SEGMENTED–MEMORY RECURRENT NEURAL NETWORKS

VERSUS HIDDEN MARKOV MODELS IN EMOTION

RECOGNITION FROM SPEECH

Stefan Gl¨uge, Ronald B¨ock and Andreas Wendemuth

Faculty of Electrical Engineering and Information Technology, Otto von Guericke University Magdeburg

Universit¨atsplatz 2, 39106 Magdeburg, Germany

Keywords:

Segmented-memory recurrent neural networks, Emotion recognition from speech.

Abstract:

Emotion recognition from speech means to determine the emotional state of a speaker from his or her voice.

Today’s most used classiﬁers in this ﬁeld are Hidden Markov Models (HMMs) and Support Vector Machines.

Both architectures are not made to consider the full dynamic character of speech. However, HMMs are able

to capture the temporal characteristics of speech on phoneme, word, or utterance level but fail to learn the

dynamics of the input signal on short time scales (e.g., frame rate). The use of dynamical features (ﬁrst and

second derivatives of speech features) attenuates this problem. We propose the use of Segmented-Memory

Recurrent Neural Networks to learn the full spectrum of speech dynamics.

Therefore, the dynamical features can be removed form the input data. The resulting neural network classiﬁer

is compared to HMMs that use the reduced feature set as well as to HMMs that work with the full set of

features. The networks perform comparable to HMMs while using signiﬁcantly less features.

1 INTRODUCTION

Automatic emotion recognition from speech aims at

identifying the emotional or physical state of a human

being from his or her voice (Ververidis and Kotropou-

los, 2006). The motivation for it mainly arises from

the wish for a natural man-machine interaction. De-

termination of the emotional state of a user helps to

derive the semantics of a spoken sentence and fur-

ther enables the machine to respond in an appropriate

manner, for example to adapt the dialogue strategy

(Vlasenko and Wendemuth, 2009a). Further, there is

a number of possible applications in various ﬁelds,

for instance, in the in-car environment to monitor the

emotional state of the driver (Schuller et al., 2004), in

call centres to detect angry speech (Kim and Hansen,

2010), and in psychology to support the diagnosis

of psychiatric disorders (Yingthawornsuk and Shiavi,

2008).

Emotion recognition from speech means to extract

adequate features from raw speech data followed by

the classiﬁcation of the feature-representation of an

utterance. In many cases, utterances are labelled with

basic emotions like anger, boredom, disgust, etc. (Ek-

man, 1992). Furthermore, utterances can be classi-

ﬁed as a point in emotion space with the dimensions

valance-arousal-dominance (Grimm et al., 2007) or

pleasure-arousal-dominance (Mehrabian, 1996). Yet,

a large range of classiﬁers was used for speech emo-

tion recognition. First of all, Hidden Markov Mod-

els (HMMs) represent a standard practice (Nwe et al.,

2003; Song et al., 2008; Inoue et al., 2011). El Ayadi

et al., 2011 state:

“Based on several studies (...), we can conclude

that HMM is the most used classiﬁer in emotion clas-

siﬁcation probably because it is widely used in almost

all speech applications.”

Beside HMM, Support Vector Machines have

been used (Pierre-Yves, 2003; Schuller et al., 2009b),

and different kinds of neural networks. For in-

stance, feedforward networks (Nicholson et al., 1999;

Petrushin, 2000), Long Short-Term Memory Recur-

rent Neural Networks (W¨ollmer et al., 2008) and

Echo State Networks (Scherer et al., 2008; Trentin

et al., 2010).

In this work we use a novel recurrent network ar-

chitecture called Segmented-Memory Recurrent Neu-

ral Network (SMRNN) (Chen and Chaudhari, 2009)

to solve the task of emotion classiﬁcation from

speech. Those networks are able to learn long-term

and short-term time dependencies in the input data.

By that, we can waive the dynamic features of the in-

308

Glüge S., Böck R. and Wendemuth A..

SEGMENTED–MEMORY RECURRENT NEURAL NETWORKS VERSUS HIDDEN MARKOV MODELS IN EMOTION RECOGNITION FROM SPEECH.

DOI: 10.5220/0003644003080315

In Proceedings of the International Conference on Neural Computation Theory and Applications (NCTA-2011), pages 308-315

ISBN: 978-989-8425-84-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

)

...

Figure 1: HMM topology.

put data, that is, reduce the feature set. The results

are compared to HMM classiﬁers that work with the

reduced feature set (no dynamic features) and the full

set of features.

The paper is organised as follows. Section 2 re-

veals the basic concept of HMMs and SMRNNs. Sec-

tion 3 introduces the speech database, feature extrac-

tion from the speech signal, and conﬁguration of the

HMM and SMRNN classiﬁers. The results are pre-

sented in Sec. 4 and discussed in Sec. 5.

2 METHODS

2.1 Hidden Markov Models

The principle of the HMM is based on the Markov

characteristic of a process, i.e., the successive pro-

cessing step is independent from previous decisions

(Rabiner and Juang, 1993; Tuzlukov, 2000). Gen-

erally, HMMs are powerful in signal processing

(Boreczky and Wilcox, 1998; Schmidt et al., 2010) as

well as in speech processing and recognition (Rabiner

and Juang, 1993; El Ayadi et al., 2011). Such a model

is a ﬁnite state automata, which passes from state s

to state s

in each time slot, where i and j are ele-

ments of the state number set. Traversing the model,

an observation sequence o

is produced according to

a probability density b

). Also the hidden values

are probabilistic, representing the transition like-

lihood from state s

to s

. A visualisation is given in

Fig. 1.

The training process of HMMs is done by the

Baum-Welsh-Algorithm (Baum et al., 1970) and the

most likely observation sequence is computed by the

Viterbi-Algorithm (Viterbi, 1967).

2.2 Segmented-memory Recurrent

Neural Networks

Conventional Recurrent Neural Networks (RNNs)

suffer the vanishing gradient problem (Bengio et al.,

1994; Hochreiter, 1998) in learning long-term de-

pendencies. The Segmented-Memory Recurrent Neu-

ral Network architecture, recently proposed by (Chen

and Chaudhari, 2009), approaches the problem based

on the observation on human memorization. Dur-

ing the process of memorization of long sequences,

it is widely recognised that people fractionise it into

segments. In the end, the single segments are con-

nected in series and form the ﬁnal sequence (Severin

and Rigby, 1963; Hitch et al., 1996). For instance,

telephone numbers are often broken into segments of

two or three digits to ease the memorization such that

6718959 becomes 67 - 18 - 959.

Figure 2 illustrates the SMRNN architecture. It

consists of two simple recurrent networks (SRN) (El-

man, 1990) arranged in an hierarchical fashion. The

ﬁrst SRN processes the symbol-level and the second

the segment-level of the input sequence. Regarding

the telephone number example, the single digits cor-

respond to symbols processed on symbol-level while

the groups of two/three digits correspond to segments

processed on segment-level.

Figure 2: SMRNN topology.

The SMRNN has an input, output, and two hid-

den layers as it is known from multilayer feedfor-

ward networks. In addition it has two context layers.

These layers have the same number of units as the

corresponding hidden layers and each unit represents

a copy of the last output of the hidden layer. Based

on this topology the network is able to learn temporal

patterns of a sequential input implicitly (Gl¨uge et al.,

2010a; Gl¨uge et al., 2010b).

In the following, we use the receiver-sender-

SEGMENTED-MEMORY RECURRENT NEURAL NETWORKS VERSUS HIDDEN MARKOV MODELS IN

EMOTION RECOGNITION FROM SPEECH

309

notation. The upper index of the weight matrices de-

note the corresponding layer and the lower index the

single units. For example, W

denotes the connec-

tion between the kth unit in hidden layer 1 and the

ith unit in the input layer (cf. Fig. 2). Moreover, f

net

denotes the transfer function of the network (e.g., hy-

perbolic tangent, sigmoid function) and n

, n

denote the number of units in the input, hidden 1, hid-

den 2, and output layer.

The introduction of the parameter d on segment-

level makes the main difference between a cascade of

SRNs and an SMRNN. It denotes the length of a seg-

ment, which can be ﬁxed or variable. The processing

of an input sequence starts with the initial symbol-

level state x(0) and segment-level state y(0). At the

beginning of a segment (segment head SH) x(t) is up-

dated with x(0) and input u(t). On other positions

x(t) is obtained from its previous state x(t − 1) and

input u(t). It is calculated by

(t) =











net



∑

(0) +

∑

(t)



,if SH

net



∑

(t − 1) +

∑

(t)



otherwise

(1)

with k = 1,...,n

. The segment-level state y(0) is

updated at the end of each segment (segment tail ST)

(t) =











net



∑

(t − 1) +

∑

(t)



if ST

(t − 1), otherwise

(2)

with k = 1, . . . , n

. The network output results in for-

warding the segment-level state

(t) = f

net

∑

(t)

with k = 1, . . . ,n

(3)

The dynamic of an SMRNN is mainly inﬂuenced

by the length of the segments d. While the symbol-

level is updated on a symbol by symbol basis, the

segment-level changes only with the end of a seg-

ment, after d symbols are processed. At the end of the

input sequence the segment-levelstate is forwarded to

the output layer to generate the ﬁnal output. The dy-

namics of an SMRNN processing a sequence is shown

in Fig. 3. In the example the interval d is ﬁxed and the

sequence consists of 3 segments.

For the training of the SMRNN we use an ex-

tention of the real-time recurrent learning algorithm

(eRTRL) as it is described in (Chen and Chaudhari,

2009). During learning the network weights W and

the initial states of the hidden layers x(0), y(0) are

adapted to minimise the sum of squared error at the

output.

3 EXPERIMENTAL SETUP

3.1 Speech Database

We chose the well-known studio recorded Berlin

Emotional Speech Database (EMO-DB) (Burkhardt

et al., 2005) to test the SMRNN approach on emo-

tion recognition from speech. It is freely accessible

and provides high quality audio material and annota-

tion. It is used in several studies on emotion recog-

nition from speech (El Ayadi et al., 2007; Schuller

et al., 2009b; Albornoz et al., 2011). Seven emotional

classes are covered, namely anger, boredom, disgust,

fear, joy, neutral, and sadness.

The corpus consists of ten predeﬁned German sen-

tences that are not emotionally biased by their mean-

ing, e.g., “Der Lappen liegt auf dem Eisschrank” (The

cloth is lying on the fridge). Sentences are spoken

by ten (ﬁve male and ﬁve female) professional ac-

tors in each emotional way. In a perception test the

recorded utterances were evaluated and deleted when

recognition errors were more than 20% and if they

were judged as non natural by more than 40% of 20

listeners. This ensures the emotional quality and nat-

uralness of the utterances.

For the recognition task each emotional class was

split into 90% training and 10% test data for the

HMMs. Further, the data for the SMRNNs was split

into 80% for training, 10% for validation, and 10%

for testing. The validation set was used to identify

the parameters of the networks (number of neurons in

hidden layers n

, n

, and length of segments d) that

seem to work best on each class. Afterwards the net-

works were tested on the test data.

Table 1 shows the distribution of the utterances

over the emotion classes.

Table 1: EMO-DB utterances grouped by emotional

class and separation into training/testing or train-

ing/validation/testing.

Emotion No. utterances HMM SMRNN

Anger 127 114/13 102/13/12

Boredom 79 71/8 63/8/8

Disgust 38 34/4 30/4/4

Fear 55 50/5 44/6/5

Joy 64 58/6 51/6/7

Neutral 78 70/8 62/8/8

Sadness 52 47/5 42/5/5

NCTA 2011 - International Conference on Neural Computation Theory and Applications

310

Figure 3: SMRNN dynamics.

3.2 Feature Selection and Extraction

One of the most relevant features for emotion recog-

nition from speech is the pitch . It represents the per-

ceived fundamental frequency (F0) of a sound. Be-

side pitch, spectral features, such as mel-frequency

cepstral coefﬁcients (MFCCs) are dominant features

used for speech recognition. Further, MFCCs are

used in speaker veriﬁcation (Ganchev et al., 2005)

and even music information retrieval such as genre

classiﬁcation (M¨uller, 2007). They have also been

found meaningful for emotion recognition (Vlasenko

et al., 2008; Vlasenko and Wendemuth, 2009b; B¨ock

et al., 2010; H¨ubner et al., 2010; Schuller et al., 2011).

MFCCs are coefﬁcients that collectively make up

a mel-frequency cepstrum (MFC). They are derived

from a type of cepstral representation of the audio

clip (a nonlinear “spectrum-of-a-spectrum”). The dif-

ference between the cepstrum and the mel-frequency

cepstrum is that in the MFC, the frequency bands are

equally spaced on the mel scale, which approximates

the human auditory system’s response more closely

than the linearly-spaced frequency bands used in the

normal cepstrum (Fant, 1960).

For our experiment, the features were extracted

with the help of the Hidden Markov Model Toolkit

(Young et al., 2006), primarily used for speech recog-

nition research.

3.2.1 Features for HMMs

The speech data was processed using a 25ms Ham-

ming window, with a frame rate of 10ms. For each

frame (25ms audio material) a 39 dimensional feature

vector was extracted. It consisted of 12 MFCCs and

0th cepstral coefﬁcient plus ﬁrst and second deriva-

tives, which gives a 39 dimensional feature vector.

The ﬁrst and second derivatives are so called dy-

namic features that take the temporal variation of the

speech signal into account. In the literature, the ﬁrst

derivatives are often called Deltas (∆) and the second

derivativesAcceleration (∆∆). This feature set is quite

common in speech community as well as in emotion

recognition from speech.

The mean length of an utterance in EMO-DB is

2.74s. With a frame rate of 10ms this resulted in a

mean of 274 × 39 = 10686 values per utterance.

To compare the results gained by the SMRNNs we

additionaly trained HMMs with a reduced feature set.

Thus, we kept the 12 MFCCs and the 0th coefﬁcient

but generated a set having just the Deltas (26 fea-

tures) and another without any additional derivatives

(13 features).

3.2.2 Features for SMRNNs

For the SMRNNs, we also used a 25ms Hamming

window to process the speech signal. Preliminary

experiments showed that the performance of the net-

works was constant in the range of the frame rate be-

tween 10ms and 25ms. To reduce the computational

effort we chose 25ms for the frame rate, which is the

same size as the Hamming window (no overlapping).

We employed 12 MFCCs and the 0th cepstral co-

efﬁcient, which gives a 13 dimensional feature vector.

Note that we did not use the dynamic features (ﬁrst

and second derivatives) as the network should learn

the temporal structure of the data. Due to the sig-

moidal characteristics of the activation function used

in the networks the features were scaled onto values

in the range of [−7,7].

With the mean length of an utterance of 2.74s and

the frame rate of 25ms we got 110× 13= 1430 values

per utterance. The larger frame rate and the reduction

of the features led to around 7.5 times less data than

it was used for the HMM approach.

3.3 Architecture of the Classiﬁer

Both types of classiﬁers work according to the one-

class-one-classiﬁer principle. We employ seven clas-

siﬁers and each is trained on one emotional class. In

the end the output of these seven ‘experts’ is used to

ﬁnd the ﬁnal decision. Figure 4 illustrates the ap-

proach.

3.3.1 HMM

In case of Hidden Markov Models for each class one

model was trained. In testing, the input was presented

to each model simultaneously and by traversing the

model the most likely path through it was computed

using the Viterbi-Algorithm. Finally, for each result

the log-likelihood was calculated. According to these

SEGMENTED-MEMORY RECURRENT NEURAL NETWORKS VERSUS HIDDEN MARKOV MODELS IN

EMOTION RECOGNITION FROM SPEECH

311

Figure 4: One-class-one-classiﬁer principle.

values a ﬁnal decision was carried out, i.e., the largest

value was taken, which is a winner-take-all principle.

The training and testing was done by utilising the Hid-

den Markov Toolkit (Young et al., 2006) by the Uni-

versity of Cambridge.

In particular, an HMM had the following struc-

ture: It was a left-to-right forward passing scheme,

which means that all connections were either forward

oriented or self-loops (cf. Fig. 1). Moreover, each

model had 3 internal states that is standard in speech

processing. The input was the sequence of feature

vectors of an utterance and the output produced by

the system was the emotion label (cf. Sec. 3.1).

3.3.2 SMRNN

According to the general structure of the classiﬁer (cf.

Fig. 4) we trained seven different SMRNNs. Each

consists of thirteen input units (n

= 13) and one out-

put unit (n

= 1), such that each network decided

whether the presented utterance belongs to its class

(z = 1) or not (z = 0). The transfer function for

the hidden and output units was the sigmoid function

( f

net

(x) = 1/(1+ exp(−x)) ). The input units simply

forwarded the input data. Initial weights were set to

uniformly distributed random values in the range of

[−0.4, 0.4].

Each network differs in three parameters, namely

the number of units in the hidden layers n

, n

, and

the length of the segments d. They were determined

using the training and validation set. Those param-

eter combinations that worked best on the validation

set after training were picked for the ﬁnal classiﬁer.

Due to the computational effort for network training

we used no systematic search technique for combina-

tions of parameters yet. In this respect, the present

parameter combinations should be taken as an edu-

cated guess. Table 2 shows the network conﬁguration

for each class.

The networks were trained for 100 epochs with

the learning rate 0.2 and momentum 0.1. For each

utterance the networks delivered an output value in

the range of (0, 1). To come up with a ﬁnal deci-

sion, we used the winner-take-all principle, that is, the

Table 2: SMRNN conﬁguration grouped by emotional

class.

Emotion hidden 1 hidden 2 segment

length d

Anger 28 8 17

Boredom 19 8 14

Disgust 22 14 8

Fear 17 17 7

Joy 19 29 2

Neutral 8 26 19

Sadness 13 13 11

network with the highest output determined the emo-

tional class that corresponds to the utterance.

4 RESULTS

The performance of both classiﬁcation methods was

measured using the weighted average (WA) of class-

wise accuracy as it is proposed in (Schuller et al.,

2009a). Since the number of utterances in the single

classes differed considerably, the weighted average

provides a more reasonable measure than the arith-

metic mean (unweighted average UA).

In the following, HMM denotes the classiﬁer that

was trained using the 13 basic features (12 MFCCs

plus 0th coefﬁcient). HMM∆ denotes the classiﬁer

that was trained with 26 features (13 basic features

plus ﬁrst derivatives). HMM∆∆ denotes the HMM

classiﬁer that was trained with the full set of 39 fea-

tures (13 basic features plus ﬁrst and second deriva-

tives).

Table 3 shows the results for the SMRNN against

the HMM approach using the weighted and un-

weighted average.

Table 3: Weighted and unweighted average of class-wise

accuracy in % for HMM and SMRNN classiﬁers during

training and testing.

Emotion training WA / UA testing WA / UA

SMRNN 91.08 / 91.62 71.02 / 73.47

HMM∆∆ 79.70 / 81.76 73.75 / 77.55

HMM∆ 81.17 / 81.08 60.03 / 63.27

HMM 71.15 / 70.72 51.72 / 55.10

The SMRNN classiﬁer performed best during

training (≈ 91%), but dropped down to 71% in test-

ing. HMM∆∆ delivered the best result on the test set

(≈ 74%). This coincides with the results reported in

(Schuller et al., 2009b) and (B¨ock et al., 2010).

Feature reduction caused a signiﬁcant decrease in

the performance of the HMMs. The HMM∆ and

NCTA 2011 - International Conference on Neural Computation Theory and Applications

312

HMM classiﬁers (cf. Tab. 3) performed inferior to the

SMRNNs.

In comparison to the HMM∆∆ the SMRNNs per-

formed slightly worse (71.02% vs. 73.75% on test

set). Note that the networks used three times less fea-

tures (13 vs. 39, cf. Sec. 3.2.2) than the HMM∆∆ and

reached a comparable performance.

Tables 4 and 5 show the class-wise accuracy of the

SMRNN and HMM∆∆ classiﬁer.

Table 4: Confusion matrix of SMRNN classiﬁer on test set

with class-wise accuracy in % (Acc.).

Emotion A B D F J N S

Anger 12 0 0 1 2 0 1

Boredom 0 5 0 0 0 3 0

Disgust 0 0 3 0 0 0 0

Fear 0 0 0 3 1 0 0

Joy 0 0 1 0 4 0 0

Neutral 0 1 0 1 0 5 0

Sadness 0 2 0 0 0 0 4

Acc. 100 62.5 75 60 57 62.5 80

Table 5: Confusion matrix of HMM∆∆ classiﬁer on test set

with class-wise accuracy in % (Acc.).

Emotion A B D F J N S

Anger 11 0 0 1 2 0 0

Boredom 0 7 0 1 0 1 1

Disgust 0 0 2 0 0 0 0

Fear 1 0 0 3 0 0 0

Joy 1 0 0 0 4 0 0

Neutral 0 0 0 0 0 7 0

Sadness 0 1 2 0 0 0 4

Acc. 84.6 87.5 50 60 66.7 87.5 80

One can see that for SMRNNs as for HMM∆∆

the accuracy on the different classes was nonhomoge-

neous. Both classiﬁers performed well on anger and

sadness (Acc. ≥ 80%) but performed worse on fear

and joy (Acc. < 70%). Anger was perfectly classiﬁed

by the SMRNNs. This might be due to the overrepre-

sentation of anger in the database (cf. Tab. 1). Further,

some emotions (e.g., disgust and sadness) occure in a

small number in the test set. Therefore, the correct

classiﬁcation of one of the utterances in that classes

had a high impact on the overall performance.

5 DISCUSSION

Our experiment showed that SMRNNs have the po-

tential to solve complex sequence classiﬁcation tasks

as they appear in automatic speech processing. The

memory for contextual information enables the net-

work to learn long-term as well as short-term tempo-

ral dependencies, while the segmentation of the mem-

ory prevents it to suffer from the vanishing gradient

problem. As the networks are able to learn the dy-

namics of the input sequences it is not necessary to

provide the dynamic features of the speech signal to

learn the task.

In the experiment SMRNNs performed slightly

worse (≈ 3% on test set) compared to HMMs

that were trained with three times more features

(HMM∆∆). Further, the input signal of the HMMs

was sampled more frequently during feature extrac-

tion (10ms for HMMs vs. 25ms for SMRNNs, cf. Sec.

3.2.2). In total the HMM∆∆s were trained with 7.5

times more data than the SMRNNs.

On the other hand, HMMs that used the same

amount of features were outperformed by the SM-

RNNs by around 19% weighted average accuracy on

the test set (cf. Tab. 3).

The perfect classiﬁcation of anger by the SM-

RNNs (cf. Tab. 4) gives rise to the hope, that the per-

formance of the networks could enhance by providing

more training material for the different classes.

We see the main drawback of the SMRNN ap-

proach in the computational costs for the network

training. In worst-case (network is fully connected

and all weights are adaptable) the RTRL algorithm

has a space complexity Θ(n

) and average time com-

plexity Θ(n

), with n denoting the number of units in

the network (Williams and Zipser, 1995). By now,

this forced us to guess the parameter combinations

,d) for the networks. The learning rate, mo-

mentum and number of epochs for the training might

also not be optimal yet. Replacement of the RTRL

algorithm by the extended Kalman ﬁlter algorithm

(EKF) could be a possible solution for the problem

(

Cerˇnansk´y and Beˇnuˇskova, 2003).

Beside the optimisation of the network parameter,

there are indications that the networks performance

can be improved with the use of alternative features,

e.g., perceptual linear prediction coefﬁcients (Her-

mansky, 1990).

ACKNOWLEDGEMENTS

The authors acknowledge the support provided

by the federal state Sachsen-Anhalt with the

Graduiertenf¨orderung (LGFG scholarship). Fur-

thermore, we acknowledge continued support by

the Transregional Collaborative Research Centre

SFB/TRR 62 “Companion-Technology for Cognitive

Technical Systems” funded by the German Research

SEGMENTED-MEMORY RECURRENT NEURAL NETWORKS VERSUS HIDDEN MARKOV MODELS IN

EMOTION RECOGNITION FROM SPEECH

313

Foundation (DFG). We also acknowledge the DFG

for ﬁnancing our computing cluster used for parts of

this work.

REFERENCES

Albornoz, E. M., Milone, D. H., and Ruﬁner, H. L. (2011).

Spoken emotion recognition using hierarchical clas-

siﬁers. Computer Speech and Language, 25(3):556–

570.

Baum, L., Petrie, T., Soules, G., and Weiss, N. (1970).

A maximization technique occurring in the statistical

analysis of probabilistic functions of markov chains.

Ann. Math. Stat., 41:164–171.

Bengio, Y., Simard, P., and Frasconi, P. (1994). Learning

long-term dependencies with gradient descent is difﬁ-

cult. IEEE transactions on neural networks, 5(2):157–

66.

B¨ock, R., H¨ubner, D., and Wendemuth, A. (2010). De-

termining optimal signal features and parameters for

hmm-based emotion classiﬁcation. In MELECON

2010 - 15th IEEE Mediterranean Electrotechnical

Conference, pages 1586–1590.

Boreczky, J. S. and Wilcox, L. D. (1998). Hidden markov

model framework for video segmentation using audio

and image features. In ICASSP, IEEE International

Conference on Acoustics, Speech and Signal Process-

ing, volume 6, pages 3741–3744.

Burkhardt, F., Paeschke, A., Rolfes, M., Sendlmeier, W.,

and Weiss, B. (2005). A database of german emo-

tional speech. In Proceedings of the 9th European

Conference on Speech Communication and Technol-

ogy; Lisbon, pages 1517–1520.

Chen, J. and Chaudhari, N. (2009). Segmented-memory

recurrent neural networks. Neural Networks, IEEE

Transactions, 20(8):1267–80.

Ekman, P. (July 1992). Are there basic emotions? Psycho-

logical Review, 99:550–553.

El Ayadi, M., Kamel, M., and Karray, F. (2007). Speech

emotion recognition using gaussian mixture vector au-

toregressive models. In Acoustics, Speech and Signal

Processing, 2007. ICASSP 2007. IEEE International

Conference on, volume 4, pages 957–960. IEEE.

El Ayadi, M., Kamel, M. S., and Karray, F. (2011). Sur-

vey on speech emotion recognition: Features, classi-

ﬁcation schemes, and databases. Pattern Recognition,

44(3):572–587.

Elman, J. L. (1990). Finding structure in time. Cognitive

Science, 14(2):179–211.

Fant, G. (1960). Acoustic theory of speech production.

Mounton, The Hague.

Ganchev, T., Fakotakis, N., and Kokkinakis, G. (2005).

Comparative evaluation of various mfcc implementa-

tions on the speaker veriﬁcation task. In Proc. of the

SPECOM, pages 191–194.

Gl¨uge, S., B¨ock, R., and Wendemuth, A. (2010a). Im-

plicit sequence learning - a case study with a 4-2-4

encoder simple recurrent network. In Proceedings of

the International Conference on Fuzzy Computation

and 2nd International Conference on Neural Compu-

tation, pages 279–288.

Gl¨uge, S., Hamid, O. H., and Wendemuth, A. (2010b). A

simple recurrent network for implicit learning of tem-

poral sequences. Cognitive Computation, 2(4):265–

271.

Grimm, M., Kroschel, K., Mower, E., and Narayanan, S.

(2007). Primitives-based evaluation and estimation of

emotions in speech. Speech Communication, 49(10-

11):787–800.

Hermansky, H. (1990). Perceptual linear predictive (PLP)

analysis of speech. Journal of the Acoustical Society

of America, 87(4):1738–1752.

Hitch, G. J., Burgess, N., Towse, J. N., and Culpin, V.

(1996). Temporal grouping effects in immediate re-

call: A working memory analysis. Quarterly Journal

of Experimental Psychology Section A: Human Exper-

imental Psychology, 49(1):116–139.

Hochreiter, S. (1998). The vanishing gradient problem dur-

ing learning recurrent neural nets and problem solu-

tions. International Journal of Uncertainty, Fuzziness

and Knowledge-Based Systems, 6(2):107–116.

H¨ubner, D., Vlasenko, B., Grosser, T., and Wendemuth,

A. (2010). Determining optimal features for emo-

tion recognition from speech by applying an evolu-

tionary algorithm. In INTERSPEECH 2010, pages

2358–2361.

Inoue, T., Nakagawa, R., Kondou, M., Koga, T., and Shi-

nohara, K. (2011). Discrimination between mothers’

infant- and adult-directed speech using hidden markov

models. Neuroscience Research, 70(1):62–70.

Kim, W. and Hansen, J. (2010). Angry emotion detec-

tion from real-life conversational speech by leverag-

ing content structure. In Acoustics Speech and Signal

Processing (ICASSP), 2010 IEEE International Con-

ference on, pages 5166–5169.

Mehrabian, A. (1996). Pleasure-arousal-dominance: A gen-

eral framework for describing and measuring individ-

ual differences in temperament. Current Psychology,

14(4):261–292.

M¨uller, M. (2007). Information Retrieval for Music and

Motion. Springer Verlag.

Nicholson, J., Takahashi, K., and Nakatsu, R. (1999). Emo-

tion recognition in speech using neural networks. In

Neural Information Processing, 1999. Proceedings.

ICONIP ’99. 6th International Conference on, vol-

ume 2, pages 495–501.

Nwe, T. L., Foo, S. W., and Silva, L. C. D. (2003). Speech

emotion recognition using hidden markov models.

Speech Communication, 41(4):603–623.

Petrushin, V. A. (2000). Emotion recognition in speech

signal: experimental study, development, and appli-

cation. In Proceedings of the ICSLP 2000, volume 2,

pages 222–225.

Pierre-Yves, O. (2003). The production and recognition of

emotions in speech: features and algorithms. Inter-

national Journal of Human-Computer Studies, 59(1-

2):157 – 183. Applications of Affective Computing in

Human-Computer Interaction.

Rabiner, L. and Juang, B.-H. (1993). Fundamentals of

NCTA 2011 - International Conference on Neural Computation Theory and Applications

314

Speech Recognition. Prentice Hall, New Jersey, 8th

edition.

Scherer, S., Oubbati, M., Schwenker, F., and Palm, G.

(2008). Real-time emotion recognition using echo

state networks. In Andr´e, E., Dybkjr, L., Minker, W.,

Neumann, H., Pieraccini, R., and Weber, M., editors,

Perception in Multimodal Dialogue Systems, volume

5078 of Lecture Notes in Computer Science, pages

200–204. Springer Berlin / Heidelberg.

Schmidt, M., Schels, M., and Schwenker, F. (2010). A

hidden markov model based approach for facial ex-

pression recognition in image sequences. In Lecture

Notes in Computer Science (including subseries Lec-

ture Notes in Artiﬁcial Intelligence and Lecture Notes

in Bioinformatics), volume 5998 LNAI, pages 149–

160. Springer.

Schuller, B., Batliner, A., Steidl, S., and Seppi, D. (2011).

Recognising realistic emotions and affect in speech:

State of the art and lessons learnt from the ﬁrst chal-

lenge. Speech Communication. Article in Press.

Schuller, B., Rigoll, G., and Lang, M. (2004). Speech

emotion recognition combining acoustic features and

linguistic information in a hybrid support vector

machine-belief network architecture. In Acoustics,

Speech, and Signal Processing, 2004. Proceedings.

(ICASSP ’04). IEEE International Conference on, vol-

ume 1, pages I – 577–80 vol.1.

Schuller, B., Steidl, S., and Batliner, A. (2009a). The in-

terspeech 2009 emotion challenge. In Tenth Annual

Conference of the International Speech Communica-

tion Association, pages 312–315.

Schuller, B., Vlasenko, B., Eyben, F., Rigoll, G., and

Wendemuth, A. (2009b). Acoustic emotion recog-

nition: A benchmark comparison of performances.

In Automatic Speech Recognition & Understanding,

2009. ASRU 2009. IEEE Workshop on, pages 552–

557. IEEE.

Severin, F. T. and Rigby, M. K. (1963). Inﬂuence of digit

grouping on memory for telephone numbers. Journal

of Applied Psychology, 47(2):117–119.

Song, M., You, M., Li, N., and Chen, C. (2008). A robust

multimodal approach for emotion recognition. Neuro-

computing, 71(10-12):1913–1920.

Trentin, E., Scherer, S., and Schwenker, F. (2010). Max-

imum echo-state-likelihood networks for emotion

recognition. In Schwenker, F. and El Gayar, N., ed-

itors, Artiﬁcial Neural Networks in Pattern Recogni-

tion, volume 5998 of Lecture Notes in Computer Sci-

ence, pages 60–71. Springer Berlin / Heidelberg.

Tuzlukov, V. P. (2000). Signal Detection Theory.

Birkh¨auser, Boston.

Cerˇnansk´y, M. and Beˇnuˇskova, L. (2003). Simple recur-

rent network trained by rtrl and extended kalman ﬁlter

algorithms. Neural Network World, 13(3):223–234.

Ververidis, D. and Kotropoulos, C. (2006). Emotional

speech recognition: Resources, features, and methods.

Speech Communication, 48(9):1162–1181.

Viterbi, A. J. (1967). Error bounds for convolutional codes

and an asymptotically optimal decoding algorithm.

IEEE Transactions on Information Theory, 13:260–

269.

Vlasenko, B., Schuller, B., Wendemuth, A., and Rigoll, G.

(2008). On the inﬂuence of phonetic content vari-

ation for acoustic emotion recognition. In Percep-

tion in Multimodal Dialogue Systems, volume 5078 of

Lecture Notes in Computer Science, pages 217–220.

Springer Berlin / Heidelberg.

Vlasenko, B. and Wendemuth, A. (2009a). Heading toward

to the natural way of human-machine interaction: the

nimitek project. In Multimedia and Expo, 2009. ICME

2009. IEEE International Conference on, pages 950–

953.

Vlasenko, B. and Wendemuth, A. (2009b). Processing af-

fected speech within human machine interaction. In

INTERSPEECH-2009, volume 3, pages 2039–2042,

Brighton.

Williams, R. J. and Zipser, D. (1995). Gradient-based

learning algorithms for recurrent networks and their

computational complexity, pages 433–486. L. Erl-

baum Associates Inc., Hillsdale, NJ, USA.

W¨ollmer, M., Eyben, F., Reiter, S., Schuller, B., Cox, C.,

Douglas-Cowie, E., and Cowie, R. (2008). Aban-

doning emotion classes - towards continuous emotion

recognition with modelling of long-range dependen-

cies. In INTERSPEECH-2008, pages 597–600.

Yingthawornsuk, T. and Shiavi, R. (2008). Distinguishing

depression and suicidal risk in men using gmm based

frequency contents ofaffective vocal tract response. In

Control, Automation and Systems, 2008. ICCAS 2008.

International Conference on, pages 901–904.

Young, S. J., Evermann, G., Gales, M. J. F., Hain, T., Ker-

shaw, D., Moore, G., Odell, J., Ollason, D., Povey, D.,

Valtchev, V., and Woodland, P. C. (2006). The HTK

Book, version 3.4. Cambridge University Engineering

Department, Cambridge, UK.

SEGMENTED-MEMORY RECURRENT NEURAL NETWORKS VERSUS HIDDEN MARKOV MODELS IN

EMOTION RECOGNITION FROM SPEECH

315
