CLUSTERING OF HETEROGENEOUSLY TYPED DATA

WITH SOFT COMPUTING

Angel Kuri-Morales

, Luis Enrique Cortes-Berrueco

and Daniel Trejo-Baños

Instituto Tecnológico Autónomo de México, Río Hondo No. 1 México D.F., Mexico

Universidad Nacional Autónoma de México, Apartado Postal 70-600, Ciudad Universitaria, México D.F., Mexico

Keywords: Clustering, Categorical variables, Soft computing, Data mining.

Abstract: The problem of finding clusters in arbitrary sets of data has been attempted using different approaches. In

most cases, the use of metrics in order to determine the adequateness of the said clusters is assumed. That is,

the criteria yielding a measure of quality of the clusters depends on the distance between the elements of

each cluster. Typically, one considers a cluster to be adequately characterized if the elements within a

cluster are close to one another while, simultaneously, they appear to be far from those of different clusters.

This intuitive approach fails if the variables of the elements of a cluster are not amenable to distance

measurements, i.e., if the vectors of such elements cannot be quantified. This case arises frequently in real

world applications where several variables correspond to categories. The usual tendency is to assign

arbitrary numbers to every category: to encode the categories. This, however, may result in spurious

patterns: relationships between the variables which are not really there at the offset. It is evident that there is

no truly valid assignment which may ensure a universally valid numerical value to this kind of variables.

But there is a strategy which guarantees that the encoding will, in general, not bias the results. In this paper

we explore such strategy. We discuss the theoretical foundations of our approach and prove that this is the

best strategy in terms of the statistical behaviour of the sampled data. We also show that, when applied to a

complex real world problem, it allows us to generalize soft computing methods to find the number and

characteristics of a set of clusters.

1 INTRODUCTION

Clustering can be considered the most important

unsupervised learning problem. As every other

problem of this kind, it deals with finding a structure

in a collection of unlabeled data. In this particular

case it is of relevance because we attempt to

characterize sets of data trying not to start from

preconceived measures of what makes a set of

characteristics relevant.

When the similarity criterion is distance: two or

more objects belong to the same cluster if they are

“close” according to a given distance (in this case, as

will be discussed, geometrical distance). This is

called distance-based clustering.

An important component of a clustering

algorithm is the distance measure between data

points.

Regardless of the distance we select it is clear

that it implies handling of exclusively numerical

vectors. To illustrate this fact we mention four of the

most used metric clustering algorithms:

• K-means

• Fuzzy C-means

• Hierarchical clustering

• Neural Networks (Self Organizing Maps)

K-means is an exclusive clustering algorithm, Fuzzy

C-means is an overlapping clustering algorithm,

Hierarchical clustering is obvious and, lastly, SOMs

are based on the connectionist paradigm.

The mentioned methods are conceptually

different. These methods are all, however, metric. It

is clear, that all of the metric algorithms are rendered

useless when one or more of the variables is non-

numeric. And this underlines the importance of

being able to encode categorical variables. As stated

before, we focus on finding an adequate encoding. A

natural alternative, of course, is to abandon metric

algorithms and there have been many attempts to do

so (Shyam, 2008).

499

Kuri-Morales A., Cortes-Berrueco L. and Trejo-Baños D..

CLUSTERING OF HETEROGENEOUSLY TYPED DATA WITH SOFT COMPUTING.

DOI: 10.5220/0003690304910494

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 491-494

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

2 UNBIASED ENCODING OF

CATEGORICAL VARIABLES

We introduce an alternative which allows the

generalization of numerical algorithms to encompass

categorical variables. Our concern is that such

encoding:

a) Does not induce spurious patterns

b) Preserves legal patters, i.e. those present in the

original data.

By "spurious" patterns we mean those which may

arise by the artificial distance induced by any

encoding. On the other hand, we do not wish to filter

out those patterns which are present in the

categories. If there is an association pattern in the

original data, we want to preserve this association

and, furthermore, we wish to preserve it in the same

way as it presents itself in the original data. The

basic idea is simple: "Find the encoding which best

preserves a measure of similarity between all

numerical and categorical variables".

In order to do this we start by selecting Pearson's

correlation as a measure of linear dependence

between two variables. Higher order dependencies

will be hopefully found by the clustering algorithms.

This is one of several possible alternatives. Its

advantage is that it offers a simple way to detect

simple linear relations between two variables. Its

calculation yields "r", Pearson's correlation, as

follows:

 









































YXXYN

(1)

Where variables X and Y are analyzed to search

their correlation, i.e. the way in which one of the

variables changes (linearly) with relation to the

other. The values of "r" in (1) satisfy







What we shall do is to search for an encoding for

categorical variable “A” so that the correlation

calculated from such encoding does not yield a

significant difference with any of the possible

encodings of all other categorical or numerical

variables.

2.1 The Algorithm

We define the i-th instance of a categorical variable

as one possible value of variable X. We denote

the number of variables in the data as V. Further, we

denote with r

Pearson's correlation between

variables i and k. We would like to a) Find the mean

μ of the correlation's probability distribution for all

categorical variables by analyzing all possible

combinations of codes assignable to the categorical

variables plus the original (numerical) values of all

non-categorical variables. b) Select the codes for the

categorical variables which yield the closest value to

μ. The rationale is that the absolute typical value of

μ is the one devoid of spurious patterns and the one

preserving the legal patterns. In the algorithm to be

discussed next the following notation applies:

N  number of elements in the data

V  number of categorical variables

V[i] the i-th variable

 number of instances of V[i]

 the mean of the j-th sample

S  sample size of a mean



 mean of the correlation's

distribution of means



 standard deviation of the

correlation's distribution of means

Algorithm A1. Optimal Code Assignment for Categorical

Variables.

01 for i=1 to V

02 j  0

03 do while

is not distri-

buted normally

04 for k=1 to S

05 Assign a code for variable

V[i]

06 Store this code

  integer random number

(1≤  ≤ V;  ≠i)

08 if variable V[  ] is cate-

gorical

09 Assign a code for

variable V[

 ]

10 endif





















YYNXXN

YXXYN

12 endfor

13 Calculate







14 j  j+1

15 enddo





; the mean of the

correlation's distribution





; the std. dev. of the

correlation's distribution

18 Select the code for V[i] which

yields the

closest to

19 endfor

For simplicity, in the formula of line (11), X stands

for variable V[i] and Y stands for variable V[

 ]. Of

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

500

course it is impossible to consider all codes, let

alone all possible combinations of such codes.

Therefore, in algorithm A1 we set a more modest

goal and adopt the convention that to Assign a Code

[as in lines (05) and (09)] means that we restrict

ourselves to the combinations of integers between 1

and Ni (recall that Ni is the number different values

of variable i in the data). Still, there are Ni! possible

ways to assign a code to categorical variable i and

Ni! x Nj! possible encodings of two categorical

variables i and j. An exhaustive search is, in general,

out of the question. Instead, we take advantage of

the fact that, regardless of the way a random variable

distributes (here the value of the random encoding of

variables i and j results in correlation r

which is a

random variable itself) the means of sufficiently

large samples very closely approach a normal

distribution(Feller, 1966). Furthermore, the mean

value of a sample of means

μ and its standard

deviation

σ are related to the mean μ and standard

deviation σ of the original distribution by

μμ 

and

σSSσ  . What a sufficiently large sample

means is a matter of convention and here we made

S=25 which is a reasonable choice. Therefore, the

loop between lines (03) and (15) is guaranteed to

end. In our implementation we split the area under

the normal curve in deciles and then used a

goodness-of-fit test with p=0.05 to determine that

normality has been achieved. This approach is

directed to avoid arbitrary assumptions regarding the

correlation's distribution and, therefore, not selecting

a sample size to establish the reliability of our

results. Rather, the algorithm determines at what

point the proper value of μ has been reached.

Furthermore, from Chebyshev's theorem, we know

that:

1)(

kXkP 



(2)

If we make k=3 and assume a symmetrical

distribution, the probability of being within three σ's

of the mean is roughly 0.95.

Three other issues remain to be clarified.

1) To Assign a code to V[i] means that we generate

a sequence of numbers between 1 and Ni and then

randomly assign a one of these numbers to every

different instance of V[i].

2) To Store the code [as in line (06)] means NOT

that we store the assigned code (for this would imply

storing a large set of sequences). Rather, we store

the value of the calculated correlation along with the

root of the pseudo random number generator from

which the assignment was derived.

3) Thereafter, selecting the best code (i.e. the one

yielding a correlation whose value is closest to μ) as

in line (18) is a simple matter of recovering the root

of the pseudo random number generator and

regenerating the original random sequence from it.

3 CASE STUDY: PROFILE OF

CAUSES OF DEATH IN A

LARGE HUMAN POPULATION

In order to illustrate our method we analyzed a data

base corresponding to the life span and cause of

death of 50,000 individuals between the years of

1900 and 2007. The confidentiality of the data has

been preserved by changing the locations and

regions involved. Otherwise data are a faithful

replica of the original.

The database contains 50,000 tuples consisting

of 11 fields: BirthYear, LivingIn, DeathPlace,

DeathYear, DeathMonth, DeathCause, Region, Sex,

AgeGroup, AilmentGroup and InterestGroup.

Therefore, our working data base has 10 dimensions

since the last variable (InterestGroup) corresponds to

interest groups identified by human healthcare

experts in this particular case and was not

considered. This last field corresponds to a heuristic

clustering of the data and could be used for the final

comparative analysis of resulting clusters as the

comparative analysis between the expert’s clusters

and the resulting clusters. We will explore this line

in future works.

Once the data were encoded, we proceeded to

use an unsupervised learning method for the

clustering process. First we needed to determine the

number of clusters in which we would group our

sample.

We applied the fuzzy c-means algorithm to our

coded sample. To determine the number of clusters

we experimented with 17 different possibilities

(assuming from 2 to 18 clusters). In each step we

calculated the partition coefficient and classification

entropy of the clustered data.

We applied the fuzzy c-means algorithm to our

coded sample. To determine the number of clusters

we experimented with 17 different possibilities

(assuming from 2 to 18 clusters). In each step we

calculated the partition coefficient (pc) and

classification entropy (pe) of the clustered data, see

(Lee, 2005); (Shannon, 1949); (Vinh, 2009). Plotting

CLUSTERING OF HETEROGENEOUSLY TYPED DATA WITH SOFT COMPUTING

501

the values of pc and pe against the number of

clusters we got a graph.

To determine the number of clusters, we used the

elbow criterion, see (Ganti, 1999), which indicates

that we should use the value where the change in

tendency is the most notable, in this case this

occurred with 3 and 4 clusters. For clarity, we

picked 3 clusters for this experiment.

Then we proceeded to apply Kohonen´s SOM to

the data. As all data is now in numerical form, the

algorithm was applicable without alterations over

the set of variables. Therefore, after running the

algorithm our data was classified in three clusters

depending on the neuron which was closer to a

specific data field. We interpreted the results

according to the values of the mean of each variable

on each cluster. We rounded the said values for

BirthYear and DeathCause and obtained the

following decoded values:

For cluster 1 the decoded values of the mean for

BirthYear and DeathCause correspond to “1960”

and cancer.

In cluster 2 the values are “1919” and

Pneumonia.

In cluster 3 the values are “1923” and Heart

stroke.

These logical backward results attest to their

validity which, we emphasize, are obtained from an

unbiased numerical encoding. Therefore we can

infer that legal patterns are preserved and,

furthermore, that such patterns (adequately encoded)

allow a numerical method to find the patterns in

spite of the fact that no unique valid metric does, in

general, exist.

4 CONCLUSIONS

We have shown that we are able to find meaningful

results by applying numerically oriented non-

supervised clustering algorithms to categorical data

by properly encoding the instances of the categories.

We were able to determine the number of clusters

arising from the data encoding according to our

algorithm and, furthermore, to interpret the clusters

in a meaningful way. Rather than a priori accepting

essential limitations in numerical methods when

applied to sets of categorical variables, we have

adopted the point of view that machine learning

techniques allow a broader scope of interpretation

which are not marred by limitations of processing

capabilities.

At any rate, the proposed encoding does allow us

to tackle complex problems without limitation due to

the non-numerical characteristics of the data. It is

also a scalable method and independent of the set of

data. Much work remains to be done, but we are

confident that these is the first of a series of

significant applications.

REFERENCES

V. Ganti, J. Gehrke, and R. Ramakrishnan. Cactus-

Clustering categorical data using summaries. In KDD

'99: Proceedings of the fifth ACM SIGKDD

International Conference on Knowledge Discovery

and Data Mining, pages 73-83, New York, NY, USA,

1999. ACM.

Lee, Y., and Choi, S., Minimum entropy, k-means,

spectral clustering, Neural Networks, 2004.

Proceedings IEEE International Joint Conference on,

volume 1, 2005.

Shannon, C. E., and Weaver, W., The Mathematical

Theory of Communication, Scientific American, July

1949.

Shyam Boriah, Varun Chandola, and Vipin Kumar.

Similarity measures for categorical data: A

comparative evaluation. In SDM, pages 243-254,

2008.

Vinh, N. X., Epps, J., and Bailey, J., Information theoretic

measures for clusterings comparison: is a correction

for chance necessary?

Feller, William, An introduction to probability theory and

its applications. Vol. II., Oxford, England: Wiley.

(1966).

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

502
