CONCEPT DISCOVERY FOR LANGUAGE UNDERSTANDING IN

AN INFORMATION-QUERY DIALOGUE SYSTEM

Nathalie Camelin, Boris Detienne, St

ephane Huet, Dominique Quadri and Fabrice Lef

evre

LIA - University of Avignon, BP 91228, 84911 Avignon Cedex 09, France

Keywords:

Concept discovery, Language understanding, Latent Dirichlet analysis, Dialogue systems.

Abstract:

Most recent efﬁcient statistical approaches for natural language understanding require a segmental annotation

of training data. Such an annotation implies both to determine the concepts in a sentence and to link them

to their corresponding word segments. In this paper we propose a two-steps alternative to the fully manual

annotation of data: an initial unsupervised concept discovery, based on latent Dirichlet allocation, is followed

by an automatic segmentation using integer linear optimisation. The relation between discovered topics and

task-dependent concepts is evaluated on a spoken dialogue task for which a reference annotation is avail-

able. Topics and concepts are shown close enough to achieve a potential reduction of one half of the manual

annotation cost.

1 INTRODUCTION

Generally, information-query spoken dialogue sys-

tems are used to interface a database with users orally.

Once a speech recogniser has transcribed the sig-

nal, the meaning of the user’s queries is extracted

by a Spoken Language Understanding (SLU) module.

The very ﬁrst step of this module is the identiﬁcation

of literal concepts. These concepts are application-

dependent and ﬁne-grained so as to provide efﬁcient

and usable information to the following reasoning

modules (e.g. the dialogue manager). To this re-

spect they can also be composed in a global tree-based

structure to form the overall meaning of the sentence.

To address the issue of concept tagging several

techniques are available. Some of these techniques

now classical rely on probabilistic models, which can

be either discriminant or generative. To obtain good

performance when probabilistic models are used in

such systems, ﬁeld data are to be collected, tran-

scribed and annotated at the semantic level. It is then

possible to train efﬁcient models in a supervised man-

ner. However, the annotation process is costly and

constitutes a real hindrance to a widespread use of the

systems. Therefore any means to avoid it would be

highly appreciable.

It seems out of reach to derive the concept def-

initions from a fully automatic procedure. Anyhow

the process can be bootstrapped, for instance by in-

duction of semantic classes such as in (Siu and Meng,

1999) or (Iosif et al., 2006). Our assumption here is

that the most time-consuming parts of concept inven-

tory and data tagging could be obtained in an unsu-

pervised way, even though a ﬁnal (but hopefully min-

imal) manual procedure is still required to tag the de-

rived classes so as to manually correct the automatic

annotation.

Unlike the previous attempts cited before, which

developed ad-hoc approaches, in the work described

here we investigate the use of broad-spectrum knowl-

edge discovery techniques. In this context the notion

most related to that of concept in SLU seems to be the

topic, as used in information retrieval systems. For a

long time, the topic detection task was limited to the

association of a single topic to a document and thus

did not ﬁt our requirements. The recently proposed

latent Dirichlet allocation (LDA) technique has the

capacity to derive a probabilistic representation of a

document as a mixture of topics. As such LDA can

consider that several topics can co-occur inside a sin-

gle document or sentence and that the same topic can

be repeated.

From these favorable characteristics we consider

the application of LDA to concept discovery for SLU.

Anyhow, LDA does not take into account the sequen-

tiality of the data (due to the exchangeability assump-

tion). It is then necessary to introduce constraints for

a better segmentation of the data: assignment of top-

ics proposed by LDA is modiﬁed to be more coherent

in a segmental way.

Camelin N., Detienne B., Huet S., Quadri D. and Lefevre F..

CONCEPT DISCOVERY FOR LANGUAGE UNDERSTANDING IN AN INFORMATION-QUERY DIALOGUE SYSTEM.

DOI: 10.5220/0003640500240029

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 24-29

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

The paper is organised as follows. Principles of

automatic induction of semantic classes are presented

in Section 2, followed by the presentation of an induc-

tion system based on LDA and the additional step of

segmentation using integer linear programming (ILP).

Then evaluations and results are reported in Section 3

on the French MEDIA dialogue task.

2 AUTOMATIC INDUCTION OF

SEMANTIC CLASSES AND

ANNOTATION

2.1 Context Modelization

The main idea of automatic induction of semantic

classes is based on the assumption that concepts often

share the same context (syntactic or lexical) (Siu and

Meng, 1999), (Pargellis et al., 2001). While there may

be still room for improvement in these techniques we

decided instead to investigate general knowledge dis-

covery approaches in order to evaluate their potential-

ity.

In that purpose a global two-steps strategy is pro-

posed: ﬁrst semantic classes (topics) are induced;

then topics are assigned to words with segmental con-

straints. The major interest of the approach is to sep-

arate the tasks of detecting topics and aligning topics

with words. It is then possible to introduce additional

constraints (such as locality, number and types of seg-

ments, etc) in the second task which would otherwise

hinder topic detection in the ﬁrst place.

Several approaches are available for topic detec-

tion in the context of knowledge discovery and in-

formation retrieval. In this work we were motivated

by the recent development of a very attractive tech-

nique which has interesting distinct features such as

the detection of multiple topics in a single document.

LDA (Blei et al., 2003) is the ﬁrst principled descrip-

tion of a Dirichlet-based model of mixtures of latent

topic variables. It generates a set of topics with prob-

abilities for each topic to be associated with a word

in a sentence. In our case this knowledge is thereafter

used to infer a segmentation of the sentence using in-

teger linear optimisation.

2.2 Implementation of an Automatic

Induction System based on LDA

Basically LDA is a generative probabilistic model

for text documents. LDA follows the assumption

that a set of observations can be explained by la-

tent variables. More speciﬁcally documents are rep-

resented by a mixture of topics (latent variables) and

topics are characterized by distributions over words.

The LDA parameters are {α,β}. α represents the

Dirichlet parameters of K latent topic mixtures as

α = [α

,α

,..., α

]. β is a matrix representing a

multinomial distribution in the form of a conditional

probability table β

k,w

= P(w|k). Based on this repre-

sentation, LDA can estimate the probability of a new

document d of N words d = [w

,..., w

] using the

following procedure.

A topic mixture vector θ is drawn from the Dirich-

let distribution (with parameter α). The correspond-

ing topic sequence κ = [k

,..., k

] is generated for

the whole document accordingly to a multinomial dis-

tribution (with parameter θ). Finally each word is

generated by the word-topic multinomial distribution

(with parameter β, that is p(w

,β)). After this pro-

cedure, the joint probability of θ, κ and d is then:

p(θ,κ,d|α,β) = p(θ|α)

∏

i=1

p(k

|θ)p(w

,β) (1)

To obtain the marginal probability of d, a ﬁnal inte-

gration over θ and a summation over all possible top-

ics considering a word is necessary:

p(d|α,β) =

p(θ|α)

∏

i=1

∑

p(k

|θ)p(w

,β)

(2)

The framework is comparable to that of probabilis-

tic latent semantic analysis, but the topic multinomial

distribution in LDA is assumed to be sampled from

a Dirichlet prior and is not linked to training docu-

ments.

In recent years, several studies have been carried

out in language processing using LDA. For instance,

(Tam and Schultz, 2006) worked on unsupervised lan-

guage model adaptation, (Celikyilmaz et al., 2010)

ranked candidate passages in a question-answering

system and (Phan et al., 2008) implemented LDA to

classify short and sparse web texts.

We chose to use an implementation of LDA,

GIBBSLDA++ tool,

to annotate each user’s utter-

ance of a dialogue corpus with topics. Each utterance

of more than one word is included in the training set

as its sequence of words. Once the models are trained,

inference on data corpus assigns each word in a docu-

ment with the highest probability topic. [LDA] system

executes 2,000 iterations with the default parameters

for α and β.

Notice that single-word utterances are processed

separately using prior knowledge. Names of cities,

month, day or short answers (e.g. “yes”, “no”,

“yeah”) and numbers are parsed in these utterances.

http://gibbslda.sourceforge.net/

CONCEPT DISCOVERY FOR LANGUAGE UNDERSTANDING IN AN INFORMATION-QUERY DIALOGUE

SYSTEM

Indeed, LDA cannot be applied on such utterances

where no co-occurrences can be observed.

2.3 Alignment with Integer Linear

Programming (ILP)

The topic alignment problem we have to solve in this

paper can be considered as a combinatorial optimiza-

tion problem. ILP is a basic method to deal with such

problems.

ILP is a mathematical method for determining

the best way to optimize a given objective. More

speciﬁcally, an integer linear model aims at optimiz-

ing a linear objective function (for instance represent-

ing a cost, a beneﬁt, a probability...) subject to lin-

ear equalities or inequalities (named the constraints).

Both the objective function and the constraints are ex-

pressed using integer unknown variables (called de-

cision variables). The coefﬁcients of the objective

function and the constraints are the input data of the

model. Consequently, solving an ILP consists in as-

signing integer values to decision variables, such that

all constraints are satisﬁed and the objective function

is optimized (maximized or minimized). We report

the interested reader to (Chen et al., 2010) for an in-

troduction on approaches and applications of ILP.

We propose an ILP formulation for solving the

topic alignment problem for one document. The in-

put data are: an ordered set d of words (indexed from

1 to N), a set of K available topics and, for each word

∈ d and topic k = 1...K, the natural logarithm of

the probability p(w

|k) that k is assigned to w

in the

considered document. Model [ILP] determines the

highest-probability assignment of one topic to each

word in the document, such that at most χ

max

differ-

ent topics are assigned.

[ILP] : max

∑

i=1

∑

k=1

p(w

|k)x

(3)

∑

k=1

= 1 i = 1...N (4)

− x

≥ 0 i = 1...N,k = 1...K (5)

∑

k∈κ

≤ χ

max

k = 1...K (6)

∈ {0,1} i = 1...N,k = 1...K

∈ {0,1} k = 1...K

Decision variable x

is equal to 1 if topic k is as-

signed to word w

, and equal to 0 otherwise. Con-

straints (4) ensure that exactly one topic is assigned to

each word. Decision variable y

, is equal to 1 if topic

k is used. Constraints (5) force variable y

to take a

value of 1 if at least one variable x

is not null. More-

over, constraints (6) limit the total number of topics

used. The objective function (3) merely states that we

want to maximize the total probability of the assign-

ment. Through this model, our assignment problem is

identiﬁed as a p-centre problem (see e.g. (ReVelle and

Eiselt, 2005) for a survey on such location problems).

Since the number of instances considered in this

work is small, [ILP] can be straightforwardly solved

to optimality using a ILP solver as ILOG-CPLEX. Nu-

merical results are reported in Section 3. The consid-

ered system is denoted [LDA + ILP] since p(w

|k) are

given by [LDA]. χ

max

has been chosen according to

the desired concept annotation. As on average a con-

cept support contains 2.1 words, χ

max

is deﬁned em-

pirically according to the number of words: with i =

[[2, 4]] :χ

max

= i with i = [[5, 10]] words: χ

max

= i − 2

and for utterances containing more than 10 words:

max

= i/2.

3 EVALUATION AND RESULTS

3.1 MEDIA Corpus

The MEDIA corpus is used to evaluate the proposed

approach. MEDIA is a French corpus related to

the domain of tourism information and hotel reser-

vation (Bonneau-Maynard et al., 2005). 1257 dia-

logues were recorded from 250 speakers with a WoZ

technique (a human simulating an automatic phone

server). In our experiments we only consider the 17k

user utterances. This dataset contains 123,538 words,

for a total of 2470 distinct words.

The MEDIA data have been manually transcribed

and semantically annotated. The semantic annotation

is rich of 75 concepts (e.g.: location, hotel-state, time-

month. . . ). Each concept is supported by a sequence

of words, the concept support. The null concept is

used to annotate every word segment that does not

support any of the 74 other concepts. Concepts do

not appear at the same frequency as shown in Table 1.

For example, 33 concepts (44% of the concepts) are

supported by 100 occurences at most, while 15 con-

cepts (21% of the concepts) present more than 1,000

occurences (only null is above 9,000).

Table 1: Number of concepts according to their occurrence

range.

[1,100] [100,500] [500,1k] [1k,9k] [9k,15k]

33 21 6 14 1 (null)

On average, a concept support contains 2.1 words,

3.4 concepts are included in a turn and 32% of the

utterances are single-word turns (generally yes or no).

3.2 Automatic Evaluation Protocol

As MEDIA reference concepts are very ﬁne-grained,

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

we introduce a high-level concept hierarchy con-

taining 18 clusters of concepts. For example, a

high-level concept payment is created, correspond-

ing to the four concepts payment-meansOfPayment,

payment-currency, payment-total-amount, payment-

approx-amount, a high-level concept location corre-

sponds to 12 concepts (location-country, location-

district, location-street, . . . ). Thus, two levels of con-

cepts are considered for the evaluation: the high-level

(18 classes) and the ﬁne-level (75 classes).

To evaluate the unsupervised procedure in a fully

automatic way, it is necessary to associate each in-

duced topic with a MEDIA concept. To that purpose,

topics are aligned with concepts based on their word

support for each utterance according to the reference

annotation. A co-occurrence matrix is computed and

each topic is associated to its most co-occurring con-

cept. Table 2 analyses this automatic association

for two values of K, the number of topics induced

by LDA. Some concepts may not be associated with

any topic, the CC column (Concept Coverage) gives

the percentage of concepts that are associated with a

topic. The NNT column (Not Null Topic) computes

the percentage of topics not associated with the null

concept.

Table 2: Analysis of the automatic association between top-

ics and concepts. CC: concept coverage by the topics. NNT:

% of topics not associated with null.

K=50 topics K=200 topics

CC NNT CC NNT

high LDA 61 60 72 51

LDA+ILP 67 62 82 57

ﬁne LDA 21 50 34 47

LDA+ILP 24 58 39 53

Considering [LDA] and ﬁne-level concepts, only

one ﬁfth of the MEDIA concepts are retrieved for

K = 50 and up to one third for K = 200. Though 72%

of the high-level concepts are retrieved with K = 200.

Considering [ILP + LDA], this value even increases

to 82%. This ”lost concept” phenomenom at high-

level can be explained by the fact that 72% of the

concepts are supported by less than 500 concept sup-

ports, which seems a bit low for [LDA] to modelize

them as a topic. [LDA + ILP] helps to cover more

concepts. Obviously, when more topics are induced,

more concepts are covered. It is also interesting to

notice that about half of the topics are associated with

the null concept. When the number of topics is in-

creased, more concepts are discovered but also more

topics are associated with null.

3.3 Generated Topic Observations

In Table 3, six topics generated by [LDA] are repre-

sented by their 8 highest probability words. For topic

13, it is interesting noting that words have quite sim-

ilar weights. The most represented words are “du”

(“from”) and “au” (“to”) and other words are numbers

or month that a priori leads to a “time-date” topic. For

topic 43, the word “oui” (“yes”) is given a 0.62 proba-

bility, other words are “absolutely” or “okay” leading

to an a priori “answer-yes” topic.

To observe which MEDIA concept is associated to

these topics, the list of the 3 most co-occurring con-

cepts and the number of co-occurrences are shown

in Table 4. The 2 ﬁrst most co-occurring concepts

in a topic are the same in [LDA] and [LDA + ILP].

However, the number of co-occurrence is higher in

[LDA + ILP] than in [LDA]. An entropy measure

Ent(t) is computed for each topic t in order to evalu-

ate the reliability of the topic-concept association over

all the possible concepts. It is computed as follows:

Ent(t) = −

∑

concepts c

p(c|t) log p(c|t) (7)

with p(c|t) =

#(c

The topic entropy is always smaller considering

[LDA + ILP] than [LDA]. This indicates that the re-

assignment due to ILP alignment improves the re-

liability of the topic-concept association. Entropies

measured with high-level concepts are always lower

than with ﬁne-level concepts, in particular because

less classes are considered (18 instead of 75). For

topic 18, we can see that high-level enables to con-

sider this topic as a Location concept and not a null

one but the entropy is quite high. On the over hand,

topic 43 shows a low entropy, speciﬁcally in [LDA +

ILP]. This shows that word “yes” is strongly associ-

ated with concept “Answer”. Other topics represent-

ing the null concept can show an entropy of 0.47 like

the 6th topic (“there”, “is”, “what”, “how”, “does”,

. . . )

3.4 Results

The evaluation is presented in terms of F-measure,

combining precision and recall measures. Quality of

topic assignment is considered also according to 2

levels:

• alignment corresponds to a full evaluation where

each word is considered and associated with one

topic,

• generation corresponds to the set of topics gener-

ated for a turn (no order, no word-alignment).

CONCEPT DISCOVERY FOR LANGUAGE UNDERSTANDING IN AN INFORMATION-QUERY DIALOGUE

SYSTEM

Table 3: Examples of topics discovered by LDA (K = 100).

Topic 0 Topic 13 Topic 18 Topic 35 Topic 33 Topic 43

information time-date sightseeing politeness location answer-yes

words prob. words prob. words prob. words prob. words prob. words prob.

d’ 0.28 du 0.16 de 0.30 au 0.31 de 0.30 oui 0.62

plus 0.17 au 0.11 la 0.24 revoir 0.27 Paris 0.12 et 0.02

informations 0.16 quinze 0.08 tour 0.02 madame 0.09 la 0.06 absolument 0.008

autres 0.10 dix-huit 0.07 vue 0.02 merci 0.08 pr

es 0.06 autre 0.008

etails 0.03 d

ecembre 0.06 Eiffel 0.02 bonne 0.01 proche 0.05 donc 0.007

obtenir 0.03 mars 0.06 sur 0.02 journ

ee 0.01 Lyon 0.03 jour 0.005

alors 0.01 dix-sept 0.04 mer 0.01 villes 0.004 aux 0.02 Notre-Dame 0.004

souhaite 0.003 nuits 0.04 sauna 0.01 bient

ot 0.003 gare 0.02 d’accord 0.004

Table 4: Topic repartitions among the high or ﬁne-level concepts for [LDA] and [LDA + ILP] (K = 100).

Topic 18 Topic 33 Topic 43

sightseeing location answer-yes

#occ. concept Ent(t) #occ. concept Ent(t) #occ. concept Ent(t)

high 292 Location 571 Location 705 Answer

LDA 258 null 2.25 156 null 1.72 107 null 1.10

94 Name 87 Comparative 27 Location

ﬁne 258 null 226 loc.-distanceRel. 705 answer

136 loc.-placeRel. 2.78 190 location-city 2.57 107 null 1.19

100 loc.-distanceRel. 156 null 17 object

high 300 Location 661 Location 846 Answer

LDA 200 null 2.19 123 null 1.52 109 null 0.76

+ 102 Name 115 Comparative 24 Location

ILP ﬁne 200 null 234 loc.-distanceRel. 846 answer

163 loc.-placeRel. 2.64 223 location-city 2.44 109 null 0.80

98 name-hotel 129 loc.-placeRel. 16 name-hotel

Plots comparing the different systems imple-

mented w.r.t. the different evaluation levels in terms

of F-measure are reported in Figures 1 and 2.

50 100 150 200

Fmeasure

Number of topics

[LDA+ILP] high

[LDA] high

[LDA+ILP] fine

[LDA] fine

Figure 1: F-measure of the concept generation as a function

of the number of topics.

The [LDA] system generates topics which are cor-

rectly correlated with the high-level concepts. It can

be observed that the bag of 75 topics reaches an F-

measure of 61.6% (Figure 1), corresponding to a pre-

cision of 59.4% and a recall of 64%. When [LDA] is

asked to generate too few topics, induced topics are

not speciﬁc enough to ﬁt the ﬁne-grained concept an-

50 100 150 200

Fmeasure

Number of topics

[LDA+ILP] high

[LDA] high

[LDA+ILP] fine

[LDA] fine

Figure 2: F-measure of the concept alignment as a function

of the number of topics.

notation of MEDIA.

On the other hand, Figure 2 shows that a too high

increase of the number of topics does not affect the

bag of high-level topics signiﬁcantly but induces a

substantial decrease of the F-measure for the align-

ment evaluation. This effect can be explained by the

automatic alignment method chosen to transpose top-

ics into reference concepts. When there are too many

topics, they co-occur with many concepts and are as-

signed to the most co-occurring one when some other

concepts can co-occur only slightly less. In such sit-

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

uations, it is likely that null is the most co-occurring

concept and the other concepts because they are too

much scattered are not associated to enough topics.

So they appear in the utterance but not on enough

words to be retained by the segmentation process.

From the high-level to ﬁne-level concept evalua-

tion, results globally decrease of 10%. A loss of 12%

is observed from the generation to the alignment eval-

uation. In the ﬁne-level evaluation, a maximum F-

measure of 52.5% is observed for the generation of

75 topics (Figure 1), corresponding to 54.9% in pre-

cision and 50.3% in recall whereas the F-measure de-

creases to 41% (precision=46.7% and recall=36.7%)

in the alignment evaluation (Figure 2).

To conclude on the [LDA] system, we can see that

it generates topics having a good correlation with the

high-level concepts, seemingly the best representation

level between topics and concepts. It is obvious that

an additional step is needed to obtain a more accurate

segmental annotation, what is expected with the use

of ILP.

[LDA + ILP] performs better whatever the level of

evaluation. For instance, an F-measure of 66% is ob-

served considering the high-level concept generation

for 75 topics (Figure 2). As for [LDA], the same losses

are observed between high-level and ﬁne-level con-

cepts and generation and alignment paradigms. Nev-

ertheless, an F-measure of 54.8% is observed at the

high-level concept in alignment evaluation (Figure 2)

that corresponds to a precision of 56.2% and a recall

of 53.5%, which is not so low considering a fully-

automatic high-level annotation system.

4 CONCLUSIONS

In this paper an approach has been presented for con-

cept discovery and segmental semantic annotation of

user’s turns in an information-query dialogue system.

An evaluation based on an automatic association be-

tween generated topics and expected concepts has

been shown that topics induced by LDA are close to

high-level task-dependent concepts. The segmental

annotation process increases performance both for the

generation and alignment evaluations. On the whole

these results conﬁrm the applicability of the technique

to practical tasks with expected gain in data produc-

tion.

Future work will investigate the use of n-grams to

extend LDA and to increase its accuracy for provid-

ing better hypotheses to the following segmentation

techniques. Also another technique for automatic re-

alignment, based on IBM models used in stochastic

machine translation, will be examined.

REFERENCES

Blei, D., Ng, A., and Jordan, M. (2003). Latent Dirichlet al-

location. The Journal of Machine Learning Research,

3:993–1022.

Bonneau-Maynard, H., Rosset, S., Ayache, C., Kuhn, A.,

and Mostefa, D. (2005). Semantic annotation of the

French MEDIA dialog corpus. In Proceedings of Eu-

rospeech.

Celikyilmaz, A., Hakkani-Tur, D., and Tur, G. (2010). LDA

based similarity modeling for question answering. In

Proceedings of the NAACL HLT 2010 Workshop on

Semantic Search, pages 1–9. Association for Compu-

tational Linguistics.

Chen, D., Batson, R. G., and Dang, Y. (2010). Applied

Integer Programming: Modeling and Solution. Wiley.

Iosif, E., Tegos, A., Pangos, A., Fosler-Lussier, E., and

Potamianos, A. (2006). Unsupervised combination of

metrics for semantic class induction. In Proceedings

of the IEEE Spoken Language Technology Workshop,

pages 86–89.

Pargellis, A., Fosler-Lussier, E., Potamianos, A., and Lee,

C. (2001). Metrics for measuring domain indepen-

dence of semantic classes. In Proceedings of Eu-

rospeech.

Phan, X., Nguyen, L., and Horiguchi, S. (2008). Learning

to classify short and sparse text & web with hidden

topics from large-scale data collections. In Proceeding

of the 17th international conference on World Wide

Web, pages 91–100. ACM.

ReVelle, C. S. and Eiselt, H. A. (2005). Location analysis:

A synthesis and survey. European Journal of Opera-

tional Research, 165(1):1–19.

Siu, K. and Meng, H. (1999). Semi-automatic acquisition of

domain-speciﬁc semantic structures. In Proceedings

of Eurospeech.

Tam, Y. and Schultz, T. (2006). Unsupervised language

model adaptation using latent semantic marginals. In

Proceedings of Interspeech, pages 2206–2209.

CONCEPT DISCOVERY FOR LANGUAGE UNDERSTANDING IN AN INFORMATION-QUERY DIALOGUE

SYSTEM
