A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED

CONNECTIVITY

Natalia Vanetik

Deutsche Telecom Laboratories and CS department, Ben Gurion University, Beer Sheva, Israel

Keywords:

Mining graphs, Graph connectivity.

Abstract:

Many real-life data sets, such as social and biological networks and biochemical data, are naturally and easily

modeled as large labeled graphs. Finding patterns of interest in these graphs is an important task, due to

the nature of the data not all of the patterns need to be taken into account. Intuitively, if a pattern has high

connectivity, it implies that there is a strong connection between data items. In this paper, we present a novel

algorithm for ﬁnding frequent graph patterns with prescribed connectivity in large single-graph data sets.

We employ the Dinitz-Karzanov-Lomonosov cactus minimum cut structure of a graph to perform the task

efﬁciently. We also prove that the suggested algorithm generates no more candidate graphs than any other

algorithm whose graph extension procedure we use at the ﬁrst step.

1 INTRODUCTION

Representing large complex naturally occurring data

structures as labeled graphs has gained popularity in

the last decade due to the simplicity of the translation

process and because such a representation is intuitive

to users. The graph is now a standard format for rep-

resenting social and biological networks, biochemi-

cal and genetic data, and Web and document struc-

ture. Frequent subgraphs that represent substructures

of the dataset, which are characteristic to that dataset,

are considered important and useful indicator of the

nature of the dataset. Frequent subgraphs are used to

build indices for graph datasets (Zhang,Li,Yang2009)

that improve search efﬁciency, to facilitate classiﬁ-

cation or clustering for machine learning tasks (See-

land,Girschick,Buchwald,Kramer 2010), and to de-

termine normal and abnormal structures within the

data (Horv´ath,Ramon 2010).

Not all of the frequent subgraphs are usually of

interest to the user performing a speciﬁc search task,

both because of the subgraph meaning in the particu-

lar database and because of the high complexity of the

graph mining problem. This obstacle becomes espe-

cially disturbing when the dataset in question is rep-

resented by a single very large labeled graph, such

as a Web or a DNA sequence. In this paper, we

concentrate on the problem of ﬁnding frequent sub-

graphs that satisfy a user-deﬁned constraint of mini-

mum edge connectivity, that determines how many e-

dges should be removed from a graph in order to

separate it into two parts. A minimal edge connectiv-

ity requirement allows us to discard frequent graphs

that do not characterize strong relations between

data items in the native dataset. Moreover, the edge

connectivity of a graph can be veriﬁed fairly easily

(in polynomial time and space), unlike some of the

other constraints, such as symmetry, maximum clique

size etc.

While there is a number of algorithms for the

task of general frequent subgraph mining exist

(see, for instance (Kuramochi,Karypis 2001)), the

issue of ﬁnding frequent graphs that are subject to

connectivity constraints has rarely been addressed in

the literature. In (Yan,Zhou,Han 2005), the authors

address the issue of mining all closed frequent graphs

with predeﬁned edge connectivity and propose two

algorithms that handle this problem. The algorithms

do not address the issue of frequent patterns that have

high connectivity but are not closed.

The authors of (Papadopou-

los,Lyritsis,Manolopoulos 2008) have proposed

the ‘CODENSE’ algorithm that ﬁnds coherent dense

subgraphs – all edges in a coherent subgraph exhibit

correlated occurrences in the whole graph set; these

graphs naturally have high connectivity.

In this paper, we propose a novel graph mining

algorithm that ﬁnds frequent subgraphs with a

user-speciﬁed constraint on edge connectivity. Our

algorithm uses the minimum cut structure of a graph

Vanetik N..

A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED CONNECTIVITY.

DOI: 10.5220/0003628300050013

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 5-13

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

in order to perform the task efﬁciently; this structure

can be computed in low polynomial time (even linear,

if one uses the randomized algorithm of (Karger, Pan-

igrahi 2009)), which makes our algorithm especially

suitable for databases consisting of a single large

graph. The mincut structure of a graph also allows

us to increase frequent patterns by more than just a

node or an edge at a time than the standard approach.

We also prove the optimality of this algorithm by

showing that every frequent subgraph produced by

our algorithm (even if it is only used as a building

block for a supergraph satisfying edge connectivity

constraints) has to be produced by a competing

algorithm.

This paper is organized as follows. Section 2 con-

tains the basic deﬁnitions and graph theoretic facts

required for our approach. Section 3 describes the

algorithm and contains proofs of the algorithm’s cor-

rectness. Section 4 contains the proof of algorithm’s

optimality.

2 STATEMENT OF THE

PROBLEM

2.1 Basic Deﬁnitions

In this paper, we deal with undirected labeled graphs.

In a graph G = (V, E), V denotes the node set, E ⊆

V ×V denotes the edge set, and each node v ∈ V has a

label l(v). A graph G

′

= (V

′

) is called a subgraph

of G, denoted by G

′

⊆ G, if V

′

⊆ V, E

′

⊆ E and ev-

ery edge in E

′

has both ends in V

′

. G

′

is an induced

subgraph of G if it is a subgraph of G and for every

pair of nodes v,u ∈ V

′

such that (u,v) is an edge of G,

(u,v) is also an edge of G

′

A graph G = (V, E) is disconnected if there exists

a partitionV

ofV so that no edge in E has one end

in V

and another in V

. If no such partition exists,

G is called connected. G is called k-edge-connected,

k ∈ N, if G is connected and one has to remove at least

k edges from E to make G disconnected.

A partition of edge set E into X ⊂ E and X :=

E \ X is called a cut. Removing all edges having one

end in X and another in X (called (X, X)-edges) from

G disconnects the graph. The size of a cut (X,X) is

the number of (X,X)-edges, denoted |(X,X)|. The

(X,X)-edges whose removal disconnects the graph

are often also called a cut. A cut of minimum size

is called a minimum cut or a mincut. The smallest

size of a cut in a graph is the edge connectivity of a

graph. In general, for two foreign subsets X,Y ⊂ V

we denote by |(X,Y)| the number of edges in G with

one end in X and another in Y.

We study the problem of graph mining in the fol-

lowing setting: our database is a single large undi-

rected labeled graph G. We are given a user-supplied

support threshold S ∈ N and a connectivity constraint

k and we are looking for all k-edge-connected sub-

graphs of G with a count of at least S (these sub-

graphs are called frequent). The count of a graph

in a database is determined by a function count()

that satisﬁes the downward closure property: for all

subgraphs g

of any database graph D such that

⊆ g

we always have count(g

,D) ≥ count(g

,D).

The main idea of our approach is to employ the spe-

cial structure of mincuts in the database graph in or-

der to make the search for frequent k-edge-connected

subgraphs faster.

2.2 The Cactus Structure of Mincuts

An unweighted undirected multigraph is called a cac-

tus if each edge is contained in exactly one cycle

(i.e., any pair of cycles has at most one node in com-

mon). Dinitz, Karzanov and Lomonosov showed in

(Dinits,Karzanov,Lomonosov1976) that all minimum

cuts in a given graph with n vertices can be repre-

sented as a cactus of size 0(n). This cactus represen-

tation plays an important role in solving many con-

nectivity problems, and we use it here for the efﬁcient

mining of graphs with connectivity constraints.

Formally, let G = (V,E) be an undirected multi-

graph and let {V

,...,V

} be a partition of V. We de-

note the set of all minimum cuts of G by Cuts(G) .

Let R = (V

) be a multigraph with node set V

,...,V

} and edge set E

:= {(V

) | (v

) ∈

E, v

∈ V

Deﬁnition 1. R is a cactus representation of Cuts(G)

if there exists a one-to-one correspondence ρ :

Cuts(G) → Cuts(R) such that for every mincut

(X,X) ∈ Cuts(G) ρ((X,X)) ∈ Cuts(R) and for every

mincut (X, X) ∈ Cuts(R) ρ

−1

((X,X)) ∈ Cuts(G).

Dinitz, Karzanov and Lomonosov

(Dinits,Karzanov,Lomonosov 1976) have proved

that for any undirected multigraph, there exists a

cactus representation (in fact, they showed that this

is always true for any weighted multigraph). A dual

graph to any cactus representation, if the cactus

cycles are taken as nodes, is a tree. The size of a

cactus tree is linear in the number of vertices in the

original graph, and any cut can be retrieved from the

cactus representation in time linearly proportional to

the size of the cut. In addition, the cactus displays

explicitly all nesting and intersection relations among

minimum cuts. Note that a graph can have at most





mincuts, where n is the size of graph’s node

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

set. The following deﬁnition and a fundamental

lemma entirely describe the structure of a cactus

representation.

Deﬁnition 2. Let λ be the size of a mincut in graph

G = (V,E). A circular partition is a partition of V

into k ≥ 3 disjoint subsets {V

,...,V

} such that

1. |(V

)| = λ/2 when j − i = 1 mod k.

2. |(V

)| = 0 when j − i 6= 1 mod k.

3. For 1 ≤ a < b ≤ k, ∪

b−1

i=a

is a mincut. Moreover,

if any mincut (X, X) is not of this form, then either

X or X is contained in some V

Lemma 1. (Dinits,Karzanov,Lomonosov1976; Bixby

1974) If X

and X

are crossing cuts in G (have a

non-trivial intersection as sets), then G has a circu-

lar partition {V

,...,V

} such that each of X

∩ X

∪ X

, X

\ X

and X

\ X

equal ∪

b−1

i=a

for appro-

priate choices of a and b.

Corollary 1. (Dinits,Karzanov,Lomonosov1976) Ev-

ery graph has a cactus representation.

Corollary 2. (Fleischer 1998) Every graph on n ver-

tices has a cactus representation with no more than

2n− 2 vertices.

Figure 1 shows a 2-edge-connected multigraph

and its cactus representing all three mincuts that exist

in the graph. In this example, there is a one-to-one

correspondence between the cycles of the cactus and

the circular partitions of G.

2.3 Cactus Construction Algorithms

The earliest well-deﬁned algorithm for ﬁnding all

minimum cuts in a graph uses maximum ﬂows

to compute mincuts for all pairs of vertices (see

(Gomory,Hu 1991)). Karzanov and Timofeev

(Karzanov,Timofeev 1986) outlined the ﬁrst algo-

rithm to build a cactus for an unweighted graph. A

randomized algorithm by Karger (Karger,Stein 1996)

ﬁnds all minimum cuts in O(n

logn) time. Fleis-

cher in (Fleischer 1998) describes an algorithm that

arranges the minimum cuts into an order suitable for

a cactus algorithm which runs in O(nm + n

logn)

time. Finally, Karger and Panigrahi proposed a near-

linear time randomized algorithm in (Karger, Pani-

grahi 2009).

3 FINDING FREQUENT

K-CONNECTED GRAPHS

In this section, we present the CactusMining algo-

rithm for ﬁnding all frequent k-connected graphs in

a graph database. For simplicity, we assume here that

the database is a single large graph; when a database

consists of two or more disconnected graphs, graph

decomposition and support counting should be per-

formed once for each transaction. The CactusMining

algorithm searches for all frequent k-connected sub-

graphs in a bottom-up fashion and relies on the search

space reduction that is implied by the cactus structure

of the database.

3.1 Computing the Cactus Structure of

a Graph

To compute the cactus structure for a given graph

G and a connectivity bound k, we employ a cactus-

constructing algorithm, denoted as BuildCactus()

(for instance, the one described in (Fleischer 1998)).

3.2 Basic Properties

In this section, we describe several useful properties

of a cactus mincut structure.

Property 1. Let g be a (k+1)-connected subgraph of

G. Then g is entirely contained in some V

, 1 ≤ i ≤ k.

The converse is not true, i.e. non-k-edge-connected

subgraphs of V

may exist.

Property 2. Let g be a k-edge-connected subgraph

of G. Let C be a minimal subcactus of G with circu-

lar partition {V

,...,V

} containing g as a subgraph.

Then either g contains all the (V

)-edges or it con-

tains no such edges.

Proof. This property is trivial since removing a

)-edge decreases the edge connectivity of a sub-

cactus C containing g.

Corollary 3. In Property 2, subgraph g∩V

contains

all the nodes incident to the (V

)-edges of a circu-

lar partition.

Proof. Follows from the fact that g contains all

)-edges.

3.3 Growing Subgraphs

In this section, we describe how an instance of a can-

didate subgraph can be grown from an existing fre-

quent subgraph instance without violating connectiv-

ity constraints.

The intuition behind our subgraph extension ap-

proach relies on properties of its location within the

cactus structure. Let T = (V

) be a dual cactus

structure of (k + 1)-cuts in database D with nodes

being the cactus cycles and the adjacency rela-

tion E

determining whether two cactus cycles share

A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED CONNECTIVITY

a mincut

(a) Graph G with mincut size = 2 (b) A corresponding cactus structure of G.

Figure 1: A cactus structure of a graph.

a node. Each cactus cycle C ∈ V

is a graph, denoted

by C = (V

), with the structure of a simple cycle.

In C, the nodes of V

are the basic (k + 1)-connected

components of D, i.e. the components that contain no

edge of a k-cut in D. Two such componentsc

∈V

are adjacent if there exist edges of D that belong to a

k-cut and are incident to nodes in c

and c

(there are

precisely ⌈

⌉ such edges). To simplify the notation,

we say that (c

) denotes the set of these edges.

Our goal is to extend instances of frequent graphs

gradually, while complying with the following rule:

• do not produce an extension whose cactus struc-

ture in C does not ensure k-connectivity.

In order to achieve the objective, our extension pro-

cedure depends strongly of the location of an instance

within the database cactus structure. Moreover, our

approach allows to extend an instance by more than

one node.

Let f ⊂ D be a frequent subgraph instance that we

are currently extending. We introduce several addi-

tional parameters of f that are updated by our mining

algorithm:

1. f.type can assume the values node, cycle and

tree,

2. f.cycle denotes the node t ∈ V

containing f as a

subgraph (if one exists),

3. f.tree denotes the subtree of T containing f as a

subgraph; | f.tree| denotes the number of nodes in

the said subtree.

For each value of f.type, we propose a separate exten-

sion procedure. The ﬁrst two procedures extend the

subgraph instance within its own type; they can fail

to extend either because no extension is possible at all

or because the type of extension needs to be changed.

For f.type = cycle and f.type = tree, additional pre-

caution needs to be taken in order to ensure a better

search space reduction. In this case, a subgraph of

such an instance contained within a (k+ 1)-connected

Algorithm 1: Contraction().

Input: subgraph g,

subcactus T containing g.

Output: contraction of g

1: K := a node of T containing g;

2: for all subtrees t ∈ T incident to K do

3: replace t \ {g, cycle edges incident to g}

with a single node;

4: end for

5: return T;

component of the database graph may cause a cut of

size less than k to appear in the extended instance. We

apply the Contraction() procedure (see Section 3.3.1)

that determines exactly if these subgraphs produce a

smaller than required edge cut or not.

3.3.1 The Contraction Procedure

The Contraction() procedure, described in Algorithm

1, receives as an input a subgraph g contained in a

(k + 1)-connectivity component of a cactus structure

T, and contracts all the parts of T that are not adjacent

or incident to g into single nodes. For each subtree

t ∈ T adjacent to g, t \ g is turned into a single node.

In fact, every such subtree is turned into a two-node

cycle with t and t \ g as nodes, and the cycle edges

incident to g as edges.

Figure 2 gives two examples of applying the Con-

traction() procedure.

The following claim ensures correctness of the

procedure.

Claim 1. Let T = (V

) be a cactus structure of

k-cuts in a graph G and let a subgraph f ⊂ G span

the (k+ 1)-connectivity components of T and contain

all the cycle edges of the cactus structure. Then there

exists a (k + 1)-connectivity component K of G such

that Contraction( f ∩ K,T) is not k-connected if and

only if f is not k-connected.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

T is a treeT is a single cycle

cycle edges

a contracted node

Figure 2: Contracting subgraphs in (k +1)-connected components.

Proof. The “only if” direction is trivial since the con-

traction described in Algorithm 1 does not reduce the

connectivity of f.

For the “if” direction, let us assume an f that is

not k-connected. Then there exists a partition V

of its node set so that |(V

)| < k. Since the number

m of cactus components C

,...,C

in T is at least 2,

there exists i ∈ [1,m] s.t. |(V

) ∩C

. Thus, we

have a partition U

of a node set of f ∩C

so that

|(U

)| <

Let us denote by f

′

:=Contraction(f ∩ C

,T).

Since there are at most k cactus edges incident to

f ∩C

, w.l.o.g. there are at most

cactus edges in-

cident to U

in f

′

, which we denote by E

′

. Then

) ∪ E

′

is an edge cut of f

′

of size less than k,

and f

′

is not k-connected.

3.3.2 Extension Procedures

The procedure for f.type = node is described in Al-

gorithm 2. This procedure simply adds a node or an

edge to an existing subgraph instance within a (k+1)-

connectivity component of D. It uses a basic pre-

existing extension procedure basic-extend(), for in-

stance such as the one in FSG (Kuramochi,Karypis

2001). An example of ExtendNodeType() procedure

is given in Figure 3 (extended subgraphs in bold).

The procedure for f.type = cycle is described in

Algorithm 3. It extends an instance f of a frequent

graph within a single cycle C = (V

) that forms a

node of the cactus dual tree structure. The main con-

cern is to extend a subgraph so as not to create a not-

k-connected instance, and for this purpose the edges

must be present in an extension. Therefore, a fre-

quent graph instance that is a subgraph of V

must be

added to f. An example of joining subgraphs of type

node into subgraphs of type cycle is given in Figure 4

(extended subgraphs in bold).

Algorithm 2: ExtendNodeType().

Input: Cactus T = (V

) of (k+ 1)-cuts in D,

frequent subgraph f.

Output: extensions of f.

1: Ext( f) :=basic-extend(g);

2: for all h ∈ Ext( f) do

3: if h∩ f.cycle 6= f.cycle then

4: Ext( f) := Ext( f) \ {h};

5: else

6: h.type = node;

7: h.cycle = f.cycle;

8: end if

9: end for

10: return Ext( f);

The ﬁnal procedure for f.type = tree is described

in Algorithm 4. In this case, f is contained in a sub-

tree of the dual cactus tree structure and it is extended

by an instance of a frequent subgraph of type cycle.

In order not to generate the same instance twice, we

assume that the tree T is a directed out-tree and that

extending a subtree of T by a node is possible only in

the direction of T’s edges. An example of joining two

subgraphs of type cycle into a subgraph of type tree

is given in Figure 5 (extended subgraphs in bold).

3.4 The CactusMining Algorithm

The CactusMining algorithm extends each frequent

graph until it spans beyond connectivity component

of the database, at which point the extension must in-

clude a non-trivial subcactus. If such an extension

is not possible, the frequent subgraph must be aban-

doned. The existence of a counting procedure for sub-

graphs, denoted count(), is assumed.

A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED CONNECTIVITY

step 1 step 2

step 3 step 4

Figure 3: Extending frequent subgraphs of type node.

Algorithm 3: ExtendCycleType().

Input: frequent subgraph instances F of type node,

frequent subgraph f.

Output: extensions of f.

1: let C = ({c

,...,c

},E

) := f.cycle;

2: let f ⊆ c

;

3: Ext( f) :=

4: E =: ∪

i, j

{(c

) ∈ E

} (as edge sets);

5: F

good

:= F ∩C; {frequent subgraphs in C}

6: for all f ∈ F

good

7: f

′

:= Contraction(f,C);

8: if f

′

is not k-connected then

9: F

good

:= F

good

\ { f

′

};

10: end if

11: end for

12: for all f

∈ F

good

∩ c

, 1 ≤ i ≤ n, i 6= j do

13: h := ∪

1≤i≤n, i6= j

∪ E;

14: if h is a graph then

15: Ext( f) := Ext( f) ∪ {h};

16: h.type = cycle; h.cycle = f.cycle;

17: h.tree = h.cycle;

18: end if

19: end for

20: return Ext( f);

Algorithm 4: ExtendTreeType().

Input: database cactus structure T = (V

frequent subgraph instances F of type cycle,

frequent subgraph f.

Output: extensions of f.

1: T

′

= (V

′

) := f.tree;

2: Ext( f) :=

3: for all C ∈ V

and C

′

∈ V

′

) do

4: if (C

′

,C) ∈ E

then

5: for all g ∈ F such that g∩C = f ∩C do

6: T

′′

:= T

′

∪C;

7: g

′

:= Contraction(g ∩C,T

′′

);

8: if g

′

is k-connected then

9: h := f ∪ g;

10: Ext( f) := Ext( f) ∪ {h};

11: h.type = tree;

12: h.tree = (V

′

∪ {C},E

′

∪ {(C

′

,C)});

13: end if

14: end for

15: end if

16: end for

17: return Ext( f);

(b)

joining and

into a subgraph of

(a) frequent subgraphs

of type

type

node

cycle cycle

Figure 4: Constructing frequent subgraphs of type cycle.

3.5 Proof of Correctness

The aim of this section is to show that every maximal

frequent k-edge-connected subgraph g of G is gener-

ated by the above algorithm at some point (complete-

ness), and no subgraph that is not k-edge-connected is

added to a candidate set (soundness).

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

of type=cycle.

(b) subgraph (a) subgraph

(a) subgraph

of type=cycle.

from join of and .

of type=tree resulting

Figure 5: Constructing a frequent subgraph of type tree.

Claim 2. The CactusMining algorithm is sound.

Proof. This claim is trivial since step 39 of Algorithm

5 ﬁlters out all not-k-connected graphs.

Claim 3. The CactusMining algorithm is complete.

Proof. Let G be a frequent k-connected subgraph of

D, where D has the k-connectivity cactus structure

T. Then every instance of G is contained in a k-

connectivity component of D. Let us assume that

G is not generated by the Algorithm 5 and let G be

minimal in the number of nodes and vertices. We

show that every instance g of G is generated by one of

the procedures ExtendNodeType, ExtendCycleType()

or ExtendTreeType(). If g.type = node, it is gener-

ated by the ExtendNodeType() procedure that ﬁlters

out nothing. Otherwise, g.type ∈ {cycle,tree} and by

Claim 1 g is not generated only if g is not-k-connected

- a contradiction.

4 CANDIDATE GRAPHS

GENERATED BY THE

ALGORITHM

In this section, we prove that the CactusMining algo-

rithm is optimal w.r.t. the set of candidate subgraphs

generated by it. We show that any algorithm based on

pattern extension must produce a superset of candi-

date subgraphs generated by the CactusMining algo-

rithm.

Theorem 1. Let AnyAlgorithm be a graph mining al-

gorithm based on pattern extension. Then Cactus-

Mining algorithm produces no more candidates than

AnyAlgorithm.

Proof. We show that any frequent candidate sub-

graph g produced by the CactusMining algorithm has

to be produced by AnyAlgorithm. We denote the

database graph by D and its cactus tree structure by

T = (V

). We denote the (k + 1)-connectivity of

the cactus structure by C

,...,C

. Let us assume that

g is produced by the CactusMining algorithm but not

by AnyAlgorithm as a candidate subgraph.

If g ⊆ g

′

, where g

′

is a k-connected frequent graph

in D, then g is produced by AnyAlgorithm (we can

assign labels to g

′

’s nodes so that g is the lexico-

graphically minimal extension of g) – a contradic-

tion. Therefore, g is neither k-connected nor is it

a subgraph of a frequent k-connected graph in D.

Let therefore V

be a partition of g’s nodes so

that |(V

)| < k (i.e. an edge cut of size < k sep-

arates V

and V

). We assume ﬁrst that g has a

non-empty intersection with cactus nodes C

,...,C

where m > 1. Then g contains all the cactus edges

connectingC

,...,C

, for otherwise it is not produced

by the CactusMining algorithm (as g.type = cycle or

g.type = node). We denote the edge set (V

) sep-

arating g by E

1,2

. Since m > 1 and |E

1,2

| < k, there

exists i s.t. |C

∩ E

1,2

| <

. Thus, we have a partition

of a node set of g ∩C

so that |(U

)| <

Let g

′

:=Contraction(g,C

). Since there are at most

k cactus edges incident to g ∩C

, w.l.o.g. there are at

most

cactus edges incident to U

in g

′

, which we

denote E

′

. Then E

1,2

∪ E

′

is an edge cut of g

′

of size

less than k – in contradiction to step 8 of Algorithm 3

or to step 8 of Algorithm 4. Then g is not produced

by the CactusMining algorithm – a contradiction.

Let us assume now that g ⊆ C

for some i ∈ [1, m].

Since g is minimal in the node and edge set, there

exists a node or an edge x such that g − x is either a

k-connected frequent graph in D or is a subset of a

k-connected frequent graph g

′

in D. We can assume

that AnyAlgorithm is locally optimal, and, since Al-

gorithm 2 can use any function as basic-extend(), that

the same function is used. Therefore, g is produced by

both AnyAlgorithm and the CactusMining algorithm

– a contradiction.

A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED CONNECTIVITY

Algorithm 5: CactusMining().

Input: graph database D, support S,

connectivity bound k.

Output: frequent k-edge-connected graphs.

1: F

:= frequent nodes of D;

2: D := D\ {non-frequent nodes};

3: BuildCactus(D,k− 1);

4: D ← k-connectivity components of D;

5: T := BuildCactus(D, k);

6: F

:= frequent nodes; {

type=node

}

7: i := 1;

8: while F

0 do

9: C

i+1

10: for all f ∈ F

11: C

i+1

:= C

i+1

∪ ExtendNodeType(T, f);

12: end for

13: i := i+ 1;

14: F

:= frequent graphs from C

;

15: end while

16: F

:= ∪

i−1

j=1

;

17: F

:= F

; {

type=cycle

}

18: i := 1;

Algorithm 6: CactusMining() contd.

19: while F

0 do

20: C

i+1

21: for all f ∈ F

22: C

i+1

:= C

i+1

∪ ExtendCycleType(F

, f);

23: end for

24: i := i+ 1;

25: F

:= frequent graphs from C

;

26: end while

27: F

:= ∪

i−1

j=1

;

28: F

:= F

; {

type=tree

}

29: i := 1;

30: while F

0 do

31: C

i+1

32: for all f ∈ F

33: C

i+1

:= C

i+1

∪ ExtendTreeType(T,F

, f);

34: end for

35: i := i+ 1;

36: F

:= frequent graphs from C

;

37: end while

38: F

III

:= ∪

i−1

j=1

;

39: remove < k-connected graphs from F

∪ F

III

;

40: return F

∪ F

III

5 CONCLUSIONS

In this paper, we have presented the CactusMin-

ing algorithm for mining frequent k-edge connected

subgraphs in a graph database, where k is a user-

deﬁned integer constant. The method presented

here is deﬁned and described for a single graph

database case, but is adapted trivially to multiple

graph databases. Our method relies on the Dinitz-

Karzanov-Lomonosov cactus minimum cut structure

theory and on the existence of efﬁcient polynomial

algorithms that compute this structure. Our algorithm

employs the pattern-growth approach, and the cactus

structure of mincuts allows us to grow frequent sub-

graphs by more than a node or an edge at a time. We

haveprovedthat the CactusMining algorithm is sound

and correct, and have also shown that the set of fre-

quent patterns it produces is the least possible, i.e. a

competing graph mining algorithm will produce all

the candidate patterns that our algorithm produces.

ACKNOWLEDGEMENTS

The author thanks the Lynn and William Fraenkel

Center for Computer Science for partially supporting

this work.

REFERENCES

Bixby, R. E. ”The minimum number of edges and vertices

in a graph with edge connectivity n and m n-bonds”,

Networks, 5:253-298, 1975.

Dinits, E. A., Karzanov, A. V., Lomonosov, M. V. ”On the

structure of a family of minimal weighted cuts in a

graph”, Studies in Discrete Optimization (in Russian)

(ed. A.A. Fridman), Nauka, Moscow, 1976, 290-306.

Fleischer, L. ”Building Chain and Cactus Representations

of All Minimum Cuts from Hao-Orlin in the Same

Asymptotic Run Time”, IPCO 1998: 294-309.

Gomory, R. E., Hu, T. C. ”Multi-terminal network ﬂows”,

J. Soc. Indust. Appl. Math, 9(4):551-570, 1991.

Horv´ath, T. and Ramon, J. ”Efﬁcient frequent connected

subgraph mining in graphs of bounded tree-width”,

Theor. Comput. Sci. 411(31-33): 2784-2797, 2010.

Karger, D. R. and Stein, C. ”A new approach to the min-

imum cut problem”, Journal of the ACM, 43(4):601-

640, 1996.

Karger, D. R. and Panigrahi, D. ”A near-linear time algo-

rithm for constructing a cactus representation of min-

imum cuts”, SODA 2009, 246-255.

Karzanov, A. V. and Timofeev, E. A. ”Efﬁcient algorithms

for ﬁnding all minimal edge cuts of a nonoriented

graph”, Cybernetics, 22:156-162, 1986. Translated

from Kibernetika 2 (1986) 8-12.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

Kuramochi, M. and Karypis, G. ”Frequent Subgraph Dis-

covery”, ICDM 2001: 313-320.

Papadopoulos, A., Lyritsis, A. and Manolopoulos, Y. ”Sky-

graph: an algorithm for important subgraph discov-

ery in relational graphs”, Data Mining and Knowledge

Discovery, 17(1), 2008.

Seeland, M., Girschick, T., Buchwald, F. and Kramer, S.

”Online Structural Graph Clustering Using Frequent

Subgraph Mining”, ECML/PKDD (3) 2010: 213-228.

Yan, X., Zhou, X. J., and Han, J. ”Mining Closed Relational

Graphs with Connectivity Constraints”, ICDE 2005:

357-358.

Zhang, S., Li, S. and Yang, J. ”GADDI: distance in-

dex based subgraph matching in biological networks”,

EDBT 2009: 192-203.

A FAST ALGORITHM FOR MINING GRAPHS OF PRESCRIBED CONNECTIVITY
