FLEXIBLE COMMAND INTERPRETATION

ON AN INTERACTIVE DOMESTIC SERVICE ROBOT

Stefan Schiffer, Niklas Hoppe and Gerhard Lakemeyer

Knowledge-Based Systems Group, RWTH Aachen University, Aachen, Germany

Keywords:

Natural language processing, Decision-theoretic planning, Interpretation, Domestic service robotics.

Abstract:

In this paper, we propose a system for robust and ﬂexible command interpretation on a mobile robot in domes-

tic service robotics applications. Existing language processing for instructing a mobile robot often make use of

a simple, restricted grammar where precisely pre-deﬁned utterances are directly mapped to system calls. This

does not take into account fallibility of human users and only allows for binary processing; either a command

is part of the grammar and hence understood correctly, or it is not part of the grammar and gets rejected. We

model the language processing as an interpretation process where the utterance needs to be mapped to a robot’s

capabilities. We do so by casting the processing as a (decision-theoretic) planning problem on interpretatory

actions. This allows for a ﬂexible system that can resolve ambiguities and which is also capable of initiating

steps to achieve clariﬁcation.

1 INTRODUCTION

In this paper we present a system for ﬂexible com-

mand interpretation to facilitate natural human-robot

interaction in a domestic service robotics domain. We

particularly target the General Purpose Service Robot

test from the RoboCup@Home competition (Wis-

speintner et al., 2009), where a robot is confronted

with ambiguous and/or faulty user inputs in form of

natural spoken language. The main goal of our ap-

proach is to provide a system capable of resolving

these ambiguities and of interactively achieving user

satisfaction in the form of doing the right thing, even

in the face of incomplete, ill-formed, or faulty com-

mands.

We model the processing of natural spoken lan-

guage input as an interpretation process. More pre-

cisely, we ﬁrst analyse the given utterance syntac-

tically by using a grammar. Then, we cast the in-

terpretation as a planning problem where the single

actions available to the planner are to interpret syn-

tactical elements of the utterance. If, in the course

of interpreting, ambiguities are detected, the system

uses decision-theory to weigh up different alterna-

tives. The system is also able to initiate clariﬁca-

tion to resolve ambiguities and to handle errors as to

arrive at a successful command interpretation even-

tually. Since our current high-level control already

knows about the robot’s capabilities (the actions and

the parameters that these actions need), we want to

tightly connect the interpretation with it.

2 FOUNDATIONS AND RELATED

WORK

In this section, we introduce the foundations, namely

the situation calculus and GOLOG, that our approach

builds upon. We then brieﬂy review related work.

2.1 Foundations

The high-level control of our domestic service robot

uses a logical programming and plan language called

READYLOG. It is a dialect of GOLOG which itself is

based on the situation calculus.

2.1.1 The Situation Calculus and GOLOG

The situation calculus (McCarthy, 1963) is a sorted

second order logical language with equality that al-

lows for reasoning about actions and their effects. The

situation calculus distinguishes three different sorts:

actions, situations, and domain dependent objects.

The state the world is in is characterised by functions

and relations with a situation as their last argument.

They are called functional and relational ﬂuents, re-

Schiffer S., Hoppe N. and Lakemeyer G..

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT.

DOI: 10.5220/0003707300260035

In Proceedings of the 4th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2012), pages 26-35

ISBN: 978-989-8425-95-9

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

spectively. The world evolves from an initial situa-

tion S

only due to primitive actions, e.g., s

′

= do(a, s)

means that the world is in situation s

′

after perform-

ing action a in situation s. Possible world histories are

represented as sequences of actions. For each action

one has to specify a precondition axiom stating un-

der which conditions it is possible to perform the re-

spective action and effect axioms formulating how the

action changes the world in terms of the speciﬁed ﬂu-

ents. An action precondition axiom states when an ac-

tion can be executed. The effects that actions have on

the ﬂuents are described by so-called successor state

axioms (Reiter, 2001).

GOLOG (Levesque et al., 1997) is a logic-based

robot programming and plan language based on the

situation calculus. It allows for Algol-like program-

ming but it also offers some non-deterministic con-

structs. A Basic Action Theory (BAT), which is a set

of axioms describing properties of the world, axioms

for actions and their preconditions and effects as de-

scribed above, and some foundational axioms, then

allows for reasoning about a course of action.

There exist various extensions and dialects to the

original GOLOG interpreter, one of which is READY-

LOG (Ferrein and Lakemeyer, 2008). It integrates

several extensions like interleaved concurrency, sens-

ing, exogenous events, and on-line decision-theoretic

planning (following (Boutilier et al., 2000)) into one

framework. In READYLOG only partially speciﬁed

programs are needed which leave certain decisions

open, which then are taken by the controller based on

an optimisation theory. This is done using a Markov

Decision Process (MDP) (Puterman, 1994); decision-

theoretic planning is initiated with solve(p, h), where

p is a GOLOG program and h is the MDP’s solution

horizon). Two important constructs used in this re-

gard are the non-deterministic choice of actions (a|b)

and arguments (pickBest(v, l, p)), where v is a vari-

able, l is a list of values to choose from, and p is a

GOLOG program. Then each occurrence of v is re-

placed with the value chosen. For details we refer

to (Ferrein and Lakemeyer, 2008).

2.2 Related Work

We want to build upon the theory of speech

acts as introduced by Austin (Austin, 1975) and

Searle (Searle, 1969). Based on these works, Cohen

and Levesque (Cohen and Levesque, 1985) already

investigated a formal theory of rational interaction.

We, restrict ourselves to command interpretation and

do not aim for a full-ﬂedged dialogue system. Nev-

ertheless, we follow their formal theory of interpreta-

tion and we carry out our work in the context of the

situation calculus.

The use of deﬁnite clause grammars for parsing

and interpreting natural language has already been

shown in (Beetz et al., 2001). Despite being relatively

ad hoc and the fact that the small grammar only cov-

ered a constrained subset of English, their system pro-

vided a wide spectrum of communication behaviours.

However, in contrast to their approach we want to ac-

count for incomplete and unclear utterances both by

using a larger grammar as well as adding interpreta-

tion mechanisms to the system.

(Fong et al., 2003) developed a system on a robot

platform that manages dialogues between human and

robot. Similar to our approach, input to the system is

processed by task planning. However, queries are lim-

ited to questions that can either be answered with yes

or no or a decimal value. A more advanced system

combining natural language processing and ﬂexible

dialogue management is reported on in (Clodic et al.,

2007). User utterances are interpreted as communica-

tive acts having a certain number of parameters. The

approach is missing a proper conceptual foundation

of objects and actions, though. This makes it hard

to adapt it to different platforms or changing sets of

robot capabilities.

(G¨orz and Ludwig, 2005), on the other hand, built

a dialogue management system well-foundedby mak-

ing use of a concept hierarchy formalised in Descrip-

tion Logics (DL). Both, the linguistic knowledge as

well as the dialogue management are formalised in

DL. This is a very generic method for linking lexi-

cal semantics with domain pragmatics. However, this

comes with the computational burden of integrating

description logics and appropriate reasoning mecha-

nisms. We want to stay within our current represen-

tational framework, that is, the situation calculus and

Golog, and we opt to exploit the capabilities to reduce

computational complexity with combining program-

ming and planning.

3 METHOD & APPROACH

As mentioned before, we cast the language process-

ing of spoken commands on a domestic service robot

as an interpretation process. We decompose this pro-

cess into the following steps. First, the acoustic ut-

terance of the user is being transformed into text via

a speech recognition component which is not part of

this paper’s contribution. The transcribed utterance is

then passed on for syntactic analysis by a grammar.

After that, the interpretation starts, possibly resolving

ambiguities and generating intermediate responses. If

the utterance could be interpreted successfully, it is

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT

executed, otherwise it is being rejected. We will now

present the individual steps in more detail.

3.1 Syntactical Language Processing

Given the textual form of the user utterance, the ﬁrst

thing we do is a syntactical analysis. This syntac-

tic operation uses a grammar. Since the entirety of

the English language is not context-free as revealed

by (Shieber, 1985) and the targeted application do-

main allows for a reasonable restriction, we con-

ﬁne ourselves to directives. Directives are utterances

that express some kind of request. Following Ervin-

Tripp (Ervin-Tripp, 1976) there are six types of direc-

tives:

1. Need statements,

e.g., “I need the blue cup.”

2. Imperatives,

e.g., “Bring me the blue cup!”

3. Imbedded imperatives,

e.g., “Could you bring me the blue cup?”

4. Permission directives,

e.g., “May I please have the blue cup?”

5. Question directives,

e.g., “Have you got some chewing gum?”

6. Hints, e.g., “I have run out of chewing gum.”

Ervin-Tripp characterises question directives and

hints as being hard to be identiﬁed as directives even

for humans. Moreover, permission directives are

mostly used only when the asker is taking a subor-

dinate role, which will not be the case of a human in-

structing a robot. That is why we restrict ourselves to

a system that can handle need statements, imperatives

and imbedded imperatives only.

3.1.1 A Grammar for English Directives

For any of these directives what we need to make the

robot understand the user’s command is to distill the

essence of the utterance. To eventually arrive at this,

we ﬁrst perform a pure syntactic processing of the ut-

terance. An analysis of several syntax trees of such

utterances revealed structural similarities that we in-

tend to capture with a grammar. An example for a

syntax tree is given in Figure 1.

Using common linguistic concepts, the main

structure elements are verb (V), auxiliary verb

(AUX), verb phrase (VP), noun phrase (NP), conjunc-

tion (CON), preposition (PREP), and prepositional

phrase (PP). We further introduce a structure element

object phrase which is a noun phrase, a prepositional

phrase, or concatenations of the two. Multiple verb

phrases can be connected with a conjunction. What

(



PREP

the kitchen

CON

and



fetch

the blue cup

Figure 1: Syntax tree for the utterance ”Go to the kitchen

and fetch the blue cup”.

is more, commands to the robots may be preﬁxed

with a salutation. Also, for reasons of politeness,

the user can express courtesy by saying “please”.

Putting all this together, we arrive at a base grammar

that can be expressed in Extended Backus-Naur Form

(EBNF) (Scowen, 1993) as shown in Figure 2.

s −−> s a l u t a t i o n u t t e ra n c e

s −−> u t te r a n c e

u t t e r an ce −−> ne e d s tatem e n t |

imp e rativ e |

imbedded imperative

need s t a teme n t −−> np vp |

need ph ra se vp

imp e rativ e −−> vp

imbedded imperative −−> aux np vp

need ph ra se −−> ” i ” prompt ” you to ”

% verb ph ra se

vp −−> vp ’

vp −−> vp ’ conj u nctio n vp

vp ’ −−> verb

vp ’ −−> verb obp

vp ’ −−> c o urte s y vp ’

% o b j e ct phrase

obp −−> np | pp

obp −−> np obp | pp obp

% noun phrase

np −−> noun | pronoun

np −−> de t e rmin e r noun

% p ro p o si t i on al phrase

pp −−> prep np

Figure 2: Base grammar in EBNF.

In addition to the base grammar we need a base

lexicon that provides us with the vocabulary for el-

ements such as prepositions, auxiliary verbs, cour-

tesies, conjunctions, determiners, and pronouns. To

generate a system that is functional in a speciﬁc set-

ting, we further need a lexicon containing all verbs for

the capabilities of the robot as well as all the objects

referring to known entities in the world. This depends

on the particular application, though. That is why we

couple this to the domain speciﬁcation discussed later.

The base grammar, the base lexicon, and the domain

speciﬁc lexicon then yield the ﬁnal grammar that is

ICAART 2012 - International Conference on Agents and Artificial Intelligence

used for syntactical processing.

Since we are only interested in the core infor-

mation, the most relevant parts of the utterance are

verbs, objects, prepositions, and determiners. We

can drop auxiliary verbs, ﬁller words, courtesies, and

alike without losing any relevant information. Doing

so, we ﬁnally arrive at an internal representation of

the utterance in a preﬁx notation depicted below, that

we use for further processing.

[

and

, [[Verb, [

objects

, [[Preposition,

[Determiner,Object]],...]] ]], ...]

The list notation contains the keyword and to con-

catenate multiple verb phrases and it uses the key-

word objects to group the object phrase. If an ut-

terance is missing information we ﬁll this with nil

as a placeholder.

3.2 Planning Interpretations

After syntactic pre-processing of an utterance into

the internal representation, the system uses decision-

theoretic planning to arrive at the most likely interpre-

tation of the utterance, given the robot’s capabilities.

The interpretation is supposed to match the request

with one of the abilities of the robot (called a skill)

and to correctly allocate the parameters that this skill

requires.

In order to do that, we need to identify the skill

that is being addressed ﬁrst. We are going about this

from the verb which has been extracted in the syn-

tactical processing, possibly leaving ambiguities on

which skill is referred to by the verb. Secondly, the

objects mentioned in the utterance need to be mapped

to entities in the world that the robot knows about.

Lastly, a skill typically has parameters, and the verb

extracted from the utterance has (multiple) objects as-

sociated to it. Hence, we need to decide which ob-

ject should be assigned to which parameter. To make

things worse, it might very well be the case that we

have either too many or too few objects in the utter-

ance for a certain skill.

We cast understanding the command as a pro-

cess where the single steps are interpretation actions,

that is, interpreting the single elements of the utter-

ance. At this point READYLOG and its ability to

perform decision-theoretic planning comes into play.

The overall interpretation can be modelled as a plan-

ning problem. The system can choose different ac-

tions (or actions with different parameters) at each

stage. Since we want to achieve an optimal interpre-

tation, we make use of decision-theoretic planning.

That is to say, given an optimisation theory, we try

to ﬁnd a plan, i.e. a sequence of actions, which max-

imises the expected reward.

3.2.1 Domain Speciﬁcation

During the interpretation process we need to access

the robot’s background knowledge. We organise this

knowledge to capture generic properties and to make

individual parts available to (only) those components

which need them. Three types of information are dis-

tinguished: linguistic, interpretation, and system. The

linguistic information contains everything that has to

do with natural language while interpretation infor-

mation is used during the interpretation process and

system information features things like the speciﬁc

system calls for a certain skill. The combination of

these three types is then what makes the connection

from natural language to robot abilities. We use ideas

from (Gu and Soutchanski, 2008) to structure our

knowledge within our situation calculus-based repre-

sentation.

In an ontology, for every Skill we store a Name as

an internal identiﬁer that is being assigned to a par-

ticular skill during the interpretation. A skill further

has a Command which is the denotation of the corre-

sponding system call of that skill. Synonyms is a list

of possible verbs in natural language that may refer

to that skill. Parameters is a list of objects that re-

fer to the arguments of the skill, where Name again

is a reference used in the interpretation process, At-

tributes is a list of properties such as whether the pa-

rameter is numerical of string data. Signiﬁcance in-

dicates whether the parameter is optional or required,

and Preposition is a (possibly empty) list of preposi-

tions that go with the parameter. For the information

on entities in the world (e.g. locations and objects)

we use a structure Object which again has a Name

as an internal identiﬁer used during the interpretation.

Attributes is a list of properties such as whether the

object “is a location” or if it “is portable”. Synonyms

is a list of possible nouns that may refer to the ob-

ject and ID is a system related identiﬁer that uniquely

refers to a particular object.

3.2.2 Basic Action Theory

Now that we have put down the domain knowledge on

skills and objects, we still need to formalise the basic

action theory for our interpretation system. We there-

fore deﬁne three actions, namely interpret action,

interpret object, and assign argument. For all three

we need to state precondition axioms and successor

state axioms. We further need several ﬂuents, that de-

scribe the properties of the interpretation domain we

operate in. Let’s take a look at those ﬂuents ﬁrst. We

use the ﬂuents spoken verb(s) and spoken objects(s)

to store the verb and the list of objects extracted in

the syntactic processing. Further, we use the ﬂu-

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT

ents assumed action(s) and assumed objects(s) to

store the skill and the list of objects that we as-

sume to be addressed by the user, respectively. Both

these ﬂuents are nil in the initial situation S

since

no interpretation has taken place so far. The ﬂuent

assumed arguments(s) contains a list of pairings be-

tween parameters and entities. Finally, finished(s)

indicated whether the interpretation process is ﬁn-

ished.

Let us now turn to the three interpretation ac-

tions. The precondition axiom for interpret action

states that interpret action(k) is only possible if we

are not done with interpreting yet and the word k

actually is a synonym of the verb spoken. Sim-

ilarly, interpret ob ject(e) is possible for an entity

e only if we are not ﬁnished and the object (from

spoken object(s)) is a synonym appearing for e. Fi-

nally, the precondition axiom for assign argument for

an entity e and parameter p checks whether the inter-

pretation process is not ﬁnished and there is no en-

tity assigned to the parameter yet. Further, p needs

to be a parameter of the assumed skill and we either

have no preposition for the object or the preposition

we have matches the preposition associated with the

parameter. Lastly, the attributes associated to param-

eter p need to be a subset of the attributes for the en-

tity. To allow for aborting the interpretation process

we additionally introduce an action reject which is

always possible. We omit the formal deﬁnitions here

for space reasons.

After detailing the preconditions of actions, we

now lay out how these actions change the ﬂuents

introduced above. The ﬂuents spoken verb and

spoken objects contain the essence of the utterance to

be interpreted. The effect of the interpret action(k)

action is to reset the ﬂuent spoken verb to nil and

to set the ﬂuent assumed action to the assumed skill

k. The action interpret object(e) iteratively removes

the ﬁrst object (in a list of multiple objects) from

the ﬂuent spoken objects and adds it to the ﬂu-

ent assumed objects along with its preposition (if

available). The action assign argument(p) removes

the object from the ﬂuent assumed objects and it

adds the pair (p, e) for parameter p and entity e

to the ﬂuent assumed arguments. Finally, the ﬂu-

ent ﬁnished is set to true if either the action was

interpret action and there are no more objects to pro-

cess (i.e. spoken objects is empty) or the action was

assign argument and there are no more objects to as-

sign (i.e. assumed objects is empty). It is also set to

true by the action reject.

3.2.3 Programs

Using the basic action theory described above, the

overall interpretation process can now be realised

with READYLOG programs as follows. In case of

multiple verb phrases we process each separately. For

each verb phrase, we ﬁrst interpret the verb. Then, we

interpret the objects before we assign them to the pa-

rameters of the skill determined in the ﬁrst step. The

procedures to do so are

proc interpret verbphrase

solve( {

( pickBest( var, AllActions,

interpret action(var) )

| re ject )

while ¬ finished do

interpret objectphrase endwhile

}, horizon, reward function )

endproc

with

proc interpret objectphrase

(pickBest( var, AllEntities,

interpret ob ject(var) )

| re ject)

if finished then nil

else

(pickBest( var, AllParams,

assign argument(var) )

| re ject)

endif

endproc

where AllActions, AllEntities, and AllParams are

sets of all skills of the robot, all entities known

to the robot, and all parameters of a skill in the

robot’s domain speciﬁcation, respectively. We con-

sider more intelligent selection methods than tak-

ing all items available in the evaluation. The solve-

statement initiates decision-theoretic planning, where

pickBest(var, VarSet, prog) is a non-deterministic

construct that evaluates the program prog with every

possibility for var in VarSet using the underlying op-

timisation theory given mainly by the reward func-

tion, which rates the quality of resulting situations.

To design an appropriate reward function situations

that represent better interpretations need to be given

a higher reward than those with not so good interpre-

tation. A possible reward function could be to give a

reward of 10 if the assumed action is not nil and one

could further add the difference between the number

of assigned arguments and the total number of param-

eters required by the selected skill. Doing so results

in situations with proper parameter assignment being

given higher reward than those with fewer matches. If

to possible interpretation have the same reward, one

can either enquire with the user on which action to

take or simply pick one of them at random.

3.2.4 Example

Consider the exemplary utterance “Move to the

kitchen.” After syntactical processing we have the in-

ternal representation

[

and

, [[move, [

objects

ICAART 2012 - International Conference on Agents and Artificial Intelligence

[[to, [the,kitchen]] ]]] ] ]

. Using the pro-

gram given above and a small basic action theory

as introduced before, one of the skills available to

the robot that has go as a synonym may be goto

which is stored in assumed action by the action

interpret action. Then, interpret object(kitchen) will

assume kitchen as the object (along with the prepo-

sition to). However, it could also interpret “move”

as bringing some object somewhere which leads to a

lower reward, because a parameter slot remains unas-

signed. Trying to assign arguments for the skill goto

may succeed since kitchen is an entity that has the

Location attribute as would naturally be required for

the target location parameter of a goto skill. Compar-

ing the rewards for the different courses of interpre-

tation the system will pick the interpretation with the

highest reward, which is executing the goto(kitchen)

skill.

3.3 Clariﬁcation and Response

Things might not always go as smooth as in our exam-

ple above. To provide a system that has capabilities

beyond a pure interface to translate utterances to sys-

tem calls we therefore include means for clariﬁcation

if the utterance is missing information.

If the verb is missing, our grammar from the syn-

tactical processing will already fail to capture to ut-

terance. Hence, we only consider missing objects for

clariﬁcation in the following. We propose to model

clariﬁcation as an iterative process where the user is

enquired for each missing object. To generate the ap-

propriate questions to the user we make use of the in-

formation that has been extracted from the utterance

already and of the information stored in the ontology.

Assuming that we know about the skill that is being

addressed we can look up the parameters required.

Using a template that repeats the user’s request as far

as it has been interpreted we can then pose an accurate

question and offer possible entities for the missing ob-

jects.

Consider that the user said “Go!” missing the re-

quired target location. So the target location is what

we want to enquire about. This can be achieved with

using a generic template as follows:

“you want me to [assumed action] [assumed arguments].

[preposition] which [attribute] ? [list of entities]”

where [preposition] is the preposition associated

to the parameter in question and [attribute] is one

of the attributes associated to the parameter. Only

including one of the parameter’s attributes seems

incomplete, but suits the application, since it still

leads to linguistically ﬂawless responses. Including

[assumed arguments] in the response indicates what

the system has already managed to interpret and addi-

tionally reminds the user of his original request. The

system would respond to the utterance “Go!” from

above with “You want me to go. To which location?

kitchen or bath?”, which is exactly what we want.

To avoid annoying the user we put a limit on the

number of entities to propose to the user. If the num-

ber of available entities exceeds, say, three we omit

it from the question. Moreover, to improve on the re-

sponse we add what we call “unspeciﬁc placeholders”

to the domain ontology. So for locations we might

add “somewhere” and for portable thing we might add

“something” which are then used in the response at

the position of a missing object.

There might be cases where information is not

missing but instead is either wrong or the skills avail-

able to the robot do not allow for execution. Our sys-

tem should provide information on rejecting faulty or

not executable requests. Depending on the type of

error, we propose the following templates for expla-

nation.

1. “I cannot [spoken verb].” if the verb could not be

matched with any skill, i.e. spoken verb 6= nil.

2. “I do not know what [next spoken object] is.” if

the object could not be matched with any entity

known to the robot, i.e. spoken objects 6= nil.

3. “I cannot [assumed action] [preposition] [next

assumed object].” if the object could not be as-

signed to a parameter of the skill that is being ad-

dressed, i.e. assumed objects 6= nil.

Note that [next some list] retrieves the next ele-

ment from some list. Also note that the ﬂuent values

we mentioned above are sound given our basic action

theory since the action reject sets the ﬂuent ﬁnished to

true and leaves the other ﬂuents’ values as they were

when the utterance was rejected.

4 EXPERIMENTAL EVALUATION

To investigate the performance of our system we eval-

uate it along two dimensions, namely understanding

and responsiveness.

4.1 Understanding

The aim of our approach was to provide a system that

is able to react to as many commands for a domestic

service robot given in natural language as possible.

With the generic grammar for English directives our

approach is able to handle more utterances than pre-

vious approaches based on ﬁnite state grammars such

as (Doostdar et al., 2008). To evaluate how far off we

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT

are from an ideal natural language interface we con-

ducted a user survey. The survey was carried out on-

line with a small group of (about 15) predominantly

tech-savvy students. A short description of the robot’s

capabilities was given and participants were asked to

provide us with sample requests for our system. Par-

ticipants took the survey without any assistance, ex-

cept the task description.

We received a total of 132 submissions. Firstly,

we are interested in the general structure of the an-

swers to see whether our grammar is appropriate.

Therefore, Table 1 shows the submissions itemised by

sentence type.

Table 1: Survey results by sentence type.

absolute relative

type frequency frequency

imperatives

114 87%

imbedded

imperatives

6 5%

need-

statements

2 2%

hints

4 3%

wh-questions

3 2%

others

3 2%

Syntactically speaking, the grammar can cover

imperatives, imbedded imperatives and need-

statements, which make for 92.37% of the survey

results. However, some of these utterances do not

possess the verb-object-structure we assumed in

our system. For example, “Make me a coffee the

way I like it” contained an adverbial (“the way I

like it”) which we did not account for neither in

the grammar nor in the interpretation process. It is

technically possible to treat adverbials as entities

and thus incorporate such utterances. A better

founded approach, however, would be to introduce

the concept of adverbials to our system as a special

case of objects that modify the mode of a skill. We

leave this for future work, though. Still, 77.01%

of the survey entries provide the assumed modular

verb-object-structure and can therefore be processed

by our system successfully.

4.2 Responsiveness

To evaluate the performance of our system in terms

of speed, we evaluated the system using the following

domain. The example agent has four different skills:

getting lost (no parameter), going somewhere (1 pa-

rameter), moving an object to some location (2 pa-

rameters) and moving an object from some location

to some location (3 parameters). Additionally, our

domain contains different entities with appropriate at-

tributes: a kitchen (location), a bath (location), a cof-

fee cup (portable object) and a football trophy (dec-

oration). Some of the synonyms for skills and enti-

ties are ambiguous, namely (1) “go” may refer to “get

lost” as well as to “go somewhere”, (2) “move” may

refer to “get lost”, “go somewhere”, “movesomething

somewhere” or “move something from somewhere to

somewhere”, and (3) “cup” may refer to the coffee

cup as well as to the football trophy.

We tested four different versions of the system

with different requests involving various degrees of

complexity using the following utterances:

(i) “scram”

(ii) “go to the kitchen”

(iii) “could you please move the cup to the kitchen”

(iv) “go to the kitchen and move the cup to the bath

room”

(v) “i need you to move the cup from the bath room

to the kitchen”

Utterance (i) is a very simple request. It addresses

a skill with no parameters and the used synonym

“scram” is unambiguous. The skill addressed in ut-

terance (ii) involves one parameter and the used syn-

onym “go” is ambiguous. Utterance (iii) involves a

skill with two parameters and the synonym “move”

is also ambiguous. Utterance (iv) is the combination

of utterances (ii) and (iii) linked with an “and”. The

skill requested in utterance (v) has three parameters

and the synonym “move” is again ambiguous.

The depth of the search tree spanned in the plan-

ning process depends on the number of objects. For

example, the depth of the search tree for utterance (i)

is exactly 1 while the depth of the search tree for ut-

terance (v) is 7. Note that utterance (iv) involves two

distinct search trees, since it contains two independent

verb phrases which are interpreted separately.

The ﬁve utterances were tested with the following

versions of the system. First, we used the base sys-

tem as described in Section 3, it does not include any

explicit performance improvements speed-wise. The

ﬁrst row of Table 2 shows the performance of the base

system.

4.2.1 Improvements

Second, we considered systems incorporating differ-

ent pre-selection methods. For each interpretation

step (interpreting action, entity and parameter), we

can pre-select the candidates that may be considered

by the appropriate interpretation action. This can lead

to considerably lower branching factors.

The pre-selection process for interpret action in-

volves two criteria: synonym and parameter count.

This means that candidates are eliminated from the

ICAART 2012 - International Conference on Agents and Artificial Intelligence

Table 2: Response times in different test scenarios.

i ii iii iv v

base

0.08 s 0.28 s 2.37 s 2.67 s 9.06 s

action

pre-select

0.08 s 0.24 s 2.10 s 2.29 s 7.15 s

entity

pre-select

0.06 s 0.19 s 2.01 s 2.16 s 7.41 s

parameter

pre-select.

0.09 s 0.19 s 1.06 s 1.20 s 4.05 s

action +

entity

0.05 s 0.16 s 1.70 s 1.85 s 6.07 s

entity +

parameter

0.05 s 0.13 s 0.99 s 1.10 s 3.75 s

action +

parameter

0.09 s 0.13 s 0.71 s 0.83 s 2.52 s

full com-

bination

0.07 s 0.10 s 0.68 s 0.76 s 2.35 s

list if the spoken verb is not one of the candidates’

synonyms or if the number of parameters the candi-

date provides is lower than the number of spoken ob-

jects. This is due to the fact that we want everyspoken

object to be assigned to a parameter slot, so we only

haveto consider skills that providea sufﬁcientamount

of parameter slots. If we would also consider skills

with fewer parameters, we would have to drop parts

of the user’s utterance. One could argue that reducing

the set of available skills is a restriction from a theo-

retical point of view. However, ignoring elements that

where uttered could easily frustrate the user. Hence,

the restriction only has little practical relevance. The

second row of Table 2 illustrates the performance of

the base system plus action pre-selection.

Entities are pre-selected just by checking whether

the spoken object is one of the entity’s synonyms. The

third row of Table 2 shows the response times includ-

ing the base system plus entity pre-selection.

Pre-selecting parameters involves checking the at-

tributes and the preposition of the corresponding can-

didate. Hence, the attributes of the parameter slot

have to be a subset of the entities attributes, and if

a preposition was provided along with the spoken ob-

ject or entity, respectively, then it has to match the

preposition required by the parameter. The fourth row

of Table 2 lists response times of the base system plus

parameter pre-selection. Rows ﬁve, six and seven il-

lustrate the performance of different pairs of the three

pre-selection methods. The last row shows the per-

formance of the system including all three enhance-

ments. As we can see, the full combination yields an

improvement except for utterance i where the differ-

ence is negligible. The relative improvement of the

enhancements increases with the complexity of the

utterances. That is to say, the more complex the ut-

terance, the more the speed-ups pay off.

Altogether, the complexity of the search tree is af-

fected by the different branching factors at each level,

and the depth which depends on the number of spo-

ken objects. The branching factor at the ﬁrst level de-

pends on the number of actions that have the spoken

verb as a synonym. The branching factor at the sec-

ond level depends on the number of entities that have

the spoken object as a synonym. At the third level the

branching factor depends on the number of parame-

ters of the respective skill. We further evaluated our

optimised system by varying the two complexity fac-

tors independently.

Along the rows of Table 3 we varied the number

of spoken objects. Along the columns we varied the

number of actions that have the spoken verb as a syn-

onym and the number of entities that have the spoken

object as a synonym. The number of parameters of

the appropriate skill are not varied, since this num-

ber already depends on the amount of spoken objects.

In this test scenario the parameters of a skill became

distinguishable for the system by providing distinct

prepositions for each parameter. Different entities be-

came distinguishable through their attributes and the

skills were distinguishable by the number of parame-

ters. So we had ﬁve skills with 1, 2, 3, 4 and 5 param-

eters, respectively.

Table 3: Response times (in seconds) depending on the two

types of difﬁculty.

# of tree #actions/#entities

obj. depth 1/1 1/5 5/1 5/5

1 3 0.15 0.32 0.48 1.27

2 5 0.47 0.96 1.61 3.50

3 7 2.54 4.83 7.40 13.92

4 9 18.77 34.00 39.72 68.19

5 11 153.40 267.55 154.97 276.20

Table 3 shows that the number of spoken objects

has a greater inﬂuence on the computation time than

has ambiguity. This is indicated by the last two rows

which only contain measurements greater than 10 sec-

onds. That is unacceptable for ﬂuent human-robot

interaction. We can also observe that action pre-

selection performs very well in this test scenario. All

tests in the last row address a skill with ﬁve param-

eters. In this test scenario there was no other skill

involving ﬁve or more parameters. As a consequence,

the action pre-selection can rule out the other four

skill candidates which implies nothing less than re-

ducing the branching factor of the top node from 5 to

1 and thus reducing the computation time by a factor

of approximately 5. This also results in comparable

computation times for the combinations 1/1 (153.40

sec) and 5/1 (154.97 sec) as well as 1/5 (267.55 sec)

and 5/5 (276.20 sec).

Finally, we analysed whether the lexicon size

poses a computational problem. Therefore, we sim-

ply added 50,000 nouns to the lexicon and used the

full combination test setup from Table 2. Now, Ta-

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT

ble 4 indicates that the additional computational effort

to process the utterances with a large lexicon plays no

signiﬁcant role.

Table 4: Response times with different lexicons.

small lexicon large lexicon

utt. i 0.07 sec 0.08 sec

utt. ii 0.10 sec 0.14 sec

utt. iii 0.68 sec 0.90 sec

utt. iv 0.76 sec 1.15 sec

utt. v 2.35 sec 2.51 sec

4.3 Discussion

An important point towards successful human-robot

interaction with respect to the user’s patience is the

system’s reaction time. The average human atten-

tion span (for focused attention, i.e. the short-term

response to a stimulus) is considered to be approx-

imately eight seconds (Cornish and Dukette, 2009).

Therefore, the time we require to process the utter-

ance of a user and react in some way must not exceed

8 seconds. Suitable reactions are the execution of a

request, rejection, or to start a clariﬁcation process.

Hence, the question whether computation times

are reasonable is in fact the question whether the com-

putation times exceed eight seconds. Nonetheless, the

answer is not as easy as the question. The optimised

system performs well in a realistic test scenario as

shown by the last row of Table 2. In turn, complex test

scenarios can lead to serious problems as Table 3 in-

dicated. However, we saw that ambiguity is a smaller

problem than the length of an utterance

. Skills that

havemore than three parameters are rare in the ﬁeld of

mobile service robots. In fact, the skills with four or

ﬁve parameters we used in the tests of Table 3 needed

to be created artiﬁcially in lack of realistic examples.

5 CONCLUSIONS & FUTURE

WORK

We presented a system for interpreting commands

issued to a domestic service robot using decision-

theoretic planning. The proposed system allows for

a ﬂexible matching of utterances and robot capabili-

ties and is able to handle faulty or incomplete com-

mands by using clariﬁcation. It is also able to provide

explanations in case the user’s request cannot be exe-

cuted and is rejected. The system covers a broader set

By the length of an utterance, we mean the number of

spoken objects.

of possible requests than existing systems with small

and ﬁxed grammars. Also, it performs fast enough to

prevent annoying the user or loosing his or her atten-

tion.

Our next step is to deploy the system in a

RoboCup@Home competition to test its applicability

in a real setup. A possible extension of the approach

could be to include a list of the n most probable in-

terpretations and to verify with the user on which of

these should be executed. Moreover, properly inte-

grating the use of adverbials as qualiﬁers for nouns

both in the grammar and the interpretation process

would further improve the system’s capabilities.

REFERENCES

Austin, J. L. (1975). How to Do Things with Words. Harvard

University Press, 2 edition.

Beetz, M., Arbuckle, T., Belker, T., Cremers, A. B., and

Schulz, D. (2001). Integrated plan-based control of

autonomous robots in human environments. IEEE In-

telligent Systems, 16(5):56–65.

Boutilier, C., Reiter, R., Soutchanski, M., and Thrun, S.

(2000). Decision-theoretic, high-level agent program-

ming in the situation calculus. In Proc. of the 17th

Nat’l Conf. on Artiﬁcial Intelligence (AAAI-00), pages

355–362. AAAI Press/The MIT Press.

Clodic, A., Alami, R., Montreuil, V., Li, S., Wrede, B.,

and Swadzba, A. (2007). A study of interaction be-

tween dialog and decision for human-robot collabora-

tive task achievement. In Proc. Int’l Symposium on

Robot and Human interactive Communication (RO-

MAN’07), pages 913–918. IEEE.

Cohen, P. R. and Levesque, H. J. (1985). Speech acts and

rationality. In Proc. of the 23rd Annual Meeting on

Association for Computational Linguistics, pages 49–

60.

Cornish, D. and Dukette, D. (2009). The Essential 20:

Twenty Components of an Excellent Health Care

Team. RoseDog Books.

Doostdar, M., Schiffer, S., and Lakemeyer, G. (2008). Ro-

bust speech recognition for service robotics applica-

tions. In Proc. of the Int’l RoboCup Symposium 2008

(RoboCup 2008), pages 1–12. Springer.

Ervin-Tripp, S. (1976). Is Sybil there? The structure of

some American English directives. Language in Soci-

ety, 5(01):25–66.

Ferrein, A. and Lakemeyer, G. (2008). Logic-based robot

control in highly dynamic domains. Robotics and Au-

tonomous Systems, 56(11):980–991. Special Issue on

”Semantic Knowledge in Robotics”.

Fong, T., Thorpe, C., and Baur, C. (2003). Collabora-

tion, dialogue, human-robot interaction. In Robotics

Research, volume 6 of Springer Tracts in Advanced

Robotics, pages 255–266. Springer.

G¨orz, G. and Ludwig, B. (2005). Speech Dialogue Systems

- A Pragmatics-Guided Approach to Rational Interac-

tion. KI–K¨unstliche Intelligenz, 10(3):5–10.

ICAART 2012 - International Conference on Agents and Artificial Intelligence

Gu, Y. and Soutchanski, M. (2008). Reasoning about large

taxonomies of actions. In Proc. of the 23rd Nat’l

Conf. on Artiﬁcial Intelligence, pages 931–937. AAAI

Press.

Levesque, H. J., Reiter, R., Lesp´erance, Y., Lin, F., and

Scherl, R. B. (1997). Golog: A logic programming

language for dynamic domains. J Logic Program,

31(1-3):59–84.

McCarthy, J. (1963). Situations, Actions, and Causal Laws.

Technical Report Memo 2, AI Lab, Stanford Univer-

sity, California, USA.

Puterman, M. L. (1994). Markov Decision Processes: Dis-

crete Stochastic Dynamic Programming. John Wiley

& Sons, Inc.

Reiter, R. (2001). Knowledge in Action. Logical Founda-

tions for Specifying and Implementing Dynamical Sys-

tems. MIT Press.

Scowen, R. (1993). Extended bnf – generic base standards.

In Proc. of the Software Engineering Standards Sym-

posium, pages 25–34.

Searle, J. R. (1969). Speech Acts: An Essay in the Phi-

losophy of Language. Cambridge University Press,

Cambridge, London.

Shieber, S. (1985). Evidence against the context-freeness

of natural language. Linguistics and Philosophy,

8(3):333–343.

Wisspeintner, T., van der Zant, T., Iocchi, L., and Schiffer,

S. (2009). Robocup@home: Scientiﬁc Competition

and Benchmarking for Domestic Service Robots. In-

teraction Studies. Special Issue on Robots in the Wild,

10(3):392–426.

FLEXIBLE COMMAND INTERPRETATION ON AN INTERACTIVE DOMESTIC SERVICE ROBOT
