ARCHITECTURE OF MEDPEER

A New P2P-based System for Integration of Heterogeneous Data Sources

Naïma Souâd Ougouti

, Haféda Belbachir

, Youssef Amghar

and Nabila Aicha Benharkat

LSSD Laboratory, U.S.T.O LP 1505 El MNaouer, 31000, Oran, Algeria

LIRIS UMR 5205, Insa of Lyon, 69620 cedex, Villeurbanne, France

Keywords: Data Mediation, Peer-to-peer Networks, Ontologies, Semantic Web.

Abstract. In this article, we present Medpeer, a new peer-to-peer (P2P) management system for heterogeneous and

distributed data sources. Its principal goal is to provide necessary tools for the semantic mediation of data

from various types (relational, image, text,..) and for the semantic routing of multimodal queries in an P2P

environment. In this environment, each peer will be able to publish the data he wants to share, he is

completely autonomous and the data can belong to different models. MedPeer is a Super-Peer system where

the super-peers are organized by type of data and contain an ontological structure specific to each type.

Each peer exports their data in a common format in the form of a semantically rich ontology in order to

contribute to schemas reconciliation. The queries exchanged have a common format in the form of XML

documents, and are routed towards the relevant peers thanks to a semantic topology built on top of the

existing physical topology.

1 INTRODUCTION

Access to distributed, heterogeneous and

autonomous information sources, has become

possible with the Internet. These information sources

are distinguished by the nature of information,

namely, the ontological domain to which they

belong but also by the type of media they are born

by, such as image, text, video, etc... With the advent

of the semantic web, new opportunities in multi-

sources integration are emerging and many

approaches are revisited, taking into account the new

requirements. We also observe the use or reuse of

datawarehouses, mediators and especially peer-to-

peer systems (Ougouti, 2010).

Recently, several PDMS (Peer Dated

Management Systems) have been born. Senpeer

(Faye, 2006),, Edutella (Nejdl

, 2002), Piazza

(Halevy, 2003), PEPSINT (Cruz, 2004), PeerDB

(Ng, 2003) and Hyperion (Arenas, 2003)

are some

examples of these systems. They combine files

exchange P2P technology such as Napster and

Kaaza with that of distributed databases. They are

based on the semantic description of data sources

that allows also semantic and

intelligent queries

routing and results integration. But, we have noted

that the majority of these systems like Edutella and

PeerDb, treat a maximum of one data model or two

at the same time and do not allow complex and

multimodal queries whose results can be various

types of data like texts, videos and images.

Our objective is to propose solutions to these

problems by presenting a new PDMS: MedPeer. The

principal goal of this system is to provide the

necessary tools for the semantic mediation of

various types of data (relational, image, text,..), the

treatment and semantic routing of multimodal

queries in a P2P environment. In this environment,

each peer will be able to publish the data they want

to share, they are completely autonomous and the

data can belong to different models.

In this article we will only present the

architecture of our system, it is organized as follows:

In section 2 we will present the MedPeer

architecture, and then we will end with a conclusion

and suggest orientations for future work.

2 MEDPEER ARCHITECTURE

2.1 MedPeer Topology

MedPeer has a Super-peer architecture based on

regrouping of peers according to the type of media

351

Ougouti N., Belbachir H., Amghar Y. and Aicha Benharkat N..

ARCHITECTURE OF MEDPEER - A New P2P-based System for Integration of Heterogeneous Data Sources.

DOI: 10.5220/0003661603510354

In Proceedings of the International Conference on Knowledge Management and Information Sharing (KMIS-2011), pages 351-354

ISBN: 978-989-8425-81-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

(Texts, Images, Relational databases, semi-

structured,..). This architecture combines a

centralized approach with a non structured one thus

bringing the advantages of centralized research such

as autonomy, and robustness for a distributed

research.

Each super-peer manages the peers containing the

same type of media it is meant to represent; it is

selected according to its calculation capacities and

band-width. In addition, it must have all the

necessary information to be able to direct the

requests arriving to it towards the relevant peers.

The super-peers form between them a pure P2P

network. The peers having different schemas, a

semantic mediation is essential between them.

Figure 1: MedPeer Architecture.

In such a system, to avoid the excessive

translations between peers, there must exist a well

adapted common language; in order to answer this

requirement, we will use an interchange schema

format, based on ontologies, and called structure

ontology. Each super-peer contains a structure

ontology specific to the field it manages. This will

permit semantic schema exchanges between peers

without making assumptions on the data model. A

query interchange format, based on XML allows the

query exchange between peers. In what follows, we

will present in detail the peer and super-peer

components.

2.2 Peer Structure

Each peer has the following components:

Data Source (DS): Each peer is independent

from the others, it contains one or more data

sources which can be relational databases, XML

documents or an images database. The peer

contains its own indexing and research system

by using a suitable, according to the model,

interrogation language (SQL, XQuery, visual,

etc).

Figure 2: Peer Structure.

• Sources Description Module: To regulate the

problem of peers syntactic and semantic

heterogeneity in a community, we use an

ontology as an internal model to represent the

semantic contents of peers. Each data source

present in the peer will be described by an

ontology called lsonto

, when i is the source

identifier. These ontologies will be regularly sent

to the super-peer community, to enable it to

generate the semantic correspondences. This also

makes it possible

to deal with the possible

modifications in data sources, then with the

system dynamicity

• Wrapper: This module rewrites the internal

queries into a common exchange format in the

form of an XML document. If the query is

multimodal i.e. returning several types of data in

answer, it will be decomposed by type of data.

Each subquery will be sent to the super-peer

responsible for treating it. This module also

converts the incoming query into the data

model of the local peer.

• Query Manager: Allows the execution of the

local query on the peer and the routing of

subqueries towards the suitable super-peers.

• User Interface: Allows the user to formulate a

local query on its data or a global one on the

network. The queries may refer just to one type

of data and thus carried out within the same

community or to many types of data and thus

carried out through different communities.

• Communication Module: We use JXTA

Open Source platform of Sun to enable the

communication between peers.

2.3 Super-peer Structure

Each super-peer has the following components:

KMIS 2011 - International Conference on Knowledge Management and Information Sharing

352

• Structure Ontology: It is an ontology that

reflects the community data structuring which

the super-peer is responsible. To each type of

data (relational, image..) is associated a structure

ontology that makes it possible to unify the local

concepts used for a semantic reconciliation.

• Mapping Manager: The purpose of this

module is to find all the mappings between data

sources local concepts and those of the structure

ontology thanks to a similarity function which

takes into account the linguistic and semantic

aspects and the various concepts of the semantic

area. The correspondences thus generated will be

stored into an XML document.

• Query Manager: Contains two modules: The

first rewrites the query with the local concepts of

the relevant peers, while the second roots them

towards these same peers. It achieves an

intelligent routing that represents one of the

advantages of the system.

• Network Index: The index contains all

information on the peers of the community and

on all the super-peers of the system. This

information relates to IP address, speed, etc.

• Communication Module: Similar to that of the

peer, based on JXTA platform of Sun.

Figure 3 : Super-peer Structure.

2.4 Ontologies

2.4.1 Structure Ontology

It is an ontology which gathers the whole of the

concepts resulting from the vocabulary used in the

medical field such as the names of relations,

elements or attributes. We propose an ontology

where each concept is defined by its identifier, its

name and its type, it can be connected to other

concepts by certains properties. A property is

defined by its name, its domain and its range, as well

as by its type (aggregation, Composition,

Association, synonym). This ontology is written

with the OWL/RDF language, it takes into account

all types of data defined in the XML Schema

recommendation which provides 44 different types

of data including 19 primitive types and 25 derived

types.

2.4.2 Data Sources Description Ontologies

To facilitate the semantic reconciliation between

peers’ schemas, we describe them thanks to

ontologies. Each handled term in the data sources,

like relation, XML document, attribute or an image

descriptor will be described by the means of a set of

synonyms. In addition, concepts are connected

between them by defined semantic properties

(aggregation, association or composition).

To each concept, a single concept (preferred

term) from the structure ontology will be associated

through the use of a global similarity measurement.

Here is, as an example the diagram of an ontology

describing XML documents.

2.5 Community Creation

When a new super-peer SPj joins the PDMS, it must

present its structure ontology. It announces its

arrival to peers and waits until those among them

that are interested propose their adhesion. This Asp

advertisement is in the form of an XML document,

containing the following information: Aspj=(IDSPj,

URIOsj, TDj,

acc

, TTL), in which IDSPj is the

identifier of the super-peer SPj and thus of the

community which it represents, URIOsj represents

the uniform resource identifier of the community

structure ontology, TDj the community data type

(BDR, XML, Texts, Images....),

acc

the minimum

value similarity to accept a mapping between a local

concept and a structure ontology concept. The TTL

(time to live) represents a given delay that stops the

advertisement from buckling

2.6 Peer Adhesion to a Community

When a peer Pi is interested by the super-peer

advertisement, it makes an adhesion request

PiAdh=(IDP, Oli), where IDP is the identifier of the

peer and Oli its local ontology. For each adhesion,

the super-peer index will be will be fed this

information.

The peer will have to give sign of life to the

super-peer before the delay expires. Beyond this

ARCHITECTURE OF MEDPEER - A New P2P-based System for Integration of Heterogeneous Data Sources

353

period if the peer does not manifest itself, it will be

excluded from semantic topology. With its re-

registration, it will have to remake all the known

stages, to take into account possible changes

(addition, suppression, modification) in its structure.

This guarantees a dynamic behavior within the

PDMS, which is strongly desirable in P2P systems.

2.7 Semantic Topology

Nowadays, it has been clearly demonstrated that the

inundation principle in query routing in PDMS

slows down the scale passage. It is thus imperative,

to proceed through a semantic and intelligent

routing.

Semantic topology in MedPeer is built on top of

the physical network, to allow direct queries towards

the relevant peers only. It is built by the super-peer

on the basis of semantic mappings stored within

XML documents.

3 CONCLUSIONS

The current tendency is to revisit the integration

approaches based on mediation and datawarehouses

or to suggest other peer-to-peer systems using the

new possibilities offered by the semantic Web.

The use of ontologies has proved very effective in

semantic integration in the mediators approaches.

But these mediation integration systems are not very

flexible, and the global schema could become a

bottleneck. A strong need, for new decentralized and

dynamic tools is being felt. The peer-to-peer systems

are regarded as a good solution for the Web scale

passage. They present the advantage that they do not

need a single schema, that they allow adding data

and information on the schema of each peer and to

query each peer with its own query language but

they do not handle data semantics. Dealing with

ontologies create a new problem in this field, which

is the definition of semantic mappings between

ontologies in an automatic way.

The MedPeer system that we have presented in

this article takes into account semantics by

describing the sources thanks to ontologies written

with OWL language. The semantic mappings

discovery then becomes easier. The architecture we

propose was conceived with the purpose of dealing

with all types of data such images, videos, texts,

relational data..etc. There is only to define,

beforehand, the specific structure ontology of each

field, or to enrich the one presented in this article.

Our future work will consist in:

• Validating the global similarity function between

two concepts.

• Finding a common queries exchange format

based on XML.

• Defining queries decomposition, rewriting and

routing algorithms.

REFERENCES

Ougouti N. S., Belbachir H., Amghar Y., Benharkat N.,

2010. Integration of Heterogeneous Dated Sources.

Journal of Applied Sciences, 10 (22): (2) 2923-2928,.

Faye D., Nachouki G, Valduriez P., 2006. Integration of

heterogeneous data in SenPeer. ARIMA, Volume

5–1-8

Nejdl W, Wolf B, C qu, Decker S., Sintek Mr., Naeve A.,

Nilsson Mr., Palmér Mr., and Risch T., 2002.

EDUTELLA: With P2P Networking Based

Infrastructure one RDF. In Proceedings of the 11th

International World Wide Web Conference

(WWW2002)

Halevy A. Y., Ives Z G. _ Peter, Mr Tatarinov. I., 2003.

Piazza: Dated Management Infrastructure for

Semantic Web Applications. ACM 1-58113-680-3/

03/0005, Budapest, Hungry

Cruz I F, Xiao H., Hsu F., 2004. Peer-to-Peer Semantic

Integration of XML and RDF Dated Sources. Internal

report, Department of Computer Science, University of

Illinois at Chicago, the USA

Ng W S., Ooi B C, Tan K, and . Zhou A., 2003. PeerDB:

In P2P-based System for Distributed Dated Sharing. In

Proceedings of the 19th International Conference one

Dated Engineering ICDE 633 –644

Arenas Mr., Kantere V, Kementsietsidis A., Kiringa I.,

Miller R. J., and Mylopoulos J., 2003. The Hyperion

Project: From Dated Integration to Data Coordination.

SIGMOD Record32(3):53 –38

KMIS 2011 - International Conference on Knowledge Management and Information Sharing

354
