DATA AND ACCESS MANAGEMENT USING ACCESS TOKENS

FOR DELEGATING AUTHORITY TO PERSONS AND SOFTWARE

Hidehito Gomi

Yahoo! JAPAN Research, 9-7-1 Akasaka, Minato-ku, Tokyo 107-6211, Japan

Keywords:

Delegation, Access management, Identity federation, Access token.

Abstract:

Delegation of authority is an act whereby an entity delegates his or her rights to use personal information

to another entity. It has most often been implemented in enterprise environments, but previous studies have

focused little on the dynamic data and access management model or the design from a practical viewpoint.

A data and access management model for the delegation of authority is proposed. In the proposed model, an

access token that is an opaque string associated with authorized permission is issued and exchanged among

users and entities across security domains. The framework enables ﬁne-grained access control and permission

assignment for delegated access by persons and software agents.

1 INTRODUCTION

With the proliferation of Web services on the Internet,

there is an increasing need for providing personalized

services for users. With such services, users are often

required to share their personal information with other

persons or software entities so that they can complete

tasks collaboratively in the same way as in the real

world. Because personal information is accessed by

an entity that is not its owner, ﬂexible access control

is essential regardless of whether the entity is a person

or a software agent. This falls within the scope of del-

egating authority to access personal information from

person to person and/or to software agent from a tech-

nical perspective.

In general, users hope to provide only trusted en-

tities with access to their personal information, and

they only do so for a very speciﬁc reason. They are

reluctant to delegate to unauthorized entities due to

security and privacy concerns. Since trusted entities

do not automatically have access privileges, it is nec-

essary to ﬂexibly and dynamically assign them. In

addition, if we assume that both a person and a soft-

ware agent can be users, there are a couple variations

to the type of access that is delegated. One is a case

in which a person delegates direct access of personal

information to another person, and the other is a case

in which a person delegates indirect access via a soft-

ware agent. The challenge here is to develop a method

of data and access management for delegating author-

ity that works well with the above cases in a distribu-

ted environment.

Various models havebeen proposed to enable ﬂex-

ible and dynamic access management for delegation

tasks. Unfortunately, many of these models are con-

ventional in that they assume the delegation takes

place in closed environments. Recently there has been

some research on dynamism and ﬂexibility when ex-

changing personal information and assigning permis-

sion, but they focus on either an abstract model or

a speciﬁc protocol design and pay little attention to

consolidating both aspects for practical requirements.

Moreover, in terms of design viewpoint, they do not

pay sufﬁcient attention to supporting both person-to-

person and person-to-software delegation.

This paper proposes a data and access manage-

ment model and design framework for delegating au-

thority between users in an environment that supports

identity federation. The proposed system has partic-

ipating entities exchange an access token that repre-

sents the authorization delegation information and is

then used to control delegated access.

The rest of this paper is organized as follows. Sec-

tion 2 reviews related work. Section 3 presents sce-

narios that provided the motivation to attempt this

work. Section 4 describes the overview of the pro-

posed system and Section 5 describes the data and

access management model. In Section 6, technical

issues are discussed. Finally, Section 7 summarizes

the conclusions and outlines future work.

457

Gomi H..

DATA AND ACCESS MANAGEMENT USING ACCESS TOKENS FOR DELEGATING AUTHORITY TO PERSONS AND SOFTWARE.

DOI: 10.5220/0003619504570463

In Proceedings of the International Conference on Security and Cryptography (MPEIS-2011), pages 457-463

ISBN: 978-989-8425-71-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2 RELATED WORK

This section summarizes previous works related to

delegation, access control models, and technical spec-

iﬁcations.

Research on delegation and access control to

enhance the role-based access control (RBAC)

model (Sandhu et al., 1996) has frequently been re-

ported (Barka and Sandhu, 2000; Zhang et al., 2003;

Wainer and Kumar, 2005; Joshi and Bertino, 2006).

When these works are combined with RBAC, they are

effective for delegation, especially in a single domain

or a closed environment such as an enterprise system,

because roles generally have a hierarchical structure

reﬂecting the users’ position therein.

Another important line of contribution focused

on dynamic and ﬂexible delegation methods in dis-

tributed and multiple security domains (Li et al.,

2003; Pham et al., 2008; Bussard et al., 2009; Chad-

wick et al.,2009). These works proposed access con-

trol models that support dynamic permission assign-

ment at the point of delegation, which is relevant to

the work proposed in this paper. However, this work

differs in that it focuses on a practical method and

system design for transferring information after dele-

gation authorization beyond security domain bound-

aries.

Another line of research related to delegation is

ﬁne-grained access control models (Hasebe et al.,

2010; Cohen et al., 2002). While that research fo-

cused on conceptual access control models, this work

focuses more on key technologies for dynamic access

control and permission assignment from the view-

point of design and implementation. In the techni-

cal approach of SPKI (Ellison et al., 1999) and that

proposed by Gomi et al. (Gomi et al., 2005), certiﬁ-

cates of authorization rights are distributed and trans-

ferred from one person to another. They focused on

the speciﬁcation of the certiﬁcates whereas this work

speciﬁcally introduces an access management model

using access tokens.

Some emerging technical speciﬁcations provide

schemes for exchanging identity information using a

token made up of short lengths of string, which is rele-

vant to the work proposed in this paper. SAML (OA-

SIS) works by specifying a scheme for exchanging

identity information using an artifact, which is a ref-

erence to an assertion containing the information.

However, the artifacts are not speciﬁcally designed

for delegation of authority and can only be used by

trusted entities, not persons. OAuth (OAuth, 2009)

provides a method for delegation from user to appli-

cation by means of an access token. In contrast, this

work focuses on a more generic access model and its

Delegation

Financial planning

request

Bob (husband)

Internet service provider

(ISP)

Financial planning center

(FPC)

Alice (wife)

records

Bob’s

pension

records

Bob’s pension record

request

Stores and reviews pension records

Bob’s pension record request

Figure 1: Motivating scenarios.

design framework for user-to-user delegation of au-

thority. In addition, SAML and OAuth do not provide

any scheme for controlling token access.

3 MOTIVATING SCENARIOS

This section describes two scenarios that illustrate the

motivation behind this work (Fig. 1). Bob and Alice

are a married couple who are working for different

companies. They are interested in ﬁnancial planning

to reduce their income taxes, repay their loans, and

prepare for their future. Bob has already stored his

pension records on his account managed by an Inter-

net service provider (ISP) and views the information

privately. Alice would like to view his information

by accessing the ISP so that she can consider their

planning by herself from their family’s perspective.

In this case, the ISP needs to identify who Alice is

and what she wants in order to ensure an appropriate

access control for the request.

Alice is also considering signing up for a ﬁnancial

planning service publicized by a ﬁnancial planning

center (FPC) on the Internet. Such a service would

require her to display her and Bob’s current ﬁnan-

cial status to offer an ideal plan for their future lives.

In this case, Bob’s pension records at the ISP need

to be provided to the FPC in a secure and privacy-

preserving manner because the FPC can only provide

Alice with the service on its site. If we assume that the

FPC requests access to Bob’s pension records man-

aged by the ISP, the access request needs to be identi-

ﬁed by the ISP in the same way as it identiﬁed Alice’s

original request.

In both scenarios, because Alice is the recipi-

ent of the services using Bob’s pension records—in

other words, one person is accessing and using an-

other person’s data—Alice’s access needs to be au-

thorized by Bob, even though they are married, before

the ISP will accept her request for his data regardless

of whether it is via the FPC or not. In order to do

so, Alice needs to be provided with an appropriate

privilege to access Bob’s pension records and use the

SECRYPT 2011 - International Conference on Security and Cryptography

458

information for the speciﬁc services.

4 SYSTEM OVERVIEW

This section describes the overview of the proposed

system supporting delegation.

A user is a person who accesses restricted re-

sources provided by other entities. A user has his

or her trusted contacts’ contact addresses (e.g., ac-

count identiﬁers or e-mail addresses) through which

they can interact with each other. In this model, there

are two types of users: delegators and delegatees.

A delegator is a user who has privileges that can en-

able others to access his or her identity information.

A delegatee is a user who is provided privileges by a

delegator to access the delegator’s identity informa-

tion. A delegator and a delegatee have a prior trust

relationship and share their contact addresses.

A service provider (SP) is an entity that provides

access to restricted resources managed by its site to

authorized users. An SP supports the delegation of re-

sources containing personal information. This means

that an SP may grant a delegatee’s access to a dele-

gator’s resource on the basis of its security policies

if an SP veriﬁes the appropriateness of the delegated

access request by the delegatee.

An identity provider (IdP) is an authentication

and attribute authority that authenticates users by

means of particular authentication methods and pro-

duces an assertion stipulating the completion of the

authentication event or the correctness of personal at-

tribute information. In this model, an IdP has an addi-

tional delegation mediating (DM) capability that su-

pervises the delegation authorization of a delegator

to a delegatee and conveys its information to a cor-

responding SP.

This work proposes introducing a delegation ac-

cess token (DAT), which is a randomized string rep-

resenting a reference to a delegated permission to be

transferred from a delegator to a delegatee. There are

two phases in the overall procedure for completing

delegation of authority. Each phase is brieﬂy intro-

duced from the viewpoint of data and access manage-

ment, which is depicted in Figs. 2 and 3. The solid

and dashed lines represent data ﬂow and relations be-

tween entities or data, respectively.

Phase 1 (Delegation Authorization Mediation) is

shown in Fig. 2.

1. The delegator sends a request to the delegation au-

thorization mediation service (DAMS) at the IdP

for mediating authorization for his or her delega-

tion. The request speciﬁes a delegatee, a set of

Delegator

Association

(2) Access control

Delegation

authorization

mediation

service (DAMS)

Permission

(5) DAT transfer

Delegatee

(1) Delegation authorization

mediation request

DAT

IdP

Permission

(4) Delegation authorization

mediation response

Object

(3) DAT generation &

permission assignment

Figure 2: Delegation authorization mediation.

personal attributes, and an entity at which a dele-

gation operation is executed by the delegatee.

2. The IdP makes a decision on whether to grant or

deny the request.

3. The IdP generates a DAT and assigns a permission

for the delegatee or the SP.

4. The IdP sends the DAT to the delegator if the re-

quest is granted.

5. The delegator transfers the received DAT to the

delegatee and informs the delegatee.

Phase 2 (Delegation Service Provisioning) is

shown in Fig. 3.

1. A delegatee attempts to access an identity service

(IdS) at an IdP (an SP) by presenting a DAT that

he or she has received from the delegator.

2. The IdP (the SP) decides whether to grant or deny

the delegated access request. When the SP re-

ceives the request (shown in Fig. 3(b)), the SP

obtains an assertion of the delegator’s personal in-

formation from the IdP in the following manner.

2-a. The SP sends an assertion request including the

DAT to the assertion issuing service (AIS) at

the IdP.

2-b. The IdP makes an access control decision on

whether to grant or deny the SP’s assertion re-

quest by verifying the received DAT.

2-c. The IdP returns the assertion if the SP’s request

is granted.

3. The IdP (the SP) provides the delegatee with the

request delegation service if the above decision is

conﬁrmed.

5 DATA AND ACCESS

MANAGEMENT MODEL

This section describes the access management model

proposed in this work.

DATA AND ACCESS MANAGEMENT USING ACCESS TOKENS FOR DELEGATING AUTHORITY TO PERSONS

AND SOFTWARE

459

(2) Access control

IdP

Permission

Object

Identity

service (IdS)

(1) Delegated access request

DAT

(3) Delegated access

response

Delegatee

(a) Delegation service provisioning (at IdP).

IdP

(1) Delegated access request

(2-c) Delegated access response

Assertion

Identity

service (IdS)

(2) Access control

Delegatee

(2-a) Delegated access request

(3) Delegated access response

Permission

Object

Assertion

issuing

service (AIS)

DAT

(2-b) Access control

Permission

Object

(b) Delegation service provisioning (at SP).

Figure 3: Delegation service provisioning.

Objects. An object is a passive entity that con-

tains a set of a user’s attribute information. This

model denotes an object set O as O = {o|o ∈

A||o ∈ AS}, where A is a set of attributes consist-

ing of pairs of attribute name and value A = {a|a =

{(n

),··· , (n

),···}} if attribute name n

and its

value v

for a speciﬁc user are given. AS is a set of

assertions containing multiple attributes a in a for-

mat: AS = {as|as = Assert(a),a ∈ A}, where func-

tion Assert(a) produces an assertion based on the

information a of a speciﬁc user in a format common

to its recipient. For example, Bob, who stores his pen-

sion records at an IdP, has the following attribute in-

formation: o = {(

BasicPensionNumber

13597

)}.

Domains. A domain is the scope of entities (IdP or

SP) in this model. The components and their rela-

tions in a domain are independent of those in other

domains. If we let D denote a set of domains, D =

{IdP,SP}. A domain that issues a DAT is called a to-

ken issuer (TI) and a domain whose service receives

an access request with a DAT is called a token con-

sumer (TC).

Operations. An operation is a function that may be

executed on an object. An operation opr is repre-

sented by action@domain, where action is an action

performed on an object and domain is the TC at which

the action on the object is performed. For example,

operation opr = read,write@SP ∈ OPR, which is a

set of operations.

Permissions. A permission is a description of the

type of authorized operations that a user can perform

on an object. P ⊆ {(opr,o)|opr ∈ OPR∧ o ∈ O}.

Services. A service is an interface of interactions

between users and the other system entities (IdP or

SP) in a speciﬁed format. A service obtains a link to

the object on which a user calls an operation when

the request is granted. S has two types of services

for an IdP and an SP: S

IdP

= {DAMS,IdS} and S

{AIS, IdS}.

Constraints. A constraint (C) is a requirement that

needs to be satisﬁed in order to grant an access re-

quest. There are separate constraints for DATs and

permissions.

The access management model consists of DATs

(Tokens for short, T), P, O, S, D, and C, which are

shown in Fig. 4. Each component and its relations are

Token-permission

association

Tokens

(T)

Permissions

(P)

Objects

(O)

Permission-object

assignment

Constraints

(C)

Services

(S)

User’s request

Operation

Token handling

invocation

Domain （D)

Figure 4: Data and access management model.

abstractly represented together for both phase 1 and 2.

Namely, the user’s request is a delegation authoriza-

tion mediation request from a delegator or a delegated

access request from a delegatee. The services are at

the IdP or the SP in either phase.

5.1 Token-based Permission

Assignment

The IdP manages an access control policy to allow a

delegator to authorize his or her delegation request in

a user-centric way. When an IdP receives a delega-

tion authorization mediation request from a delegator,

namely Domain d = IdP and Service s = DAMS, and

it is authorized, it assigns the appropriate permission

SECRYPT 2011 - International Conference on Security and Cryptography

460

to grant access to the authorized object. This proce-

dure consists of the DAT generation, the object and

permission creation, and the DAT and permission as-

sociation.

Delegation Access Token Generation. After an

IdP grants a delegator’s delegation authorization me-

diation request, the IdP generates a unique DAT t. A

DAT encapsulates the information of an IdP which

generates and issues the DAT. Given a DAT, an IdP

and an SP can obtain its issuer information by a pre-

deﬁned method. A DAT also encapsulates its token

type information, which is unique to its issuer’s do-

main. The state transition from T to T

′

when gener-

ating a new DAT t is represented by T

′

← T ∪ {t},

where t /∈ T. Let t.issuer and t.type respectively de-

note the TI’s identiﬁer and the type of DAT t that are

available to the token consumer receiving the DAT.

Constraints for DATs (Token Constraints) are speci-

ﬁed by t.type on the basis of how and where the dele-

gator’s personal information is to be used.

Object and Permission Creation. If an IdP re-

ceives a delegator’s authorization mediation request

specifying that he or she allows a delegatee to use a

set of attribute information, the following object and

permission is created:

• O

′

← O∪ {o}, where o /∈ O;

• P

′

← P ∪ {p}, if p /∈ P; and

• PO

′

← PO ∪ {(p,o)|o ∈ O}.

Token and Permission Association. A DAT gen-

erated from the delegation authorization of a delega-

tor and a permission created to perform the delegation

are associated with each other to securely control the

delegated access. We denote permission as a map-

ping function from T to P; TP

′

← TP ∪ {(t, p)|p ∈

P, p = permission(t), where (t, p) /∈ TP. This map-

ping function will also be used when verifying a DAT

attached to a delegated access request (see Sec. 5.2).

Permission Assignment Algorithm. The proce-

dure for permission assignment is shown in Alg. 1,

which integrates each operation described above.

First, an IdP (a TI), receives a delegation authoriza-

tion mediation request and obtains the information

of operation and attribute names contained in the re-

quest (steps 1–3). In steps 4–12, a set of attributes

based on the attribute names received in the above

request by retrieving a value of each attribute name

for a given delegator u is obtained. After creating

a permission for the requested operation and the at-

tribute (step 13), the access decision for delegation

authorization is made (steps 14–16), where the op-

erator “<” indicates the dominance relation between

two permissions. Here, p

′

< p means that p has more

authority than p

′

. Namely, if any permission’s autho-

rization is not included in p, the access request is de-

nied. Next, authzID uniquely represents the identiﬁer

of the delegator’s authorization in the IdP. Using this

identiﬁer as well as the issuer and type information,

a DAT is generated and registered (steps 17–19). If

the speciﬁed consumer is not the issuer domain, an

assertion is created using attribute a and a new per-

mission for propagating it to the consumer is created

(steps 20–25). Finally, the target object is registered,

the permission is also registered if its scope is not cov-

ered by any existing permission, and an association is

made between the DAT and the permission (steps 26–

30). If the request is granted, the DAT is returned

(step 31).

5.2 Token-based Service Provisioning

When a service receives an access request with an at-

tached DAT, the entity managing the service executes

the procedure of access control in which it decides

to grant or deny the request. In this model, the pro-

cedure consists of verifying the DAT, determining its

corresponding permission and object, and enforcing

its corresponding constraints.

Algorithm 1: Permission Assignment (at IdP).

Require: delegator u has been authenticated; issuer: this

IdP;

1: req ← receiveDlgAuthZMedRequest()

2: opr ← getOperation(req)

3: attrNames ← getAttrNames(req)

4: a ←

5: for all i such that n

∈ attrNames do

6: v

← getAttributeValue(u,n

)

7: if v

= null, then

8: return false

9: else

10: add(a,(n

))

11: end if

12: end for

13: p ← createPermission(opr,a)

14: if ∃p

′

∈ P; p

′

< p, then

15: return false

16: end if

17: authzID ← generateAuthzID()

18: t ← generateDAT(authzID,issuer,type)

19: add(T,t)

20: if opr.consumer = issuer, then

21: o ← a

22: else

23: o ← Assert(a)

24: p ← createPermission(provision@opr.consumer,o)

25: end if

26: add(O,o)

27: if ∀p

′

∈ P; p

′

< p, then

28: add(P, p)

29: end if

30: associate(t, p)

31: return t

DATA AND ACCESS MANAGEMENT USING ACCESS TOKENS FOR DELEGATING AUTHORITY TO PERSONS

AND SOFTWARE

461

Here, if the combination of a domain and a service

is denoted by (d,s), (d,s) = (IdP,IdS),(IdP,AIS),

and (SP, IdS). This model deals with all three cases

together. If the domain is either an IdP or SP, the TI is

the IdP for all three cases, while for (d,s) = (SP,IdS),

the TC is the SP.

Token Veriﬁcation. When an entity (an IdP or an

SP) receives a delegated access request with an at-

tached DAT, the entity determines whether or not it

is correct. If a received DAT t does not have a pre-

deﬁned format or a ﬁxed length, t is incorrect because

it has been inappropriately forged or modiﬁed. Even

if the above condition is true, if t.type or t.issuer is

incorrect, t is incorrect. Otherwise, t is correct.

Permission and Object Discovery. After a DAT

has been veriﬁed, the above entity retrieves and

checks which entity issued it by referring to the in-

formation of t.issuer. If the TI is the entity itself,

it attempts to determine the permission and the ob-

ject corresponding to the DAT in its local domain by

means of the mapping function, permission(t). If

the above function does not drive any existing per-

mission, the entity determines that the access request

is invalid because the DAT does not have an appropri-

ate association with a permission. If the TI is not the

entity, it attempts to retrieve an assertion by present-

ing it to the TI.

Constraint Enforcement. The proposed model

supports dynamic and ﬂexible permission assignment

because a delegatee can access personal information

as long as he or she presents a correct DAT. To pre-

vent inappropriate access and strengthen the proposed

token-based access control, a TI can specify con-

straints for permission (permission constraints) that

place some restrictions and conditions on the permis-

sion of delegating authority.

Token-based Access Control Algorithm. The pro-

cedure of a TC controlling delegated access is shown

in Alg. 2, which integrates the above operations.

In steps 1–3, the TC receives a delegate access

request and then obtains its operation and DAT. In

steps 4–6, the DAT is veriﬁed. In step 8, the per-

mission associated with the DAT is obtained. If an

expired permission is discovered, it is deleted from

the permission set (steps 11–13). In steps 17–25, the

TC sends a delegated access request recursively to the

TI, retrieves an assertion, and assigns the permission.

In steps 26–31, the procedure for constraint enforce-

ment is performed. If any constraints associated with

permission are not satisﬁed, the access request is de-

nied. This procedure returns the authorized object if

the request is granted. In this way, the scheme pro-

vides a delegation service that is consistent with the

three types of interactions in Fig. 3.

6 DISCUSSION

This section discusses several security issues. The

proposed model is considered to complement exist-

ing access control models such as RBAC. DATs and

the roles used in the RBAC model are relevant in that

these are intermediaries to permissions. Therefore,

more investigation is needed to integrate these mod-

els. In this work, the focus was not on how a del-

egator distributes a DAT to his or her delegatee in a

secure fashion. However, this is a fundamental issue

relevant to how two entities share their secret with one

another, and it remains an open issue.

Algorithm 2: Token-based Access Control.

Require: TC thisEntity ∈ {IdP,SP}; token type: type.

1: req ← receiveDelegatedAccessRequest()

2: opr ← getOperation(req)

3: t ← getDAT(req)

4: if t = null or verified(t) = false, then

5: return null

6: end if

7: if t.issuer = thisEntity, then

8: p ← permission(t)

9: if p /∈ P, then

10: return null

11: else if expired(p) = true, then

12: del(P, p)

13: return null

14: else

15: o ← p.o

16: end if

17: else {t.issuer 6= thisEntity}

18: res ← sendDelegatedAccessRequest(t,t.issuer)

19: as ← getAssertion(res)

20: o ← getObject(as)

21: p ← createPermission(opr, o)

22: if ∀p

′

∈ P; p

′

< p, then

23: add(P, p)

24: end if

25: end if

26: constraints ← getConstraints(p)

27: for all c such that c ∈ constraints do

28: if satisfied(c) = false, then

29: return null

30: end if

31: end for

32: return o

SECRYPT 2011 - International Conference on Security and Cryptography

462

7 CONCLUSIONS AND FUTURE

WORK

The data and access management model proposed in

this paper supports the delegation of authority from

user to user and/or software agent using access to-

kens. Algorithms and a design for token-based per-

mission assignment and access control enable dy-

namic delegation of authority with limited overhead

cost for managing the association between an access

token and its corresponding permission. Our future

work will include further investigation into the in-

tegration of the proposed model and other relevant

models.

REFERENCES

Sandhu, R., Coyne, E., Feinstein, H., Youman, C. (1996).

Role-based access control models. IEEE Computer

38–47

Barka, E., Sandhu, R. (2000). Framework for role-based

delegation models. In Proceedings of the 16th Annual

Computer Security Applications Conference. 168–176

Zhang, L., Ahn, G. J., Chu, B. (2003). A rule-based

framework for role-based delegation and revocation.

ACM Transactions on Information and System Se-

curiry, 404–441.

Wainer, J. and Kumar, A. (2005). A ﬁne-grained, control-

lable, user-to-user delegation method in RBAC. In

Proceedings of the 10th ACM Symposium on Access

Control Models and Technologies (SACMAT’05). 59–

Joshi, J. and Bertino, E. (2006). Fine-grained role-based

delegation in presence of the hybrid role hierarchy. In

Proceedings of the 11th ACM Symposium on Access

Control Models and Technologies (SACMAT’06). 81–

Li, N. and Grosof, B. and Feigenbaum, J. (2003) Delegation

logic: a logic-based approach to distributed authoriza-

tion. ACM Transactions on Information and System

Securiry 128–171

Pham, Q. and Reid, J.and McCullagh, A. and Dawson, E.

(2008) Commitment issues in delegation process. In:

Proceedings of the 6th Australasian Information Se-

curity Conference (AISC’08). 27–38

Bussard, L. and Nano, A. and Pinsdorf, U. (2009) Delega-

tion of access rights in multi-domain service composi-

tions. Identity in the Information Society, 2, 137–154

Chadwick, D. W. and Otenko, S. and Nguyen, T. (2009)

Adding support to XACML for multi-domain user to

user dynamic delegation of authority. International

Journal of Information Security, 8, 137–152

Hasebe, K. and Mabuchi, M. and Matsushita, A. (2010)

Capability-based delegation model in RBAC. In Pro-

ceedings of the 15th ACM Symposium on Access Con-

trol Models and Technologies (SACMAT’10) 109–118

Cohen, E. and Thomas, R. and Winsborough, W. and

Shands, D. (2002) Models for coalition-based access

control (CBAC). In Proceedings of the 7th ACM Sym-

posium on Access Control Models and Technologies

(SACMAT’02). 97–106

Ellison, C. and Frantz, B. and Lampson, B. and Rivest, R.

and Thomas, B. and Ylonen, T. (1999) SPKI certiﬁ-

cate theory RFC 2693.

Gomi, H., Hatakeyama, M., Hosono, S., Fujita, S. (2005) A

delegation framework for federated identity manage-

ment. In Proceedings of the ACM Workshop on Digital

Identity Management (DIM’05). 94–103

OASIS (2005) Assertions and protocol for the OASIS

security assertion markup language (SAML) v2.0

http://www.oasis-open.org/committees/tc home.php?

wg abbrev=security.

OAuth Core Workgroup: OAuth core 1.0 revision A

http://oauth.net/.

DATA AND ACCESS MANAGEMENT USING ACCESS TOKENS FOR DELEGATING AUTHORITY TO PERSONS

AND SOFTWARE

463
