A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION

ESTIMATORS FOR FEATURE SELECTION

Gauthier Doquire and Michel Verleysen

Machine Learning Group - ICTEAM, Universit

e catholique de Louvain,

Place du Levant 3, 1348 Louvain-la-Neuve, Belgium

Keywords:

Mutual information estimation, Feature selection, Nearest neighbors.

Abstract:

Mutual Information estimation is an important task for many data mining and machine learning applications.

In particular, many feature selection algorithms make use of the mutual information criterion and could thus

beneﬁt greatly from a reliable way to estimate this criterion. More precisely, the multivariate mutual informa-

tion (computed between multivariate random variables) can naturally be combined with very popular search

procedure such as the greedy forward to build a subset of the most relevant features. Estimating the mutual

information (especially through density functions estimations) between high-dimensional variables is however

a hard task in practice, due to the limited number of available data points for real-world problems. This paper

compares different popular mutual information estimators and shows how a nearest neighbors-based estimator

largely outperforms its competitors when used with high-dimensional data.

1 INTRODUCTION

The ways to acquire and store data increase every day;

machine learning practitioners often have to deal with

databases of very large dimension (containing data

described by a lot of features). When considering a

prediction task, all the features are not equally rel-

evant to predict the desired output while some can

be redundant; irrelevant or redundant features can in-

crease the variance of the prediction models with-

out reducing their bias while most of distance-based

methods are quite sensitive to useless features. More

generally, learning with high-dimensional data is a

hard task due to the problems related to the curse of

dimensionality (Bellman, 1961).

Two main approaches exist to reduce the dimen-

sionality of a data set. One solution is to project the

data on a space of smaller dimension. Projections can

be very effective but do not preserve the original fea-

tures; this is a major drawback in many industrial or

medical applications where interpretability is primor-

dial. On the contrary, feature selection, by trying to

ﬁnd a subset of features with the largest prediction

power, does allow such an interpretability.

Even if many ways of selecting features can be

thought of, this paper focuses on ﬁlters. Filters are in-

dependent from the model used for regression or clas-

siﬁcation and thus do not require building any predic-

tion model (including time-consuming learning and

potential meta-parameters to tune by resampling

methods). They are faster than wrappers which try

to ﬁnd the best subset of features for a speciﬁc model

through extensive simulations. Filters are often based

on an information-theoretic criterion measuring the

quality of a feature subset and a search procedure

to ﬁnd the subset of features maximising this crite-

rion; the mutual information (MI) criterion (Shannon,

1948) has proven to be very efﬁcient for feature selec-

tion and has been used successfully for this task since

many years (see e.g. (Rossi et al., 2007)).

As it is not possible in practice to evaluate the MI

between all the 2

f −1

( f being the initial number of

features) possible feature subsets and the output vec-

tor when f is large, incremental greedy procedures

are frequently used, whose most popular ones are for-

ward, backward or forward/backward. Such proce-

dures are said to be multivariate, in the sense that

they require the evaluation of the MI (or of another

chosen criterion) directly between a set of features

and the output vector. These methods have the ad-

vantage over bivariate ones such as ranking that they

are able to detect subsets of features which are jointly

relevant or redundant. Consider the XOR problem

as a simple example; it consists in two features and

an output scalar which is zero if both features have

the same value and one otherwise. Obviously, indi-

176

Doquire G. and Verleysen M. (2012).

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION.

In Proceedings of the 1st International Conference on Pattern Recognition Applications and Methods, pages 176-185

DOI: 10.5220/0003726101760185

 SciTePress

vidually each feature does not carry any information

about the outptut; univariate procedures will never be

able to detect them as relevant. However, when com-

bined, the two features completely determine the out-

put; when one is selected, a multivariate procedure

will select the other one as relevant. A detailed intro-

duction to the feature selection problem can be found

in (Guyon and Elisseeff, 2003).

As will be seen, the MI generally cannot be com-

puted analytically but has to be estimated from the

data set. Even if this task has been widely studied, it

remains very challenging for high-dimensional vec-

tors. In this paper, it is shown how a MI estima-

tor based on the principle of nearest neighbors (NN)

outperforms traditional MI estimators with respect to

three feature selection related criteria. This study is,

to the best of our knowledge, the ﬁrst one to compare

MI estimators in such a context.

The rest of the paper is organized as follows. Sec-

tion 2 brieﬂy introduces the MI criterion and de-

scribes ﬁve of the most popular MI estimators. Sec-

tion 3 presents the experiments carried out to com-

pare these estimators and shows the results obtained

on artiﬁcial and real-world data sets. Discussions and

conclusions are given in Section 4.

2 MUTUAL INFORMATION

This section recalls basic notions about the MI and

brieﬂy presents the estimators used for comparison.

2.1 Deﬁnitions

Mutual information (Shannon, 1948) is a symmetric

measure of the dependence between two (groups of)

random variables X and Y , assumed to be continuous

in this paper. Its interest for feature selection comes

mainly from the fact that MI is able to detect non-

linear relationships between variables, whereas, as an

example, it is not the case for the popular correla-

tion coefﬁcient which is limited to linear dependen-

cies. Moreover, the MI can be naturally deﬁned for

groups of variables and is thus well-suited for multi-

variate search procedures. MI is formally deﬁned as

I(X;Y ) = H(X) + H(Y ) −H(X,Y ) (1)

where H(X ) is the entropy of X, deﬁned for a contin-

uous random variable as:

H(X ) = −

(ζ

)log f

(ζ

) dζ

. (2)

In this last equation, f

is the probability density

function (pdf) of X. The MI can then be rewritten as

I(X;Y ) =

Z Z

X,Y

(ζ

,ζ

)log

X,Y

(ζ

,ζ

)

(ζ

) f

(ζ

)

dζ

(3)

In practice, neither f

, f

nor f

X,Y

are known for

real-world problems; the MI has thus to be estimated.

2.2 Estimation

Plenty of methods have been proposed in the litera-

ture to estimate the MI. The great majority of them

starts by estimating the unknown pdf before plugging

these results into Equation (1) or an equivalent expres-

sion. However, the dimension of X increases at each

step of a forward feature selection procedure (or is al-

ready very high at the beginning of a backward proce-

dure) and most of these methods suffer dramatically

from the curse of dimensionality (Bellman, 1961); in-

deed they require an exponentially growing number

of samples as the dimension of X grows while the

number of available samples is in practice often very

limited. Such MI estimations do not thus seem well

suited for feature selection ends. A NN-based MI es-

timator (Kraskov et al., 2004) avoiding the pdf esti-

mation step has been used successfully in a feature

selection context (Francois et al., 2007; Rossi et al.,

2007). In the rest of this section, this estimator and

four popular other ones are introduced.

2.2.1 The Basic Histogram

The histogram is one of the oldest and simplest ways

to estimate a pdf. The basic idea is to divide the obser-

vation, prediction and joint spaces into non overlap-

ping bins of ﬁxed size and then to count the number of

points falling in each of the bins. The entropy of X, Y

and (X,Y ) can be estimated using the discretized ver-

sion of (2) and the estimation of the MI then naturally

follows from (1). If histograms with bins of the same

ﬁxed size are considered, as it is the case in this paper,

the size of the bins needs to be determined. Here, the

approach by Sturges (Sturges, 1926) will be followed:

the number k of bins will be

1 + log

(N)

, where N

is the number of samples in the data set; other ap-

proaches could also be thought of (Scott, 1979).

2.2.2 The Kernel Estimator

The basic histogram suffers from many drawbacks.

Among others, it is sensitive to the choice of the ori-

gin and to the size of the bins. In order to avoid

sharp steps between the bins (and hence discontinu-

ities), one can use the kernel density estimator (KDE)

given by:

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION

177

(x) =

∑

i=1

x −x

), (4)

where N is the number of observations in X, h is the

window width and K is the kernel function required to

integrate to one, leading

f to be a probability density

(Parzen, 1962); x

denotes the i

observation of the

data set X. One possible choice for K is the Gaussian

kernel, leading to the following density estimator:

f (x) =

√

2π

∑

i=1

exp(

−(x −x

)

). (5)

In practice, the choice of the bandwidth h is funda-

mental. In this paper, the approach by Silverman

(Silverman, 1986) using a rule of thumb will be fol-

lowed. It is often used as a good trade-off between

performance and computational burden. The idea is

to choose the width minimizing the asymptotic mean

integrated square error (AMISE) between the estima-

tion and the true density, assuming the underlying dis-

tribution is Gaussian. The resulting width is:

rot

≈ σ(

f + 2

)

1/( f +4)

−1/( f +4)

(6)

where f is again the dimensionality of X. A large

overview of different ways to select the kernel band-

width is given in (Turlach, 1993).

2.2.3 The B-splines Estimator

Another generalisation of the simple binning ap-

proach is given by the use of B-splines functions

(Daub et al., 2004). The idea is again to ﬁrst dis-

cretize the X, Y and (X,Y ) spaces. However, in this

approach, the data points are allowed to be assigned

to more than one bin a

simultaneously in order to

prevent the positions of the borders of the bins from

affecting too much the estimation. The weights with

which each point belongs to a bin are given by the B-

spline functions B

i,k

(k being the spline order). With-

out getting too much into details, B-splines are recur-

sively deﬁned as:

i,1

(x) :=

(

1 if t

≤ x ≤t

i+1

0 otherwise

i,k

(x) := B

i,k−1

(x)

x −t

i+k−1

−t

+ B

i+1,k−1

(x)

i+k

−x

i+k

−t

i+1

(7)

where t is a knot vector deﬁned for a number of

bins M and a spline order k = 1...M −1 as:











0 if i < k

i −k + 1 if k ≤i ≤M −1

M −1 −k + 2 if i > M −1

(8)

To estimate the density

, M

weights B

i,k

) are

determined for each datapoint x

(where M

is the

number of bins in the X space). As the sum of the

weights corresponding to each data point is 1, the

sum of the mean values of each bin is also 1. The

weights can thus be seen as the probability of each

bin (p(a

) =

∑

u=1

i,k

)) and the entropy of the

distribution can be estimated. The process is repeated

for the Y space and for the joint (X,Y ) space to esti-

mate the MI. The notion of B-splines can be extended

to the multivariate case from univariate splines by the

tensor produt construct. As an example, in two di-

mensions, the probability of a bin a

i, j

is given by

p(a

i, j

) =

∑

u=1

i,k

) ×B

j,k

) where x denotes

the ﬁrst variable and y the second one.

2.2.4 The Adaptive Partition of the Observation

Space

Darbellay and Vajda proved (Darbellay and Vajda,

1999) that the MI can be approximated arbitrar-

ily closely in probability by calculating relative fre-

quencies on appropriate partitions. More precisely,

they use an adaptive partitioning of the observation

scheme, different from the traditional product parti-

tions, to take into account the fact that with such basic

partitions, much of the bins are not used to estimate

the MI and can be replaced by fewer bins; they proved

the weak consistency of the proposed method. Math-

ematical details can be found in (Darbellay and Vajda,

1999). In the rest of this paper, this methodology will

be denoted adaptive histogram.

2.2.5 The Nearest Neighbors-based or Kraskov

Estimator

Since the hardest part when estimating the MI is the

estimation of the underlying probability densities, an-

other alternative is simply not to estimate densities

and therefore directly estimating the MI by using NN

statistics. The intuitive idea behind Kraskov’s estima-

tor (Kraskov et al., 2004) is that if the neighbors of

a speciﬁc observation in the X space correspond to

the same neighbors in the Y space, there must be a

strong relationship between X and Y. More formally,

the estimator is based on the Kozachenko-Leonenko

estimator of entropy deﬁned as:

H(X) = −ψ(K) + ψ(n)+ log(c

) +

∑

n=1

log(ε

(N,K))

(9)

where ψ is the digamma function, N the number

of samples in X, d the dimensionality of these sam-

ples, c

the volume of a d-dimensional unitary ball

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

178

and ε

(n,K), twice the distance (usually chisen as the

Euclidean distance) from the n

observation in X to

its K

NN. Two slightly different estimators are then

derived whose most popular one is:

I(X;Y ) = ψ(N) + ψ(K) −

−

∑

i=1

(ψ(τ

) + ψ(τ

))

(10)

where τ

is the number of points whose distance

from x

is not greater than 0.5 × ε(n, K) = 0.5 ×

max(ε

(n,K),ε

(n,K)). By avoiding the evaluation

of high-dimensional pdf, the hope is to reach better re-

sults than with the previously introduced estimators.

It is also important to note that other NN based

density estimators have been proposed in the littera-

ture, whose recent examples are (Wang et al., 2009;

Li et al., 2011). However, as they are less popular

than (Kraskov et al., 2004) for feature selection, they

are not used in the present comparison.

3 EXPERIMENTS

Three sets of experiments are carried out in this sec-

tion. The objective is to assess the interest of the dif-

ferent estimators for incremental feature selection al-

gorithms. The criteria of comparison and the exper-

imental setup are thus very different from the ones

used in previous papers only focused on MI estima-

tion (see e.g. (Walters-Williams and Li, 2009)). First,

a suitable estimator should be accurate, i.e. it should

reﬂect the true dependency between groups of fea-

tures and increases (resp. decreases) when the depen-

dance between groups of features increases (resp. de-

creases). Then it should also be able to detect uninfor-

mative features and return a value close to zero when

two independent groups of features are given. Even-

tually, a good estimator should be quite independent

from the value of its parameters or some fast heuris-

tics to ﬁx them should be available.

From a practical point of view, the implementa-

tion by Alexander Ihler has been used for KDE

. For

the NN-based estimator, the parameter K is set to 6

unless stated otherwise. For the B-splines estimator,

the degree of the splines is set to 3 and the number of

bins to 3. These values correspond to those advised in

the respective original papers (Kraskov et al., 2004;

Daub et al., 2004).

3.1 Accuracy of the Estimators

The ﬁrst set of experiments consists in comparing the

http://www.ics.uci.edu/ ihler/code /

precision of the MI estimators as the dimension of

the data set increases. To this end, they will be used

to estimate the MI between n correlated Gaussians

...X

with zero mean and unit variance. This way,

the experimental results can be compared with exact

analytical expressions as the MI for n such Gaussians

is given by (Darbellay and Vajda, 1999):

I(X

...X

) = −0.5 ×log[det(σ)] (11)

where σ is the covariance matrix.

All the correlation coefﬁcients are set to the same

value r which will be chosen to be 0.1 and 0.9. The

estimation is repeated 100 times on randomly gen-

erated datasets of 1000 instances and the results are

shown for n = 1...9. Even if this can be seen as a rela-

tively small number of dimensions, there are practical

limitations when using splines and histogram-based

estimators in higher dimensions. Indeed the gener-

alization of the B-splines-based estimator to handle

vectors of dimension d involves the tensor product of

d univariate B-splines, a vector of size M

, where M

is the number of bins. Histogram-based methods are

also limited in the same way since they require the

storage of the value of k

bins, where k is the num-

ber of bins per dimension. Nearest neighbors-based

methods are not affected by this kind of problems and

have only a less restrictive limitation regarding the

number n of data points since they require the cal-

culation of O(n

) pairwise distances. As will be seen,

the small number of dimensions used in the experi-

ments is sufﬁcient to underline the drawbacks and ad-

vantages of the compared estimators.

Figure 1 shows that, as far as the precision is con-

cerned, Kraskov et al.’s estimator largely outperforms

its competitors for the two values of r (r = 0.1 and

r = 0.9). The estimated values are always very close

to the true ones and show small variations along the

100 repetitions. The adaptive histogram provides on

average accurate estimations up to dimension 8 and

6 for r = 0.1 and r = 0.9 respectively, with however

very strong ﬂuctuations observed accross the experi-

ments. The B-spline estimator is also extremely ac-

curate for the ﬁve ﬁrst dimensions and r = 0.1. For

r = 0.9 (and thus for higher values of MI), it severely

underestimates the true values while the aspect of the

true MI curve is preserved. This cannot be consid-

ered as a major drawback in a feature selection con-

text where we are interested by the comparison of MI

between groups of features. The results achieved by

the kernel density estimator are very poor as soon as

n exceeds 1, largely overestimating the true values for

r = 0.1 while immediately decreasing for r = 0.9. Fi-

nally, as one could expect, the basic histogram pro-

duces the worst results; the estimated values are too

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION

179

r=0.1 r=0.9

Figure 1: Boxplots of the approximation of the MI for correlated Gaussian vectors by several estimators: the basic histogram

(green), a KDE (red), an adaptive histogram (cyan), a NN-based estimator (black) and a B-splines estimator (magenta). The

solid line represents the true MI.

high to be reported on Figure 1 for r = 0.1 when the

dimension of the the data exceeds two.

3.2 Mutual Information between

Independent Variables

In a feature selection context, a suitable estimator

should assign a value close to zero to the MI between

independent (groups of) variables. More precisely,

one has to make sure that a large (greatly above zero)

value of MI is not the result of a weakness or a bias

of the estimator but does correspond to a dependence

between the variables. Moreover, as the MI is not

bounded to a known interval (as [−1,1] for the corre-

lation coefﬁcient), the relevance of each feature sub-

set cannot be directly assessed based only on the value

of the MI. A solution is to establish the relevance of

a feature subset by looking if the MI between this

subset and the outptut vector is signiﬁcantly larger

than the MI between this subset and a randomly per-

muted version of the output. It is thus important in

practice to study how the MI between the actual data

points and a randomly permuted objective vector is

estimated. In theory, the MI estimated in this way

should be 0 as no more relationship exists between

the observations and the permuted outputs.

Experiments have been carried out on one artiﬁ-

cial and two real-world data sets. The artiﬁcial prob-

lem is derived from Friedman (Friedman, 1991) and is

often used as a benchmark for feature selection algo-

rithms. It consists of 10 input variables X

uniformly

distributed over [0, 1] and an output variable Y given

by Y = 10 sin(X

)+20(X

−0.5)

+10X

+5X

+ε

where ε is a Gaussian noise with zero mean and unit

variance. The sample size is 1000 and 100 data sets

are randomly generated. As can be deducted easily,

only the ﬁve ﬁrst features are relevant to predict Y .

The ﬁrst real data set is the well known Delve cen-

sus data set, available from the University of Toronto

for which the 2048 ﬁrst entries of the training set are

kept. The dimension of the data set is 104. The sec-

ond real data set is the Nitrogen data set

, containing

only 141 spectra discretized at 1050 different wave-

lengths. The goal is to predict the Nitrogen content of

a grass sample. As pre-processing, each spectrum is

represented using its coordinates in a B-splines basis,

in order to reduce the amount of features to a reason-

able number of 105 ((Rossi et al., 2005)). For each

data set, a forward feature selection procedure using

the NN-based estimator is conducted (since it per-

formed the best in the previous section) and is halted

when nine features have been selected. The MI is then

estimated as well as the MI with the permuted output

for 100 random permutations of the output and for

each of the nine subsets of features of increasing di-

mension. The performance of the estimators is thus

compared on the same sets of relevant features.

In Figure 2, it can be seen that for the three prob-

lems, the NN-based estimator used with permuted

output produces values very close to 0, even when

working with few samples as for the Nitrogen data set

(the variance is however larger in this case). This sat-

isfactory observation is in good agreement with pre-

vious results found in (Kraskov et al., 2004) where

the authors conjectured the fact that equation (10) is

exact for independent variables, without proof of this

result. Let us also notice two undesirable facts about

the estimator. First it sometimes produces slightly

negative values. Even if this has no theoretical jus-

tiﬁcation (Cover and Thomas, 1991), this can easily

http://www.idrc-chambersburg.org/index.html

http://kerouac.pharm.uky.edu/asrg/cnirs/

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

180

(a) (b) (c)

Figure 2: Estimated MI between a group of features and the output (circles) and boxplots of the estimated MI between the

same features and a permuted output for the NN-based estimator: (a) Delve dataset, (b) Nitrogen dataset , (c) Artiﬁcial dataset.

(a) (b) (c)

Figure 3: Estimated MI between a group of features and the output (circles) and boxplots of the estimated MI between the

same features and a permuted output for the B-splines density estimator: (a) Delve dataset, (b) Nitrogen dataset , (c) Artiﬁcial

dataset.

be dealt with in practice, by setting negative values

to 0. Secondly, it can be seen that the MI decreases

after the addition of some variables. Once again, this

phenomenon is not theoretically founded (Cover and

Thomas, 1991) even if it has often been used as a stop-

ping criterion in greedy feature selection algorithms.

The B-splines estimator (Figure 3) also performs

well on the Delve data set. However, the results on

the two other data sets contrast with this behaviour;

as far as the artiﬁcial data set is concerned, the eight

and nine ﬁrst features have a higher MI with the per-

muted output than the ﬁrst three with the actual out-

put. This can also be understood as the eight and nine

ﬁrst permuted features having a higher MI with the

output than the three ﬁrst original features have. This

is of course a very undesirable fact in the context of

feature selection. Indeed, it is obvious that permuted

features do not carry any information about Y while

the ﬁrst three original ones actually do.

The adaptative histogram (Figure 4), produces

highly negative values for the Delve and the Nitro-

gen data sets. Even if the same trick as the one used

for the Kraskov estimator could also be applied here

(setting the negative values to 0), things does not be-

have so well. First, the absolute values of the negative

results are very large, traducing instabilities of the al-

gorithm as the dimension increases. Next, for the Ni-

trogen data set, the ﬁrst third and fourth features have

a higher MI with the permuted output than the ﬁrst

eight and nine have with the actual output. For the

artiﬁcial data set, the ﬁrst nine features have a higher

MI with the permuted output than the ﬁrst six have

with the true output.

The KDE (Figure 5) also returns values highly

above 0 with the permuted output; on the artiﬁcial

data set, the MI between the features and the actual

or the permuted output becomes equal as the dimen-

sion increases. However, no confusion is possible for

the two real-world data sets.

Eventually, the histogram (Figure 7) shows dra-

matically incorrect results, with almost equal values

for the MI between any subset of features and the per-

muted or the actual output; things are however better

for the Delve Census data set.

3.3 Choice of the Parameters

The last experiment is about the choice of the param-

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION

181

(a) (b) (c)

Figure 4: Estimated MI between a group of features and the output (circles) and boxplots of the estimated MI between

the same features and a permuted output for the adaptive histogram estimator: (a) Delve dataset, (b) Nitrogen dataset , (c)

Artiﬁcial dataset.

(a) (b) (c)

Figure 5: Estimated MI between a group of features and the output (circles) and boxplots of the estimated MI between the

same features and a permuted output for the kernel density estimator: (a) Delve dataset, (b) Nitrogen dataset , (c) Artiﬁcial

dataset.

Figure 6: Estimated MI with the kernel density estimator for different values of the kernel width: (a) Delve dataset, (b)

Nitrogen dataset , (c) Artiﬁcial dataset.

eters in the estimators. As already mentioned, the ba-

sic histogram, the KDE, the B-splines approach and

the NN-based estimator all have at least one parame-

ter to ﬁx, which can be fundamental for the quality of

the estimations. Since the performances of the basic

histogram in high-dimensional spaces are obviously

dramatic, this estimator is not studied in more details.

To compare the different estimators, the same data

sets are used as in the previous section and the MI

estimations are shown for dimension 2 to 5. Once

again this limitation is due to the time and space-

consuming generalization of the B-splines approach

in high-dimensional spaces. Moreover, the choice of

the parameter is less related to feature selection.

3.3.1 The Kernel Density Estimator

For the KDE, the parameter to be ﬁxed is the width

of the kernel. As an alternative to the rule of thumb

used so far (see Equation (6)), two other methods

are considered. The ﬁrst one is the very popular

Least Squares Cross-Validation (LSCV) introduced

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

182

(a) (b) (c)

Figure 7: Estimated MI between a group of features and the output (circles) and boxplots of the estimated MI between the

same features and a permuted output for the histogram based estimator: (a) Delve dataset, (b) Nitrogen dataset , (c) Artiﬁcial

dataset.

by Rudemo and Bowman (Bowman, 1984) (Rudemo,

1982) whose goal is to estimate the minimizer of the

Integrated Square Error. The second one is the Plug-

In method proposed by Hall, Sheater Jones and Mar-

ron (Hall et al., 1991). Figure 6 shows the extreme

sensitivity of the KDE to the width of the kernel since

the results obtained with both bandwidth determina-

tion strategies are totally different for the three data

sets. Moreover, as illustrated in Figure 8 which shows

the estimation of the MI for correlated Gaussians and

r = 0.9, none of the methods used to set the kernel

width clearly outperforms the other ones.

3.3.2 The B-splines Estimator

Two parameters have to be determined in this ap-

proach: the degree of the splines and the number of

bins. We ﬁx the degree of the splines to three (as sug-

gested in the original paper) and only focus on the

number of bins per dimension as this parameter has

been shown to inﬂuence much more the output (Daub

et al., 2004); it will be taken between 2 and 5. Even if

these values can seem surprisingly small, only three

bins are used in (Daub et al., 2004).

The results presented in Figure 9 show that the es-

timated MI increases with the number of bins. These

conclusions are consistent with those found in (Daub

et al., 2004) for the one-dimensional case. However,

even if the estimator is extremely sensitive to the num-

ber of bins, the relative values of the MI between the

output and different groups of features is preserved,

and so is the relative signiﬁcance of the feature sub-

sets. The sensitivity of the estimator is thus not a

drawback for feature selection.

3.3.3 The Nearest Neighbors-based Algorithm

The only parameter to ﬁx in the NN-based estimator is

the number of neighbors K. Kraskov et al. suggest a

value of 6, arguing it leads to a good trade-off between

Figure 8: Estimated MI for correlated Gaussians with a ker-

nel density estimator whose kernel’s width has been deter-

mined by three different procedures.

the variance and the bias of the estimator (Kraskov

et al., 2004). Here, K is considered between 4 and 8.

Figure 10 shows very little sensitivity of the esti-

mator in terms of absolute differences between esti-

mations and thus a small sensitivity of the estimator

to the number of neighbors used. However the results

on the Delve data set indicate that even a small vari-

ation in the values of the estimated MI can lead to a

different ranking of the features subsets in terms of

relevance. As an example, in this data set, when us-

ing K = 4 or K = 5 neighbors, the subset of the ﬁve

ﬁrst features is less informative for the output than

the subset of the four ﬁrst features, while the oppo-

site conclusion (which is in theory true) can be drawn

when using 6, 7 or 8 neighbors. This is something

that must be taken care of when performing feature

selection because it could lead to the selection of irrel-

evant (or less relevant than other) features. One idea

to overcome this issue is to average the estimations

obtained within a reasonable range of values of K. In

(Gomez-Verdejo et al., 2009), this principle is applied

to feature selection using a version of the Kraskov es-

timator adapted for classiﬁcation problems. Another

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION

183

Figure 9: Estimated MI with the B-splines estimator for different values of bins per dimension: (a) Delve dataset, (b) Nitrogen

dataset , (c) Artiﬁcial dataset.

Figure 10: Estimated MI with the NN-based estimator for different values of the parameter k: (a) Delve dataset, (b) Nitrogen

dataset , (c) Artiﬁcial dataset.

idea is to choose the value of K using the permutation

test and resampling techniques (Francois et al., 2007).

4 CONCLUSIONS AND

DISCUSSIONS

In this paper several popular approaches to the estima-

tion of multi-dimensional MI are compared through

three important criteria for feature selection: the ac-

curacy, the consistency with an independence hypoth-

esis and the sensitivity to the values of the parame-

ter(s). The conclusion is the superiority of the NN-

based algorithm which is by far the most accurate and

the most consistent with an independent hypothesis

(i.e. it returns values very close to 0 when estimating

the MI between independent variables) on the three

data sets used for comparison. The B-splines esti-

mator presents interesting properties as well but can

hardly be used when dimension becomes higher than

9 or 10, because of the exponential number of values

to compute; the NN-based estimator is not affected by

this major drawback, since it only requires the com-

putation of the distances between each pair of points

of the data set in the input, output and joint input-

output spaces. By avoiding the hazardous evaluation

of high-dimensional pdf, it is able to produce very ro-

bust results as the dimension of the data increases. It

is also the less sensitive to the value of its single pa-

rameter, the number of neighbors K. However, as it

has been seen, the choice of this parameter cannot be

made at random since slight variations in the estima-

tion of the MI can lead to a different ranking of the

features subset relevance. Two approaches have been

reported to deal with this issue, both producing satis-

factory results. Being aware of all these facts, it thus

appears to be a good choice to use the Kraskov esti-

mator, or its counterpart for classiﬁcation, to achieve

MI-based multivariate ﬁlter feature selection.

ACKNOWLEDGEMENTS

G. Doquire is funded by a grant from the Belgian

F.R.I.A.

REFERENCES

Bellman, R. E. (1961). Adaptive control processes - A

guided tour. Princeton University Press, Princeton,

New Jersey, U.S.A.

Bowman, A. W. (1984). An alternative method of cross-

validation for the smoothing of density estimates.

Biometrika, 71(2):353–360.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

184

Cover, T. M. and Thomas, J. A. (1991). Elements of Infor-

mation Theory. Wiley-Interscience.

Darbellay, G. and Vajda, I. (1999). Estimation of the in-

formation by an adaptive partitioning of the observa-

tion space. IEEE Transactions on Information Theory,

45(4):1315–1321.

Daub, C., Steuer, R., Selbig, J., and Kloska, S. (2004). Es-

timating mutual information using b-spline functions

- an improved similarity measure for analysing gene

expression data. BMC Bioinformatics, 5(1):118.

Francois, D., Rossi, F., Wertz, V., and Verleysen, M. (2007).

Resampling methods for parameter-free and robust

feature selection with mutual information. Neurocom-

puting, 70(7-9, Sp. Iss. SI):1276–1288.

Friedman, J. H. (1991). Multivariate adaptive regression

splines. The Annals of Statistics, 19(1):1–67.

Gomez-Verdejo, V., Verleysen, M., and Fleury, J. (2009).

Information-theoretic feature selection for functional

data classiﬁcation. Neurocomputing, 72:3580–3589.

Guyon, I. and Elisseeff, A. (2003). An introduction to vari-

able and feature selection. Journal of Machine Learn-

ing Research, 3:1157–1182.

Hall, P., Sheater, S. J., Jones, M. C., and Marron, J. S.

(1991). On optimal data-based bandwidth selection

in kernel density estimation. Biometrika, 78(2):263–

269.

Kraskov, A., St

ogbauer, H., and Grassberger, P. (2004).

Estimating mutual information. Phys. Rev. E,

69(6):066138.

Li, S., Mnatsakanov, R. M., and Andrew, M. E. (2011). k-

nearest neighbor based consistent entropy estimation

for hyperspherical distributions. Entropy, 13(3):650–

667.

Parzen, E. (1962). On estimation of a probability den-

sity function and mode. The Annals of Mathematical

Statistics, 33(3):1065–1076.

Rossi, F., Delannay, N., Conan-Guez, B., and Verleysen, M.

(2005). Representation of functional data in neural

networks. Neurocomputing, 64:183 – 210.

Rossi, F., Lendasse, A., Franc¸ois, D., Wertz, V., and Verley-

sen, M. (2007). Mutual information for the selection

of relevant variables in spectrometric nonlinear mod-

elling. CoRR.

Rudemo, M. (1982). Empirical choice of histograms and

kernel density estimators. Scandinavian Journal of

Statistics, 9(2):65–78.

Scott, D. W. (1979). On optimal and data-based histograms.

Biometrika, 66(3):605–610.

Shannon, C. E. (1948). A mathematical theory of com-

munication. Bell Systems Technical Journal, 27:379–

423,623–656.

Silverman, B. W. (1986). Density estimation for statistics

and data analysis. Chapman and Hall, London.

Sturges, H. A. (1926). The choice of a class inter-

val. Journal of the American Statistical Association,

21(153):65–66.

Turlach, B. A. (1993). Bandwidth selection in kernel den-

sity estimation: A review. In CORE and Institut de

Statistique, pages 23–493.

Walters-Williams, J. and Li, Y. (2009). Estimation of mu-

tual information: A survey. In RSKT ’09, pages 389–

396, Berlin, Heidelberg. Springer-Verlag.

Wang, Q., Kulkarni, S. R., and Verdu, S. (2009). Diver-

gence Estimation for Multidimensional Densities Via

k-Nearest Neighbor Distances. Information Theory,

IEEE Transactions on, 55(5):2392–2405.

A COMPARISON OF MULTIVARIATE MUTUAL INFORMATION ESTIMATORS FOR FEATURE SELECTION

185
