Monitoring Information Quality: With Applications for

Traffic Management Systems

Markus Helfert

, Fakir Hossain

and Owen Foley

School of Computing, Dublin City University, Glasnevin, Ireland

Galway Mayo Institute of Technology, Dublin Road, Galway, Ireland

Abstract. Information quality (IQ) plays a critical role in all management

systems; however for traffic management systems IQ is often of limited

consideration. The general approach to the study of IQ has offered numerous

management approaches, IQ frameworks and list of IQ criteria. As the volume

of data increases, IQ problems become pervasive. An example is decisions

within traffic surveillance and management system, with its large amount of

real time data and short decision times. Recognizing limitation in the

applicability of current IQ frameworks with our work we aim to provide a

practical-orient approach, and propose a process centric IQ monitoring

framework that can be useful for traffic surveillance and management systems.

Key to our work is the perspective of information systems as information

manufacturing system (IMS). Objective of our information quality monitoring

framework is to develop a comprehensive monitoring system that complements

traffic management and surveillance systems.

1 Introduction

Ensuring the quality of information has become an increasingly important factor in

decision support and management systems [7,11,33,34]. However for traffic

management systems IQ is often of limited consideration. Thus it is not surprising

that traffic surveillance and management systems need to address the issues of

improving information quality in order to be successful. Recognizing the importance

of Information Quality (IQ), practitioners and researchers have considered for many

years ways to improve its quality. Scientists have worked on mathematical and

statistical models to introduce constrain based mechanism to prevent data quality

problems. Management of the process of data generation and the management of

Information Manufacturing Systems (IMS) have also attracted many researchers.

With the increasing importance of IQ, much research in recent years has been focused

on IQ assessment. Researchers have developed many frameworks, criteria lists and

approaches for assessing and measuring IQ. The frameworks most widely used have

been recently documented and adopted by the International Standards Organizations

(ISO) [16].

IQ has been often defined as a measure for ‘fitness for use’ of information [32].

The discussion follows the general quality literature by viewing quality as the

capability to ‘meet or exceed users’ requirements.’ Common examples of IQ

Helfert M., Hossain F. and Foley O. (2011).

Monitoring Information Quality: With Applications for Trafﬁc Management Systems.

In Proceedings of the 1st International Workshop on Future Internet Applications for Trafﬁc Surveillance and Management, pages 114-123

DOI: 10.5220/0004473601140123

 SciTePress

dimensions are accuracy, completeness, consistency, timeliness, interpretability, and

availability. Over the last decade, many studies have confirmed that IQ is a multi-

dimensional concept [e.g. 3,15,28,31,32] and its evaluation should consider different

aspects. The literature provides numerous definitions and taxonomies of IQ

dimensions analyzing the problem in different contexts. Also, literature provides us

with numerous case studies, investigating IQ in practice.

However, the practical application of most of the proposed approaches is still very

limited and continuous improvement activities for data quality are rarely integrated.

Furthermore although some studies examine effects of IQ [e.g. 6], applications of IQ

Management to traffic management and surveillance systems are rare. Therefore the

IQ problem continues to exist. In addition as the volume of data and the complexity of

traffic management system increases [9], IQ problems become pervasive. Most

frameworks are aiming to adopt IQ criteria and to develop suitable and domain

specific measurements. Currently this process requires intensive domain expertise, as

the adoption of the frameworks is limited. Furthermore, Knight and Burn [21] point

out that despite the sizeable body of literature available relatively few researchers

have tackled quantifying some of the conceptual definitions. We also observed that

despite the inherent subjective nature of IQ, most researchers focus on providing a

general applicable IQ framework without considerations of its adoption in different

environments. Neither process mapping nor data modeling provides sufficient

provision to define the required quality that data/information must conform to.

Furthermore, on-going monitoring of the conformance of the information production

process is not possible without developing a cost and time prohibitive data monitoring

system. The problem of data and information quality increases as the volume of data

and the time requirements increase.

Recognizing the limitations of current approaches and aiming to provide a

practical-orient approach, we propose a process centric data quality approach that can

be useful for traffic surveillance and management systems. In contrast to other

approaches we do not aim to develop a domain specific IQ approach. In our work we

aim to develop a more general approach that can then be used in several contexts,

include traffic management and surveillance systems. It also incorporates a technique

to specific suitable data product qualities and assesses its conformance. Objective of

data quality monitoring framework is to develop a comprehensive monitoring system

that for instance can be used to complement the traffic management systems in form

of an information manufacturing system. To test the approach on key develop step is

to design and implement a process independent monitoring system that will

continuously monitor data in traffic management systems to ensure various aspects of

data and information quality.

In this paper we present the overall framework, consider the benefit of a process

centric framework for on-going data quality monitoring and discuss its application to

traffic surveillance and management systems. Our results show that the context

dimension is crucial in IQ assessment and that our framework helps to form context-

aware IQ assessments that indeed can be applied to other contexts. The paper is

structured as follows. In Section 2 we reflect our work with related research and

outline limitations of current approaches. In Section 3 we propose a context-aware IQ

framework which is then used to outline or data quality monitor framework in Section

4. Section 5 concludes the article and presents indications for further research in form

of implementing the framework for traffic management and surveillance systems.

115

2 Related Work

IQ has been investigated for many years and numerous frameworks and criteria lists

have been proposed. Although claims are made to provide generic criteria lists [32],

on closer examination most research has been focused on investigating IQ within a

specific context [e.g.1,4,10,13,20,24]; however traffic surveillance and management

systems are little or not considered [12]. Analyzing some popular IQ frameworks

[18,26,32] we can observe a large number of dimensions and criteria associated with

IQ. One of the most popular and referenced frameworks was proposed by Wang and

Strong [32], and since then has been applied to many contexts and research. A critical

element of any IQ assessment is to assign specific values for each IQ criteria through

objective, repeatable and reliable measures. Over the years a variety of IQ assessment

methodologies have been proposed. [2,8,15,19,22,27,28,30] provide examples of

typical methodologies that can be compared by various criteria [14]. On the one hand,

IQ is often measured with subjective perceptions from information users. On the other

hand, research has developed objective IQ measures on the basis of quality criteria

(mostly for intrinsic IQ characteristics such as accuracy, completeness and

correctness). But as of today no widely accepted IQ framework with generic,

generally applicable measurements is available. This makes the application of IQ

concepts to traffic management and surveillance systems challenging. Furthermore,

most frameworks do not provide any guidelines to apply the framework to various

contexts. Most frameworks only provide very limited assistance for analyzing causes

of insufficient IQ and often do not provide any plan for solving identified problems.

Furthermore most frameworks are limited in considering specific requirements.

The limited work on IQ in traffic management and surveillance systems together

with the challenges to apply foremost IQ approaches to new domains, underpins the

requirement for our current work to design a more general applicable information

quality management approach.

3 A Context-oriented IQ Framework

In order to develop our general applicable IQ framework, we base our concept on two

traditional and well established concepts. In order to structure characteristics of

information, we follow the theory of semiotics. In addition, in order to provide

different quality views, we follow general quality literature and structure quality

along “quality of conformance” and “quality of design”. Semiotic is a relatively

widely established discipline, which has recently received increasing attention.

Indeed, since the publication of Stamper [29] semiotic has revealed its relevance to

information systems (IS) in many research. Stamper extended the traditional three

layers of semiotics (syntactics, semantics and pragmatics) with additional aspects

(physical, empirical and social aspects) forming the “semiotic ladder” that consists of

the views on signs from the perspective of physics, empirics, syntactics, semantic,

pragmatics, and the social world [25].

Furthermore, numerous discussions related to quality indicate that defining quality

is at least as challenging as the term information itself [12,17]. This approach

116

comprises of two aspects of quality:

(1) Quality represents certain product characteristics, which meet customer

needs and thereby provide customer satisfaction.

(2) The absence from deficiencies that result in customer dissatisfaction [17].

In general, the first aspect refers to quality of design whereas the second aspect

refers to quality of conformance [12]. Quality of design addresses the aspect of

information requirements and information product design. “How good are the

requirements met by the information product design?”

The conformance of the final information product with the product design is

addressed by quality of conformance. Quality of conformance takes the divergence of

design with the final product into consideration. Because low quality of design and

low quality of conformance have different causes and therefore different solutions, it

is fundamental to consider both aspects. High quality of design does not mean high

quality of conformance and vice versa. Increasing quality of design tends to result in

higher costs, whereas increasing in quality of conformance tends to results in lower

costs. In addition, higher conformance means fewer complains and therefore

increased customer satisfaction. In this article we limit our discussion of this view on

IQ and refer to [12], in which an application to Data Warehouse Systems is

illustrated.

Having established an IQ framework for relevant IQ dimensions (Table 1), it

needs to be applied to a particular context such as traffic management and

surveillance systems. In order to evaluate the application context, the application of

an IQ framework requires an analysis of the IS environment (e.g. traffic management)

prior to the measurement of IQ dimensions.

Table 1. Information quality dimensions based on Semiotic and Quality aspects [12].

Semiotic

Level

Quality Aspects

Measurement

Approach

Quality of Design

Quality of

Conformance

Pragmatic

Relevance,

completeness

Timeliness, actuality,

efficiency

Information

process, application

Semantic

Precise data

definitions, easy to

understand and

objective data

definitions.

Interpretability, accuracy

(free-of error), consistent

data values, complete data

values, , believability,

reliability

Comparison with

real world and

experience

Syntax

Consistent and

adequate syntax

Syntactical correctness,

consistent representation,

security, accessibility

Syntactical

standards and

agreements

The dimensions for an environment are many and varied. For example for traffic

and surveillance environment timeliness, completeness and accuracy might be of high

priority. They are also highly dynamic, time-depended and different user groups will

117

priorities different dimensions. Knight and Burn [21] indicate that the choice and

implementation of quality related algorithms for Internet searching is very much

dependent on the characteristics of the World Wide Web. In addition, the emergences

of new information system architectures and service oriented architecture (SOA) have

underpinned the importance of the environment and context to the fore. The ability

for organizations to distinguish between the impact of the environment and the

traditional view of IQ dimensions is vital. The employment of traditional IQ

frameworks does not allow for this. This observation led us to the development of an

context-oriented IQ Framework that includes the context dimension and its relation to

information quality measurements.

Technology

Available

Resources (e.g. budget)

Decision

Environment

(Requirements)

Context (e.g. Traffic management and Surveillance System)

Context-specific IQ Measurement

IQ Dimension

Selection

IQ Dimension

Prioritising

Assessment

Te ch niq ue

Objective

Subjective

Dimensions Score

Context-specific

IQ Requirements

…

Assessment

Te ch niq ue

derivation

Data Quality Monitoring

Framework (DQMF)

Fig. 1. Information quality framework (grey area indicates context dimensions derived e.g.

from traffic management system).

Depending on the particular context, we are able to select and prioritize different

IQ dimensions. For example, by applying Leung’s [23] metric for importance,

urgency and cost we can select the dimensions that are most suitable for traffic

management and surveillance systems. In general, this will vary from environment to

environment and within the same environment different user groups may select

different IQ dimensions that most reflect the particular view of quality or the software

services they require. These dimensions may change over time for reasons such as

user skill level or change in software service.

The application of the framework should be on a regular basis in order to maintain

the currency of the dimensions. This dynamic allows for adaptation of IQ dimensions

to the constantly changing environment that more and more IS will find themselves.

In our future research we aim to apply this framework to traffic management and

surveillance systems, in order to identify the most important IQ dimensions. For

example following dimensions could be identified (see Table 2).

118

Table 2. Information quality dimensions for traffice mangement and surveillance system

(example).

Semiotic Level Quality Aspects

Quality of Design Quality of Conformance

Pragmatic Completeness Timeliness

Semantic Easy to understand

Interpretability,

believability, reliability

Syntax Consistent syntax

Syntactical correctness,

consistent representation,

accessibility

4 Introducing the Data Quality Monitoring Framework (DQMF)

In order to measure the IQ dimensions, the above framework will be extended by a

data quality monitoring framework which can be implemented as a comprehensive

mentoring system. The key is to develop a process independent monitoring system

that will continuously monitor data to ensure various aspects of IQ. In an example

scenario, if traffic data could be continuously monitored to ensure notifications are

sent timely, a problem could be detected much earlier and rectified with no impact to

client/decision maker.

Buildings form the discussion above, we specify a data quality block in form of

rules that incorporates data quality constrains and allows us to monitor certain aspects

of ensuring quality. In the context of our example, if a text message fails to be sent

from the traffic monitoring system, client might be not aware of a new situation.

Instead of including the quality block into the system, an IMS independent quality

conformance monitor would generate far better results in terms of performance.

However, developing a parallel system to monitor data can also be time and cost

prohibitive. Our aim in modeling quality block is also to develop data quality rules in

such a way so that it can be feed to an independent data quality monitor. The

framework consists of three core components. Data Quality Monitor (DQM), Data

Product Markup Language (DPML) and Information Quality Markup Language

(IQML).

4.1 Data Quality Monitor (DQM)

The data quality monitor is an application that accepts data product quality rules as its

input and continuously monitors data product to ensure that it meets the agreed

quality as defined. When designing the quality block, usually Business Process

Modeling Notation (BPMN) can be supplemented by metadata about each

information manufacturing block. Objective of the monitor is not to intervene in the

process, but merely to monitor the data products to see if the data meets the quality

requirement of the product relevant to the stage of its production. If the product fails

119

to meet the requirement, it will report the inconsistency in accordance with agreed

protocol to facilitate immediate intervention for corrective measures.

4.2 Data Product Markup Language (DPML)

A key element of our framework is DPML. In order to be effective quality controller,

Information System models must describe sufficiently and accurately static, dynamic

and organizational aspect of IMS. In a traditional manufacturing assembly line, as a

product reaches various stages of its development, it can be inspected to ensure that it

has met the requirement to be achieved at the relevant stage of the production. This is

possible because a product in traditional sense will be predefined to achieve certain

quality criteria that will be developed as part of designing the product. For our

framework to work, we treat data as a product of information manufacturing system.

At the design phase, we must then define the quality criteria that a data must meet at

various stages of its production. In order to achieve this objective, we developed a

Data Product Markup Language as an IP Unified Modeling Language (UML) based

data product definition language. By using UML we can build on previous work to

create visualized mapping of the data processes [5]. Furthermore, UML/BPMN is

widely accepted is that it can be exported to code directly by cutting down on

development time. This was further developed by IP MAP which extended a

systematic method of representing the process involved in manufacturing of IP. Flow

of data at various stages is also visualized by IP MAP. However, it lacks the ability to

bridge various process and information product. There is also a need to, as described

in the next section, to export the quality rules for automated execution. Hence we

also base DPML on BPMN. We extend this model to model an integrated approach

to define data quality requirements and business process together.

4.3 Information Quality Markup Language (IQML)

Once we are able to model data product using DPML, as described above, we need to

translate it into an executable that can be processed by automated software.

Otherwise, for each system a separate monitoring tool have to be developed. This is

likely to make it cost and time prohibitive. This is why there needs to be ability to

convert this DPML into and XML based rules that can be accepted by the monitoring

tool. Information Quality Markup Language (IQML) is an XML based data product

definition language. The purpose and nature of IQML is identical to that of DPML.

Difference is that while DPML is UML based, IQML is XML based. IQML is either

auto generated from DPML or generated independent of it. It is merely a means to

facilitate data product definitions to be consumed by the Data Quality Monitor.

5 Conclusions and Further Research

As discussed above, IQ research provided numerous frameworks, criteria and

methodologies to guide enterprise in the assessment, analysis, and improvement of

120

Traffic Management and Surveillance

System

Many surveillance and

sensor technolo

ies…

Applications

Data Quality Requirements

Data Quality Metrics

Our

current

Research

focus

Fig. 2. Data Quality Monitor and Research Focus.

IQ. However, focusing on the critical issues related to the assessment phase, the

literature does not provide an exhaustive set of metrics or guidelines that

organizations can apply. Indeed examining literature on Traffic Management and

Surveillance Systems, IQ in general and IQ assessments in particular are

underrepresented. Our current research aims to apply common IQ approaches to

various contexts, including traffic management. As illustrated in Figure 2, we aim to

build a Data Quality Monitor. Most enterprises are developing their own approaches

to address IQ issues although several algorithms have been developed for a subset of

dimensions, such as accuracy, completeness, consistency, and timeliness. In fact the

practical relevancy and generalization of some frameworks can be argued. Most

common approaches used to obtain an IQ assessment is to consider domain specific

measures associated with the different quality dimensions. Our research and

discussion above shows the importance of context in measuring IQ. Indeed, the

variations of IQ frameworks for different application scenarios indicate the

significance of context in assessing IQ. Considering this observation we proposed a

context-aware IQ framework. A critical element of our framework is the recognition

of pragmatics (in the sense of semiotics) within our framework and the differentiation

of quality of conformance and quality of design. This was used to propose a process

centric Data Quality Monitoring Framework (DQMF), which can be useful for traffic

surveillance and management systems incorporating data product quality and

conformance. Objective of data quality monitoring framework is to develop a

comprehensive mentoring system that can complement traditional traffic surveillance

and management systems. The framework consists of three core components. Data

Quality Monitor (DQM), Data Product Markup Language (DPML) and Information

Quality Markup Language (IQML).

In future work we will implement our monitoring framework and develop a

software tool that considers the context of IQ as outlined in our framework. This can

be applied in the context of traffic surveillance and management systems. This will be

considered for the empirical validation of the proposed context-aware IQ framework.

121

Furthermore, future work will also focus on the definition of an algorithm to obtain an

aggregate quality measure able to assess the organizations’ IQ level.

References

1. Alexander, J. E., and Tate, M. A. (1999) Web Wisdom: How to Evaluate and Create

Information Quality on the Web, Lawrence Erlbaum, Mahwah, NJ.

2. Amicis, F. D. and Batini, C. (2004), A methodology for data quality assessment on

financial data, Studies in Communication Sciences, 4(2), pp. 115-137.

3. Ballou D. P. and Pazer H. L.(1995) Designing Information Systems to Optimize the

Accuracy-Timeliness Tradeoff, Information Systems Research, 6,1, 51-72.

4. Ballou, D. P. and Tayi, G. K. (1999). Enhancing data quality in data warehouse

environments. Communications of the ACM. 42, 1, 73-78.

5. Ballou, D. P., Wang R., Pazer, H., Tayi, G. K. (1998) Modelling information manufacturing

systems to determine information product quality, in Management Science, April 1998,

Vol. 44, Issue 4, pp. 462-484.

6. Chen, Peter Shen-Te; Karthik K. Srinivasan, Hani S. Mahmassani: Effect of Information

Quality on Compliance Behavior of Commuters Under Real-Time Traffic Information,

Journal Transportation Research Record : Journal of the Transportation Research Board,

1676 (1999), pp. 53-60.

7. Chengalur-Smith, I. N., Ballou, D. P. and Pazer, H. L. (1999), The impact of data quality

information on decision making: an exploratory analysis. IEEE Transactions on Knowledge

and Data Engineering, 11(6), pp. 853-864.

8. Dedeke, A. (2000) A conceptual framework for developing quality measures for

information systems. Proceedings of 5th International Conference on Information Quality,

MIT, USA.

9. Dunkel, Jürgen , Alberto Fernández, Rubén Ortiz, Sascha Ossowski, Event-driven

architecture for decision support in traffic management systems, Expert Systems with

Applications, 38, 6, June 2011, Pages 6530-6539

10. English, L.: Improving Data Warehouse and Business Information Quality, New York:

Wiley & Sons, 1999.

11. Fisher C.W. and Kingma B.R. (2001), Criticality of data quality as exemplified in two

disasters, Information & Management, 39, 2, 109-116.

12. Helfert, M. (2001), Managing and measuring data quality in data warehousing, Proceedings

of the World Multiconference on Systemics, Cybernetics and Informatics.

13. Helfert, M. and Heinrich B. (2003), Analyzing data quality investments in CRM: a model-

based approach, 8th International Conference on Information Quality, MIT, USA.

14. Helfert, M., Foley, O., Ge, M., Cappiello, C. (2009) Limitations of weighted sum measures

for Information Quality 15thAmericas Conference on Information Systems, San Francisco,

California August 6th-9th 2009

15. Huang K. T., Lee Y. W., Wang R.Y.(1999), Quality Information and Knowledge

Management, Prentice Hall.

16.

ISO/IEC 25012 (2008) Software engineering -Software product Quality Requirements and

Evaluation (SQuaRE) -Data quality model, International Organization for Standardization.

17. Juran, J. M. (1998) How to think about Quality, in Juran, J. M., Godfrey A. B. (ed.): Juran’s

quality handbook, 5th ed., New York: McGraw-Hill, 1998, pp. 2.1-2.18.

18. Kahn B. K. & Strong D. M. (1998) Product and Service Performance Model for

Information Quality: An Update, in Proceedings of the 1998 International Conference on

Information Quality, MIT, USA.

122

19. Kahn, B. & Strong, D. M. (2002) Information Quality Benchmarks: Product and Service.

Communications of the ACM, 45, 4,184-192.

20. Katerattanakul, P. & Siau, K. (1999) Measuring information quality of web sites:

Development of instrument, in Proceedings of the 20th international conference on

Information Systems. Charlotte, North Carolina.

21. Knight, S. & Burn, J. (2005) Developing a Framework for Assessing Information Quality

on the World Wide Web. Informing Science, 8, 159-172.

22. Lee Y., Strong D., Kahn B., and Wang R. Y. (2002), AIMQ: A Methodology for

Information Quality Assessment, Information & Management, 40, 2, 133-146.

23. Leung, H. K. N. (2001) Quality Metrics for Intranet Applications. Information &

Management, 38, 137-152.

24. Li, S. and Lin, B. (2006), Accessing information sharing and information quality in supply

chain management, Decision Support Systems, 42(3), pp.1641-1656.

25. Liu, K. (2000) Semiotics in information systems engineering. Cambridge, England:

Cambridge University Press.

26. Miller, H. (1996) The multiple dimensions of information quality, in Information Systems

Management, Vol. 13, Issue 2, Spring 1996, pp. 79-82.

27. Pipino, L. Lee, Y. W. & Wang, R. Y. (2002) Data Quality Assessment. Communications of

the ACM, 45, 4, 211-218.

28. Redman, T.(1996) Data Quality For The Information Age, Publisher: Artech House.

29. Stamper, R. K. (1973) Information in Business and Administrative Systems. New York:

John Wiley and Sons (1973)

30. Stvilia, B., Gasser, L., Twidale M. B. and Smith L. C. (2007). A Framework for

Information Quality Assessment, Journal of the American Society for Information Science

and Technology. 58(12), 1720-1733

31. Wand Y., and Wang R. Y. (1996), Anchoring data quality dimensions in ontological

foundations, Communications of the ACM, 39,11, pp.86-95.

32. Wang, R. Y. and Strong, D. M. (1996) Beyond accuracy: What Data Quality Means to Data

Consumers. Journal of Management Information System, 12,4, pp. 5-34.

33. Xu, H. and Koronios, A. (2004), Understanding information quality in E-business, Journal

of Computer Information Systems, 45(2), pp. 73-82.

34. Xu, H., Horn, J., Brown, N. and Nord G. D. (2002), Data quality issues in implementing an

ERP, Industrial Management & Data Systems, 102(1/2), pp. 47-59.

123
