SEMI-LOCAL FEATURES FOR THE CLASSIFICATION OF

SEGMENTED OBJECTS

Robert Sorschag

Institute of Software Technology and Interactive Systems, Vienna University of Technology

Favoritenstrasse 9-11, A-1040 Vienna, Austria

Keywords: Visual Features, Segmentation, Object Detection.

Abstract: Image features are usually extracted globally from whole images or locally from regions-of-interest. We

propose different approaches to extract semi-local features from segmented objects in the context of object

detection. The focus lies on the transformation of arbitrarily shaped object segments to image regions that

are suitable for the extraction of features like SIFT, Gabor wavelets, and MPEG-7 color features. In this

region transformation step, decisions arise about the used region boundary size and about modifications of

the object and its background. Amongst others, we compare uniformly colored, blurred and randomly

sampled backgrounds versus simple bounding boxes without object-background modifications. An

extensive evaluation on the Pascal VOC 2010 segmentation dataset indicates that semi-local features are

suitable for this task and that a significant difference exists between different feature extraction methods.

1 INTRODUCTION

The main research question of this work is: How to

extract state-of-the-art texture and color features best

from segmented objects to classify them? This

question is relevant because a set of object detection

approaches have been proposed where segmentation

is used as a pre-processing step (Pantofaru et al.,

2008), (Li et al, 2007), (Rabinovich et al., 2007),

(Russel et al., 2006). They outperform sliding

window approaches although almost the same

features and classification techniques are used. We

believe that customized features that are less

distracted by the object’s background can further

improve these results. The features proposed in this

work exploit this benefit. Furthermore, they are

simple and fast to compute which makes them

suitable to assist segmentation-based object

detection systems.

Generally, the detection of class-level objects in

real-world images is a challenging task for

automated systems that is far from solved. Objects

can be situated everywhere and at every size in an

image. They can be occluded and shown under all

kinds of perspective distortions or under different

lighting conditions. Moreover, intra class differences

and inter class similarities can complicate this task.

Even humans sometimes fail to distinguish between

closely related classes like bicycles and motorbikes

when only a single image with difficult examples is

shown. However, the complexity of object detection

can be reduced when a set of segmented object

hypotheses are given in the first place (Li et al.,

2007) because it is accurately known where to

search for an object.

In this work, we extract well-established image

features semi-locally from segmented objects.

Thereby, color and texture features are generated

from image regions that contain the entire object.

We use the term semi-local features because these

features are locally extracted from the image but

globally extracted from

the object. Furthermore, we

show that the use of differently prepared image

regions

facilitates the power of these features. For

Figure 1: Semi-local features.

instance, the object background is excluded and

170

Sorschag R. (2012).

SEMI-LOCAL FEATURES FOR THE CLASSIFICATION OF SEGMENTED OBJECTS.

In Proceedings of the 1st International Conference on Pattern Recognition Applications and Methods, pages 170-175

DOI: 10.5220/0003712301700175

 SciTePress

replaced by white pixels in Figure 1.

This work contributes to object detection research

with an extensive study on the suitability of semi-

local features for the classification of segmented

objects and the influence of different region

preparation techniques. The used set of image

features and dissimilarity measures should ensure

that the evaluation results are as universally valid as

possible. We do not propose a complete object

detection system with object segmentation and

classification techniques. Instead we work on

interactively generated segmentations that are

provided by the Pascal VOC challenge (Everingham

et al., 2010) and use a simple nearest neighbor

classification. In addition to this perfect

segmentation, we simulate inaccurate segmentations

for comparison.

The remainder of the paper is organized as

follows. Section 2 describes related work in the field

of object detection and segmentation. Section 3

presents semi-local features. Section 4 explains the

experiments and Section 5 draws conclusions.

2 RELATED WORK

Local features (Mikolajczyk and Schmid, 2005a) are

a part of the best practice for object detection

systems. First, these features are regularly sampled

or extracted around interest-regions (Mikolajczyk et

al., 2005b) before they are generalized to one or

more bag-of-features (BoF) per image (Van de

Sande et al., 2010), (Lazebnik et al., 2006). This

BoF approach produces fixed-length vectors for

classification. In order to locate objects within an

image, many sub-regions are then investigated with

a sliding window (Lampert et al., 2008). In addition

to BoFs, global and semi-local features have been

successfully used for related tasks, like scene

classification (Oliva and Torralba, 2006), geometric

context retrieval (Hoiem et al., 2005), and human

body detection (Dalal and Triggs, 2005).

2.1 Segmentation-based Detection

Object detection approaches that operate on

segmented objects (Pantofaru et al., 2008), (Li et al.,

2007), (Rabinovich et al., 2007), (Russel et al.,

2006) work similar to sliding window approaches

but with a heavily reduced search-space. Thus, more

powerful (and computationally more expensive)

recognition approaches can be applied. However,

this benefit is not extensively exploited so far: In

Pantofaru et al. (2008) color histograms and RCF

(regionSIFT) descriptors are extracted from the

segmented objects. Li et al. (2007), Rabinovich et al.

(2007), and Leibe et al. (2008) generate BoFs from

SIFT (Lowe, 2004), colorSIFT (Van de Sande et al.,

2010), local shape context (Leibe et al., 2008), and

gray-value patches. In Li et al. (2007) independent

BoFs are extracted from the segmented object and

its background within a bounding box as well as

semi-local HoG features (Dalal and Triggs, 2005).

Rabinovich et al. (2007) sets all background pixels

to black and extracts local features from interest-

regions that overlap with the segmented object. We

use a similar zero-masking step to generate features

with a higher weighting of the object shape.

Only Toshev et al. (2010) propose segmentation

specific features, called boundary object shape,

where the geometric relations of object boundary

edges are measured. We further explore this idea and

propose customized features for the classification of

segmented objects. To the knowledge of the authors,

no work has been proposed so far that investigates

such semi-local features for object detection.

2.2 Segmentation Approaches

Different object segmentation approaches including

Normalized Cuts (Shi and Malik, 1997), MinCuts

(Carreira and Sminchisescu, 2010), and Mean-Shift

(Comaniciu and Meer, 2002) have been used for the

object detection systems described above. A good

overview of segmentation approaches can be found

in Hoeim et al. (2011). In contrast to semantic

segmentation (Csurka and Perronnin, 2010), these

approaches work without knowledge about the

segmented objects and they are used to generate a

‘soup’ of many overlapping segmentations. Such

multi-segmentation approaches can achieve higher

object detection rates when overlapping segments

are individually classified and combined afterwards

(Li et al., 2007). All of the described object

detection systems work with unsupervised

segmentation. However, it can be useful to test

single stages of such detection systems on

interactively generated object segments that are

almost perfect (Pantofaru et al., 2008). We use this

strategy to compare different semi-local features that

are extracted from perfectly and inaccurately

segmented objects.

3 SEMI-LOCAL FEATURES

We extract and classify semi-local features from

segmented objects in following steps. First, a set of

SEMI-LOCAL FEATURES FOR THE CLASSIFICATION OF SEGMENTED OBJECTS

171

transformed image regions are prepared from every

segmented object. Next, different color and texture

features are extracted from these regions and stored

in a database. The features of each object are then

matched against the features of all other objects

using a nearest neighbor strategy with several

dissimilarity measures. At last, we evaluate the

percentage of correctly matched features for each

object class.

3.1 Region Preparation

In this work, semi-local features are extracted from

regions around segmented objects using different

object-background modifications, segment-ation

accuracies and bounding boxes. In the following,

these region preparation methods are explained and

their effects on the resulting feature properties are

discussed.

Figure 2: Region preparation techniques.

Object-background modifications: We use six

different modification techniques, shown in the

columns of Figure 2. Region 1 (leftmost column) is

equivalent to bounding boxes without segmentation.

No focus is set to specific properties of the object in

these regions. In the opposite, shape is the only

attribute left to describe in Region 6 (rightmost

column). In Region 2 and Region 3 black and white

backgrounds are used. These regions set the focus to

the object shape and its content. Region 4 keeps the

characteristics of the original background although

the object is focused and the object boundaries are

sharpened. We use Gaussian smoothing to blur the

background of these regions heavily. The Gaussian

noise of Region 5 also sets focus to the object but

with fewer weighting of the object shape. In

preliminary experiments, we have tested further

object-background modifications (e.g. object bound

expansion) but the six selected ones performed best.

Segmentation accuracy: As shown in Figure 2,

we use two different segmentation accuracies. On

the one hand, perfect segmentations are given from

the Pascal VOC dataset (Everingham et al., 2010).

The object pixels are thereby used as foreground and

all others are used as background. On the other hand,

we simulate an inaccurate segmentation using the

convex hull of all pixels that belong to a perfectly

segmented object. No holes are given in this

approach but the actual object shape is heavily

changed.

Bounding boxes: Most image features are

extracted from square image regions. However,

segmented objects are given as arbitrarily shaped

polygons or image masks, and thus we operate on

bounding boxes around such object segments. As

shown in Figure 3, we select two different bounding

boxes for each object. First, we use tight, rectangular

bounding boxes that touch the segment bounds on

all four sides. These regions are resized to squares in

a pre-processing step. Secondly, we use squared

bounding boxes that touch the object bounds only in

the larger dimension. These regions contain larger

parts of the object’s background but no additional

resize step changes the aspect ratio of these regions.

Figure 3: Bounding boxes.

3.2 Image Features

In this work, four state-of-the-art texture and color

features are used: SIFT, Gabor wavelets, MPEG-7

ColorLayout and ScalableColor. We omit to add

specific shape features because the used texture

features extracted from Region 6 (white object on

black background) already present effective shape

features. All features are computed on 64 x 64 pixel

regions.

SIFT features (Lowe, 2004) consist of 8-

dimensional orientation histograms that are

computed from the image gradients in 16 slightly

overlapping sub-regions on a 4x4 grid. The feature is

normalized to increase the robustness against color

and illumination changes. In the proposed semi-local

feature approach, we extract only one SIFT feature

from the entire object region. No interest point

detection is used in this process.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

172

Gabor wavelets (Frigo and Johnson, 2005) are

computed with a bank of orientation and scale

sensitive Gabor filters. The mean and standard

deviation of each filter output is thereby used as

features values.

MPEG-7 ColorLayout features (Manjunath et

al., 2001) present the spatial distribution of colors in

a very compact form. They cluster an image or

image region into sub-regions of 8x8 pixels and

compute the average pixel value for each of them.

Finally, the first low frequency coefficients of a

discrete cosine transform are selected.

MPEG-7 ScalableColor features (Manjunath et

al., 2001) are computed from a quantized HSV color

histogram. A scalable binary representation is then

generated by indexing the probability values of each

histogram bin before a discrete Haar transformation

is applied. The resulting feature is scale invariant.

3.3 Classification

We compute the nearest neighbor for segmented

objects using all described region preparation

techniques and feature types independently.

Thereby, each segmented query object is matched

against all segmented objects in the dataset that do

not stem from the same image as the query object.

The object class of the nearest neighbor is then used

to classify a query object. We perform this nearest

neighbor classification with following dissimilarity

measures to get as general findings as possible.

 Minkowski family distances: L1, Euclidian, and

Fractional distance

 Cosine function based dissimilarity

 Canberra metric

 Jeffrey divergence

 Chi-Square statistics

These measures have been chosen according to

their high performance for image retrieval with

global features in Liu et al. (2008) where further

information about these measures can be found. We

believe that more sophisticated classification

approaches can be used to achieve better results, but

it is out of the scope of this work to identify the best

classification strategies. Instead, we try to perform a

fair comparison between the proposed feature

extraction techniques.

4 EVALUATION

In the experiments of this work, we used two

different evaluation strategies. On the one hand, the

recall of correctly classified objects is computed for

each object class and for all classes combined. On

the other hand, we perform an additional k-nearest

neighbor classification to evaluate the percentage of

query objects with at least one correct match in the

top k entries (k = 1-10).

4.1 Dataset

We used the open Pascal VOC 2010 segmentation

dataset (Everingham et al., 2010) for experiments. In

this dataset, 20 different object classes (see x-axis of

Figure 4) are perfectly segmented in 1928 Flickr

images. The ground-truth contains a total number of

4203 objects whereby several object classes occur

more often than other ones. For instance, 928

persons and 108 dinning tables are given. All images

are provided with jpg encoding and a longer

dimension side of 500 pixels.

4.2 Results

The results are organized according to following

aspects: the suitability of semi-local features to

classify segmented objects and the role of region

preparation, segmentation accuracy, used image

feature types, and dissimilarity measures. Figure 4

and Table 1 are used to illuminate these points. Both

show the achieved recall of nearest neighbor

classification for Jeffrey divergence on squared

bounding boxes.

Semi-local features: Figure 4 shows that the

classification rates of the best matching object

classes are significantly above 50% for texture

features. Furthermore, the results of all objects are

clearly above random classification (5%)

independent of the used feature type. The fact that

all 4-legged animals (sheep, horse, cow, cat, dog)

are below the average, indicates that inter class

similarities decrease their classification. As shown in

Table 1, the highest overall classification rate of

46,5% was achieved with SIFT features from

perfectly segmented Region 6. Moreover, 80% of all

objects have at least one correct match within the

first 10 retrieved objects for the same configuration.

These results clearly indicate that semi-local features

are able to facilitate the classification of accurately

segmented objects.

SEMI-LOCAL FEATURES FOR THE CLASSIFICATION OF SEGMENTED OBJECTS

173

Figure 4: Classification results per object class for perfect

segmentations and square bounding boxes. For each

feature type we give the recall of the best performing

region.

Region preparation: Table 1 shows that texture

features achieved the best results on Region 6 (white

foreground on black background) where only shape

information is given. This is also true for most

object classes. MPEG-7 color descriptors generally

perform best with original objects on uniformly

colored background (Regions 2 and 3). These

regions are also the best choice for texture features

when no accurate segmentation is given. At the first

glance, white background outperforms black

background on the given dataset but the results of k-

nearest neighbour matching did not verify this

assumption. Moreover, square bounding boxes

always achieved better results than rectangle

bounding boxes for SIFT and MPEG-7 features by

an average increase of 2%. This indicates that the

effect of changing the object’s aspect ratio is worse

than using a larger amount of background. However,

for Gabor wavelets no significant changes have been

measured between square bounding boxes and

rectangle ones.

Segmentation accuracy: In order to simulate

inaccurate segmentations from the given test set, we

used the convex hull around perfectly segmented

objects. Table 1 shows the classification results of

perfectly and inaccurately segmented objects. These

results indicate that accurate segmentation can

improve the classification significantly (up to

+24,5%) when the region is prepared appropriately.

In contrast, only smaller improvements of about 2%

are achieved between unmodified regions (Region 1)

and modified ones for inaccurate segmentation. Only

the results of Gabor wavelets improved from 20,5%

25.3% and 24.8% for uniformly colored back-

grounds. Region 6 performs worse than all other

Table 1: Overall results (recall) for square bounding

boxes.

R.1 R.2 R.3 R.

R.5 R.6

Perfect Seg

SIFT 25,0 38,3 40,4 32,0 29,8 46,5

GW 20,5 37,2 39,9 21,0 31,5 45,0

CL 15,4 22,4 23,6 19,6 15,0 28,7

SC 16,4 21,8 21,4 21,6 16,5 -

Inacc. Seg.

SIFT 25,0 27,2 27,5 22,5 27,2 12,1

GW 20,5 25,3 24,8 19,1 25,1 10,8

CL 15,4 16,8 18,6 17,9 15,2 15,1

SC 16,4 16,5 16,8 16,5 15,8 -

regions for inaccurate segmentation because these

regions only contain very rough object contours, as

shown in Figure 2.

Feature types: The performance of SIFT and

Gabor wavelets is similar for both segmentation

accuracies and all regions except Region 1 and

Region 4 where the background is left unmodified

and blurred, respectively. Gabor wavelets perform

slightly better on rectangular bounding boxes while

SIFT achieves better results on square regions.

MPEG-7 ColorLayout and ScalableColor features

perform worse than texture features for the given

task. Although Figure 4 indicates that ColorLayout

outperforms ScalableColor this is only true because

the best performing region preparation approach

(Region 6) is not applicable for pure color features,

like ScalableColor, where no spatial information is

used.

Dissimilarity measures: The difference bet-

ween the best and the worst dissimilarity measure

for all features is about 3-5%. For instance, the

results of SIFT features for Region 6 on perfect

segmentations lie between 46,5% for the best

(Jeffrey divergence) and 42,4% for the worst mea-

sure (Canberra metric). The highest variations are

caused by MPEG-7 ScalableColor features. It seems

that the ranking of dissimilarity measures does not

depend on the used region preparation technique

because the results of all measures are similarly

ordered for all techniques. The best dissimilarity

measure for all features was Jeffrey divergence

followed by Chi-Squared statistics. The worst

measure was Fractional distance for all features

followed by Canberra metric for texture features. L1

metric performed best of the Minkowski family

measures, especially for texture features where the

difference to Euclidian distance was above 2,5%.

5 CONCLUSIONS

We have proposed semi-local features for the

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

174

classification of segmented but unknown objects. In

this approach, state-of-the-art texture and color

features are extracted from regions that cover the

entire object with and without background-

modifications. Results of an extensive evaluation

indicate that the proposed approach offers the

opportunity to improve the task of object class

detection in combination with efficient segmentation

approaches. The experiments of this work

investigated perfect segmentations as well as

inaccurate ones. The classification was done with a

nearest neighbor matching strategy and different

dissimilarity measures to keep the evaluation as

simple and universally valid as possible.

In the evaluation, we have first shown that it

does matter how the regions of segmented objects

are prepared for semi-local feature extraction.

Regions where the object and its background are

modified can improve the overall classification rate

significantly compared to unmodified regions,

especially for accurate segmentations. Secondly,

square bounding boxes achieves better results than

tight, rectangular bounding boxes. Thirdly, texture

features perform better than color features and

improvements of a few percent can be achieved

when the right dissimilarity measures are chosen.

The Jeffrey divergence and Chi-Square correlation

performed best for all feature types and region

preparation techniques. We conclude that semi-local

features are good candidates to improve object

detection systems due to their simplicity and the

promising results in this work. Furthermore, we plan

to investigate semi-local features in an integrated

object detection system to verify this assumption.

ACKNOWLEDGEMENTS

The author would like to thank Horst Eidenberger

for his feedback and support. The research leading to

this publication has received funding from the

Austrian FIT-IT project ‘IV-ART – Intelligent

Video Annotation and Retrieval Techniques’.

REFERENCES

Carreira, J., Sminchisescu, C., 2010. Constrained

parametric min cuts for automatic object

segmentation. CVPR.

Comaniciu, D., Meer, P., 2002. Mean shift: A robust

approach toward feature space analysis. PAMI.

Csurka, G., Perronnin, F., 2010. An efficient approach to

semantic segmentation. IJCV.

Dalal, N., Triggs, B., 2005. Histograms of oriented

gradients for human detection. CVPR.

Everingham, M., Van Gool, L., Williams, C., Winn, J.,

Zisserman, A., 2010. The PASCAL Visual Object

Classes (VOC) challenge. IJCV.

Frigo, M., Johnson, S., 2005. The design and implement-

tation of FFTW3. Proc. Program Generation, Optimi-

zation, and Platform Adaptation

Hoiem, D., Efros, A., Hebert, M., 2005. Geometric

context from a single image. ICCV.

Hoiem, D., Stein, A., Efros, A., Hebert, M., 2011.

Recovering occlusion boundaries. IJCV.

Lampert, C., Blaschko, M., Hofmann, T., 2008. Beyond

sliding windows: Object localization by efficient

subwindow search. CVPR.

Lazebnik, S., Schmid, C., Ponce, J., 2006. Beyond bags of

features: Spatial pyramid matching for recognizing

natural scene categories. CVPR.

Leibe, B., Leonardis, A., Schiele, B., 2008. Robust object

detection with interleaved categorization and

segmentation. IJCV.

Li, F., Carreira, J., Sminchisescu, C., 2007. Object

recognition as ranking holistic figure-ground

hypotheses. CVPR.

Liu, H., Song, D., Rüger, S., Hu, S., Uren, V., 2008.

Comparing dissimilarity measures for content-based

image retrieval. AIRS.

Lowe, D., 2004. Distinctive image features from scale-

invariant keypoints. IJCV.

Manjunath, B., Ohm, J.-R., Vasudevan, V., Yamada, A.,

2001. Color and texture descriptors. Trans. on Circuits

and Systems for Video Technology.

Mikolajczyk K., Schmid, C., 2005a. A performance

evaluation of local descriptors. Trans. PAMI.

Mikolajczyk, K., Tuytelaars, T., Schmid, C., Zisserman,

A., Matas, J., Schaffalitzky, F., Kadir, T., Van Gool,

L., 2005b. A comparison of affine region detectors.

IJCV.

Oliva, A., Torralba, A., 2006. Building the GIST of a

Scene: The Role of Global Image Features in

Recognition, Visual Perception, Progress in Brain

Research.

Pantofaru, C., Schmid C., Hebert, M., 2008. Object reco-

gnition by integrating multiple image segmentations.

ECCV

Rabinovich A., Vedaldi, A., Belongie, S., 2007. Does ima-

ge segmentation improve object categorization? Tech.

Rep. CS2007-090.

Russell, B., Freeman, W., Efros, A., Sivic, J., Zisserman,

A., 2006. Using multiple segmentations to discover

objects and their extent in image collections. CVPR.

Shi, J., Malik, J., 1997. Normalized cuts and image

segmentation. CVPR.

Toshev, A., Taskar, B., Daniilidis, K, 2010. Object

detection via boundary structure segmentation. CVPR.

Van de Sande, K., Gevers, T., Snoek, C., 2010. Evaluating

color descriptors for object and scene recognition.

PAMI.

SEMI-LOCAL FEATURES FOR THE CLASSIFICATION OF SEGMENTED OBJECTS

175
