THE COMBINATION OF HMAX AND HOGS IN AN ATTENTION

GUIDED FRAMEWORK FOR OBJECT LOCALIZATION

Tobias Brosch and Heiko Neumann

Institute of Neural Information Processing, Ulm University, Ulm, Germany

Keywords:

Combination of HMAX and HOGs, Attention, Object localization, Performance evaluation.

Abstract:

Object detection and localization is a challenging task. Among several approaches, more recently hierarchical

methods of feature-based object recognition have been developed and demonstrated high-end performance

measures. Inspired by the knowledge about the architecture and function of the primate visual system, the

computational HMAX model has been proposed. At the same time robust visual object recognition was

proposed using feature distributions, e.g. histograms of oriented gradients (HOGs). Since both models build

upon an edge representation of the input image, the question arises, whether one kind of approach might be

superior to the other. Introducing a new biologically inspired attention steered processing framework, we

demonstrate that the combination of both approaches gains the best results.

1 INTRODUCTION

Finding objects in images is a key task for a variety of

important applications. The visual input stream pro-

vides various features among which edges serve as

powerful clues for object detection. Exploiting edge

maps, hierarchical methods of feature-based object

recognition have recently been developed and demon-

strated high-end performance measures. Inspired by

the known function and architecture of the primate vi-

sual system, the computational HMAX model (Serre

et al., 2005; Mutch and Lowe, 2008) has been pro-

posed. At the same time robust visual object recogni-

tion was proposed using histograms of oriented gra-

dients (HOGs) (Dalal and Triggs, 2005). Since both

models build upon an edge representation of the in-

put image, we explore, whether one kind of feature is

superior to the other.

• The HMAX mechanism constitutes a hierarchical

model applying iteratively mechanisms of feature

combination and pooling. It compares small parts

of an intermediate representation in a template

like fashion to obtain individual features (Mutch

and Lowe, 2008).

• In contrast to the template matching applied in the

HMAX model, the HOGs describe local distribu-

tions of features derived from the input, namely

contrasts in the luminance image. These distribu-

tions are calculated for regular-subdivision in in-

put images and normalized by the distributions in

the discretized neighborhood. HOGs thus can be

considered as a likelihood of the presence of cer-

tain structure and its distribution in the input data.

Though being quite different in their processing na-

ture, both mechanisms provide some scale and po-

sition invariance and build upon an initial edge rep-

resentation of the input scene. We explore whether

the two feature types constitute in a similar way to

the classiﬁcation result or if they signiﬁcantly facil-

itate each other when used in combination. This

exploration is done proposing a generic coarse-to-

ﬁne framework for object localization utilizing sev-

eral standard techniques of past research. It suggests a

systematic way to combine multiple processing chan-

nels which are by no means limited to the features

used in this work. To compare it with previous results,

evaluation is done on two different datasets consisting

of different object types. We demonstrate state of the

art performance on a car data set presented in (Agar-

wal et al., 2004a) and show that it is also suited for dif-

ferent object categories such as pedestrian on a subset

of the very challenging Daimler Pedestrian set (En-

zweiler and Gavrila, 2009). The results demonstrate

that neither feature type alone represents a complete

description of the input and that classiﬁcation signiﬁ-

cantly beneﬁts from the combination of both types.

The remaining part of this paper is organized as

follows: We describe the novel framework of object

localization in section 2, the data sets are presented

281

Brosch T. and Neumann H. (2012).

THE COMBINATION OF HMAX AND HOGS IN AN ATTENTION GUIDED FRAMEWORK FOR OBJECT LOCALIZATION.

In Proceedings of the 1st International Conference on Pattern Recognition Applications and Methods, pages 281-288

DOI: 10.5220/0003708702810288

 SciTePress

in section 3, results are shown in section 4 and ﬁnally

we discuss the results and the connection to previous

work in section 5.

2 ARCHITECTURE

The overall architecture is described in two parts:

1. The basic processing framework combining

HMAX and HOGs (histogram of oriented gradi-

ents) features to end up with an assembly of view

tuned units (VTUs) indicating presence of a target

object at a given location and scale.

2. An attention guided region of interest (ROI) se-

lector component inspired by the architecture of

(Hamker, 2005). It combines coarse-to-ﬁne pro-

cessing (Schyns and Oliva, 1994) and the idea

of cascaded classiﬁers (Viola and Michael, 2001;

Zhu et al., 2006; Heisele et al., 2001) to focus pro-

cessing on relevant parts of the input scene.

The suggested processing framework is illustrated in

Figure 1.

2.1 Preprocessing

The processing starts with a two-level hierarchy. In

addition to plain edge detection using a Gabor stage,

we introduce a normalization step to compensate dif-

ferent illumination conditions of the input image I by

a center surround normalization mechanism given by

norm

I − G

∗ I

1 + I + G

∗ I

, (1)

where G

is a Gaussian with standard deviation σ = 2

and the operator ∗ denotes the spatial convolution op-

erator. The resulting activities are mapped to a range

of [0, 1]. The edges are extracted by the convolution

of I

norm

with 2D-Gabor-ﬁlters of six different orienta-

tions to generate pairs of oriented response maps. The

Gabor ﬁlters are described by

G(x,y) =

2πσ

exp



−

+ y





exp



2πi f



(2)

where f

= 0.25 pixels and σ is chosen for half-

magnitude overlap of adjacent Gabor-envelopes (ro-

tated for different orientations). Last, the energy

response of the complex-valued Gabor-responses

(i.e. the absolute value of the complex ﬁlter response)

forms the S1 layer activities which deﬁne an (x, y, θ)-

space that is input for further processing along two

parallel streams, namely HMAX and HOGs.

2.2 Selective Feature Channels

After the S1 stage, processing splits into two streams

composed of the different feature processing ap-

proaches, namely HMAX and HOGs respectively. A

discussion of their function follows below.

• HMAX: To provide better comparability to the

single scale HOGs features (see below), we de-

cided to employ a single scale HMAX scheme in

contrast to the multiple scales and max-pooling

across scales in (Mutch and Lowe, 2008). For

completeness, we brieﬂy summarize the process-

ing steps of their approach which aim to pro-

vide a certain amount of position and scale in-

variance by iterative application of feature com-

bination (simple cells “S”) and pooling mecha-

nisms (complex cells “C”): Layer C1 responses

are computed using max-ﬁltering on the S1-layer

(Gabor-ﬁlter responses) of size 3 × 3. During

training small patches P of size n × n × p

, n ∈

{4,8,12,16}, p

= 6 (p

is the number of edge

orientations) are extracted from this layer, then

sparsiﬁed, rated and selected by the classiﬁer.

During testing, a patch P is compared to each re-

gion X of C1 units using a Gaussian radial ba-

sis function to obtain a similarity estimate of each

patch:

R(X,P) = exp



−

kP − Xk

2ασ



, (3)

As in (Mutch and Lowe, 2008) the standard devi-

ation σ is set to 1. To compensate for the effect

of comparison in the higher dimensional space in

the case of n ∈ {8,12,16}, the normalization fac-

tor α is set to α = (n/4)

. The maximal response

of a patch in a small neighborhood of its origi-

nal position in its training image forms an entry in

the C2 feature vector. Depending on the searched

scale of a target object (i.e. search for a near or

distant object) the neighborhood is adjusted. We

set the neighborhood arbitrarily to 10% of the es-

timated object size (given by the dataset) which

seems to work well. This results in different C2

layers (red, green and blue ellipses in Figure 1),

each layer representing an (x,y, f ) space, where f

is the number of patches or, more generally, the

number of features.

• HOGs: We chose the basic variant of HOG fea-

tures using square cells and square blocks adopt-

ing the best parameters as described in (Dalal and

Triggs, 2005) (for the pedestrian set we adopted

parameters from (Enzweiler and Gavrila, 2009)).

To allow for better comparison, we chose the same

input (the previously described S1 stage) to both

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

282

Input Image

HOGs HMAX

VTUs

car

...

max

mean

Preprocessing

Orientation Selective

Responses

Energy Response

max

Figure 1: General architecture: The input image is preprocessed and Gabor ﬁltered (layer S1). Subsequent processing results

in a feature vector of two different types of features (layer C2, big red ellipses correspond to all locations of small target

objects, small blue ellipses to all possible locations of large target objects) at each possible location and scale of a target

object. The right side illustrates the HMAX processing, the left side the creation of the HOG features. The ﬁnal stage of

the processing cascade is formed by view tuned units (VTUs). These encode the likelihood of the presence of a target object

at a given location and scale (e.g. likelihood of presence of a car). Please note, that for the purpose of better readability, we

omitted the component of attentional guidance (please see text section 2.4).

feature types, HMAX and HOGs. Note, how-

ever, that according to (Dalal and Triggs, 2005)

the common S1 layer (which is chosen to allow

comparability to the HMAX features) might not

be optimal for HOG features due to the slightly

smoothing nature of a Gabor ﬁlter. The scene is

split into small cells of size 6 × 6 pixels across

all orientations. For each orientation the mean is

taken and normalized across the 3 × 3 neighbor-

ing cells (so called blocks) using L2 normaliza-

tion. Similar to adjusting the neighborhood in the

HMAX processing stream, we adjusted cell size

to end up with the same number of features at each

scale (i.e. the layers searching for near and distant

objects; red, green and blue circles in Figure 1).

In analogy to the HMAX stream, the computa-

tions yield a similar C2 layer structure, wherein

each layer represents an (x,y, f ) space.

2.3 Channel Fusion and View-tuned

Representations

The ﬁnal stage for feature processing is formed by

View Tuned Units (VTUs) (Riesenhuber and Poggio,

1999a; Riesenhuber and Poggio, 1999b; Jiang et al.,

2006). A VTU encodes the likelihood of presence of

a certain object at its position and scale (e.g. a VTU at

the center for large objects specialized for cars). Once

the activity of each VTU is known the most likely

presence of an object is given by the correspond-

ing object-VTU having maximal activity. To obtain

a suitable measure of object presence, we chose an

early fusion mechanism (i.e. the combination of our

intermediate C2 feature vectors of each feature type

at each position and scale forms the input to a classi-

ﬁer. The activity of a VTU at this location and scale

is then given by the output of the classiﬁer). In con-

trast to a late fusion mechanism, which directly results

in VTUs (or another intermediate representation) for

each feature type, the early fusion variant employed

here has the advantage that no additional fusion mech-

anism for this second intermediate level is required.

2.4 Attention Guided Region of Interest

Selector Framework

The extensive search of a large input scene using a

strong classiﬁer at several locations leads to an unfa-

vorable computational cost. In order to reduce those

costs we apply several concepts and principles of

THE COMBINATION OF HMAX AND HOGS IN AN ATTENTION GUIDED FRAMEWORK FOR OBJECT

LOCALIZATION

283

computational mechanisms that have been success-

fully employed in previous work.

• Coarse-to-Fine Processing (CtF). Experimental

investigations have shown that early visual pro-

cessing in humans is dominated by coarse fea-

tures in contrast to ﬁne grained details which seem

to dominate later processing stages (Schyns and

Oliva, 1994). From a computational point of

view, several studies applied the principle of CtF

processing and reported signiﬁcant beneﬁts, e.g.

(Pedersoli et al., 2010; Amit et al., 2004).

• Cascaded Classiﬁers. Recent approaches

showed that the computational cost of extensive

object search can be greatly reduced by applying

a cascade of detectors (Viola and Michael, 2001;

Zhu et al., 2006; Heisele et al., 2001). Iteration

of a process that allows to discard many locations

from further processing at an early stage greatly

reduces processing time while maintaining a high

classiﬁcation rate.

• Inhibition of Return and Neighborhood Sup-

pression (IOR-Nsupp). Once a suspected or ﬁ-

nal target position is found the surrounding re-

gion can be suppressed, enabling the detection of

further candidate locations (IOR) and sparsifying

the amount of locations to be searched (Nsupp).

This can be formulated in a dynamic framework

(Hamker, 2005) as well as in a static context

(Agarwal et al., 2004a; Mutch and Lowe, 2008).

We apply the neighborhood suppression described

in (Agarwal et al., 2004a) with the parameters of

(Mutch and Lowe, 2008).

Our attention guided region of interest selector frame-

work combines elementary principles of each of these

three mechanisms: We use a simple cascade of two

classiﬁers which already resulted in promising results

(this can be extended to support multiple resolution

layers as well as multiple classiﬁers). The ﬁrst classi-

ﬁer is applied only on the features obtained from the

input image that has been downsampled to a quarter

of the original resolution (CtF processing). To pre-

vent that possible target locations are discarded, the

early stage classiﬁer output behavior is biased to a

low rejection rate which can be trained and set to a

desired false rejection rate (Viola and Michael, 2001;

Zhu et al., 2006; Heisele et al., 2001). To evaluate

the VTU responses, we apply the IOR-Nsupp mech-

anism to identify target locations of the next classi-

ﬁer which is applied on the features of the full resolu-

tion input (at this level experimental evaluation sug-

gested 60% of the neighborhood suppression of the

ﬁnal classiﬁcation stage to facilitate a low rejection

rate). After the ﬁnal classiﬁer is applied, object loca-

tion estimates are created under consideration of the

IOR-Nsupp mechanism.

3 TEST SETS

The evaluation of the proposed model is done on two

different data sets. We chose the UIUC car data set

(Agarwal et al., 2004a) to compare our model to the

results presented in (Mutch and Lowe, 2008). To

demonstrate generalizability to a different kind of ob-

jects we took a subset of the very challenging Daim-

ler Pedestrian data set (Enzweiler and Gavrila, 2009).

Please note, that we chose a one layered architecture

of HMAX and that the edge input to HOGs are subop-

timal according to (Dalal and Triggs, 2005) in order

to allow direct comparability between the two feature

types. Consequently the performance of each feature

type might suffer a bit compared to the optimal im-

plementation.

3.1 UIUC Car Data Set

Figure 2 shows some sample images of the UIUC car

data set (Agarwal et al., 2004a). It contains images

of side views of cars for use in evaluating object de-

tection algorithms. It comprises 1,050 training im-

ages, a single-scale test sequence and 108 multi-scale

test images containing 139 cars at various scales and

some evaluation ﬁles (Agarwal et al., 2004b). We will

concentrate on the multiple scales test sequence since

our model achieved almost perfect results on the sin-

gle scale scenario like reported in (Mutch and Lowe,

2008). The evaluation program of (Agarwal et al.,

2004b) results in three measures, namely recall, pre-

cision and F-measure (the harmonic mean of preci-

sion and recall).

Table 1: Symbols used in deﬁning performance mea-

surement quantities with their accompanying meanings

(cf. (Agarwal et al., 2004a)).

symbol

meaning

T P Number of true positives

FP Number of false positives

FN Number of false negatives

nP Total number of positives in data set

(nP = T P + FN)

Using the notation of table 1, these are deﬁned as

Rec =

T P

T P + FN

T P

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

284

Figure 2: Sample images of the car data set of (Agarwal et al., 2004a). First row: test images containing side-views of cars at

multiple scales. Second row: left: negative training images, right: positive training images.

Prec =

T P

T P + FP

F-measure =

2 · Rec · Prec

Rec + Prec

(4)

It is only when both recall and precision have high

values that the F-measure is close to one.

3.2 Daimler Pedestrian Data Set

Figure 3 visualizes some of the images of the Daim-

ler benchmark (Enzweiler and Gavrila, 2009). The

training set contains 15,560 pedestrian samples and

6,744 full images not containing any pedestrians. The

test sequence consists of 21,790 images with 56, 492

pedestrian labels. It was captured from a vehicle dur-

ing a 27 min drive through urban trafﬁc at a resolution

of 640× 480 pixels. Only pedestrians of a height of at

least 72 pixels must be detected. Detection of smaller

pedestrians, partially occluded pedestrians, cyclists,

etc. are optional and are not counted as detection or

false positive. Using the ratio of intersection area and

union area of the bounding boxes of a system alarm

and a ground-truth event e

Γ(a

) =

A(a

∩ e

)

A(a

∪ e

)

, (5)

a correct detection is given if Γ(a

) > 0.25.

Due to computational resource constraints we

trained our model on only 5,000 positive and 5, 000

negative training images without any bootstrapping

and evaluated it on the 1,846 images containing at

least one pedestrian of at least 72 pixels height.

4 RESULTS

4.1 Feature Types

We pose the question whether HMAX or HOGs fea-

tures encode the same information or whether they

provide supplementary information and thus mutually

support for each other. This question is quite difﬁcult

to answer. From a theoretical point of view, HOGs

as well as HMAX features consist of an assembly of

nonlinear operations which are hard to compare. Thus

we concentrate on an experimental evaluation. Per-

forming initial tests using three different classiﬁers

(AdaBoost (Freund and Schapire, 1997) using a de-

cision tree classiﬁer, Gaussian kernel SVM and lin-

ear SVM

we chose a linear SVM classiﬁer which

constantly resulted in good classiﬁcation results at a

reasonable training and classiﬁcation time. We did

a systematic evaluation of three different variants of

the suggested architecture, the fusion of processing

channels (full model, see Figure 1) and ones with

only one channel being active. Based on these re-

sults, we found that it is the combination of HMAX

and HOGs features that results in the best perfor-

mance compared to either feature type alone (Table 2

shows the results along with comparable previous re-

sults. (Lampert et al., 2008) reported a F-measure of

98.6%. However, they used a spatial pyramidal struc-

ture that does not compare well to our single scale

variant which allows for comparison with HMAX fea-

tures). Taking into account the standard deviation, the

performance gain is signiﬁcant. To exclude the pos-

sibility of a wrong classiﬁcation bias, we calculated

a precision-recall curve which is displayed in Figure

4. It clearly shows that the combination of HMAX

and HOGs channels performs best compared to either

channel alone.

To assure independence of the evaluated data set,

we applied our model to the task of pedestrian detec-

tion using a subset of the challenging Daimler Pedes-

trian set (see section 3.2). We just adjusted the HOG

parameters to those given in (Enzweiler and Gavrila,

2009) choosing a scale factor of 1.25 (most similar to

their parameter set S

) and left everything else identi-

See (Fradkin and Muchnik, 2006) for more details on

support vector machine classiﬁers; we used the implemen-

tation of (Fan et al., 2008).

THE COMBINATION OF HMAX AND HOGS IN AN ATTENTION GUIDED FRAMEWORK FOR OBJECT

LOCALIZATION

285

Figure 3: Sample images of the pedestrian data set of (Enzweiler and Gavrila, 2009). First row: positive training images,

second row: images containing no pedestrians to generate negative training images and third row: test images.

Table 2: Results on the multiple scales car detection task (at Recall=Precision=F-measure). Scores of our model are the

average of 8 independent runs along with standard deviation. Scoring methods were those of (Agarwal et al., 2004a). Note

that despite the lower classiﬁcation rate of our simpliﬁed HMAX model compared to (Mutch and Lowe, 2008) and the

suboptimal input to the HOG features (to provide comparability), the feature combination of HMAX and HOGs features

compensates for it.

Model Performance

Agarwal et al. (Agarwal et al., 2004a) 39.6%

Fritz et al. (Fritz et al., 2005) 87.8%

Mutch & Lowe (Mutch and Lowe, 2008) (sophisticated HMAX) 90.6%

Our model (only HMAX) 84.08% ± 1.4%

Our model (only HOGs) 68.35%

Our model (HMAX&HOGs) 90.83% ± 1.2%

cal. Due to computational constraints we limited our-

selves to a subset of the very large dataset presented

in (Enzweiler and Gavrila, 2009) with still consider-

able extent (see section 3.2 for details, evaluation took

multiple weeks of CPU-time). To allow for compari-

son with the results of (Enzweiler and Gavrila, 2009)

we supplemented the precision measure by the false

positives per frame measure. The resulting false pos-

itives per frame-recall curve is visualized in Figure 5.

This conﬁrms that the combination of features gains

best performance.

4.2 Region of Interest Selector

Variations

In section 2.4 we presented a novel region of interest

selector framework combining several state of the art

techniques. In addition to the examination of HMAX

and HOGs features we explored the impact of the

different processing stages of our coarse-to-ﬁne ar-

chitecture. We compared four conﬁgurations of our

novel model:

1. The entire Coarse to Fine model as described in

section 2.

2. The model using only the Coarse resolution part.

3. A variant of processing the entire image at its

Coarse and Fine level (i.e. no selective process-

ing on the high resolution part is done).

4. The model using only the Fine resolution part thus

omitting the coarse level and its contribution.

Results are visualized in Figure 6. It shows that each

resolution level itself does not perform as well as the

model variants using both resolution levels. The two

variants using both resolution levels (i.e. the Coarse

and Fine and Coarse-to-Fine variants) perform almost

identically. This demonstrates that the coarse infor-

mation is sufﬁcient to arouse attention to the relevant

target locations. Even more interesting is the signif-

icant beneﬁt of the Coarse-to-Fine architecture. The

measured processing time of the high resolution fea-

tures of the Coarse-to-Fine variant is just about 15%

of the processing time of the Coarse and Fine variant.

Of course the processing can be highly parallelized.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

286

0 0.1 0.2 0.3 0.4

0.6

0.65

0.7

0.75

0.8

0.85

0.9

0.95

1−Precision

Recall

Precision−Recall−Curve UIUC Car Data Set

HMAX and HOGs

HMAX

HOGs

Figure 4: Precision-recall curves of the combination of

HMAX and HOG features in comparison to classiﬁcation

results using either feature alone on the UIUC car data set.

The “X” marks the system output without any bias. Note,

that for the sake of comparison, the input to the HOG fea-

tures is not optimal.

−2

−1

0.2

0.4

0.6

0.8

False Positives Per Frame

Recall

Precision−Recall−Curve Daimler Pedestrian Subset

HMAX and HOGs

HMAX

HOGs

Figure 5: False positives per frame-recall curves of the com-

bination of HMAX and HOG features in comparison to

classiﬁcation results using either feature alone on a subset

of the Daimler Pedestrian set. The “X” marks the system

output without any bias (note that only a subset was used

for training as well as testing; compare to (Enzweiler and

Gavrila, 2009) their Figure 6d subset S

However, even if one had unlimited parallel process-

ing resources, the architecture signiﬁcantly limits the

amount of used data. A course resolution image is

sufﬁcient to predict target locations with a high pre-

cision. This can be very handy in a surveillance sce-

nario there a large region can be watched using a wide

angle camera. A controllable camera can then focus

on relevant parts of the scene and conﬁrm respectively

decline presence of an object at this location.

0 0.1 0.2 0.3 0.4

0.6

0.65

0.7

0.75

0.8

0.85

0.9

0.95

1−Precision

Recall

Precision−Recall−Curve UIUC Car Data Set

Coarse-to-Fine

Coarse

Coarse and Fine

Fine

Figure 6: Precision-recall curves of the proposed coarse-to-

ﬁne architecture in comparison to components of it on the

UIUC car data set.

5 DISCUSSION

Among several approaches, more recently local fea-

ture descriptors based on edge maps demonstrated

high-end performance measures. We explored the

combination of two commonly used feature descrip-

tors for object detection and localization and our re-

sults show that it is worth investigating feature combi-

nations from hierarchical feature processing based on

ﬁltering and max-selection (HMAX) as well as fea-

ture distributions (HOGs). Our research demonstrates

that (though being based on the same input) both

feature types facilitate each other and result in im-

proved classiﬁcation performance in different tasks.

Despite using only simple variants of two different

processing variants based on the same kind of im-

age features (edges) at only two different spatial res-

olutions, we showed state of the art performance on

the UIUC car data set (Agarwal et al., 2004a). The

simpliﬁed basic variants of the feature descriptors

were chosen to provide comparibility between the two

kinds of feature descriptors. Consequently, all re-

sults can be further improved by using the complete

models as described in the given literature. In addi-

tion, we presented a novel general architecture com-

bining elementary principles of previous work in a

schematic way that eases extensions in several direc-

tions. We demonstrate signiﬁcant beneﬁts of each of

the applied mechanisms. The proposed architecture is

meant to serve as a general framework combining dif-

ferent optimization techniques of classiﬁcation, com-

putational cost reduction as well as combination of

different feature types (e.g. coarse-to-ﬁne processing,

classiﬁer cascades, neighborhood suppression). It is

THE COMBINATION OF HMAX AND HOGS IN AN ATTENTION GUIDED FRAMEWORK FOR OBJECT

LOCALIZATION

287

easily extendable by a more advanced classiﬁer cas-

cade (e.g. (Viola and Michael, 2001)) or a cascade of

increasingly more complex classiﬁers (e.g. (Heisele

et al., 2001)). These in turn could be combined with

efﬁcient subwindow search techniques (e.g. (Lampert

et al., 2008; An et al., 2010)). We demonstrated the

combination of two feature types. However, in the

same way the two feature types have been combined,

it can easily be extended by an arbitrary number of ad-

ditional features. We think that the presented results

encourage further investigations in this direction and

we will investigate ways of incorporating additional

features based on, for example, motion, depth clues,

color, etc.

ACKNOWLEDGEMENTS

We thank the ﬁve reviewers for their comments to im-

prove the manuscript. T.B. is supported by a scholar-

ship from the Graduate School of Mathematical Anal-

ysis of Evolution, Information, and Complexity at

Ulm University. H.N. and T.B. are supported in part

by the Transregional Collaborative Research Centre

SFB/TRR 62 “Companion-Technology for Cognitive

Technical Systems” funded by the German Research

Foundation (DFG). We greatly appreciate the compu-

tational ressources provided by the (bwGRID, 2011).

REFERENCES

Agarwal, S., Awan, A., and Roth, D. (2004a). Learning

to Detect Objects in Images via a Sparse, Part-Based

Representation. TPAMI, 26(11):1475–1490.

Agarwal, S., Awan, A., and Roth, D. (2004b). UIUC

Image Database for Car Detection download page.

http://l2r.cs.uiuc.edu/∼cogcomp/Data/Car/. [Online;

accessed 27-Mar.-2010].

Amit, Y., Geman, D., and Fan, X. (2004). A Coarse-to-

Fine Strategy for Multiclass Shape Detection. TPAMI,

26(12):1606–21.

An, S., Peursum, P., Liu, W., Venkatesh, S., and Chen,

X. (2010). Exploiting Monge Structures in Optimum

Subwindow Search. In CVPR.

bwGRID (2011). member of the German D-Grid

initiative, funded by the Ministry for Education

and Research (Bundesministerium f

ur Bildung und

Forschung) and the Ministry for Science, Research

and Arts Baden-Wuerttemberg (Ministerium f

ur Wis-

senschaft, Forschung und Kunst Baden-W

urttem-

berg). http://www.bw-grid.de. [Online; accessed 13-

Apr.-2011].

Dalal, N. and Triggs, B. (2005). Histograms of Oriented

Gradients for Human Detection. In CVPR, volume 1,

pages 886–893.

Enzweiler, M. and Gavrila, D. M. (2009). Monocu-

lar Pedestrian Detection: Survey and Experiments.

TPAMI, 31(12):2179–95.

Fan, R., Chang, K.-W., Hsieh, C.-J., Wang, X.-R., and Lin,

C.-J. (2008). LIBLINEAR: A Library for Large Lin-

ear Classiﬁcation. JMLR, 9:1871–1874.

Fradkin, D. and Muchnik, I. (2006). Support Vector Ma-

chines for Classiﬁcation. DIMACS Series in Dis-

crete Mathematics and Theoretical Computer Science,

70:13–20.

Freund, Y. and Schapire, R. E. (1997). A Decision-

Theoretic Generalization of On-Line Learning and an

Application to Boosting. Journal of Computer and

System Sciences, 55:119–139.

Fritz, M., Leibe, B., Caputo, B., and Schiele, B. (2005).

Integrating Representative and Discriminative Models

for Object Category Detection. In ICCV.

Hamker, F. H. (2005). The Emergence of Attention by

Population-based Inference and its Role in Distributed

Processing and Cognitive Control of Vision. Com-

puter Vision and Image Understanding, 100:64–106.

Heisele, B., Serre, T., Mukherjee, S., and Poggio, T. (2001).

Feature Reduction and Hierarchy of Classiﬁers for

Fast Object Detection in Video Images. In CVPR.

Jiang, X., Rosen, E., Zefﬁro, T., Vanmeter, J., Blanz, V., and

Riesenhuber, M. (2006). Evaluation of a Shape-Based

Model of Human Face Discrimination using FMRI

and Behavioral Techniques. Neuron, 50(1):159–72.

Lampert, C. H., Blaschko, M. B., and Hofmann, T. (2008).

Beyond Sliding Windows: Object Localization by Ef-

ﬁcient Subwindow Search. In CVPR, pages 1–8.

Mutch, J. and Lowe, D. G. (2008). Object Class Recogni-

tion and Localization using sparse Features with lim-

ited Receptive Fields. IJCV, 80(1):45–57.

Pedersoli, M., Gonz

alez, J., Bagdanov, A. D., and Vil-

lanueva, J. J. (2010). Recursive Coarse-to-Fine Local-

ization for fast Object Detection. In ECCV, volume 6.

Riesenhuber, M. and Poggio, T. (1999a). Are Cortical Mod-

els Really Bound by the “Binding Problem”? Neuron,

24:87–93.

Riesenhuber, M. and Poggio, T. (1999b). Hierarchical Mod-

els of Object Recognition in Cortex. Nature Neuro-

science, 2(11):1019–1025.

Schyns, P. G. and Oliva, A. (1994). From Blobs To Bound-

ary Edges: Evidence for Time- and Spatial-Scale-

Dependent Scene Recognition. Psychological Sci-

ence, 5(4):195–200.

Serre, T., Wolf, L., and Poggio, T. (2005). Object Recog-

nition with Features inspired by Visual Cortex. In

CVPR, pages 994–1000.

Viola, P. and Michael, J. (2001). Rapid Object Detection us-

ing a Boosted Cascade of Simple Features. In CVPR.

Zhu, Q., Avidan, S., Yeh, M.-C., and Cheng, K.-T. (2006).

Fast Human Detection Using a Cascade of Histograms

of Oriented Gradients. In CVPR.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

288
