LINKED DATA MEETS ONTOLOGY MATCHING

Enhancing Data Linking through Ontology Alignments

Franc¸ois Scharffe

and J

ome Euzenat

LIRMM, University of Montpellier, 161 Rue Ada, Montpellier, France

INRIA, 655 Avenue de l’Europe, Montbonnot, France

Keywords:

Semantic web, Linked data, Data linking, Ontology alignment, Ontology matching, Entity reconciliation,

Object consolidation.

Abstract:

The Web of data consists of publishing data on the Web in such a way that they can be connected together

and interpreted. It is thus critical to establish links between these data, both for the Web of data and for the

Semantic Web that it contributes to feed. We consider here the various techniques which have been developed

for that purpose and analyze their commonalities and differences. This provides a general framework that the

diverse data linking systems instantiate. From this framework we consider the relation between data linking

and ontology matching activities. Although, they can be considered similar at a certain level (they both relate

formal entities), they serve different purposes: one acts at the schema level and the other at the instance level.

However, they would ﬁnd a mutual beneﬁt at collaborating. We thus present a scheme under which it is

possible for data linking tools to take advantage of ontology alignments. We present the features of expressive

alignment languages that allows linking speciﬁcations to reuse ontology alignments in a natural way.

1 INTRODUCTION

The Web of data is the network resulting from pub-

lishing structured data sources in RDF and inter-

linking these data sources with explicit links. Web

datasets are expressed according to one or more vo-

cabularies or ontologies, which range from simple

database schema exposure to full-ﬂedged ontologies.

The Web of data requires to interlink the various

published data sources. Given the large amount of

published data, it is necessary to provide means to au-

tomatically link those data. Many tools were recently

proposed in order to solve this problem, each having

its own characteristics.

In many cases, datasets containing similar re-

sources are published using different ontologies.

Hence, data interlinking tools need to reconcile these

ontologies before ﬁnding the links between entities.

This could be done automatically, but more often this

is done manually and built in the link speciﬁcations.

This has two drawbacks: (a) this prevents to reuse the

work made in ontology matching for reconciling on-

tologies and (b) the information about reconciling the

ontologies is mixed with the information about how

to identify entities.

Hence, the goal of this work is to consider data

interlinking and ontology matching and to determine

how these two activities are related and how they

could better cooperate.

For that purpose, after brieﬂy introducing the chal-

lenges of data interlinking and ontology matching

(Section 2), we provide a general framework for data

interlinking (Section 3). This framework clearly sep-

arates the data interlinking and ontology matching

activities and we show how these can collaborate

through three different languages for links, data link-

ing speciﬁcation and ontology alignment. We provide

examples of an expressive alignment language and a

modiﬁed linking speciﬁcation language that can im-

plement this cooperation (Section 4).

An extended version of this paper is available as a

technical report (Scharffe and Euzenat, 2011).

2 WEB OF DATA, DATA

INTERLINKING, AND

ONTOLOGY ALIGNMENT

We brieﬂy introduce the data interlinking problem.

We provide examples of this problem and why it

would require speciﬁc linking tools. We then present

279

Scharffe F. and Euzenat J..

LINKED DATA MEETS ONTOLOGY MATCHING - Enhancing Data Linking through Ontology Alignments.

DOI: 10.5220/0003666002790284

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2011), pages 279-284

ISBN: 978-989-8425-80-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

why these tools could take advantage of ontology

matching and alignments.

The main problem on the Web of data is to create

links between entities of different datasets. Most of-

ten, this consists of identifying the same entity across

different datasets and publishing a link between them

as a sameAs statement. We call this task data interlink-

ing and summarize it in Figure 1.

URI1 URI2

Data interlinking

owl:sameAs

Figure 1: The data interlinking problem.

Once identiﬁed, the links discovered between two

datasets must also be published in order to be reused.

The VoiD vocabulary (Alexander et al., 2009) allows

for describing linksets as special datasets containing

sets of links between resources of two given datasets.

Once linksets are constructed, two approaches are

proposed to retrieve equivalences between resources:

it is possible to assign to each real world entity a

global identiﬁer that will then be related to every URIs

describing this entity. This is the approach taken in

the OKKAM project (Bouquet et al., 2008) that pro-

poses the usage of Entity Name Servers taking the

role of resource name repositories. The other ap-

proach uses equivalence lists maintained with inter-

linked resources across datasets. There is thus no

global identiﬁer in this approach but equivalence links

can be followed using a third-party Web service, e.g.,

http://sameas.org, or a bilatteral protocol (Volz et al.,

2009).

The data interlinking task can be achieved manu-

ally or with the help of data interlinking tools. These

tools take as input two datasets and ultimately provide

a linkset. In addition, they use what we call a linking

speciﬁcation, i.e., a “script” specifying how and/or

what to link. Indeed, given dataset sizes, the search

space for resources interlinking can reach many bil-

lion resources, e.g., DBPedia. It is thus necessary to

use heuristics giving hints to the interlinking system

where to look for the corresponding resources in the

two datasets. These linking speciﬁcations can be spe-

ciﬁc to a pair of datasets and can be reused for re-

generating linksets (we provide an example of such a

speciﬁcation in the Silk language in Section 4).

Mining for similar resources in two Web datasets

raises many problems. Each datasets having its own

namespace, resources in different datasets are given

different URIs. Also, although naming conventions

exist, there is no formal nor standard way of naming

resources. For example, if we take the URI for the fa-

mous musician Johann Sebastian Bach in various Web

datasets we obtain very different results even though

they all represent the same real world object.

Fortunately, dereferencing URIs can be used for

retrieving more information about entities: property

values and related resources can be observed. But

for a same real-world entity, the same property can

take different values, making the interlinking process

more difﬁcult. This can be because of varying value

approximations across datasets, because of different

units of measure, because of mistakes in the datasets,

or because of loose ontological speciﬁcations. For

instance, the property foaf:name does not specify in

what format should the name be given. “J.S. Bach”,

“Bach, J.S.” or “Johann Sebastian Bach” are possible

values for this property. Hence, data interlinking tools

have to compare property values in order to decide if

two entities are the same, and must be linked, or not.

For that purpose, tools use similarity measures based

on the type of values (e.g., string, numbers, dates) and

aggregate the results of these measures. This activity

is reminiscent of record linkage which has been given

considerable attention in database (Fellegi and Sunter,

1969; Winkler, 2006; Elmagarmid et al., 2007).

Another problem is caused by the usage of het-

erogeneous ontologies for describing datasets. In this

case, a same resource is typed according to differ-

ent classes and described with different RDF pred-

icates belonging to different ontologies. For exam-

ple, a name in a dataset can be attributed using the

foaf:name data property from the FOAF ontology

while it is attributed using the vcard:N object prop-

erty from the VCard ontology in another dataset.

Hence, for the interlinking techniques to work, it

is necessary that the datasets use the same ontology

or that data interlinking tools are aware of the corre-

spondences between ontologies.

The goal of this paper is to investigate the relation-

ships between data interlinking and ontology match-

ing (Euzenat and Shvaiko, 2007). In particular, we

want to understand if these two activities would ben-

eﬁt to be merged into a single activity and sharing the

same formats.

3 A FRAMEWORK FOR DATA

INTERLINKING

We provide in this section a general framework en-

compassing the various approaches used to interlink

resources on the Web of data. We ﬁrst consider each

case that may happen when interlinking data and de-

scribe them abstractly and through an example. In the

KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development

280

end, we unify all this cases in a common framework.

In the ﬁrst case resources are manually inter-

linked. Manually linking resources can be performed

using collaborative tools in the case of large datasets.

In some cases, illustrated below, resources can be

trivially linked using a simple transformation of their

URIs.

URI1 URI2

URI transformation

owl:sameAs

Figure 2: URI transformation.

A set of rules can be deﬁned to identify equiva-

lent resources from their identiﬁer. For example, in

the dataset LastFM

, the URI representing an artist

is built on the pattern “First name+Last name”. Per-

son URIs in DBPedia

are built around the pattern

“FirstName LastName”. A trivial algorithm can be

developed to ﬁnd equivalent artists based on their

URIs.

Further that the URIs, it may be necessary to con-

sider the ontologies in order to identify entities. In

a ﬁrst case, the two datasets to interlink are described

by the same ontology. The role of the interlinking sys-

tem is to analyze resources of the same type in order

to detect the equivalent ones. To do this, the system

compares resource properties with a similarity mea-

sure. Systems in this category take as input the prop-

erties to compare, the type of comparison algorithm to

use for each property, and the method to aggregate the

similarity measures of the various properties in order

to construct a measure between two resources.

URI1

URI2

Resource matching of

datasets described by

the same ontology

owl:sameAs

Figure 3: Matching two datasets described according to the

same ontology.

For example, Jamendo and MusicBrainz, two

datasets containing musicological data, are both de-

scribed according to a common music ontology (Rai-

mond et al., 2007). The artist J.S. Bach can be iden-

tiﬁed in both datasets by observing the ﬁrst name and

last name properties of the class MusicArtist. It is not

http://last.fm

http://dbpedia.org

possible in this case to identify the equivalence of re-

sources based on their URIs. This example is illus-

trated in Figure 4.

URI1

URI2

first

mo:MusicArtist

last

first

last

Johann-

Sebastian

Bach

Jean-

Sébastien

Bach

Resource matching algorithm,

datasets described according

to a common ontology

type

DBPedia

Musicbrainz

Figure 4: Example of matching two datasets described ac-

cording to the same ontology.

Datasets can be described by different ontologies.

This case is illustrated in Figure 5. In order to know

which types of entities have to be linked together, the

system needs to know the correspondences between

these types of entities. Then it can work similarly as

if there were a single ontology.

We represent this case in Figure 5 by introducing

the correspondences between ontology classes as an

alignment. This alignment is presented as implicit be-

cause it does not exist as such, but it is mixed with the

data interlinking speciﬁcation or system.

O1 O2

URI1 URI2

Implicit alignment

Resource matching of

datasets described by

different ontologies

owl:sameAs

Figure 5: Two datasets matched using an implicit align-

ment.

For example, OpenCyc

represents the artist J.S.

Bach using a different ontology than the one used

to describe MusicBrainz. The properties “ﬁrstname”

and “lastname” correspond to a property “EnglishID”

in which both names are concatenated. The class Mu-

sicArtist in the Music Ontology corresponds to a class

Classical Music Composer in OpenCyc. An align-

ment between classes and properties needs to be spec-

iﬁed in order to ﬁnd an equivalence between the two

resources. This example is illustrated in Figure 6.

sw.opencyc.org

LINKED DATA MEETS ONTOLOGY MATCHING - Enhancing Data Linking through Ontology Alignments

281

URI1

URI2

mo:MusicArtist

givenname

name

Sebastian

Bach"

"Johann

"Jean-Sébastien"

"Bach"

type

OpenCyc

Musicbrainz

Classical Music Performer

English ID

Figure 6: Example of two datasets described with heteroge-

neous ontologies.

O1 O2

URI1 URI2

Explicit alignment

Resource matching of

datasets described by

different ontologies

owl:sameAs

Figure 7: Two datasets matched using an explicit alignment.

Another approach, illustrated in Figure 7, takes

advantage of an already existing explicit alignment

between the two ontologies used by the datasets.

An additional possibility, not found in existing

systems, would be for the data linking system to ﬁrst

match the two ontologies before using the resulting

alignment for supporting data interlinking. In such

a system, ontology matching and data interlinking

would be merged.

Figure 8 uniﬁes all these processes in a single de-

scription. This framework leads to clarify interactions

between data interlinking and ontology matching. It

would be useful to use it in order to make tools in-

teroperate. This would present many advantages, in

particular the possibility to share, distribute and im-

prove link speciﬁcations, as well as reuse them or ex-

tend them instead of computing them again whenever

a dataset is modiﬁed. This would also allow to com-

pose linking speciﬁcations such that it would be pos-

sible to go from one dataset to another without going

through an intermediary. We consider below many

possible ways to realize this integration.

O1 O2

URI1 URI2

Ontology matching

Alignment

Data interlinking

owl:sameAs

Figure 8: General framework for data interlinking involving

ontology matching.

The next section discusses how using ontology

alignments could lead to more automation for the

interlinking task, as well as how linked data could

provide evidence for obtaining better ontology align-

ments.

4 DATA INTERLINKING USING

ONTOLOGY ALIGNMENTS

Although ontology matching and data interlinking

can be similar at a certain level (they both relate for-

mal entities), there are important differences as dis-

played by the the previous framework. Indeed, one

acts at the schema level and the other at the instance

level. These differences are reﬂected in the types of

speciﬁcation involved in these processes - asameAs

statement tells which City in wikipedia correspond

to which P (place) in geonames, - a linking speciﬁca-

tion tells how to ﬁnd the former, an ontology align-

ment tells which components from one ontology cor-

responds to which components in the other. This re-

sults in two process speciﬁcations – interlinking and

matching – and their results – linksets between data

and alignments between ontologies. By clearly es-

tablishing these differences, we obtain a natural parti-

tioning between data links, linking speciﬁcations and

ontology alignments:

The assertion expression language allows for rep-

resenting equivalence between resources in

datasets, e.g., RDF and VoiD;

The linking speciﬁcation language allows for

deﬁning how to search for equivalence between

resources, e.g., Silk;

The alignment representation language allows for

specifying equivalence rules between ontological

entities, e.g., the Alignment format or EDOAL

(see below).

However, data interlinking and ontology match-

ing could ﬁnd a mutual beneﬁt at collaborating. We

propose a scheme under which it is possible for data

linking tools to take ontology alignments as a way to

constrain their solution space. The of Section 3, as

displayed in Figure 8, provides a natural way to im-

plement this collaboration.

EDOAL (Expressive Declarative Ontology Align-

ment Language) is the new name of the OMWG map-

ping language for expressing ontology alignment (Eu-

zenat et al., 2007) that has been available through the

Alignment API since version 3.1. This language is

an extension of the Alignment format (David et al.,

2011) that can be generated by most matchers. Its

main purpose is to offer more expressiveness in the

KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development

282

way alignments are expressed so it can represent com-

plex alignment patterns (Scharffe and Fensel, 2008;

Scharffe, 2009). It presents the advantage to be

declarative and also to specify transformations like

those needed in order to construct links between re-

sources.

In particular, EDOAL allows for expressing con-

textual relations between elements. For instance, the

typical example in Silk documentation is the link-

ing of DBpedia cities and geoname P(laces) through

comparing their names and populations. Expressing

this with a simple alignment does not express the ex-

pected meaning because, of course, rdfs:label is not

equivalent to gn:name. One could consider expressing

that gn:name is more speciﬁc than rdfs:label. This

is correct but still not precise enough. The intended

meaning is that, in the context of dbpdia:City and

gn:P, these two properties are equivalent. This is what

EDOAL can express through the following alignment:

:dbp-geo a align:Alignment;

align:onto1 <http://dbpedia.org/ontology/>;

align:onto2 <http://www.geonames.org/ontology#>;

align:map [ :map1 a align:Cell;

align:entity1 dbpedia:City;

align:entity2 gn:P;

align:relation align:subsumedBy.

];

align:map [ :map2 a align:Cell;

align:entity1 [ a align:Property;

edoal:and dbpedia:populationTotal.

edoal:and [ a edoal:PropertyDomainRestriction;

edoal:domain dbpedia:City.

];

align:entity2 [ a align:Property;

edoal:and gn:population;

edoal:and [ a edoal:PropertyDomainRestriction;

edoal:domain gn:P. ];

align:relation align:equivalent.

];

align:map [ :map2 a align:Cell;

align:entity1 [ a align:Property;

edoal:and rdfs:label.

edoal:and [ a edoal:PropertyDomainRestriction;

edoal:domain dbpedia:City.

];

align:entity2 [ a align:Property;

edoal:and gn:name;

edoal:and [ a edoal:PropertyDomainRestriction;

edoal:domain gn:P. ];

align:relation align:equivalent.

Even if such an alignment would provide infor-

mation to data interlinking tools, this is still not suf-

ﬁcient. Of course, it tells which properties should be

equivalent and thus can be used for identifying enti-

ties. But it does not tell how to take them into account.

So, this alignement would be sufﬁcient to link entities

if the values of rdfs:label were exactly the same as

those of gn:name and the values of populationTotal

were exactly the same as those of population, but not

otherwise.

EDOAL provides more features for transforming

this information. This could be helpful but the prob-

lem is deeper: data interlinking is a decision problem

rather that just a transformation. It is the role of the

data linking speciﬁcation to tell when a dbpedia:City

and a gn:P should be considered the same. This is

why we propose to use data interlinking speciﬁcations

together with alignments.

Indeed, using an explicit alignment, provided that

it is expressive enough, can serve two functions:

1. narrowing the search space through pointing to

equivalent concepts, and

2. providing the properties that can be used for iden-

tifying concepts.

A link speciﬁcation like Silk-LSL (Bizer et al.,

2009) fulﬁlls two roles: - it is an alignment: it speci-

ﬁes the classes in which entities to link can be found,

it speciﬁes how to link entities. It could be possible to

refer to an external alignment between the two under-

lying ontologies instead of specifying it in the link-

ing speciﬁcation. This approach would present ob-

vious reuse advantages when other datasets requiring

the same alignment, i.e., using the same ontologies,

need to be interlinked.

Given that the alignment is available, it is pos-

sible to simplify the Silk speciﬁcation and refer to

the alignment, by introducing three types of informa-

tion: which alignments to use (UseAlignment), entities

of which correspondences must be linked (LinkCell)

and which matched properties can be compared for

identifying entities (CellParam).

<LinkType>owl:sameAs</LinkType>

<AVG>

</Compare>

</Compare>

</AVG>

</LinkCondition>

<Output acceptedLinks="accepted_links.n3"

verifyLinks="verify_links.n3"

mode="truncate" />

</Interlink>

The speciﬁcs of the data interlinking task remain

in this speciﬁcation: how to compare values, how to

aggregate their results and when to issue the link or

LINKED DATA MEETS ONTOLOGY MATCHING - Enhancing Data Linking through Ontology Alignments

283

not.

This approach presents several advantages:

1. The link speciﬁcation is simpliﬁed, reducing the

manual input;

2. The alignment can be reused for linking any two

datasets described according to these two ontolo-

gies;

3. There is a clear separation between links, linking

speciﬁcation, and ontology alignments.

5 CONCLUSIONS

We have proposed an architecture based on three dif-

ferent languages having each its own precise pur-

pose: expressing links, expressing linking speciﬁca-

tions, and expressing ontology alignments. This ar-

chitecture can be used in order to organize a better

collaboration between ontology matchers and data in-

terlinking tools. This can be achieved with only min-

imal extensions to existing languages. In particular,

we have illustrated the ontology alignment part with

EDOAL, an expressive ontology alignment language

that offers the necessary concepts for being used in

data interlinking. On the data interlinking side, we

have focussed on the Silk-LSL language which seems

to be at once declarative and powerful enough to ex-

press a wide range of constraints on data interlinking.

Extending it with the capacity to beneﬁt from ontol-

ogy alignments would allow tools using it to beneﬁt

from the wide range of ontology alignment techniques

and tools.

ACKNOWLEDGEMENTS

This work was conducted in the context of the Datalift

project funded by the French ANR (Agence Nationale

de la Recherche) under grant ANR-10-CORD-009.

REFERENCES

Alexander, K., Cyganiak, R., Hausenblas, M., and Zhao, J.

(2009). Describing linked datasets - on the design and

usage of void, the ’vocabulary of interlinked datasets’.

In Linked Data on the Web Workshop (LDOW09),

Workshop at 18th International World Wide Web Con-

ference (WWW09), Madrid, Spain.

Bizer, C., Volz, J., Kobilarov, G., and Gaedke, M. (2009).

Silk - a link discovery framework for the web of data.

In 18th International World Wide Web Conference.

Bouquet, P., Stoermer, H., and Bazzanella, B. (2008). An

Entity Naming System for the Semantic Web. In Pro-

ceedings of the 5th European Semantic Web Confer-

ence (ESWC2008), LNCS.

David, J., Euzenat, J., Scharffe, F., and dos Santos, C. T.

(2011). The alignment api 4.0. Semantic Web, 2(1):3–

10.

Elmagarmid, A., Ipeirotis, P., and Verykios, V. (2007). Du-

plicate record detection: A survey. IEEE Transactions

on Knowledge and Data Engineering, 19(1):1–16.

Euzenat, J., Scharffe, F., and Zimmermann, A. (2007).

D2.2.10: Expressive alignment language and imple-

mentation. Project deliverable 2.2.10, Knowledge

Web NoE (FP6-507482).

Euzenat, J. and Shvaiko, P. (2007). Ontology matching.

Springer-Verlag, Heidelberg (DE).

Fellegi, I. P. and Sunter, A. B. (1969). A theory for record

linkage. Journal of the American Statistical Associa-

tion, 64(328):1183–1210.

Raimond, Y., Abdallah, S., Sandler, M., and Giasson, F.

(2007). The music ontology. In Proceedings of the

International Conference on Music Information Re-

trieval.

Scharffe, F. (2009). Correspondence Patterns Representa-

tion. PhD thesis, University of Innsbruck.

Scharffe, F. and Euzenat, J. (2011). MeLinDa: an inter-

linking framework for the web of data. Rapport de

recherche 7691, INRIA.

Scharffe, F. and Fensel, D. (2008). Correspondence pat-

terns for ontology mediation. In Springer, editor,

Proceedings of the 16th International Conference on

Knowledge Engineering and Knowledge Management

(EKAW2008), pages 83–92.

Volz, J., Bizer, C., and Gaedke, M. (2009). Web of data link

maintenance protocol. Protocol speciﬁcation, Frei

Universit

at Berlin.

Winkler, W. (2006). Overview of record linkage and current

research directions. Technical Report 2006-2, Statis-

tical Research Division. U.S. Census Bureau.

KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development

284
