Bellare, M., Hoornaert, F., Naccache, D.,

Ranen, O. (2005). HOTP: An HMAC-Based One-

Time Password Algorithm. In Request for Comments,

4226. Internet Engineering Task Force. Retrieved May

15, 2011, from http://www.ietf.org/rfc/rfc4226.txt

Saltzer, J. H., Schroeder, M. D. (1974). The Protection of

Information in Computer Systems. Communications of

the ACM, 17(7).

Schneier, B., Kelsey, J., Whiting, D., Wagner, D., Hall, C.

(1998). Twofish: A 128-Bit Block Cipher. AES-Sub-

mission.

Schneier, B. (2011). Schneier on Security (Blog).

Retrieved April 8, 2011, from

http://www.schneier.com/blog/archives/2011/03/rsa_s

ecurity_in.html

Sood, S. K., Sarje, A. K., Singh, K. (2010). An

Improvement of Xu et al.’s Authentication Scheme

using Smart Cards. In COMPUTE '10, Proceedings of

the Third Annual ACM Bangalore Conference. ACM.

Yang, G., Wong, D., Wang, H., Deng, X. (2006). Formal

Analysis and Systematic Construction of Two-Factor

Authentication Scheme. In Information and

Communications Security (Lecture Notes in Computer

Science) (pp. 82-91). Berlin / Heidelberg: Springer.

Yang, W. H., Shieh, S. P. (1999). Password

Authentication with Smart Cards. Computers &

Security, 18(8), 727-733.

NO SECURITY BY OBSCURITY - WHY TWO FACTOR AUTHENTICATION SHOULD BE BASED ON AN OPEN

DESIGN

421
