GENETIC PROGRAMMING WITH EMBEDDED FEATURES

OF SYMBOLIC COMPUTATIONS

Yaroslav V. Borcheninov and Yuri S. Okulovsky

Institute of Mathematics and Computer Sciences, Ural Federal University, Mira str. 56, Yekaterinburg, Russia

Keywords:

Genetic programming, Symbolic computations.

Abstract:

Genetic programming is a methodology, widely used in data mining for obtaining the analytic form that

describes a given experimental data set. In some cases, genetic programming is complemented by symbolic

computations that simplify found expressions. We propose to unify the induction of genetic programming

with the deduction of symbolic computations in one genetic algorithm. Our approach was implemented as

the .NET library and successfully tested at various data mining problems: function approximation, invariants

ﬁnding and classiﬁcation.

1 INTRODUCTION

Genetic programming (Koza, 1992) is a methodology

of using the genetic algorithms (Goldberg, 1986) to

ﬁnd a program that performs a user-speciﬁed task. We

consider the particular case of genetic programming

that operates not with arbitrary programs, but with

expressions. Genetic programming (GP) is widely

used to obtain the analytic form of the experimental

data in natural sciences (Schmidt and Lipson, 2009),

robotics (Robertson and Dumont, 2002), economics

(Koza, 1994), medicine (Zhang and Wong, 2008), etc.

The classic GP approach can shortly be described

as follows. The expressions are represented as the op-

erator trees. Initially, the population consists of the

randomly generated expressions. On each algorithm’s

iteration, the following actions are performed:

• Mutation. The randomly chosen expression is

changed by a replacement of a node.

• Crossover. Two randomly chosen expressions ex-

change subtrees.

• After all the mutations and crossovers are per-

formed, the resulting expressions’ set is subjected

to the selection, which evaluates how each expres-

sion ﬁts the experimental data. The least valuable

expressions are then removed from the popula-

tion.

The well known problem of GP is the excessive

growing of expressions, or bloating. Various methods

are proposed to resolve the issue: the limitation of

the tree’s depth; special mutations and crossovers that

preserve the expressions’ size; selection that sorts out

bloated trees (Poli et al., 2008); removal of subtrees

that have lesser analogues in the population (Mori

et al., 2009).

The obvious way to reduce the expression’s size

is the algebraic or numerical simpliﬁcation. If the

algorithm has succeeded in ﬁnding a correct expres-

sion, the expression can be then simpliﬁed for a bet-

ter perception. However, aside from producing non-

aesthetic solutions, bloating also signiﬁcantly reduces

the algorithm’s performance. Recent studies (Zhang

et al., 2006; Kinzett et al., 2008) show the effective-

ness of the online simpliﬁcation, when expressions

are simpliﬁed during the evolution.

The simpliﬁcation of the expression inevitably

leads to the potential growing points’ elimination. For

example, while approximating the function (x+ 1)y

the intermediate solution (1 + 1)y

1+1

can be found.

This solution will be simpliﬁed to 2y

, which requires

at least two mutations to become a correct answer,

e.g. 2y

⇒ xy

⇒ (x + 1)y

. The initial solution

(1+1)y

1+1

requires only one mutation (1+1)y

1+1

⇒

(x + 1)y

1+1

. Hence, the simpliﬁcation hampers the

evolution in this case. On other hand, the partial

simpliﬁcation (1+ 1)y

1+1

⇒ (1+ 1)y

does not show

such effect for the function (x + 1)y

, but does so for

x+1

. Therefore, the question of where to apply the

simpliﬁcation depends on the problem speciﬁcation,

on the particular found expression, etc.

The main idea of our work is to integrate the on-

line simpliﬁcation — and, more general, arbitrary

symbolic computations — with genetic programming

476

V. Borcheninov Y. and S. Okulovsky Y..

GENETIC PROGRAMMING WITH EMBEDDED FEATURES OF SYMBOLIC COMPUTATIONS.

DOI: 10.5220/0003682004680471

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 468-471

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

on the most basic level. Symbolic computations trans-

form the expression according to some rules and do

not change the function, encoded by the expression.

Let us call such transformations deductive. Transform

x+ 2x ⇒ 3x is both deductive and simplifying, while

(x + y)z ⇒ xz + yz is deductive but not simplifying,

since it is not always clear, which form is more prefer-

able. The inductive transforms change both the form

of the expression and the encoded function. Muta-

tions and crossovers described above are inductive.

To combine inductive and deductive transforms,

we introduce the following changes in the classic ge-

netic programming algorithm. For the mutations, a

collection of rules is deﬁned. Each rule transforms an

expression in inductive or deductive way. When we

need to perform the mutation operation, we randomly

select a rule from the collection and apply it to an ex-

pression. Crossover is also deﬁned by the set of rules.

Crossover’s rules have a slightly different format, they

accept two expressions and produce one.

Inductive transforms bloat the tree, while deduc-

tive transforms hamper the induction. Therefore, in-

ductive and deductive tendencies are in the opposi-

tion. Therefore, we should measure the ﬁtness for

both tendencies independently, to ﬁnd the appropri-

ate balance between them. In our variation of GP,

the selection is performed based on various metrics.

We calculate these metrics for each expression, obtain

their weighted total, and then remove the expressions

that have the least weighted total in the population.

Our approach was implemented in C# language

(Drayton et al., 2002) as a library for .NET frame-

work, and tested in various data mining problems.

The project will be released under GPL v.3. license.

2 ALGORITHM’S ESSENTIALS

An expression is represented as a tree of nodes. Three

types of nodes are considered: constants, variables

and operators. Each node has a return type, which

is an arbitrary C# type. Different return types can be

used in one expression.

Each tree can be compiled into .NET lambda ex-

pression. Suppose f(x

,. .. ,x

) is a function en-

coded by a tree. Let a be an array of the argu-

ments a = (x

,. .. ,x

). A node for a constant c is

compiled into the lambda a 7→ c. A node for the i-

th variable is compiled to a 7→ a[i]. If a node en-

codes an operator g(y

,. .. ,y

), it is compiled into

a 7→ g(c

(a),. .. ,c

(a)), where c

is the compiled i-

th child of the node. The compilation of the nodes is

possible due to the abstract syntax trees, one of .NET

features. It improves the performance of the evalua-

tion.

Trees can be modiﬁed according to rules. A rule

consists of a condition and an action. The ﬁrst stage

of a rule’s application is ﬁnding all the tuples of nodes

that satisfy the condition. The second stage is to ap-

ply the action to one of the selected tuples. Let us

consider some examples of the rules.

select ?A where A.Type=double

mod A→Plus(A,c)

(R1)

Here A is an identiﬁer of selected node, c is a ran-

dom constant. The rule R1 processes a tree and selects

all its nodes of

double

type. It is possible to apply the

rule to one of the selected nodes, and replace the node

with a new subtree.

The R1 rule allows us introducing an addition in a

tree. Due to the type check

A.Type=double

, the

Plus

operation can only be applied to a

double

node, and

therefore the tree remains correct. That shows how

the rules assure the correctness of the mutations and

crossover.

The following R2 rule shows, how the operation

can be removed from a tree.

select ?A(.B) where A.Type=B.Type

mod A→B

(R2)

The rule R2 searches for all pairs (A, B), where A is

an arbitrary node, B is an arbitrary child of A, and

types of A and B coincide. In each such pair, A can be

replaced with B.

We also need rules for simpliﬁcation of expres-

sions. The following rules R3 and R4 are examples of

such rules.

select ?A(.B,.C) where A is Plus &&

B is Const &&

C is Const

mod A→B.Val+C.Val

(R3)

select ?A(B(C)) where A is Minus &&

B is Minus

mod A→C

(R4)

Crossover can also be based on the rules. The

following rule R5 is the simplest crossover that ex-

changes subtrees.

select ?A,?B where A.Type=B.Type

produce A→B; ret A.Root

(R5)

This rule accepts two trees, searches for a pair

(A,B) where A is from the ﬁrst tree, B is from the sec-

ond tree, and their types coincide. Since the rule ac-

cepts two trees instead of one, it is not clear in which

of them the crossover’s result is stored. To resolve

this, the mod clause is replaced with the produce

clause, which modiﬁes trees and returns some node

as the result of the rule’s application. More complex

crossover schemata are available. For example, the

following rule R6

GENETIC PROGRAMMING WITH EMBEDDED FEATURES OF SYMBOLIC COMPUTATIONS

477

select A,B where A.Type=double &&

B.Type=double

produce ret Div(Plus(A,B),2)

(R6)

is applicable only to the trees’ roots A and B and re-

turns their half-sum.

We have developed an elegant way to deﬁne rules

in C#. The rules can be programmed in the almost

natural way, by only deﬁning its logic, without exces-

sive code to adopt this logic to C#. That was achieved

with the intensive use of lambda-expressions, gener-

ics and code generation. For example, rule R1 can be

programmed with the code in List. 1.

Listing 1: Rule R1 deﬁnition in C#.

var rule=Rule

.New("Intro +")

.Select("?A")

.Where<INode>(c=>c.A.Type

==typeof(double))

.Mod(c=>c.A.Replace(new Plus(c.A,0)))

Rules are very numerous and their categorization

is necessary. The ﬁrst category is universal rules that

are applicable to any expressions. The rules R2 and

R5 are in this category. The second category of rules

describes data types. The following rules are required

for each data type:

T1 Introduction of the constant: replacement of a

subtree with the return type

to a constant of the

same type;

T2 Introduction of the varuable: replacement of a

subtree with the return type

to a variable of the

same type;

T3 Adjustment of the constant: replacement of a con-

stant by another constant with the close value.

For example, ﬂoating point constant c may be

replaced to a random number from an interval

[c(1− ε),c(1 + ε)].

Rules of the third category describe domains of op-

erations: the sets of operations that are often used in

expressions together. For example, the algebraic do-

main consists of addition, subtraction, multiplication,

and so on. In each domain, the following types of

rules should be developed:

D1 Introduction of each operator (R1);

D2 Calculation rules for each operator (R3);

D3 Deductive rules for the operators (R4, distributiv-

ity laws, De Morgan’s laws);

D4 Special crossover rules, if they are available (R6).

In the programming implementation, an arbitrary

amount of tags can be chosen for each rule. Tags

indicate the category of the rule, the domain it be-

longs to, whether the rule is purposed for mutation

or crossover, etc. During the work of the algorithm,

each tag is associated with its weight. We calculate

the weight of each rule as a product of associated tags’

weights. The weight of the rule determines how often

it will be used. The probability of applying a rule with

weight w is w/W, where W is a total sum of all rules’

weights. Tags and weights allow us managing the al-

gorithm. For example, on the early stage, when the

optimal solution is not found, inductive rules should

be applied more often. When the optimal solution is

found and we need to get its acceptable presentation,

we should use calculation and deductive rules.

3 APPLICATION AREAS AND

METRICS

In the function approximation problem we are given

a set of tuples {(x

i,1

i,2

,. .. ,x

i,m

) : i = 1,... ,n},

where y

= f(x

i,1

,. .. ,x

i,m

)·c

and c

is a random num-

ber from the interval [1− α,1+ α]. The goal is to ﬁnd

the analytic form of f. To do that, we use our algo-

rithm with the following two metrics. Fitness metric

for the function g, found by the algorithm, is calcu-

lated as

ρ(g) =

∑

i=1

|g(x

i,1

,. .. ,x

i,m

) − y

−1

Taking the reciprocal value is important, because it

allows bounding the value of ρ, and provides corre-

spondence between a higher value of ρ and a better

expression.

Length metric λ(g) is a number, reciprocal to the

count of operations in g. Valuation of an expression

is determined as a weighted total e(g) = w

ρ(g) +

λ(g). Typically, w

= 1 and w

= 0.1. In our

implementation of the algorithm, we allow user ad-

justing metrics’ weights during the algorithm’s work.

Such adjustment leads to interesting effects. For ex-

ample, setting the weight of the length metric to a

negative value can drive the algorithm out of the local

minimum. On the other hand, when the average ρ of

the population is high, increasing the length metric to

0.2–0.3 allows ﬁnding the most compact form of g.

In the invariants ﬁnding problem we are given the

set {(x

i,1

i,2

,. .. ,x

i,m

) : i = 1,... ,n} and need to

ﬁnd such f that f(x

i,1

,. .. ,x

i,m

) ≈ 0 (or equals to zero

in the absence of the noise). The algorithm requires

three metric to solve the problem. The ﬁrst metric is

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

478

the length metric λ. The second metric is the invari-

ance metric

ι( f) =

∑

i=1

i,1

,. .. ,x

i,m

)

−1

However, these two metrics are not enough. The ex-

pression

100

is almost invariant on small x, how-

ever this expression is not acceptable. The solution is

introducing the tautology metric

τ( f) = 1−

∑

i=1

i,1

,. .. ,y

i,m

)

−1

where y

i, j

are random numbers. Typical weights of

metrics are w

= 1, w

= 1 and w

= 0.1.

In classiﬁcation problem we are given the set

{(x

i,1

i,2

,. .. ,x

i,m

) : i = 1,.. .,n}, where c

is a

Boolean value indicating whether the corresponded

tuple belongs to a class. We need to use the rules for

ﬂoating point type and associated operators’ domains;

rules to support Boolean type (deﬁned by items T1–

T3 in the section 2); rules to support relation operators

<, >, = (only D1 and D2, because these operators do

not preserve the operands’ types); rules for operators

∨, ∧, ¬ (D1–D4).

The ﬁtness metric is adjusted as follows

σ(g) =



|{i : g(x

i,1

,. .. ,x

i,m

) = c



−1

4 CONCLUSIONS AND FUTURE

WORK

We have proposed a methodology of genetic pro-

gramming algorithm that embeds the features of

symbolic computations. This approach was imple-

mented in .NET library. We have supported alge-

braic, trigonometric and comparison operations with

ﬂoating-points numbers, as well as logical operations

with Boolean values. Using the library, we were able

to solve the different data mining problems: function

approximation, invariants ﬁnding and classiﬁcation.

Our future research will be conducted in the fol-

lowing directions:

• Finding the parameters that provide the most ef-

ﬁcient GP performance. By our observation,

changing of rules’ and metrics’ weights leads to

signiﬁcant changes in performance. Moreover,

changing the parameters during the algorithm’s

work has different effect depending on the current

state of the population. We believe that the thor-

ough examination of such effects can lead to sig-

niﬁcant improvements in genetic programming.

• Using genetic programming in new domains:

fuzzy numbers, fuzzy logic, temporal logic, etc.

• Exploring substitutions for length metric. Length

metric does not seem to catch the intuitive mean-

ing of a “good” expression. We plan to introduce

computation complexityand aesthetics metrics in-

stead, and understand how it improves the work of

the algorithm.

ACKNOWLEDGEMENTS

The work is supported by the Russian Federation

President’s program MK-844.2011.1.

REFERENCES

Drayton, P., Albahari, B., and Neward, T. (2002). C# in a

Nutshell. O’Reilly.

Goldberg, D. (1986). Genetic Algorithms in Search, Opti-

mization, and Machine Learning. Addison-Wesley.

Kinzett, D., Johnston, M., and Zhang, M. (2008). Numer-

ical simpliﬁcation for bloat control and analysis of

building blocks in genetic programming. Evolution-

ary Intelligence, 4.

Koza, J. R. (1992). Genetic programming: on the program-

ming of computers by means of natural selection. MIT

Press, Cambridge, MA.

Koza, J. R. (1994). Genetic programming for economic

modeling. In Intelligent Systems for Finance and

Business.

Mori, N., McKay, B., Hoai, N. X., Essam, D., and Takeuchi,

S. (2009). A new method for simplifying algebraic

expressions in genetic programming called equiva-

lent decision simpliﬁcation. Journal of Advanced

Computational Intelligence and Intelligent Informat-

ics, 13(14):237–238.

Poli, R., Langdon, W. B., McPhee, N. F., and Koza, J. R.

(2008). A Field Guide to Genetic Programming.

Robertson, A. P. and Dumont, C. (2002). Design of robot

calibration models using genetic programming. In

Mayorga, R. V. and Rios, A. S.-D. L., editors, Pro-

ceedings of the Third International Symposium on

Rob. and Autom., volume 3, pages 449–454.

Schmidt, M. and Lipson, H. (2009). Distilling free-

form natural laws from experimental data. Science,

324(5923):81–85.

Zhang, M. and Wong, P. (2008). Genetic programming

for medical classiﬁcation: a program simpliﬁcation

approach. Genetic Programming and Evolvable Ma-

chines, 9(2):229–255.

Zhang, M., Wong, P., and Qian, D. (2006). Online pro-

gram simpliﬁcation in genetic programming. Simu-

lated Evolution and Learning - SEAL, pages 592–600.

GENETIC PROGRAMMING WITH EMBEDDED FEATURES OF SYMBOLIC COMPUTATIONS

479
