THE SPANISH WEB IN NUMBERS

Main Features of the Spanish Hidden Web

Manuel Álvarez, Fidel Cacheda, Rafael López-García and Víctor M. Prieto

Department of Information and Communication Technologies, University of A Coruña,

Facultade de Informática – Campus de Elviña S/N, A Coruña, Spain

Keywords: Information retrieval, Hidden Web, Spanish Web.

Abstract: This article submits a study about the web sites of the “.es” domains which focuses on the level of use of the

technologies that hinder the traversal of the Web to the crawling systems. The study is centred on HTML

scripts and forms, since they are two well-known entry points to the “Hidden Web”. For the case of scripts,

it pays special attention to redirection and dynamic construction of URLs. The article concludes that a

crawler should process those technologies in order to obtain most of the documents of the Web.

1 INTRODUCTION

The “Hidden Web” or “Deep Web” (Bergman,

2000) is the portion of the Web that is not directly

linked. Conventional crawlers cannot treat some of

the technologies that constitute the entry points to

those documents considered “hidden”. On the one

hand, forms are a way to access the server-side

Hidden Web. On the other hand, technologies like

scripting languages or Flash are entry points to the

client-side Hidden Web.

Álvarez et al. (2009) started a high-level study

about the “.es” domains, introducing quantitative

statistics. This article continues that study by

analyzing the content of the first page of each “.es”

domain, in order to determine what Hidden Web

technologies they use. The objective is to conclude if

a crawling engine should deal with these

technologies in order to obtain more documents.

The structure of this article is as follows. Section

2 reviews the related work. Section 3 explains the

architecture of the crawler we have used. Section 4

analyses the results of our experiment. Finally,

Section 5 concludes and explains the future works.

2 RELATED WORK

Most of the studies about the Web only deal with the

Surface Web, but just a few also deal with the

Hidden Web (Chang et al., 2004). There are also

some Web sites that offer statistics about the

indexed content (de Kunder, 2011), the number of

servers (NetCraft, 2011) or the content of the web

pages (BuiltWith, 2011) (Google, 2011). In addition,

some organizations are in charge of both

maintaining the domain names and counting the

machines registered in them. (Internet Systems

Consortium, 2011). Some of them make reports

about the evolution of the domains (Verisign, 2011)

(Red.es, 2011). However, there are not public

reports that analyse the pages of the Spanish sites in

order to determine the technologies they use.

There are also several works that reveal the

difficulties that a crawler has to overcome in order to

retrieve web documents. Scripting languages is an

example, but Weideman and Schwenke (2006) and

Wu and Davidson (2005) stated that crawlers often

do not evaluate them although they are widely used.

3 ARCHITECTURE

Unlike conventional crawlers, the one used in this

research does not follow the links of the web pages,

but uses a list of domains to obtain their state and

their main page. A Crawling Analysis Module

obtains the data of the Álvarez et al. (2009) study. A

Content Analysis Module has been added to

compute and store the features of each web page in

order to simplify the generation of content statistics.

Figure 1 shows the system architecture:

371

Álvarez M., Cacheda F., López-García R. and M. Prieto V..

THE SPANISH WEB IN NUMBERS - Main Features of the Spanish Hidden Web.

DOI: 10.5220/0003626603630366

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 363-366

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Crawler architecture.

Some elements like the “DNS resolver” were

especially tuned to get extra information from DNS

servers. On the other hand, the content analysis

module uses the CyberNeko HTML analyser to treat

every HTML document as an XHTML resource.

4 EXPERIMENTS

According to Álvarez et al. (2009), the Spanish Web

had a total of 1,093,193 domains in May of 2009,

but only 577,442 (52.82%) had a web server. From

here on, we comment the results we obtained from

the analysis of the main page of the “.es” domains

with a web server in terms of including scripting

languages (4.1), web forms (4.2) and other

technologies (4.3).

4.1 Scripts

Scripts are the main entry point to the client-side

Hidden Web. In the case of the Spanish Web, we

have found scripts in 266,737 domains, 46.2% of

those which had a server that did not return an error.

We have also classified them in 542,322 invocations

of external script files in 179,576 domains (31.1%),

744,111 <script> tags in 231,059 domains (40%)

and 2,266,881 occurrences in HTML attributes

inside 147,617 domains (25.6%).

Not all the scripts follow the recommendations

of the RFC 4329 in order to make their language

clear, but most of the scripts we have found follow

the ECMAScript standard. In fact, almost all of them

are written in JavaScript. VBScript have very few

occurrences (1,769) and languages such as TCL

script could not be found in the Spanish Web.

We have also studied which HTML tags contain

the biggest number of <script> tags (including both

embedded scripts and external calls). Scripts should

be placed in the <head> tag or in the beginning of

the <body> tag to ensure visibility, but Table 1

shows that some components that generate markup

can contain <script> tags too.

Table 1: Location of the <script> tags inside other tags.

HTML tag Number of scripts Domains

<head> 530,522 200,713

<div> 260,275 75,619

<body> 228,887 99,361

<td> 116,191 43,992

<p> 31,488 13,941

Table 2 shows the tags that contain the biggest

number of scripts in their attributes.

Table 2: Location of <script> tags inside HTML attributes.

HTML tag Number of scripts Domains

<a> 1,305,831 95,402

<img> 196,419 18,880

<td> 184,657 6,495

<div> 140,825 12,519

<input> 111,013 36,531

Most of the scripts are located in “onXXX”

attributes of <a> links. In many cases, this is done to

dynamically generate the target URL. However, we

have found scripts in many other places such as the

“action” attribute of the forms, etc. We have paid

special attention to the “onLoad” event of the

<body> tag, appearing in 47,064 domains (8.2%).

Regarding the number of scripts per page, Figure

2 shows the distribution:

Figure 2: Use of scripts in the Spanish Web.

We have obtained a power law distribution for

both the embedded scripts and the external

invocations. This means that most of the pages do

not include any scripts, a lot of them include very

few and only some pages include a big number of

them. We have also confirmed that they do not

DNS Resolver

HTTP Fetcher

Internet

DNS

HTTP

Database

JDBC

List of .es domains

State of the domains

JDBC

Crawling Module

Parking domains

Statistics

Crawling Analysis

Module

Web Querying Tool

JDBC

DNS

HTTP

Content Analysis

Module

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

372

follow a Zipf distribution. Figure 2 only shows the

distributions of external scripts and all the scripts,

since the distribution of embedded scripts is very

similar to the latter. Only a small number of sites use

more than 300 scripts, so we can omit a big portion

of the tail of the distribution.

We have also found both sites that invoke the

same scripts many times and sets of sites that invoke

the same scripts. In the latter case, most of the times

the pages of a set of sites have the same content (so

they represent replicate content).

Furthermore, we have studied which script files

are the most invoked. We have concluded that there

is a group of 63 JavaScript files whose names appear

more than 1000 times. Table 3 shows the top ten

positions of that group with the number of

occurrences and the number of domains:

Table 3: Script files that are invoked more times.

File name Calls Domains

show_ads.js 36,248 18,443

urchin.js 33,898 32,873

AC_RunActiveContent.js 29,746 28,526

swfobject.js 19,918 18,887

prototype.js 9,029 8,837

mootools.js 8,483 8,032

jquery.js 8,207 7,851

caption.js 5,947 5,916

scriptaculous.js 5,172 5,028

funciones.js 4,578 4,419

We have also tried to group those libraries by

functionality and to count the number of domains

that use libraries of each functionality. Table 4

shows the results:

Table 4: Functionality of the most common scripts.

Functionality Domains Calls

Management of Flash and

active content

51,895 59,713

Visit count and generation of

statistics

39,354 41,777

Content dynamization with

AJAX

28,819 41,767

Content rendering and image

treatment

22,185 24,598

Menu generation 4,714 5,198

Data treatment and validation 4,376 6,586

We have concluded that, although there are a lot

of libraries on the Web, we can group them in a

small number of functionalities (generation of

statistics, AJAX, Flash, image treatment, etc.).

An interesting feature of the use of scripts is how

they are used to create URLs dynamically. One of

the cases that crawlers hardly ever manage well is

when URLs have parameters whose values are

injected with JavaScript, like in the following code:

location.href =

“http://www.tienda.es/prod?id=”+id;

In many cases, crawlers will believe that the

inner expression showed below is an URL:

“http://www.tienda.es/prod?id=” + id

Or if they perform a tokenization, it could be:

http://www.tienda.es/prod?id=

Actually, the result of the tokenization is an

URL, but as the product identifier is missing, it

probably will not lead the crawler to the expected

resource. The problem here is that we cannot guess

the best values for the parameters unless we interpret

JavaScript, but other techniques could be researched.

Table 5 shows the number of URLs we found in

typical redirection sentences, as well as the number

of simple “potential” URLs that have parameters

injected by means of JavaScript as in the previous

example. Moreover, it also shows how many of

them are considered “well formed” by the algorithm

of the OpenSource crawler Nutch, which uses, first,

regular expressions to detect potential URLs and,

then, a filter to discard not valid ones.

Table 5: Finding complete and potential URLs.

Name Number Pass Nutch filter %

Complete URLs 41,716 41,590 99.7

Potential URLs 8,709 8,581 98.5

As it is shown in Table 5, we have found 8,709

potential URLs that could be completed with some

extra processing. However, conventional crawlers

would treat them as valid URLs although they

actually point to error pages or uninteresting pages.

4.2 Web Forms

Forms are the main entry point to the server-side

Hidden Web, so we need to study them thoroughly.

We have found 188,712 forms in 124,865 domains

(21.6%) following a power law distribution. 122,417

of them (64.9%) make their request by POST and

48,443 (25.7%) use GET for that purpose. Also,

17,779 forms (14.2%) do not specify a method, so

the default value for them is GET too.

Table 6 shows the use of password fields in

forms. The percentages are relative to the number of

pages with forms. These fields are often associated

to authentication, register or password change tasks.

THE SPANISH WEB IN NUMBERS - Main Features of the Spanish Hidden Web

373

Table 6: Use of password fields.

Password fields Forms Domains %

1 (authentication) 26,918 25,832 20.7%

2 (register) 251 239 0.2%

3 (password change) 33 33 <0.1%

We have also found 5,346 forms with only one

text field in 4,861 domains (3.9%). They are

typically used for doing simple searches. Regarding

more complex searches, 34,006 forms in 31,288

domains (25%) are made of several text fields and

buttons, and 126,095 forms in 91,235 domains

(73%) contain at least two elements of the following

categories: <input>, <select> and <textarea>.

4.3 Other Technologies

Some tags like <meta> can contain interesting

information for crawlers. Table 7 shows some of the

purposes for which they were used:

Table 7: Use of <meta> tags.

Functionality Domains %

Refresh or redirection 22,064 3.8%

Refresh (no redirection URL) 1,346 0.2%

Robot Excusion Standard 128,288 22.2%

Keywords 246,752 42.8%

Sending cookies 26 <0.1%

Although stating the keywords and Robot

Exclusion Standard (Koster, 1994) are the most

popular purposes, many search engines do not take

the first one into account since Gyöngyi and Garcia-

Molina (2005) explained how they could be used to

do boosting (an unfair rise of the score of the page).

Flash applications are another difficulty that

crawlers have to overcome. We have found <object>

tags in 89,911 domains (15.6%). 25.060 of them

(4.3%) did not have <a> links, so most of them were

100% Flash sites.

5 CONCLUSIONS

This article has shown the main results of an

analysis of the “.es” websites in 2009. Particularly,

15.6% of the domains had <object> tags, 21.6% had

forms and 46.2% contained scripts, most of them

written in JavaScript. Other scripting languages are

rarely used, so only the effort of processing

JavaScript would be justified in order to retrieve

more pages from the Web.

The future work would consist in making new

crawlings of the Spanish Web in order to supervise

the evolution of the documents and the technologies.

ACKNOWLEDGEMENTS

This research work has been financed by Ministerio

de Educación y Ciencia of Spain and the FEDER

funds of the European Union (Project TIN2009-

14203) and the list of “.es” domains that was

employed in the crawling is courtesy of Red.es.

REFERENCES

Álvarez, M., Cacheda, F., Pan, A., 2009. Análisis

Macroscópico de los Dominios .es. In JITEL’09, VIII

Jornadas de Ingeniería Telemática.

Bergman, M., 2000. The Deep Web. Surfacing Hidden

Value. In Technical Report, BrightPlanet LLC.

BuiltWith Trends. 2011. BuiltWith Technology Usage

Statistics. In http://trends.builtwith.com/

Chang, K. C.-C., He, B., Patel, M., Li, C., Zhang, Z.,

2004. Structured Databases on the Web: Observations

and Implications. In SIGMOD Record, vol. 33, no. 3.

De Kunder, M. 2011. The size of the World Wide Web. In

http://www.worldwidewebsize.com/

Google. 2011. Web Authoring Statistics. In

http://code.google.com/intl/es-MX/webstats/index.html

Gyöngyi, Z., Garcia-Molina, H., 2005. Web Spam

Taxonomy. In AIRWeb’05, Proceedings of the First

International Workshop on Adversarial Information

Retrieval on the Web.

Internet Systems Consortium. 2011. The ISC Domain

Survey. In http://www.isc.org/solutions/survey

Koster, M. 1994. A Standard for Robot Exclusion. In

http://www.robotstxt.org/orig.html

Netcraft. 2011. March 2011 Web Servers Survey. In

http://news.netcraft.com/archives/category/web-server

-survey/

Red.es. 2011. In http://www.red.es

VeriSign. 2011. Internet Profiling Service Statistics. In

http://www.nic.at/en/uebernic/statistics/ips_statistics_i

nformations/

Weideman, M., Schwenke, F. 2006. The influence that

JavaScript™ has on the visibility of a Website to

search engines - a pilot study. In Information

Research, vol. 11, no. 4.

Wu, B., Davison., B.D. 2005. Cloaking and Redirection: A

Preliminary Study. In AIRWeb ’05, Proceedings of

First International Workshop on Adversarial

Information Retrieval on the Web.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

374
