FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF

GENETIC ASSOCIATIONS

Christine Sinoquet

1∗

, Rapha

el Mourad

2∗

and Philippe Leray

∗

Joint ﬁrst authors

LINA, UMR CNRS 6241, Universit

e de Nantes, 2 rue de la Houssini

ere, BP 92208, 44322 Nantes Cedex, France

LINA, UMR CNRS 6241, Ecole Polytechnique de l’Universit

e de Nantes

rue Christian Pauc, BP 50609, 44306 Nantes Cedex 3, France

Keywords:

Probabilistic graphical model, Bayesian network, Latent tree model, Detection of genetic association, Latent

variable, Data dimension reduction.

Abstract:

Together with the population aging concern, increasing health care costs require understanding the causal

basis for common genetic diseases. The high dimensionality and complexity of genetic data hamper the

detection of genetic associations. To alleviate the core risks (missing of the causal factor, spurious discoveries),

machine learning offers an appealing alternative framework to standard statistical approaches. A novel class

of probabilistic graphical models has recently been proposed - the forest of latent tree models - , to obtain

a trade-off between faithful modeling of data dependences and tractability. In this paper, we evaluate the

soundness of this modeling approach in an association genetics context. We have performed intensive tests,

in various controlled conditions, on realistic simulated data. We have also tested the model on real data.

Beside guaranteeing data dimension reduction through latent variables, the model is empirically proven able

to capture indirect genetic associations with the disease, both on simulated and real data. Strong associations

are evidenced between the disease and the ancestor nodes of the causal genetic marker node, in the forest. In

contrast, very weak associations are obtained for other nodes.

1 INTRODUCTION

Thanks to their ability to capture (conditional) inde-

pendences and dependences between variables, pro-

babilistic graphical models (PGMs) offer an adapted

framework for a ﬁne modeling of relationships bet-

ween variables in an uncertain data framework. A

PGM is a probabilistic model relying on a graph en-

coding conditional dependences within a set of ran-

dom variables. A PGM provides a compact and natu-

ral representation of the joint distribution of the set of

variables. Bayesian networks (BNs) are a commonly

used branch of PGMs.

Despite the fact that the observed variables are of-

ten sufﬁcient to describe their joint distribution, some-

times, additional unobserved variables, also named

latent variables, have a role to play. In this context,

hierarchical Bayesian networks such as latent tree

models (LTMs), formerly named hierarchical latent

class models, were proposed. LTMs are tree-shaped

BNs where leaf nodes are observed while internal

nodes are not. LTMs generalize latent class models

(LCMs), deﬁned as containing a unique latent varia-

ble and edges only connecting the latent variable to all

the observed variables. In LTMs, multiple latent va-

riables organized in a hierarchical structure allow to

depict a large variety of relations encompassing local

to higher-order dependences (see Figure 1). LCMs

enforce observed variables to be independent, condi-

tionally on the latent variable. In contrast, LTMs re-

lax this local independence assumption which is often

violated for observed data.

Few algorithms have been developed to learn such

models and still fewer for applications in association

genetics (Zhang and Ji, 2009). Forests of LTMs have

been recently proposed as potentially useful for asso-

ciation studies (Mourad et al., 2010; Mourad et al.,

2011). In the biomedical research domain, associa-

tion studies rely on the description of DNA variants at

characterized genome loci - or genetic markers - for

all subjects in case and control cohorts. Such studies

attempt to identify any putative dependence - or asso-

ciation - between one or possibly some genetic mark-

ers and the affected/unaffected status. In the case of a

Sinoquet C., Mourad R. and Leray P..

FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF GENETIC ASSOCIATIONS.

DOI: 10.5220/0003703400050014

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2012), pages 5-14

ISBN: 978-989-8425-90-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

single causal locus, a putative association is revealed

if the distribution of variants between cases and con-

trols shows an accumulation of the former with re-

spect to some variant(s). From now on, we will refer

to the most popular genetic markers, that is, Single

Nucleotide Polymorphisms (SNPs).

One of the ﬁrst motivations to propose this novel

model - the forest of LTMs (FLTM) - is to take ac-

count of linkage disequilibrium (LD) in the most pos-

sible faithful way. Linkage disequilibrium occurs be-

cause DNA variants close on the chromosome are

scarcely separated by the shufﬂing of chromosomes

(recombination) that takes place during sex cell for-

mation. Such variants are therefore transmitted to-

gether (as an haplotype) from parent to child. Such

patterns are at the basis of the so-called haplotype

block structure (Daly et al., 2001): ”blocks” where

statistical dependences between loci are high alter-

nate with shorter regions characterized by low statis-

tical dependences, the recombination hotspots. LD

is crucial for association studies since a causal lo-

cus not sharply coinciding with a SNP is neverthe-

less expected to be ﬂanked by SNPs highly likely to

be shown (indirectly) associated with the phenotype.

Besides, beneﬁtting from high correlations is appea-

ling to implement data dimension reduction.

Data dimension reduction exploiting LD is not

new to genetics. However, tackling this issue through

adapted Bayesian networks has but recently been pro-

posed (Mourad et al., 2011). Notably, these authors

have successfully compared the FLTM-based method

to other methods with respect to faithfulness in LD

modeling and data dimension reduction. Besides,

FLTM models seem appealing to enhance associa-

tion studies: due to their hierarchical structure, FLTM

models would help pointing out a region containing

a genetic factor associated with a studied disease.

However, bottom-up information fading is likely to

be observed in the hierarchical structure. The im-

pact on downstream analyses such as association stu-

dies remains questionable. The very point is to check

whether latent variables covering a causal region are

found associated with the disease. In this paper, we

have conducted a systematic and comprehensive eva-

luation of the ability of the FLTM model to help evi-

dence genetic associations through latent variables.

This paper is organized as follows: after the

Section ”Deﬁnitions”, the motivation for the FLTM

model proposal is provided, together with the con-

text of this proposal. The next Section describes the

FLTM learning algorithm used in this paper and high-

lights the differences with the initial version. In Sec-

tion ”Study Protocol”, we deﬁne the notion of ”indi-

rect association”; then we detail the protocol imple-

mented to evaluate the ability of FLTM’s latent va-

riables to capture indirect associations. The Section

Results and Discussion describes and discusses inten-

sive tests on realistic simulated data and real geno-

typic data.

2 DEFINITIONS

BNs are deﬁned by a directed acyclic graph G(X,E)

and a set of parameters θ. The set of nodes X =

,...,X

} represents p random variables and the set

of edges E captures the conditional dependences bet-

ween these variables (i.e. the structure). The set of

parameters θ describes a conditional probability dis-

tributions θ

= [P(X

/Pa

)] where Pa

denotes node

i’s parents. If a node has no parent, then it is described

by an a priori probability distribution. The variables

are described for n observations. For further under-

standing, we now brieﬂy recall some deﬁnitions.

Deﬁnition 1 (conditional independence). Given a

subset of variables S ⊆ X\{X

}, conditional

independence between X

and X

is deﬁned as:

P(X

|S) = P(X

|S) P(X

|S). The non-equality en-

tails that both variables are conditionally dependent

given S.

Deﬁnition 2 (entropy, mutual informa-

tion). The entropy of variable X writes as:

H (X) = −

∑

i=1

P(x

)log P(x

) where P(x

) is

the probability mass function of outcome x

Given two variables X

and X

, the mutual in-

formation measures the dependence of the two

variables, expressing the difference of entropies

between the independent model P(X

) P(X

) and

the dependent model P(X

) P(X

): I (X

) =



H (X

) + H (X

)



−



H (X

) + H (X

)



H (X

) − H (X

). The larger the difference

between entropies, the higher is the dependence.

Due to the presence of pairs of chromosomes in

the human genome, the DNA at a given chromosome

locus (SNP) may either be described through a pair

of variants (alleles or phased data) at the ﬁner de-

scription level or through a unique variant (unphased

data). As SNPs are biallelic, only two alleles are en-

countered at the corresponding loci (instead of the 4

possible nucleotides A,T,C,G). Thus, SNPs are dis-

crete variables whose three possible values may be

coded as, say 0, 1 and 2, to respectively account for

aa, {Aa, aA} (usually not distinguishable) and AA,

where A and a are the two alleles. In the context of

this paper, we restrain our concern to discrete and ﬁ-

nite variables (either observed or latent). In this work,

we address the case of the single causal genetic factor.

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

layer 0

layer 1

layer 3

forest of latent tree models

latent tree model

layer 2

Figure 1: Latent tree model and forest of latent tree models.

The light shade indicates the observed variables whereas the

dark shade points out the latent variables.

3 MOTIVATION AND RELATED

WORK

3.1 Motivation

To tackle the difﬁcult problem of disease association

detection, several algorithms coming from the ma-

chine learning domain have been proposed. Some

of them use PGMs (Verzilli et al., 2006; Han et al.,

2010). Recently, forests of latent tree models have

been investigated for LD modeling purpose (Mourad

et al., 2011). A forest of latent tree models (FLTM)

is a forest whose trees are LTMs (see Figure 1).

FLTMs generalize LTMs, since the variables are not

constrained to be dependent upon one another, either

directly or indirectly. Thus, FLTMs can describe a

larger set of conﬁgurations than LTMs.

When modeling such highly correlated variables

as those in genotypic data, the challenge is all the

more crucial for downstream analyses such as study

and visualization of linkage disequilibrium, mapping

of disease susceptibility genetic patterns and study of

population structure. Most notably, the beneﬁts of

using FLTMs to model LD rely on their ability to ac-

count for multiple degrees of SNP dependences and

to naturally deal with the fuzzy nature of LD block

boundaries. As we will further emphasize, this latter

advantage results from the FLTM learning algorithm,

which does not impose that the SNPs subsumed by

the same latent variable be neighbouring SNPs (along

the genome).

3.2 Related Work

As for general BNs, besides learning of parameters

(θ), i.e. a priori and conditional probabilities, one of

the tasks in LTM learning is structure inference. This

task generally remains the most challenging due to

the complexity of the search space. Regarding LTM

learning, the proposals published in the literature fall

A nodes

OT nodes

O nodes

causal SNP

causal tree

OO nodes

Figure 2: Illustration of key terms speciﬁc to our approach.

A nodes: ancestor nodes of the causal SNP; O nodes: other

latent nodes categorized in OT nodes (in causal tree) and

OO nodes (outside the causal tree). See Figure 1 for node

nomenclature.

into two categories. The ﬁrst category relies on stan-

dard Bayesian network learning techniques. The se-

cond category is based on the clustering of the varia-

bles. To learn θ, both categories rely on the expecta-

tion maximization (EM) algorithm or an EM variant.

In the ﬁrst category, the algorithms explore the

search space through a local search strategy and opti-

mize a score, such as the BIC score (Schwartz, 1978).

Zhang proposed a greedy algorithm, to navigate in the

structure search space (Zhang, 2004). This algorithm

is coupled with a hill climbing procedure, to adjust the

cardinality of the latent variables. A more efﬁcient

variant of this algorithm has recently been proposed

(Chen et al., 2011). In this ﬁrst category, structural ex-

pectation maximization (SEM) has also been adapted

to the case of Bayesian networks with latent varia-

bles. SEM successively optimizes θ, conditionally

on the structure S , then optimizes S conditionally on

θ. Parameter learning being a time-consuming step,

in this framework, Zhang and Kocka have adapted a

procedure, called local EM, to optimize the variables

whose connexion or cardinality have been modiﬁed

in the transition from former to current model (Zhang

and Kocka, 2004). In one of the two LTM-based ap-

proaches dedicated to LD modeling, Zhang and Ji use

a set of LCMs and apply a SEM strategy (Zhang and

Ji, 2009). The number of LCMs has to be speciﬁed.

To avoid getting trapped in local optima while run-

ning the EM algorithm to learn a set of latent models,

these authors have adapted a simulated annealing ap-

proach.

The above score-based approaches require the

computation of the maximum likelihood in presence

of latent variables, a prohibitive task regarding com-

putational burden. Thus, various methods based on

the clustering of variables have been implemented.

They all construct the model following an ascending

strategy; they all rely on the mutual information (MI)

criterion, to identify clusters of dependent variables.

In their turn, these methods may be sub-categorized

into binary- and non binary-based approaches.

FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF GENETIC ASSOCIATIONS

Hwang and co-workers’ learning algorithm is de-

dicated to binary trees and binary latent variables

(Hwang et al., 2006). It has to be noted that the trees

are possibly augmented with connexions between si-

blings, that is nodes sharing the same parent into the

immediate upper layer. Also conﬁning themselves to

binary trees, Harmeling and Williams have proposed

two learning algorithms (Harmeling and Williams,

2011). One of them approximates MI between a la-

tent variable H and any other variable X, based on a

linkage criterion (single, complete or average) applied

for X and the variables in the cluster subsumed by

H. A variant of this ﬁrst algorithm locally infers the

data corresponding to any latent variable; therefore it

is possible to achieve an exact computation of the MI

criterion between a latent variable and any other va-

riable.

Two approaches have been proposed to circum-

vent binary tree-based structures. Wang and co-

workers ﬁrst build a binary tree; then they apply re-

gularization and simpliﬁcation transformations which

may result in subsuming more than two nodes through

a latent variable (Wang et al., 2008). In their approach

devoted to LD modeling, Mourad and collaborators

implement the clustering of variables through a par-

titioning algorithm (Mourad et al., 2011); the latter

yields cliques of pairwise dependent variables. Be-

sides, this method imposes the control of information

fading as the level increases in the hierarchy, which

generally results in the production of a forest of LTMs

(instead of a single LTM).

Two of the above cited methods have been shown

to be tractable. For these two non binary-based ap-

proaches, some reports are available: Hwang and co-

workers’ approach was able to handle 6000 variables

and around 60 observations. The scalability of the

FLTM construction by Mourad et al. has been shown

for benchmarks describing 10

variables and 2000 in-

dividuals.

4 THE LEARNING ALGORITHM

We now describe the algorithm we have used to test

the FLTM model in the context of association gene-

tics. We have adapted the initial version of Mourad

and co-workers. We will highlight the differences bet-

ween the two implementations.

4.1 Sketch of the Algorithm

The learning is performed through an adapted ag-

glomerative hierarchical clustering procedure. At

each iteration, a partitioning method is used to as-

sign variables into non-overlapping clusters. The par-

titioning is based on the identiﬁcation of cliques of

strongly dependent variables in the complete graph

of pairwise dependences. Amongst the clusters, each

cluster of size at least two is a candidate for subsump-

tion into a latent variable H. To acknowledge or re-

ject the creation of H, a prior task considers the LCM

rooted in this latent variable candidate and whose

leaves are all the variables of the cluster. Parame-

ter learning using the EM algorithm is performed for

this LCM. Then probabilistic inference allows mis-

sing data imputation for the latent variable. Once all

the data are known for this LCM, a validation step

checks whether the latent variable captures enough

information from its children. If a latent variable is

validated, its child variables are then replaced with

the latent variable. In contrast, the nodes in unvali-

dated clusters are kept isolated for the next iteration.

Iterating these steps yields a hierarchical structure. In

other words, latent variables capture the information

borne by underlying observed variables (e.g. genetic

markers). In their turn, these latent variables, now

playing the role of observed variables, are synthesized

through additional latent variables, and so on.

For a better understanding, we now detail ﬁve

points of this algorithm. We start with the two points

establishing the difference between the initial version

in (Mourad et al., 2011) and our novel version.

4.1.1 Window-based Data Scan versus

Straightforward Data Scan

First, we remind the reader that the initial observed

variables are SNPs, which are located along the

genome in a sequence of ”neighbouring” (but gene-

rally non contiguous) genetic markers. To meet the

scalability criterion, a divide-and-conquer procedure

has been implemented in (Mourad et al., 2011): the

data is scanned through contiguous windows of iden-

tical ﬁxed sizes. However, such splitting is questio-

nable. It entails a bias in the processing of the varia-

bles located in the neighbourhood of the artiﬁcial win-

dow frontiers. Managing overlapping windows would

not have lead to a practicable algorithm. Therefore, a

ﬁrst notable difference with the algorithm in (Mourad

et al., 2011) lies in that our novel version does not

require data splitting. Instead, a simple principle is

implemented: not all pairs of variables are processed

by the partitioning algorithm. Beyond a physical dis-

tance on the chromosome, δ, speciﬁed by the geneti-

cist, variables are not allowed in the same cluster. Set-

ting the δ constraint actually corresponds to imple-

menting a sliding window approach.

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

4.1.2 Partitioning of Variables into Cliques

Standard agglomerative hierarchical clustering con-

siders a similarity matrix. As a latent variable is in-

tended to connect pairwise dependent variables, the

standard agglomerative approach was adapted accor-

dingly. Within each window, our previous version run

a clique partitioning algorithm on the complete graph

of pairwise dependences. In the novel version, no

complete matrix is required anymore. The physical

constraint δ leads to calculate a sparse matrix of pair-

wise dependences, where only computed values are

stored.

In our former version, we used the clique parti-

tioning algorithm CAST devoted to the clustering of

variables (Ben-Dor et al., 1999). The dependence bet-

ween two variables, evaluated through pairwise mu-

tual information, is used to derive a binary similar-

ity measure (requested by CAST), depending on a

threshold τ

pairwise

. Our algorithm automatically ad-

justs this threshold, based on a given quantile value

of the mutual information values in the whole matrix

(e.g. the median value). We have rewritten the CAST

algorithm to take account of the physical constraint

δ. Through the management of a sparse matrix of

pairwise dependences, we actually allow the modu-

lation of the useful matrix bandwidth, depending on

the physical constraint imposed by the sliding win-

dow size δ.

However, unlike SNPs, latent variables are not

characterized by a physical location on the chromo-

some. In this speciﬁc case, we average the locations

of the SNPs subsumed by the latent variable.

4.1.3 Data Imputation for Latent Variables

Data imputation is processed locally, that is conside-

ring the LCM rooted in the latent variable and whose

leaves are the variables in the cluster. For simpliﬁca-

tion, the cardinality of the latent variable is estimated

as an afﬁne function of the number of leaves. Para-

meter learning is ﬁrst performed in this LCM, through

the EM algorithm. This step yields the marginal dis-

tribution of the latent variable and the conditional dis-

tributions of the child variables. Therefore, (linear)

probabilistic inference can be carried on, based on the

following principle:

P(H = c|x

) =

i=1

P(x

|H = c) P(H = c)

∑

c=1

i=1

P(x

|H = c) P(H = c)

with k the cardinality of latent variable H, c a possi-

ble value for H, j an observation, i.e. an individual in

our case, and x

the vector of values {x

,...,x

} cor-

responding to the variables in the cluster {X

,...,X

4.1.4 Local Parameter Learning

In parallel with the structure growing, the parameters

of the forest of LTMs are learned locally (see Sub-

section 4.1.3). At a given iteration, for any varia-

ble shown to be a leaf node in an LCM (correspond-

ing to a cluster), the current marginal distribution is

replaced with the conditional distribution learned in

the LCM. Thus, during the bottom-up construction of

the FLTM, marginal distributions are successively re-

placed with conditional distributions.

4.1.5 Validation of Latent Variables

The subsumption of the candidate cluster into the la-

tent variable H is validated through a criterion ave-

raging a normalized dependence measure between H

and each of H’s child nodes:

Criter =

| C

∑

i ∈ C

I (X

,H)

min (H (X

), H (H))

≥ τ

latent

with | C

| the size of cluster C

4.2 Recapitulation

In the forest of LTMs, the subsumption process is

controlled through thresholds τ

pairwise

and τ

latent

and

constraint δ. No latent variable is allowed to sub-

sume variables which are not highly pairwise depen-

dent (τ

pairwise

) or which refer to regions which are too

far from one another (δ); τ

latent

controls bottom-up

information fading through the hierarchy. τ

pairwise

latent

and δ thus monitor the number of connected

components (trees) and the number of layers in the

forest. These three parameters rule the trade-off bet-

ween faithfulness to the underlying reality and tracta-

bility of the modeling.

We have tested the behaviour of our algorithm -

in particular its handling of large sparse matrices - on

datasets describing 10

SNPs for 2000 individuals.

In (Mourad et al., 2011), the running time was

around 15 hours for an arbitrary window size of

100 SNPs. When setting the sliding window size δ

to 0.5 Mb, a reasonable choice to capture LD, our

novel algorithm now runs in less than 12 hours. It

has to be emphasized that as our algorithm runs EM

with 10 restarts, a signiﬁcant improvement has been

brought with respect to the initial version. Finally,

we have checked that our algorithm is quasi linear

with the number of SNPs and linear with the sliding

window size. The corresponding experimentations

are not shown in this paper. Neither are our exami-

nations of the robustness with respect to parameter

adjustment. The application software is available at

http://sites.google.com/site/raphaelmourad/Home/pro

grammes.

FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF GENETIC ASSOCIATIONS

5 STUDY PROTOCOL

Our purpose in this paper is to investigate how infor-

mation about causality fades from bottom to top in

the hierarchy and what are the trends regarding the ra-

tios of latent variables erroneously associated with the

disease. Therefore, we used realistic simulated data

or real data designed or known to harbour a causal

SNP. We name indirect genetic association any de-

pendence between a causal SNP ancestor node (ab-

breviated as A) in the FLTM and the disease. This

dependence is due to the fact that an A node is likely

to capture the information of the causal SNP. If in-

direct genetic association may be evidenced for A

nodes, the identiﬁcation of A nodes will allow poin-

ting out potentially causal markers since the latter are

leaf nodes of the trees rooted in A nodes (see Figure 2

which clariﬁes the meaning of speciﬁc key terms fur-

ther used). We will examine the difference between

causal SNP ancestors (As) and other latent nodes (ab-

breviated as Os). We will also examine the behaviour

of Os in causal trees (OTs) and of Os outside causal

trees (OOs).

5.1 Simulation of Realistic Genotypic

Data

Conducting a systematic analysis under con-

trolled conditions requires that we are able to

simulate both realistic SNP data and an as-

sociation between one of these SNPs and the

disease status (affected/unaffected). For this pur-

pose, we have chosen one of the most widely

used software applications, namely HAPGEN

(http://www.stats.ox.ac.uk/∼marchini/software/gwas

/hapgen.html) (Spencer et al., 2009). The reader well

acquainted with such HAPGEN simulations may skip

the two following paragraph, where we describe the

simulation in the case of a single causal SNP.

Generating realistic genotypic simulation lies in

the ability to mimic linkage disequilibrium (see Intro-

duction, fourth paragraph). HAPGEN relies on the

haplotypes (sequence of alleles, see Introduction, last

paragraph) of a population of reference, to generate

new haplotypes as mosaics of the known haplotypes,

for a user-speciﬁed number of cases and controls. The

genotype of any individual is generated based on the

two haplotypes simulated for this individual.

HAPGEN selects at random the causal SNP,

checking for the minor allele frequency to be within

a user-speciﬁed range. Assuming causality under a

speciﬁc disease model and effect sizes, it is straight-

forward to calculate the genotype frequencies in cases

at that locus. On this basis, any case individual is

simulated by ﬁrst simulating the alleles at the causal

locus and then working outwards in each direction

to construct the two haplotypes. Note that the same

mechanism governs the construction of haplotypes,

whatever the status of the individual (case or control).

The only distinction lies in that the locus from which

the extension is started is chosen at random, for con-

trols. For cases, the extension is initiated from the

causal locus. The extension processes conditionally

on reference haplotypes and is ruled by the ﬁne-scale

knowledge of recombination rates and the physical

distance between loci, to calculate the probability of

breaks in the mosaic pattern as one moves along the

region. Moreover, partial copies (of haplotype subre-

gions) are blurred by simulated mutations.

To control the simulation conditions, three ingre-

dients have been combined: minor allele frequency

(MAF) of the causal SNP, severity of the disease

expressed as genotype relative risks (GRRs) for va-

rious disease models. The range of the MAF at the

causal SNP has been speciﬁed to be 0.1-0.2, 0.2-0.3

or 0.3-0.4. Various genotype relative risks have been

considered and the disease model has been speciﬁed

amongst additive, dominant, multiplicative or reces-

sive (add, dom, mul, rec). These choices are justiﬁed

as standards used for simulations in association gene-

tics.

For short, together with GRRs, the disease models

allow specifying the probability to be affected, de-

pending on the genotype at the causal locus: GRR =

P(a f f ected|Aa)

P(a f f ected|aa)

, where A is the disease allele. The speci-

ﬁcation of the disease model amongst add, dom, mul

and rec allows the adjustment of the probability to

be affected when carrying the two disease alleles AA,

with respect to the probability to be affected when

carrying Aa (or aA). Thus various effect sizes may

be simulated. If 1 stands for the effect when no dis-

ease allele is present at the causal locus (aa), the ef-

fect sizes for the Aa and AA carriers are respectively:

1 +

,1 + α (add); 1 +α, 1 + α (dom); 1 + α, 1 + α

(mul); 1, 1 + α (rec).

To run HAPGEN, we have chosen the widely used

reference haplotypes of the HapMap phase II coming

from U.S. residents of northern and western European

ancestry (CEU) (http://hapmap.ncbi. nlm.nih.gov/).

The disease prevalence (percentage of cases observed

in a population) speciﬁed to HAPGEN has been set to

0.01, a standard value used for disease locus simula-

tion. The simulated data have been generated for 1000

unaffected subjects and 1000 affected subjects and

consist of unphased genotypes relative to a 1.5 Mb re-

gion containing around 100 SNPs. Combining all pre-

vious conditions led to testing 36 scenarii (3 × 3 × 4).

To derive signiﬁcant trends, we replicated each sce-

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

nario 100 times. Together with our aim of a com-

prensive study, the necessity to replicate explains our

choice of the number of variables (100 SNPs). Stan-

dard quality control for genotypic data has been car-

ried out: SNPs with MAF less than 0.05 and SNPs de-

viant from the so-called Hardy-Weinberg Equilibrium

(not detailed) with a p-value below 0.001 have been

removed.

5.2 Detection of Genetic Associations

We have used the G

standard test of independence

rather than the well-known Chi

test: for relatively

small sample sizes (below 300 subjects) as is the case

for the real dataset analyzed, G

is recommended. We

have compared the p-values obtained, successively

testing the phenotype Y against the causal SNP, the

causal SNP ancestor nodes (A nodes) and other nodes

(abbreviated as Os) in the FLTM’s graph. We dis-

play the −log

(p-value) values. Values near 0 point

out independence and the previous indicator increases

with the strength of the dependence.

To measure the signiﬁcance of associations, we

have implemented a permutation procedure dedicated

to the computation of the per-test error rate α

(type

I error), in order to control the family-wise error rate

α (type I error) at 5%. Namely, α

deﬁnes the signif-

icance threshold for each association test. α controls

the probability to make one or more false discoveries

among all hypotheses when performing multiple as-

sociation tests. The procedure implemented to obtain

is the following: (i) for each permutation, and each

FLTM’s layer L, we perform independence tests bet-

ween the variables in L and the phenotype. For each

permutation, the minimum of the p-values over all va-

riables belonging to L is identiﬁed (pmin). Given the

threshold α, the distribution of pmins over all permu-

tations allows to extract a pointwise threshold α

An advantage of the FLTM strategy relies on the

fact that there are less variables in the highest layers

than in the lowest ones. Thus, we expect an increase

of α

with the layer level. That is the reason why our

permutation procedure was adapted to the calculation

of layer-speciﬁc thresholds α

6 RESULTS AND DISCUSSION

6.1 Simulated Data

In the following, the data analysis has entailed the ge-

neration of up to 7 layers in the FLTMs. We will not

report results obtained for layers with numbers above

Figure 3: Histograms of −log

(p-value) values resulting

from association tests of the phenotype with the causal SNP

ancestor nodes (As) and the other latent nodes (Os). Gene-

ral results compiling all simulated scenarii (see 5.1): MAF

(0.1-0.2, 0.2-0.3 and 0.3-0.4), heterozygous GRR (1.4, 1.6

and 1.8) and disease model (dominant, recessive, additive

and multiplicative).

3: such layers do not provide sufﬁcient data to com-

pute representative medians or draw informative box-

plots. On average, over all 3600 FLTMs (36 scenarii

× 100 replicates), the percentages of nodes are dis-

tributed as follows: 89.1% in layer 0, 9.5% in layer 1,

1.2% in layer 2 and 0.2% in layer 3.

6.1.1 General Trends

Figure 3 compares the histograms of −log

(p-value)

values resulting from association tests of Y with A

nodes and O nodes, respectively. The comparison of

these two histograms reveals a large dissimilarity bet-

ween the two distributions. The majority (70%) of

−log

(p-value) values relative to A nodes is greater

than 1, whereas it is the case for only 19% of O nodes.

Indeed, we observe that large −log

(p-value) values

(e.g., greater than 5) are common for the former and

are very rare for the latter. A non-parametric test, the

Wilcoxon rank-sum test, shows a p-value less than

−16

, thus conﬁrming that A and O p-values follow

two different distributions.

Figure 4(a) more thoroughly describes the

−log

(p-value) values observed for the different la-

yers of the FLTM in the cases of tests relative to A

and O nodes. The layer 0 refers to the association

tests between the phenotype and the causal SNP and

serves as the reference value. In this ﬁgure, we ob-

serve that the association strength for A nodes slowly

decreases when the layer number increases, whereas

the association for O nodes sticks to −log

(p-value)

values below 0.4, corresponding to p-values greater

than 0.4. Although O nodes reveal false positive as-

sociations (less than 10% have a p-value below 0.01),

these results clearly highlight a general trend: indi-

rect associations are captured by the A nodes while it

is not the case for a large majority of O nodes.

Figure 4(b) emphasizes the general trend of

FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF GENETIC ASSOCIATIONS

0 1 2 3

1 2 3 4 5

Layer

−log10(p−value)

Median -log10(p-value)

Causal SNP

Per-test error rate α'

(a) (b)

Figure 4: −log

(p-value) values for the different layers of the FLTM, resulting from association tests of the phenotype with

the causal SNP ancestor nodes (As) and with the other latent nodes (Os) - simulated data. (a) Boxplots. (b). Median values.

The layer 0 shows the results of the association tests between the phenotype and the causal SNP (over all simulated scenarii).

See Figure 3 for details about the scenarii, see last paragraph of 5.2 for the deﬁnition of error rate α

Legend

GRR = 1.4

GRR = 1.6

GRR = 1.8

(a)

(b)

Figure 5: Median −log

(p-value) values for the different layers of the FLTM, resulting from association tests between the

phenotype and latent nodes - simulations under thirty-six conditions. (a) Causal SNP ancestor nodes (As). (b) Other latent

nodes (Os). The different windows represent possible genetic scenarii. At the top of each window, the range of the simulated

causal SNP’s minor allele frequency and the disease model assumption (additive, dominant, multiplicative or recessive) are

indicated. The three different symbols used refer to as many genotype relative risks considered for the simulated causal SNP

(see Legend and 5.1). The layer 0 refers to the association tests between the phenotype and the causal SNP (over all 100

replications).

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

−log

(p-value) observed for A and O nodes, and

compares the median −log

(p-value) value obtained

for each layer to the corresponding value associated

with the signiﬁcance threshold α

speciﬁc to this layer

(see Subsection 5.2, second paragraph). This ﬁgure

reveals that up to the second layer, signiﬁcant asso-

ciations are identiﬁed for A nodes. In contrast, regar-

ding O nodes, for all layers, median −log

(p-value)

values are smaller than the corresponding −log

(α

)

values. Focusing on the O distribution, we observe

that the percentage of p-values lower than α

(false

positives) is 4.7%.

The existence of the false positives (FPs) can

partly be explained by the presence of indirect depen-

dences between the causal SNP and the OTs, that is

the O nodes located in the causal tree. The causal tree

is the tree containing the causal SNP (see Figure 2).

At the opposite, no FPs are expected for O nodes out-

side the causal tree (OOs). The three key relations

are: Os = OTs(21%) + OOs(79%); True Positives =

As; False Positives = FP Os = FP OTs (73%) + FP

OOs (27%). Thus 73% of FPs are in the causal tree,

representing only 21% of O nodes (in causal tree and

other trees). In the causal tree, the FP rate is 16%;

over all non causal trees, the FP rate is 1.6%. In con-

clusion, the major part of FPs is conﬁned in the causal

tree.

6.1.2 Behaviour under Thirty-six Genetic

Scenarii

We now compare association test results between A

and O nodes for each scenario described in Subsec-

tion 5.1 (see Figure 5). Globally, similar tendencies

are observed over all scenarii: the association strength

drops continuously from bottom to layer number 3; in

the case of O nodes, an overwhelming majority of re-

sults points out the absence of association, whichever

the FLTM’s layer concerned.

When considering the easiest case (MAF range

= 0.3-0.4, GRR = 1.8 and multiplicative model),

over all layers, the A nodes present strong asso-

ciations (−log

(p-value) > 7). Regarding a less

ideal but more plausible conﬁguration (MAF range

= 0.2-0.3, GRR = 1.6 and additive model), the me-

dian −log

(p-value) value computed for A nodes de-

creases from 8.3 at layer 0, to reach 4.6, 3.2 and 2.2 at

layers 1, 2 and 3, respectively. On the contrary, when

the model is recessive, the association with the causal

SNP is low and the A nodes cannot capture anything

(similar results are obtained with most of the methods

dedicated to association studies). As regards the O

nodes, null associations are reported in all conﬁgura-

tions.

Figure 6: Boxplot of −log

(p-value) values for the diffe-

rent layers of the FLTM, resulting from association tests of

the phenotype with the causal SNP ancestor nodes (As) or

with the causal SNP non-ancestor nodes (Os) - real data.

Layer 0 refers to the association test between the phenotype

and the causal SNP (marker 19). In layer 3, no O nodes are

observed in the FLTMs.

6.2 Real Data

We have also evaluated on real data the ability of

FLTM models to capture the indirect associations

with the phenotype. We have used a reference dataset

relative to a 890 kb region ﬂanking the CYP2D6 gene

on human chromosome 22q13. This gene has a con-

ﬁrmed role in drug metabolism (Hosking et al., 2002).

The dataset consists of 32 SNP markers genotyped

for 268 individuals and was downloaded from the R

package graphminer developed by Verzilli and colla-

borators (Verzilli et al., 2006). The SNP 19 at the

position 550 kb is the closest marker to CYP2D6 gene

(at 525.3 kb). For this reason, for our experiment, we

have considered the SNP 19 as the causal marker.

To take into account the stochastic nature of our

algorithm (random initialization of parameters during

the EM algorithm), we present the results relative to

1000 runs. Each run takes on average 5.4 s on a

standard PC computer (3 GHz, 2 GB RAM). On ave-

rage, over all 1000 FLTMs (1000 replicates), the per-

centages of nodes are distributed as follows: 82.62%

in layer 0, 16.89% in layer 1, 0.39% in layer 2 and

0.10% in layer 3. Figure 6 shows the −log

(p-value)

values of association tests relative to As and Os. As

expected in view of experiments led on simulated

data, the A nodes succeed in capturing indirect asso-

ciation, in particular in layer 1, with a median value of

5.5, corresponding to p-values lower than 5.10

−6

. In

the other layers, the strength of associations is lower

but remains relatively high as in the layer 2 showing

a median value of 4, equivalent to a p-value of 10

−4

As previously seen, when we focus on O nodes, we

observe very few strong associations. The majority of

p-values (over 80%) is greater than 0.01.

FORESTS OF LATENT TREE MODELS FOR THE DETECTION OF GENETIC ASSOCIATIONS

7 CONCLUSIONS AND

PERSPECTIVES

Based on both simulated and real data analyses, this

paper promotes the use of FLTMs as a simple and use-

ful framework for disease association detection in hu-

man genetics. Efﬁcient capture of indirect genetic as-

sociation is achieved through two major reasons: (i)

the causal SNP ancestor nodes succeed in capturing

indirect associations with the phenotype; (ii) at the

opposite, the other latent nodes globally show very

weak associations. In other words, this property al-

lows to distinguish between true and false indirect ge-

netic associations.

The numbers of SNPs in the benchmarks were

limited. Nonetheless, this limitation is not a bias to

the sound characterization of the fading of informa-

tion in the FLTM hierarchies: bottom-up information

decays does concern the forest depth and does not in-

terfere with the forest width. It must be underlined

that our tests were not designed to meet the small

n, large p condition (many more variables (SNPs)

than subjects) as in genome-wide association studies

(GWASs). Again, this is not a bias to our study:

over thirty-six various scenarii, we have shown that

the overwhelming part (about three quarters) of false

positives conﬁnes in a unique tree, namely the one

harbouring the causal SNP (causal tree). In the con-

ditions of a GWAS, the forest width may well be far

larger than those observed in our tests, the false po-

sitives are expected to remain conﬁned in the causal

tree, for the major part.

In a previous work, we have developped a scala-

ble FLTM learning algorithm, thus reaching orders of

magnitude consistent with GWAS demands (10

va-

riables, 2000 individuals). In addition to scalability,

data dimension reduction advocates the use of FLTM-

based modeling in GWASs: the issue of multiple hy-

pothesis testing in GWASs would be resolved by tes-

ting a low number of latent variables instead of a large

number of observed variables. However, before en-

visaging an FLTM-based GWAS, an inescapable pre-

requisite was testing whether the bottom-up informa-

tion fading through the forest would nevertheless al-

low reliable association detection. No less unavoida-

ble was the close examination of ratios of latent varia-

bles erroneously associated with the disease.

A precursory work to the GWAS concern, the

present contribution assets the soundness of the

FLTM model for association detection. Besides, we

have conceived a procedure to guarantee a given

family-wise (type I) error rate through the computa-

tion of layer-speciﬁc per-test error rates. The success-

ful test of our algorithm under a large spectrum of

conditions allows its integration in a GWAS tool.

REFERENCES

Ben-Dor, A., Shamir, R., and Yakhini, Z. (1999). Clustering

gene expression patterns. In Proc. of the 3rd annual

int. con. on Computational molecular biology, pages

33–42.

Chen, T., Zhang, N., Liu, T., Poon, K., and Wang, Y. (2011).

Model-based multidimensional clustering of categori-

cal data. In Artiﬁcial intelligence, in press.

Daly, M. J., Rioux, J. D., Schaffner, S. F., Hudson, T. J., and

Lander, E. S. (2001). High-resolution haplotype struc-

ture in the human genome. Nat. Genet., 29(2):229–

232.

Han, B., Park, M., and Chen, X. W. (2010). A Markov

blanket-based method for detecting causal SNPs in

GWAS. BMC Bioinformatics, 11(Suppl 3):S5+.

Harmeling, S. and Williams, C. K. I. (2011). Greedy learn-

ing of binary latent trees. IEEE Transactions on Pat-

tern Analysis and Machine Intelligence, 33(6):1087–

1097.

Hosking, L. K., Boyd, P. R., and Xu, C. F. e. a. (2002). Link-

age disequilibrium mapping identiﬁes a 390 kb region

associated with CYP2D6 poor drug metabolising ac-

tivity. Pharmacogenomics J., 2(3):165–175.

Hwang, K.-B., Kim, B.-H., and Zhang, B.-T. (2006). Learn-

ing hierarchical bayesian networks for large-scale data

analysis. In ICONIP, pages 670–679.

Mourad, R., Sinoquet, C., and Leray, P. (2010). Learning

hierarchical Bayesian networks for genome-wide as-

sociation studies. In COMPSTAT, pages 549–556.

Mourad, R., Sinoquet, C., and Leray, P. (2011). A hierar-

chical Bayesian network approach for linkage dise-

quilibrium modeling and data-dimensionality reduc-

tion prior to genome-wide association studies. BMC

Bioinformatics, 12:16+.

Schwartz, G. (1978). Estimating the dimension of a model.

The Annals of Statistics, 6(2):461–464.

Spencer, C. C., Su, Z., Donnelly, P., and Marchini, J. (2009).

Designing genome-wide association studies: sample

size, power, imputation, and the choice of genotyping

chip. PLoS Genetics, 5(5):e1000477+.

Verzilli, C. J., Stallard, N., and Whittaker, J. C. (2006).

Bayesian graphical models for genome-wide associa-

tion studies. The American Journal of Human Gene-

tics, 79:100–112.

Wang, Y., Zhang, N. L., and Chen, T. (2008). Latent tree

models and approximate inference in Bayesian net-

works. Machine Learning, 32:879–900.

Zhang, N. L. (2004). Hierarchical latent class models for

cluster analysis. JMLR, 5:697–723.

Zhang, N. L. and Kocka, T. (2004). Efﬁcient learning of

hierarchical latent class models. In ICTAI, pages 585–

593.

Zhang, Y. and Ji, L. (2009). Clustering of SNPs by a struc-

tural EM algorithm. In Int. Joint Conf. on Bioinfor-

matics, Systems Biology and Intelligent Computing,

pages 147–150.

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms
