E-BUSINESS INTEROPERABILITY

Challenges and Opportunities

George Feuerlicht

1,2

Faculty of Engineering and Information Technology, University of Technology, Sydney

P.O. Box 123, Broadway, NSW, 2007, Australia

Faculty of Information Technology, University of Economics, Prague, Czech Republic

Keywords: e-Business interoperability, SOA, e-Business standards.

Abstract: Starting with EDI in the 1970s numerous efforts have been made to facilitate electronic business

communications. Early attempts based on proprietary document formats and VAN (Value Added Networks)

networks have been superseded by a range of international standards that include ebXML, UBL, BODs,

GS1, RosettaNet and numerous other XML-based specifications. While successful in some industry

domains, overall e-business standardization suffers from complexity of the specifications, difficult

customization and limited extensibility leading to expensive implementation and low adoption rates. A

common feature of such e-business standards is their focus on documents as the key artefacts of business

communications and reliance on document engineering methods for the design of the standard

specifications. In this paper we briefly review the main e-business document standards, and then argue that

the document-centric interoperability model underlying most current e-business standards produces

inflexible specifications that are difficult to evolve and maintain. As an alternative to the document-centric

interoperability model we advocate a service-centric approach based on well-designed domain services.

1 INTRODUCTION

The vision of seamless electronic communications

between organization dates back to the early days of

networking in 1970s. Replacing paper-based

business communications with electronic documents

that can be transmitted at very low cost and acted on

instantly has been the focus of considerable efforts

initially in supply chain situations and later across

entire industry domains. The economic benefits of

reducing the cost and improving the accuracy of

business to business transactions can be

considerable. For example, a study that investigated

the cost of poor interoperability resulting from a lack

of standardization in the US automotive industry

estimated the loss to be about one billion dollars per

year (Brunnermeier and Martin 2002). In a recent

study of the impact of e-business (electronic

business) interoperability Legner et al. compare the

cost of lack of interoperability across various

application domains, including manufacturing and

healthcare management and identifies a range of

interoperability research issues (Legner and

Lebreton 2007). Notwithstanding extensive

standardization efforts over several decades, e–

business interoperability remains an open problem.

Numerous standardisation bodies including

UN/CEFACT (UN/CEFACT 2011), OAGIS (The

Open Applications Group. 2010), RosettaNet

(www.rosettanet.org 2007) have produced a plethora

of e-business standards in various stages of

completion. Low quality of standard specification

resulting from poorly controlled standardization

process relying on “design by committee” rather

than on an effective design methodology is a

frequent source of ambiguities and complexity

presenting challenges to organizations adopting such

standards. Furthermore, some researchers argue that

availability of a document standard while being an

essential prerequisite is not sufficient to guarantee e-

business interoperability and advocate service-based

interoperability solutions (Feuerlicht 2005; Legner

and Vogel 2008). In this paper we first discuss the

concept of e-business interoperability (section 2),

and then review e-business standardization efforts

identifying their common characteristics and

limitations (section 3). In section 4 we argue that the

document-centric model that forms the basis of most

193

Feuerlicht G..

E-BUSINESS INTEROPERABILITY - Challenges and Opportunities.

DOI: 10.5220/0003618601930198

In Proceedings of the International Conference on e-Business (ICE-B-2011), pages 193-198

ISBN: 978-989-8425-70-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

major e-business standard specifications is

fundamentally flawed and that a new service-centric

approach is needed in order to improve the

effectiveness of e-business solutions. In the

following section (section 5) we describe the

service-centric interoperability model, and in section

6 we present our conclusions.

2 E-BUSINESS

INTEROPERABILITY

Interoperability requirements of e-business

applications have been exhaustively documented in

the literature (Bussler 2001), (McAfee, Bettiol et al.

2007). According to Bussler interoperability can be

classified into three levels: 1) technical, 2)

information, and 3) business process levels.

Technical level interoperability addresses technical

issues including communication protocols,

programming language environments, and

technology platforms used by individual business

partners. Information level interoperability concerns

data elements transmitted between partner

organizations and can be further classified into:

syntax, structure, and semantic interoperability.

Syntax refers to formats used to represent data

elements (e.g. delimited document formats, XML,

etc.). Structure and semantics of data elements refers

to organization of data elements into compound

structures and the meaning of individual data

elements, respectively. Business process

interoperability is concerned with collaborative

activities between partner organizations. Bussler

classifies business processes into public and private.

A private process represents a flow of business tasks

within an enterprise, while a public process

represents a flow of interactions between business

partners. Business process interoperability is

concerned with public processes that define external

actions that participants perform. Classification of e-

business interoperability into different types (levels)

is shown in Table 1. Other authors use similar

classifications of e-business interoperability and

there is an agreement about the need to develop

standards for all levels of interoperability to fully

automate e-business interactions.

Wide acceptance of XML as a document

formatting standard and the emergence of standard

protocols for delivering document payloads as XML

formatted messages (REST (www.ics.uci.edu 2002),

and Web Services SOAP (WC3 2007)) provide an

effective interoperability solutions for the

technology and syntax levels.

Table 1: Levels of e-business interoperability.

INTEROPERABILITY

LEVEL

DESCRIPTION

Business Process collaborative activities

between partner

organizations

Semantic meaning of individual data

items

Structure structure of data elements

Syntax document formats

Technology communication protocols

and technology platforms

Most standardization efforts focus on the

remaining interoperability levels and attempt to

address structure, semantic and business process

heterogeneity by specifying standard XML messages

and business process interactions, either for a

specific industry domain (vertical standards) or

across industry domains (horizontal standards).

Examples of vertical standards include RosettaNet

(www.rosettanet.org 2007), Chemical Industry

CIDX (Chemical Information Technology Center)

(Open Application Group 2010), Healthcare HL7

(Health Level 7) (HL7.ORG 2007), and Travel OTA

(Open Travel Alliance) (OTA 2010). Attempts at

all-encompassing horizontal standardization centre

around the UN/CEFACT (UN/CEFACT 2011) Core

Components Technical Specification (CCTS) and

include ebXML (ebXML 2007), UBL 2.0 (OASIS

2011), OAGIS Business Object Documents (BODs)

(The Open Applications Group. 2010) and The

Global Standard One (GS1) XML (European Article

Number (EAN) and the Uniform Commercial Code

(UCC)). We discuss some of these standards in the

following section.

3 E-BUSINESS

STANDARDIZATION

Over the last three decades e-business solutions have

evolved from relatively simple proprietary point-to-

point systems that rely on documents translation to

highly complex XML-based specifications. EDI

(Electronic Data Interchange) (UN/EDIFACT 2010)

was the first attempt to establish e-business

interoperability standard initially using delimited

plain-text documents mainly for procurement,

logistics and finance domains. Communication

between partner organizations is implemented using

VANs (Value-Added Networks) and EDI adapters

that are used to interface internal systems to the

network. While providing an overall framework by

defining a set of common business messages, EDI

requires that the parties agree on the format and

ICE-B 2011 - International Conference on e-Business

194

content of business documents, with dominant

partners often imposing their standard on smaller

organizations. This leads to fragmentation of the

specification and to proliferation of diverse EDI

versions that are established over time by dominant

partners or groups. Such standards do not scale well

when a large number of organizations is involved as

each new business relationship requires a new set of

message standards and corresponding translation

software that converts internal proprietary data

formats into trading partner-specific standard

messages. The creation of new business messages or

changes to the existing standard message sets are

complex and time consuming activities, as the

modifications have to be approved by

UN/EDIFACT (United Nations/Electronic Data

Interchange For Administration, Commerce and

Transport) standard committees. More recent

versions of EDI use Internet protocols (i.e. HTTP) as

the transport for XML formatted messages. Despite

its well documented limitations EDI use is still

growing (Kabak and Dogac 2010).

Following these early attempts to standardize e-

business interactions with EDI related specifications,

a wave of vertical (industry domain specific) and

horizontal (cross-industry domain) standards

emerged, some with perplexing inter-relationships

and overlapping specifications. We discuss these

standardization efforts in the following sections.

3.1 Vertical Industry Domain

Standards

Vertical standardization efforts are typically driven

by industry-domain consortia that produce XML

message specifications and standard process

definitions for a given industry domain. When

compared to horizontal standards, vertical standards

tend to be more narrowly focused and provide

higher levels of interoperability as many of the

concepts and processes are shared across all

participants. Examples of vertical domain standards

include RosettaNet, OTA, and HL7. RosettaNet is a

consortium of major computer and consumer

electronics, semiconductor manufacturing, tele-

communications and logistics companies.

RosettaNet defines standards at three levels:

technology, vocabulary, and process levels, covering

the entire interoperability spectrum described in

Table 1, and supports multiple messaging standards,

including Web Services. RosettaNet uses the

concept of Partner Interface Processes (PIPs) to

define business processes between trading partners.

PIPs define the interfaces between processes running

in different partner organizations that constitute a

supply chain. PIP definitions include message

structure specification and business process logic

that controls the flow of messages. RosettaNet has

been particularly successful in high-technology

supply chain applications, but so far has not gained

wide acceptance outside the high technology sector.

Another example of a vertical standard is the

Open Travel Alliance specification that defines a

comprehensive set of XML message schemas (over

230 message schemas) as the basis for electronic

communications between partner organizations

within the travel industry. The OTA specification

covers all aspects of travel business, including air

travel, cruises, hotel accommodation, car hire, and

travel insurance, with the scope of the specification

continuously expanding. To implement specific

business functions, for example to book a flight,

OTA uses request (RS) and response (RQ) message

pairs that are typically transmitted between parties as

Web Services SOAP messages. OTA standard

messages are widely adopted by companies that

implement travel applications (e.g. Sabre (Sabre

2007)) and follow strict naming conventions and

design guidelines (OTA 2010). OTA messages are

constructed using common data types that form a

repository of reusable XML Schema components.

OTA specification does not directly address business

process interoperability; composing individual Web

Services into process flows using BPEL (Business

Process Execution Language) (Arkin, Askary et al.

2007) could be used to provide such functionality.

3.2 Horizontal Industry Standards

Vertical standards do not fully address the

requirements of e-business application that span

industry domains. Horizontal e-business standards

are designed to be industry domain neutral and

typically deal with much greater scope of

standardization. Horizontal e-business standard-

ization efforts are led by UN/CEFACT with its Core

Components Technical Specification (CCTS). The

main idea underlying the CCTS specification is the

concept of Core Components - context-free reusable

building blocks that are maintained in a common

repository (Core Component Library) and used to

construct business documents. Core Components are

aggregated into Aggregated Core Components

(ACCs) to represent real-world entities (e.g.

Purchase Order). Core Components that are

specialized (adapted) for a specific business context

(for example, a geopolitical context of the European

Union) are called Business Information Entities

(BIEs). Core Components and other CCTS artefacts

are stored in the Core Component Library (CCL)

and are used across a number of standard

specifications as the basis for defining business

documents. These standards include OASIS

E-BUSINESS INTEROPERABILITY - Challenges and Opportunities

195

Universal Business Language (UBL) 2.0 (OASIS

2011), Open Applications Group Integration

Specification (OAGIS) Business Object Documents

(BODs) (The Open Applications Group. 2010) and

The Global Standard One (GS1) XML (European

Article Number (EAN) and the Uniform

Commercial Code (UCC)). In some cases the

standards have been re-designed for compliance

with the UN/CEFACT CCTS (e.g. OAGIS BODs).

Although all of these standards are based on CCTS

with the aim to ensure maximum flexibility of the

specification, customization and extensibility

features vary considerably from standard to standard

(Kabak and Dogac 2010). Furthermore, some

standards allow documents to contain embedded

command commands that specify the operation to be

executed on the document. For example, OAGIS

BODs introduce the concept of Nouns (documents)

and Verbs (actions) with verb-noun combinations

specifying the action to be performed on the object,

e.g. CancelOrder. Multiple Nouns can be associated

with a single verb, allowing for the same action to be

performed on multiple documents. GS1 XML

documents contain Commands (Add, Delete,

Refresh) and Transactions that support the execution

of multiple Commands within the scope of a single

transaction.

4 LIMITATIONS OF THE

DOCUMENT-CENTRIC

APPROACH

A common characteristic of the interoperability

approaches described in the previous section

(section 3) is that they adopt the document-centric

interoperability model characterized by shipping

business documents between partner systems. The

original motivation for the document-centric

approach was the need to overcome technology level

heterogeneity; as documents provide a level of

abstraction that allows business interactions based

on the mutual understanding of data semantics

without the need for compatible technology

platforms (i.e. no direct interoperability between the

partner systems is needed as the receiving partner is

responsible for mapping the documents into

transactions against the target system). As noted in

section 2, standard protocols (i.e. Web Service

SOAP or REST) address technical level

interoperability making this approach unnecessary

today.

The principal limitation of the document-centric

approach is its tendency to use large and complex

documents that often mirror the original paper-based

forms, as message payloads. Messages typically

include all the information needed to perform a

particular business function without any reference to

information already received. While such stateless

interactions reduce the number of messages needed

to implement a particular business function,

improving reliability in failure-prone high latency

network environments, the externalization of

complex data structures introduces high levels of

data coupling (Feuerlicht 2007). The message

payloads form the interface between e-business

applications and introduce interdependencies,

making changes to standard documents difficult to

perform without causing undesirable side-effects

that invalidate existing applications. Design of

standard documents is typically based on Document

Engineering (Glushko and McGrath 2008) or similar

methods that construct documents by identifying and

aggregating common data elements, e.g.

UN/CEFACT CCTS Core Components. Embedding

aggregated Core Component structures into multiple

business documents causes high levels of data

coupling with corresponding impact on applications

when the specification evolves. Embedding complex

data structures formed by aggregation of core

components (ACCs, etc) in business documents is

promoted in Document Engineering literature as a

technique for achieving reuse, but this approach

differs fundamentally from software reuse as it

applies to software engineering (e.g. in the

programming context). It can be argued that the use

of aggregated data structures implicit in the

document-centric approach limits, rather than

enhances reuse.

5 SERVICE-CENTRIC

INTEROPRABILITY MODEL

Service-centric approach provides an alternative

interoperability model by changing the level of

abstraction from document interchange to a

programmatic approach based on well-defined APIs

(Application Service Interfaces). Unlike documents,

procedures (i.e. service operations) typically

implement specific business functions and use

simple data parameters as procedure signatures (i.e.

service interfaces). Service interfaces can be

designed to limit externalization of data and to avoid

creating unnecessary interdependencies between

services. Encapsulating data structures and

externalizing method signatures (i.e. interfaces of

service operation) that constitute a stable contract

between the service provider and the service

ICE-B 2011 - International Conference on e-Business

196

consumer results in improved stability and ability to

accommodate change. Software engineering

principles can be applied to the design of service

interfaces maximizing cohesion and minimizing

service coupling. This limits the impact of changes

to a small number of services improving the stability

and maintainability of services, (Feuerlicht 2004).

Extensibility is supported by versioning individual

service interfaces rather than the entire specification

as is the case in most document-centric standards

(e.g. OTA).

There are two key requirements for achieving

information-level interoperability for service-centric

e-business applications in a particular domain: 1)

standardization of all data elements (i.e. a domain-

wide vocabulary standard) and 2) standardization of

service interfaces. Without a domain-wide service

interface standard, equivalent services published by

different providers will not be compatible, placing

the burden for resolving the inconsistencies on

service consumers. Such domain-specific service

interfaces are conceptually similar to APIs that are

used extensively in programming environments (e.g.

JDBC, or ODBC for database access). The

abstraction level of standardized, domain-specific

APIs is closely related to business processes in the

particular domain, so that the APIs constitute a

programming environment for developing domain-

specific applications. For example, a travel

application could be implemented using a

specialized set of travel APIs based on the OTA

specification, but with low granularity service

operations that perform airline flight bookings, hotel

reservations, car rentals, and other travel related

transactions. Unlike the current practice of using

OTA based Web Services as a transport mechanism

for OTA messages, this approach relies on a well-

designed domain-specific programming language as

the basis for developing travel applications.

6 CONCLUSIONS

The emergence of SOA (Service-Oriented

Architecture) and related technologies (Web

Services, REST services, etc.) has created an

opportunity to address e-business interoperability

using a new paradigm. So far, most e-business

solutions use Web Services (or REST services)

primarily as a transport layer for the delivery of

standard documents, failing to take full advantage of

the service-oriented approach. Faster and

significantly more reliable network connectivity

available today makes it possible to design lower

granularity services that closely correspond to

atomic business functions. This reduces the problem

of managing complex document standards to a more

manageable task of standardizing service interfaces

(i.e. service APIs) for a given application domain.

Such domain-specific service APIs are conceptually

similar to APIs that are used extensively in

programming environments. The key difference

between document-centric and service-centric

interoperability models is that service APIs can be

designed to minimize interdependencies by

encapsulating message data structures and

externalizing stable service interfaces that constitute

a contract between the service provider and the

service consumer. Regarding domain standardization

as a software project rather than an effort to define

message structures for data interchange enables the

deployment of proven software development

methodologies resulting in a more stable and flexible

specification. As is the case with other complex

software projects, the ability to design standard

specifications from software modules (i.e. services

and service operations) that can evolve

independently enhances the flexibility of the

specification and provides a solid basis for

accommodating future requirements.

ACKNOWLEDGEMENTS

The authors wish to acknowledge the support of the

Grant Agency, Czech Republic - GACR Grant No.

GA406011, P403/11/0574 and of the Research

Centre for Human Centered Technology Design at

the University of Technology, Sydney, Australia.

REFERENCES

Arkin, A., S. Askary, et al. (2007). "Web Services

Business Process Execution Language (WS-BPEL)."

OASIS (www. oasis. org), Version 2.

Brunnermeier, S. B. and S. A. Martin (2002).

"Interoperability costs in the US automotive supply

chain." Supply Chain Management: An International

Journal 7(2): 71-82.

Bussler, C. (2001). "B2B Protocol Standards and their

Role in Semantic B2B Integration Engines." Bulletin

of the Technical Committee on Data Engineering

24(1): 3-11.

ebXML. (2007). "ebXML - Enabling A Global Electronic

Market." Retrieved 9 December 2007, 2007, from

http://www.ebxml.org/.

European Article Number (EAN) and the Uniform

Commercial Code (UCC). "Global Standards One

E-BUSINESS INTEROPERABILITY - Challenges and Opportunities

197

(GS1)." Retrieved 02-04-2011, 2011, from http://

www.gs1.org/.

Feuerlicht, G. (2005). "Design of service interfaces for e-

business applications using data normalization

techniques." Information Systems and E-Business

Management 3(4): 363-376.

Feuerlicht, G., Meesathit, S. (2004). Design framework for

interoperable service interfaces. 2nd International

Conference on Service Oriented Computing, New

York, NY, USA, ACM Press.

Feuerlicht, G., Wijayaweera, A. (2007). Determinants of

Service Resuability. 6th International Conference on

Software Methodologies, Tools and Techniques,

SoMet 06, Rome, Italy, IOS Press.

Glushko, R. and T. McGrath (2008). "Document

engineering: analyzing and designing documents for

business informatics and Web services." MIT Press

Books 1.

HL7.ORG. (2007). "Health Level 7." Retrieved 10

December 2007, from http://www.hl7.org/.

Kabak, Y. and A. Dogac (2010). "A survey and analysis of

electronic business document standards." ACM

Computing Surveys (CSUR) 42(3): 1-31.

Legner, C. and B. Lebreton (2007). "Business

interoperability research: Present achievements and

upcoming challenges." Electronic Markets 17(3): 176-

186.

Legner, C. and T. Vogel (2008). "Leveraging Web

Services for implementing vertical industry standards:

a model for service-based interoperability." Electronic

Markets 18(1): 39-52.

McAfee, A., M. Bettiol, et al. (2007). Electronic

Hierarchies and Electronic Heterarchies: Relationship-

Specific Assets and the Governance of Interfirm IT,

Citeseer.

OASIS. (2011). "Universal Business Language (UBL)."

from http://www.oasis-open.org/committees/

tc_home.php?wg_abbrev=ubl.

Open Application Group. (2010). "CIDX." from http://

www.cidx.org/.

OTA. (2010). "OTA Specifications." Retrieved 6 May

2010, from http://www.opentravel.org/Specifications/

Default.aspx.

Sabre. (2007). "Sabre Holdings :: World Leader in Travel

Distribution, Merchandising, and Retailing Airline

Products." Retrieved 10 December 2007, from

http://www.sabre-holdings.com/.

The Open Applications Group. (2010). "Open

Applications Group Integration Specification."

Retrieved 02-04-2011, 2011, from http://

www.oagi.org/oagis/9.0/.

UN/CEFACT. (2011). "United Nations Centre for Trade

Facilitation and Electronic Business." Retrieved 02-

04-2011, 2011, from http://www.unece.org/cefact/.

UN/EDIFACT. (2010). "United Nations Directories for

Electronic Data Interchange for Administration,

Commerce and Transport." from http://

www.unece.org/trade/untdid/down_index.htm.

WC3. (2007). "SOAP Specifications." Retrieved 6 May

2008, from http://www.w3.org/TR/soap/.

www.ics.uci.edu. (2002). "Architectural Styles and the

Design of Network-based Software Architectures."

Retrieved 31 January 2008, from http://

www.ics.uci.edu/~fielding/pubs/dissertation/top.htm.

www.rosettanet.org. (2007). "RosettaNet Home."

Retrieved 9 December 2007, from http://

www.rosettanet.org/cms/sites/RosettaNet/.

ICE-B 2011 - International Conference on e-Business

198
