How Many Realities Fit Into a Program? Notes on the

Meaning of Meaning for Programs

Daniel Speicher, Jan Nonnen and Holger Mügge

University of Bonn, Computer Science III, Bonn, Germany

Abstract. Programs are written in programming languages with a certain well

deﬁned semantics that describes how an interpreter or a machine will operate

based on the program. Higher level programming languages and especially object-

oriented programming languages encourage programmers to write programs that

contain knowledge and have meaning in an additional sense. This meaning of

program elements, their identiﬁer and the terms from which identiﬁers are built

is the topic of this paper. Programs gather knowledge of different realities. There

is at least an application domain and a technical domain. If we want to make the

knowledge within a program more explicit and accessible, we need to differenti-

ate, which program element refers to which domain.

1 Introduction

The ﬁrst object-oriented programming language “Simula” presented its self-conception

of its mode of denotation, i.e. how it relates to what it represents, in its name: Programs

simulate reality. Objects as deﬁned by the language, behave in a certain sense like real

things, but they are no real things. If we consider programs simulations, programs are

closed worlds simulating something that could be in a real world, but without any con-

nection between these two worlds.

A simulation represents the world that it simulates. So the meaning of the program

is this represented world. And the knowledge about this simulated world within this

program is not hard to ﬁnd: It is just the whole program. In the following we present

some thoughts commenting on the question what it means for a program to mean some-

thing. We hope to contribute thereby to a deeper understanding, how knowledge can be

found within programs. Our comments consider the question in three major steps:

– What is meant by the program? Is meaning in general best understood, if we con-

sider it as representing some reality?

– How does the program mean something? Is the mode of denotation always straight

representation as it is the case for simulations?

– How can the meaning of parts of the program be identiﬁed? What are current ap-

proaches to identify knowledge in programs?

1.1 What is Meant by the Program?

Approximation: Concepts are Meant. Ratiu and Deissenböck report in “How Pro-

grams Represent Reality (and how they don’t)” [9] about a successful approach to iden-

tify semantic defects in programs. Ideally a concept has a unique name which is used as

Speicher D., Nonnen J. and Mügge H..

How Many Realities Fit Into a Program? - Notes on the Meaning of Meaning for Programs.

DOI: 10.5220/0003700000920099

In Proceedings of the 2nd International Workshop on Software Knowledge (SKY-2011), pages 92-99

ISBN: 978-989-8425-82-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

identiﬁer for the program element that represents the concept, e.g. the concept of an ac-

count (that the reader has in mind as soon as its name is mentioned here) is represented

by a class Account. A defect in the sense of the paper is a violation of one of the

one-to-one relationships between program elements (program space

), the lexical ele-

ments in their identiﬁer (lexical space) and the corresponding concepts (concept space).

Program elements represent concepts and that is their meaning. The title of the paper

implicitly identiﬁes the concept space with reality. As a representation of the concept

space the authors used the WordNet ontology [3] and mapped portions of it onto the

program code via graph matching, improved in [10].

Things are Meant! Is it really concepts that are meant by the program? We consult the

philosophical subsection of linguistics that discusses the meaning of meaning: Semi-

otics. Anything that may have a meaning is called a sign in semiotics and relates to

three spaces (called levels) [7, p.24]:

“In considering signs, their relationship to the cognitive world and to the world

of things, it is important to distinguish clearly between three different level of

observation: (a) the linguistic level of signs (words, sentences); (b) the epis-

temological level of cognitive correlates (concepts, propositions, etc.); and (c)

the ontological level of things, truth values, and facts.”

Obviously the linguistic level can be seen as our lexical space and the epistemo-

logical level as our concept space. As the program space can not be identiﬁed with the

ontological layer we need to add a separate space: Reality. We will prefer reality as the

target space of meaning but not strictly exclude the concept space. Soon we will see that

the distinction between concept space and reality is especially important, if the program

interacts with reality.

Given a class SalesContract, “sales contract” has a meaning and “sales” and

“contract” may have a meaning as well. In addition the class itself is a model of a

contract and most of its attributes and methods are models of the state and behavior of

the real contract. Therefore we may as well consider classes, attributes and methods as

signs. If we want to be brief in the following, we use program signs to refer to these

signs in the program space as well as to the signs in the lexical space, i.e. to program

elements and terms.

Some Programs do not Represent. There are signs (in the sense of linguistics) that

have meaning without representing something. Imagine seeing an inattentive person

coming closer to a crowded street so that you fear for her safety. Shouting "hey!" to-

wards her has the clear meaning to get her attention and to make her aware of the situa-

tion, but the word does not represent something. Likewise some programs just contain

a textual representation of yelling at the interpreter or virtual machine.

For object-oriented programs it is quite natural to consider them as representation of

something, as they consist of objects. But in general a programmer might not have had

the intention to represent something with a program. The primary goal of a program is

[9,10] used the term "layer", but for this paper "space" is more instructive.

to inﬂuence a machine to behave in a certain way. The text might be written with the

question in mind “What do I need to write to make the machine do this or that?” And the

answer can be meaningless but effective: Sending a notiﬁcation not because the event

occurred, but because we expect a certain reaction - Programs that rewrite themselves

- Provoking buffer overﬂows - Letting Prolog predicates fail to provoke backtracking.

We suggest that one deﬁnition of “hacking” (in the pejorative sense) could be, that

the program tries to instruct the compiler without creating at least partially consistent

meaning.

Instrumental Notion of Meaning. Is it possible to think about meaning without the

notion of representation? Keller elaborates in [7] besides the representational notion

(based on Aristotle and Frege) the instrumental notion (based on Plato and Wittgen-

stein) of meaning. From the instrumental perspective the core question is: What makes

a sign a good instrument for communication? Or, to transfer a question stated by Plato

(cf. [7, p.viii, p.47]) to our context: “When a programmerwrites this program elementor

term and has that thing in mind, how is it possible that another programmer, who reads

it, knows that the ﬁrst programmer has it in mind.” Elaborating a remark by Wittgen-

stein Keller explains that the consistent use of a sign allows for understanding: “[. ..]

the meaning of a word in a language, L, consists of the rule of its use in L. [...] If you

know how a word is used – if you know the rule of its use in the language L – you know

everything there is to know.” (cf. [7, p.51], emphasis in the original.)

The “rules” Keller refers to are regularities to be processed by the minds of the

human users of the language, not by machines. Such rules for program signs can only

have evolved for program signs that are used within a larger culture of developers. We

suggest that e.g. the use of “open” and “close” is governed by rules of this strength. If an

object provides open and close operations, we expect that it allows for a certain kind of

interaction which is only valid after the open operation and before the close operation is

executed. Developers understand the meaning of “open” and “close” without any notion

of representation. Notice as well that the notion of “certain kind of interactions” is too

imprecise to be checked by a machine but good enough for human minds. The rest of

the rule is a well-formedness condition that is perfectly understandable to machines.

Structural Knowledge. We can make part of the meaning (in the instrumental sense)

of program signs explicit by adding explicit deﬁnitions of the code structures in which

they can be used to our code. Knowledge about structures is already very useful on its

own and there is a whole body of work about mining and representing this knowledge.

Examples are architectural patterns, design patterns and programming idioms. Design

pattern use many terms in analogy to real things (e.g. the Product creating Factory,

Visitors, Observers), but the rules of the usage of these terms in programs have become

so strict, that we can say, that their meaning now lies in their usage.

From a pragmatic

perspective we may – giving up philosophical precision – use the encoded structural

regularities as a representation of the (instrumental) meaning of program signs and call

the space of these regularities the structural domain.

Keller elaborates that the representational notion of meaning does not allow to explain the

evolution of meaning, while the instrumental notion does.

1.2 How does the Program Mean Something?

Objects in programs as well as things in reality have identity, state and behavior. To

implement simulations one can follow a natural modeling approach: Represent the state

of the real thing by attributes of the object and behavior by methods. In this case the

implementation can be an accurate model of the represented reality. If the program does

interact with reality the natural modeling approach fails and programs are for good

reasons systematically distorted representations.

Non-identical Individuals and Speciﬁcations. In a perfect model there would be ex-

actly one object for one thing. Yet, already a standard class like File from the package

java.io expresses that it is not identical with the thing it represents. It is possible to

interact with a File object even when the method exists() returns false or after

calling delete(). While delete() represents a meaningful operation on the real

thing, exists() is only meaningful on the object. A simulation would not need to

care for the lifespan of a real ﬁle and the existence of a ﬁle could easily be represented

by the existence of an object.

For many programs individual things are not important, but sets of individuals

with common properties. We can call the object that speciﬁes such a set following

[4, p.81] a speciﬁcation. Such an object has attributes that correspond to state of all

things in the set, but adds methods that provide information about the set. For example

a conﬁguration for the rocket family Ariane could be represented by an Ariane ob-

ject that one could ask for the number of individuals and a call to new Ariane(5,

“ECA”).numberRocketsBuilt()would yield 33.

Peter Coad: Archetypes. Peter Coad’s Archetypes introduced in [1] are mainly a pre-

cise distinction of entities with respect to their mode of denotation. Objects of a class

of the archetype «party», «place» or «thing», represent a single party/person, a single

location or a single thing. Objects of a class with the archetype «description» represent

more than one thing, i.e. it is a speciﬁcation in the sense we just introduced. Objects of

an «moment-interval» class represent an event or process that takes place at a certain

point in time or extends over a certain time. Objects of a «role» class ﬁnally collect any

information about a «party», «place», «thing» or «description», which are only relevant

in the context of one or more «moment-interval»’s. These distinctions are very relevant

for the process of modeling, but these archetypes can only be understood, by taking

reality into account - a dimension that is not accessible to the compiler.

Mirror, Window, Itself. There are two basic modes an object can interact with the

thing it represents. They result in two different modes of denotation. First, the object

may interact via a boundary with the real thing. This allows the remaining objects to

call methods on the object as if they were operations on the real thing, i.e. the object is a

window to the real thing. Second, other objects indirectly interact with the real thing and

represent the changes in the object, i.e. the object is a mirror of the real thing. Programs

that contain mirrors of windows typically contain as well objects that do not represent

any real thing. Such an object can be just itself.

In a simulation the ability of a rocket to be launched can be represented by a method

Rocket.launch(). In a program controlling a real rocket the same signature can

be used, if we consider the object to be a window to the thing. Unfortunately there

can be many obstacles during a rocket launch - even in the communication between

the program and the real rocket so that Spolsky’s law [11] applies: “All non-trivial

abstractions, to some degree, are leaky.” The abstract representation of the launching

process by the launch() method is in many cases a good model but as obstacles

may occur, the system needs to handle them. Therefore it makes sense to reduce the

illusion of a direct access to the real thing, e.g. by changing the names of class and

method to RocketProxy.initiateLaunch() or by declaring exceptions. Then

the class name expresses that the object is not the rocket itself but a proxy for it. The

method name makes clear that the method invocation does not execute the launch, but

only initiates it, which might fail. The goal of a reconstruction of the model would be to

ﬁnd out that “rocket” is a thing that can “launch”. In addition the reference to the Proxy

design pattern should be detected, as well as if "initiate" has an (instrumental) meaning.

In case the class Rocket is a mirror of a rocket, it probably has no

method launch(). This method will be in another object that uses an object of class

Rocket to store for example the start time of the rocket by invoking a

method Rocket.setLaunchInitiated(Time). The distortions in mirror ob-

jects are larger, but the same amount of knowledge should be represented. Behavior

of the real thing is often represented as state. Sometimes behavior that belongs to the

real things is not present in the mirror object but in the objects collaborating with it.

Systems Automating the Real World. Isoda describes in [6] that for simulations mod-

els can be build by natural modeling. Unfortunately this already not true anymore for

systems that automate the real world, e.g. that facilitate business processes. If the soft-

ware would contain a natural model of the automated real world, it would need to con-

tain itself. In addition the natural modeling approach would lead to classes unrelated

to the business process under consideration, or class that are related but unnecessary

for the implementation, or to methods in necessary classes that are confusing (cf. [6,

p.159]). Therefore already [4, p.31] recommended: “For real-world objects, create sys-

tem representations of those objects that respond to events rather than initiate them.

They should be maintaining a representation of the object, rather than initiating activi-

ties.” In our terminology: These objects should be mirrors. If developers want to make

this explicit, the can name a class instead of Customerfor example CustomerData.

Note that “customer” refers to the application domain and “data” the technical domain

of the (virtual) machine.

Boundary, Control, Entity. The distinction of classes using the UML stereotypes

«boundary», «control», «entity» corresponds to differences in the mode of denotation.

Entities are typically mirrors of real things. Boundaries as elements of the user inter-

face are typically windows (in our sense) to virtual elements on the screen. User and

developers can easily ignore the virtuality of these elements (“mediated immediacy”)

and typically do so. Still there is more about this object than internal state. Classes of

these stereotypes and their names tend to refer to different realities: Entities refer to

the application domain. Boundaries refer to the virtual reality of user interfaces often

mimicking different real devices. Controls might represent processes in the application

domain, but add further more technical processes.

1.3 How Can the Meaning of Parts of the Program be Identiﬁed?

Debugging Method Names. Høst and Østvold presented in [5] an approach to mine

common properties of methods following certain naming schemes. They used proper-

ties like returns-void, creates-own-type-object, catches-exception. The naming schemes

had not been predeﬁned, but they explored for which naming schemes strong statistical

evidence was found. This knowledge was precise and reliable enough to identify meth-

ods with inappropriate names. This work can be seen as an example how knowledge

about the structure of methods can be found in names.

Mining Identiﬁer “Ontologies”. Falleri et al. suggested in [2] to create a WordNet

like structure from method names. The method names are split into terms and tagged

with their part-of-speech. In a second step the terms are sorted by linguistic dominance.

Intuitively a word a dominates a word b, if b renders a more precisely. For example

“getNextWarning” is parsed into (“get”, “next”, “warning”). Adding the part-of-speech

yields the term list ((“get”, Verb), (“next”,Adjective), (“warning”, Noun)). Finally dom-

inance sorting gives ((“get”, Verb), (“warning”, Noun), (“next”, Adjective)). If a term

list is a preﬁx of another term list, it is considered to be a generalization of the later.

Longest common preﬁxes of these term lists are then regarded as entities in their own

right. For example if we have "getPreviousWarning" as well, "getWarning" is added and

considered a generalization of the two other methods.

Location of Origin for Terms in Names. To identify to which reality a term in a

name refers, it is useful to ﬁnd out where in the program it originated. Considering the

identiﬁer “WindowFactory” we will probably ﬁnd both terms to be originating from the

same domain. Either both were ﬁrst used in GUI code or both were ﬁrst used as part

of the model of the application domain. In the identiﬁer “FactoryWindow”, the term

“factory” might stem from the domain model, while “window” is an GUI term. The

“factory” would represent a real factory and the “window” would be a virtual entity in

our program.

In [8] we reported about an extensive exploratory study that deﬁned and evaluated

a heuristic to identify introduction locations. To subsume both notions of meaning we

deﬁned a class c to be an introduction location for a term t, "if the meaning of t can

be understood by reading the code in c." Our heuristic already had a precision of 75%.

Based on the theoretical reﬂections presented in this paper, we can make our deﬁnition

even more precise hopefully leading to further improvements of our heuristic: Program

elements that are models represent. Such an program element should be seen as the

introduction location for all terms in its name as long as there is no better candidate,

i.e. with fewer terms in the name. For terms used in names of program elements that

do not represent but do have meaning in the instrumental sense we have to select the

location that illustrates the rules of its use best. In case we added explicit deﬁnitions of

the structures in our code to our code base, these deﬁnitions should be regarded as the

introduction locations.

1.4 Conclusions, Research Objectives, Approaches

We discussed the representational and the instrumental notion of "meaning" for pro-

gram signs. Typical programs contain program signs representing portions of at least

one application domain and some technical domains. Other program signs allow for

understanding by following regularities in their use. As far as these regularities are

structural, we can deﬁne them as elements of the structural domain and consider the

signs as representing them. This leads us to the research objectives to identify these

regularities and to identify which program signs represent the same domain.

The question whether domains are systems of concepts in mindor of things in reality

is not purely philosophical. Some program elements that represent a real thing can as

well indirectly interact with this thing - a semiotic relation that is speciﬁc for computer

programs. An object interacting with a real thing that it represents is typically either

like a window to or a mirror of it. As windows and mirrors do not perfectly represent

the thing, it is a research objective to reconstruct better models from them. Another

objective is to automatically identify objects that do not represent individual things but

sets of similar individuals.

Once we correctly identiﬁed the meaning of program signs representing the same

domain, the question of the meaning of the whole arises. We expect the composition to

have meaning in the instrumental sense. As such it is rather independent from external

realities, and may dynamically evolve over time. The same is true for program signs

representing structures. This leads to the research question, how such an evolution of

meaning can be identiﬁed.

As a basis for further research, we suggest to conduct thorough code based case

studies: Can an expert developer identify the represented domains for all program signs

in sample objects? Can she identify the modes of denotation for objects and correct

the imperfections? As result we will get annotated code bases, that can be used as

benchmark for algorithms and as prototypes of supplemental knowledge representation.

We demonstrated that certain objects have to be for good reasons imperfect mod-

els. Therefore we suggest to revisit the modeling literature from the last century with

respect to their recommendations, how to translate reality into code. Where modeling

defects are created systematically, we expect that some meaning can be restored based

on manually deﬁned or even mined rules.

The algorithms mentioned in the previous section are promising candidates for an-

swering the research questions stated: Terms that are introduced (in the sense of [8])

in the same package probably refer to the same reality. Complementary [2] identiﬁes

regularly reoccurring combinations of terms that we can expect to have structural mean-

ing. Pattern mining like the approach in [5] on the level of methods even identify some

of the structural regularities. In case we have an ontology as a second representation

of the represented reality the approach presented in [9,10] may be used to identify the

program signs that refer to this reality and to ﬁnd modeling defects. Applying these

technologies on software repositories gives a ﬁrst approach to the identiﬁcation of the

evolution of meaning.

References

1. P. Coad, E. Lefebvre, and J. D. Luca. Java modeling in color with UML: enterprise compo-

nents and process. Java Series. Prentice Hall PTR, 1999.

2. J. R. Falleri, M. Huchard, M. Lafourcade, C. Nebut, V. Prince, and M. Dao. Automatic

Extraction of a WordNet-Like Identifer Network from Software. In ICPC, pages 4–13, 2010.

3. C. Fellbaum. WordNet: an eletronic lexical databse. Cambridge MIT Press, 1999.

4. S. Gossain. Object modeling and design strategies: tips and techniques. Advances in object

technology. Cambridge University Press, 1998.

5. E. W. Høst and B.M. Østvold. Debugging Method Names. In ECOOP, 2009.

6. S. Isoda. Object-oriented real-world modeling revisited. Journal of Systems and Software,

59(2):153–162, 2001.

7. R. Keller. A theory of linguistic signs. Oxford University Press, 1998.

8. J. Nonnen, D. Speicher, and P. Imhoff. Locating the meaning of terms in source code, re-

search on ”term introduction”. In WCRE, 2011.

9. D. Ratiu and F. Deissenböck. How programs represent reality (and how they don’t). In

WCRE, pages 83–92, 2006.

10. D. Ratiu and F. Deissenböck. From reality to programs and (not quite) back again. In ICPC,

pages 91–102, 2007.

11. J. Spolsky. The law of leaky abstractions, 2002. [Online; accessed 01-August-2011], http://
