SEMANTIC WEB IN EEG/ERP PORTAL

Extending of Data Layer using Java Annotations

Petr Ježek and Roman Mouček

Department of Computer Science and Engineering, University of West Bohemia

Univerzitní 8, 306 14 Pilsen, Czech Republic

Keywords: Semantic web, EEG, ERP, Experiment, OWL, RDF, Object-oriented code, Mapping, Semantics,

Transformation, EEG/ERP portal.

Abstract: Because the Semantic Web uses its technologies for presenting data/metadata on the web and common

systems are based on object-oriented languages a need for suitable mapping is emerging. This paper

describes the difficulties during transformation of data layer represented by object-oriented code into the

semantic web structures (OWL, RDF). Since there is difference between semantic expressivity of these data

representations it is necessary to fill this semantic gap. Authors investigate these differences in semantics

and provide a preliminary idea to add missing semantics into the Java code using Java annotations. These

annotations are consequently processed by the proposed framework. The transformation is demonstrated

within the EEG/ERP Portal.

1 INTRODUCTION

Our research group at Department of Computer

Science and Engineering, University of West

Bohemia specializes in the research of brain activity

using the methods of electroencephalography (EEG)

and event related potentials (ERP). Because large

data are obtained during EEG/ERP experiments we

were facing a problem with their long term storage

and management. We solve this problem by

developing a custom solution (named EEG/ERP

Portal) based on a relational database, application

logic and a web interface. The EEG/ERP Portal

enables registered users to store and manage

experiments (including raw data, metadata or

experimental scenarios).

Since we currently work on the registration of

the EEG/ERP Portal as a recognizable neuroscience

data source within the NIF portal (NIF, n. d.) we

need to describe EEG/ERP experiments using

a suitable ontology.

Since the current World Wide Web lacks

a description of data semantics (expressed by

ontologies) an extension called the Semantic web

(Berners-Lee, 2001) is being developed. The

Semantic web uses a triple oriented representation

described by Resource Description Framework

(RDF). Since expressivity of RDF schema is

insufficient, an extension called Ontology Web

Language (OWL) was introduced. Both RDF and

OWL can use XML syntax; richer semantic

relationships can be expressed by OWL.

Despite advantages that the Semantic web

brings, current software systems are usually

developed using object oriented languages. Data are

usually stored in a relational database. Since there

are differences in semantic richness between these

approaches it is necessary to ensure a suitable

mapping.

This paper introduces EEG/ERP domain

ontology with online data/metadata serialization.

Some semantic gaps between object-oriented code

and its semantic web representation are bridged by

extension of object-oriented code using Java

annotations. The mapping of these annotations to the

Semantic web output is provided by the

transformation framework described in this paper.

2 EEG/ERP PORTAL

The EEG/ERP Portal is a solution using a layered

architecture according to the MVC design pattern.

Data are stored into the relational database (Oracle

11g). The persistent layer is created by POJO

350

Ježek P. and Mou

cek R..

SEMANTIC WEB IN EEG/ERP PORTAL - Extending of Data Layer using Java Annotations.

DOI: 10.5220/0003731303500353

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2012), pages 350-353

ISBN: 978-989-8425-88-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

objects. Object-relational mapping is ensured by the

Hibernate framework.

The application layer ensures processing of user

requests, managing user accounts and user groups

according to user privileges. The layer is

implemented using the Spring framework (includes

Spring Core, Spring Security and Spring MVC).

This layer also contains a module for the dynamic

generation of the Semantic web structure from data

stored in the database mapped to POJOs according

to a search agent request.

The presentation layer is created by a set of JSP

pages translated into a HTML output shown in

a user web browser.

The EEG/ERP Portal preview is in Figure 1, the

full system specification is in (Ježek and Mouček,

2009).

Figure 1: EEG/ERP Portal

3 OBJECT ORIENTED CODE TO

SEMANTIC WEB MAPPING

3.1 OWL and OOP Differences

There are fundamental differences in richness of

semantics between OWL and OOP. OWL is based

on description logic and an open world assumption

while OOP deals with closed world assumptions. It

means that if some information is not present in an

object oriented code it is considered to be false. By

contrast if some information is not present in an

OWL document, it may be true.

3.2 Framework Selection

We tested several frameworks that provide

a mechanism for transforming an object oriented

code (classes and their attributes) to an RDF or

OWL output. From the tested tools we selected

JenaBean (JenaBean, n. d.) and OWL API (OwlApi,

n. d.). This selection and integration was described

in (Ježek and Mouček, 2010) and (Mouček and

Ježek, 2010). Using selected tools we are able to

sufficiently transform data from our EEG/ERP

portal to the Semantic web output (one side

transformation is used). Since the object oriented

model has poorer semantics, capabilities of OWL

are not used. The next sections of the paper describe

a semantic extension of object-oriented code.

3.3 Existing Approaches

There are many frameworks that try to enrich an

object oriented code by adding missing semantics.

(Oren et al., 2007) developed a library ActiveRDF

for accessing RDF data from Ruby programs.

(Po-Huan et al., 2009) present the Semantic

Object Framework (SOF) as a solution that uses

embedded comments in source codes to describe

semantic relationships between classes and

attributes.

(Liu et al., 2007) developed a solution named

eClass. EClass is a Java class with changed syntax

containing additional semantic information about

methods and properties.

The tested frameworks have several important

disadvantages. The most of them are difficult to use

either because they do not include suitable means for

adding missing semantics, or they require

a modification of common programming syntax.

4 ANNOTATION FRAMEWORK

The specification of requirements originated from

the needs of the Semantic web output provided by

our EEG/ERP Portal. We expect that our solution

could serve a wide community of researchers that

use object oriented systems and need to generate

ontologies. To support this idea we decided to use

only the standard syntactic structures of the Java

programming language for data input, which is

extended by missing semantics, and the standard

Java Runtime Environment for the transformation

process.

We introduced an idea to extend the JenaBean

framework in (Ježek and Mouček, 2011). As the

next step we proposed a framework using Java

Annotations that extend the semantics of Java

classes and fields. This approach ensures that our

framework could be used not only by the experts in

the Semantic web field but also by the software

engineers who are able to prepare data objects

suitable for the transformation to the Semantic web

output. In addition, when a user has difficulties with

SEMANTIC WEB IN EEG/ERP PORTAL - Extending of Data Layer using Java Annotations

351

Figure 2: Library integration within EEG/ERP Portal.

a manual annotation of classes we provide

a graphical tool which can be used for loading Java

classes and annotating them easily.

4.1 Framework Integration

Figure 2 shows the main components of the library

and its integration within the EEG/ERP Portal. The

transformation library includes modified JenaBean

and the OWL API. This component serves as

a black-box; we provide it as a single library, so it

could be used in various systems.

4.2 Transformation Library

The transformation library processes input POJO

objects and serializes them into an output OWL

structure. This processing includes parsing of Java

classes (with their methods and attributes) using the

Java Reflection API, creating an internal ontology

model and writing an output RDF model. This RDF

model is later processed by the OWL API, which

generates the corresponding OWL output. In

addition, the transformation into the internal

ontology model includes processing of Java

annotations and enrichment of the internal model.

5 PRELIMINARY RESULTS

5.1 OWL Constructs

We enriched the JenaBean framework by designing

and implementing a new set of transformations from

Java annotations into OWL constructs, e. g. Property

restriction (allValuesFrom, someValuesFrom,

cardinality), Versioning (versionInfo, priorVersion,

incompatibleWith...), and Annotation properties

(label, comment, seeAlso ...). A more detailed

specification of these constructs is in (OWL, n.d.).

In the next section we describe an example of

mapping of the selected OWL constructs.

5.2 Mapping Example

Let us suppose a Java class named Person. We can

e.g. annotate this class using @RdfType that

determinates the name of the class in the output

OWL structure. In addition we can define e.g.

Equivalent construct (@EquivalentClass

annotation). Later we can e. g. determinate the

corresponding class using @SameAs annotation.

Specifically, suppose the following Java class:

@RdfType("Person")

@EquivalentClass("http://www.kiv.zcu.cz

/measured_person")

@SameAs("http://www.kiv.zcu.cz/eegerpPe

rson")

public class Person {

@Id

private int personId;

private String givenname;

//get and set methods

}

This code is serialized into the output OWL

structure where we can see the following constructs:

 Declaration of the class name:

<Class

IRI="http://www.kiv.zcu.cz/Person"/>

</Declaration>

 Definition of equivalent classes:

HEALTHINF 2012 - International Conference on Health Informatics

352

<Class

IRI="http://www.kiv.zcu.cz/Person"/>

<Class

IRI="http://www.kiv.zcu.cz/measured_per

son"/>

</EquivalentClasses>

 Definition of the same individuals:

<NamedIndividual

IRI="http://www.kiv.zcu.cz/Person"/>

<NamedIndividual

IRI="http://www.kiv.zcu.cz/eegerpPerson

"/>

</SameIndividual>

6 CONCLUSIONS

Currently the domain description using a specific

ontology is discussed in many scientific fields.

These ontologies can serve as structures for

recognizable data sources. The Semantic web, which

is based on domain ontologies, is suitable for

machine processing. OWL is used for expressing the

Semantic web. Although the idea of the Semantic

web is promising several disadvantages have to be

solved. Mostly OWL is not considered to be

a software programming language in contrast with

the object oriented programming that is not intended

for construction of ontologies.

Since common software systems are usually

based on object oriented languages, scientific

community is facing the problem how to ensure

a suitable mapping.

We had to deal with the same issue when

ontology in EEG/ERP domain was built. Only one

side transformation (from an object oriented code to

an ontology web language) was solved (it is easier

than any reverse transformation). However, there are

several semantic gaps that are needed to be solved.

We investigated several existing solutions described

in this paper.

We presented a custom solution based on Java

annotations that adds missing semantics into an

object oriented code and developed a framework that

processes such a code and provides an OWL

serialization. The integrated JenaBean framework

was enriched by a new set of transformations into

OWL constructs. Our solution uses a common

programming language and common technologies;

hence it can be immediately deployed.

Our future work includes a full registration of the

EEG/ERP portal as a recognizable data source

within the NIF portal. Simultaneously we plan to

provide and implement a full description of all OWL

constructs using Java annotations.

ACKNOWLEDGEMENTS

The work was supported by the UWB grant SGS-

2010-038 Methods and Applications of Bio- and

Medical Informatics

REFERENCES

Neuroscience Information Framework (NIF). (n. d.).

Retrieved May 20, 2011, from http://www.neuinfo.

org/

Berners-Lee, T., 2001. The Semantic Web. In Scientific

American (pp. 34-43).

Ježek, P., Mouček, R. 2010. Database of EEG/ERP

experiments. In HEALTHINF 2010 - Proceedings of

the Third International Conference on Health

Informatics. (pp. 222-227).

Mouček, R, Ježek, P., 2010. System for Storage and

Management of EEG/ERP Experiments – Generation

of Ontology. In 12

International Conference on

Enterprise Information System, Volume 1 (pp. 415-

420)

Ježek, P., Mouček, R., 2010. EEG/ERP Portal – Semantic

Web Extension. In Second Global Congress on

Intelligent Systems (pp. 392-395)

Oren, E., Delbru, R., Gerke, S., Haller, A. and Decker S.,

2007. ActiveRDF: object-oriented semantic web

protramming, In Proceedings of the 16

international

conference on World Wide Web (pp. 817-824)

Po-Huan, Ch., Chi-Chuan, L., Kuo-Ming, Ch., 2009.

Integrationg Semanic Web and Object-Oriented

Programming for Cooperative Desig, In Journal of

University Computer Science, vol. 15, no. 9

Liu, F., Wang, J., Dillon, S. T., 2007. Web Information

Representation, Extraction and Reasoning based on

Existing Programming Technology, In Computational

Inteligence 37 (pp. 147-168)

JenaBean, n.d. Retrieved May, 2011, from

http://www.ibm.com/developerworks/java/library/j-

jenabean.html

OwlApi, n.d. Retrieved May, 2011, from

http://owlapi.sourceforge.net/

Ježek, P., Mouček, R., 2011. Transformation of object-

oriented code into semantic web using Java

annotations. In 13

International Conference on

Enterprise Information System, (pp. 207-210)

OWL Web Ontology Language Overview (OWL), n.d.

Retrieved May, 2011, from http://www.w3.org/

TR/owl-features/

SEMANTIC WEB IN EEG/ERP PORTAL - Extending of Data Layer using Java Annotations

353
