GENERATING PHONEMES FROM WRITTEN THAI USING

LEXICAL ANALYSIS BASED ON REGULAR EXPRESSIONS

Leo van Moergestel

and John-Jules Meyer

HU University of Applied Sciences Utrecht, Utrecht, The Netherlands

Utrecht University, Utrecht, The Netherlands

Keywords:

Natural Language Processing, Thai Language, Romanization of Written Thai.

Abstract:

This document describes the approach and techniques used in software that has been developed to generate

phonemes from written Thai. This software has been used to generate the phonetic transcription of Thai

words in a Thai-Dutch dictionary. The most important part of this software is a lexical analyzer based on

regular expressions for matching patterns in the Thai writing system. Because most software tools that use

regular expressions are still based on the 7-bit ASCII set, a mapping of Thai characters to ASCII-characters

has been used.

1 INTRODUCTION

The written form of words, the so called orthogra-

phy, differs in some languages from the pronuncia-

tion. Especially English uses the written form ough

at least for seven different sounds as can be shown in

the sentence: ”Though a rough cough and hiccoughs

ploughed through him, he houghed the horse with

thorough thoughtfulness.” For these languages it is

difﬁcult, if not impossible, to generate the pronunci-

ation sounds in a written form using the international

phonetic alphabet (IPA) (Samuel, 1983), except for

the situation where a list of phonetic representations

for every single word is available. For languages like

Spanish and Italian the situation is a bit better, though

it is still a hard problem to generate what is called

the transcription. By transcription we mean the broad

transcription that is used in dictionaries, not the nar-

row transcription that is used in studying dialects or

differences in pronunciation of the same word among

different people using that word. In the current paper,

transcription of Thai is discussed, but the techniques

and approaches could be useful for other non roman

based writing systems.

2 FLEX

Flex (Levine, 2009) is a tool to build scanners and

stands for fast lexical analyzer. Flex is based on an

older tool called lex. A scanner is a program which

recognizes lexical patterns in text. To use ﬂex one has

to write a ﬂex source ﬁle where the most important

part consists of rules. These rule are pairs containing

a regular expression and an action for the scanner to

perform when the regular expression is matched. By

using ﬂex, the ﬂex source ﬁle can be converted to a

C program ﬁle that can be compiled by a C compiler

thus producing the scanner.

A regular expression is a pattern describing a set

of text strings. A regular expression is said to match a

text if the text is a member of the set described by the

regular expression. A good treatment of regular ex-

pressions can be found in (Friedl, 2006). The theory

of regular expressions is based on formal languages

and ﬁnite state machines. (Hopcroft et al., 2006).

In the current work the most important part is the

development of regular expressions that match with

patterns of written Thai. By using these expressions

in ﬂex rules we can generate output from our scan-

ner. This output explains the structure or blueprint of

the Thai text. If the structure is known, it is easy to

generate phonemes for the given text.

3 THE THAI WRITING SYSTEM

The Thai language has its own alphabet consisting of

44 consonants (Campbell and Shaweevongs, 1956).

The vowels are a separate set of symbols that are

sometimes combined to represent other vowels or

306

van Moergestel L. and Meyer J..

GENERATING PHONEMES FROM WRITTEN THAI USING LEXICAL ANALYSIS BASED ON REGULAR EXPRESSIONS.

DOI: 10.5220/0003735603060311

In Proceedings of the 4th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2012), pages 306-311

ISBN: 978-989-8425-95-9

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

vowel combinations (diphthongs). Finally there is a

set of extra symbols that can be used to mark the tone

of a syllable but also to suppress the sound of a syl-

lable or character. Thai is a tonal language that has

5 tones, low, medium, high, rising and falling. For

speakers of a language that does not use tones, it is

rather difﬁcult to get used to a tonal language. The

Thai writing system is capable to express the tone of

a certain syllable. So syllables with different tones

are also written in a different way. A word consists

of one or more syllables. Every syllable has its own

tone. Here are some important rules of the Thai writ-

ing system:

• All consonant characters can be at the start of a

syllable, but a few consonants are not used at the

end of a syllable;

• A syllable can have an inherent short ’a’ vowel

sound;

• A syllable can have an inherent short ’o’ vowel

sound;

• A syllable end can be considered living or dead

and this fact inﬂuences the tone;

• A vowel symbol (or group of symbols represent-

ing a vowel or diphthong) cannot be used on its

own, it should always have an accompanying con-

sonant character or a consonant cluster. This is the

consonant representing the beginning of the sylla-

ble;

• Vowels can have a long or short duration

• Depending on the vowel symbol, the written po-

sition of the vowel can be before, after, above or

under the consonant it is belonging to;

4 CLASSIFICATION OF THE

SOUNDS IN SPOKEN THAI

In this section we will focus on the sounds of spo-

ken Thai. For this section, it is important to under-

stand what we are trying to accomplish. When we

have a word written in Thai, we want a classiﬁca-

tion or blueprint for the syllables of this word. This

means that after classiﬁcation we have information

for a word in a standardized form. The role of the

symbols, both consonants and vowels, for each sylla-

ble is clear. Consider a word consisting of two sylla-

bles our aim is to produce a classiﬁcation that looks

like this string:

< SaaV bbEcc >< SxxV yyEzz >

Where aa...zz represent numbers for identiﬁcation

purposes. S stands for starting consonant, V for vowel

sound, and E for end consonant for that syllable. The

set of S types includes consonant clusters and special

cases where we do not use a consonant at the begin-

ning of a syllable. The same thing is true for the end

consonants though that set of possibilities is signif-

icant smaller for the Thai language. So in our no-

tation every syllable classiﬁcation starts with < and

ends with > and uses a ﬁxed format.

4.1 Consonants

At the start of a syllable the following situations are

possible:

• A single consonant sound consisting of one Thai

character.

• A cluster of two consonants. All possible conso-

nant clusters are summarized in table 1

• A single consonant sound consisting of two Thai

characters. This is mostly the case where a con-

sonant named hoh-heep is used to inﬂuence the

tone of the syllable. In Thai this character in this

situation is called hoh-nahm.

• No consonant sound at the beginning, though

there is a Thai consonant character (oh-ang) to

carry the vowel symbol that cannot stand on its

own. Sometimes the aforementioned situation re-

sults in a glottal stop at the beginning of a syllable.

The end of a syllable is rather simple. There are only

13 possibilities of a single consonant sound. Three

of them are only used in loanwords, mostly from En-

glish origin. The possibilities are summarized in ta-

ble 3. Remark that the occlusives are unreleased ﬁ-

nals in contrast to western European languages where

these occlusives are mostly released. Table 2 shows

the notation we use for the classiﬁcation of the end

consonants.

Table 1: Possible start clusters.

unaspirated aspirated

kr kl kw khr khl khw

pr pl phr phl

tr thr

Table 2: End consonant types.

E00 no end consonant

E01 glottal stop

E02 end consonant

E03 end consonant and start of next syllable

The type of consonant at the beginning of a sylla-

ble as well as the ending of a syllable will inﬂuence

the tone.

GENERATING PHONEMES FROM WRITTEN THAI USING LEXICAL ANALYSIS BASED ON REGULAR

EXPRESSIONS

307

Table 3: All possible syllable ends.

k m w f (loan words)

p n j s (loan words)

t ng no sound l (loan words)

glottal stop

4.2 Vowels

The Thai writing system uses a special symbol set to

express vowel sounds. A vowel or vowel combina-

tion can use one or more symbols of this set. Even

some consonant symbols are used as vowels or in

combination with vowel characters. The patterns for

these vowels play an important role is our scanner, be-

cause it will clearly indicate the beginning consonant

or consonant cluster of a syllable.

4.3 Special Symbols

Special symbols are used to mute a character, repeat

a word or denote the tone of a syllable.

4.4 Properties of the Thai Writing

System

The Thai writing system is capable of expressing the

tone as well as the sound of a vowel. By carefully

analyzing written Thai, it is possible to generate most

of the information for a transcription, there are how-

ever situation where this transcription is ambiguous.

These situations must be taken care of before scan-

ning. Also special constructions should be taken in

account by the scanner.

5 DESIGN OF THE SCANNER

The scanner is based on lexical analysis of written

Thai and is done in a sequence of passes. To use

ASCII based tools, like lex and its GNU derivative

ﬂex we made a transcription to ASCII characters. The

scanner focuses on a character string generated by the

a pass called prelex. This pass maps the consonants

and vowels in the syllables of a Thai word to ASCII

characters. The following sequence of passes is used

(in parenthesis is the name of the tool that is respon-

sible for the action taken).

1. in the ﬁrst pass the Thai string to parse is dupli-

cated (dupthai). This is done because our analy-

sis will result in an abstract classiﬁcation of the

syllables. To construct the transcription, we need

the original Thai text for extra information like the

tones of the syllables;

2. The duplicated string is converted to an ASCII

based representation. Some Thai characters with

identical properties are represented by the same

ASCII character (prelex);

3. the next step is called ”dining vowels” (dinvow).

In Thai, a vowel is always attached to one or more

consonants. In this step we generate part of the

classiﬁcation of the sounds by letting these vowel

symbols absorb the consonant(s) they belong to.

That is the reason why this step is called ”dining

vowels”. When this step is completed, all written

vowels are classiﬁed together with a substantial

amount of consonants.

4. There is now a partial transcription to consonant

and vowel types, but there are still consonants left.

Some of these dangling consonants have inher-

ent vowel sounds depending on the situation of

a closed or an open syllable. This pass tries to

solve this situation by looking at the number of

consonants and the position in the string. (ﬂex-

pass). Another possibility is that these consonant

are closing consonants for a syllable that is par-

tially converted in step 2. Finally a scan is done to

close all unclosed patterns. If there are syllables

that were classiﬁed as possibly closed syllables in

the classiﬁcation a ! symbol is used. If this sym-

bol is now followed by the start of a new syllable

i.e. <, the ! symbol is replaced by an > denoting

the end of the syllable.

All steps are simple commands or tools. On a Unix

based system, these commands are operating in a so

called pipeline.

dupthai i | prelex | dinvow | flexpass o

After applying these commands, where i is the in-

put ﬁle and o the output, the classiﬁcation is done.

6 SCANNER DETAILS

Because the most complex parts are implemented us-

ing ﬂex, this section will focus on the passes using

ﬂex (i.e. dinvow and ﬂexpass). Of these two pases,

dinvow is the most complex part and has 252 patterns

with related actions pairs. To make the source better

readable and also maintainable a set of macro deﬁni-

tions has been introduced.

S [YWHoGChKlsmTtPpwRLSNfc]

E [GChKlsmTtPwRLSY]

ot [1-4]?

Hn H[sYRLWN]

Kc [GCK][RLW]

Pc [Ppw][RL]

ICAART 2012 - International Conference on Agents and Artificial Intelligence

308

S is the set of possible start consonants, E the set of

possible end consonants and ot an optional tone mark

symbol. Hn shows all possible combinations of Hoh-

nahm with other consonants. Kc is a shorthand for all

possible K-clusters and Pc for the possible P-clusters.

A possible pattern action pair is:

{S}M{ot}{E} printf("<S01V03E02>");

If the scanner detects a single start consonant, repre-

sented by the macro {S}, followed by a vowel sym-

bol, represented here by M, with one or zero tone

marks, given by the macro {ot} and an end conso-

nant that is in the set of possible end consonants {E}

it will output <S01V03E02 >.

Another possible pattern action pair is:

e{Kc}I{ot}Y printf("<S04V27!");

The pattern matches a K-cluster Kc in combina-

tion with a compound vowel symbol, represented

here by e-IY (where the dash is the place of the

start consonant or cluster), with one or zero tone

marks, the action will be the generation of the out-

put <S04V27E02!. This syllable could be complete,

but there is also a possibility of an end consonant. In

ﬂexpass this situation will be solved. This is also a

ﬂex based scanner, but uses less patterns than dinvow.

The actions of ﬂexpass will be discussed in the exam-

ple of the next section.

7 EXAMPLES

To explain in more detail the working of the scan-

ner, in this section two examples will be given. Let

us start with the famous ”Hello world” example. In

written Thai Hello world looks like and is

pronounced sawatdee lohk, phonetic [sawatdi: lo:k].

These are the steps from the scanner to come to a

blueprint where this phonetic result can be derived

from. First the Thai string is duplicated with dupthai

and then prelex makes a translation of Thai characters

to standard ASCII characters. When the duplication

of the original Thai text is ignored, this results in:

[SWMSmIOLG]

The [ and ]-signs are used as delimiters. Every char-

acter in this string represents a Thai symbol, a Thai

vowel or a set (mostly with one member) of Thai con-

sonants. Now we are ready to use dinvow to detect

the vowels and associated consonants. The result is:

[S<S01V03E02><S01V10!<S01V18!G]

In this phrase, three vowel-symbols in written Thai

are involved. The ﬁrst one always needs an ending

consonant, so this syllable is ﬁnished. For the sec-

ond one there is the possibility of an end consonant

and the same is true for the third one. This is the rea-

son why these syllables are not closed by a > but by

a ! symbol. At the beginning as well as at the end

there is still a dangling consonant (symbol S and G).

In the next step (ﬂexpass) the dangling consonant at

the beginning is treated as a single syllable with in-

herent a-sound and no end consonant. The dangling

consonant at the end is combined with the possibly

not closed syllable before it. The syllable denoted by

S01V10 appears to have no possible end consonant

so the combination !<will be translated to ><. The

result is:

[<S01V02E00><S01V03E02><S01V10E00>

<S01V18E02>]

Now we have a complete blueprint of the phrase. In

the section ’sound generation’ a tool will be intro-

duced to make a phonetic representation. The difﬁcult

part however is now done by the scanner.

As a second example we consider the word

meaning sour and pronounced priaw. This word con-

sists of a consonant cluster pr in combination

with a compound vowel consisting of four symbols

and a tone symbol. To make things a bit more

complicated, this compound vowel also uses conso-

nant symbols. Using prelex the Thai characters are

translated to:

[exxI2YW]

Using dinvow gives the result:

The meaning of this blueprint is: this is a word with

a p-consonant cluster (being either pl or pr accord-

ing to table 1) and a compound vowel V33 (having

the sound iaw) and no end consonant. In this case

no operation is done by the next pass of the scanner,

because the blueprint is already ﬁnished.

8 ERROR RECOVERY

There are situations where the scanner fails to produce

the correct result. In this case a hint can be given to

tell the scanner where the end of a syllable actually is.

The scanner uses these hints as extra information and

this could result in a correct transcription. Hinting is

used in words where the syllables are not easy to de-

termine. An example is the word: birdcage that is

written in Thai using only ﬁve consonants and

is pronounced [krong nok]. In this situation the scan-

ner has a choice of using an inherent ’o’ between two

consonants or an inherent ’a’ after every single con-

sonant or perhaps a combination of inherent ’o’ and

’a’ sounds. K-R-NG-N-K should however result in

GENERATING PHONEMES FROM WRITTEN THAI USING LEXICAL ANALYSIS BASED ON REGULAR

EXPRESSIONS

309

krong nok, so only two inherent o-sounds. By hinting

we tell the scanner that there is a syllable end after the

NG. In that case the scanner separates this composite

word in two parts that it will handle correctly. After

using prelex, this results in:

[GRs<Z00>sG]

Where <Z00>represents the separator. Using this in-

formation, the next passes of the scanner are capable

of generating the correct blueprint for two syllables.

[<S04V01E02><Z00><S01V01E02>]

If hinting does not give the expected result the Thai

word is added to a ﬁle of exceptions where the correct

set of sounds is entered by hand. In an extra pass at the

beginning all these exceptions are searched for and

the sounds are already added and marked as complete.

In the scanning system some decisions are beyond

any doubt but some decisions are just good guesses.

It is also possible to fall back on these guesses to pro-

duce another transcription in case of an erroneous re-

sult. This means that the aforementioned hints can

also be generated by the system itself in a so called su-

pervised learning situation, where an operator trains

the system. This could be a useful add-on for this

system.

9 SOUND GENERATION

By using the classiﬁcation in combination with the

original text, the sounds can be generated. This is

done by a separate program that can use any table of

transcription codes to generate the ﬁnal transcription

including a way to denote the tones of the syllables.

This transcription can be based on the IPA, thus pro-

ducing a phonetic transcription, but depending on the

transcription code used, the transcription can also be

adjusted to the phonemes of a certain target language.

This results in a phonemic transcription. For exam-

ple in Dutch the phonetic sound for [u:] is written as

[oe], while in English it is written [oo], in German or

Spanish [u] and in French [ou].

10 RESULTS

Figure 1 shows a dictionary entry (van Moergestel,

1995b) (van Moergestel, 1995a). The transcription

is produced by the aforementioned scanner in combi-

nation with the sound generation program that trans-

lates according to a given set of sound representa-

tions including the tones. Because this is table-driven,

one can produce different types of transcription as

is explained in the previous section. A dictionary

could use the IPA notation (Tingsabadh and Abram-

son, 1993). In the given example dashes, located at

the baseline of the text, are used to indicate the low

tone of both syllables.

[ fa rang] buitenlander

(blanke), westerling guave

(vrucht)

Figure 1: Entry in the Thai-Dutch dictionary.

The small dictionary where this system is used for

contained 6932 Thai words. The ﬁle of exceptions

contains 373 words, meaning that 95 % can be tran-

scribed by the parser. We used 630 words with hints to

guide the scanner to the correct transcription. These

results are summarized in table 4.

Table 4: Results.

Number of words 6932 100%

Exceptions 373 5%

Hints 630 9%

11 RELATED WORK

The Royal Institute of Thailand has published he

Royal Thai General System of Transcription (RTGS).

This system describes how the transcription of Thai

words in the Latin alphabet should be done. Re-

search in the ﬁeld of Thai romanization has also

been addressed, among others, by Aroonmanakun.

In (Aroonmanakun et al., 2004) a system is described

that can be used for transcribing English words, us-

ing the Thai writing system. By the same author

a tool for transcription of Thai based on the system

RTGS has been developed (Aroonmanakun, 2010).

This is an interactive tool where the user enters Thai

and the transcription is generated. Jucksriporn and

Sornil developed a system for syllabiﬁcation of Thai.

They used a minimum cluster-based trigram statisti-

cal model (Jucksriporn and Sornil, 2011). This sys-

tem could be used in combination with the system

presented in the current paper and be useful for au-

tomatic hinting.

The system we present in the current paper can be

seen as a generic approach for transcribing in gen-

eral. This approach is based on a transposition of

non ASCII characters to the ASCII-set and thus stan-

dard parsing tools that are used for compiler building

can be used. By ﬁrst generating a classiﬁcation of

the syllables, the ﬁnal transcription can be generated

in a ﬂexible way. Most other transcription systems

ICAART 2012 - International Conference on Agents and Artificial Intelligence

310

use huge pattern bases and the transcription is gener-

ated without an intermediate classiﬁcation. The sys-

tem presented in this paper is compact, fast and it is

possible to use the RTGS as well as symbols of the

IPA or a transcription that maps the Thai sounds to a

writing system that is familiar for readers of a certain

language.

12 CONCLUSIONS

The Thai writing system is much better apt for auto-

matic transcription than most European writing sys-

tems. Especially in English it is not possible to gen-

erate the sounds of pronunciation by using simple

and consequent rules. The system presented here is

useful for bulk transcription as needed in dictionar-

ies but could be used as an intermediate system for

generating sounds of the spoken language. The topic

of future research will be the possibility of improve-

ments of the scanner by studying patterns and classes

of words in the exceptions and hinted groups.

REFERENCES

Aroonmanakun, W. (2010). ling.arts.chula.ac.th/tts. De-

partment of Linguistics, Chulalongkorn University,

Bangkok.

Aroonmanakun, W., Thapthong, N., Wattuya, P., Kasisopa,

B., and Luksaneeyanawin, S. (2004). Automatic thai

transcriptions of english words. Southeast Asian Lin-

guistics Society Conference 14 (SEALS 14), Bangkok,

Thailand, May 19-21, 2004.

Campbell, S. and Shaweevongs, C. (1956). The Funda-

mentals of the Thai Language. Paragon Book Gallery,

New York.

Friedl, J. E. F. (2006). Mastering Regular Expressions, third

ed. O’Reilly Media, Sebastopol, CA.

Hopcroft, J. E., Motwani, R., and Ullman, J. (2006). Intro-

duction to Automata Theory, Languages and Compu-

tation, third ed. Addison Wesley.

Jucksriporn, C. and Sornil, O. (2011). A minimum cluster-

based trigram statistical model for thai syllabiﬁcation.

CICLing (2)2011 p493-505.

Levine, J. R. (2009). Flex and Bison. O’Reilly Media, Se-

bastopol, CA.

Samuel, J. T. B. (1983). Introduction to Practical Phonet-

ics. Summer Institute of Linguistics, England.

Tingsabadh, M. R. K. and Abramson, A. S. (1993). Thai.

Journal of the International Phonetic Association, 23,

pp 24-28 doi:10.1017/S0025100300004746.

van Moergestel, L. (1995a). Woordenboek Nederlands-Thai

(Dutch-Thai dictionary). Nangsue.

van Moergestel, L. (1995b). Woordenboek Thai-Nederlands

(Thai-Dutch dictionary). Nangsue.

GENERATING PHONEMES FROM WRITTEN THAI USING LEXICAL ANALYSIS BASED ON REGULAR

EXPRESSIONS

311
